1. By Abu-ul-hasan ALi
Roll# 451
ADP(S.T)
Tarbela Dam

2. History of Tarbela Dam
Basic Orientation
 Tarbela Dam is one of
the world’s largest earth
and rock filled Dam.
 Greatest water
resources
The Dam is built on
one of the World’s
largest rivers – the Indus
known as the “Abbasin”
or the father of rivers.

3. History of Tarbela Dam
 The World Bank
accepted Tarbela Dam
Project in 1965
 WAPDA was entrusted
with its execution on behalf
of Govt. of Pak
 General consultant of
WAPDA is HAZARA
ENGINEERING COMPANY
 Built between 1968 and
1976

4. THE PROJECT – MAIN FEATURES
 Project Consists of a 9,000
(2,743 meters) long.
 It has a volume of 138,600,000
cubic yards (106,000,000 cubic
m).
 Reservoir capacity of
11,098,000 acre-feet
(13,690,000,000 cubic m).
 The dam is 469 feet (143 m)
high.
 The Dam is 8,997 feet (2,743 m)
wide at its crest.
 The total spillway capacity is
1,500,000

5. Power Stations

6. Power Stations

7. Power House
Inside Power House

8. Thanks to all !!!
 The End
