This document discusses maximizing power point tracking from a photovoltaic (PV) panel using a fuzzy logic controller. A 1.1 kW PV panel and boost converter system is designed. A fuzzy logic controller is used to track the maximum power point from the PV panel in order to improve efficiency. The fuzzy logic controller provides a duty cycle input to the boost converter based on the PV panel voltage to transfer maximum power to the load. Simulation results show the output voltage is maintained at 230V with an average efficiency of 98.5% using this system.
