System Information
• Hydrant System:
Being one of the oldest but yet the most effective and common fire fighting solution, a well
designed and a well laid out Hydrant System forms the backbone of the entire fire fighting system. It
comprises of heavy duty above & underground piping with accessories. External and Fire Escape
Hydrant valves are provided at every strategic location. A fire hydrant is a pipe that allows water to
flow from a water main with the control of a valve in order to put out a fire.
Fire Hydrant Protection System is designed to fight fire of huge proportions, in all classes of
risks. It is designed to be in operation even if a part of the affected structure collapses.
Dry barrel and wet barrel are the two kinds of Fire Hydrants. The wet barrel fire hydrant holds
a constant water supply, while the dry barrel fire hydrant needs to have a valve release to let water in.
It is designed to provide rapid access to water in the event that a fire breaks out. Fire Brigade
Connections are installed as standalone systems which act like building-specific fire hydrants,
providing fire protection which will be readily available to fire fighters.
Guidelines and approval for Hydrant System are available from various national and
international organizations like: NBC, NFPA, TAC, IS, FM and Local Fire Authorities.
Components of the System:
o Fire Fighting Pumps & Accessories
o Piping
o Panels
o Landing Valves
o Hoses
o Couplings
o Hose Reel
o Branch Pipes & Nozzles
o Fire Brigade Connections
o Wiring & Instrumentations
o Maintenance Valves
FIRE KNOCK
FIRE KNOCK
FIRE KNOCK

2. _______________________________________________________________________________________
Keshavji Jadhavji Trust Blgd., 2
nd
Floor, Office No. 86, 112 Yusuf Meherali Road, Masjid Bunder, Mumbai – 3.
Tel: +91-22-2345 4498 Mob: +91-98670 64498 Email: fireknock09@gmail.com Web: www.fireknock.com
Operational Information
• Hydrant System:
Fire hydrant installation consists of a system of pipe work connected directly to the water
supply main to provide water to each and every hydrant outlet and is intended to provide water for
the firemen to fight a fire. The water is discharged into the fire engine form which it is then pumped
and sprayed over fire. Where the water supply is not reliable or inadequate, hydrant pumps should be
provided to pressurize the fire mains.
A typical hydrant installation fed directly from water main and pressurized by fire pumps is shown as
below:
The Fire Pump Station comprises of the Jockey Pump, Electric Driven Pump and Stand-by
Diesel driven Pump. The pump operation is automatic through pressure switch contacts based on
header Pressure in the hydrant network. The delivery of the jockey pump and main pump is connected
to the common delivery header.
The Fire Hydrant Line is always kept pressurized with water. In the event of any minor pressure
drop in the system, the pressure reaches the preset pressure setting for Jockey pump, the Jockey
pump will start automatically to compensate the pressure differential. In the event of opening one or
more hydrant valve for fighting fire the Jockey pump will not be able to make up this water loss
resulting in further pressure drop. When the falling pressure reaches the Preset pressure for main
pump, the main pump will start automatically. In case of electric supply failure, stand by diesel engine
driven pump will come into operation.
A fire-fighter connects a fire hose to the fire hydrant and releases a valve to get water from the
water main. Most fire hydrants are designed to allow not less than 250 gallons (950 litres) of water to
flow through the hydrant per minute.
