NetWork Design Question2.) How does TCP prevent Congestion Dicuss.pdfoptokunal1
NetWork Design Question
2.) How does TCP prevent Congestion? Dicuss the information identifying congestion in the
network as well as the mechanism for reducing congestion?
Solution
Congestion is a problem that occurs on shared networks when multiple users contend for access
to the same resources (bandwidth, buffers, and queues).
Transmission Control Protocol (TCP) uses a network congestion-avoidance algorithm that
includes various aspects of an additive increase/multiplicative decrease (AIMD) scheme, with
other schemes such as slow-start to achieve congestion avoidance.
The TCP congestion-avoidance algorithm is the primary basis for congestion control in the
Internet.
Congestion typically occurs where multiple links feed into a single link, such as where internal
LANs are connected to WAN links. Congestion also occurs at routers in core networks where
nodes are subjected to more traffic than they are designed to handle.
TCP/IP networks such as the Internet are especially susceptible to congestion because of their
basic connection- less nature. There are no virtual circuits with guaranteed bandwidth. Packets
are injected by any host at any time, and those packets are variable in size, which make
predicting traffic patterns and providing guaranteed service impossible. While connectionless
networks have advantages, quality of service is not one of them.
Shared LANs such as Ethernet have their own congestion control mechanisms in the form of
access controls that prevent multiple nodes from transmitting at the same time.
Identifying:
Congestion is primarily reflected by a conventional user feeling-- slowness. This statement
reflects the change in the network effective flow, that is the time required to transmit an entire
data from one point to another. The effective flow doenot exist as such, it consists in reality of
three seperate indicators:
*Latency:the effective flow is inversely proportional to the latency.
*Jitter:it is latency variation over time, impacts by influencing the flow latency
*Loss Rate:the theoritical bandwidth is inversely proportional to the square root of the loss rate
These Congestion symtoms allow us to rely on objective indicators to characterize it.
Mechanism to reduce congestion:
The standard fare in TCP implementations today has four standard congestion control algorithms
that are now in common use. Their usefulness has passed the test of time.
The four algorithms, Slow Start, Congestion Avoidance, Fast Retransmit and Fast Recovery are
described below. (a) Slow Start
Slow Start, a requirement for TCP software implementations is a mechanism used by the sender
to control the transmission rate, otherwise known as sender-based flow control. This is
accomplished through the return rate of acknowledgements from the receiver. In other words, the
rate of acknowledgements returned by the receiver determine the rate at which the sender can
transmit data. When a TCP connection first begins, the Slow Start algorithm initializes a
.
New Proposed Contention Avoidance Scheme for Distributed Real-Time Systemspaperpublications3
Abstract: One method to handle collisions in a contention based distributed system is to optimize collision detection and subsequent recovery. An alternative method to handle collisions in a contention based system is to attempt to avoid them. Some systems may utilize a strict scheduling guideline to identify who may use which resources when. Other systems may have the senders listen to the channel immediately prior to transmitting and determine suitable times to transmit. A primary challenge in Distributed Real-Time Systems applications is how to carry out data given source-to-sink, end-to-end deadlines when the communication resources are scarce. A new scheme resolves collisions and tries to reduce the number of potential collision events. In this paper, we develop New Avoiding Contention Scheme that delays data packet transmission nonlinearly during forwarding for a duration that correlates with their remaining deadline and distance to the destination, and avoiding the contention in bursty traffic by using multi-path routing.
KALMAN FILTER BASED CONGESTION CONTROLLERijdpsjournal
Facing burst traffic, TCP congestion control algorithms severely decrease window size neglecting the fact
that such burst traffics are temporal. In the increase phase sending window experiences a linear rise which
may lead to waste in hefty proportion of available bandwidth. If congestion control mechanisms be able to
estimate future state of network traffic they can cope with different circumstances and efficiently use
bandwidth. Since data traffic which is running on networks is mostly self-similar, algorithms can take
advantage of self-similarity property and repetitive traffic patterns to have accurate estimations and
predictions in large time scales.
In this research a two-stage controller is presented. In fact the first part is a RED congestion controller
which acts in short time scales (200 milliseconds) and the second is a Kalman filter estimator which do
RTT and window size estimations in large time scales (every two seconds). If the RED mechanism decides
to increase the window size, the magnitude of this increase is controlled by Kalman filter. To be more
precise, if the Kalman filter indicates a non-congested situation in the next large time scale, a magnitude
factor is calculated and given to RED algorithm to strengthen the amount of increase.
