Network Protocol Analysis
•Download as PPTX, PDF•
0 likes•951 views
This document discusses network protocol analysis. It provides an introduction to network protocols, packet sniffing, and the structure of IP packets and TCP segments. Specifically, it outlines the key components of IP packet headers including version, header length, total length, identification, flags, time to live, protocol, and source and destination addresses. It also describes the fields in a TCP segment header, including source/destination ports, sequence numbers, acknowledgement numbers, flags, window size, checksum, and urgent pointers. Finally, it briefly explains the three-way handshake used to establish connections in TCP.
