1) Researchers developed a microcontroller-based multi-frequency ultrasonic pulser receiver system that can generate pulsed radio frequencies of different frequencies as selected from a PC without needing to change oscillators.
2) The system uses an ATMega16 microcontroller to control an oscillator chip that can generate frequencies from 1-10MHz as commanded by the PC. It then generates pulse repetition frequencies to create tone bursts that are amplified and transmitted into samples via a transducer.
3) Received echoes are amplified and processed by the receiver section before being displayed on an oscilloscope. The system was tested on water and ethanol samples and able to measure ultrasonic velocities accurately at different frequencies.
