A numeral system (or system of numeration) is a writing system for expressing numbers; that is, a mathematical notation for representing numbers of a given set, using digits or other symbols in a consistent manner. It can be seen as the context that allows the symbols "11" to be interpreted as the binary symbol for three, the decimal symbol for eleven, or a symbol for other numbers in different bases.

1. Presentation Topic
Convers i on
of
Numbers

2. What we are going to
explain
• Conversion between Binary & Decimal.
• Conversion between Decimal & Hexadecimal.
• Conversion between Hexadecimal & Binary.
• Conversion between Decimal & Octal.
• Conversion between Octal & Hexadecimal.
• Conversion between Binary & Octal.

3. The possibilities:
Hexadecimal
Decimal Octal
Binary
Conversion Among Bases

4. SystemSystem BasBas
ee
SymbolsSymbols
Used byUsed by
humanshumans
??
Used inUsed in
computerscomputers
??
DecimaDecima
ll
1010 0, 1, … 90, 1, … 9 YesYes NoNo
BinaryBinary 22 0, 10, 1 NoNo YesYes
OctalOctal 88 0, 1, … 70, 1, … 7 NoNo NoNo
HexadeHexade
cimalcimal
1616 0, 1, …0, 1, …
9,9,
A, B, …A, B, …
FF
NoNo NoNo
Common Number SystemsCommon Number Systems

5. Binary to Decimal
Hexadecimal
Decimal Octal
Binary

6. • Technique
–Multiply each bit by 2n
, where n is the
“weight” of the bit.
–The weight is the position of the bit,
starting from 0 on the right.
–Add the results.
Binary to Decimal

7. (101011)2 => 1 x 20
= 1
1 x 21
= 2
0 x 22
= 0
1 x 23
= 8
0 x 24
= 0
1 x 25
= 32
(43)10
Bit “0”
EXAMPLE

8. Decimal to Binary
Hexadecimal
Decimal Octal
Binary

9. Example

10. Example

11. Hexadecimal
Decimal Octal
Binary
Hexadecimal to BinaryHexadecimal to Binary

12.  TechniqueTechnique
 Convert each hexadecimal digit to a 4-bitConvert each hexadecimal digit to a 4-bit
equivalent binary representationequivalent binary representation
Hexadecimal to BinaryHexadecimal to Binary

13. ExampleExample
1 0 A F1 0 A F
0001 0000 1010 11110001 0000 1010 1111
10AF16 = 00010000101011112
10AF16 = ?2

14. Hexadecimal
Decimal Octal
Binary
Binary to HexadecimalBinary to Hexadecimal

15.  Technique
› Group bits in fours, starting on
right
› Convert to hexadecimal digits

16. 10101110112 = ?16
10 1011 1011
2 B B
10101110112 = 2BB16

17. Hexadecimal
Decimal Octal
Binary
Octal to DecimalOctal to Decimal

18. Octal to DecimalOctal to Decimal
 TechniqueTechnique
• Multiply each bit by 8Multiply each bit by 8nn
, where, where nn isis
the “weight” of the bit.the “weight” of the bit.
• The weight is the position of theThe weight is the position of the
bit, starting from 0 on the right.bit, starting from 0 on the right.
• Add the resultsAdd the results

19. 7248 =>4 x 80
= 4
2 x 81
= 16
7 x 82
= 448
(468)10

20. Example

21. Decimal to Octal
Hexadecimal
Decimal Octal
Binary

22.  Technique
 Divide by 8
 Keep track of the remainder
Decimal to Octal

23. ExampleExample

24. Hexadecimal
Decimal Octal
Binary

26. Hexadecimal
Decimal Octal
Binary
Binary to Octal

27. Binary to Octal
• Technique
–Group bits in threes, starting on right
–Convert to octal digits

28. 10110101112 = ?8
1 011 010 111
1 3 2 7
10110101112 = 13278
Example

29. Hexadecimal
Decimal Octal
Binary

30. Technique
Multiply each bit by 16n
, where n is the
“weight” of the bit
The weight is the position of the bit, starting
from 0 on the right
Add the results

32. ABC16 => C x 160
= 12 x 1 = 12
B x 161
= 11 x 16 = 176
A x 162
= 10 x 256 = 2560
274810
ExampleExample

33. Hexadecimal
Decimal Octal
Binary

34.  Technique
Divide by 16
Keep track of the remainder

36. Hexadecimal
Decimal Octal
Binary

37. Technique
Use binary as an intermediary

38. 10768 = ?16
1 0 7 6
001 000 111 110
2 3 E
10768 = 23E16

39. Hexadecimal
Decimal Octal
Binary

40. Technique
Use binary as an intermediary

41. 1F0C16 = ?8
1 F 0 C
0001 1111 0000 1100
1 7 4 1 4
1F0C16 = 174148

42. That’s all for our today’s presentation

43. Any question

44. Before We Go…….

45. Thanks to everyone for your kind support
Good Bye
