A sun-synchronous orbit is a near-polar orbit that allows a satellite to pass over any point on a planet's surface at the same local solar time. This orbit is useful for imaging satellites because it provides consistent lighting conditions. Satellites in this orbit cross the equator around 10:30am local time when shadows are most visible. Examples of satellites in sun-synchronous orbits include Landsat, SPOT, and IRS.

1. Sun-synchronous orbit

2. Sun-synchronous Orbit
• A Sun-synchronous orbit (SSO), also called
a helio synchronous orbit, is a nearly polar orbit
around a planet, in which the satellite passes over
any given point of the planet's surface at the
same local mean solar time.
• More technically, it is an orbit arranged so that
it processes through one complete revolution
each year, so it always maintains the same
relationship with the Sun.

4.  Near polar orbit chosen in such a way that the satellite
always passes overhead at the same time.
 The inclination angle is between 98 and 990 to achieve this.
 Most sun synchronous orbits cross the equator at mid-
morning at around 10:30 hours local solar time.
 At this time the sun angle is low and the resultant shadows
reveal terrain relief.
 In addition to day-time images, this orbit also allows the
satellite to record night-time images (thermal or radar)
during the ascending phase of the orbit at the dark side of the
earth.
 Examples of Polar and SS orbits: Landsat, SPOT and IRS

5. Applications
 A Sun-synchronous orbit is useful
for imaging, reconnaissance, and weather satellites, because
every time that the satellite is overhead, the
surface illumination angle on the planet underneath it is
nearly the same.
 This consistent lighting is a useful characteristic
for satellites that image the Earth's surface in visible or
infrared wavelengths, such as weather and spy satellites,
and for other remote-sensing satellites, such as those
carrying ocean and atmospheric remote-sensing
instruments that require sunlight.
 For example, a satellite in Sun-synchronous orbit might
ascend across the equator twelve times a day, each time at

6. Sun-synchronous orbit from a top view of
the ecliptic plane with local solar time (LST)
zones for reference and a descending
node of 10:30. The LST zones show how the
local time beneath the satellite varies at
different latitudes and different points on

7.  Special cases of the Sun-synchronous orbit are
the noon/midnight orbit, where the local mean solar time of
passage for equatorial latitudes is around noon or midnight,
and the dawn/dusk orbit, where the local mean solar time of
passage for equatorial latitudes is around sunrise or sunset, so
that the satellite rides the terminator between day and night.
Riding the terminator is useful for active radar satellites, as the
satellites' solar panels can always see the Sun, without being
shadowed by the Earth. It is also useful for some satellites with
passive instruments that need to limit the Sun's influence on
the measurements, as it is possible to always point the
instruments towards the night side of the Earth. The
dawn/dusk orbit has been used for solar-observing scientific
satellites such as TRACE, Hinode and PROBA-2, affording them
a nearly continuous view of the Sun.

8. Technical details
 Sun-synchronous orbits are mostly selected for Earth
observation satellites, with an altitude typically between 600
and 1000 km over the Earth surface. Even if an orbit
remains Sun-synchronous, however, other orbital
parameters such as argument of periapsis and the orbital
eccentricity evolve, due to higher-order perturbations in the
Earth's gravitational field, the pressure of sunlight, and
other causes. Earth observation satellites, in particular,
prefer orbits with constant altitude when passing over the
same spot. Careful selection of eccentricity and location of
perigee reveals specific combinations where the rate of
change of perturbations are minimized, and hence the orbit
is relatively stable – a frozen orbit, where the motion of
position of the periapsis is stable.The ERS-1, ERS-2
and Envisat of European Space Agency, as well as
the MetOp spacecraft of EUMETSAT and RADARSAT-2 of
