NetApp provides an enterprise-grade all-flash storage solution called AFF (All Flash FAS) that delivers flash performance and data services. SolidFire is another all-flash storage platform in NetApp's portfolio that is designed for large-scale infrastructure and can guarantee performance to thousands of applications through its quality of service features. The document discusses the benefits of flash storage and how NetApp's solutions help customers transform their data centers and lower costs through flash innovation like inline data compaction in ONTAP 9.

1. NetApp All Flash storage
​Enterprise-Grade All Flash Solution
© 2016 NetApp, Inc. All rights reserved. --- NETAPP CONFIDENTIAL ---1
​Jan Jiskra
​Country Manager CZ/SK
​2016

2. Agenda
• All-flash landscape
• AFF
• SolidFire® within the flash portfolio
• What is SolidFire?
2

3. TCO quickly becoming the major driver for flash
3
16% maintenance savings *
76% power and cooling cost savings *
63% rack space savings *
48% simplicity of
administration savings *

4. Business imperatives
IT is transforming to meet the needs of the digital business
Drive growth and
new revenue
Move with
speed and scale
Reduce the cost
of taking risks
Value of flash for IT
Flash dramatically
simplifies the
environment
Radically changes
the economics
of the data center
Delivers
performance to all
environments
4

5. Enterprise IT is transforming globally
Public cloud has raised the bar
5
Regardless of the name, desired outcomes are the same: next-generation data center
Software-Defined
Data Center Infrastructure 2.0 Cloud Computing
Private Cloud Third Platform
Agile Scalable Automated Predictable
Next-Generation Data Center

6. Gartner: “Select SSAs for all primary applications and workloads, but do not restrict their usage for other applications.”
Performance
Low
Performance and Capacity
High
Cheap and deep
Numberofapplications
Performance at any cost
First-generation AFAs
Virtualization
Engineering
Home directories
Database
Public/private cloud, IaaS
Next-generation AFAs
The next wave – flash going mainstream
6
Flash is almost the same cost as SAS and is exceeding HDD capacity

7. All-flash array landscape
Scale
Scale features
 Cloud OS (i.e., OpenStack)
 Seamless scale-out
 App consolidation with QoS
 Full automation (enables aaS and SDDC)
 Next-gen virtualization (VVOL, containers, etc.)
Data services features
 Integrated data protection and
synchronous replication
 Integrated flash disk cloud support
 Integrated enterprise app support
 Multiprotocol
Data Services
Speed features
 Consistent, ultralow latency
 Single-application focused
 Leverage application services
 $/IOPS/RU
Speed
EF-
Series
All Flash
FAS
SolidFire®
7

8. Applying all flash to your data center
8
Flash for the Next Generation Data
Center
Requirements constantly changing
Consumes the most capital and time
Performance and Capacity
Public/Private Cloud, IaaS
Cheap and Deep (Object/File)
Backup/Archive/Video Streaming
Extreme Performance
Transactional Processing/
Trading Platforms
#ofApplications
Flash V1
PCI Flash
Low HighP e r f o r m a n c e
NetApp® Hybrid Storage
StorageGRID®
AltaVault™
All Flash FAS
Services
Scale
NetApp Data Fabric
EF-Series
SolidFire®

9. The NetApp flash portfolio
For the all-flash storage market
9
All Flash FAS
Performance plus robust
data management optimized
for shared general IT
 Scale-up and scale-out
 NDO tiering with hybrid
 SAN and NAS support
 Secure multitenancy
 Infrastructure deployments
9
Scale-out service-oriented
flash storage for next-
generation applications
SolidFire
 Linear scale-out
 SLA guarantees via QoS
 Hardware and software
deployment
 Cloud/XaaS deployments
(third platform and webscale)
Ultralow-latency storage
platform for application silos
EF560
 Scale-up capacity
 Extremely low latency
 High IOPS/$/rack U
 Application-centric acceleration

10. All Flash FAS: flash performance + enterprise-grade data services
Architecture natively suited for all flash
Optimized read and write
paths deliver high performance
NetApp® WAFL® file system
delivers inherent wear leveling
All-flash platform with richest data services
Seamless data management
across flash, disk, and cloud
Lower TCO through ease
of use and inline efficiencies
10

11. Start your data center transition with AFF
11
AFF A300
Speed
 20x faster response time
 12x higher IOPS
 Enables new business
opportunities
Simplicity/Economics
 1PB (effective) in 2U—11x
power and rack space
savings
 No tuning—reduced support
cost
 Serve data within 10
minutes
Flexibility
 SAN/NAS, flash/disk/cloud
 Mixed controllers and drives
 Broadest ecosystem
integration

12. AFF—what’s new
Increased performance
 7M IOPS—fastest unified AFA
 2x the IOPS at half the latency for Oracle database
 First to support both 40GbE and 32Gb FC connectivity
Better economics
 First to support multi-stream-write (MSW) SSDs—42%
increase in usable capacity combined with ADP
 Inline data compaction
 15TB SSD supported on all models
Simplified management
 Software encryption—NetApp® Volume Encryption
 Massively scalable NAS container—NetApp ONTAP®
FlexGroups
 Greater serviceability
12
High-End
Expandable
Midrange
AFF A300
AFF A700
New applications on flash

13. The impact of flash innovation
1PB of storage
10K high-performance HDDs
2+
racks
13
 <1ms latency performance to all data
 11 times smaller footprint
 11 times lower power consumption
 No tuning for performance
 6-month payback
1 1 PB in 2U shelf, using 15TB SSDs
NetApp® AFF
Radically change the economics of your data center

14. NetApp AFF: enterprise-grade data services anywhere
>7 million IOPS and 360PB of effective capacity
Cloud
Data Fabric
powered by
ONTAP®
AFF Hybrid FAS
Unified management across flash, disk, and cloud
Performance
Application
integration
Data protection
and security
Management
simplicity
14

15. NetApp® ONTAP® 9
Build your optimal storage without silos
 Upgrade hardware/software or scale up—without disrupting users
 Incorporate software-defined, cloud, and next-generation flash
15
 Scale out by intermixing your choice of flash and hybrid nodes
Scale Out by Adding Controllers
AFF AFF FAS
Scale Up
Individual
Controllers
FAS
Next-Generation
SSD
ONTAP Select
ONTAP Cloud

16. Inline data compaction—new in NetApp ONTAP 9
 Places multiple logical data blocks from the same volume into a single 4KB block
on storage
 Occurs after inline adaptive compression and inline deduplication, before writing to media
 Benefits
 Additional space savings for highly compressible data
 Space savings for very small I/Os and files (≤2KB) and for larger I/Os that have extensive “white
space”
 Provides 2 to 4 times the space savings that are achieved from inline compression alone for
database workloads—as high as 67:1 as a combined savings from compression and compaction
NetApp continues to innovate beyond compression and deduplication
16

17. SolidFire
What is SolidFire?
 SolidFire® is a scale-out all-flash storage platform designed
for large-scale infrastructure
What makes SolidFire unique?
 Our ability to manage storage performance independent of
capacity
 Our ability to guarantee performance to not just one
application but to thousands of applications within a single
storage platform
17

18. SolidFire
Proven in the world’s most demanding data centers
1818
Service Providers Large Enterprise

19. Guaranteed
Quality of Service
(gQoS)
Scale-out architecture
 4–100 nodes
 35TB–3.4PB usable capacity
 200k–7.5M controllable IOPS Industry-leading density
SolidFire
The all-flash storage platform built for the next-generation data center
19
Proven in the most demanding data centers

20. SolidFire
The all-flash storage platform built for the next-generation data center
20
Proven in the most demanding data centers
Simple all-inclusive pricing model
 No licensing of any features
(including snaps/clones, encryption,
sync/async replication)
Direct tier 3 support for every customer
 SolidFire® ActiveIQ monitoring and
ActiveSupport are proactive services that
are included
 Customers always talk to a 3rd-level
support engineer

21. Gartner CC 2014 + 2015
Highest rated all-flash array
21
1
SolidFire is Gartner’s highest scoring product for Overall Use Cases for the second consecutive year. That makes us the defending solid-state array champion.
In this year’s Critical Capabilities for Solid-State Arrays study, learn why SolidFire SF Series nodes received the highest product score for 5 out of 6 use cases
and understand how the SolidFire architecture compares against other all-flash arrays.
Online Transaction Processing
Server Virtualization
Virtual Desktop Infrastructure
High-Performance Computing
Analytics
SolidFire® SF Series Overall Score
ScoreCritical Capability SolidFire Rating
2
3.58
3.61
3.56
3.61
3.66
3.60
Source: Gartner (June 2015)
1
1
1

22. Scale-out
infrastructure agility
Guaranteed
quality of service
Complete
system automation
Global
efficiencies
Self-healing
high availability
All-flash storage platform for the next-generation data center
22

23. Can your all-flash array do this?
Deploy from bare metal to OS to OpenStack or VI
in 90 minutes (that’s compute, networking, and storage)?
Deploy 1000s of virtual machines without even looking at a
disk or controller configurations (dial it in and/or set policies)?
Implement VDI, databases, and test/dev on the same array
without any effect on each other (no noisy neighbors)?
SolidFire® agile infrastructure (reference architectures)
enables your data center cloud strategy
23

24. The SolidFire advantage for cloud infrastructure
 Streamlined
configuration
 Validated, tested
design
 Seamless
scalability
Deep
integration
Flexibility Lower risk
Decreased
time to market
 Modularized design
 Use what makes
sense for the
customer
 Seamless
integration of
storage into
management and
orchestration
 Intelligent offload
of tasks to storage
 Move from
procurement to
provisioning more
quickly
 Minimize
nonrecurring
engineering
24

25. NetApp flash leadership and innovation
*Compares Q1FY’17 and Q1FY’16
All-flash controllersRevenue growth*
573+
$775M Annual
run rate
PB of flash
Metrics through July 2016
25

26. © 2016 NetApp, Inc. All rights reserved. NetApp confidential. Limited use.26

27. Thank you
jan.jiskra@netapp.com
27
