This document describes a face recognition system created by three students from Vietnam National University, Hanoi. The system uses a PDBNN algorithm for face detection and recognition. It first applies discrete Fourier transforms to input images before using neural network filters and merging to detect faces. Eye localization then precisely finds eyes before facial features are extracted using principal component analysis, Fisher's linear discriminant, or local feature analysis. The extracted feature vectors are input to face recognition to identify individuals. Potential applications of the system include security, access control, surveillance, photo tagging, and digital photography.
Kubernetes & AI - Beauty and the Beast !?! @KCD Istanbul 2024
Face recognition system
1. VIETNAM NATIONAL UNIVERSITY, HANOI
ĐẠI HỌC
CÔNG NGHỆ
University of Engineering & Technology
Face Recognition System
Members: Van-Ly Nguyen
Van-Khai Ngo
Ngoc-Sinh Nguyen
2. VIETNAM NATIONAL UNIVERSITY, HANOI
ĐẠI HỌC
CÔNG NGHỆ
University of Engineering & Technology
Face Recognition System
Members: Van-Ly Nguyen
Van-Khai Ngo
Ngoc-Sinh Nguyen
3. ĐẠI HỌC
CÔNG NGHỆ Outline
Introduction
Architecture
Discrete Fourier Transform (DFT)
Face Detection
Eye Localization
Facial Feature Extraction
Face Recognition
Applications
Conclusion
5/23/12 Signals and Systems 3
4. ĐẠI HỌC
CÔNG NGHỆ
Introduction
Are they the
same
people?
5/23/12 Signals and Systems 4
5. ĐẠI HỌC
CÔNG NGHỆ Architecture
Figure 1: System configuration of the PDBNN face recognition system
5/23/12 Signals and Systems 5
6. ĐẠI HỌC
CÔNG NGHỆ
Discrete Fourier Transform (DFT)
Transformation of input images from time domain to frequency domain
5/23/12 Signals and Systems 6
7. ĐẠI HỌC
CÔNG NGHỆ
Discrete Fourier Transform (DFT)
Fourier Transform in 2 – D images
5/23/12 Signals and Systems 7
8. ĐẠI HỌC
CÔNG NGHỆ
Discrete Fourier Transform (DFT)
• Low frequencies contain much more information which is
suitable for recognition than higher ones
• Low frequencies are likely to be found at four corners of
image spectrum
5/23/12 Signals and Systems 8
9. ĐẠI HỌC
CÔNG NGHỆ
Discrete Fourier Transform (DFT)
Coefficient selection is one of the most
important parameters in any recognition
technique.
Some coefficient selection methods:
• Low frequency coefficient selection methods
• Square selection methods
• Curcular selection methods
5/23/12 Signals and Systems 9
10. ĐẠI HỌC
CÔNG NGHỆ
Face Detection
Face Detection consists of two stages:
• Neural – Network Filters
• Merging overlapping detection
Figure 2: The basic algorithm used for face detection.
5/23/12 Signals and Systems 10
11. ĐẠI HỌC
CÔNG NGHỆ
Face Detection
The result of face detection:
5/23/12 Signals and Systems 11
12. ĐẠI HỌC
CÔNG NGHỆ
Eye Localization
• Eye Localization is activated when face detection has found face
in the input image.
• Since the purpose of eye localization is to normalize facial
patterns into a format the recognizer can accept, eye locations
need to pinpoint with much higher precision than face location
5/23/12 Signals and Systems 12
13. ĐẠI HỌC
CÔNG NGHỆ
Facial Feature Extraction
• Facial feature extraction techniques can be classified into two
categories are feature – invariant approaches and template –
based approaches
Facial Feature Extraction
Feature – Invariant Template-Based
Approaches Approaches
5/23/12 Signals and Systems 13
14. ĐẠI HỌC
CÔNG NGHỆ
Facial Feature Extraction
• Feature – Invariant Approaches
This type of algorithm looks for structural features that exist
even when the pose, viewpoint, or lighting condition vary
The system can use various features including width of the
head; distance from eyes to eyes, top of the head to eyes, eyes
to the nose; and distance from eyes to the mouth
• Template – based approaches
The algorithm designs one or several standard face templates
(usually frontal face template) either manually or by learning
from examples in the image database
5/23/12 Signals and Systems 14
15. ĐẠI HỌC
CÔNG NGHỆ
Facial Feature Extraction
One important issue for statistical template matching is the curse
of dimensionality.
Principal Component Analysis
(PCA)
Fisher's Linear Discriminant
Efficient Extraction (PLD)
Local Feature Analysis
(LFA)
5/23/12 Signals and Systems 15
16. ĐẠI HỌC
CÔNG NGHỆ
Face Recognition
Accept
Feature Face
Vectors Recognition
Reject
5/23/12 Signals and Systems 16
17. ĐẠI HỌC
CÔNG NGHỆ
Applications
Sercurity
5/23/12 Signals and Systems 17
18. ĐẠI HỌC
CÔNG NGHỆ
Applications
Access control Surveillance
5/23/12 Signals and Systems 18
19. ĐẠI HỌC
CÔNG NGHỆ
Applications
Photo tagging in Social Network Digital Photography
5/23/12 Signals and Systems 19
20. ĐẠI HỌC
CÔNG NGHỆ
Conclusion
The System uses the PDBNN algorithm
Face detection and Eye localization are two very
important parts in the system
PDBNN can perform these two processes at very
high accuracy, more effective than other
algorithms
The system is more and more popular.
5/23/12 Signals and Systems 20
