Item Category Material Description Material Long Description
Material Number
9COM/9CAT
1
Chemicals
(Drilling Fluids)
POLYVINYL/POLYACRYLIC
COMPOUNDS TO 400F
ADMIXTURE: DRILLING MUD; 25 KG PAPER SACKS; SHIPMENT OF PRODUCT SHALL
CONFORM TO SAUDI ARAMCO EXPORT ADMIXTURE DRILLING MUD; POWDER
FORM,POLYACRYLIC,FOR FILTRATE REDUCER FLUID LOSS ADDITIVE,CO-POLYMER
OF POLYVINYL COMPOUNDS,25 KG OR 50 LB BAG,API 13A,HIGH TEMPERATURE
ENVIRONMENT 150 DEG C (300 DEG F) TO 205 DEG C (400 DEG F), SHIPMENT OF
PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL
NOTE: THE CONSTRUCTION OF THE MULTI-WALLED PAPER BAG (CONTAINER)
SHALL BE AS FOLLOWS: 1ST PLY 50 LB MIN. NATURAL KRAFT PAPER (INTERIOR
PLY) 2ND PLY 50 LB MIN. NATURAL KRAFT PAPER 3RD PLY SEPARATE INNER BAG
LINER, HIGH DENSITY ORIENTED AND CROSS-LAMINATED INNER LINER (TUBULAR
SHAPE) MADE OF POLYETHYLENE RESIN MATERIAL WITH A MINIMUM WALL
THICKNES OF 0.1 MM. 4TH PLY 50 LB MIN. NATURAL KRAFT PAPER. 5TH PLY 60 LB
MIN. NATURAL KRAFT PAPER WET STRENGTH (EXTERIOR PLY) THE BAG MUST BE
VALVE/SPOUT TYPE, COMPLETELY SEALED, MOISTURE AND WATER PROOF.
1000021602
Vendor Liaison Group (VLG)/Supplier Registration Unit
Room A-119, Saudi Aramco Box 87 - North Park 1
Dhahran 31311, Kingdom of Saudi Arabia
Phone: +966-13-874-0799 ; General Line: +966-13-874-0958; Fax: +966-13-874-0015/0335
Email: Vendor-registration@aramco.com; OR On-line registration: https://onboarding.aramco.com
2015 1Saudi Aramco: Company General Use

Material Number
9COM/9CAT
2
Chemicals
(Drilling Fluids)
LIQUID GILSONITE
GILSONITE: LIQUID GILSONITE; BORE HOLE STABILIZING AND FLUID LOSS
CONTROL AGENT ADMIXTURE DRILLING MUD; BLEND OF DISPERSED COUPLED
GILSONITE AND LIGNITE FORM,SUSPENDED SURFACTANT LIQUID,FOR BOREHOLE
STABILIZING, AND FLUID LOSS CONTROL AGENT PRIMARY FUNCTION IS TO
PREVENT STUCK PIPE, REDUCE FLUID LOSS AND CREATE STRONG BOREHOLE
CONDITIONS WITH EXCEPTIONAL HTHP AND DYNAMIC FLUID LOSS CONTROL,
NON- TOXIC, ENVIRONMENTALLY SAFE ALSO FUNCTIONS AS A SHALE STABILIZER
AND HAS A BROAD PSD FOR SEALING MICRO- FRACTURES. NON SHEENING,55
GAL/DRUM,APPEARANCE, BLACK SUSPENSION.FREEZING POINT, -4 F(-20 C)TO -13
F(-25C). FLASH POINT,F, >200. SOLUBILITY IN WATER, MISCIBLE. LUBRICITY TEST,
TORQ REDUCTION :5% AND 12% AT 4 PPB RESPECTIVELY IN STANDARD SAUDI
ARAMCO WATER BASE MUD SYSTEM, USING OFI MODEL EP/LUBRICITY TESTER.
FILTRATION CONTROL, API FILTRATE LOSS:6.0 ML/30MIN AT 4PPB HTHP FILTRATE
LOSS AT 250 F AND 500 PSI:16 ML/30MIN AT 8PPB SHALE ACCRETION TEST, <5%
IN STANDARD SAUDI ARAMC KCL POLYMER MUD. AT 8 PPB IN STANDARD KCL
POLYMER MUD:1. IMPROVE HTHP FLUID LOSS: 20% MINIMUM AT 250 F AND 500
PSI 2. IMPROVE LUBRICITY: 15% MINIMUM, BY USING OFI MODEL EXTREME
PRESSURE (PE)/LUBRICITY TESTER 3. SHALE ACCRETION TEST, <5%.
1000021608
3
Chemicals
(Drilling Fluids)
ZINC OXIDE
ADMIXTURE: DRILLING MUD; 50 LB BAG; ADMIXTURE DRILLING MUD; FINE
POWDER FORM,ZINC OXIDE (ZNO), 90% (MINIMUM) PURE, SP. GR.,5.5,FOR
HYDROGEN SULFIDE SCAVENGER FOR DRILL PIPE CORROSION PROTECTION IN
FRESH WATER OR BRINE FOR DRILLING & COMPLETION OPERATIONS,25 KG OR 55
LB BAGS,API 13A.
1000021671
4
Chemicals
(Drilling Fluids)
MUTUAL SOLVENT
AGENT: WELL STIMULANT; SURFACE TENSION REDUCER; SOLUBLE IN
HYDROCARBONS; DISPERSIBLE IN FRESH AGENT WELL STIMULANT; FOR SURFACE
TENSION REDUCER FOR HYDROFLUORIC ACID SOLUTION ADDITIVES,ETHYLENE
GLYCOL MONOBUTYL ETHER MUTUAL SOLVENT,LIQUID FORM,55 GAL
DRUM,SOLUBLE IN HYDROCARBONS, DISPERSIBLE IN FRESH WATER, ACID &
BRINE, 150 DEG F FLASH POINT (TOC).
1000021973
5
Chemicals
(Drilling Fluids)
THINNER OBM
ADDITIVE DRILLING FLUID; LIQUID FORM,POLYOLEFIN/ORGANIC SULFONATE
BLEND, FATTY ACID DERIVATIVES OR OTHER CHEMICAL THAT DO SAME
FUNCTION.,FOR TO LOWER REHEOLOGICAL PROPERTIES FOR SYNTHETIC OR OIL
BASE FLUIDS.,55 GALLON DRUM,APPEARANCE: AMBER LIQUID, COLOUR: DARK
AMBER, ODOUR/TASTE: SLIGHT, S.G: 0.9-0.96, INSOLUBLE, FLASH POINT: MORE
THAN 190 F DEG.
1000823699

Material Number
9COM/9CAT
6
Chemicals
(Drilling Fluids)
OIL WETTING AGENT
ADMIXTURE, DRILLING MUD: INVERTED EMULSION MUD COMPONENTS,
DRILTREAT (STABILIZER), AMBER-COLOR VISCOUS ADMIXTURE DRILLING MUD;
VISCOUS LIQUID, AMBER COLOR FORM,ORGANIC SURFACTANT OIL-WETTING
AGENT,FOR OIL BASE MUDS,5 GAL /PAIL,AN ORGANIC SURFACTANT OIL-WETTING
AGENT FOR OIL BASE MUDS. ITS PRIMARY FUNCTION IS TO ACT AS AN OIL-WET
WEIGHTING MATERIAL AND DRILL SOLIDS TO PREVENT WATER WET SOLIDS, TO
IMPROVE FILTERATION CONTROL, RHEOLOGICAL STABILITY AND EMULSION
STABILITY. NORMAL TREATMENTS RANGE 0.25 û 2.0 LBS/BBL DIRECTLY TO THE
SYSTEM AND IT IS TEMPERATURE STABLE GREATER THAN 350 DEG F (176 DEG C).
PHYSICAL APPEARANCE: AMBER COLOR, VISCOUS LIQUID. SG: 0.93 û 1.0. FLASH
POINT: > 200 DEG F (93 DEG C) BY PMCC.
1000022171
7
Chemicals
(Drilling Fluids)
ORGANOPHILIC LIGNITE
ADMIXTURE, DRILLING MUD: INVERTED EMULSION MUD COMPONENTS OIL-
DISPERSIBLE ORGANOPHILIC LEONARDITE 25 KG (50 LB) ADMIXTURE DRILLING
MUD; 25 KG (55 LB) BAG,INVERTED EMULSION MUD COMPONENTS, OIL-
DISPERSIBLE ORGANOPHILIC LEONARDITE, 25 KG (55 LB) BAG: MOISTURE GRATER
THAN 8% WT. PARTICLE SIZE 100% WT PASSING THROUGH 70 US MESH
IMPURITIES (SAND, LIME, GYPSUM-..ETC) 2% WT, MAX.
1000022172
8
Chemicals
(Drilling Fluids)
SECONDARY EMULSIFIER
POLYAMINATED FATTY ACID & PARTIAL AMIDE OF ADMIXTURE DRILLING MUD;
BLEND OF POLYAMINATED FATTY ACID & PARTIAL AMIDE OF POLYAMINE WITH
METHANOL,FOR SECONDARY EMULSIFIER AND WETTING AGENT FOR INVERTED
EMULSION DRILLING FLUIDS,55 GAL PER DRUM,SECONDARY EMULSIFIER AND
WETTING AGENT FOR INVERTED EMULSION DRILLING FLUIDS. A BLEND OF
POLYAMINATED FATTY ACID AND PARTIAL AMIDE OF POLYAMINE WITH
METHANOL, AUTHORIZED SAUDI ARAMCOÆS PERSONNEL WILL CARRY OUT
SAMPLING AND TESTING AS NEEDED. SPECIFIC GRAVITY @ 77 DEG F (25 DEG C)
0.95 - 0.96 FLASH POINT: HIGHER THAN 149 DEG F (65 DEG C) ACTIVE
INGREDIENTS: A. FATTY ACID & AMINE DERIVATIVES 65 - 70% B. ASPHALTIC-TYPE
MATERIAL NONE C. ACID NUMBER, 45 - 50 MG KOH/G.
1000022173

Material Number
9COM/9CAT
9
Chemicals
(Drilling Fluids)
PRIMARY EMULSIFIER
OXIDIZED TALL OIL & POLYAMINATED FATTY ACID, CLEAR, ADMIXTURE DRILLING
MUD; CLEAR FORM,A BLEND OF OXIDIZED TALL OIL AND POLYAMINATED FATTY
ACID,FOR PRIMARY EMULSIFIER FOR INVERTED EMULSION DRILLING FLUIDS,55
GAL PER DRUM,SPECIFIC GRAVITY @ 77 DEG F (25 DEG C) 0.94 - 0.95 FLASH
POINT: HIGHER THAN 149 DEG F (65 DEG C) ACTIVE INGREDIENTS: A: OXIDIZED
TALL OIL & FATTY ACID 65 - 70% B: ASPHALTIC-TYPE MATERIAL NONE C: ACID
NUMBER, 80 - 85 MG KOH/G.
1000022175
10
Chemicals
(Drilling Fluids)
LIQUID SPOTTING FLUID
ADMIXTURE, DRILLING MUD: INVERTED EMULSION MUD COMPONENTS, TO FREE
STUCK PIPES (EMULSIFIER), SPECIAL BLEND OF LIQUID, ADMIXTURE DRILLING
MUD; LIQUID FORM,SPOTTING FLUID,FOR SOAK SOLUTION FOR FREEING STUCK
PIPE,ORGANIC CHEMICAL CONCENTRATE OF EMULSIFIERS AND LUBRICANTS,208
L OR 55 GAL DRUM,CONCENTRATE TO BE MIXED WITH DIESEL OIL OR MINERAL
OIL TO FORM STABLE INVERT EMULSION TO HELP FREE DIFFERENTIALLY STUCK
PIPE. FLASH POINT: >190 DEG F.
1000022178
11
Chemicals
(Drilling Fluids)
FIBER, SWEEPING AGENT
ADMIXTURE: DRILLING MUD; WELLBORE CLEANING AGENT DRY PILLS, TREATED
POLYMERIZED SYNTHETIC FIBER; HOLE CLEANING AGENT ADMIXTURE DRILLING
MUD; DRY FORM,TREATED SYNTHETIC POLYPROPYLENE FIBER,FOR
TRANSPORTING DRILL CUTTINGS METAL SHAVINGS AND OTHER DEBRIS OUT OF
WELLBORE WHILE DRILLING,15 LBS PAIL,EASILY DISPERSABLE IN ALL DRILLING
FLUIDS, NON TOXIC, NON-CORROSIVE, NON-MAGNETIC, CHEMICALLY INERT AND
TEMPERATURE STABLE. COMPATIBLE IN WATER, DIESEL AND MINERAL OIL
FLUIDS. SPECIFIC GRAVITY, 0.9.
1000720919
12
Chemicals
(Drilling Fluids)
LUBRICANT - HIGH PH AND
DIVALENT BRINES
ADMIXTURE DRILLING MUD; CLEAR LIQUID FORM,WATER SOLUBLE
LUBRICANT,FOR REDUCES TORQUE, DRAG AND FRICTION IN WATER BASED
DRILLING MUDS,ND OF SURFACTANT MIXTURES POLYOLS DESIGNED FOR USE AS
MIUM LUBRICANT COMPATIBLE IN HIGH SALINE FLUIDS INCLUDING SATURATED
NACL, KCL, NABR, K-FORMATE CALCIUM CHLORIDE FLUIDS WITHOUT GREASING
OUT AND/OR CHEESING. STABLE OVER WIDE RANGE OF TEMPERATURE UP TO
325 F DEG. THE NORMAL (PMCC).
1000757580

Material Number
9COM/9CAT
13
Chemicals
(Drilling Fluids)
LUBRICANT SALT WATER MUD
AND BRINE
LUBRICANT; DRILLING MUD, ADDITIVE TYPE,AMBER LIQUID FORM,55
GAL/DRUM,LUBRICANT FOR SALT WATER BASED MUD AND BRINES, DISPERSED,
SEA WATER, SALT SATURATED, FORMATS, COMPLETION, WORKOVER FLUIDS.
USED WITH BRINES, ALSO, RECOMMENDED FOR DRILL-IN FLUIDS CONTAINING
HIGH AMOUNT OF SIZEABLE CALCIUM CARBONATE, SODIUM CHLORIDE OR
CALCIUM CHLORIDE.PHYSICAL STATE @ 20 C DEG: AMBER COLOR, FAINT ODOR,
POUR POINT IS -10 C DEG MAX, SP. GR. 1.002 G/CC, VISCOSITY @ 40 C DEG IS 120
MM2/S, FLASH POINT 230 C DEG, INSOLUBLE IN WATER, DOES NOT FORM
GREASING AND IT DOES NOT PHASE OUT. BOTTOM HOLE TEMP. LIMIT: 160 C
DEG(320 F), PH LIMIT MAX 10.5, REDIAGREEN EME SALT IS A MIXTURE OF FATTY
ACID, C1618 AND C18-UNSATURATED COMPOUNDS WITH 2,2,2-NITRILOTRI-
ETHANOL AND FATTY ACIDS, ESTERS WITH POLYOL. OTHER ASSOCIATED
ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL AND/OR ADVERSELY
AFFECTED FLUID PROPERTIES.
1000774613
14
Chemicals
(Drilling Fluids)
OIL IN WATER EMULSIFIER
ADMIXTURE DRILLING MUD; THICK LIQUID FORM,FOR EFFECTIVELY EMLSIFIES
HYDROCARBONS IN BOTH FRESH & SALT WATER. USE IN LOW DENSITY OIL IN
WATER BENTONITE MUD EMULSION,55 GAL (208 LITER) DRUM,OTHER
ASSOCIATED ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL AND/OR
ADVERSELY AFFECT FLUID PROPERTIES.
1000779780

Material Number
9COM/9CAT
15
Chemicals
(Drilling Fluids)
MODIFIED NON-IONIC STARCH
ADMIXTURE DRILLING MUD; WHITE, FREE-FLOWING POWDER FORM,STABILIZED
NON-IONIC STARCH DERIVATION,FOR TO CONTROL HIGH PRESSURE AND HIGH
TEMPERATURE FILTRATION CONTROL AND MINIMIZE DAMAGE TO THE
PRODUCTIVE FORMATION,MODIFIED STARCH 60-100%, SOLID, WHITE, SG 1.5,
STABILITY TEMPERATURE: 250 DEG F, BIODEGRADABLE, SOLUBLE IN WATER,50 LB
(22.7 KG) SACK,ENHANCES THE LOW SHEAR RATE VISCOSITY OF A FLUID
CONTAINING XANTHAN GUM BIO-POLYMER. POLYMER COMBINATION IS
SYNERGISTIC AND YIELDS IMPROVED STATIC SUSPENSION. FLUID COMPOSITIONS
MIXED WITH N-DRIL HT PLUS FILTRATION CONTROL AGENT CAN BE USED TO
DRILL INTO PAY ZONES AND UNDER REAM. IT CAN ALSO BE USED AS 'PRE' AND
'POST' GRAVEL PACK FLUID AND AS LOST CIRCULATION PILLS. SUITABLE FOR ALL
WATER-BASED DRILLING FLUIDS, WORKOVER AND COMPLETION FLUIDS
INCLUDING SEAWATER, POTASSIUM CHLORIDE, MAGNESIUM CHLORIDE SODIUM
CHLORIDE, SODIUM BROMIDE, CALCIUM BROMIDE AND ZINC BROMIDE: RESISTS
CALCIUM CONTAMINATION OVER A WIDE PH RANGE, SOLUBLE IN ACIDS AND
OXIDIZERS CONTAINER MUST BE PROPERLY LABELED WITH, VENDOR'S NAME,
MANUFACTURER'S NAME, LOCATION, PRODUCTION DATE AND BATCH NUMBER.
1000788390
16
Chemicals
(Drilling Fluids)
CALCIUM CARBONATE FLAKE
FINE
ADMIXTURE DRILLING MUD; FINE WHITE FLAKES FORM,SIZED CALCIUM
CARBONATE FLAKES,FOR USED AS BRIDGING AGENT TO CONTROL DRILLING
FLUID CIRCULATION LOSSES ESPECIALLY IN GAS DRILLING,CALCIUM CARBONATE
60-100 WT% AND CRYSTALLINE SILICA UP TO 0.1 WT%,MULTI-WALLED 50 LB PER
BAG,WHITE FLAKES, SG:2.7-2.8 AT 20 DEG, ACID SOLUBILITY(10-15% HCL)99%
MIN.
1000813534
17
Chemicals
(Drilling Fluids)
MEDIUM
ADMIXTURE DRILLING MUD; MEDIUM WHITE FLAKES FORM,SIZED CALCIUM
BAG,WHITE FLAKES, SG:2.7-2.8 AT 20 DEG, ACID SOLUBILITY(10-15% HCL)99%
MIN.
1000813690
18
Chemicals
(Drilling Fluids)
COARSE
ADMIXTURE DRILLING MUD; COARSE WHITE FLAKES FORM,SIZED CALCIUM
BAG,WHITE FLAKES, SG:2.7-2.8 AT 20 DEG, ACID SOLUBILITY (10-15% HCL) 99%
MIN.
1000813535

Material Number
9COM/9CAT
19
Chemicals
(Drilling Fluids)
TEMPERATURE
EXTENDER/STABILIZER
ADDITIVE DRILLING FLUID; LIQUID FORM,AMINOETHANOL,FOR POLYMER
TEMPERATURE EXTENDER/STABILIZER FOR WATER BASED DRILLING AND
COMPLETION FLUIDS BY REDUCING THE RATE OF BREAKDOWN OF POLYMERS BY
SLOWING/PREVENTING THE THERMAL DEGRADATION OF THE POLYMERS. THIS
GIVES A PRONOUNCED IMPROVEMENT IN TEMPERATURE STABILITY, ENABLING
POLYMER FLUIDS TO BE USED IN HOTTER WELLS. THE TEMPERATURE STABILITY
INCREASE BY MARGIN OF UP TO 70 DEG F. IT IS PARTICULARLY SUITED FOR USE IN
DRILLING, COMPLETION, WORKOVER AND PACKER FLUIDS.,55 GAL PER
DRUM,PPEARANCE: LIQUID COLOUR : COLORLESS GRAVITY :1.0- 1.02 ADD
SOLUBILITY IN WATER: SOLUBLE IN WATER BOILING POINT (C):> 142 C FLASH
POINT (C) : > 96 C PH : 11-12,CONTAINER MUST BE PROPERLY LABELED WITH
VENDOR'S NAME, MANUFACTURER'S NAME, GRAVITY: 1.0 - 1.02 LOCATION,
PRODUCTION DATE AND BATCH NUMBER. SAUDI SOLUBILITY IN WATER:
ARAMCO'S PERSONNEL WILL SOLUBLE IN WATER, BOILING CARRY OUT PROPER
SAMPLING POINT: > 142 DEG C, FLASH AND TESTING AS NEEDED. POINT: > 96
DEG C, PH: 11 - 12.
1000829739
20
Chemicals
(Drilling Fluids)
Temperature Stabilizer
ADDITIVE; DRILLING MUD TYPE,FOR FREE RADICAL SCAVENGER AND
TEMPERATURE STABILIZER,COLORLESS LIQUID FORM,200
LITERS/DRUM,FUNCTIONS BY SCAVENGING FREE RADICALS AND SLOWS DOWN
THERMAL DEGRADATION OF POLYMERIC COMPONENTS, SUCH AS XANTHAN
GUM, PAC AND STARCH, IN THE DRILLING FLUID WHICH ALLOWING THE
TEMPERATURE STABILITY TO BE EXTENDED BY UP TO 50 DEG F. NORMAL
TREATMENT: 2.0 TO 4.0 LB/BBL FLASH POINT : > 195 DEG. F, SPECIFIC GRAVITY :
1.05-1.15, SOLUBILITY : SOLUBLE IN WATER, ACTIVES % W/W 68 - 72, SG @ 20° C
1.05 - 1.15.
1000823316
21
Chemicals
(Drilling Fluids)
POLYSTYRENE COPOLYMER
BEADS
ADMIXTURE: DRILLING MUD; DRY, LUBRA-GLIDE BEADS; DIVINYL BENZENE
COPOLYMER; DRY, COARSE GRADE; FOR REDUCING TORQUE AND DRAG.
ADMIXTURE DRILLING MUD; DRY, COARSE FORM,AA POLYSTYRENE COPOLYMER
BEAD,FOR SOLID LUBRICANT, TO REDUCE TORQUE AND DRAG WHILE DRILLING.
CHEMICALLY INERT,22.7 KGS (55 LBS) /SACK,PARTICLE SIZE DISTRIBUTION RANGE:
100 TO 1000 MICRON. COMPRESSIVE STRENGTH: 16,000 PSI. SOFTENING
TEMPERATURE: > 260 C DEG.
1000720918

Material Number
9COM/9CAT
22
Chemicals
(Drilling Fluids)
GUAR GUM POWDER FORM 25
KG BAG
ADDITIVE DRILLING FLUID; CREAMY COLOURED POWDER FORM,PURE GUAR
GUM,FOR USED AS COMPETITIVE SUPPLEMENTARY VISCOSIFIER FOR QUICK
VISCOSITY SWEEPS BUILDER WHILE DRILLING SURFACE HOLES WITH WATER.,25
KG METAL BAGS,IT IS PARTICULARLY USEFUL FOR OFFSHORE DRILLING, AS IT CAN
BE ADDED DIRECTLY TO SEAWATER, , WHICH ELIMINATES THE NEED FOR LARGE
QUANTITIES OF FRESH WATER AS WELL AS THE TIME REQUIRED TO PREHYDRATE
BENTONITE. IT IS AN UNTREATED GUAR GUM AND IS NON-IONIC IN NATURE. IT
SHOWS EXCELLENT PERFORMANCE OVER A WIDE PH RANGE. IT'S
RECOMMENDED TO ADD BIOCIDE, IF GUAR GUM SOLUTION KEPT OVER A PERIOD
OF TIME. APPEARANCE: CREAMY COLOURED POWDER, ODOR: BEAN LIKE,
MOISTURE: 8.0% (MAXIMUM), PH: 8.0, ASH :1% (MAXIMUM), PARTICLE SIZE
THROUGH 200 MESH (75 MICRON): 95% (MINIMUM), BROOKFIELD VISCOSITY :
8000 CP (MINIMUM), (1% SOLUTION IN DISTILLED WATER AT 25 DEG. C, AFTER 24
HOURS (SPINDLE #4, 20 RPM), FANN VISCOSITY INITIAL 10 MINUTE: 42 CP
(MINIMUM), (2.00 GM / 350 MLS, IN SEA WATER, @ 511 SEC-1, F1 SPRING. SEA
WATER: 41.95 GM NACL IN 1000 MLS DISTILLED WATER.
1000824113
23
Chemicals
(Drilling Fluids)
POLYETHER POLYOL DEFOAMER
ADDITIVE DRILLING FLUID; LIQUID FORM,POLYETHER POLYOL,FOR DEFOAMER
USED IN BOTH FRESHWATER AND SALTWATER DRILLING FLUIDS SYSTEMS,5
GALLON PAIL,DEFOAMER USED IN BOTH FRESHWATER AND SALTWATER
DRILLING FLUIDS SYSTEMS,EFFECTIVE FOR REDUCING FOAM CAUSED BY WATER
SOLUBLE GLYCOL PRODUCTS, CONTAINS NO OIL FOR CAUSING SHEEN OR SLICK
ON WATER SURFACE, NORMAL TREATMENT ,0.05 GAL BBL,CLEAR LIQUID, MILD
ODOR DENSITY 1003 KG/M3 8.36 LB/GAL, POUR POINT 26 DEG C, FLASH POINT
ADDITIVE, DRILLING FLUID, LIQUID, POLYETHER POLYOL DEFOAMER USED IN
BOTH FRESHWATER AND SALTWATER DRILLING FLUIDS SYSTEMS, 5 GALLON PAIL,
DEFOAMER USED IN BOTH FRESHWATER AND SALTWATER DRILLING FLUIDS
SYSTEMS, EFFECTIVE FOR REDUCING FOAM CAUSED BY WATE.
1000815463
24
Chemicals
(Drilling Fluids)
CRUDE OIL EMULSION BRAKER
ADDITIVE DRILLING FLUID; LIQUID AQUEOUS SOLUTION FORM,MIXTURE OF
ORGANIC NOMINAL PIPE SIZE: 5-1/8 IN,FOR EMULSION BREAKER, BREAKS DOWN
CRUDE FOR THE SEPARATION OF BOTH OIL AND SOLIDS,ORGANIC,
BIODEGRADABLE, CITRUS ODOR,55-GALLON DRUM,MEDIUM BLUE AQUEOUS
SOLUTION, SG:1.2-1.4, PH:7-9, VISCOSITY:100 CST,FREEZE POINT: 26 DEG F,
SOLUBLE IN FRESH AND BRINE WATER, APPLIED BY BATCH OR DOWN HOLE
INJECTION METHODS.
1000813531

Material Number
9COM/9CAT
25
Chemicals
(Drilling Fluids)
CRUDE OIL VISCOSITY REDUCER
ADDITIVE DRILLING FLUID; LIQUID, AQUEOUS SOLUTION FORM,MIXTURE OF
ORGANIC COMPOUNDS AND ENZYMES,FOR VISCOSITY REDUCING AGENT,
RETURNS HEAVY HYDROCARBONS TO AN OIL PHASE,ORGANIC, BIODEGRADABLE,
CITRUS ODOR,55-GALLON DRUM,MEDIUM BLUE AQUEOUS SOLUTION, SG:1.2-
1.4, PH:7-9, VISCOSITY:200 CST,FREEZE POINT: 27 DEG F, SOLUBLE IN FRESH &
BRINE WATER AND OIL SOLUBLE, APPLIED BY BATCH OR DOWN HOLE INJECTION
METHODS, ++DESIGNED FOR THE TREATMENT OF DIFFICULT PARAFFIN AND
ASPHALTENE PROBLEMS BREAK DOWN THE LONG CHAIN AND CYCLIC PARAFFIN'S
(ALONG WITH OTHER LONG CHAIN HYDROCARBONS SUCH AS ASPHALTENES)
ALLOWING THEM TO RETURN TO THE OIL PHASE PERMANENTLY.
1000813532
26
Chemicals
(Drilling Fluids)
EC-101 cutting wash
ADDITIVE DRILLING FLUID; AQUEOUS SOLUTION FORM,MIXTURE OF ORGANIC
COMPOUNDS AND ENZYMES,FOR A NON-TOXIC ,NON- HAZARDOUS,NON-
FLAMMABLE NON-CORROSIVE,100% BIODEGRADABLE,WATER BASED PRODUCT
WHICH IS UTILIZED IN BUT NOT LIMITED TO THE FOLLOWING APPLICATION,DRILL
CUTTING DECONTAMINATION, TREATMENT AND DISPOSAL, HYDROCARBON
CONTAMINATED SOLIDS TREATMENT AND DE- OILING OPERATION ON ONSHORE
AND OFFSHORE OIL DRILLING RIGS,PRODUCTION PLLATFORMS AND VESSELS , OIL
SPILL CLEANUP OPERATION AND PROCESS PLANT CLEAN UP . THE PRODUCT
LEAVES NO PETROCHEMICAL DISTILLATES AFTER PROPER
TREATMENT,APPEARANCE: MEDIUM BLUE AQUEOUS SOLUTION, SPECIFIC
GRAVITY: 1.2 - 1.4 (WATER=1), PH: 7 - 9 POUR POINT : 26 DEG F FREEZE POINT: 26
░F SOLUBILITY : FRESH AND BRINE WATER,55-GAL DRUM.
1000820609
27
Chemicals
(Drilling Fluids)
ALL TEMP
ADDITIVE; DRILLING MUD TYPE,FOR USED AS HT THINNER IN WIDE RANGE OF
WATER-BASE.,SOLID - WHITE POWDER FORM,25.0 LB/BAG,USED AS HT THINNER
IN WIDE RANGE OF WATER-BASE. DOES NOT CONTAIN HEAVY METALS/CHROME
OR REQUIRE SODIUM HYDROXIDE FOR ACTIVATION AND STABLE UP TO
TEMPERATURE 400 F DEG(204 DEG). TREATMENT RANGE FROM 0.5 LB/BBL TO
3.0 LB/BBL, ODOURLESS, PH : 7-9 (1%AQ. SOLN.), SOLUBLE IN WATER, SHEAR
STRENGTH, LB/100 FT▓, 32 MAX PLASTIC VISCOSITY, CP, 32 MAX, YIELD POINT,
LB/100 FT▓, 32 MAX, 10 SECOND GEL, LB/100 FT▓, 12 MAX, 10 MINUTE GEL,
LB/100 FT▓, 38 MAX, 30 MINUTE FILTRATE, ML, 48 MAX.
1000823315

Material Number
9COM/9CAT
28
Chemicals
(Drilling Fluids)
CHEMTROL X
ADDITIVE; ADDITIVE: DRILLING MUD TYPE,FOR PROVIDES HPHT FILTRATION
CONTROL AND RHEOLOGICAL STABILITY IN WIDE RANGE OF WATER-BASE
MUD.,SOLID - TAN TO BLACK POWDER FORM,50.0 LB/BAG,BLEND OF
DERIVATIZED ACRYLIC COPOLYMER DEFLOCCULANT AND CAUSTICIZED LIGNITE
PROVIDES HPHT FILTRATION CONTROL AND RHEOLOGICAL STABILITY IN WIDE
RANGE OF WATER-BASE MUD. INITIAL TREATMENTS OF 2.0 TO 6.0 LB/BBL.
NORMAL TREATMENT LEVELS ARE BASED ON TYPES OF WBM & NEEDED.
APPEARANCE : SOLID, TAN TO BLACK POWDER, ODOR: EARTHY, SPECIFIC
GRAVITY: 1.5 , PARTIALLY SOLUBLE IN WATER. SPECIFIC GRAVITY: 1.5 PH: 9-10
SOLUBILITY : PARTIALLY SOLUBLE IN WATER.
1000823317
29
Chemicals
(Drilling Fluids)
KEM-SEAL PLUS
ADDITIVE; ADDITIVE: DRILLING MUD TYPE,FOR HTHP FILTRATION CONTROL
ADDITIVE WORK WITH ALL TYPES OF WATER BASED FLUIDS,SOLID - WHITE
POWDER FORM,25.0 LB/BAG,HTHP FILTRATION CONTROL ADDITIVE WORK WITH
ALL TYPES OF WATER BASED FLUIDS, TEMPERATURES UP TO 500 DEG. F.
TREATMENT RANGE VARIES BASED ON FILTRATE VALUE DESIRED AND WELL
TEMPERATURE, A REASONABLE RANGE WILL BE 1 TO 6 LB/BBL.IS, SHOULD BE
ADDED SLOWLY TO AVOID HIGH RAISE IN VISCOSITY. APPEARANCE : SOLID,
WHITE POWDER, ODOR:SLIGHT, SPECIFIC GRAVITY :1300 KG/M3 @ 16 DEG. C,
SOLUBILITY : SOLUBLE IN WATER, SALT/HARD WATER PERFORMANCE, FILTRATE,
ML: 17 MAX AGING PERFORMANCE, FILTRATE, ML: 19 MAX.
1000823318
30
Chemicals
(Drilling Fluids)
Temperature Stabilizer
ADDITIVE; DRILLING MUD TYPE,FOR FREE RADICAL SCAVENGER AND
TEMPERATURE STABILIZER,COLORLESS LIQUID FORM,200
LITERS/DRUM,FUNCTIONS BY SCAVENGING FREE RADICALS AND SLOWS DOWN
THERMAL DEGRADATION OF POLYMERIC COMPONENTS, SUCH AS XANTHAN
GUM, PAC AND STARCH, IN THE DRILLING FLUID WHICH ALLOWING THE
TEMPERATURE STABILITY TO BE EXTENDED BY UP TO 50 DEG F. NORMAL
TREATMENT: 2.0 TO 4.0 LB/BBL FLASH POINT : > 195 DEG. F, SPECIFIC GRAVITY :
1.05-1.15, SOLUBILITY : SOLUBLE IN WATER, ACTIVES % W/W 68 - 72, SG @ 20° C
1.05 - 1.15.
1000823316

Material Number
9COM/9CAT
31
Chemicals
(Drilling Fluids)
COASTAL SPOT
ADDITIVE DRILLING FLUID; LIQUID FORM,BLEND OF POLYALPHAOLEFIN ( PAO)
SYNTHETIC HYDROCARBON, EMULSIFIERS, ACTIVATORS AND INITIATORS,FOR
SPOTTING FLUID FOR FREEING STUCK PIPE,PAO BASED PRODUCT WITH
PATENTED ADDITIVES,275 GALLON IBC CONTAINER,ADDITIVE, DRILLING FLUID:
LIQUID, BLEND OF POLYALPHAOLEFIN (PAO) SYNTHETIC HYDROCARBON,
EMULSIFIERS, ACTIVATORS AND INITIATORS, SPOTTING FLUID FOR FREEING
STUCK PIPE, PAO BASED PRODUCT WITH PATENTED ADDITIVES, 275 GALLON IBC
CONTAINER,CLEAR YELLOW LIQUID: SG:0.95-1. 05: DISPERSIBLE IN WATER: POUR
POINT: -20 DEG F, FLASH POINT GREATER 300 DEG F: REPLACEMENT FOR DIESEL
AND MINERAL OIL BASED SPOTTING FLUIDS: DEHYDRATES AND CRACKS FILTER
CAKE TO ALLOW PENETRATION AROUND THE PIPE WITH PAO TO FREE STUCK
PIPE.
1000813125
32
Chemicals
(Drilling Fluids)
SX PLUS, 160 MICRONS
ADDITIVE DRILLING FLUID; BLACK SOLID POWDER PARTICULATES OF SPECIFIC
SIZED GRINDS FORM,HEAT TREATED CARBON BASED MATERIAL,FOR USED FOR
SEEPAGE CONTROL, BRIDGING, PLUGGING, OIL & WATER MUDS, LUBRICITY,
SEALING OF DEPLETED ZONES, PREVENTION OF STUCK PIPES,GRAPHITE
PARTICLES 40 MESH TO GRATER THAN 200 MESH ( 425 TO > 75
MICRONS),ADDITIVE, DRILLING FLUID: BLACK SOLID POWDER PARTICULATES OF
SPECIFIC SIZED GRINDS, HEAT TREATED CARBON BASED MATERIAL, USED FOR
SEEPAGE CONTROL, BRIDGING, PLUGGING, OIL & WATER MUDS, LUBRICITY,
SEALING OF DEPLETED ZONES PREVENTION OF STUCK PIPES, GRAPH GREY TO
BLACK POWDER SG 1.5 FLASH POINT > 350 DEG (F): MELTING POINT > 500 DEG
(F): PARTICLE SIZE:D90-245, D50-160, D10-111 NEGLIGIBLE SOLUBILITY IN WATER
AND OIL: USED FOR SEALING POROUS SANDS AND OTHER FORMATION TO
REDUCE DIFFERENTIAL PRESSURE TRANSFER.
1000813126
33
Chemicals
(Drilling Fluids)
Cross-LINK LCM Retarder
ADMIXTURE DRILLING MUD; CLEAR LIQUID FORM,ADDITIVE RETARDER,FOR
CROSS-LINKING X-LINK POLYMER FOR MIXING VISCOUS PILLS FOR CURING FLUID
CIRCULATION LOSS DURING DRILLING OPERATION,CROSS LINKING MATERIAL FOR
X-LINK POLYMER,5 GALLONS PER CAN,SPECIFIC GRAVITY 1.323 @20 DEG C,
BOILING POINT 221 DEG F (105 DEG C), MOLECULAR WEIGHT 112.0, SOLUBLE IN
WATER SHIPMENT OF PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT
PACKING MANUAL.
1000757568

Material Number
9COM/9CAT
34
Chemicals
(Drilling Fluids)
Cross-LINK LCM
ADMIXTURE DRILLING MUD; POWDER, SOLID FORM,LOST CIRCULATION
MATERIAL,ECTED BY TEMPERATURE AND EXTENDERS. ND OF HIGH MOLECULAR
RETARDERS LULOSE FIBERS AND PARTICLE SS-LINKING AGENTS, G. THE CROSS-
LINKING IS PERATURE TOLERANT GEL-LIKE FORM STIFF, DURABLE AND PAPER
BAG,INSOLUBLE IN WATER. SHIPMENT OF PRODUCT SHALL CONFORM TO SAUDI
ARAMCO EXPORT PACKING MANUAL. THE ORIGINAL MANUFACTURER, PRODUCT
NAME, BATCH NUMBER, DATE OF PRODUCTION OF MATERIAL, EXPIRATION DATE
IF REQUIRED, STOCK NUMBER AND COUNTRY OF ORIGIN SHALL BE PRINTED ON
THE CONTAINER. THE CONSTRUCTION OF THE MULTI-WALLED PAPER BAG
(CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY 75 LB MIN. NATURAL KRAFT PAPER
(INTERIOR PLY) 2ND PLY 75 LB MIN. NATURAL KRAFT PAPER 3RD PLY 80 LB MIN.
NATURAL KRAFT PAPER (EXTERIOR PLY).
1000757567
35
Chemicals
(Drilling Fluids)
BIG BAG BARITE TRANS 0.99 M3
ORANGE
BIG BAG SYSTEM COMPONENTS: CONTAINER: BIG BAG; 35 CU FT CAPACITY;
ORANGE COLOR; (FOR BARYTES). CONTAINER; BARYTE TRANSPORT TYPE,0.99 M3
(35 CU FT),BODY AND CONE SECTION: M049 LID SECTION: M426 INLET AND
OUTLET SPOUT: M326 HEAVY DUTY WIRE RING: INSERTED IN THE TOP WELDED
LID MADE FROM WIO2 MATERIAL,ORANGE,BIG BAG SYSTEM COMPONENT, IBC
TRANSPORT CONTAINERS LTD THERE ARE TWO (2) CERTIFICATE NUMBERS FOR
THE BAGS, AND THE FOLLOWING MANDATORY TEST REQUIREMENTS MUST BE
MET: A) STANDARD: BS-EN 1898-2001, CLASS: HEAVY DUTY THERMOPLASTIC,
CERTIFICATE NUMBER: 101043, APPROVED RATING: SWL: 2500KG/8:1 SF. B)
STANDARD: EFIBCA 003: 1985, CLASS: HEAVY DUTY THERMOPLASTIC,
CERTIFICATE NUMBER: 101161E APPROVED RATING: SWL: 2500KG/8:1 SF
1000029881
36
Chemicals
(Drilling Fluids)
BIG BAG BENTONITE TRANS 0.99
M3 BLUE
BIG BAG SYSTEM COMPONENTS: CONTAINER: BIG BAG; 35 CU FT CAPACITY; BLUE
COLOR; (FOR BENTONITE). CONTAINER; BENTONITE TRANSPORT TYPE,0.99 M3
(35 CU FT),BODY AND CONE SECTION: M047 LID SECTION: M425 INLET AND
OUTLET SPOUT: M325 HEAVY DUTY WIRE RING: INSERTED IN THE TOP WELDED
LID MADE FROM WIO2 MATERIAL,BLUE,BIG BAG SYSTEM COMPONENT, IBC
TRANSPORT CONTAINERS LTD THERE ARE TWO (2) CERTIFICATE NUMBERS FOR
THE BAGS, AND THE FOLLOWING MANDATORY TEST REQUIREMENTS MUST BE
MET: A) STANDARD: BS-EN 1898-2001, CLASS: HEAVY DUTY THERMOPLASTIC,
CERTIFICATE NUMBER: 101043, APPROVED RATING: SWL: 2500KG/8:1 SF. B)
STANDARD: EFIBCA 003: 1985, CLASS: HEAVY DUTY THERMOPLASTIC,
CERTIFICATE NUMBER: 101161E APPROVED RATING: SWL: 2500KG/8:1 SF
1000029882

Material Number
9COM/9CAT
37
Chemicals
(Drilling Fluids)
BIG BAG, ZIP NYLON
BIG BAG SYSTEM COMPONENTS: ZIP TIES: NYLON; BIG BAG; TYPE 120-R. . TIE; ZIP
TYPE,NYLON,BIG BAG SYSTEM COMPONENT, IBC TRANSPORT CONTAINERS LTD
TYPE "120-R".
1000029930
38
Chemicals
(Drilling Fluids)
BIG BAG, LIFTING
BIG BAG SYSTEM COMPONENTS: LIFTING RING: BIG BAG; TYPE 109.5. . RING; BIG
BAG LIFTING TYPE,BIG BAG SYSTEM COMPONENTS, IBC TRANSPORT CONTAINERS
LTD, TYPE 109.5.
1000029887
39
Chemicals
(Drilling Fluids)
PENETREX - ROP enhancer
ADMIXTURE DRILLING MUD; LIQUID FORM,ISOMERISED OLEFINS 60-90%,FOR
DESIGNED TO INCREASE RATE OF PENETRATION (ROP)IN WATER BASED DRILLING
FLUID SYSTEMS, USED IN MEDIUM TO HARD SHALES,ISOMERISED OLEFINS 60-
90%,55 GAL/DRUM,RECOMMENDED INITIAL TREATMENT OF 1% TO 2% BY
VOLUME SHOULD BE MADE BY INJECTION TO THE CIRCULATING SYSTEM.
ADDITIONAL CAN BE ADDED UP TO 5-6% BY VOLUME DEPENDING ON THE ROP
ACHIEVED, AMOUNT OF SHALE ENCOUNTERED, TYPE OF MUD SYSTEM AND THE
INTERVAL LENGTH COLORLESS TO LIGHT YELLOW, MILD ODOR,SG 0.84, FREEZING
POINT-10 DEG C, BOILING POINT >270OC, FLASH POINT > 136 DEG C,INSOLUBLE
IN WATER SOLUBLE IN HYDROCARBONS SHIPMENT OF PRODUCTS MUST
CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL.
1000775552
40
Chemicals
(Drilling Fluids)
MAX-PLEX
ADMIXTURE DRILLING MUD; BROWN POWDER DUST FORM,RESIN AND
ALUMINATE COMPOUND,FOR FOR REDUCING PORE PRESSURE TRANSMISSION
AND HPHT FILTRATION RATES,ALUMIUM COMPLEX-40-60%&OXYALKYLATED
ALKANOL -1-5% BY WT,50 LB BAG,USED IN FRESH UP TO SATURATED SALT WATER
BASE MUD SYSTEMS FOR STABILIZING SHALE AND PREVENTION OF BIT AND
BOTTOM HOLE ASSEMBLY BALLING BROWN COLOR, ODORLESS, SG 1.85,PH 11-12
(1% SOLUTION) TEMP. STABILITY300 DEG F, SOLUBLE IN WATER, INSOLUBLE IN
ORGANIC SOLVENTS SHIPMENT OF PRODUCTS MUST CONFORM TO SAUDI
ARAMCO EXPORT PACKING MANUAL.
1000775553
41
Chemicals
(Drilling Fluids)
MAX-GUARD
ADMIXTURE DRILLING MUD; LIQUID FORM,POLYAMINE,FOR PRIMARY CLASS
HYDRATION AND SWELLING SUPPRESSANT,AQUEOUS SOLUTUTION OF AMINE
ACID COMPLEX,55 GAL DRUM,THAT PROVIDES INHIBITION OF REACTIVE CLAY
AND GUMBO BY SUPPRESSING HYDRATION AND SWELLING WITHIN THE CLAY
MINERAL PLATELETS AMBER COLOR, MILD ODOR,SG 1.07-1.09, PH 6.8-7.2 (2%
SOLUTION),SOLUBLE IN WATER,FLASH POINT >93OC SHIPMENT OF PRODUCTS
MUST CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL.
1000775554

Material Number
9COM/9CAT
42
Chemicals
(Drilling Fluids)
CLAY-SEAL
ADMIXTURE CEMENT; FOR CLAYSEAL SHOULD BE ADDED DIRECTLY TO THE
SYSTEM.THIS SHOULD OCCUR AFTER PREHYDRATING.,TYPE ADMIXTURE, CEMENT
HYDRO GUARD, CLAYSEAL,ETHOXYLATED POLYAMINE,5 GAL GALLON
PAIL,APPEARANCE: TRANSPARENT YELLOW LIQUID, ODOR: AMINE, SPECIFIC
GRAVITY: 1GM/CC, SOLUBILITY: SOLUBLE IN WATER. CLAYSEAL SHOULD BE
ADDED DIRECTLY TO THE SYSTEM.THIS SHOULD OCCUR AFTER PREHYDRATING
ALL BENTONITE ADDITIONS AND ADDING FLUID LOSS ADDITIVES.INITIAL
TREATMENTS IN NONDISPERSED SYSTEMS MAY CAUSE SLIGHT FLOCCULATION
AND MAY REQUIRE A THINNER. CLAYSEAL ADDITIONS WILL BE 4-8 LB/BBL AND
FOR BEST RESULTS A MINIMUM OF 4 LB/BBL OF CLAYSEAL┐ IS REQUIRED.
1000812301
43
Chemicals
(Drilling Fluids)
GLYCOL - GEM GP
ADMIXTURE DRILLING MUD; DARK BROWN LIQUID FORM,POLYALKYLENE GLYCOL
OTHER ASSOCIATED ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL AND/OR
ADVERSELY AFFECT FLUID PROPERTIES.,FOR USED TO IMPROVE LUBRICITY, SHALE
STABILITY AND REDUCE BIT BALLING. NORMAL TREATMENT,POLYALKYLENENE
GLYCOL,55 GALLON DRUM,CONCENTRATION IS 2-6% BY VOLUME IN A MUD
SYSTEM BUT OPTIMUM CONCENTRATION SHOULD BE IDENTIFIED ON A CASE BY
CASE BASIS. APPEARANCE YELLOW TO BROWN LIQUID, ODOR MILD, SPECIFIC
GRAVITY 1.01, BOILING POINT (░C) 126 C, SOLUBILITY IN WATER MISCIBLE.
SHIPMENT OF PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT PACKING
MANUAL.
1000812016
44
Chemicals
(Drilling Fluids)
BORE-HIB
ADDITIVE DRILLING FLUID; DARK YELLOW LIQUID FORM,GLYCERINE AND SILICATE
SALT OTHER ASSOCIATED ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL
AND/OR ADVERSELY AFFECT FLUID PROPERTIES.,FOR USED AS STABILIZER WHILE
DRILLING HIGHLY REACTIVE SHALE AND CLAYS. BORE-HIB CAN BE DEPLETED
WHEN DRILLING ANHYDRITE, GREEN. CEMEN,GLYCERINE AND SILICATE SALT
MIXTURE,55 GALLON DRUM,ADDITIVE, DRILLING FLUID: DARK YELLOW LIQUID,
GLYCERINE AND SILICATE SALT OTHER ASSOCIATED ELEMENTS MUST NOT BE
HARMFUL TO PERSONNEL AND/OR ADVERSELY AFFECT FLUID PROPERTIES USED
AS STABILIZER WHILE DRILLING HIGHLY REACTIVE SHALE AND CLAYS. BORE-HIB
CAN. APPEARANCE DARK YELLOW SHIPMENT OF PRODUCT SHALL CONFORM TO
SAUDI ARAMCO EXPORT PACKING MANUAL.
1000812015

Material Number
9COM/9CAT
45
Chemicals
(Drilling Fluids)
LC-LUBE, 300-450 MICRON
ADMIXTURE DRILLING MUD; SOLID BLACK OF SPECIFIC SIZED GRINDS
PARTICULATES FORM,PHITE H RESILIENCY SYNTHETIC,FOR WELLBORE
STRENGTHENING. DEPLETED D IN OIL OR WATER BASE MUD ES, PREVENTION OF
STUCKPIPE,50 LB (22.7 KG)/ SACK,1ST PLY OTHER ASSOCIATED ELEMENTS MUST
NOT BE HARMFUL TO PERSONNEL AND/OR ADVERSELY AFFECT FLUID
PROPERTIES. APPEARANCE: GRAY TO BLACK POWDER. ODOR: ODORLESS. SG: 1.75-
2.5 GM/CC. SOLUBILITY: INSOLUBLE IN WATER & ACID. PARTICLE SIZE: D50: 300-
450 MICRON. RESILIENCY: GREATER THAN 80% AT 10,000 PSI. CONTAINER IS A
MULTI-WALLED SACK - 75 LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY). 2ND
PLY - 75 LB MIN. NATURAL KRAFT PAPER. 3RD PLY - 80 LB MIN. NATURAL KRAFT
PAPER (EXTERIOR PLY).
1000758660
46
Chemicals
(Drilling Fluids)
LC-LUBE Fine, 165 MICRON
ADMIXTURE DRILLING MUD; SOLID BLACK OF SPECIFIC SIZED GRINDS TICULATES
FORM,LC-LUBE FINE, GRAPHITE, SYNTHETIC,FOR USE FOR SEEPAGE CONTROL
BRIDGING, PLUGGING, OIL MUDS, WATER MUDS, LUBRICITY, SEALING OF
DEPLETED ZONES, PREVENTION OF STUCK PIPE,LC-LUBE FINE SYNTHETIC
GRAPHITE,50 LB (22.7 KG)/ SACK,1ST PLY OTHER ASSOCIATED ELEMENTS MUST
NOT BE HARMFUL TO PERSONNEL AND/OR ADVERSELY AFFECT FLUID
PROPERTIES. APPEARANCE: GRAY TO BLACK POWDER ODOR: ODORLESS SP. GR.:
2.25 GM/CC FREEZING POINT: NA MELTING POINT: >5000 F DEG SOLUBILITY:
INSOLUBLE IN WATER & ACID PARTICLE SIZE: D90 300 D50 165 D10 75
CONTAINER IS A MULTI-WALLED SACK - 75 LB MIN. NATURAL KRAFT PAPER
(INTERIOR PLY). 2ND PLY - 75 LB MIN. NATURAL KRAFT PAPER. 3RD PLY - 80 LB
MIN. NATURAL KRAFT PAPER (EXTERIOR PLY).
1000758661
47
Chemicals
(Drilling Fluids)
MAX-SHIELD
ADMIXTURE DRILLING MUD; MILKY, WHITE LIQUID FORM,MAX-SHIELD LATEX, 60
WT%,FOR SEALING POLYMER IN WATER-BASED DRILLING FLUID SYSTEM,LATEX,
60 WT%,55 GAL/DRUM,USED TO CREATE A SEMI-PERMEABLE MEMBRANE AT
BOREHOLE, IMPROVE HOLE STABILITY AND REDUCE PORE PRESSURE
TRANSMISSION WHICH HELPS PREVENT STUCK PIPE WHEN DRILLING DEPLETED
ZONES. OTHER ASSOCIATED ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL
AND/OR ADVERSELY AFFECT FLUID PROPERTIES. NORMAL TREATMENT: 2-5 % BY
VOLUME. APPEARANCE: MILKY, WHITE LIQUID. ODOR: MILD PH: 6-9 SP. GR.: 1.05
GM/CC FREEZING POINT: 32 F DEG (0 C DEG) BOILING POINT: 212 F DEG (100 C
DEG) FLASH POINT: NA RELATIVE DENSITY: 1025 KG/M3 @ 16 C DEG. SOLUBILITY:
MISCIBLE WITH WATER VOC WEIGHT: <0.6%.
1000758663

Material Number
9COM/9CAT
48
Chemicals
(Drilling Fluids)
STEEL SEAL
ADMIXTURE DRILLING MUD; POWDER, SOLID FORM,GRAPHITE,FOR LOSS
CIRCULATION ADDITIVE TO STOP LOSSES IN POROUS AND FRACTURED
FORMATIONS,BLACK ANGULAR MATERIAL CARBON BASED MATERIAL,50 LB
BAG,FOR USE WITH SYNTHETIC AND WATER-BASED DRILLING FLUIDS IMPARTS
LUBRICITY FOR WATER BASED FLUIDS TO CONTROL SEEPAGE AND LOST
CIRCULATION 15-25 LB/BBL USED AS A BACKGROUND CONCENTRATION, 50-100
LB/BBL LCM PILL FOR SPOTTING OVER THIEF ZONES, 3-10 LB/BBL FOR LUBRICITY
IN WATER BASED FLUIDS. ODORLESS, SG 1.75, FLASH POINT >356OC,INSOLUBLE
IN WATER, PARTICLES SIZE PERCENT < 40 MESH: 100 PERCENT > 200 MESH: 95
CONTAINER MUST BE PROPERLY LABELED WITH, VENDOR'S NAME,
THE CONSTRUCTION OF THE MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE
AS FOLLOWS: 1ST PLY - 75 LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY). 2ND
PLY - 75 LB MIN. NATURAL KRAFT PAPER. 3RD PLY - 80 LB MIN.
1000775555
49
Chemicals
(Drilling Fluids)
STEEL SEAL Fine
ADMIXTURE DRILLING MUD; POWDER, SOLID FORM,GRAPHITE,FOR LOSS
CIRCULATION ADDITIVE TO STOP LOSSES IN POROUS AND MICRO-FRACTURED
FORMATIONS,GRAY-BLACK ANGULAR MATERIAL CARBON BASED MATERIAL,50 LB
SACK,FOR USE WITH SYNTHETIC AND WATER-BASED DRILLING FLUIDS IMPARTS
LUBRICITY FOR WATER BASED FLUIDS TO CONTROL SEEPAGE AND LOST
CIRCULATION 15-25 LB/BBL USED AS A BACKGROUND CONCENTRATION, 60-110
LB/BBL LCM PILL FOR SPOTTING OVER THIEF ZONES, 4-10 LB/BBL FOR LUBRICITY
IN WATER BASED FLUIDS. ODORLESS, SG 1.75,FLASH POINT >356OC,INSOLUBLE
IN WATER, PARTICLES SIZE DRY SIEVE ANALYSIS:FINE 99% MIN & REGULAR 95%
MIN. THROUGH (30 MESH) DRY SIEVE ANALYSIS:FINE 40% MIN & REGULAR 2%
MAX THROUGH (200 MESH) MEDIAN PARTICLE SIZE: 80 CONTAINER MUST BE
PROPERLY LABELED WITH, VENDOR'S NAME, MANUFACTURER'S NAME,
LOCATION, PRODUCTION DATE AND BATCH NUMBER. THE CONSTRUCTION OF
THE MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY -
75 LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY). 2ND PLY - 75 LB MIN.
NATURAL KRAFT PAPER. 3RD PLY - 80 LB MIN. NATURAL KRAFT PAPER (EXTERIOR
PLY) SAUDI ARAMCO'S PERSONNEL WILL CARRY OUT SAMPLING AND TESTING AS
NEEDED.
1000775556

Material Number
9COM/9CAT
50
Chemicals
(Drilling Fluids)
STEEL SEAL 50
ADMIXTURE DRILLING MUD; POWDER, SOLID FORM,SYNTHETIC GRAPHITE,FOR
LOSS CIRCULATION ADDITIVE TO STOP LOSSES IN POROUS AND MICRO-
FRACTURED FORMATIONS,SYNTHETIC GRAPHITE,50 LB. BAG,FOR USE WITH
SYNTHETIC AND WATER-BASED DRILLING FLUIDS IMPARTS LUBRICITY FOR WATER
BASED FLUIDS GREY-BLACK ANGULAR MATERIAL,ODORLESS, SG 1.75, INSOLUBLE
IN WATER, MEDIAN PARTICLE SIZE D-50: 50 15-25 LB/BBL AS A BACKGROUND
CONCENTRATION FOR SEEPAGE AND LOST CIRCULATION CONTROL. 60-110
LB/BBL LCM PILL FOR SPOTTING OVER THIEF ZONESOR ON BOTTOM PRIOR TO
TRIPS AND 4-10 LB/BBL FOR LUBRICITY IN WATER-BASED FLUIDS. CONTAINER
MUST BE PROPERLY LABELED WITH, VENDOR'S NAME, MANUFACTURER'S NAME,
LOCATION, PRODUCTION DATE AND BATCH NUMBER. THE CONSTRUCTION OF
THE MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY -
75 LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY). 2ND PLY - 75 LB MIN.
NATURAL KRAFT PAPER. 3RD PLY - 80 LB MIN. NATURAL KRAFT PAPER (EXTERIOR
PLY)
1000775557
51
Chemicals
(Drilling Fluids)
CLAY-GRABBER
ADMIXTURE DRILLING MUD; LIQUID FORM,NON-IONIC LIQUID POLYMER,FOR
FLOCCULANT AND CLAY ENCAPSULATOR. IT STOPS SHALE DISPERSION AND HELPS
STABILIZE SHALES IN THE WELLBORE,HIGH MOLECULAR WEIGHT, NON-IONIC
LIQUID POLYMER,5 GAL PAIL,OPAQUE LIQUID, OFF-WHITE COLOR, PH:6.5-7.5,
CONCENTRATION 30-40 (1% ACTIVE POLYMER), SG 1.02 -1.06, STABILITY UP TO
300 DEG F, IMIISCIBLE IN WATER FOR RESULTS CLAY GRABBER FLOCULANT
SHOULD BE MIXED THROUGH A HIGH SHEAR HOPPER. 0.5-1.0 LB/BBL IN THE
HYDRO-GUARD SYSTEM. 0.25-0.5 LB/BBL FOR CLEAR WATER DRILLING. 0.5-1.0
FOR TROUBLESOME SHALES IN A WATER- BASED SYSTEM.
1000775561
52
Chemicals
(Drilling Fluids)
CLAY-SYNC
ADMIXTURE DRILLING MUD; GRANULES FORM,NON-IONIC 100% ACTIVE DRY
POLYMER,FOR A CLAY INHIBITOR FOR WATER BASED DRILLING FLUIDS. SHALE
STABILIZER AND WELLBORE LUBRICATOR,LOW MOLECULAR WEIGHT, NON-IONIC
DRY POLYMER,50 LB. BAG,POLYMER ADHERES TO SURFACE OF REACTIVE CLAYS
PREVENTING DISPERSION AND HYDRATION, SHOULD BE MIXED THROUGH THE
HOPPER IN THE HYDRO-GUARD SYSTEM. IF SALINITY >140,000 PPM USE 2 LB/BBL,
IF SALINITY IS<140,000 PPM, USE 3 LB/BBL OFF-WHITE GRANULES, SOLID,
ODORLESS , PH (1% SOLUTION): 6.5-7.5 , SG 1.04, 100 (%ACTIVE POLYMER), BULK
DENSITY 50 LB/FT3 @ 20OC, SOLUBLE IN WATER SHIPMENT OF PRODUCT SHALL
CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL.
1000775562

Material Number
9COM/9CAT
53
Chemicals
(Drilling Fluids)
MICROWASH - OHR-759
ADMIXTURE DRILLING MUD; LIQUID FORM,N-BUTANOL,FOR USED AS A CO-
SURFACTANT TO REMEDIATE WELLBORE DAMAGE,SURFACTANT BLEND WITH N-
BUTANOL 100%,55 GALLON DRUM,APPEARANCE CLEAR, COLORLESS
LIQUID,ODOR SWEET, RELATIVE DENSITY:810 KG/M3 BOILING POINT:118 DEG
C,FLASH POINT:37 DEG C, SOLUBLE IN WATER,AUTO-IGNITION TEMPERATURE
343░C. ++THIS ITEM IS ONE OF COMPONENT USED TO FORMULATE THE MICRO-
WASH SYSTEM FOR WELLBORE REMEDIATION AND REMOVE DAMAGE TO THE
RESERVOIR DRILLED WITH INVERT EMULSION FLUIDS. ++ CONTAINER MUST BE
LOCATION, PRODUCTION DATE AND BATCH NUMBER. SAUDI ARAMCO'S
PERSONNEL WILL CARRY OUT PROPER SAMPLING AND TESTING AS NEEDED.
MICRO-WASH ACID SYSTEM CONSISTS BAKER ++ HUGHES PRODUCTS, PRIME-743,
PRIME-760, PRIME-770,OHR-759, OHR-AC, OHR-757, OHR-750 & GLACIAL ACETIC
ACID AND FORMIC ACID.
1000811421
54
Chemicals
(Drilling Fluids)
MICROWASH - OHR-AC
ADMIXTURE DRILLING MUD; LIQUID FORM,ACID CORROSION INHIBITOR,FOR
USED AS AN ACID CONTROL ADDITIVE IN THE MICRO-WASH ACID
SYSTEM,,CONTAINING PROPARGYL ALCOHOL 5-10%,METHANOL 30-60% AND
BLEND OF NON-IONIC SURFACTANTS,55 GALLON DRUM,APPEARANCE:CLEAR
AMBER LIQUID,ODOR:SWEET,SPECIFIC GRAVITY:885-897 KG/M3,FLASH POINT:10-
15.6 DEG C, POUR POINT:LESS THAN -20.2 DEG C,SOLUBLE IN WATER, PH:4-6(5%
IN 25% IPA/75% WATER),FLASH POINT:10-15.6 DEG C (TAG CLOSED CUP),VAPOUR
PRESSURE:85MM HG AT 21 DEG C, ++ THIS ITEM PROVIDES CORROSION
RESISTANCE WHILE REMEDIATING WELLBORE DAMAGE AND DESTROYING OIL-
MUD FILTER CAKE, THE PRODUCT IS BIODEGRADABLE, ACID DISPERSIBILE AND IS
TOLERANT FOR SALTS PRESENT IN ACIDS.CONTAINER MUST BE PROPERLY
LABELED WITH, VENDOR'S NAME, MANUFACTURER'S NAME, LOCATION,
PRODUCTION DATE AND BATCH NUMBER. SAUDI ARAMCO'S PERSONNEL WILL
CARRY OUT PROPER SAMPLING AND TESTING AS NEEDED. ++ MICRO-WASH ACID
SYSTEM CONSISTS BAKER HUGHES PRODUCTS, PRIME-743, PRIME-760, PRIME-
770,OHR-759, OHR-AC, OHR-757, OHR-750 & GLACIAL ACETIC ACID AND FORMIC
ACID.
1000811422

Material Number
9COM/9CAT
55
Chemicals
(Drilling Fluids)
MICROWASH - OHR-757
ADMIXTURE DRILLING MUD; LIQUID FORM,BLEND OF NON-IONIC AND ANIONIC
SURFACTANTS.FOR TO DESTROY INVERT EMULSION IN OIL-BASED MUD FILTER
CAKE AND SOILDS,SODIUM TRIDECYL ETHER SULFATE 10-20% & OTHER
COMPONENTS,275 GALLON IBC CONTAINER,ADMIXTURE, DRILLING MUD: LIQUID,
BLEND OF NON-IONIC AND ANIONIC SURFACTANTS., TO DESTROY INVERT
EMULSION IN OIL-BASED MUD FILTER CAKE AND SOILDS, SODIUM TRIDECYL
ETHER SULFATE 10- 20% & OTHER COMPONENTS, 275 GALLON IBC CONTAINER,
APPEARANCE:TRANSPARENT, YELLOW LIQUID, ODOR:DISINFECTANT,SPECIFIC
GRAVITY: 1086.5 KG/M3,. FLASH POINT >100░C SOLUBLE IN WATER, PH: 7.8 AT
25 DEG C, VISCOSITY: 28. 0CST AT 40░C.THIS MATERIAL IS USED AS ONE OF
SURFACTANT COMPONENT IN THE MICRO-WASH ACID SYSTEM IT IS BLENDED OF
NON-IONIC AND ANIONIC SURFACTANTS WITH NEAR ZERO INTERFACIAL.
CONTAINER MUST BE PROPERLY LABELED WITH:VENDOR'S NAME
SAUDI ARAMCO'S PERSONNEL WILL CARRY OUT PROPER SAMPLING AND TESTING
AS NEEDED. MICRO-WASH ACID SYSTEM CONSISTS BAKER HUGHES PRODUCTS:
PRIME-743, PRIME-760, PRIME-770 ,OHR- 759, OHR-AC, OHR-757, OHR- 750 &
GLACIAL ACETIC ACID AND FORMIC ACID.
1000811423

Material Number
9COM/9CAT
56
Chemicals
(Drilling Fluids)
MICROWASH - OHR-750
SURFACTANTS,FOR TO REMEDIATE WELLBORE DAMAGE, DESTROY INVERT
EMULSION IN OIL-BASED MUD FILTER CAKE AND WATER-WET METAL
SURFACES,ALKYPHENYL OXIDE SULPHONATES,275 GALLON IBC
CONTAINER,ADMIXTURE, DRILLING MUD: LIQUID, BLEND OF NON-IONIC AND
ANIONIC URFACTANTS, TO REMEDIATE WELLBORE DAMAGE, DESTROY INVERT
EMULSION IN OIL-BASED MUD FILTER CAKE AND WATER-WET METAL SURFACES,
ALKYPHENYL OXIDE SULPHONATES , 275 GALLON IBC CONTAINER ,
APPEARANCE:CLEAR ,YLLOW- ORANGE LIQUID, ODOR:DISINFECTANT SPECIFIC
GRAVITY:1108 KG/M3,. BOILING POINT:212?F , FLASH POINT >100░C, SOLUBLE IN
WATER : PH:5.5 AT 25?C, VISCOSITY:69CST AT 40░C PROPRIETARY BLEND THAT IS
CUSTOM DESIGNED TO DISPERSE FILTER CAKE AS A COMPONENT IN MICRO-
WASH ACID SYSTEM TO REMOVE OBM SKIN DAMAGE AND ALLOW THE
RESERVOIR TO FLOW AT MAXIMUM POTENTIAL. IT IS BLEND OF NON-IONIC AND
ANIONIC SURFACTANTS WITH NEAR ZERO INTERFACIAL TENSION. NORMAL
TREATMENT: 10 - 25% BY VOLUME ++ CONTAINER MUST BE PROPERLY LABELED
WITH: VENDOR'S NAME, MANUFACTURER'S NAME, LOCATION, PRODUCTION
DATE AND BATCH NUMBER.
1000811424
57
Chemicals
(Drilling Fluids)
MICROWASH - PRIME-743
ADMIXTURE DRILLING MUD; LIQUID FORM,GLYCEROL-BELEND OF NON-IONIC
SURFACTANTS,FOR USED FOR REMOVE OIL-WET SOLIDS FROM THE WELLBORE
AND WATER-WET METAL SURFACES.,GLYCEROL, BLEND OF NON-IONIC AND
ANIONIC SURFACTANTS,5 GALLON CAN,++ APPEARANCE OPAQUE YELLOW-
ORANGE LIQUID, PH 7.6, SPECIFIC GRAVITY 1015 KG/M3, BOILING POINT 100
DEG, FLASH POINT GREATER THAN 93 DEG C, WATER SOLUBLE ++ FULLY
COMPATIBLE AT ALLRATIOS WITH OIL MUD SPACERS AND OIL-NORMAL ONE OF
THE SURFACTANT COMPONENTS IN THE MICRO-WASH ACID SYSTEM ++
CONTAINER MUST BE PROPERLY LABELED WITH, VENDOR'S NAME,
MANUFACTURE'S NAME LOCATION, PRODUCTION DATE AND BATCH NUMBER
AS NEEDED. CONTAINER MUST BE PROPERLY LABELED ++MICRO-WASH ACID
SYSTEM CONSISTS BAKER HUGHES PRODUCTS, PRIME-743, PRIME-760, PRIME-
770,OHR-759, OHR-AC, OHR-757, OHR-750 & GLACIAL ACETIC ACID AND FORMIC
ACID.
1000811425

Material Number
9COM/9CAT
58
Chemicals
(Drilling Fluids)
ADMIXTURE DRILLING MUD; LIQUID FORM,2-BUTOXYETHANOL > 60% AND
SURFACTANTS,FOR USED TO CREATE AN EFFECTIVE PUSH PILL TO PILOT THE
DISPLACEMENT AND ACT AS NON EMULSIFIER,2-BUTOXYETHANOL > 60% AND A
BLEND OF UNSATURATED AROMATIC HYDROCARBONS, NON-IONIC SURFACTANT
AND ANIONIC SURFACTANTS,5 GALLON CAN,APPEARANCE CLEAR,`LIGHT YELLOW
LIQUID, ODOR MILD, SWEET SPECIFIC GRAVITY:920 KG/M3 FLASH POINT
64░C(PMCC),PH 4.7-5.7(75%IPA/25% WATER), SOLUBLE IN WATER, VISCOSITY: 95-
105 CPS AT 20 DEG C ++ USED FOR REMOVING OIL-WET DEBRIS FROM THE
METAL SURFACES, FULLY COMPATIBLE AT ALL RATIOS WITH OIL MUD SPACERS
AND ALL OIL- BASED DRILLING FLUIDS.ONE OF THE SURFACTANT COMPONENTS
IN THE MICRO-WASH ACID SYSTEM ++ CONTAINER MUST BE PROPERLY LABELED
WITH, VENDOR'S NAME, MANUFACTURE'S NAME LOCATION, PRODUCTION DATE
AND BATCH NUMBER SAUDI ARAMCO'S PERSONNEL WILL CARRY OUT PROPER
SAMPLING AND TESTING AS NEEDED CONTAINER MUST BE PROPERLY LABELED ++
MICRO-WASH ACID SYSTEM CONSISTS BAKER HUGHES PRODUCTS, PRIME-743,
PRIME-760, PRIME-770,OHR-759, OHR-AC, OHR-757, OHR-750 & GLACIAL ACETIC
ACID AND FORMIC ACID.
1000811426
59
Chemicals
(Drilling Fluids)
SURFACTANTS,FOR TO CREATE AN EFFECTIVE FOLLOW-UP DISPLACEMENT
NEWTONIAN CLEANING PILL USED TO REMOVE OIL-WET SOLIDS,BLEND OF NON-
IONIC AND ANIONIC SURFACTANTS,5 GALLON CAN,APPEARANCE: TURBID,`
YELLOW-ORANGE LIQUID ODOR: MILD, SWEET SPECIFIC GRAVITY: 1098 KG/M3,
FLASH POINT: GREATER THAN 100 DEG C(TCC),WATER SOLUBLE ++ FULLY
COMPATIBLE AT ALL RATIOS WITH OIL MUD SPACERS AND ALL OIL- BASED
DRILLING FLUIDS. ONE OF THE SURFACTANT COMPONENTS IN THE MICRO-WASH
ACID SYSTEM ++ CONTAINER MUST BE PROPERLY LABELED WITH, VENDOR'S
NAME, MANUFACTURER'S NAME, LOCATION, PRODUCTION DATE AND BATCH
NUMBER. ++ SAUDI ARAMCO'S PERSONNEL WILL CARRY OUT PROPER SAMPLING
AND TESTING AS NEEDED. CONTAINER MUST BE PROPERLY LABELED ++ MICRO-
WASH ACID SYSTEM CONSISTS BAKER HUGHES PRODUCTS, PRIME-743, PRIME-
760, PRIME-770,OHR-759, OHR-AC, OHR-757, OHR-750 & GLACIAL ACETIC ACID
AND FORMIC ACID.
1000811427

Material Number
9COM/9CAT
60
Chemicals
(Drilling Fluids)
ACETIC ACID > 96%
ADDITIVE DRILLING FLUID; CLEAR,COLORLESS LIQUID FORM,ACETIC ACID >
96%,FOR TO ACIDIZE SOLUBLE CALCIUM CARBONATE PARTICLES IN WELLBORE
REMEDIATION,ACETIC ACID > 96%,275 GALLON IBC TOTE,CLEAR LIQUID, STRONG
PUNGENT VINEGAR ODOR DENSITY 1050 KG/M3, BOILING POINT 117 DEG C,
FLASH POINT >102.2░C, SOLUBLE IN WATER,SOLUBLE AUTO-IGNITION
TEMPERATURE 799░C. ACETIC ACID IS A COMPONENT OF THE BAKER HUGES
MICRO- WASH SYTEM TO IMPROVE WELL PRODUCTIVITY. IT IS A CARBOXYLIC
ACIDS WITH THE MOLECULAR FORMULA OF CH3COOH, NORMAL TREATMENT 1 -
15 % BY VOLUME. 275 GALLON IBC.
1000814796
61
Chemicals
(Drilling Fluids)
FORMIC ACID >90%
ADDITIVE DRILLING FLUID; CLEAR,COLORLESS LIQUID FORM,FORMIC ACID
>90%,FOR TO ACIDIZE SOLUBLE CALCIUM CARBONATE IN MICRO-WASH,FORMIC
ACID >90%,55 GALLON DRUM,ADDITIVE DRILLING FLUID CLEAR,COLORLESS
LIQUID FORM,FORMIC ACID >90%,FOR TO ACIDIZE SOLUBLE CALCIUM
CARBONATE IN MICRO-WASH, FORMIC ACID >90%,55 GALLON DRUM,ADDITIVE,
DRILLING FLUID: CLEAR,COLORLESS LIQUID, FORMIC ACID >90%, TO ACIDIZE
SOLUBLE CALCIUM CARBONATE IN MICRO-WASH, FORMIC ACID >90%, 55
GALLON DRUM , ADDITIVE, DRILLING FLUID: CLEAR,COLORLESS LIQUID,FORMIC
ACID >90%, TO ACIDIZE SOLUBLE CALCIUM CARBONATE IN MICRO-WASH,
FORMIC ACID >90%, 55 GALLON DRUM.
1000811877
62
Chemicals
(Drilling Fluids)
N-FLOW - LOSURF-259
ADDITIVE DRILLING FLUID; LIQUID FORM,ISOPROPANOL AND HEAVY AROMATIC
PETROLEUM NAPTHA,FOR BREAKS EMULSION IN OIL BASE MUD FILTER CAKE,
USED IN PUSH PILL SPACER PRIOR TO SPOT N-FLOW 325 TREATMENT FILTER CAKE
REMOVAL,5 GALLON CAN,ADDITIVE, DRILLING FLUID: LIQUID, ISOPROPANOL AND
HEAVY AROMATIC PETROLEUM NAPTHA, BREAKS EMULSION IN OIL BASE MUD
FILTER CAKE, USED IN PUSH PILL SPACER PRIOR TO SPOT N-FLOW 325
TREATMENT FOR FILTER CAKE REMOVAL, ISOPROPANOL AND HEAVY AROMATIC
PETROLEUM NAPTHA, 5 GALLON CAN, APPEARANCE: CLEAR LIGHT AMBER,
ALCOHOL ODOR, SPECIFIC GRAVITY: 0.92 @ 20 DEG C BOILING POINT: 92 DEG C,
DISPERSES IN WATER. ++ PREVENTS OIL WET FINES FROM STABILIZING
EMULSIONS, NORMAL USE CONCENTRATION: 0.1 - 2.0 % V/V. NONIONIC
NONEMULSIFIER BLEND, PRIMARILY DESIGNED FOR ACIDIZING LIMESTONE,
DOLOMITE AND SANDSTONE FORMATION & FRACTURE TREATMENT.
1000811529

Material Number
9COM/9CAT
63
Chemicals
(Drilling Fluids)
Mutual Solvent - MUSOL
ADDITIVE DRILLING FLUID; LIQUID FORM,ETHYLENE GLYCOL MONOBUTYL ETHER
SOLVENT,FOR REDUCE OIL WET TENDENCIES AND IMPROVE THE OVERALL
WETTING CONDITION OF THE FORM,ETHYLENE GLYCOL MONOBUTYL ETHER,55
GALLON DRUM,ADDITIVE, DRILLING FLUID: LIQUID, ETHYLENE GLYCOL
MONOBUTYL ETHER SOLVENT, USED WITH NONANIONIC SURFACTANT (LOSURF-
259) TO REDUCE OIL WET TENDENCIES AND IMPROVE THE OVERALL WETTING
CONDITION OF THE FORM, ETHYLENE GLYCOL MONOBUTYL ETHER, 55 GALLON
DRUM , APPEARANCE: COLORLESS LIQUID, MILD ODOR, SPECIFIC GRAVITY: 0.9 @
20 DEG C BOILING POINT: 171 DEG C SOLUBLE IN WATER. ++ PREVENTS OIL WET
FINES FROM STABILIZING' EMULSIONS, NORMAL USE CONCENTRATION: 10 %
V/V. PRIMARILY USED DURING ACIDIZING OPERATIONS IN SILICATE FORMATION.
++ CONTAINER MUST BE PROPERLY LABELED WITH VENDOR'S NAME,
MANUFACTURE'S NAME LOCATION, PRODUCTION DATE AND BATCH NUMBER
AS NEEDED ++ N-FLOW 325 SYSTEM CONSISTS OF HALLIBURTON BAROID
PRODUCTS LOSURF-259, MUSOL, N-FLOW 325 & BDF-443.
1000811540
64
Chemicals
(Drilling Fluids)
N-FLOW 325
ADDITIVE DRILLING FLUID; LIQUID FORM,DIETHYLENE GLYCOL DIFORMATE,FOR
RELEASED FORMIC DISSOLVES CALCIUM CARBONATE TO REMOVE FILTER CAKE
AND REPAIR FILTER CAKE AND REPAIR MUD DAMAGE,DIETHYLENE GLYCOL
DIFORMATE,55 GALLON DRUM,ADDITIVE, DRILLING FLUID: LIQUID, DIETHYLENE
GLYCOL DIFORMATE , RELEASED FORMIC DISSOLVES CALCIUM CARBONATE TO
REMOVE FILTER CAKE AND REPAIR MUD DAMAGE, DIETHYLENE GLYCOL
DIFORMATE, 55 GALLON DRUM , APPEARANCE: LIGHT YELLOW LIQUID,ODOR:
CHARACTERISTIC, SPECIFIC GRAVITY 1.2 GM/CC, BOILING POINT:240 DEG C,
PH:2.8 SOLUBLE IN WATER ++ COMPATIBLE WITH OIL, FORMATION BRINE AND
DRILL- IN FLUID BASE OIL (DIESEL), THE CHEMICAL IS DISSOLVED IN THE CARRIER
BRINE, BECAUSE THE ACID LIBERATION ACTION IS SLOW. ACID WILL BE
GENERATED OVER THE SUBSEQUENT PERIOD OF TIME, NORMAL CO.
1000811647

Material Number
9COM/9CAT
65
Chemicals
(Drilling Fluids)
N-FLOW - BDF-443
ADDITIVE DRILLING FLUID; LIQUID FORM,SURFACTANT,FOR VALUE EMULSIFIER,
CHANGES THE WETTABILITY OF OIL MUD FILTER CAKE, FOR ACID
CLEANING,BLEND OF PROPRIERATORY CHEMICALS,55 GALLON DRUM,ADDITIVE,
DRILLING FLUID: LIQUID, SURFACTANT, EMULSIFIER, CHANGES THE WETTABILITY
OF OIL MUD FILTER CAKE, FOR ACID CLEANING, BLEND OF PROPRIERATORY
CHEMICALS, 55 GALLON DRUM , APPEARANCE: MILKY TO PALE YELLOW LIQUID,
ODOR: MILD SWEET, SPECIFIC GRAVITY 1.04 GM CC, BOILING POINT: 240 DEG C,
PH 5 - 7.5 (2.5 %), FLASH POINT: GREATER THAN 100 DEG C, SOLUBLE IN WATER
++ IS WATER WET SURFACTANT DISSOLVED IN THE CARRIER BRINE ALONG WITH
N-FLOW. IT CHANGES THE WETTABILITY OF OIL MUD FILTER CA.
1000812034
66
Chemicals
(Drilling Fluids)
LIQUID THINNER - 450 F
ADMIXTURE: DRILLING MUD; 25 KG DRUM. . . ADMIXTURE DRILLING MUD;
LIQUID FORM,MODIFIED ANIONIC SULPHONATED POLYACRYLATE,FOR
POLYMERIC DEFOCCULANT AND THINNER FOR USE IN LOW LOW SOLID NON
DISPERSED WATER BASE MUD TO IMPACT HIGH TEPERATURE STABILITY,5 GAL
PER CAN,UP TO 234 DEG C (450 DEG F), FOR DEEP WELL APPLICATIONS.
EFFECTIVE IN THE PRESENCE OF DIVALENT IONS AND SALTS.
1000021600
67
Chemicals
(Drilling Fluids)
HYDROXY ETHYL CELLULOSE
(HEC)
ADMIXTURE: DRILLING MUD; VISCOSIFIER; HYDROXY ETHYL CELLULOSE (HEC),
EXTREMELY HIGH-YIEDLING ADMIXTURE DRILLING MUD; DRY FREE FLOWING
WHITE POWDER FORM,HYDROXY ETHYL CELLULOSE (HEC),FOR MULTI-PURPOSE
VISCOSIFYING POLYMER RAPIDLY SOLUBLE IN FRESHWATER, SEA WATER SALT
SATURATED WATER AND COMPLEX BRINE SYSTEMS. IT IS STABLE AT 250 DEG
F.,HYDROXY ETHYL CELLULOSE (HEC),25 KG OR 50 LB BAG,WATER-SOLUBLE, NON-
IONIC, HIGH MOLECULAR WEIGHT POLYMER, SHIPMENT OF PRODUCT SHALL
CONFORM TO SAUDI NOTE: THE CONSTRUCTION OF THE MULTI-WALLED PAPER
BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY (INTERIOR PLY) 10# PE
COATING 0.000285 MICRON ALUMINUM SHEET 6# PE COATING 50 LB NATURAL
KRAFT PAPER. THE ALUMINUM SHEET IS COATED ON ONE SIDE WITH 10# PE THE
10# PE IS NEXT TO THE PRODUCT. THE COATED ALUMINUM SHEET IS LAMINATED
TO THE 50 LB KRAFT PAPER. 2ND PLY 50 LB NATURAL KRAFT PAPER. 3RD PLY 50
LB NATURAL KRAFT PAPER. 4TH PLY 50 LB BLEACHED WHITE NATURAL KRAFT
PAPER (EXTERIOR PLY). THE BLEACHED PAPER IS "FULLY BLEACHED WHITE". THE
BAG MUST BE VALVE/SPOUT TYPE, COMPLETELY SEALED AND MOISTURE AND
WATER PROOF.
1000021672

Material Number
9COM/9CAT
68
Chemicals
(Drilling Fluids)
XANTHAN GUM (POWDER)
ADMIXTURE COMPONENTS: XANTHAN GUM BIO-POLYMER; 25 KG (50 LB) BAG.
ADMIXTURE DRILLING MUD; DRY FREE FLOWING POWDER FORM,PURE XANTHAN
GUM BIO-POLYMER,FOR PRIMARILY USED FOR VISCOSITY/ SUSPENSION IN FRESH
WATER, SEA WATER, & SATURATED BRINE-BASED DRILLING, WORKOVER &
COMPLETION FLUIDS,PURE XANTHAN GUM BIO-POLYMER,25 KG OR 50 LB
BAG,SHIPMENT AND PACKING: 25 KG (50 LB) SEALED MULTI-WALL PAPER BAG
(WITH INNER POLYETHYLENE BAG TO PREVENT MOISTURE CONTACT), SHIPMENT
OF PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL.
1000021930
69
Chemicals
(Drilling Fluids)
ORGANOPHILIC CLAY - 400F
INVERTED EMULSION MUD COMPONENTS: 25 KG (50 LB) BAG; POWDER; DRY
WHITE, ADMIXTURE DRILLING MUD; WHITE, DRY, FREE FLOWING POWDER, FREE
OF LUMPS FORM,OIL-BASED DRILLING FLUID GELLING AGENT,FOR HELPS
VISCOSIFY ANY OIL- BASED DRILLING FLUIDS HELPS IMPROVED HOLE CLEA- NING
DURING DRILLING AND WORKOVER OPERATIONS DRILL OIL MUDS FOR LONG
TERM SUSPENSION OF WEIGHTING AGENTS IN PACKER FLUIDS & CASING
PACKS.,AMINE TREATED BETONITE, A BENTONITE CLAY THAT HAS BEEN TREATED
WITH AN AMINE COMPOUND TO PROMOTE ITS DISPERSION/YIELD IN OILS.,22.7
KG (50 LB) MULTI-WALL SACKS.,SPECIFIC GRAVITY: 1.57 TO 1.70 APPEARANCE:
OFF-WHITE TO TAN POWDER ODOR/TASTED: SLIGHT, AMINE SOLUBILITY:
INSOLUBLE IN WATER DISPERSIBLE IN ORGANIC SOLVENTS. DECOMPOSITION
TEMP: >200C DEG FLASH POINT: NON- FLAMMABLE REACTIVITY: CHEMICALLY
STAB,ORGANOPHILIC CLAY, USED TO IMPART VISCOSITY AND SUSPENSION
PROPERTIES TO OIL-BASED DRILLING FLUIDS ORGANOPHILIC CLAY VISCOSIFIER
TEMPERATURE APPROACHING APPROACHING 400 F DEG (20C DEG) IMPROVES
FILTER. CAKE QUALITY AND FILTARATION-CHARACTERISTICS PROVIDES GEL-
STRUCTURE AND VISCOSITY FOR THE- SUSPENSION OF WEIGHT MAERIALS
VICOSITY FOR IMPROVED- HOLE CLEANING CAPACITY EFFECTIVE GELLING AGENT
IN CASING PACKS AND PACKER FLUIDS.
1000022174

Material Number
9COM/9CAT
70
Chemicals
(Drilling Fluids)
POTASSIUM FORMATE (75% SOL,
WATER 25%)
ADMIXTURE DRILLING MUD; LIQUID FORM,POTASSIUM FORMATE SOLUTION
(KCOOH & H20),FOR FORMULATING SOLIDS FREE WORKOVER FLUIDS FOR USE IN
THE KHUFF AND PRE-KHUFF FORMATION,POTASSIUM FORMATE 75% AND
WATER 25% SOLUTION, CLEAR LIQUID, DENSITY 1570 KG/M3 @ 20 DEG C, PH
10.0 @ 25 DEG C,1000 LITER (1570 KG) IBC OR TOTE CONTAINER (CO),IRON LESS
THAN 10 PPM, CHLORIDE CONTENT LESS THAN 40 PPM, TURBIDITY MAX 10 NTU,
SOLUBLE IN ALL PROPORTIONS IN WATER EXPORT PACKING MANUAL.
1000774250
71
Chemicals
(Drilling Fluids)
POTASSIUM FORMATE CRYSTALS
(97% KCOOH)
ADMIXTURE DRILLING MUD; FREE FLOWING SOLID CRYSTALS FORM,POTASSIUM
FORMATE 97% WEIGHT (KCOOH),FOR FORMULATING SOLIDS FREE WORKOVER
FLUIDS FOR USE IN THE KHUFF AND PRE-KHUFF FORMATION,POTASSIUM
FORMATE 97% WEIGHT & CONDITIONING AGENT 3% WEIGHT, POWDER, WHITE
COLOR, BULK DENSITY 1080 KG/M3,25 KG MULTI-WALL SACK,SPECIFIC GRAVITY
(POWDER ONLY) 1.91, SOLUBILITY IN WATER 355 GR/100 ML @ 20 DEG C ,
MELTING POINT 169 DEG C TEMPERATURE STABILITY UP TO 400 ░F (204 ░C),
SHIPMENT OF PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT PACKING
MANUAL.
1000774251
72
Chemicals
(Drilling Fluids)
SODIUM FORMATE POWDER
(98% NACOOH)
ADMIXTURE DRILLING MUD; FREE FLOWING GRANULES FORM,SODIUM
FORMATE POWDER 98% (NACOOH),FOR FORMULATING SOLIDS FREE WORKOVER
FLUIDS FOR USE IN THE KHUFF AND PRE-KHUFF FORMATION,SODIUM FORMATE
98% WEIGHT & OTHER ORGANICS 2% WEIGHT, WHITE COLOR, BULK DENSITY 900-
950 KG/M3,25 KG MULTI-WALL SACK,SPECIFIC GRAVITY (POWDER ONLY) 1.92,
SOLUBILITY IN WATER 81GR/100 ML @ 20 DEG C , MELTING POINT 253 DEG C ,
TEMPERATURE STABILITY UP TO 400 ░F (204 ░C), SHIPMENT OF PRODUCT SHALL
CONFORM TO SAUDI ARAMCOEXPORT PACKING MANUAL.
1000774252
73
Chemicals
(Drilling Fluids)
LIGNITE
ADDITIVE DRILLING FLUID; POWDER FORM,LIGNITE / CRYSTALLINE SILICA,
QUARTZ,FOR USED TO AID IN FILTRATION CONTROL AND CONTROL VISCOSITY
AND GEL STRENGTHS OF WATER-BASED DRILLING FLUIDS,SACK PACKING (25 KG
OR 50 LB),USED TO APPEARANCE: BLACK POWDER, COLOUR: BLACK,
ODOUR/TASTE: ODORLESS, SPECIFIC GRAVITY: 1.7, SOLUBILITY IN WATER:
INSOLUBLE, BULK DENSITY AT 20 DEG C: 40 LBS/FT3, USED TO EMULSIFY OIL INTO
WATER-BASED FLUIDS, SHIPMENTS OF PRODUCT SHALL CONFORM TO SAUDI
ARAMCO EXPORT PACKING MANUAL.
1000827162

Material Number
9COM/9CAT
74
Chemicals
(Drilling Fluids)
POLYANIONIC CELLULOSE
REGULAR (PAC-R)
ADMIXTURE: DRILLING MUD POLYANIONIC CELLULOSE DERIVATIVE (REGULAR)
PAC-R ADMIXTURE DRILLING MUD; DRY, FREE FLOWING POWDER
FORM,POLYANIONIC CELLULOSE,FOR USED AS A FILTRATE REDUCER AND
SUPPLEMENTARY VISCOSIFIER TO FORM A THIN, RESILIENT FILTER CAKE. IT IS
EFFECTIVE IN FRESH WATER, SEA WATER AND SALT SATURATED FLUIDS,PURE,
SALT-FREE POLYANIONIC CELLULOSE POLYMER,MULTI-WALLED BAGS, 25 KG OR
50 LB BAG,API 13 I SUPPLEMENT-2, SECTION 22 (MAY, 2000 OR LATEST
EDITION),OTHER ASSOCIATED ELEMENTS IN THE COMPOSITION MUST NOT BE
HARMFUL TO PERSONNEL AND/OR ADVERSELY AFFECT FLUID PROPERTIES.
PROPER TUBE SAMPLING AND QUARTERING TO BE CARRIED OUT BY TRAINED
AND EXPERIENCED PERSONNEL. POLYANIONIC CELLULOSE, PAC-R SHALL NOT
CONTAIN ANY OTHER POLYSACCHARIDES SUCH AS STARCH, GUAR, OR OTHER
POLYMERS OR THEIR DERIVATIVES NOTE: THE CONSTRUCTION OF THE MULTI-
WALLED PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY 50 LB MIN.
NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY 50 LB MIN. NATURAL KRAFT
PAPER 3RD PLY SEPARATE INNER BAG LINER, HIGH DENSITY ORIENTED AND
CROSS-LAMINATED INNER LINER (TUBULAR SHAPE) MADE OF POLYETHYLENE
RESIN MATERIAL WITH A MINIMUM WALL THICKNESS OF 0.1 MM. 4TH PLY 50 LB
MIN.
1000021605
75
Chemicals
(Drilling Fluids)
CHROME FREE LIGNOSULFONATE
ADMIXTURE: DRILLING MUD; 25 KG (50 LB) SACK; SHIPMENT OF PRODUCT SHALL
CONFORM TO SAUDI ARAMCO EXPORT ADMIXTURE DRILLING MUD; POWDER
FORM,MODIFIED CHROME FREE LIGNOSULFONATE,FOR DISPERSANT FOR
REDUCING VISCOSITY & GELS IN SALTY, GYPPY & FRESH WATER MUDS,25 KG OR
50 LB BAG,API 13A,FREE FLOWING, SHIPMENT OF PRODUCT SHALL CONFORM TO
SAUDI ARAMCO EXPORT PACKING MANUAL NOTE: THE CONSTRUCTION OF THE
MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY 50 LB
MIN. NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY 50 LB MIN. NATURAL
KRAFT PAPER 3RD PLY SEPARATE INNER BAG LINER, HIGH DENSITY ORIENTED
AND CROSS-LAMINATED INNER LINER (TUBULAR SHAPE) MADE OF
POLYETHYLENE RESIN MATERIAL WITH A MINIMUM WALL THICKNES OF 0.1 MM.
4TH PLY 50 LB MIN. NATURAL KRAFT PAPER. 5TH PLY 60 LB MIN. NATURAL KRAFT
PAPER WET STRENGTH (EXTERIOR PLY) THE BAG MUST BE VALVE/SPOUT TYPE,
COMPLETELY SEALED, MOISTURE AND WATER PROOF.
1000021670
76
Chemicals
(Drilling Fluids)
DETERGENT
AGENT: WELL STIMULANT; 20 LITER (5GAL.) CAN. . AGENT WELL STIMULANT; FOR
SURFACTANT & DETERGENT FOR DRILLING WATER & LOW SOLID MUD,LIQUID
FORM,20 L OR 5 GAL CAN.
1000021975

Material Number
9COM/9CAT
77
Chemicals
(Drilling Fluids)
CALCIUM CHLORIDE (77-78%)
2200 lb/BAG
ADMIXTURE, CEMENT: ADDITIVE, CEMENT, 1000 KG PER BAG, CALCIUM
CHLORIDE ADMIXTURE CEMENT; FOR WATER SOLUBLE WEIGHTING AGENT FOR
FORMULATING SOLIDS-FREE COMPLETION BRINES AND TO PROVIDE THE DESIRED
WATER PHASE ACTIVITY IN INVERT EMULSION MUDS. ALSO USED AS AN
ACCELERATOR IN OIL WELL CEMENT SLURRIES,TYPE 1,77-78% CALCIUM
CHLORIDE (CACL2), FLAKES OR PELLETS,1000 KG OR 2200 LBS BAG,ASTM D98-
68,LIFTING STRAP, BAG IS DISPOSABLE, TOP CLOSURE WATERTIGHT, STACKABLE
& WITHOUT BOTTOM SPOUT, MINIMUM TENSILE STRENGTH FACTOR 5,
FLEXURAL STRENGTH FOR NORMAL HANDLING & OUTSIDE STORAGE NO
PARTICLES GREATER THAN 2MM IN ANY DIMENSION, MULTI-WALL MOISTURE-
PROOF POLYETHYLENE LINED BAGS W/LIFTING STRAPS, WITHOUT BOTTOM
SPOUT. DRY, FREE FLOWING FLAKES, GRANULES OR PELLETS.
1000022533
78
Chemicals
(Drilling Fluids)
NVIS HI - 50 LB
ADMIXTURE DRILLING MUD; POWDER, SOLID FORM,SILICATE,FOR VISCOSIFIER
USED IN MILLING CASING WINDOWS,CALCIUM ALUMINOSILICATE,50 LB SEALED
MULTI-WALL PAPER BAG,GRAY COLOR, SPECIFIC GRAVITY 0.6@ 20 DEG C, PH 11,
INSOLUBLE IN WATER, ODERLESS, SHIPMENT OF PRODUCT SHALL CONFORM TO
SAUDI ARAMCO EXPORT PACKING MANUAL THE ORIGINAL MANUFACTURER ,
PRODUCT NAME, BATCH NUMBER, DATE OF PRODUCTION OF MATERIAL,
EXPIRATION DATE IF REQUIRED, STOCK NUMBER AND COUNTRY OF ORIGIN BE
PRINTED ON THE CONTAINER, THE CONSTRUCTION OF THE MULTI-WALLED
PAPER BAG FOLLOWS: (CONTAINER) SHALL BE AS 1ST PLY 50 LB MIN. NATURAL
KRAFT PAPER (INTERIOR PLY) 2ND PLY 50 LB MIN. NATURAL KRAFT PAPER 3RD
PLY SEPARATE INNER BAG LINER , HIGH DENSITY ORIENTED AND CROSS-
LAMINATED INNER LINER (TUBULAR SHAPE) MADE OF POLYETHYLENE RESIN
MATERIAL WITH A MINIMUM WALL THICKNESS OF 0.1 MM. 4TH PLY 50 LB MIN.
1000757569

Material Number
9COM/9CAT
79
Chemicals
(Drilling Fluids)
H2S SCAVENGER, POWDER
ADMIXTURE DRILLING MUD; POWDER, GRANULAR FORM,ORGANOMETAL,FOR
SCAVENGES HYDROGEN SULFIDE FROM DRILLING FLUIDS,IRON GLUCONATE,25
KG SEALED MULTI-WALL PAPER BAG,SOLID, LIGHT YELLOW GREEN COLOR, BULK
DENSITY 650 - 850 KG/M3 @ 20 DEG C, PH 4.5 (1% AQUEOUS SOLUTION),
SOLUBLE IN WATER, MILD BURNT SUGAR ODOR, SHIPMENT OF PRODUCT SHALL
CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL THE ORIGINAL
MANUFACTURER , PRODUCT NAME, BATCH NUMBER, DATE OF PRODUCTION OF
MATERIAL, EXPIRATION DATE IF REQUIRED, STOCK NUMBER AND COUNTRY OF
ORIGIN BE PRINTED ON THE CONTAINER, THE CONSTRUCTION OF THE MULTI-
WALLED PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS 1ST PLY 75 LB MIN.
NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY 75 LB MIN. NATURAL KRAFT
PAPER 3RD PLY SEPARATE INNER BAG LINER, HIGH DENSITY ORIENTED AND
CROSS-LAMINATED INNER LINER (TUBULAR SHAPE) MADE OF POLYETHYLENE
RESIN MATERIAL WITH A MINIMUM WALL THICKNES OF 0.1 MM. 4TH PLY 80 LB
MIN. NATURAL KRAFT PAPER (EXTERIOR PLY).
1000757581
80
Chemicals
(Drilling Fluids)
ACID SOLUBLE FIBER
ADMIXTURE DRILLING MUD; POWDER, SOLID FORM,SPUN MINERAL FIBER,FOR
CONTROLS SEEPAGE, BRIDIGING, PLUGGING VOIDS, FRACTURES DURING
WORKOVER OPERATIONS,CRYSTALLINE SILICA, QUARTZ AND BLAST FURNACE
SLAG,30 LB SEALED MULTI-WALL PAPER BAG,WHITE TO GRAY COLOR, SPECIFIC
GRAVITY 2.6@ 20 DEG C, PH 7-8, BULK DENSITY 12-26 LBS/GALLON @ 20 DEG C
INSOLUBLE IN WATER, ODERLESS, SHIPMENT OF PRODUCT SHALL CONFORM TO
SAUDI ARAMCO EXPORT PACKING MANUAL THE ORIGINAL MANUFACTURER ,
PRODUCT NAME, BATCH NUMBER, DATE OF PRODUCTION OF MATERIAL,
EXPIRATION DATE IF REQUIRED, STOCK NUMBER AND COUNTRY OF ORIGIN BE
PRINTED ON THE CONTAINER, THE CONSTRUCTION OF THE MULTI-WALLED
PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY 30 LB MIN. NATURAL
KRAFT PAPER (INTERIOR PLY) 2ND PLY 30 LB MIN. NATURAL KRAFT PAPER 3RD
PLY SEPARATE INNER BAG LINER, HIGH DENSITY ORIENTED AND CROSS-
LAMINATED INNER LINER (TUBULAR SHAPE) MADE OF POLYETHYLENE RESIN
MATERIAL WITH A MINIMUM WALL THICKNES OF 0.1 MM. 4TH PLY 30 LB MIN.
NATURAL KRAFT PAPER. 5TH PLY 30 LB MIN. NATURAL KRAFT PAPER WET
STRENGTH (EXTERIOR PLY).
1000757582

Material Number
9COM/9CAT
81
Chemicals
(Drilling Fluids)
SULPHONATE ASPHALT
CONFORM TO SAUDI ARAMCO EXPORT ADMIXTURE DRILLING MUD; BLACK, DRY,
FREE FLOWING POWDER OR FLAKES, FREE OF LUMPS FORM,MODIFIED
HYDROCARBON COMPOUND SODIUM ASPHALT SULPHONATE. OTHER
ASSOCIATED ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL AND/OR
ADVERSELY AFFECT FLUID PROPERTIES.,FOR STABILIZES SHALE FORMATIONS
REDUCES TORQUE AND DRAG, INHIBITS THE DISPERSION OF DRILL SOLIDS,
REDUCES FILTRATE, EMULSIFIER COMPATIBLE TO ALL MUD SYSTEMS, AS IT IS
SOLUBLE IN BOTH OIL & WATER. HAS GOOD EMULSIFYING CHARACTERISTICS.
REDUCES THE FREQUENCY OF STUCK PIPE HAS NO ADVERSE EFFECTS ON MUD
PROPERTIES.,A BLEND OF HYDROXYLATED SODIUM ASPHALT SULPHONATE WITH
MINOR AMOUNTS OF ASPHALT PHENALATES, INORGANIC SALTS & OXIDIZED
ASPHALT. EXHIBITS SOME FLUORESCENCE. HOWEVER, THIS PROBLEM IS USUALLY
ELIMINATED THROUGH THE WASHING OF CUTTINGS.
1000021607
82
Chemicals
(Drilling Fluids)
HYDRATED CALCIUM SULFATE -
GYPSUM
ADMIXTURE: DRILLING MUD; 25 KG/SACK; CALCIUM SULFATE (GYPSUM)
ADMIXTURE DRILLING MUD; DRY, FREE FLOWING FINE WHITISH POWDER
FORM,HYDRATED CALCIUM SULFATE,FOR A SOURCE OF CALCIUM IONS TO TREAT
CARBONATE CONTAMINATION IN HIGH PH MUDS, AND TO AVOID HOLE
ENLARGEMENT WHEN ANHYDRITE IS DRILLED,25 KG OR 55 LBS/SACK,SHIPMENT
OF PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL
MULTI-WALLED PAPER BAGS, CONTAINER PROPERLY LABELED, W/VENDOR'S
NAME, MANUFACTURER'S NAME LOCATION, PRODUCTION DATE AND BATCH
NO.,SAUDI ARAMCO STOCK NUMBER AND SAUDI ARAMCO P.O. NUMBER NOTE:
THE CONSTRUCTION OF THE MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE
AS FOLLOWS: 1ST PLY 75 LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY
75 LB MIN. NATURAL KRAFT PAPER. 3RD PLY 80 LB MIN. NATURAL KRAFT PAPER
(EXTERIOR BF PLY) THE BAG MUST BE VALVE/SPOUT TYPE COMPLETELY SEALED,
PACKING SPEC CODES 8444-18 APPLIES.
1000021559
83
Chemicals
(Drilling Fluids)
XANTHAN GUM (LIQUID
SUSPENSION)
ADDITIVE; 5 GAL PER PAIL,ADDITIVE: DRILLING MUD LIQU XANTHAN GUM USED
TO BUILD VISCOSITY AND GEL STRENGTH IN WATER BASED DRILLING WORKOVER
AND COMPLLETION FLUIDS. ALSO UNIQUE WITH ITS ABILITY TO FLOW AND MIX
HOMOGENOUSLY WITHOUT CREATING "LUMP"AND PROVIDES LOW-SOLIDS
CONTENTS IN THE MIXED FLUID 5 GAL/PAIL. APPEARANCE: CREAM LIQUID,
SG@20C (WATER=1): 0.95-1.05 SOLUBILITY IN WATER: MISCIB PH: (1%SOL.IN DIS
WATER, 77.
1000815368

Material Number
9COM/9CAT
84
Chemicals
(Drilling Fluids)
SIZED CACO3 AND POLYMERS
LCM
ADMIXTURE DRILLING MUD; ADMIXTURE FORM,BLEND OF SIZED CACO3 AND
POLYMERS,FOR REDUCES FLUID INVASION WITHOUT DAMAGING THE
FORMATION BY SEALING GAUGE SCREEN FROM INTERNAL SIDE TO BE EASILY
REMOVED WITH PRODUCTION FLUID FLOW.,BLEND OF SIZED CACO3 AND
POLYMERS,BBL.
1000876985
85
Chemicals
(Drilling Fluids)
Spacer-Tek - SBP-9125
SURFACTANT
AGENT WELL STIMULANT; FOR MIXED WITH OTHER SURFACTANTS TO PROVIDE
OPTIMUM CLEANING OF SYNTHETIC AND OIL-BASED MUD SURFACTANT WITH
LOWER HLB NUMBER FOR LOWER TEMPERATURE CLEANING APPLICATION
SPACER-TEK SYSTEM CONSISTS OF SBP-24 DEFOAMER , SBP-85 GEL-E POLYMER,
SBP-101 SOLVENT, SBP,ETHOXYLATED ALCOHOL BASE,LIQUID
FORM,DRUM,APPEARANCE: LIGHT YELLOWIS CLEAR SOLUTION DENSITY: 0.92 PH:
7-8 PLASH POINT: 255 F.
1000877462
86
Chemicals
(Drilling Fluids)
SURFACTANT
OPTIMUM CLEANING OF SYNTHETIC AND OIL-BASED MUD OVER A WIDE RANGE
OF TEMPERATURES SPACER-TEK SYSTEM CONSISTS OF SBP-24 DEFOAMER , SBP-
85 GEL-E POLYMER, SBP-101 SOLVENT, SBP-4620 SURFACTANT, SBP-9125
SURFACTANT SBP,BLEND OF NON-IONIC SURFACTANTS AND LINEAR ALCOHOL CO-
SOLVENT,LIQUID FORM,DRUM,APPEARANCE: LIGHT YELLOWIS CLEAR SOLUTION
DENSITY: 1.002 PH: 7-8 PLASH POINT: > 200 F.
1000877461
87
Chemicals
(Drilling Fluids)
Spacer-Tek - SBP-101 SOLVENT
AGENT WELL STIMULANT; FOR USED AS THE PRIMARY CLEANING PILL FOR
DISPLACEMENT CLEANUP OF SYNTHETIC AND OIL-BASED DRILLING MUD. THE
SOLVENT PRODUCT IS TYPICALLY MIXED WITH BRINE TO PROVIDE DISPERSED
MACRO DROPLETS OF SOLVENT IN BRINE AND ALSO A HIGHER SOLVENT PILL
DENSITY FOR SUPER,BLENDS OF SURFACTANTS AND SOLVENTS,LIQUID
FORM,DRUM,APPEARANCE: LIGHT YELLOWIS CLEAR SOLUTION DENSITY: 0.85-
0.87 PLASH POINT: 122 F.
1000877460
88
Chemicals
(Drilling Fluids)
Spacer-Tek - SBP-SPACER MIX
AGENT WELL STIMULANT; FOR TO DEVELOP THE VISCOSITY AND GELLING AND TO
BE EASILY HYDRATED EVEN UNDER A LIMITED MIXING CONDITION. ALSO, IT
ENHANCES THE HIGH TEMPERATURE VISCOSITY PERFORMANCE IN SOLID-FREE
POLYMER GEL. TYPICAL TREATMENT: 8-25 LB/BBL. SPACER-TEK SYSTEM CONSISTS
OF,PATENTED BLEND OF VISCOSIFIERS AND DISPERSANT,POWDER
FORM,BAG,APPEARANCE: BEIGE-COLORED P S.G.: 1.76.
1000877299

Material Number
9COM/9CAT
89
Chemicals
(Drilling Fluids)
Spacer-Tek - SBP-600 BIOCIDE
AGENT WELL STIMULANT; FOR TO CONTROL ALL FORMS OF BACTERIA WHICH IS
PARTICULARLY DETRIMENTAL IN FRESH AND BRINE-WATER DRILLING AND
PACKER FLUIDS TYPICAL TREATMENT: 5 GAL/100 BBL. SPACER-TEK SYSTEM
CONSISTS OF SBP-24 DEFOAMER , SBP-85 GEL-E POLYMER, SBP-101 SOLVENT, SBP
4620,BLENDED ORGANIC SULFUR ANTIMICROBIAL AGENT,POWDER
FORM,PAIL,APPEARANCE: WHITE CRYSTAL SPECIFIC GRAVITY: 0.96.
1000877298
90
Chemicals
(Drilling Fluids)
Spacer-Tek - SBP-85 GEL-E
AGENT WELL STIMULANT; FOR NON-DAMAGING VISCOSIFIER THAT READILY
DISPERSIBLE IN ALL BRINE SYSTEMS AND EASIER TO USE THAN DRY VISCOSIFIERS .
IT IS SOLUBLE IN HYDROCHLORIC, ACETIC AND FORMIC ACIDS AND DEGRADABLE
AT TEMPERATURES ABOVE 275°F,BLEND OF XANTHAN GUM/ORGANIC
SOLVENT,LIQUID FORM,PAIL,APPEARANCE: BEIGE COLORED SPECIFIC GRAVITY:
1.07 PH: 7 FLASH POINT: 160 F.
1000877297
91
Chemicals
(Drilling Fluids)
Spacer-Tek - SBP-24 DEFOAMER
AGENT WELL STIMULANT; FOR TO CONTROL FOAMING IN SPACER OR CLEANING
FLUID FORMULATIONS TYPICALLY TREATMENT: 100-500 PPM. SPACER-TEK
SYSTEM CONSISTS OF SBP-24 DEFOAMER , SBP-85 GEL-E POLYMER, SBP-101
SOLVENT SBP-4620 SURFACTANT, SBP-9125 SURFACTANT, SBP-9755 SURFACTANT
SBP-600,SILICONE EMULSION BASE,LIQUID FORM,PAIL,APPEARANCE: WHITE
CREAMY SPECIFIC GRAVITY: 0.99 PH: 7-8.
1000877296
92
Chemicals
(Drilling Fluids)
SURFACTANT
OPTIMUM CLEANING OF SYNTHETIC AND OIL-BASED MUD OVER A WIDE RANGE
OF TEMPERATURES. SPACER-TEK SYSTEM CONSISTS OF SBP-24 DEFOAMER ,SBP-
85 GEL-E POLYMER, SBP-101 SOLVENT, SBP-4620 SURFACTANT, SBP-9125
SURFACTANTS,ALKYL POLYGLUCOSIDE BASE,LIQUID FORM,DRUM,APPEARANCE:
LIGHT YELLOWIS CLEAR SOLUTION DENSITY: 1.1 PH: 7-8 PLASH POINT: 212 F.
1000877463
93
Chemicals
(Drilling Fluids)
MODIFIED POLYMER FOR FLUID
LOSS
ADDITIVE DRILLING FLUID; POWDER FORM,BLEND OF MODIFIED POLYMERS,FOR
PROVIDES CENTRAL TO THE ULTRA-LOW INVASIVE FLUID AND GREATLY REDUCES
FLUID INVASION INTO MATRIX. TYPICAL TREATMENT: 3- 8 LB/BBL.,BLEND OF
MODIFIED POLYMERS,25 POUND MULTI-WALLED SACKS,APPEARANCE: POWDER
TO FLAKE. SPECIFIC GRAVITY: 1.0.
1000883084

Material Number
9COM/9CAT
94
Chemicals
(Drilling Fluids)
LUBRICANT OBM
ADDITIVE DRILLING FLUID; LIQUID FORM,MIXTURE OF FATTY ACIDS AND
SPECIALTIES,FOR DRILLING LUBE IS USED TO HELP IMPROVE LUBRICITY OF OIL-
BASED MUD SYSTEMS, THEREBY HELPING TO REDUCE TORQUE AND DRAG, AND
REDUCING RISK OF DIFFERENTIAL STICKING IN DEEP, TORTUOUS, HIGH ANGLE OR
EXTENDED REACH WELLS,MIXTURE,55-GALLON (208 LITRE) DRUM,APPEARANCE:
AMBER LIQUID. POUR.
1000885304
95
Chemicals
(Drilling Fluids)
THERMASET 100-2
ADDITIVE DRILLING FLUID; LIQUID FORM,POLYESTER RESIN BASE,FOR THERMALLY
ACTIVATED LIQUID LOST CIRCULATION MATERIAL THAT MAKES AN
INSTANTANEOUS SEAL ACROSS ANY FRACTURE OR VUGS TO STOP
LOSTCIRCULATION OF DRILLING FLUID AND ALSO SEAL OFF CASING
LEAKS.,POLYESTER RESIN BASE,IBC,APPEARANCE: YELLOW LIQUID. DEN,WORKING
TEMPERATURE RANGE IS 212 °F - 302 °F FOR HIGH TEMPERATURE APPLICATIONS.
THERMASET SYSTEM CONSISTS OF THERMASET 100-2 OR 55-4, AEROSOL 200,
NORPOL PEROXIDE 40(CI 40), DIBENZOYL PEROXIDE (CI 65) MICROMAX FILLER
AND GLASS FILLER.
1000888051
96
Chemicals
(Drilling Fluids)
THERMASET 55-4
ADDITIVE DRILLING FLUID; LIQUID FORM,POLYESTER RESIN BASE,FOR THERMALLY
ACTIVATED LIQUID LOST CIRCULATION MATERIAL THAT MAKES AN
INSTANTANEOUS SEAL ACROSS ANY FRACTURE OR VUGS TO STOP LOST
CIRCULATION OF DRILLING FLUID AND ALSO SEAL OFF CASING LEAKS.,POLYESTER
RESIN BASE,IBC,APPEARANCE: YELLOW LIQUID. DEN,WORKING TEMPERATURE
RANGE IS 140 °F - 275 °F FOR LOW TEMPERATURE APPLICATIONS. THERMASET
SYSTEM CONSISTS OF THERMASET 100-2 OR 55-4, AEROSOL 200, NORPOL
PEROXIDE 40(CI 40), DIBENZOYL PEROXIDE (CI 65) MICROMAX FILLER AND GLASS
FILLER.
1000888052
97
Chemicals
(Drilling Fluids)
THERMASET Glass Filler
ADDITIVE DRILLING FLUID; SOLID (PULVERIZED POWDER) FORM,GLASS
BEADS,FOR IT IS CHEMICALLY INERT WEIGHTING MATERIAL FOR LOW DENSITY
FLUIDS. IT IS USED IN THERMASET LCM SYSTEM. IT IS STABLE AT TEMPERATURES
UP TO 1112 °F.,GLASS BEADS,BAG,APPEARANCE: SOLID CLEAR AND ODORLESS.
SG1: 0.
1000888050
98
Chemicals
(Drilling Fluids)
THERMASET Aerosol/orisil 200
ADDITIVE DRILLING FLUID; SOLID FORM,SILICON DIOXIDE,FOR ESPECIAL
VISCOSIFIER FOR THERMASET LCM SYSTEM. IT CAN BE USED IN TEMPERATURE
RANGE OF 32 °F - 1112 °F.,SILICON DIOXIDE,BAG,APPEARANCE: SOLID ODORLESS.
SG: 2.2.
1000888053
99
Chemicals
(Drilling Fluids)
THERMASET CI-40
ADDITIVE DRILLING FLUID; LIQUID FORM,TERT-BUTYL PERBENZOATE,FOR CURING
AGENT (ACCELERATOR) FOR THERMASET LCM SYSTEM FOR HIGH TEMPERATURE
APPLICATIONS (205 °F - 266 °F),TERTIARY-BUTYL
PEROXYBENZOATE,CAN,APPEARANCE: LIQUID. DENSITY: 1.
1000888054

Material Number
9COM/9CAT
100
Chemicals
(Drilling Fluids)
THERMASET CI-65
ADDITIVE DRILLING FLUID; LIQUID DISPERSION FORM,DIBENZOYL PEROXIDE,FOR
CURING AGENT (ACCELERATOR) FOR THERMASET LCM SYSTEM FOR LOW
TEMPERATURE APPLICATIONS (32 °F – 205 °F),DIBENZOYL PEROXIDE/ C 9-11
BRANCHED ALKYLBENZOATE,CAN,APPEARANCE: LIQUID. COLOR: WHI.
1000888055
101
Chemicals
(Drilling Fluids)
THERMASET CLEANER
ADDITIVE DRILLING FLUID; LIQUID FORM,DIMETHYL SUCCINATE, DIMETHYL
GLUTARATE, DIMETHYL ADIPATE,FOR IT IS A CLEANING AGENT USED IN
THERMASET SYSTEM APPLICATIONS TO CLEAN OILY AREAS IN TANKS, PIPES,
ETC.,DIMETHYL SUCCINATE, DIMETHYL GLUTARATE, DIMETHYL
ADIPATE,IBC,APPEARANCE: LIQUID. COLOR: LIG.
1000888056
102
Chemicals
(Drilling Fluids)
DI-TROL
ADDITIVE DRILLING FLUID; SOLID FORM,SPECIAL BRANCHED CHAIN MODIFIED
STARCH DERIVATIVE,FOR PROVIDES BOTH VISCOSITY AND FLUID LOSS CONTROL
IN DIVALENT DRILLING FLUID SYSTEM MIXED IN CALCIUM CHLORIDE OR CALCIUM
BROMIDE BRINES IN MI-SWACO DI-PRO SYSTEM.,HIGH MOLECULAR WEIGHT,
BRANCHED-CHAIN STARCH DERIVATIVE,A 25 KG MULTI-WALLED SACK,TYPICAL
PHYSICAL AND CHEMICAL,ORDER UNIT OF MEASURE AND UNIT OF ISSUE SHOULD
BE IN SACKS (1 SACK = 25 KGS). CONTAINER MUST BE PROPERLY LABELED WITH
VENDOR'S NAME, MANUFACTURER'S NAME, LOCATION, PRODUCTION DATE AND
BATCH NUMBER. SAUDI ARAMCO WILL CARRY OUT PROPER SAMPLING AND
TESTING AS NEEDED. NOTE: DI-TROL IS NOT COMPATIBLE FOR USE IN MONO-
VALENT BRINES.#IT WORKS SYNERGISTICALLY WITH OTHER COMPONENTS OF DI-
PRO SYSTEM MAINLY DI-BALANCE (MM: 1000892842) AND DI-BOOST (MM:
1000892844). IT WORKS SYNERGISTICALLY WITH DI-BALANCE TO ENHANCE THE
LSRV.
1000892845
103
Chemicals
(Drilling Fluids)
DI-BALANCE
ADDITIVE DRILLING FLUID; SOLID FORM,FINE PARTICLE-SIZE MAGNESIUM
COMPOUND,FOR CONTROLS THE PH OF BRINE-BASED AQUEOUS DRILLING FLUID
SYSTEMS MIXED IN ZINC BROMIDE, CALCIUM CHLORIDE OR CALCIUM BROMIDE
IN MI-SWACO'S DI-PRO MUD SYSTEM.,MINIMUM PERCENTAGE AS MGO: 98,A 25
KG MULTI-WALLED SACK,PHYSICAL PROPERTIES: APPEARANC,ORDER UNIT OF
MEASURE AND UNIT OF ISSUE SHOULD BE IN SACKS (1 SACK = 25 KGS).
1000892842

Material Number
9COM/9CAT
104
Chemicals
(Drilling Fluids)
DI-BOOST
ADDITIVE DRILLING FLUID; LIQUID FORM,DIETHYLENE GLYCOL,FOR A VISCOSITY
ENHANCER AND STABILIZER IN DI-VALENT DRLG FLUID SYSTEMS MIXED IN
CALCIUM CHLORIDE OR CALCIUM BROMIDE BRINES IN MI-SWACO DI-PRO
SYSTEM. IT REDUCES DI-PRO SYSTEM VISCOSITY IF CONCENTRATION EXCEEDS 1.0
% BY VOLUME.,DIETHYLENE GLYCOL: 100% PURITY,7.6 LITERS CAN,PHYSICAL AND
CHEMICAL PROPERTI,ORDER UNIT OF MEASURE AND UNIT OF ISSUE SHOULD BE
IN CANS (1 CAN = 7.6 LITERS). CONTAINER MUST BE PROPERLY LABELED WITH
VENDOR'S NAME, MANUFACTURER'S NAME, LOCATION, PRODUCTION DATE AND
BATCH NUMBER. SAUDI ARAMCO WILL CARRY OUT PROPER SAMPLING AND
TESTING AS NEEDED. NOTE: DI-BOOST WORKS SYNERGISTICALLY WITH OTHER
COMPONENTS OF DI-PRO SYSTEM MAINLY DI-BALANCE (MM: 1000892842) AND
DI-TROL (MM: 1000892845).
1000892844
105
Chemicals
(Drilling Fluids)
LE SPERMUL - OBM emulsion
control
ADDITIVE DRILLING FLUID; LIQUID FORM,EMULSIFIER FOR INVERT EMULSION
MUD,FOR THIS IS PART OF HIGH PERFORMANCE CLAY-FREE OBM SYSTEM. A
LIQUID PRIMARY EMULSIFIER AND OIL-WETTING AGENT FOR USE IN MINERAL OIL-
OR DIESEL OIL OR SYNTHETIC OIL-BASED DRILLING FLUID SYSTEMS OF INNOVERT,
INTEGRADE OR ENCORE DRILLING FROM HALLIBURTON BAROID.,A PROPRIETARY
EMULSIFIER MIXTURE,DRUM,APPEARANCE: CLEAR AMBER VISCOU,REQUIRED
QTY: 55 GAL PER DRUM.
1000904194
106
Chemicals
(Drilling Fluids)
FACTANT - OBM emulsifer
ADDITIVE DRILLING FLUID; LIQUID FORM,EMULSIFIER AND WETTING AGENT FOR
INVERT EMULSION MUD,FOR THIS IS PART OF HIGH PERFORMANCE CLAY-FREE
OBM SYSTEM. A LIQUID EMULSIFIER AND OIL-WETTING AGENT FOR USE IN
MINERAL OIL- OR DIESEL OIL OR SYNTHETIC OIL-BASED DRILLING FLUID SYSTEMS
OF INNOVERT, INTEGRADE OR ENCORE DRILLING FROM HALLIBURTON BAROID.,A
PROPRIETARY EMULSIFIER MIXTURE,DRUM,APPEARANCE: DARK VISCOUS
LIQUI,REQUIRED QTY: 55 GAL PER DRUM.
1000904195
107
Chemicals
(Drilling Fluids)
BHD-513 - OBM filtrate control
ADDITIVE DRILLING FLUID; SOLID FORM,CROSS-LINKED POLYMER SOLID,FOR THIS
IS PART OF HIGH PERFORMANCE CLAY-FREE OBM SYSTEM. A CROSS-LINKED
POLYMER SOLID THAT PROVIDES FILTRATION CONTROL FOR USE IN MINERAL OIL-
OR DIESEL OIL OR SYNTHETIC OIL-BASED DRILLING FLUID SYSTEMS OF INNOVERT,
INTEGRADE OR ENCORE OF HALLIBURTON BARO,A CROSS-LINK POLYMER
SOLID,BAG,APPEARANCE: SOLID. SPECIFIC GR,REQUIRED QTY: 25 KG PER BAG.
1000904196

Material Number
9COM/9CAT
108
Chemicals
(Drilling Fluids)
BDF-489 - OBM viscofifier
ADDITIVE DRILLING FLUID; SOLID FORM,ORGANIC BASED VISCOSIFER,FOR THIS IS
PART OF HIGH PERFORMANCE CLAY-FREE OBM SYSTEM. AN ORGANIC BASED
RHEOLOGY MODIFIER FOR USE IN MINERAL OIL- OR DIESEL OIL OR SYNTHETIC OIL-
BASED DRILLING FLUID SYSTEMS OF INNOVERT, INTEGRADE OR ENCORE OF
HALLIBURTON BAROID.,ORGANIC BASED VISCOSIFIER,25 KG BAG,APPEARANCE:
SOLID WHITE. MELTING POINT: 55,REQUIRED QTY: 25 KG PER BAG.
1000904197
109
Chemicals
(Drilling Fluids)
ADAPTA - OBM filtrate control
ADDITIVE DRILLING FLUID; SOLID FORM,METHYLSTYRENE ACRYLATE
COPOLYMER,FOR THIS IS PART OF HIGH PERFORMANCE CLAY-FREE OBM SYSTEM.
PRIMARY FILTRATION CONTROL AGENT FOR USE IN MINERAL OIL- OR DIESEL OIL
OR SYNTHETIC OIL-BASED DRILLING FLUID SYSTEMS OF INNOVERT, INTEGRADE
OR ENCORE OF HALLIBURTON BAROID.,METHYLSTYRENE ACRYLATE
COPOLYMER,25 KG BAG,APPEARANCE: SOLID WHITE. SPECIFIC GRAVITY
:,REQUIRED QTY: 25 KG PER BAG.
1000904198
110
Chemicals
(Drilling Fluids)
RHEOMOD-L- OBM viscosifer
ADDITIVE DRILLING FLUID; LIQUID FORM,MODIFIED TRIMER FATTY ACID,FOR THIS
IS PART OF HIGH PERFORMANCE CLAY-FREE OBM SYSTEM. LIQUID POLYMERIC
VISCOSIFIER AGENT FOR USE IN MINERAL OIL- OR DIESEL OIL OR SYNTHETIC OIL-
BASED DRILLING FLUID SYSTEMS OF INNOVERT, INTEGRADE OR ENCORE OF
HALLIBURTON BAROID.,MODIFIED TRIMER FATTY ACID,55 GAL
DRUM,APPEARANCE: LIQUID DARK. SPECIFIC GRAVITY : 0,REQUIRED QTY: 55 GAL
PER DRUM.
1000904199
111
Chemicals
(Drilling Fluids)
TAU-MUD - OBM viscofifier
ADDITIVE DRILLING FLUID; POWDER FORM,CYRISTALLINE SILICA AND
SEPIOLITE,FOR A HIGH TEMPERATURE VISCOSIFER, ONE OF THE COMPONENT OF
CLAY FREE OIL-BASED DRILLING FLUID SYSTEMS OF HALLIBURTON # BAROID
INNOVERT (LOW TOXICITY MINERAL OIL BASE) AND INTEGRADE (DIESEL BASE).
1000908546
112
Chemicals
(Drilling Fluids)
RHEOLOGY MODIFIER -
OMNIPLEX
ADDITIVE DRILLING FLUID; LIQUID FORM,ANIONIC SYNTHETIC POLYMER IN
EMULSION FORM,FOR A LIQUID POLYMERIC PREMIER VISCOSIFIER WHICH HELPS
TO IMPROVE THE RHEOLOGICAL AND SUSPENSION CHARACTERISTIC OF LOW
TOXICITY MINERAL OIL- AND SYNTHETIC OIL-BASED DRILLING FLUIDS OR IN
DIESEL OIL-BASED MUD. IT HELPS INCREASE PRIMARILY LOW SHEAR
RHEOLOGICAL,ANIONIC SYNTHETIC POLYMER IN EMULSION
FORM,DRUM,PHYSICAL PROPERTIES: APPEAR BOILING POINT: ~ 100 OC
MELT/FREEZE POINT: -12 OC PH VALUE CONC. SOLN: 2 # 5 FLASH
PO,PARAMETERS VALUE #FANN-35 F1 SPRING 6 RPM READING @ 120 OF EQUAL
OR GREATER THAN 9 #FANN-35 F1 SPRING 3 RPM READING @ 120 OF EQUAL OR
GREATER THAN 8#LOW SHEAR YIELD POINT LSYP @120 OF EQUAL OR GREATER
THAN 7#.
1000904472

Material Number
9COM/9CAT
113
Chemicals
(Drilling Fluids)
OIL SOLUBLE H2S SCAVENGER
ADDITIVE DRILLING FLUID; LIQUID FORM,HYDROCARBON,FOR OIL SOLUBLE
HYDROGEN SULFIDE SEQUESTERING AGENT/SCAVENGER AQUEOUS SOLUTION
MIXTURE OF INORGANIC COMPOUNDS, FOR THE REMOVAL OF H2S IN VARIOUS
APPLICATIONS AND NOT LIMITED TO ZERO FLARING/FLOWBACK, CRUDE OIL
ROAD TRANSPORTATION, DRILLING MUD, REFINING AND P,PROPRIETARY BLEND
OF ZINC COMPOUNDS IN HYDROCARBON BASE,DRUM,APPEARANCE/ODOR:
VISCOUS YELLOW TO YELLOW-GREEN LIQUID /MILD ODOR. BOILING POINT: 180
DEG CELSIUS. VAPOR PRESSURE: 0.50 MMHG. SOLUBILITY IN WATER: INSOLUBLE.
SPECIFIC GRAVITY: 0.9 (WATER = 1.0). MOLECULAR WEIGHT: PROPRIETARY. PH: 6-
7. FLASH POINT (METHOD): >200F. FOR THE REMOVAL OF H2S IN VARIOUS
APPLICATIONS AND NOT LIMITED TO ZERO FLARING/FLOWBACK, CRUDE OIL
ROAD TRANSPORTATION, DRILLING MUD, REFINING AND PETROCHEMICAL
PLANTS, CRUDE OIL SHIPMENTS AND DISPOSAL WELLS.
1000843350
114
Chemicals
(Drilling Fluids)
HTHP FLUID LOSS SYNTHETIC
POLYMER
ADDITIVE DRILLING FLUID; WHITE POWDER FORM,SYNTHETIC POLYMER,FOR
CONTROLS HTHP FLUID LOSS IN FRESH, SALTY, OR HARD BRINE FLUIDS. IT
INHIBITS SHALE AND STABILIZING FLUID RHEOLOGY. IT CONTROLS WATER LOSS
IN ALL ENVIRONMENTS AND REDUCES DIFFERENTIAL STICKING TENDENCIES.,25
LB MULITIWALL PAPER BAG,APPEARANCE : WHITE COLOURED PO.
1000847072
115
Chemicals
(Drilling Fluids)
SEALING PARTICLES LCM
ADDITIVE DRILLING FLUID; POWDER FORM,SPECIAL BLEND OF GRADED SEALING
PARTICLES.,FOR DESIGNED TO BE EFFECTIVE IN CURING SEVERE TO TOTAL LOSS
CIRCULATION IN HIGHLY FRACTURED/VUGULAR OR POROUS CARBONATE
FORMATIONS, WITHOUT THE ADDITION OF OTHER CONVENTIONAL LCMS IT CAN
BE USED IN ALL TYPES OF DRILLING FLUIDS AND IT IS NOT
RECOMMENDED,SPECIAL BLEND OF GRADED SEALING
PARTICLES.,BAG,APPEARANCE: LIGHT TAN/BROWN SPECIFIC GRAVITY: 0.9
SOLUBILITY IN WATER: INSOLU PH: 6.5-7.5.
1000866812
116
Chemicals
(Drilling Fluids)
HIGH SOLIDS HIGH FLUID LOSS
LCM
ADDITIVE DRILLING FLUID; POWDER FORM,MIXTURE,FOR HIGH FLUID LOSS LCM
FORMS A RAPID SOLID PLUG AGAINST LOSS ZONE WHEN LIQUID PHASE IS
SQUEEZE FROM SLURRY IN ORDER TO CURE PARTIAL TO SEVERE LOSSES OF
WATER/OIL BASED MUDS.,MIXTURE,BAG,APPEARANCE: OFF-WHITE TO GA BULK
DENSITY: 41-46 LB/CU PH: 11.5-12.8.
1000881942

Material Number
9COM/9CAT
117
Chemicals
(Drilling Fluids)
SWELLING SEALING LCM
ADDITIVE DRILLING FLUID; POWDER FORM,MIXTURE OF POLYSACCHARIDES,FOR
SWELLING/SEALING AGENT USED TO FILL FRACTURES AND VOIDS BY CREATING A
SOLID INNER MATRIX SEAL IN ORDER TO CURE PARTIAL TO SEVERE LOSSES OF
WATER/OIL BASED MUDS. USUALLY PUMPED AHEAD OF EZ-SQUEEZE OR CEMENT
JOB AND IT HAS A GOOD SOLUBILITY IN ACID,MIXTURE OF
POLYSACCHARIDES,PAIL,APPEARANCE: LIGHT TAN TO OF BULK DENSITY: 35-55
BA/CU.
1000881943
118
Chemicals
(Drilling Fluids)
DRILZONE - ROP enhancer
ADDITIVE DRILLING FLUID; LIQUID FORM,IVE ND OF SURFACE,FOR SPECIAL BLEND
OF SURFACE AGENTS ROP ENHANCER ,USED IVE IN THE WATER BASE MUD FOR
REDUCING TORQUE AND ,DRAG AND PREVENTING BIT BALLING. NORMAL
TREATMENT:1-2% VOL/VOL. KLA-SHIELD SYSTEM CONSISTS OF DRILZONE IDCAP
D, KLA-STOP AND POROSEAL.,IVE ND OF SURFACE,55 GAL/ DRUM,APPEARANCE:
YELLOW TO BROWN 0.78- FLASH POINT: > 201°F UID SPECIFIC GRAVITY.
1000875822
119
Chemicals
(Drilling Fluids)
KLA-STOP
ADDITIVE DRILLING FLUID; LIQUID FORM,POLYAMINE DERIVATIVE,FOR USED FOR
SUPPRESSING CLAY SWELLING. IT EFFECTIVELY , INHIBITS SHALE OR GUMBO
CLAYS FROM HYDRATING , AND MINIMIZES THE POTENTIAL FOR BIT BALLING.
NORMAL TREATMENT: 1-4% VOL/VOL. KLA-SHIELD SYSTEM CONSISTS OF
DRILZONE , IDCAP D, KLA-STOP AND POROSEAL,POLYAMINE DERIVATIVE,DRUM
55 GAL/ DRUM,PH (5% SOLUTION): 9.2-10. FLASH POINT: > 200°F
EARANCE:COLORLESS LIQUID CIFIC GRAVITY: 1.03-1.0.
1000875823
120
Chemicals
(Drilling Fluids)
IDCAP D
ADDITIVE DRILLING FLUID; POWDER FORM,DRY ACRYLIC ACID COPOLYMER,FOR
ENCAPSULATION COPOLYMER USED TO PROVIDE CUTTINGS , ENCAPSULATION
AND CLAY DISPERSION INHIBITION WITH MINIMAL VISCOSITY CONTRIBUTION
FOR WATER BASE FLUIDS AND SALINE WATER ENVIRONMENTS. NORMAL
TREATMENT: 2-4 LB/BBL. KLA-SHIELD SYSTEM CONSISTS OF DRILZONE,DRY
ACRYLIC ACID COPOLYMER,BAG 25 KG/SACK,APPEARANCE: WHITE POWDER
SPECIFIC GRAVITY: 0.8 PH (1% SOLUTION): 6.
1000875824

Material Number
9COM/9CAT
121
Chemicals
(Drilling Fluids)
POROSEAL
ADDITIVE DRILLING FLUID; LIQUID FORM,STARCH COPOLYMER,FOR PROVIDES
PERMEABILITY PLUGGING TO EFFECTIVELY SEAL SHALES AND FILTER CAKES,
IMPROVING THE PERFORMANCE OF HIGHLY INHIBITIVE WATER-BASE DRILLING
FLUIDS. IT ADDITIVE IS ALSO USED TO PROVIDE SUPPLEMENTAL FLUID LOSS
CONTROL IN HIGH-TEMPERATURE APPLICATIONS NORMAL POROSEAL -SHIELD
SYSTEM CONSISTS DRILZONE IDCAP D, KLA-STOP ATMENT:2-5%
VOL/VOL.,STARCH COPOLYMER,55 GAL/DRUM,APPEARANCE: WHITE LIQUID
SPECIFIC GRAVITY: 1.0-1.1 PH (CONC. SOLUTION): 10.
1000875825
122
Chemicals
(Drilling Fluids)
FIBER FINE
ADMIXTURE DRILLING MUD; SOLID FORM,ORGANIC CELLULOSE FIBER, LIGHT TAN
/ BROWN,FOR USED FOR SEALING THIEF ZONES, HIGHLY FRACTURED/VUGULAR
FORMATIONS AND MINIZING THE RISK OF DIFFERENTIAL STICKING,A FINELY SIZED
(MICRONIZED) ORGANIC CELLULOSE FIBER,25LB.BAG,ODORLESS, SG: 0.9, MIX OF
FINELY DIVIDED CELLULOSE FIBERS, INSOLUBLE IN WATER, NON TOXIC, PH: 6.5-
7.5,SIEVE SPECIFICATION FOR FRAC-SEAL FINE: RETAIN ON 40 MESH SIEVE: 0%,
RETAIN ON 60 MESH SIEVE: 0.10%, RETAIN ON 80 MESH SIEVE: 0.20%, RETAIN ON
100 MESH SIEVE: 2.83%, RETAIN ON 140 MESH SIEVE:11.2%, RETAIN ON 170
MESH SIEVE:28.5%, RETAIN ON 270 MESH SIEVE:38.23%:NORMAL TREATMENT: 8-
10 LB/BBL OF FRACSEAL-FINE , THE CONSTRUCTION OF THE MULTI-WALLED
PAPER BAG (CONTAINER)SHALL BE FOLLOWS: 1ST PLY 75 LB.NATURAL KRAFT
PAPER(INTETIOR PLY) 2ND PLY 75 LB.NATURAL KRAFT PAPER 3RD PLY 80
LB.NATURAL KRAFT PAPER (EXTERIOR PLY). THE BAG DOES NOT HAVE AN INNER
POLYETHYLENE LINER. THE BAG MUST BE VALVE/SPOUT TYPE COMPLETELY
SEALED OTHER ASSOCIATED ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL
AND/OR ADVERSELY AFFECT FLUID PROPERTIES.
1000792802

Material Number
9COM/9CAT
123
Chemicals
(Drilling Fluids)
FIBER MEDIUM
7.5,SIEVE SPECIFICATION FOR FRAC-SEAL MEDIUM: RETAIN ON 40 MESH
SIEVE:1.8%, RETAIN ON 60 MESH SIEVE: 0.30%,RETAIN ON 80 MESH SIEVE:1.7%,
RETAIN ON 100 MESH SIEVE: 4.33%, RETAIN ON 140MESH SIEVE:5.40%, RETAIN
ON 170 MESH SIEVE: 15.97%,RETAIN ON 270 MESH SIEVE:31.17%:NORMAL
TREATMENT: 8-10 LB/BBL OF FRACSEAL-MEDIUM , THE CONSTRUCTION OF THE
MULTI-WALLED PAPER BAG (CONTAINER)SHALL BE FOLLOWS: 1ST PLY 75
LB.NATURAL KRAFT PAPER(INTETIOR PLY) 2ND PLY 75 LB.NATURAL KRAFT PAPER
3RD PLY 80 LB.NATURAL KRAFT PAPER (EXTERIOR PLY). THE BAG DOES NOT HAVE
AN INNER POLYETHYLENE LINER.
1000792803
124
Chemicals
(Drilling Fluids)
FIBER COARSE, 25 LB
7.5,SIEVE SPECIFICATION FOR FRAC-SEAL COARSE: RETAIN ON 40 MESH SIEVE:
4.93%, RETAIN ON 60 MESH SIEVE: 2.17%, RETAIN ON 80 MESH SIEVE: 3.73%,
RETAIN ON 100 MESH SIEVE: 6.17%, RETAIN ON 140 MESH SIEVE:6.87%, RETAIN
ON 170 MESH SIEVE:17.63%, RETAIN ON 270 MESH SIEVE:30.47%:NORMAL
TREATMENT: 8-10 LB/BBL OF FRACSEAL-COARSE, THE CONSTRUCTION OF THE
MULTI-WALLED PAPER BAG (CONTAINER)SHALL BE FOLLOWS,1ST PLY 75
LB.NATURAL KRAFT PAPER(INTETIOR PLY)2ND PLY 75 LB.NATURAL KRAFT PAPER
3RD PLY 80 LB.NATURAL KRAFT PAPER (EXTERIOR PLY).THE BAG DOES NOT HAVE
AN INNER POLYETHYLENE LINER.THE BAG MUST BE VALVE/SPOUT TYPE
COMPLETELY SEALED OTHER ASSOCIATED LEMENTS MUST NOT BE HARMFUL TO
PERSONNEL AND/OR ADVERSELY AFFECT FLUID PROPERTIES.
1000792804

Material Number
9COM/9CAT
125
Chemicals
(Drilling Fluids)
BARABRINE Defoam
ADDITIVE DRILLING FLUID; LIQUID FORM,BLEND OF NONIONIC
SURFACTANTS,FOR NON-DAMAGING FLUIDS RDF-615 AND NON-RESERVOIR
WBM AND BRINES, INCLUDING ZNBR2,BLEND OF NONIONIC SURFACTANTS,PAIL
(ONE PAIL = 5 GALLONS),APPEARANCE: COLORLESS CLEAR LI,ADDITIVE FOR FLUID
FORMULATION FOR SYSTEM RDF-615. THIS DEFOAMER IS USED AS PART OF THE
NON-DAMAGING FLUIDS RDF-615, WHICH INCLUDES BARAZAN D PLUS, BARA
CARB 150, OXYGON, BARABUF (MM: 1000184370), N DRILL HT PLUS (MM:
1000788390), BARACARB 5 (MM: 1000775558), BARACARB 25 (MM:
1000775559), BARACARB 50 (MM:1000775560) AND BAROLUBEGOLD SEAL (MM:
1000757580). TYPICAL TREATMENT IS 0.05-0.25 LB/BBL (0.007-0.033 GAL/BBL).
THIS DEFOAMER CAN ALSO BE USED IN NON-RESERVOIR WATER BASED MUDS
AND BRINES, INCLUDING ZNBR2. SUPPLIER/VENDOR IS REQUIRED TO SUBMIT LAB
CERTIFICATE OF ANALYSIS (COA) AND CERTIFICATE OF ORIGIN (COO).
1000908534
126
Chemicals
(Drilling Fluids)
PUREFIED XANTHAN GUM
ADDITIVE DRILLING FLUID; POWDER FORM,VISCOSIFIER / SUSPENSION AGENT
(POLYSACCHARIDE),FOR FRESH WATER, SEA WATER AND BRINE,DISPERSANT-
ADDED BIOPOLYMER (XANTHAN GUM),BAG (ONE BAG =55 LBS),APPEARANCE:
YELLOW TO WHITE PO,ADDITIVE FOR FLUIDFORMULATION FOR SYSTEM RDF-615.
IT IS A BIOPOLYMER XANTHAN GUM USED TO HELP TO DISPERSE EASILY, AND TO
PROVIDE VISCOSITY AND SUSPENSION IN FRESH WATER, SEA WATER AND IN
BRINES, AS SODIUM AND POTASSIUM BROMIDES AND SODIUM AND POTASSIUM
CHLORIDES. IT IS STABLE AT 250 DEG F (121 DEG C). TYPICAL TREATMENT OF 0.1-
2 LB/BBL (0.3-5.7 KG/ CUBIC M) AS NEEDED TO OBTAIN THE DESIRED VISCOSITY.
THE UNIT IS 55 LBS (25 KG)/BAG. IT IS PART OF A NON-DAMAGING SYSTEM RDF-
615, WHICH CONTAINS BARABRINE DEFOAM, BARA CARB 150, OXYGON,
BARABUF (MM: 1000184370), N DRILL HT PLUS (MM: 1000788390), BARACARB 5
(MM: 1000775558), BARACARB 25 (MM:1000775559), BARACARB 50 (MM:
1000775560) AND BAROLUBE GOLD SEAL (MM: 1000757580).
1000908458

Material Number
9COM/9CAT
127
Chemicals
(Drilling Fluids)
Ground Marble CaCO3, 50-150,
55 LB
ADDITIVE DRILLING FLUID; POWDER OR GRANULES FORM,SIZED CALCIUM
CARBONATE (CACO3) MARBLE QUALITY,FOR WATER BASED MUD (WBM), OIL
BASED MUD (OBM) AND BRINE,CALCIUM CARBONATE (CACO3) MARBLE
QUALITY.,BAG (ONE BAG = 55 LBS),APPEARANCE: WHITE POWDER OR
GR,ADDITIVE FOR FLUID FORMULATION FOR SYSTEM RDF-615. SIZED MARBLE
CALCIUM CARBONATE (D50 = 150 MICRONS) USED TO INCREASE DENSITY IN
WBM AND OBM FOR RESERVOIR APPLICATIONS AND BRINES AND AS A BRIDGING
AGENT FOR FLUID LOSS CONTROL AND SEALING/LCM IN NON - DAMAGING
SYSTEMS. THE UNIT IS 55 LBS (25 KG) / BAG. IT IS PART OF THE RDF -615 WHICH
CONTAINS BARABRINE DEFOAM, BARAZAN D PLUS, OXYGON, BARABUF (MM:
1000184370), N DRILL HT PLUS (MM:1000788390), BARACARB5 (MM:
1000775558), BARACARB 25 (MM:1000775559), BARACARB 50 (MM:
1000775560) AND BAROLUBE GOLD SEAL (MM: 1000757580).
1000908535
128
Chemicals
(Drilling Fluids)
Oxygon
ADDITIVE DRILLING FLUID; POWDER FORM,ORGANIC ACID SALT (OXYGEN
SCAVENGER),FOR FRESH WATER, WATER BASED MUD (WBM) AND MONO OR
DIVALENT BRINES,GRANULAR ERYTHORBATE MATERIAL,PAIL (ONE PAIL =55
LBS),APPEARANCE: WHITE GRANULAR POW,ADDITIVE FOR FLUID FORMULATION
FOR SYSTEM RDF-615. IT IS USED AS A CORROSION INHIBITOR OR OXYGEN
SCAVENGER IN WBM, WATER AND IN MONO OR DIVALENT BRINES/COMPLETION
FLUIDS. THE UNIT IS 55 LBS (25KG)/PAIL. IT IS PART OF THE NON-DAMAGING
SYSTEM - RDF -615 SYSTEM WHICH CONTAINS BARABRINE DEFOAM, BARAZAN D
PLUS, BARA CARB 150, BARABUF (MM: 1000184370), N DRILL HT PLUS
(MM:1000788390), BARACARB 5 (MM: 1000775558), BARACARB 25
(MM:1000775559), BARACARB 50 (MM: 1000775560) AND BAROLUBE GOLD SEAL
(MM: 1000757580). TYPICAL TREATMENT OF 0.1 LB/BBL. BASE THE TREATMENT
OF CIRCULATING FLUIDS ON OXYGEN CONTENT.
1000908459
129
Chemicals
(Drilling Fluids)
MAGNESIUM OXIDE
CHEMICAL; GR TECHNICAL,M20,POWDER FORM,22.7 KG (50 LB) - 25.0 KG (55 LB)
SACK,96% MG0 MIN,MAGNESIUM OXIDE,SHIPMENT OF PRODUCT SHALL
CONFORM TO SAUDI ARAMCO EXPORT PACKING MANUAL THE PRODUCT
SHOULD BE PACKED IN 3 OR 4 PLY PAPER SACKS
1000184370

Material Number
9COM/9CAT
130
Chemicals
(Drilling Fluids)
LUBRICANT - RADIAGREEN EME
SALT
ADDITIVE DRILLING FLUID; SPECIAL BLEND,FOR 5 MAX C DEG (320 F) MAX AND
PH USED TO REDUCE TORQUE AND DRAG IN VERY CHALLENGING DRILLING AND
COMPLETION OPERATIONS E.G. SPECIAL COILED TUBING UNDER BALANCED
DRILLING. THE PRODUCT SHOULD BE COMPATIBLE FOR APPLICATION IN
SEAWATER AND SALT BRINE-BASED DRILLING FLUIDS AND BRINES. IENT
CONDITIONS TOM HOLE LIMITATIONS: NHOLE CONDITIONS OR ING
APPLICATIONS UNDER ASING IN DRUM OR CHEESING E PHASE SEPARATION
PROBLEMS ALKALINE DRILLING FLUIDS PRODUCT SHOULD BE EASY PRODUCT
SHOULD NOT FORM HANDLE, EASY TO FLOW AT,SPECIAL
BLEND,DRUM,APPEARANCE: AMBER LIQUID SPECIFIC GRAVITY: 0.98-1.1
SOLUBILITY IN WATER: INSOLU FLASH POINT (METHOD): 185 POUR POINT: 32 C
DEG MAX.
1000857139
131
Chemicals
(Drilling Fluids)
POLYANIONIC CELLULOSE LO-VIS
(PAC-LV)
ADMIXTURE DRILLING MUD; AA SOLID, GRANULAR, WHITE TO FORM,MIL-PAC LV,
POLYANIONIC ODORLESS, POLYANIONIC,FOR AA USED FOR FILTRATION
CONTROL,AA POLYANIONIC CELLULOSE,50 LB OR 25 KG / SACK,AA APPEARANCE:
SOLID, CREAM,OTHER ASSOCIATED ELEMENTS BULID-UP. CONTAINER IS A MULTI-
WALLED SACK, 1ST PLY - 70 G/SQM NATURAL KRAFT PAPER (INTERIOR PLY). 2ND
PLY - 70 G/SQM NATURAL KRAFT PAPER. 3RD PLY - SEPARATE INNER BAG LINER,
HIGH DENSITY ORIENTED AND CROSS LAMINATED INNER LINER (TUBULAR SHAPE)
MADE UP OF POLYETHYLENE RESIN MATERIAL WITH A WEIGHT RANGE OF 15-24
G/SQM. 4TH PLY - 70 G/SQM NATURAL KRAFT PAPER. 5TH PLY - SEPARATE INNER
BAG LINER, HIGH LAMINATED INNER LINER (TUBULAR SHAPE)MADE UP OF
POLYETHYLENE RESIN MATERIAL MATERIAL WITH A WEIGHT RANGE OF 15-24
G/SQM. 6TH PLY - 70 G/SQM NATURAL KRAFT PAPER (EXTERIOR PLY). THE BAG
MUST BE PROPERLY CONTAINER BE VALVE / SPOUT TYPE COMPLETELY SEALED
AND MOISTURE PROOF.
1000758662

Material Number
9COM/9CAT
132
Chemicals
(Drilling Fluids)
2200 lb/BAG
ADDITIVE: CEMENT; 2200 LB BAG; NON-BREATHABLE FABRIC; DISPOSABLE BAG;
WITH LIFTING STRAPS; NO ADMIXTURE CEMENT; FOR USED FOR BUILDING OIL
WELL COMPLETION FLUIDS,TYPE 1,94-98% CALCIUM CHLORIDE (CACL2) POWDER,
FLAKES OR PELLETS,2200 LB BAG,ASTM D98,PURITY AS FOLLOW: A. CALCIUM
CHLORIDE (CACL2): 98% WT. B. MAGNESIUM AS MGCL2: 0.2 - 0.4 % WT. C. ALKALI
CHLORIDES AS NACL: 1.4 - 5.0 % WT. D. HEAVY METALS AS PB: 0.005 % WT
MAXIMUM. E. SULFATE AS CASO4: 0.05 % WT MAXIMUM. F. WATER INSOLUBLES:
0.20 % WT MAXIMUM. G. OTHER WATER SOLUBLE IMPURITIES: 0.35 % WT
MAXIMUM. H. PH: 10 % (V/V) SOLUTION (5.89 G IN 97.3 CC DEIONIZED WATER):
7.5 TO 9.5. REQUIRES SAUDI ARAMCO HAZCOM LABEL IN MM # 1000644273.
LIFTING STRAP BAG IS DISPOSABLE, TOP CLOSURE WATERTIGHT, STACKABLE &
WITHOUT BOTTOM SPOUT, MINIMUM TENSILE STRENGTH FACTOR 5, FLEXURAL
STRENGTH FOR NORMAL HANDLING & OUTSIDE STORAGE NON-BREATHABLE
FABRIC, STACKABLE WITHOUT USE OF PALLET, BAG TOP CLOSURE TO BE WATER
TIGHT & CAPABLE OF WITHSTANDING THE SAME HANDLING & STORAGE
REQUIREMENTS AS THE BAG ITSELF REQUIRES SAUDI ARAMCO HAZCOM LABEL IN
MM 1000644274.
1000022538
133
Chemicals
(Drilling Fluids)
RHEOLOGY MODIFIER
ADMIXTURE DRILLING MUD; DARK LIQUID FORM,COMPLEX BLEND OF DIMER
AND TRIMER POLYMERIC FATTY ACIDS,FOR USED TO INCREASE LOW-SHEAR
RHEOLOGY, WHILE HAVING ONLY A SLIGHT EFFECT ON YIELD POINT,COMPLEX
BLEND OF DIMER AND TRIMER POLYMERIC FATTY ACIDS,55
GAL.DRUM,APPEARANCE: DARK LIQUID, SPGR: 0.95 GM/CC, FLASH POINT 475
DEG F (246 C), ODOR: FATTY ACID, FREEZING POINT: NOT DETERMINED, BOILIING
POINT: 300 C, SOLUBILITY: INSOLUBLE IN WATER, DENSITY@20DEG C IS 0.95,
OTHER ASSOCIATED ELEMENTS MUST NOT BE HARMFUL TO PERSONNEL AND/OR
ADVERSELY AFFECT FLUID PROPERTIES.
1000789179
134
Chemicals
(Drilling Fluids)
H2S SCAVENGER, LIQUID
ADDITIVE DRILLING FLUID; LIQUID FORM,NITROGEN,FOR ADMIXTURE
HYDROGEN SULFIDE SCAVENGER FOR USE IN WATER-BASE MUD AND INVERT
EMULSION OIL-BASE MUD. NITROGEN-BASED ORGANIC LIQUID COMPOUND.
READILY AVAILABLE FOR APPLICATION AND CAN BE USED IN COLD AND WARM
TEMPERATURES.,A NITROGEN-BASED, NON-ZINC
COMPOUND,DRUM,APPEARANCE: AMBER LIQUID. S PH: 9 - 11.5 SOLUBILITY IN
WATER: SOLUBL FLASH POINT (METHOD): >212F POUR POINT: < - 4 F.
1000845182

Material Number
9COM/9CAT
135
Chemicals
(Drilling Fluids)
SODIUM BROMIDE (NaBr) SOL
12.35 LB/GAL
ADDITIVE DRILLING FLUID; LIQUID COLORLESS FORM,SODIUM BROMIDE
SOLUTION,FOR USED AS A SINGLE-SALT BRINE WITH MIN DENSITY OF 12.35
LB/GAL @ 60 DEG F. IT IS THERMALLY AND CHEMICALLY STABLE AND GENERALLY
USED TO PREPARE DENSE CLEAR FLUIDS FOR USE IN DRILLING, COMPLETION OR
WORK-OVER OF OIL OR GAS WELLS.,SODIUM BROMIDE,IBC,COLORLESS LIQUID.
ASSAY: MIN 4.
1000847075
136
Chemicals
(Drilling Fluids)
CAUSTIC SODA - NAOH
ADMIXTURE: DRILLING MUD; SODIUM HYDROXIDE (CAUSTIC SODA) ADMIXTURE
DRILLING MUD; DRY, WHITE FREE FLOWING FLAKES, BEADS OR PELLETS, MAIN
COMPONENT: SODIUM HYDROXIDE, NAOH FORM,SODIUM HYDROXIDE
(NAOH),FOR USED FOR PH AND ALKALINITY CONTROL. CAUSTIC SODA MINIMIZE
THE SOLUBILITY OF CALCIUM AND MAGNESIUM IN DRILLING FLUIDS,SODIUM
HYDROXIDE (CAUSTIC SODA),22.7 KG OR 50 LB STEEL DRUM,DRUM WITH
MINIMUM 7 IN TOP OPENING & LOW DENSITY POLYETHYLENE INNER LINER.
1000021749
137
Chemicals
(Drilling Fluids)
WALNUT SHELLS
CONFORM TO SAUDI ARAMCO EXPORT ADMIXTURE DRILLING MUD; GROUND
FORM,WALNUT SHELLS,FOR LOSS CIRCULATION MATERIAL,25 KG OR 50 LB
BAG,SPECIFIED AS 39.8% ON MESH NO 8, 45.4% ON MESH NO 30, 4.2% THRU
MESH NO 40, 4.2% THRU MESH NO 70, 1.7% THRU MESH NO 100, NOT MORE
THAN 4.7% THRU MESH NO 100 SHIPMENT OF PRODUCT SHALL CONFORM TO
SAUDI ARAMCO EXPORT PACKING MANUAL NOTE: THE CONSTRUCTION OF THE
MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY 75 LB
MIN. NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY 75 LB MIN. NATURAL
KRAFT PAPER. 3RD PLY 80 LB MIN.
1000021811

Material Number
9COM/9CAT
138
Chemicals
(Drilling Fluids)
SODIUM BICARBONATE
ADMIXTURE: DRILLING MUD; 25 KG (50 LB); SODUM BICARBONATE ADMIXTURE
DRILLING MUD; DRY, WHITE FINE CRYSTALLINE POWDER FORM,SODIUM
BICARBONATE (NAHCO3),FOR FOR TREATING CEMENT CONTAMINATION AND TO
PRECIPITATE SOLUBLE CALCIUM IN DRILLING FLUIDS BASE MUD,SODIUM
BICARBONATE,25 KG OR 50 LB BAG,API 13A,PACKED IN KRAFT PLIES & (1)
WATERPROOF POLY LINER PLY SACKS, SHIPMENT OF PRODUCT SHALL CONFORM
TO SAUDI ARAMCO EXPORT PACKING MANUAL MULTI-MOISTURE-PROOF BAGS.
NO PARTICLES GREATER THAN 2MM IN ANY DIMENSION NOTE: THE
CONSTRUCTION OF THE MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE AS
FOLLOWS: 1ST PLY 75 LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY 75
LB MIN. NATURAL KRAFT PAPER. 3RD PLY SEPARATE INNER BAG LINER, HIGH
DENSITY ORIENTED AND CROSS-LAMINATED INNER LINER (TUBULAR SHAPE)
MADE OF POLYETHYLENE RESIN MATERIAL WITH A MINIMUM WALL THICKNES
OF 0.1 MM. 4TH PLY 80 LB MIN. NATURAL KRAFT PAPER (EXTERIOR PLY) THE BAG
MUST BE VALVE/SPOUT TYPE, COMPLETELY SEALED, MOISTURE AND WATER
PROOF.
1000021745
139
Chemicals
(Drilling Fluids)
CALCIUM HYDROXIDE - LIME
ADMIXTURE: DRILLING MUD; 25 KG/SACK; CALCIUM HYDROXIDE (HYDRATED
LIME) ADMIXTURE DRILLING MUD; DRY, FREE FLOWING FINE POWDER
FORM,CALCIUM HYDROXIDE, CA(OH)2 (TECHNICAL GRADE),FOR TO CONTROL PH,
BICARBONATE, AND H2S CONTAMINATION. LIME IS ALSO A PRIMARY
COMPONENT OF INVERT EMULSION MUDS,CALCIUM HYDROXIDE (HYDRATED
LIME),25 KG OR 50 LB BAG,SHIPMENT OF PRODUCT SHALL CONFORM TO SAUDI
ARAMCO EXPORT PACKING MANUAL MULTI-WALLED PAPER BAGS, CONTAINER
PROPERLY LABELED, W/VENDOR'S NAME, MANUFACTURER'S NAME AND
LOCATION, PRODUCTION DATE AND BATCH NO. NOTE: THE CONSTRUCTION OF
THE MULTI-WALLED PAPER BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY 75
LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY 75 LB MIN. NATURAL
KRAFT PAPER. 3RD PLY 80 LB MIN. NATURAL KRAFT PAPER (EXTERIOR PLY) THE
BAG DOES NOT HAVE AN INNER POLYETHYLENE LINER
1000021558

Material Number
9COM/9CAT
140
Chemicals
(Drilling Fluids)
ACRYLIC COPOLYMER BASE,
SWEEPING AGENT
ADDITIVE DRILLING FLUID; SOLID FORM,ACRYLIC COPOLYMER BASE,FOR TO
PROVIDE VISCOSITY, REDUCE FRICTION, ENCAPSULATE CUTTINGS AND PROVIDE A
LIMITE AMOUNT OF FLUID-LOSS CONTROL IN WATER-BASE DRILLING FLUIDS. IT IS
A POLYMER STICK THATEASILY ADDED TO THE DRILLSTRING DURING
CONNECTIONS AND PROVIDES A CONSISTENT METHOD OF,ACRYLIC COPOLYMER
BASE,PAIL,APPEARANCE: TUBE FILLED WI STICK SPECIFIC GRAVITY: 1.0 SOLUBILITY
SOLUBLE IN WATER SIZE: 1-1/4 X 15 IN.
1000876207
141
Chemicals
(Drilling Fluids)
100 lb/BAG
ADDITIVE: CEMENT; 50 KG, CALCIUM CHLORIDE (94-98%) ADMIXTURE CEMENT;
FOR A WATER SOLUBLE WEIGHTING AGENT FOR FORMULATING SOLIDS-FREE
COMPLETION BRINES AND TO PROVIDE THE DESIRED WATER PHASE ACTIVITY IN
INVERT EMULSION MUDS. ALSO USED AS AN ACCELERATOR IN OIL WELL CEMENT
SLURRIES,TYPE 1,94-98% CALCIUM CHLORIDE (CAC12) POWDER, FLAKES OR
PELLETS,50 KG OR 100 LB BAG,ASTM D98,WATERPROOF POLYETHYLENE LINED
BAG SHIPMENT OF PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT
PACKING MANUAL NO PARTICLES GREATER THAN 5MM IN ANY DIMENSION,
MULTI-WALL MOISTURE-PROOF POLYETHYLENE LINED BAGS CONTAINER
PROPERLY LABELED, W/ VENDOR'S NAME, MANUFACTURER'S NAME AND
LOCATION, PRODUCTION DATE, BATCH NO. AND SAUDI ARAMCO STOCK
NUMBER, FORM DRY, FREE FLOWING FLAKES, GRANULES OR PELLETS NOTE: THE
CONSTRUCTION OF THE MULTI-WALLED PAPER BAG SHALL BE AS FOLLOWS: 1ST
PLY 50 LB MIN. NATURAL KRAFT PAPER (INTERIOR PLY) 2ND PLY 50 LB MIN.
NATURAL KRAFT PAPER 3RD PLY SEPARATE INNER BAG LINER, HIGH DENSITY
ORIENTED AND CROSS-LAMINATED INNER LINER (TUBULAR SHAPE) MADE OF
POLYETHYLENE RESIN MATERIAL WITH A MINIMUM WALL THICKNES OF 0.1 MM.
4TH PLY 50 LB MIN.
1000022536
142
Chemicals
(Drilling Fluids)
MANGANESE TETRAOXIDE - BAG
ADDITIVE DRILLING FLUID; POWDER FORM,MANGANESE TETRAOXIDE,FOR
MANGANESE TETRAOXIDE IS AN INORGANIC COMPOUND WHICH IS USED TO
PREPARE HIGH DENSITY FLUIDS FOR USE IN DRILLING, COMPLETION OR WORK-
OVER OF OIL OR GAS WELLS.,MANGANESE TETRAOXIDE,BAG,APPEARANCE:
REDDISH-BROWN POWD.
1000845612

Material Number
9COM/9CAT
143
Chemicals
(Drilling Fluids)
COTTONSEED HULLS, 55 LB
ADMIXTURE: DRILLING MUD; 25 KG (50 LB) 4 PLY PAPERSACK; SHIPMENT OF
PRODUCT SHALL CONFORM TO SAUDI ADMIXTURE DRILLING MUD; COARSE
FORM,COTTONSEED HULLS,FOR LOST CIRCULATION,FINES & DUST FREE,25 KG OR
50 LB BAG,SHIPMENT OF PRODUCT SHALL CONFORM TO SAUDI ARAMCO EXPORT
PACKING MANUAL NOTE: THE CONSTRUCTION OF THE MULTI-WALLED PAPER
BAG (CONTAINER) SHALL BE AS FOLLOWS: 1ST PLY 75 LB MIN. NATURAL KRAFT
PAPER (INTERIOR PLY) 2ND PLY 75 LB MIN. NATURAL KRAFT PAPER. 3RD PLY
SEPARATE INNER BAG LINER, HIGH DENSITY ORIENTED AND CROSS-LAMINATED
INNER LINER (TUBULAR SHAPE) MADE OF POLYETHYLENE RESIN MATERIAL WITH
A MINIMUM WALL THICKNES OF 0.1 MM. 4TH PLY 80 LB MIN. NATURAL KRAFT
PAPER (EXTERIOR PLY) THE BAG MUST BE VALVE/SPOUT TYPE, COMPLETELY
SEALED, MOISTURE AND WATER PROOF.
1000021603
144
Chemicals
(Drilling Fluids)
BAROFIBER COARSE, 40 LB
ADMIXTURE DRILLING MUD; ADDITIVE, FIBROUS CELLULOSIC MATERIAL
FORM,FIBROUS CELLULOSIC MATERIAL,FOR DESIGNED TO EFFECTIVELY SEAL THE
BOREHOLE WALL IN SAND AND FRAC AND TO STOP THE LOSS OF DRILLING FLUID
BY PLUGGING THE VOIDS,FIBROUS CELLULOSIC MATERIAL,40
LB/SACK,APPEARANCE: COARSE:GRANUALTED MATERIAL, BULK DENSITY: 31
LB/FT(497 KG/M), PH 4.9, SPECIFIC GRAVITY: 1.3, ODOR: ODORLESS,
DENSITY@20C (KG/L) 1.1, FREEZING POINT 190 C, FLASH POINT 193 C, SOLUBILITY
IN WATER: INSOLUBLE, OTHER ASSOCIATED ELEMENTS MUST NOT BE HARMFUL
TO PERSONNEL AND/OR ADVERSELY AFFECT FLUID PROPERTIES.
1000789221
145
Chemicals
(Drilling Fluids)
LIQUID PHPA
ADMIXTURE: DRILLING MUD; PARTIALLY HYDROLIZED POLYACRYLAMIDE (PHPA);
MINIMUM 32% ACTIVE NON CONFIGURED; ADMIXTURE: DRILLING MUD,
PARTIALLY HYDROLIZED POLYACRYLAMIDE (PHPA), MINIMUM 32% ACTIVE FROM
LIQUID BASE MATERIAL PARTIALLY HYDROLIZED POLYACRYLAMIDE SERVICE
SHALE STABILIZER COMPOSITION 32% ACTIVE CONTAINER 5 GAL/CAN
STANDARDS SUPPLEMENTARY REQUIREMENTS DRILLING FLUID ADDITIVE
1000021673
146
Chemicals
(Drilling Fluids)
HYDROCARBON BASED
DEGREASER
CLEANER; CONTACT TYPE,LIQUID FORM,FOR ELECTRIC MOTOR AND
EQUIPMENT,20 LITER CAN,HYDROCARBON BASED CLEANER & DEGREASER,FLASH
POINT (CLOSED CUP) 63 DEG C, NON-CONDUCTIVE & NON-CORROSIVE,
APPERANCE CLEAR LIQUID.
1000732382

Material Number
9COM/9CAT
147
Chemicals
(Drilling Fluids)
THINNER MODIFIED TANNIN -
DRILL THIN
ADDITIVE DRILLING FLUID; BROWN COLORED POWDER FORM,MODIFIED TANNIN
COMPOUND,FOR USED AS MUD CONDITIONER PROVIDING RHEOLOGY CONTROL
IN WATER BASE FLUIDS WITH MAXIMUM DEFLOCCULATING AND SHEAR
STRENGTH REDUCTION AT LOW CONCENTRATIONS.,25 LB MULITIWALL PAPER
BAGS,APPEARANCE: BROWN COLORED POWD,CONTAINER MUST BE PROPERLY
LABELED WITH, VENDOR'S NAME, MANUFACTURER'S NAME, LOCATION,
PRODUCTION DATE AND BATCH NUMBER. SAUDI ARAMCO WILL CARRY OUT
PROPER SAMPLING AND TESTING AS NEEDED. PRODUCT MANUFACTURER AND
OR SUPPLIER REQUIRED TO SUBMIT LAB CERTIFICATE OF ANALYSIS (COA) AND
CERTIFICATE OF ORIGIN (COO).
1000845427
148
Chemicals
(Drilling Fluids)
CEMENT SPACER VISCOSIFIER, IN-
HOUSE
ADDITIVE DRILLING FLUID; GREY POWDER FORM,VISCOSIFIER FOR IN-HOUSE
CEMENT SPACER SYSTEM,,FOR COMPONENT OF AN IN-HOUSE CEMENT SPACER
SYSTEM FOR USE WITH OBM (OIL-BASE-MUD) SYSTEMS, OR OTHER COMPATIBLE
MUD SYSTEMS DESIGNED TO PROVIDE FLUID LOSS CONTROL AND VISCOSITY
ALLOWING USERS TO EASILY FORMULATE A CEMENT SPACER WITH THE DESIRED
RHEOLOGY CERTIFICATE OF ORIGIN COO DENSITY THIS VISCOSIFIER I LOSURF-
259 SAP #1000811529 A SYSTEM TO FORMULATE -S SAP # 1000903745 ENT
SPACER DESIGNS FOR IDS PACKAGED IN 50-LB COMBINATION WITH DIACEL®
TIWALL WATER RESISTANT BAGS ANALYSIS (COA) WITH NON-AQUEOUS DRILLING
DER TO SUBMIT CERTIFICATE,PROPRIETARY. COMPONENT FOR USE IN IN-HOUSE
CEMENT SPACER SYSTEM,BAG,APPEARANCE: OFF-WHITE POWDE SPECIFIC
GRAVITY: 2.08 G/M TEMPERATURE: 40°F - 400°F CONCENTRATION: 2-22 LBS/BB.
1000903746
149
Chemicals
(Drilling Fluids)
CEMENT SPACER ANTI-FOAMER,
IN-HOUSE
ADDITIVE DRILLING FLUID; LIQUID FORM,ANTI-FOAMER FOR IN-HOUSE CEMENT
SPACER SYSTEM,FOR COMPONENT OF AN IN-HOUSE CEMENT SPACER SYSTEM
FOR USE WITH OBM (OIL-BASE-MUD) SYSTEMS, OR OTHER COMPATIBLE MUD
SYSTEMS DESIGNED TO PREVENT AIR-ENTRAPMENT AND USED DURING MIXING
TO PROVIDE AN ACCURATE FLUID WEIGHT. THIS ANTI-FOAMER IS USED IN
COMBINATION LOSURF-259(SAP# 1000811529 A SYSTEM TO FORMULATE ENT
SPACER DESIGNS FOR USE TIFICATE . TIFICATE OF ORIGIN COO IDS PACKAGED IN
A 5 GALLON -ANALYSIS (COA) AND STIC PAIL .VENDER TO SUBMIT COSIFIER (SAP#
1000903746) H DIACEL® ADJUSTABLE SPACER H NON -AQUEOUS
DRILLING,PROPRIETARY. COMPONENT FOR USE IN IN-HOUSE CEMENT
SPACER,PAIL,APPEARANCE: VISCOUS WHITE SPECIFIC GRAVITY = 1.00 G BOILING
POINT > 35 C (>95F VISCOSITY: 10000 CST FLASHPOINT: > 101.1°C (>21.
1000903745

Material Number
9COM/9CAT
150
Chemicals
(Drilling Fluids)
CHEMICAL: SODIUM
HEXAMTAPHOSPHATE
CHEMICAL; GR FOOD,SODIUM HEXAMETAPHOSPHATE,FOR POTABLE WATER
TREATMENT,GRANULAR FORM,40-45 KG (88-100 LB) DRUM,SODIUM
HEXAMETAPHOSPHATE,AWWA B502,REQUIRES SAUDI ARAMCO HAZCOM LABEL
IN MM# 1000642502
1000186247
151
Chemicals
(Drilling Fluids)
Acid Precursor - ORCA-B
ADDITIVE DRILLING FLUID; LIQUID FORM,ORGANIC ESTERS,FOR A LIQUID
ORGANIC ACID PRECURSOR WHICH WILL GENERATE ORGANIC ACID IN#SITU
DOWNHOLE WHICH HAS THE CAPABILITY TO DISSOLVE CALCIUM CARBONATE
FILTER CAKE SOLIDS TO REMOVE FORMATION DAMAGE DUE TO CARBONATE
SOLIDS PLUGGING,55 GAL PER DRUM,A PROPRIETARY BLEND OF ORGANIC
ESTERS,PHYSICAL PROPERTIES:APPEARANCE,A LIQUID ORGANIC ACID PERCURSOR
WHICH WILL GENERATE ORGANIC ACID IN-SITU DOWNHOLE WHICH HAS THE
CAPAVILITY TO DISSOLVE CALCIUM CARBONATE FILTER CAKE SOLIDS TO REMOVE
FORMATION DAMAGE DUE TO CARBONATE SOLIDS PLUGGING. IT IS TO BE USED
TOGETER WITH ORCA-4 WATER-WETTING SURFCTANT IN THE PREPARATION OF
THE PROPRIETARY MUDWASH FILTER-CAKE BREAKER SYSTEM FOR OBM
WELLBORE CLEAN-UP. VENDOR TO SUBMIT CERTIFICATE OF ANALYSIS (COA) AND
CERTIFICATE OF ORIGIN (COO). 210 KG (55 GAL)
1000905195
152
Chemicals
(Drilling Fluids)
Water wetting surfactant - ORCA-
4
ADDITIVE DRILLING FLUID; LIQUID FORM,WATER WETTING SURFACTANTS,FOR A
LIQUID WATER WETTING SURFACTANT MIXTURE USED IN THE PREPARATION OF
WELLBORE CLEAN-UP FLUID TO ALTER THE WETTEABILITY OF THE FILTER CAKE
SOLIDS FROM OIL-WET TO WATER # WET.,A WATER-WETTING SURFACTANT
MIXTURE,55 GAL PER DRUM,PHYSICAL PROPERTIES : APPEARAN,#CONTAINER
MUST BE PROPERLY LABELED WITH, VENDOR'S NAME, MANUFACTURE'S NAME
LOCATION,PRODUCTION DATE AND BATCH NUMBER SAUDI ARAMCO'S
PERSONNEL WILL CARRY OUT PROPER SAMPLING AND TESTING AS
NEEDED.####A LIQUID WATER WETTING SURFACTANT MIXTURE USED IN THE
PREPARATION OF WELLBORE CLEAN-UP FLUID TO ALTER THE WETTEABLITY OF
THE FILTER CAKE SOLIDS FROM OIL-WET TO WATER-WET. IT IS TO BE USED
TOGETHER WITH ORCA-B THE ACID PRECURSOR IN THE PREPARATION OF THE
PROPRIETARY MUDWASH FILTER CAKE BRAKER SYSTEM FOR OBM WELLBORE
CLEAN-UP. VENDER TO SUBMIT CERTIFICATE OF ANALYSIS (COA) AND
CERTIFICATE OF ORIGIN (COO). 200 KG (55 GAL).
1000905196

Material Number
9COM/9CAT
153
Chemicals
(Drilling Fluids)
WBM filter cake removal -
Enzyme
ADDITIVE DRILLING FLUID; LIQUID FORM,ENZYME PROTEIN,FOR FILTER CAKE
REMOVAL FOR WATER BASED MUD AND BRIDGING PARTICLES PRESENT IN THE
CAKE, REMOVING THE NEAR-WELLBORE DAMAGE,ENZYME PROTEIN,DRUM (ONE
DRUM = 55 GALLONS),APPEARANCE: LIGHT BROWN LIQUID,ADDITIVE FOR
DRILLING FLUID. IT IS A FILTER CAKE REMOVAL FOR WATER BASED MUD WHICH
BREAKS DOWN THE STARCH POLYMERS PRESENT IN THE MUD FILTER CAKE
BREAKING ITS INTEGRITY AND ENABLE MORE EFFICIENT ACIDIZING TREATMENT
OF ACID-SOLUBLE DRILL SOLIDS AND BRIDGING PARTICLES PRESENT IN THE CAKE,
REMOVING THE NEAR-WELLBORE DAMAGE. TYPICAL TREATMENT IS 5 - 6% V/V.
SUPPLIER/VENDOR IS REQUIRED TO SUBMIT LAB CERTIFICATE OF ANALYSIS (COA)
AND CERTIFICATE OF ORIGIN (COO).
1000908540
154
Chemicals
(Drilling Fluids)
LOW TOXICITY BASED OIL
FSARALINE 185V
ADDITIVE DRILLING FLUID; CLEAR LIQUID FORM,CLEAN NATURAL GAS
ORIGIN,FOR IT IS LOW TOXICITY MINERAL OIL USE AS BASE OIL FOR
FORMULATING OIL-BASED DRILLING FLUID IT IS COMPATIBLE WITH ALL OIL
BASED DRILLING FLUIDS ADDITIVES. IT IS COMPARABLE WITH LOW TOXICITY
MINERAL OIL AND TS SPECIFICATION OF # 1000022138 AS STATED BEL,A
MIXTURE OF ALKANES. CLEAR AND ODORLESS PARAFFIN OIL,GALLON,TM D1319)
TM D611) TM D93) LYSIS (COA) AND LINE POINT: MORE THAN 75 DE HORIZED
ZENE CONTENT: NIL PPM ASSAY TEST): > 100,000 PPM. RY OUT TIFICATE OF
ORIGIN (COO). SH POINT: MORE THAN 85 DEG 50 (MYSID SHRIMP 96-HR : 0.77-
0.97 (ASTM D1298) FINS CONTENT: NIL PPM KAGING AS PER SAUDI ARAMCO
YNUCLEAR AROMATIC: NIL PPM PLING AND TESTING AS NEEDED DI ARAMCO
PERSONNEL WILL CIFIC GRAVITY AT 15 OC : PLIER/VENDOR IS REQUIRED SUBMIT
LAB CERTIFICATE OF AL AROMATIC: LESS THAN 0.5.
1000908544
155
Chemicals
(Drilling Fluids)
CHEMICAL: GR TECHNICAL,
SODIUM
CHEMICAL; GR TECHNICAL,SODIUM CARBONATE,FOR WATER
TREATMENT,GRANULAR FORM,40 OR 50 KG SACK,98% CALCINED,SODA ASH
(WASHING SODA),AWWA B201,SHIPMENT OF PRODUCT SHALL CONFORM TO
SAUDI ARAMCO EXPORT PACKING MANUAL REQUIRES SAUDI ARAMCO HAZCOM
LABEL IN MM# 1000644353
1000186131
156
Chemicals
(Drilling Fluids)
CHEMICAL: GR ACS, SODIUM
SULFITE,
CHEMICAL; GR ACS,SODIUM SULFITE,FOR REDUCE FREE CHLORINE & OXYGEN
CONTENT OF RAW WATER PRELIMINARY TO WATER SOFTENING,POWDER
FORM,50 KG (110 LB) DRUM WITH POLYETHYLENE INNER BAG,97% ANHYDROUS
SODIUM SULFITE MIN UNCATALYZED SOLUBLE IN WATER,OXYGEN
SCAVENGER,REQUIRES SAUDI ARAMCO HAZCOM LABEL IN MM# 1000642488
1000186443

Material Number
9COM/9CAT
157
Chemicals
(Drilling Fluids)
ANTIFREEZE: TRIETHYLENE
GLYCOL, LIQUID
ANTIFREEZE; TRIETHYLENE GLYCOL TYPE,TECHNICAL, LIQUID, 208.2 LITER/ DRUM
TO BE LABELED IN ARABIC AND ENGLISH AS FOLLOWS: TRIETHYLENE GLYCOL S/N
26-922-105-00 REQUIRES SAUDI ARAMCO HAZCOM LABEL IN MM# 1000644191
1000187171
158
Chemicals
(Drilling Fluids)
CHEMICAL: GR USP, CITRIC ACID,
POWDER
CHEMICAL; GR USP,CITRIC ACID,FOR LABORATORY,POWDER FORM,50 KG (110 LB)
NET WT POLYETHYLENE LINED DRUM,99.5% CITRIC ACID MIN,CITRIC ACID
(ANHYDROUS),REQUIRES SAUDI ARAMCO HAZCOM LABEL IN MM# 1000644278
1000177936
159
Chemicals
(Drilling Fluids)
CHEMICAL: GR A, METHANOL,
LIQUID,
CHEMICAL; GR A,METHANOL,LIQUID FORM,208.2 L (55 US GAL) STEEL
DRUM,SYNTHETIC,METHYL ALCOHOL (WOOD ALCOHOL),ASTM D1152, FED SPEC
O-M-232G GRADE A,DRUM TO BE LABELED IN ARABIC & ENGLISH AS FOLLOWS:
"METHANOL" S/N 26-646-940-00 REQUIRES SAUDI ARAMCO HAZCOM LABEL IN
MM# 1000642494
1000184543
160
Chemicals
(Drilling Fluids)
POTASSIUM HYDROXIDE
CHEMICAL; GR TECHNICAL,POTASSIUM HYDROXIDE,FREE FLOWING GRANULAR
OR FLAKES FORM,25 KG (55 LBS)/SACK,POTASSIUM CARBONATE, K2CO3 0.8%
WT, MAXIMUM POTASSIUM CHLORIDE 0.02% WT MAXIMUM, IRON 0.001% WT
MAXIMUM,90% KOH PURITY, SHIPMENT OF PRODUCT SHALL CONFIRM TO SAUDI
ARAMCO EXPORT PACKING MANUAL. SAUDI ARAMCO WILL CARRY OUT
SAMPLING AND TESTING AS NEEDED.
1000185389
161
Chemicals
(Drilling Fluids)
FIBER, 25 LB
ADMIXTURE DRILLING MUD; ADDITIVE, FIBROUS CELLULOSIC MATERIAL
FORM,FIBROUS CELLULOSIC MATERIAL,FOR DESIGNED TO EFFECTIVELY SEAL THE
BOREHOLE WALL IN SAND AND FRAC AND TO STOP THE LOSS OF DRILLING FLUID
BY PLUGGING THE VOIDS,FIBROUS CELLULOSIC MATERIAL,25
LB/SACK,APPEARANCE: FINE: BROWN POWDERED, BULK DENSITY: 31 LB/FT(497
KG/M), PH 4.9, SPECIFIC GRAVITY: 1.3, ODOR: ODORLESS, DENSITY@20C (KG/L)
1.1, FREEZING POINT 190 C, FLASH POINT 193 C, OTHER ASSOCIATED ELEMENTS
MUST NOT BE HARMFUL TO PERSONNEL AND/OR ADVERSELY AFFECT FLUID
PROPERTIES.
1000789220
162
Chemicals
(Drilling Fluids)
SODIUM BROMIDE (NaBr) WHITE
CRYSTALS
ADDITIVE DRILLING FLUID; FINE CRYSTAL FORM,SODIUM BROMIDE,FOR SODIUM
BROMIDE IS AN INORGANIC COMPOUND THAT IS USED TO PREPARE DENSE
CLEAR FLUIDS FOR USE IN DRILLING, COMPLETION OR WORK&#8208 GAS WELLS.
R OF OIL OR,SODIUM BROMIDE,PP WOVEN BAG WITH PE LINER
INSIDE,APPEARANCE: WHITE FINE CRYSTAL,CONTAINER MUST BE PROPERLY
LABELED WITH VENDOR'S NAME, MANUFACTURER'S NAME, LOCATION,
PRODUCTION DATE AND BATCH NUMBER. SAUDI ARAMCO WILL CARRY OUT
PROPER SAMPLING AND TESTING AS NEEDED.
1000847074

Material Number
9COM/9CAT
163
Chemicals
(Drilling Fluids)
POWDER PHPA
ADDITIVE DRILLING FLUID; POWDER FORM,HIGH-MOLECULAR WEIGHT PARTIALLY-
HYDROLYZED POLYACRYLAMIDE (PHPA),FOR IT PROVIDES BOREHOLE STABILITY
AND REDUCES FRICTION IN SENSITIVE SHALE SECTIONS. IT, ALSO, ACTS AS A
FILTRATION CONTROL AND INCREASES VISCOSITY IN WATER-BASED DRILLING
FLUIDS.,PARTIALLY-HYDROLYZED POLYACRYLAMIDE (PHPA),BAG,APPEARANCE:
GRANULAR WHITE SOLID POLYMER. SOLUBILITY I,CONTAINER MUST BE
LOCATION, PRODUCTION DATE AND BATCH NUMBER. SAUDI ARAMCO WILL
CARRY OUT PROPER SAMPLING AND TESTING AS NEEDED.
1000866365
164
Chemicals
(Drilling Fluids)
ORGANOPHILIC CLAY
ADDITIVE DRILLING FLUID; POWDER FORM,ORGANOPHILIC CLAY,FOR PROVIDES A
RAPID YIELD UNDER LOW-SHEAR AND LOW-TEMPERATURE CONDITION AND
DEVELOPS THE MAXIMUM RHEOLOGICAL PROPERTIES SHORTLY AFTER BEING
MIXED. IT MORE EFFECTIVE IN ALL-OIL FLUIDS THAN STANDARD ORGANOPHILIC
CLAYS,ORGANOPHILIC CLAY,BAG,APPEARANCE: POLYMER RELATIVE DENSITY: 1.7
@ 20 SOLUBILITY IN WATER: INSOLU.
1000866368
165
Static Equipment
(Heat Transfer)
EJECTOR; AIR; STEAM OR
WATER.;
EJECTOR; AIR,STEAM OR WATER.,AIR, STEAM OR WATER.
6000002415
166
Static Equipment
(Heat Transfer)
HEAT EXCHANGER; ELECTRIC; 32-
SAMSS-027;
HEAT EXCHANGER; ELECTRIC TYPE,32-SAMSS-027
6000002436
167
Static Equipment
(Heat Transfer )
FLARE; PROCESSED PLANT;
INCLUDING TEMPER
FLARE; PROCESSED PLANT TYPE,32-SAMSS-022,31-SAMSS-003 32-SAMSS-004,32-
SAMSS-011 32-SAMSS-013,34-SAMSS-830 34-SAMSS-711,INCLUDING
TEMPERATURE CONTROLS,IGNITERS AND STACK AND BURNPIT WITH
ACCESSORIES, FOR FGRS INCLUDES: COMPRESSORS. PRESSURE VESSELS(WATER
SEAL DRUMS) OR CONTROL VALVES WITH BUCKING PIN VALVES, BLOWERS AND
AIR COOLED HEAT EXCHANGERS. FOR IN-HOUSE HPAAS (HIGH PRESSURE AIR
ASSIST SYSTEM) FLARE SMOKELESS APPLICATION INCLUDE: HPAAS FLARE TIP,
COMPRESSORS, PRESSURE VESSELS(AIR DRYER AND RECEIVER DRUM), CONTROL
VALVES AND HEAT EXCHANGERS.
6000002508
168 Static Equipment
CONDENSER; SURFACE STEAM
SYSTEM;
CONDENSER; SURFACE STEAM SYSTEM TYPE,32-SAMSS-007,CONDENSER SYSTEM
TYPE, COMPLETE WITH EJECTORS & EXCHANGER FACE STEAM
6000002534
169
Static Equipment
(Heat Transfer)
BURNER; HIGH INTENSITY, FOR
SULFUR
BURNER; HIGH INTERSITY TYPE,HIGH INTERSITY,FOR SULFUR RECOVER UNIT
REACTION FURNACE
6000011229
170 Static Equipment SKID; THERMAL OXIDIZER
SKID; THERMAL OXIDIZER TYPE,WITH RE-BOILER
6000011955
171
Static Equipment
(Fittings)
SLEEVE; PIPE; TWO HALVES;
BOLTED FLANGED
SLEEVE PIPE BOLTED; STEEL,FOR PIPE REPAIR,FOR PIPE REPAIR
6000000134

Material Number
9COM/9CAT
172
Static Equipment
(Fittings)
FLANGE; BLIND; COPPER-ALLOY,
EEMUA 145;
FLANGE BLIND NON-KHUFF; FLANGE COPPER-ALLOY, EEMUA 145 ND
6000000180
173
Static Equipment
(Fittings)
FLANGE; PIPE; COPPER NICKEL,
EEMUA 145
FLANGE PIPE; ALL DESIGNS TYPE,EEMUA 145,EEMUA 145,COPPER-ALLOY
FLANGES AND CS BACKING (LAP JOINT) FLANGES PER EEMUA
6000000181
174
Static Equipment
(Fittings)
FLANGE; COMPACT WN PAIR, M-
F CONNECTOR
FLANGE PIPE; COMPACT FLANGE WN PAIR, WN-BLIND, WN-WN SWIVEL-RING OR
AS DESIGNED TYPE,ASME CLASS 900 AND ABOVE SUPPLY,WN WITH SELF-
ENERGIZING SEAL TERMINAL,ANY STEEL PER 02-SAMSS-011,ASME SEC VIII
DESIGN,02-SAMSS-011,COMPLETE ASSEMBLY WITH MALE-FEMALE CONNECTOR,
SEAL RING, BOLTS AND NUTS
6000000188
175
Static Equipment
(Fittings)
TRAP: STEAM; MECHANICAL
TRAP STEAM; FLOAT, BALL TYPE,FLANGED, THREADED, SOCKET INLET,FLANGED,
THREADED, SOCKET OUTLET,PR PISG,PISG INLET,LB/HR CONDENSA,DEG F (DEG
C0) OPERATIN,ASTM BODY,ASTM TRIM,ASTM STRAINER,ASTM
ELEMENT,FLOAT,BALL,OTHER STANDARD EQUIVALENT MAY BE SHOWN
6000000196
176
Static Equipment
(Fittings)
FLANGE; NON-METALIC BLIND
FLANGE BLIND; EPOXY, POLYESTER, VINYL ESTER RESIN,01-SAMSS-034,SAES-S-040
SAES-S-070
6000000225
177
Static Equipment
(Fittings)
FLANGE: BLIND, EPOXY RESIN, 01-
SAMSS-034
FLANGE BLIND; EPOXY RESIN,01-SAMSS-034
6000011660
178
Static Equipment
(Fittings)
FITTING; PIPE; CUNI;ALL
TYPES;EEMUA 146
FITTING: PIPE; CUNI PIPE FITTINGS, ALL TYPES, EEMUA 146 INCLUDING ELBOWS,
TEES, REDUCERS, CAPS, COUPLING, BRANCH CONNECTION, BW OR SW OR
THREADED AS PER EEMUA 146. NON-HYDRCARBON UTILITY.
6000014202
179
Static Equipment
(Heat Transfer )
HOSE: CORRUGATED METALLIC
ASSEMBLIES
HOSE; ISO 10380,CORRUGATED METALLIC HOSE ASSEMBLIES
6000015210
180
Static Equipment
(Valves)
VALVE; GATE; PARALLEL SLIDE; 2
INCH AND
VALVE GATE; PARALLEL SLIDE TYPE,SIZE NPS 2 AND UP,ASME CL 150 AND UP
SUPPLY,FLANGED OR BUTTWELD END CONN,STEEL BODY,04-SAMSS-035,04-
SAMSS-048 04-SAMSS-001,WITH OR WITHOUT ACTUATOR
6000000286
181
Static Equipment
(Valves)
VALVE; GATE; THRU
CONDUIT;EXPANDING GATE
VALVE GATE THRU CONDUIT; SIZE NPS 2 AND UP,ASME CL 150 AND UP
SUPPLY,FLANGED OR BUTTWELD END CONN,STYLE EXPANDING GATE,STEEL
BODY,04-SAMSS-050,WITH OR WITHOUT ACTUATOR
6000000290
182
Static Equipment
(Valves)
VALVE; GATE; UP TO 12 INCH;
NON-FERROUS;
VALVE GATE; SIZE UP TO NPS 12,ANY RATING, ALLENDS SUPPLY,NON-FERROUS,
(BRONZE/ALUMINUM-BRONZE BODY,04-SAMSS-035,04-SAMSS-048 04-SAMSS-
001,WITH OR WITHOUT ACTUATOR
6000000292
183
Static Equipment
(Valves)
VALVE; PLUG; EXPANDING;04-
SAMSS-041;
VALVE PLUG; EXPANDING TYPE,SIZE ANY SIZE,ANY PRESSURE RATING
SUPPLY,STEEL BODY,04-SAMSS-041,04-SAMSS-035 04-SAMSS-048,WITH OR
WITHOUT ACTUATOR
6000000307
184
Static Equipment
(Valves)
VALVE; PLUG; NON-LUBRICATED
VALVE PLUG; NON-LUBRICATED TYPE,SIZE ANY SIZE,ANY PRESSURE RATING
SUPPLY,STEEL OR DUCTILE IRON BODY,04-SAMSS-035,04-SAMSS-048 API
599,ASME B16.34,WITH OR WITHOUT ACTUATOR
6000000309

Material Number
9COM/9CAT
185
Static Equipment
(Valves)
VALVE: CHOKE; API 6A, 10000 PSI
VALVE CHOKE; NEEDLE AND SEAT TYPE,1-13/16 IN & UP BODY,PR 10000
PSI,HUBBED, FLANGED OR BUTTWELD END CONN,MR API 6A,STEEL BODY,04-
SAMSS-049,04-SAMSS-035 04,WITH OR WITHOUT ACTUATOR
6000000313
186
Static Equipment
(Valves)
VALVE; CHECK; 2 THRU 24 IN;
SOFT SEAT
VALVE CHECK; SIZE 2 THRU 24 INCH,ANSI CL 150 AND UP SUPPLY,STEEL
BODY,SWING,REGULAR,FLANGED OR BUTTWELD END CONN,METAL OR SOFT
SEAT,04-SAMSS-005,04-SAMSS-035
6000000326
187
Static Equipment
(Valves)
VALVE: HYDRANT PIT, JET FUEL
VALVE; HYDRANT PIT TYPE,SIZE ALL SIZES,ALL RATINGS SUPPLY,FOR JET FUEL,
CONTACT CSD FOR DETAILS.
6000004665
188
Static Equipment
(Valves)
VALVE; GATE, GLOBE&CHECK,
CRYOGENIC
VALVE GATE; GLOBE&CHECK, CRYOGENIC TYPE,SIZE ANY SIZE,ANY RATING
SUPPLY,04-SAMSS-035,04-SAMSS-048,GLOBE,CHECK CRYOGENIC
6000013010
189
Static Equipment
(Valves)
VALVE; PLUG; Full Opening
LUBRICATED
VALVE PLUG; LUBRICATED TYPE,FULL BORE BORE,STEEL BODY,04-SAMSS-035,04-
SAMSS-048 API 599 AND ASME B16,FULL BORE TO ALLOW FOR THE PASSAGE OF
SCRAPERS WITH OR WITHOUT ACTUATOR
6000013743
190
Static Equipment
(Valves)
VALVE, BALL; HIGH
PERFORMANCE STEEL
VALVE BALL; ANSI CL 150 AND UP SUPPLY,FLANGED OR BUTTWELD END
CONN,STYLE SPLIT BODY,SEAT SUPPORTED SUPPORT,METAL SEATED SEAT,04-
SAMSS-035,04-SAMSS-048 04-SAMSS-051,HIGH PERFORMANCE STEEL AND ZERO
LEAKAGE, WITH OR WITHOUT ACTUATOR
6000013744
191
Static Equipment
(Valves)
VALVE;BUTTERFLY; TRICENTRIC
VALVE BUTTERFLY; HIGH PERFORMANCE TYPE,TRICENTRIC,CL 150 AND UP
SUPPLY,FLANGED OR BUTTWELD END CONN,04-SAMSS-035,04-SAMSS-048 API
6D,API 609,HIGH PERFORMANCE, ZERO LEAKAGE, WITH OR WITHOUT ACTUATOR
6000013745
192
Static Equipment
(Valves)
VALVE: BLIND; STEEL; FULL BORE;
NPS
VALVE; BLIND TYPE,SIZE NPS 2 THRU 24,ASME CLASS 150 AND UP
SUPPLY,FLANGED END CONN,STEEL BODY,ASME SCE VII DIV 1, ASME B31.3,FULL
BORE, FOR NON- HYDROCARBON SEVICES
6000014054
193
Static Equipment
(Valves)
VALVE: BALL;1-13/16 IN AND UP;
API 10000
VALVE BALL; SIZE 1-13/16 IN AND UP,API 10000 SUPPLY,FLANGED OR BUTTWELD
END CONN,STYLE SPLIT BODY,TRUNNION SUPPORT,METAL SEAT,04-SAMSS-049 6000014982
194
Static Equipment
(Vessels)
TANK; FIBER GLASS; 32-SAMSS-
002
TANK; FIBER GLASS,32-SAMSS-002
6000002481
195
Static Equipment
(Process Vessels)
SKID; NITROGEN GENERATION;
MEMBRANE TYPE
SKID; MEMBRANE TYPE,32-SAMSS-038,NITROGEN GENERATION
6000002461
196
Static Equipment
(Process Vessels)
SKID; DRYER, INSTRUMENT AIR &
COMPRESSED
SKID; DRYER TYPE,32-SAMSS-038,INSTURMENT AIR & COMPRESSED GAS
6000002879
197
Static Equipment
(Tanks)
TANK;ROOF;FLOATING;INTERNAL
;32-SAMSS-005
TANK; ROOF TYPE,32-SAMSS-005,ATING ERNAL
6000011664
198
Static Equipment
(Tubes)
DRIER, LIQUID, GAS AND
COMPRESSED AIR
DRIER; LIQUID,GAS AND COMPRESSED AIR,LIQUID, GAS AND COMPRESSED AIR
6000002414

Material Number
9COM/9CAT
199
Static Equipment
(Tubes)
TUBE BUNDLE; TWISTED TUBE
TYPE, HEAT
TUBE; 32-SAMSS-007
6000011344
200
Static Equipment
(HVAC)
AIR HANDLING UNIT; AHU;
CHILLED WATER OR
AIR HANDLING UNIT; AHU TYPE,CHILLED WATER OR DIRECT
EXPANSION,ONSHORE ALL SIZES AND OFFSHORE LESS THAN 10 TONS
COOLING,MANUFACTURER STANDARD
6000001821
201
Static Equipment
(HVAC)
AIR CONDITIONING UNIT; SELF
CONTAINED; O
AIR CONDITIONING UNIT; SELF CONTAINED TYPE,(PACKAGED UNIT) CERTIFIED TO
AHRI 340 AND UL 1995 STD
6000001822
202
Static Equipment
(HVAC)
AIR CONDITIONING UNIT;
PACKAGED UNIT TRA
AIR CONDITIONING UNIT; PACKAGED UNIT TRAILERIZED TYPE,AIR COOLED,R-22
OR R-134A,MANUFACTURER STANDARD
6000001823
203
Static Equipment
(HVAC)
HVAC; THROUGH THE WALL;
WINDOW UNIT
AIR CONDITIONING UNIT; WINDOW TYPE,R-22 AND R-134A,AHRI-210/240 UL-
484,USE 9COM 6000001826 INSTEAD.
6000001825
204
Static Equipment
(HVAC)
A/C Unit,mini-split,DE below 5.5
Tons
AIR CONDITIONING UNIT; AIR CONDITIONING UNIT SPLIT TYPE, LESS THAN 5.5
TON COOLING TONNAGE, DIRECT EXPANSION TYPE,AHRI 210/240,UL-1995 6000001826
205
Static Equipment
(HVAC)
CONDENSING UNIT; AIR COOLED;
ONSHORE ALL
CONDENSING UNIT AIR COOLED; ONSHORE ALL SIZES AND OFFSHORE LESS THAN
10 TONS COOLING,MANUFACTURER STANDRADRS
6000001831
206
Static Equipment
(HVAC)
CONTROLLER; PROGRAMMABLE
LOGIC; ENERGY M
CONTROLLER PROGRAMMABLE LOGIC; ENERGY MANAGEMENT SYSTEM:
BUILDING 6000001838
207
Static Equipment
(HVAC)
A/C UNIT;SPLIT;DIRECT EXP,5.5
TO 63 TONS
AIR CONDITIONING UNIT; AIR CONDITIONING UNIT SPLIT UNIT DIRECT
EXPANSION TYPE,SIZES 5.5 TO 63 COOLING TONNAGE COOLING,AHRI
340/360,UL1995
6000001862
208
Static Equipment
(HVAC)
AIR CONDITIONING UNIT;
AIRCONDIONING AND
AIR CONDITIONING UNIT; AIRCONDIONING AND PROCESS REFRIGERATION
SYSTEMS TYPE,ONSHORE ALL SIZES, OFFSHORE LESS THAN 10 TONS. COOLING,AB
REFRIGERATION SYSTEMS,EXPLOSION PROOF
6000001881
209
Static Equipment
(HVAC)
CHILLER: HVAC/REFRIG, PACKGD
RECIPROCTG,
CHILLER; HVAC/REFRIGERATION TYPE,PACKAGED RECIPROCATING, AIR COOLED,
FOR NON-PROCESS APPLICATIONS
6000001884
210
Static Equipment
(HVAC)
AIR CONDITIONING UNIT; SPLIT
AIR CONDITIONING UNIT; SPLIT TYPE,DIRECT EXPANSION,R-22 OR R-
134A,PRECISION COOLING FOR CONTROL, COMMUNICATION, AND DATA
PROCESSING
6000013333
211
Static Equipment
(HVAC)
AIR VOLUME BOX; VAR OR
CONST
BOX; AIR VOLUME, VARIABLE OR CONSTANT TYPE
6000013335
212
Static Equipment
(HVAC)
CHILLER: ABSORPTION; WATER
COOLED
CHILLER; ABSORPTION WATER COOLED DIRECT FIRED OR STEAM TYPE,AHRI
560,FOR HVAC APPLICATION. ABSORPTION WATER CHILLING AND WATER
HEATING PACKAGES
6000012733
213
Rotating Equipment
(Compressor)
COMPRESSOR: PROCESS; SCREW;
WET
COMPRESSOR PROCESS; SCREW TYPE,API-619,WET, GAS APPLICATIONS
6000013840

Material Number
9COM/9CAT
214
Rotating Equipment
(Pump)
TURBINE, HYDRAULIC RECOVERY,
API STD
TURBINE; HYDRAULIC TYPE,31-SAMSS-004,POWER RECOVERY
6000014644
215
Rotating Equipment
(Pump)
DEVICE:HYDRAULIC POWER
RECOVERY, MFR STD
TURBINE; HYDRAULIC TYPE,MFR STANDARD,POWER RECOVERY
6000014646
216
Rotating Equipment
(Compressor)
FILTER: COMPLETE UNIT; SELF-
CLEANING
FILTER COMPLETE UNIT; SELF-CLEANING AIR FILTRATION SYSTEM, PULSE TYPE
TYPE,FOR FOR 31-SAMSS-006 AIR CENTRIFUGAL COMPRESSORS,FILTER ELEMENTS
TO COMPLY WITH 32-SAMSS-016
6000013953
217
Rotating Equipment
(Power Transmission)
COUPLING: VARIABLE SPEED,
HYDRAULIC
COUPLING SHAFT; 13-SAMSS-001,API 613,FOR ROTATING EQUIPMENT, VARIABLE
SPEED HYDRAULIC FLUID TYPE, WITH OR WITHOUT GEAR, WHEN GEAR ROTORS
ARE USED, THE GEARS SHALL COMPLY TO 13-SAMSS-001/API 613.
6000000722
218
Rotating Equipment
(Compressor)
COMPRESSOR; PROCESS; SCREW;
DRY
COMPRESSOR PROCESS; SCREW TYPE,API-619,DRY, GAS APPLICATIONS
6000002339
219
Rotating Equipment
(Engine & Maint Eqpt)
ENGINE; DIESEL; INDUSTRIAL
ENGINE DIESEL; INDUSTRIAL TYPE,50 KW (67 HP ) OR GREATER BHP,30-SAMSS-
001 6000002198
220
Rotating Equipment
(Turbine, Gas)
TURBINE: WIND, FOR POWER
GENERATOR
TURBINE; WIND TYPE,IEC 61400,FOR POWER GENERATOR
6000015090
221
Rotating Equipment
(Blowers)
BLOWER; CENTRIFUGAL
BLOWER; CENTRIFUGAL TYPE,31-SAMSS-001 CHAPTER 2 OR 3
6000002340
222
Rotating Equipment
(Compressor)
PUMP; VACUUM; API 681, HIGH
POWER
PUMP; VACUUM TYPE,API 681,HIGH POWER, LIQUID RING VACUUM PUMPS OR
COMPRESSORS
6000002365
223
Rotating Equipment
(Compressor)
EXPANDER: TURBO, FOR
CRYOGENIC APPLICATI
EXPANDER; TURBO TYPE,API-617,7 EDITION,FOR CRYOGENIC APPLICATIONS IN
GAS REFRIGERATION AND AIR SEPARATION SERVICES
6000010962
224
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; CANNED
MOTOR;
PUMP CENTRIFUGAL; CANNED MOTOR TYPE,ASME B73.3M / ISO15783
6000002367
225
Rotating Equipment
(Turbine, Gas)
FILTER; ELEMENT; COMBUSTION
GAS TURBINE;
FILTER ELEMENT; FOR COMBUSTION GAS TURBINE,32-SAMSS-008,AIR INLET,
FINAL STAGE
6000002417
226 Rotating Equipment
ENGINE: DIESEL, FIRE WATER
PUMP DRIVER
ENGINE DIESEL; FIRE WATER PUMP DRIVER (PER UL 1247 OR FM 1333)
TYPE,EMERGENCY/STANDBY SERVICE CYCLE,PER UL 1247 OR FM1333 COOLED,30-
SAMSS-001,UL 1247,FM 1333,INSPECTION FORM 175-300100
6000016250
227
Rotating Equipment
(Pump)
PUMP; CENT, HORIZ, ASMEB73.1
OR ISO5199
PUMP CENTRIFUGAL; HORIZONTAL MTG,ASME B73.1 OR ISO 5199
6000002350
228
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL;
VERTICALLY SUSPENDED;
PUMP CENTRIFUGAL; VERTICALLY SUSPENDED TYPE,VERTICAL MTG,31-SAMSS-
004
6000002288
229
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; GENERAL
SERVICE;HORIZ
PUMP CENTRIFUGAL; GENERAL SERVICE TYPE,HORIZONTAL MTG
6000002283

Material Number
9COM/9CAT
230
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL;
FIREWATER;HORIZONTAL;
PUMP CENTRIFUGAL; FIREWATER TYPE,HORIZONTAL MTG,NFPA 20,UL OR FM
APPROVED
6000002355
231
Rotating Equipment
(Pump)
PUMP; HORZ; MULTISTAGE; LESS
THAN 10 MW
PUMP CENTRIFUGAL; MULTISTAGE STAGE(S),DOUBLE CASE, RADIALLY SPLIT
CASING,HORIZONTAL MTG,31-SAMSS-004,LESS THAN 10 MW
6000002360
232
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; HIGH
HEAD, LOW FLOW
PUMP CENTRIFUGAL; HIGH HEAD, LOW FLOW TYPE,31-SAMSS-004
6000002352
233
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; SINGLE
STAGE; DOUBLE
PUMP CENTRIFUGAL; SINGLE STAGE STAGE(S),DOUBLE SUCTION IMPELLER,AXIAL
SPLIT CASING,HORIZONTAL MTG,31-SAMSS-004
6000002357
234
Rotating Equipment
(Compressor)
CRYOGENIC APPLICATI
6000010962
235
Rotating Equipment
(Pump)
PUMP: RECIPROCATING, 31-
SAMSS-009
PUMP RECIPROCATING; POSITIVE DISPLACEMENT, CONTROLLED VOLUME
TYPE,31-SAMSS-009
6000002361
236
Rotating Equipment
(Compressor)
COMPRESSOR; DRY-SCREW, FOR
AIR SERVICE
COMPRESSOR; DRY-SCREW TYPE,31-SAMSS-002,FOR AIR SERVICE
6000002338
237
Rotating Equipment
(Blowers)
BLOWER; CENTRIFUGAL
BLOWER; CENTRIFUGAL TYPE,31-SAMSS-001 CHAPTER 2 OR 3
6000002340
238
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; SELF-
PRIMING; MFR STD
PUMP CENTRIFUGAL; SELF-PRIMING TYPE
6000002342
239
Rotating Equipment
(Engine & Maint Eqpt)
ENGINE; DIESEL; INDUSTRIAL
ENGINE DIESEL; INDUSTRIAL TYPE,50 KW (67 HP ) OR GREATER BHP,30-SAMSS-
001 6000002198
240
Rotating Equipment
(Compressor)
CRYOGENIC APPLICATI
6000010962
241
Rotating Equipment
(Turbine, Gas)
TURBINE; HOT GAS EXPANSION;
TURBINE; HOT GAS EXPANSION TYPE,FOR DRIVING GAS COMPRESSOR OR
GENERATOR
6000002498
242
Rotating Equipment
(Compressor)
COMPRESSOR; RECIPROCATING;
COMPRESSOR; RECIPROCATING TYPE,FOR PLANT & INSTRUMENT AIR
6000002246
243
Rotating Equipment
(Compressor)
COMPRESSOR; DRY-SCREW, FOR
AIR SERVICE
COMPRESSOR; DRY-SCREW TYPE,31-SAMSS-002,FOR AIR SERVICE
6000002338
244
Rotating Equipment
(Compressor)
COMPRESSOR; PROCESS; SCREW;
DRY
COMPRESSOR PROCESS; SCREW TYPE,API-619,DRY, GAS APPLICATIONS
6000002339
245
Rotating Equipment
(Compressor)
COMPRESSOR:PROCESS;CENTRIF
UGAL;SEAL-LESS
COMPRESSOR PROCESS; CENTRIFUGAL TYPE,31-SAMSS-001,API-617,SEAL-LESS,
GAS APPLICATIONS
6000014055
246
Rotating Equipment
(Compressor)
COMPRESSOR:PROCESS;CENTRIF
UGAL INTEGRALY
COMPRESSOR PROCESS; CENTRIFUGAL, INTEGRALLY GEARED TYPE,31-SAMSS-001
6000014210
247
Rotating Equipment
(Pump)
PUMP: ROTARY, GEAR, API 676
PUMP ROTARY; GEAR TYPE,API-676
6000002300

Material Number
9COM/9CAT
248
Rotating Equipment
(Pump)
PUMP: ROTARY, SCREW, API 676
PUMP ROTARY; SCREW TYPE,API-676
6000002303
249
Rotating Equipment
(Pump)
PUMP: ROTARY, VANE, API 676
PUMP ROTARY; VANE TYPE,API-676
6000002304
250
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; SELF-
PRIMING; MFR STD
PUMP CENTRIFUGAL; SELF-PRIMING TYPE
6000002342
251
Rotating Equipment
(Pump)
PUMP; CENT, INLINE, ASMEB73.2
OR ISO5199
PUMP CENTRIFUGAL; INLINE TYPE,VERTICAL MTG,ASME B73.2 OR ISO 5199
6000002351
252
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL;
FIREWATER;HORIZONTAL;
PUMP CENTRIFUGAL; FIREWATER TYPE,HORIZONTAL MTG,NFPA 20,UL OR FM
APPROVED
6000002355
253
Rotating Equipment
(Pump)
PUMP: RECIPROCATING, 31-
SAMSS-009
PUMP RECIPROCATING; POSITIVE DISPLACEMENT, CONTROLLED VOLUME
TYPE,31-SAMSS-009
6000002361
254
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; MAGNETIC
DRIVE;HORIZO
PUMP CENTRIFUGAL; MAGNETIC DRIVE TYPE,HORIZONTAL MTG,ASME B73.3M /
ISO15783
6000002366
255
Rotating Equipment
(Pump)
PUMP; CENTRIFUGAL; CANNED
MOTOR;
PUMP CENTRIFUGAL; CANNED MOTOR TYPE,ASME B73.3M / ISO15783
6000002367
256
Rotating Equipment
(Pump)
PUMP;
CENTRIFUGAL;VERTICAL;MOLTO
N SULFUR
PUMP CENTRIFUGAL; VERTICAL TYPE,MFR STD DESIGN +SAES-G-005,MOLTEN
SULFUR, SUMP 6000002371
257
Rotating Equipment
(Pump)
PUMP, CENTRIFUGAL,
HORIZONTAL, MOLTEN SU
PUMP CENTRIFUGAL; HORIZONTAL TYPE,MFR STD DESIGN +SAES-G-005,MOLTEN
SULFHUR
6000008842
258
Rotating Equipment
(Pump)
PUMP: MULTIPHASE, ROTARY,
API 676
PUMP; MULTIPHASE, ROTARY, SCREW OR PROGRESSIVE TYPE,API 676
6000010365
259
Rotating Equipment
(Pump)
PUMP: ROTARY, SCREW, API 676,
ASPHALT
PUMP ROTARY; SCREW TYPE,API 676,ASPHALT SERVICE
6000012249
260 Rotating Equipment
PUMP; ROTARY; PROGRESSIVE
CAVITY;
PUMP ROTARY; PROGRESSIVE CAVITY TYPE,API 676
6000002363
261
Rotating Equipment
(Pump)
PUMP: CENTRIFUGAL; SEALLESS;
VERTICAL
PUMP CENTRIFUGAL; SEALLESS TYPE,VERTICAL MTG,MFR STD
6000014690
262 Electrical
POLE; LINE; POWER
DISTRIBUTION; STEEL;
POLE LINE; POWER DISTRIBUTION TYPE,14-17 METERS LG,OCTAGONAL SHAPE
SHAPE,GALVANIZED STEEL,14-SAMSS-603,SINGLE PIECES 14-17 METERS IN
LENGTH, LONGER THAN 14 METERS MAY BE MANUFACTURED IN TWO PIECES,
SHALL BE PRE-DRILLED AND SUPPLIED COMPLETE WITH POLE TOP CAP AND BASE
PLATE.
6000000771
263
Electrical
(Protective & Control
Electrical Devices )
CABLEBUS 16-SAMSS-520
BUS; CABLE,16-SAMSS-520
6000000929

Material Number
9COM/9CAT
264 Electrical
PANELBOARD,LOW VOLTAGE,
EXPLOSIONPROOF
PANELBOARD ELECTRICAL; LOW VOLTAGE, EXPLOSIONPROOF TYPE,16-SAMSS-
518
6000000897
265
Electrical
(Switchgear)
BUS; ISOLATED PHASE BUS DUCT
BUS; 16-SAMSS-523,ISOLATED PHASE BUS DUCT
6000015923
266
Electrical
(Switchgear)
SWITCHGEAR; SF6 GAS
INSULATED, 380 KV
SWITCHGEAR; SF6 GAS INSULATED TYPE,380 KV,SEC 32-TMSS-02
6000016000
267
Electrical
(HV Cable)
CABLE; POWER, 380 KV,
CABLE ELECTRICAL HIGH VOLTAGE; 380 KV SUPPLY,XLPE TYPE,SEC 11-TMSS-02
6000016001
268
Electrical
(Solar Energy)
INVERTER, SOLAR POWER,
PHOTOVOLTAIC
INVERTER; PHOTOVOLTAIC SOLAR TYPE,AA GRID CONNECTION
6000014451
269
Electrical
(Cathodic Protection -
Above Grade
Equipment)
CABLE;ELECTRICAL, CP,
OFFSHORE ANODE
CABLE ELECTRICAL; ORED HODIC PROTECTION OFFSHORE TYPE,17-SAMSS-
017,ARMORED
6000000957
270
Electrical
(Switchgear)
SWITCHGEAR; LV CONTROLGEAR,
FIREWATER PU
SWITCHGEAR; CONTROLGEAR,FIREWATER PUMP TYPE,UL-218,LOW
VOLTAGE,OUTDOOR 6000000919
271
Electrical
(Switchgear)
SWITCHGEAR; HV
CONTROLGEAR, FIREWATER PU
SWITCHGEAR; CONTROLGEAR,FIREWATER PUMP TYPE,UL-218,HIGH
VOLTAGE,OUTDOOR 6000000920
272
Electrical
(Cable Support)
POLE LINE; POWER
TRANSMISSION, 69 KV
POLE LINE; POWER DISTRIBUTION TYPE,17 METERS AND UP LG,OCTAGONAL
SHAPE SHAPE,GALVANIZED STEEL,SEC
6000014870
273
Electrical
Above Grade
Equipment)
POWER
SUPPLY;ELECTRICAL;SOLAR,CP
POWER SUPPLY ELECTRICAL; HODIC PROTECTION POWER PLY ELECTRICAL SOLAR
POWER TYPE,17-SAMSS-012
6000001011
274
Electrical
Below Grade or
Immersed Equip.)
ANODE;GALVANIC,HIGH
TEMPERATURE ZINC,CP
ANODE GALVANIC; HIGH TEMPERATURE ZINC,17-SAMSS-006,CATHODIC
PROTECTION
6000015510
275
Electrical
Above Grade
Equipment)
CABLE; CP, FOR ONSHORE
ANODE
CABLE ELECTRICAL; STRANDED CONDUCTO,CATHODIC PROTECTION TYPE,FOR
FOR ONSHORE ANODE CONNECTION,,17-SAMSS-017
6000000938

Material Number
9COM/9CAT
276
Electrical
Below Grade or
Immersed Equip.)
ANODE
GALVANIC;MAGNESIUM,WITHO
UT LEAD,CP
ANODE GALVANIC; MAGNESIUM,17-SAMSS-006,CATHODIC PROTECTION
WITHOUT LEADS
6000001040
277
Electrical
(Cathodic Protection)
CABLE;
ELECTRICAL;OFFSHORE/ONSHOR
E,CP
CABLE ELECTRICAL; CATHODIC PROTECTION TYPE,STRANDED, NEGATIVE &
POSITIVE TYPE,SINGLE INSULATED INSUL LV,HMWPE INSUL,FOR
OFFSHORE/ONSHORE,17-SAMSS-017
6000001045
278 Electrical
STATIC SWITCH, UPS
APPLICATIONS
SWITCH; UPS APPLICATIONS,SOLID STATE STATIC TRANSFER TYPE,17-SAMSS-
516,EXTERNAL STAND-ALONE
6000001058
279
Electrical
Below Grade or
Immersed Equip.)
BOX: JUNCTION, FOR U/G
ANODE BED,CP
BOX ELECTRICAL; CATHODIC PROTECTION UNDERGROUND ANODE BED JUNCTION
BOX TYPE,SIZE 2500CM3 (MINIMUM),CYLINDRICAL OR BOX SHAPE,12X16MM2
AND 2X70MM2 CONNECTN,12+2 TERMINAL SCREW LUG COONECTN,FOR
WEATHERPROOF (DIRECT BURIAL),NON-CLASSIFIED,NON-METALLIC SUITABLE
FOR DIRECT BURIAL AND IMMERSION SERVICE IN AMBIENT TEMPERATURE
SEAWATER,OPTIONAL FINISH,OPTIONAL THK,17-SAMSS-008 'JUNCTION BOX FOR
CATHODIC PROTECTION',MEMBRANE GLANDS & FILLER/ SEALING COMPOUND
SUITABLE FOR DIRECT BURIAL AND IMMERSION SERVICE IN AMBIENT
TEMPERATURE SEAWATE
6000012080
280
Electrical
Below Grade or
Immersed Equip.)
ANODE: GALVANIC,
MAGNESIUM,CP
ANODE GALVANIC; MAGNESIUM,17-SAMSS-006,CATHODIC PROTECTION LARGE
SIZE CYLINDRICAL, FOR OFFSHORE APPLICATION
6000012790
281
Electrical
(Transformer, power
& distribution)
UNIT; MOBILE SUBSTATION
UNIT; MOBILE SUBSTATION TYPE,60044,IEC60376, 60076,IEC60255,
60332,IEC60146, 60478,IEC60529, 60518,IEC60099, 62271,IEC60137,ALL
COMPONENTS DETAILS ARE BASED ON AND INSPECTED TO IEC STANDARDS.
OPERATING AT 230 KV, 115KV, OR 69KV CONSISTING OF: EIGHT (8) AXLES
SEMITRAILER , METAL OXIDE SURGE ARRESTERS, SWITCHGEAR, DISCONNECT
SWITCHES, CURRENT TRANSFORMERS AND AUXILIARIES, CAPACITIVE VOLTAGE
TRANSFORMER , POWER TRANSFORMER , AUXILIARY TRANSFORMER,
CONDITIONED CONTAINER, PROTECTION/ CONTROL PANELS, BATTERIES
EQUIPMENT, SCADA CAPABILITIES. ((COMPONENTS DETAILS AND REQUIREMENTS
SHOULD BE DETERMINED IN THE PURCHASE REQUEST.
6000015902

Material Number
9COM/9CAT
282
Instrumentation and
IT
(Valve, Control)
VALVE: BACKFLOW PREVENTER;
FOR INSTRUMEN
VALVE; BACKFLOW PREVENTER INSTRUMENT INSTALLATIONS
6000002680
283
Instrumentation and
IT
(Controller: HYD; ESD,
SSV & SSSV)
MONITOR; WELL HEAD ESD;;
MONITORING & CO
MONITOR; WELL HEAD ESD, TYPE,WELL HEAD ESD,MONITORING & CONTROL
SYSTEMS
6000002721
284
Instrumentation and
IT
(DCS, ESD & Plant
Control Systems)
ESD; RELAYS
RELAY PROTECTION ELECTRO-MECHANICAL; 34-SAMSS-622,EMERGENCY
SHUTDOWN SYSTEM RELAY BASED USED TO SAFELY SHUTDOWN A PROCESS IN
CASE OF PROCESS DEVIATING TO HAZARDOUS OPERATING CONDITIONS.
6000002724
285
Instrumentation and
IT
(DCS, ESD & Plant
Control Systems)
ESD; ELECTRONIC; SOLID STATE
RELAY PROTECTION SOLID STATE; EMERGENCY SHUTDOWN SYSTEM ACTION,34-
SAMSS-621,SOLID STATE ELECTRONICS BASED USED TO SAFELY SHUTDOWN A
PROCESS IN CASE OF PROCESS DEVIATING TO HAZARDOUS OPERATING
CONDITIONS.
6000002725
286
Instrumentation and
IT
(Monitoring Eqpt
(Vibration, etc))
MONITOR; FLAME MONITORING
SYSTEM
MONITOR; IGNITERS AND BURNERS USED E MONITORING SYSTEM D IN FIRED
EQUIPMENT. TYPE,34-SAMSS-617
6000002732
287
Instrumentation and
IT
(Flow
Instrumentation)
FLOWMETER; THERMAL;
FLOWMETER; THERMAL TYPE,THERMAL
6000002736
288
Instrumentation and
IT
NOZZLE; FLOW;
NOZZLE; FLOW TYPE
6000002740
289
Instrumentation and
IT
(Flow
Instrumentation)
FLOWMETER:FOR REDUCE
PIPING REQUIREMENTS
FLOWMETER; 34-SAMSS-010,SPECIALTY FLOWMETER FOR REDUCING PIPING
REQUIREMENTS
6000002742
290
Instrumentation and
IT
(Gauges, Indicators,
Recorders)
INDICATOR; SIGHT FLOW; GLASS;
INDICATOR SIGHT FLOW; GLASS
6000002744
291
Instrumentation and
IT
(Instrumentation)
MONITOR; GAS; HYDROGEN
SULFIDE;
MONITOR GAS; HYDROGEN SULFIDE,34-SAMSS-514
6000002786

Material Number
9COM/9CAT
292
Instrumentation and
IT
(Analyzers,
Instrument)
MONITOR; GAS; COMBUSTIBLE;
OPEN PATH TYP
INDICATOR; PRESSURE TYPE
6000002787
293
Instrumentation and
IT
RECORDER; MULTI-POINT;
RECORDER; MULTI-POINT TYPE
6000002807
294
Instrumentation and
IT
(Gauges, Indicators,
Recorders)
SWITCH; TARGET
SWITCH FLOW; FLOW TYPE, INSTRUMENTATION
6000002831
295
Instrumentation and
IT
(Valves,
Instrumentation)
VALVE; CHECK; LEVEL GAUGE
GLASS; FLOW SH
VALVE CHECK; LEVEL GAUGE GLASS, FLOW FLOW SHUT-OFF SPRING,LEVEL
GAUGE GLASS, FLOW SHUT-OFF
6000002854
296
Instrumentation and
IT
(Instrumentation)
VALVE; AUTOMATIC
RECIRCULATION;
VALVE; AUTOMATIC RECIRCULATION TYPE,34-SAMSS-711
6000002856
297
Instrumentation and
IT
(Instrumentation)
VALVE; RELIEF; SURGE GAS
LOADED
VALVE RELIEF; SAES-J-605,SURGE GAS LOADED
6000002896
298
Instrumentation and
IT
(Instrumentation)
ANALYZER; GAS
CHROMATOGRAPH; Sheltered
ANALYZER; GAS CHROMATOGRAPH TYPE,34-SAMSS-511,PROCESS GAS OR LIQUID
6000002914
299
Instrumentation and
IT
(MULTIPHASE FM)
FLOWMETER; MULTIPHASE;
FLOWMETER; MULTIPHASE TYPE,34-SAMSS-001
6000002917
300
Instrumentation and
IT
(DCS, ESD & Plant
Control Systems)
CONTROLLER;
COMPRESSOR/TURBOMACHINER
Y;
CONTROLLER; COMPRESSOR/TURBOMACHINERY
TYPE,COMPRESSOR/TURBOMACHINERY,INEGRATED SYSTEMS
6000009392
301
Instrumentation and
IT
CUSTODY METER, TURBINE,
LIQUID
FLOWMETER TURBINE; CUSTODY TRANSFER LIQUID TYPE,34-SAMSS-117
6000009831
302
Instrumentation and
IT
(Custody Transfer
Measurement
Equipment)
CUSTODY METER, POS DISPL ,
LIQUID
FLOWMETER POSITIVE DISPLACEMENT; CUSTODY TRANSFER LIQUID TYPE,34-
SAMSS-118
6000009832

Material Number
9COM/9CAT
303
Instrumentation and
IT
(Custody
Measurement)
CUSTODY METER, CORIOLIS,
LIQUID
FLOWMETER CORIOLIS; CUSTODY TRANSFER LIQUID TYPE,CUSTODY TRANSFER
LIQUID
6000009833
304
Instrumentation and
IT
(Custody
Measurement)
CUSTODY METER, CORIOLIS GAS
FLOWMETER CORIOLIS; CUSTODY TRANSFER GAS TYPE
6000009883
305
Instrumentation and
IT
(Custody Transfer
Measurement
Equipment)
ORIFICE PLATE FOR CUSTODY
TRANSFER
ORIFICE PLATE; CUSTODY TRANSFER GAS TYPE,34-SAMSS-112
6000009887
306
Instrumentation and
IT
(Custody
Measurement)
CUSTODY CHROMATOGRAPH,
GAS OR LIQUID
CHROMATOGRAPH PROCESS; FOR CUSTODY TRANSFER CHROMOTOGRAPHY,34-
SAMSS-511
6000009898
307
Instrumentation and
IT
(Custody
Measurement)
CUSTODY FLOW COMPUTER,
LIQUID, PANEL-MNT
COMPUTER FLOW; CUSTODY TRANSFER LIQUID TYPE,CUSTODY TRANSFER LIQUID
6000009899
308
Instrumentation and
IT
(Custody
Measurement)
GAS, PANEL-MNTD
COMPUTER FLOW; CUSTODY TRANSFER GAS TYPE,CUSTODY TRANSFER GAS
6000009900
309
Instrumentation and
IT
(Custody
Measurement)
LIQUID, FIELD-MNT
COMPUTER FLOW; CUSTODY TRANSFER LIQUID TYPE,CUSTODY TRANSFER LIQUID
6000009901
310
Instrumentation and
IT
(Custody
Measurement)
GAS, FIELD MOUNTD
COMPUTER FLOW; CUSTODY TRANSFER GAS TYPE,CUSTODY TRANSFER GAS
6000009902
311
Instrumentation and
IT
CUSTODY PRESET CONTROLLER,
TRUCK LOADING
COMPUTER FLOW; CUSTODY PRESET CONTROLLER TYPE,34-SAMSS-847,FOR
TRUCK LOADING SYSTEMS
6000009906
312
Instrumentation and
IT
CUSTODY PRESET CONTROLLER
TRUCK UNLOADNG
COMPUTER FLOW; CUSTODY PRESET CONTROLLER TYPE,34-SAMSS-847,FOR
TRUCK UNLOADING SYSTEMS
6000009907

Material Number
9COM/9CAT
313
Instrumentation and
IT
Custody Tank Gauge, Radar
GAUGE TANK LEVEL; 34-SAMSS-321,CUSTODY TANK GAUGE, RADAR TYPE
6000009908
314
Instrumentation and
IT
Custody Tank Management
System, Radar
COMPUTER; FOR CUSTODY TRANSFER,34-SAMSS-321,CUSTODY TANK
MANAGEMENT SYSTEM, RADAR
6000009909
315
Instrumentation and
IT
(Custody Transfer
Measurement
Equipment)
CUSTODY WEIGH SCALE
SCALE WEIGH; CUSTODY TRANSFER TYPE,CUSTODY TRANSFER
6000009910
316
Instrumentation and
IT
(Communication,
Radio Equipment)
TETRA HANDHELD RADIO&DEVIS
FOR CLASSIFID
DEVICE; TETRA HANDHELD RADIO AND DEVICES FOR CLASSIFIED AREA
TYPE,TETRA HANDHELD RADIOS & TETRA DEVICES USED IN HAZARDOUS OR
CLASSIFIED AREAS SUCH AS OIL & GAS PLANTS, REFINERIES, PIPELINES, ETC
6000010102
317
Instrumentation and
IT
(Multivariable
Instrumentation)
POWER SUPPLIES,FOUNDATION
FIELDBUS (FF)
POWER SUPPLY; FOUNDATION FIELDBUS (FF) TYPE,FOR USE WITH FOUNDATION
FIELD-BUS INSTRUMENTS ONLY
6000010825
318
Instrumentation and
IT
(Valves, Relief/Safety
& Busting Disks)
VALVE, RELIEF; SURGE PILOT
OPERATED
VALVE RELIEF; SAES-J-605,SURGE PILOT OPERATED TYPE.FACTORYTESTING IS
REQUIRED FOR COMPLEX RATE-OF-RISE OR MODULATINGVALVES.
6000012803
319
Instrumentation and
IT
(Temperature
Instrumentation)
Multiplexer; Foundation Fieldbus
(FF)
MULTIPLEXER; FOUNDATION FIELDBUS (FF) TYPE,SAES-J-904,AA MULTI-INPUT
TEMPERATURE
6000013000
320
Instrumentation and
IT
(Monitoring Eqpt
(Vibration, etc))
CABINETS FOR VIBRATION
MONITORING SYS
CABINET; SAMSS-820 SAMSS-820,CABINETS FOR VIBRATION CABINETS FOR
VIBRATION MONITORING SYSTEMS (VMS MONITORING SYSTEMS (VMS
INTEGRATION) INTEGRATION) MONITOR; SAMSS-820 SAMSS-820,CABINETS FOR
VIBRATION CABINETS FOR VIBRATION MONITORING SYSTEMS (VMS
MONITORING SYSTEMS (VMS INTEGRATION) INTEGRATION)
6000013781
321
Instrumentation and
IT
(Custody
Measurement)
CUSTODY TANK GAUGING
SYSTEM, RADAR
GAUGE TANK LEVEL; SAES-Y-301,34-SAMSS-321
6000014614
322
Instrumentation and
IT
(Communications)
CABLE: SUBMARINE FIBER OPTIC
CABLE; SUBMARINE FIBER OPTIC CABLE TYPE,STAND-ALONE SUBMARINE FIBER
OPTICAL CABLE,18-SAMSS-006 6000014631

Material Number
9COM/9CAT
323
Instrumentation and
IT
(Instrumentation)
ANALYZERS,GAS
CHROMATOGRAPH; FIELD
MOUNT
ANALYZER; GAS CHROMATOGRAPH TYPE,34-SAMSS-511,IR343200,FIELD
MOUNTED 6000014780
324
Instrumentation and
IT
(DCS, ESD & Plant
Control Systems)
REAL-TIME TRANSIENT MODEL
PLDS
DETECTOR LEAK; RTTM METHODS TYPE,FOR PIPELINE,SAES-Z-003,SYSTEMS USE
MATHEMATICAL MODELS OF THE FLOW WITHIN A PIPELINE TO DETECT THE LEAK
6000014890
325
Instrumentation and
IT
(DCS, ESD & Plant
Control Systems)
ACOUSTIC PRESSURE WAVES
PLDS
DETECTOR LEAK; ACOUSTIC PRESSURE WAVES TYPE,FOR PIPELINE,SAES-Z-003,THE
ACOUSTIC PRESSURE WAVE METHOD ANALYSES THE RAREFACTION WAVES
PRODUCED WHEN A LEAK OCCURS.
6000014891
326
Instrumentation and
IT
(DCS, ESD & Plant
Control Systems)
BALANCING METHODS PRINCIPLE
PLDS
DETECTOR LEAK; BALANCING METHODS TYPE,FOR PIPELINE,SAES-Z-003,THESE
METHODS BASE ON THE PRINCIPLE OF CONSERVATION OF MASS
6000014892
327 Pipe & OCTG COUPLING: OCTG; HIGH NICKEL
COUPLING OCTG; HIGH NICKEL ALLOY STAINLESS STEEL,SEAMLESS,API-5CT,ISO-
13680,GR UNS N08020 OR EQUIVALENT,PREMIUM THREAD END CONN,COLLAPSE
TEST PER API WITH ONE SAMPLE TESTED PER 200 JOINTS OF MOTHER TUBE
6000007293
328 Pipe & OCTG
CASING: OCTG; HIGH NICKEL;
SEAMLESS
CASING OCTG; HIGH NICKEL ALLOY STAINLESS STEEL,SEAMLESS,API-5CT,ISO-
13680,GR UNS N08028 OR EQUIVALENT,PREMIUM THREAD END CONN,
COLLAPSE TEST PER API WITH ONE SAMPLE TESTED PER 200 JOINTS
6000007303
329 Pipe & OCTG CROSSOVER: OCTG; HIGH NICKEL
CROSSOVER; OCTG, HIGH NICKEL ALLOY STAINLESS STEEL,SEAMLESS
TYPE,PREMIUM THREAD TERMINAL,API-5CT, ISO-13680,COLLAPSE TEST PER API
WITH ONE SAMPLE TESTED PER 200 JOINTS OF MOTHER TUBE, GR UNS N08020
OR EQUIVALENT
6000007305
330 Pipe & OCTG
PUP JOINT: CASING OCSG; HIGH
NICKEL
PUP JOINT OCTG; HIGH NICKEL ALLOY STAINLESS STEEL,SEAMLESS,API-5CT,ISO-
13680,GR UNS N08028 OR EQUIVALENT,PREMIUM THREAD END CONN,COLLAPSE
TEST PER API WITH ONE SAMPLE TESTED PER 200 JOINTS OF MOTHER TUBE
6000007307
331 Pipe & OCTG
TUBING: OCTG; HIGH NICKEL;
SEAMLESS
TUBING OCTG; HIGH NICKEL ALLOY STAINLESS STEEL,SEAMLESS,API-5CT,ISO-
13680,PREMIUM THREAD END CONN,COLLAPSE TEST PER API WITH ONE SAMPLE
TESTED PER 200 JOINTS OF MOTHER TUBE, UNS N08028
6000007350
332 Pipe & OCTG
PUP JOINT: TUBING OCTG; HIGH
NICKEL
PUP JOINT OCTG; HIGH NICKEL ALLOY STAINLESS STEEL, TUBING,SEAMLESS,API-
5CT,ISO-13680,GR UNS N08028,PREMIUM THREAD END CONN,COLLAPSE TEST
PER API WITH SAMPLE TESTED PER 200 JOINTS OF MOTHER TUBE,
6000007352

Material Number
9COM/9CAT
333
Pipe & OCTG
(OCTG)
COLLAR: DRILL; STANDARD
DRILL; SPIRAL/ SLICK TYPE,SIZE "3-1/8"" - 11"" OD",31 FEET LG,AISI 4145 H
MODIFIED,API-7
6000003831
334 Pipe & OCTG
TUBING: OCTG; API GR;
SEAMLESS
TUBING OCTG; STEEL,SEAMLESS,API-5C2,API-5B 45-SAMSS-006
6000003877
335
Pipe & OCTG
(OCTG)
CASING: OCTG; API GR; ERW
CASING OCTG; STEEL,ERW OR SEAMLESS,AA 45-SAMSS-006,API-5L,SIZE 24 IN
6000003851
336
Pipe & OCTG
(OCTG)
CASING: OCTG; API GR; SAW
CASING OCTG; STEEL,SAW,45-SAMSS-006,API-5L,SIZE 26 IN. AND LARGER
6000003855
337
Pipe & OCTG
(Pipe)
HEADER: PIPE; EXTRUDED OR
REINFORCED
HEADER PIPE; EXRUDED OR REINFORCED BRANCHES,ANY APPLICATION,ANY
APPLICATION
6000000060
338
Pipe & OCTG
(Pipe)
PIPE: METALLIC, WELD
OVERLAYED PIPE
PIPE METALLIC; CARBON STEEL,OVERLAYED WITH CORROSION RESISTANT
ALLOY,01-SAMSS-048, API 5LD
6000014017
339
Pipe & OCTG
(Pipe)
CUNI PIPE, EEMUA 144
PIPE; CUNI, EEMUA 144 TYPE
6000014200
340
Pipe & OCTG
(Pipe)
PIPE;METALLIC; HFW CLASS C
FOR SOUR GAS
PIPE METALLIC; ALL SIZE NPS,STEEL,GR B THRU X-65,HFW,API 5L,01-SAMSS-
333,CLASS C,FOR SOUR GAS SERVICE ONSHORE
6000000046
341
Pipe & OCTG
(Pipe)
PIPE: METALLIC, LINED PIPE
PIPE METALLIC; CARBON STEEL,LINED WITH CORROSION RESISTANT ALLOY,01-
SAMSS-048, API 5LD
6000014016
342 Pipe & OCTG
PIPE; METALLIC; HFW CLASS B
FOR NON SOUR
PIPE METALLIC; ALL SIZE NPS,STEEL,GR GRADE B THRU X70,HFW,API 5L,01-SAMSS-
333,CLASS B,NON SOUR SERVICE
6000000049
343
Pipe & OCTG
(Pipe)
Pipe; Nonmetallic, Subsea
flexible
PIPE METALLIC; PA,PE & PVDF,FLEXIBLE PIPE,LINER AND OUTER SHEATHING,API
17J
6000000037
344 Pipe & OCTG
PIPE & FITTINGS;
THERMOPLASTIC;
PIPE NON-METALLIC; 1300 MM TO 3600 MM NPS,AA STRUCTURED
WALL,THERMOPLASTIC, HDPE, PVC, PP,FOR WATER, GRAVITY,DIN
16961,SEWERAGE, STORM WATER DRAIN, SEAWATER INTAKE AND OUTFALL
6000011205
345
Pipe & OCTG
(Pipe)
UMBILICAL SYS, SUBSEA,
OFFSHORE, NONMETA
PIPE NON-METALLIC; 15-SAMSS-503,15-SAMSS-504 ISO 13628,UMBILICALSYSTEM
IS AN INTEGRATED BUNDLE OF TUBES, HOSES, POWER CABLESAND/OR FIBER
OPTICS ENCLOSED WITH AN OUTER RING SPECIALLYDESIGNED FOR THE SUBSEA
ENVIRONMENT TO WHICH IT WILL BE DEPLOYED.
6000014895
346 Pipe & OCTG Pipe; Nonmetallic, (RTP) PIPE
PIPE NON-METALLIC; MAXIMUM 8 INCHES NPS,REINFORCED THERMOPLASTIC
(RTP),INTERNAL / EXTERNAL LINING THERMOPLASTIC(PE,PE- RT, PP
PA,PVDF,PREFABRICATED SPOOL ENDS,FOR WATER AND HYDROCARBON
APPLICATIONS MAX TEMP 180 F,API RP 15S FOR FIBER,REINFO 17J FOR STEEL
REINFORCED,ONSHORE / OFFSHORE WATER AND HYDROCARBON APPLICATIONS.
6000000042
347 Pipe & OCTG GRATING; FIBERGLASS GRATING FIBERGLASS; AB 12-SAMSS-021 AND 12-SAMSS-0 6000000631

Material Number
9COM/9CAT
348
Pipe & OCTG
(Pipe)
PIPE&FITTINGS;NON-METAL;RTR
PIPE NON-METALLIC; MAXIMUM 30 IN. NPS,PER CALCULATION,REINFORCED
THERMOSETTING RESIN,REINFORCED THERMOSETTING RESIN,FOR WATER (NON-
UTILITY) AND HYDROCARBON APPLICATIONS MAX TEMP 210 F,01-SAMSS-042,API
RP 15HR API RP 15LR,FOR PIPE AND FITTINGS
6000013160
349 Pipe & OCTG
Grating; Offshore; Fire
Retardant; Non-M
GRATING; FIRE RETARDANT TYPE,PULTRUDED PHENOLIC RESIN,12-SAMSS-
023,NONMETALLIC FIBER-REINFORCED COMPOSITE PLATFORMS. ASTM E84
RESOLUTION A653 (16) D635 M M D2863. SHORE 94
6000007813
350
Pipe & OCTG
(Pipe)
PIPE; NON-METAL; LINED PIPING
SYSTEMS
PIPE NON-METALLIC; UP TO 20 NPS,300 PSIG MAX
SUPPLY,CARBONSTEEL,THERMOPLASTIC LINED PIPING SYSTEMS,FOR CORROSIVE
FLUIDS,ACIDS, ALKALINE,CHEMICAL SOLUTIONS OR OILY DRAINS,01-SAMSS-025
6000013900
351 Pipe & OCTG
PIPE, NON-METALLIC, ALL SIZES,
FOR WATER
PIPE NON-METALLIC; ALL SIZES NPS,POLYPROPYLENE,ASTM F2389,FOR WATER
DISTRBUTION SYSTEMS
6000009750
352
Pipe & OCTG
(Pipe)
Service: Pre-Engineered
Composite Repair
SERVICE; PRE-ENGINEERED THERMOSET FIBER REINFORCED
COMPOSITETYPE,SAEP-345,ASME-PCC2 ISO 24817,LIMITED TO PIPELINE FOR
WATER,HYDROCARBON, AND CHEMICALS APPLICATIONS. SUITABLE FOR
PIPELINESWITH EXTERNAL CORROSION UP TO 80 PERCENT METAL LOSS. FOR
SABKHAAREA APPLICATIONS, AN EXTERNAL WATER PROTECTION LAYER SHALL
BEADDED ON THE SLEEVE. NOT APPLICABLE FOR FITTINGS SUCH AS ELBOW,TEE,
REDUCER#.ETC. FOR PLANT PIPING, IT SHALL BE UTILIZED AS ATEMPORARY
REPAIR WITH A PRIOR APPROVAL FROM NONMETALLIC SCC.
6000014191
353
Pipe & OCTG
(Pipe)
SERVICE: WET -TYPE COMPOSITE
REPAIR EXT.
SERVICE; WET-TYPE THERMOSET COMPOSITE FIBER REINFORCED
OMPOSITE.TYPE,SAEP-345,ASME-PCC2 ISO 24817,USE FOR WATER,
HYDROCARBON,CHEMICALS PLANT PIPING AND PIPELINES. SUITABLE FOR
EXTERNALCORROSION UP TO 80 PERCENT METAL LOSS. FOR PLANT PIPING
ANDFITTINGS, IT SHALL BE UTILIZED AS A TEMPORARY REPAIR WITH APRIOR
APPROVAL FROM NONMETALLIC SCC.
6000014681
354 Pipe & OCTG
SERVICE: WET-TYPE; COMPOSITE
REPAIR, INT
SERVICE; WET-TYPE THERMOSET COMPOSITE FIBER REINFORCED TYPE,SAEP-
345,ASME-PCC2 ISO 24817,USE FOR WATER, HYDROCARBON, CHEMICALS PLANT
PIPING AND PIPELINES. SUITABLE FOR INTERNAL CORROSION UP TO 80 PERCENT
METAL LOSS PROVIDED THAT CORROSION SOURCE IS MITIGATED. FOR PLANT
PIPING AND FITTINGS, IT SHALL BE UTILIZED AS A TEMPORARY REPAIR WITH A
PRIOR APPROVAL FROM NONMETALLIC SCC.
6000015710

Material Number
9COM/9CAT
355 Pipe & OCTG
PIPE; NONMETALLIC; CPVC; FOR
FIRE SPRINK
PIPE; PIPE, ANY SIZE TYPE,CHLORINATED POLY VINYL CHLORIDE (CPVC),UL OR
EQUIVALENT CERTIFIED FOR FIRE SPRINKLER SYSTEMS STANDARDS: UL 1887, UL
1821 ASTM D1784, ASTM F442, UL LISTED ADHESIVE, ASTM F493, ASTM F656
6000016271
356
Drilling Equipment
(Downhole
Equipment)
KIT,9-5/8",VALVE+GRV
PACKER+SEAL+MFIV
VALVE; MECHANICAL FORMATION ISOLATION TYPE,SIZE 9-5/8 IN,5000PSI
(DIFFERENTIAL PRESSURE) SUPPLY,4140 L-80 BODY,4140 L-80TRIM, 4.562" ID X
8.000" OD (3 FT) EXTENSION, 5,000 PSI BALLDIFFERENTIAL PRESSURE RATING,
300 DEG. F TEMPERATURE RATING,5-1/2" 17 PPF NEW VAM BOX X PIN, AND 106"
OVERALL LENGTH, 1.COMPLETE ASSEMBLY WITH ITEMS AS DESCRIBED IN KITS
SECTION MUSTBE BOXED AS AN INDIVIDUAL UNIT FOR SHIPMENT AND STORAGE
PERSAUDI ARAMCO PACKAGING SPEC 844418. 2. MANUFACTURER MUST
BARCODE IDENTIFY EACH ISSUE UNIT ON BOTH THE MATERIAL AND OUTSIDETHE
CONTAINER IN WHICH THE ISSUE UNIT IS CONTAINED. CODE TO BEIN THE
INTERNATIONAL CODE 39 BAR CODING SYSTEM FORMAT AND ADHERETO ANSI
MH10.8 ( LATEST EDITION) SPECIFICATION (LESS SECTIONS 12& 13). BAR CODE
TAG MUST INCLUDE THE SAUDI ARAMCO STOCK NUMBERAND PURCHASE ORDER
NUMBER. ALL ITEMS SHOULD BE ASSEMBLEDTOGETHER PRIOR TO TESTING.KITS
COMPONENTS
1000809798
357
Drilling Equipment
(Downhole
Equipment)
PACKER,ECP,4-
1/2X6.1,NVAM,12.6#,MPAS,MEC
PACKER; MPAS KIT TYPE,4-1/2 IN, FOR 6-1/8 IN OHCONSIST OF:ITEM QUANTITY
DESCRIPTION01 01 Baker M-Pas Mech. External CasingPackerwith bottom
subSize: 4-1/2 IN. 11.6lb/ftThread connection: 4-1/2IN. 12.6# NewVamBox X
BoxElement O.D.: 5.625 IN.Tool I.D.: 3.500 IN.Material: L-80PART# H30158450802
01 Baker Lift Nipples for Mpas PackersSize: 4-1/2 in. 11.6lb/ft, 6 feet longThread
Connection: New Vam Box X PinTool O.D.: 5.000 IN.Tool I.D.: 3.950 IN.Material: L-
80PART# H494079210
1000750621
358
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,9-
5/8X14",VAM21,53.5#,CRA,MDS
K
LINER; TOP PACKER ASSEMBLY TYPE,SIZE 9-5/8 IN 53.5 PPF X 14 IN114
PPF,#CONNECTION : VAM 21.KIT COMPONENTS 1000835538
359
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,VTHC,13.5#CRMO,HYD
PACKER: PRODUCTION, 5.687 IN OD, 3.720IN ID, FOR 7 IN, 32-35 LB/FT
CASINGPACKER PRODUCTION; "S-3" 1-TRIP HYDRO-SET COMP . PACKER
TYPE,FORH2S, CO2,WIRELINE OR HYDRAULIC SET ACTIVATI,5.879 IN OD,3.720
INID,7.000 IN OD,32-35 LB/FT,4-1/2 IN CONNECTN,13.5 LB/FT,VAM TOPHC PIN X
PIN COONECTN,10000 PSI SUPPLY,NACE MR-01-75,MATERIAL:PACKER: 125 KSI
MYS CR-MO LOW ALLOY STEEL PACKING ELEMENT: BPSAFLAS O-RINGS: BPS
AFLAS. TEMPERATURE RATING: 150-350 DEG F.KITS COMPONENTS
1000025107

Material Number
9COM/9CAT
360
Drilling Equipment
(Downhole
Equipment)
VALVE,ICV,3-
1/2",EUE,CRA,7.5K,FCV-002
VALVE; TUBING RETRIEVABLE FLOW CONTROL-HYDRAULIC TYPE,SIZE 3-1/2IN,3-
1/2 IN 9.3 PPF EUE BOX X PIN END CONN,INC718 BODY,INC718,9CR-1MO,
4140/4130 TRIM,EXTERNAL WORKING PRESSUR: 7500 PSI,INTERNAL DIA.: 2.812
IN MIN, DRIFT ID: 2.808 IN, LENGTH: 219 IN,MAX FLOW RATE: 40000 BBL/DAY,
MAX WORKING TEMP.: 325°F, MINWORKING TEMP.: 40°F, MAJOR OD: 5.850 IN,
SEAL BORE SIZE: 2.812IN, NO. OF BYPASS CONTROL LINES: 4. THE TUBING
RETRIEVABLE FLOWCONTROLLER SYSTEM MUST PROVIDE REMOTELY ACTUATED
DOWNHOLECONTROL OF FLOW FROM THE RESERVOIR. THE SYSTEM MUST BE
OPERATEDBY A 0.25-IN HYDRAULIC CONTROL LINE THAT IS ROUTED FROM
THESURFACE CONTROLS TO THE CHOKE SECTION OF THE TOOL.
1000782175
361
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,4-
1/2X7",NVAM,12.6#,CEMENTED
LINER; CEMENTED, KIT TYPE,4-1/2 IN BOTTOM CEMENTING KIT. FOR 7IN 26 #
CASING AND 6-1/8 IN OPEN HOLECONSIST OF:ITEM QUANTITY DESCRIPTION01 01
Baker #PBR# Style Locator SealAssemblySize: 5.250 IN. X 4-1/2 IN. 11.6lb/ftThread
connection: New Vam Box Up x ½MulshoeLength: 10ft effective Seal
StrokeMaterial: L-80PART# H29755079802 01 Baker Hyflo III Liner Top PackerSize:
5 IN. 18b/ft X 7 IN. 23-29Lb/ftThread: 5 IN. 18lb/ft New Vam Box DownMaterial: L-
80Extension ID: 5-1/4 IN.Tool OD: 6.050 IN.Tool ID: 4.276 IN.Extension Length: 10
feetPART# H29618006603 01 Model #HMC# Liner HangerSize: 4-1/2 IN. X 7 IN. 23-
26#/ftMaterial: BMS # A099Threads: 4-1/2 IN. 12.6#/FT New VamMinimum ID:
4.000 IN.Max OD: 6.000 IN.PART# H292230110Including following items:Flapper
Valve Assembly/Cross OverPART# H282050540Plug Holder BushingPART#
H299940415ITEM QUATITY DESCRIPTION04 01 Baker#PAC# ValveSize: 4-1/2IN. X
12.6 ppfThread: New VamMaterial: L-80Pressure: Field Adjustable, 2000-
3500Temp. Rating: 325 deg.PART# H30112240805 02 Baker #Isozone# External
Casing PackerWith Standard ValveSize: 4-1/2 IN. 12.6 lb/ft.Thread Connection: 4-
1/2 IN. 12.6# NewVam Box X PinElement O.D.: 5.625 IN.Tool I.D.: 3.821
IN.Material: L-80Elastomer Length: 7 ft.PART# H30139241606 01 Baker Landing
CollarSize: 4-1/2 IN. X 12.6 ppfThread: New VamMaterial: L-80O.D.: 4.891 IN.I.D.:
3.937 IN.Seat I.D.: 1.500 IN.PART# H26679007307 01 Liner Wiper plug for PAC
valveNitrile, 4.500 IN. OD 9.500-11.60lb/ftCasing, 4.125 IN.SHAER TAB, 3.678
IN.Stabilizer OD. 1.641 IN. tool IDF/1.812PART# H26932002208 01 Baker Pump
Down PlugSize: 1.844 IN. Nose O.D.Material: NitrileO.D.: 5.130 IN.Max Csg I.D.:
2.00 IN.Max Pressure: 3000 psi @ 350 deg. FPART# H270200056
1000750589

Material Number
9COM/9CAT
362
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,VTHC,32#,110,HYD
HANGER LINER; HYDRAULIC CONTROL SET FLEX-LOCK TYPE IIIACTIVATI,7 IN END
1,32 PPF END 1,9-5/8 IN END 2,47-58.4 PPF END2,VAM TOP HC PIN X PIN END
CONN,CONTROL SET FLEX-LOK LINERHANGER WITH ZXP TOP PACKER
ASSEMBLY.KIT COMPONENTS
1000889169
363
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,4-
1/2,NVAM,12.6#,250MC,SNDST
SCREEN; RESFLOW INFLOW CONTROL DEVICE (ICD) TYPE,SIZE 4-1/2 IN X40 FT
LG,SS316L,FOR STANDSTONE INSTALLATION, BASE PIPE MATERIAL:L-80, PIPE SIZE:
4-1/2 IN, 12.6 LB/FT, THREAD CONNECTION: NEWVAM, WEIGHT: 17.57 LB/FT,
DISPLACEMENT: 0.35 GAL/FT, AXIAL RODPROFILE: 4.0 X 3.0 MM, NO. OF RODS:
28, WRAP WIRE PROFILE: 4.0 X3.0 MM, SCREEN (WRAPPED) INFLOW AREA:
7.69%, SLOT OPENING: 250MICRONS/0.010 IN, CENTRALIZER PER LOCATION:
ONE/JT @ PIN END,NO. OF STOP COLLARS: TWO/CENTRALIZERS, NOZZLE
DIAMETER: 4 MM,NUMBER OF NOZZLES: 4 PER JOINT.
1000778420
364
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,VTHC,32#,718,HYD
HANGER LINER; 7 IN END 1,32 PPF END 1,9-5/8 IN END 2,53.5-58.4 PPF END
2,CORROSION RESISTANT ALLOY MATERIAL, SYSTEM INCLUDES 1/2 IN MULE-
SHOE, WIRELINE ENTRY GUIDE KIT COMPONENTS
1000815460
365
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,NVAM,12.6#,ALLOY,RET
PACKER PRODUCTION; VHR, HYDRAULIC SET RETRIEVABLE TYPE,FOR
H2S,CO2,HYDRAULIC SET ACTIVATI,6.000 IN MAX OD,3.880 IN MIN ID,7 INOD,23-
29 LB/FT,5.250-6RTH-LTH LEFT HAND (TOP) X 4-1/2 IN 12.6#NEW VAM BOX
(BOTTOM) CONNECTN,12.6 LB/FT (BOTTOM),LEFT-HAND(TOP), NEW VAM BOX
(DOWN) COONECTN,6,000 PSI SUPPLY,NACEMR0175,AFLAS ELEMENT AND
VITON/AFLAS O-RINGSKIT COMPONENTS
1000764262
366
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,4-
1/2,NVAM,11.6#,0.014,SNDST
LG,SS 316L,FOR SANDSTONE INSTALLATION, BASE PIPE MAT'L:L-80, PIPE SIZE: 4-
1/2 IN 11.6 LB/FT, THREAD CONNECTION: NEWVAM, WEIGHT: 15.46 LB/FT,
DISPLACEMENT: 0.31 GAL/FT, AXIAL RODPROFILE: 6.2 X 3.2 MM, NO OF RODS: 28,
WRAP WIRE PROFILE: 4.0 X3.0 MM, SCREEN (WRAPPED) INFLOW AREA: 10.45%,
SLOT OPENING: 350MICRONS/0.014 IN, CENTRALIZER PER LOCATRION: ONE/JT @
PIN END,NO OF STOP COLLARS: TWO/CENTRALIZERS, NOZZLE DIA: 4MM, NO
OFNOZZLES: 4 PER JOINT
1000790538
367
Drilling Equipment
(Downhole
Equipment)
KIT,FRAC,4-
1/2X5.875"OH,VTHC,13.5#,PK-SL
PACKER PRODUCTION; STAGE FRAC SET UP ASSEMBLY TYPE,5.625 INOD,3.375 IN
ID,7 IN OD,32-35 LB/FT,4-1/2 IN CONNECTN,13.5LB/FT,VAM TOP HC BOX X PIN
COONECTN,10,000 PSI WORKING PRESSURESUPPLY,OPEN HOLE SIZE: 5-7/8 IN,
MATERIAL: P-110.KITS COMPONENTS:
1000835551

Material Number
9COM/9CAT
368
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,5-
1/2,NVAM,17#,350MC,SNDST
SCREEN; RESFLOW INFLOW CONTROL DEVICE (ICD) TYPE,SIZE 5-1/2 IN X 40 FT
LG,SS316,FOR SANDSTONE INSTALLATION, BASE PIPE MATERIAL: L-80, PIPE SIZE:
5-1/2 IN 17.0 LB/FT, THREAD CONNECTION: NEW VAM, WEIGHT: 21.78 LB/FT,
DISPLACEMENT: 0.42 GAL/FT, AXIAL ROD PROFILE: 4.0 X 3.0 MM, NO OF RODS:
32, WRAP WIRE PROFILE: 4.0 X 3.0 MM, SCREEN (WRAPPED) INFLOW AREA:
9.78%, SLOT OPENING: 350 MICRONS/0.009 IN, CENTRALIZER PER LOCATION:
ONE/JT @ PIN END, NO OF STOP COLLARS: TWO/CENTRALIZERS, NOZZLE
DIAMETER: 4 MM, NO OF NOZZLES: 4 PER JOINT
1000788091
369
Drilling Equipment
(Downhole
Equipment)
PIPE,5-1/2",XPC,18.24#,EX-
80,37FT,EXPAND
JOINT; SOLID EXPANDABLE LINER TYPE,SIZE 5-1/2 IN 18.24 PPF X 7 IN 26 PPF,EX-
80,COUPLED WITH CONNECTION SLEEVE, CONNECTION: ENVENTURE
PROPRIETARY XPC PIN X BOX LH, LENGTH: 37 FT
1000819339
370
Drilling Equipment
(Downhole
Equipment)
CONNECTOR,HYD,4-1/2,WET
MATE,2PORT,HNBR
ELEMENT; HYDRAULIC LINE TYPE,SIZE 4-1/2 IN,4140 (L-80),WET MATECONNECT
SYSTEMKITS COMPONENTS 4-1/2 IN HYDRAULIC LINE WET MATECONNECT
SYSTEM CONSISTS OF:ITEM QTY DESCRIPTION01 01 4-1/2" x 9-5/8" HLWM
RECEPTACLE ASSEMBLYMATERIAL: 4140GRADE: L-80WEGHT (APPROX): 600
LBSEXT. WP @ TEMP: 6000 PSI @ 250 DEG FID: 3.958 INID (MIN): 3.943 ININT.
WP @ TEMP: 6000 PSI @ 250 DEG FLOWER THREAD: 4.5-8RD,12.2 PPF, EUE,
PINMAKEUP LENGTH: NAMATERIAL/ELASTOMERS: HNBRMAX. WORKING TEMP:
250 DEG FMIN. WORKING TEMP: 40 DEG FOD: 8.369 INOD (MAX): 8.379
INOVERALL LENGTH: 72 INSERVICE NACE: NOTENSILE STRENGTH: 250,000 LBS @
250 DEG FUPPER THREAD: NAPART NUMBER: 10051791AB02 01 4-1/2" x 9-5/8"
STINGER ASSEMBLYMATERIAL: 4140GRADE: L-80WEGHT (APPROX): 500 LBSEXT.
WP @ TEMP: 6000 PSI @ 250 DEG FID: 3.750 INID (MIN): 3.745 ININT. WP @
TEMP: 6000 PSI @ 250 DEG FLOWER THREAD: NAMAKEUP LENGTH:
NAMATERIAL/ELASTOMERS: HNBRMAX. WORKING TEMP: 250 DEG FMIN.
WORKING TEMP: 60 DEG FOD: 8.369 INOD (MAX): 8.379 INOVERALL LENGTH: 135
INSERVICE NACE: NOTENSILE STRENGTH: 250,000 LBS @ 250 DEG FUPPER
THREAD: 4.5-8RD, 12.2 PPF,EUE, BOX.PART NUMBER: 10051785AB
1000839903

Material Number
9COM/9CAT
371
Drilling Equipment
(Downhole
Equipment)
KIT,7",VALVE+GRV
PACKER+SEAL+MFIV
VALVE; MECHANICAL FORMATION ISOLATION TYPE,SIZE 7 IN,5000
PSI(DIFFERENTIAL PRESSURE) SUPPLY,4140 L-80 BODY,4140 L-80TRIM,2.940" ID X
5.500" OD (3 FT) EXTENSION, 5,000 PSI BALLDIFFERENTIAL PRESSURE RATING,
300 DEG. F TEMPERATURE RATING,4-1/2" 13.5 PPF NEW VAM BOX X PIN, AND
106" OVERALL LENGTH, 1.COMPLETE ASSEMBLY WITH ITEMS AS DESCRIBED IN
KITS SECTION MUSTBE BOXED AS AN INDIVIDUAL UNIT FOR SHIPMENT AND
STORAGE PERSAUDI ARAMCO PACKAGING SPEC 844418. 2. MANUFACTURER
MUST BARCODE IDENTIFY EACH ISSUE UNIT ON BOTH THE MATERIAL AND
OUTSIDETHE CONTAINER IN WHICH THE ISSUE UNIT IS CONTAINED. CODE TO
BEIN THE INTERNATIONAL CODE 39 BAR CODING SYSTEM FORMAT AND
ADHERETO ANSI MH10.8 ( LATEST EDITION) SPECIFICATION (LESS SECTIONS 12&
13). BAR CODE TAG MUST INCLUDE THE SAUDI ARAMCO STOCK NUMBERAND
PURCHASE ORDER NUMBER. ALL ITEMS SHOULD BE ASSEMBLEDTOGETHER PRIOR
TO TESTING.KITS COMPONENTS
1000809797
372
Drilling Equipment
(Downhole
Equipment)
PIPE,16",XPC,75#,LSX80,ERW,37F
T,EXPN,SES
UNIT; EXPANDABLE, SOLID, ERW TYPE,COMPLETE ASSEMBLY MUST BEBOXED AS
AN INDIVIDUAL UNIT FOR SHIPMNET AND STORAGE.MANUFACTURER MUST BAR
CODE IDENTIFY EACH ISSUE UNIT ON BOTH THEMATERIAL AND OUTSIDE THE
CONTAINER IN WHICH THE ISSUE UNIT ISCONTAINED. CODE TO BE IN THE
INTERNATIONAL CODE 39 BAR CODINGSYSTEM FORMAT AND ADHERE TO ANSI
NH10.8M (LATEST EDITION)SPECIFICATION (LESS SECTIONS 12 & 13) BAR CODE
MUST INDLUDE THESAUDI ARAMCO STOCK NUMBER AND PURCHASE ORDER
NUMBER, PACKAGINGSPEC 844418 APPLIES.KITS COMPONENTS
1000840031
373
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,4-
SCREEN; FLOREG INFLOW CONTROL DEVICE (ICD) TYPE,SIZE 4-1/2 IN XR3,L-
80,FOR SANDSTONE INSTALLATION, SIZE: 4-1/2 IN 11.6 LB/FT,THREAD
CONNECTION: NEW VAM BOX X PIN, FILTER: CSM IN SS 316,JACKET LENGTH: 16
FT (SINGLE MODULE), MAX OD: 5.400 IN, MIN. ID:3.958 IN,
1000794601
374
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,4-
1/2",NVAM,9CR1MO,TRSV,5K
VALVE; SAFETY, TUBING-RETRIEVABLE, FLAPPER CLOSURE TYPE,SIZE 4-1/2
IN,5000 PSI SUPPLY,4-1/2-12.60 VAM-NEW, BOX-PIN END CONN,9CR-1MO/410
STAINLESS STEEL /NICKEL ALLOY 925 MATL BODY,API 14A,API CLASS 1 3S,NACE
MR0175 NACE MR-01-75,API-14A NACE MR-01-75/,ISO 1515 API
MONOGRAMMED,MAX. OD 6.73 IN, MIN ID 3.813 IN, OA LENGTH 57.16 IN, X
LOCK PROFILE, 1650 PSI MAX FULL OPEN PRESSURE, 600 PSI MIN CLOSING
PRESSURE, 20-300 DEG F TEMP RATING
1000744611

Material Number
9COM/9CAT
375
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,4-
1/2X5.60",VTHC,13.5#,110
PACKER; SWELLABLE, ISOLATION TYPE,PACKER TYPE: SWELLPACKER OS H2S.
PACKER DIMENSIONS: 4.5 IN X 5.60 IN X 9 M. DELAY SYSTEM: 6 A. SWELL
MEDIUM: OILSWELLING. TEMPERATURE UP TO 392 DEG F. TOTAL LENGTH: 40 FT.
MIN HANDLING SPACE PIN END: 2 FT. MIN HANDLING SPACE BOX END: 6 FT.
PACKER ELEMENT LENGTH: 30 FT. BASE PIPE OD: 4.5 IN. PACKER ELEMENT OD:
5.6 IN. END-RING OD: 5.6 IN. BASE PIPE WEIGHT: 13.5 PPF. BASE PIPE MATERIAL:
P-110. BASE PIPE NOMINAL ID: 3.920 IN. BASE PIPE DRIFT ID: 3.795 IN. THREAD
TYPE: VAM TOP HC. END RING MATERIAL: ST-52. END RING LENGTH: 4 IN.
1000908558
376
Drilling Equipment
(Downhole
Equipment)
PACKER,LINER,4-
1/2,NKS3B,13.5#,TBR 25FT
PACKER, LINER: 'ZXP' LINER TOP, (BMSA-142)41XX-HC110 MYS, HT SOUR
SERVICE,25 FT TIE-BACK, 7 IN CASING OD, 29-32PACKER LINER; 'ZXP' LINER TOP
TYPE,(BMS A-142)41XX-HC110 MYS,FORHT SOUR SERVICE,25 FT TIE-BACK,7 IN
OD,29-32 LB/FT,NK-3SB BOXDOWN COONECTN,4-1/2 IN 13.5 LB/FT BOX DOWN
CONNECTN,NACEMR-01-75 97,WITH HOLD DOWN SLIPS, HR PROFILE AND XYLAN-
1052COATED, 6 IN MIN IDKITS COMPONENTS
1000644366

Material Number
9COM/9CAT
377
Drilling Equipment
(Advanced Well
Completion
Equipment)
SCREEN,MESH,6-
5/8,SLHT,24#,250MIC
SCREEN; MESH TYPE,SIZE 6-5/8 IN,6-5/8 INCH PREMIUM SCREEN FILTERMESH
TYPES, 6.63 PREMIUM SCREEN, 250 MICRON /316L, 0-TUBE, NOCENTRALIZER,
24.0LB/FT, SLHT,37-39FT, L-80 (BLANK SPACING -PINEND (IN)24, (BASE PIPE
WEIGHT(PPF) 24.0, (HOLE SIZE /BASE PIPE(IN) 1/2,(MATERIAL /SHROUD)304,
(LENGTH FILTER (FT) 28.0,(ACTIVE FLOW WETTED MATERIAL YIELD STRENGTH
(KSI) L80(80),316L(80), 316(25), OVER ALL LENGTH (IN ) 466, LOW
THREADCONNECTING - SIZE (IN),WT(PPF), TYPE CONFIG, 6.625,24 SLHT PIN,MAX
WORKING TEMPERATURE 200 DEG F, TENSILE STRENGTH (LBS) - EOECAT
SPECIFIED TEMP (FT) 356859(80), BASE PIPE LENGTH (FT) 37-39,(OUTER SHROUD
THICKNESS (GAUGE/IN) 14/0.75, (COLLAPSE PRESSURE(PSI) 4515, OD - MAX IN
7.400, (BLANK SPACING - BOX END (IN) 72,6.625 (MATERIAL/BASE PIPE) L80,
THREAD SIZE WT.TYPE CONFIG 6.63IN 24 LB/FT, SLHT, STANDARD, OPEN AREA
BASE PIPE (%) 10, MESHSIZE (MICRON) 250, OUTER DRAINAGE LAYER (YES/NO)
NO, OUTERSHROUD TYPE 20% OPEN AREA, O.D - SHROUD (IN) 7.400, (NUMBER
OFCENTRALIZERS) 0, CENTRALIZER TYPE NA, CENTRALIZER O.D (IN) NA,FISHING
O.D. (IN) 7.400, (SHROUD O.D.) SERVICE NACE (YES/NO)NO,(BURST PRESSURE
(PSI) 1081, I.D. (IN) 5.921 I.D - MIN (IN)5.921, ID -DRIFT (IN) 5.796, MAKE-UP
LENGTH (IN) 462, UPPERTHREAD CONNECTION - SIZE (IN), WT (PPF), TYPE CONFIG
6.625, 24SLHT, BOX (MATERIAL /ELASTOMERS) NA, MIN WORKING
TEMPERATURE(DRG.F)32, EXTERNAL WORKING PRESSURE (PSI) - EOEC AT
SPECIFIEDTEMP (F) 4515(80), INTERNAL WORKING PRESSURE (PSI) - EOEC
ATSPECIFIED TEMP (F) 1081(80), APPROXIMATE WEIGHT (LBS)1223.
1000828969
378
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,4-
1/2",NVAM,CRA,5K,TRSSSV
VALVE; FLAPPER, TUBING RETRIEVABLE SUBSURFACE TYPE,SIZE 4-1/2IN,5000 PSI
SUPPLY,4-1/2 IN 12.60 NEW VAM BOX-PIN ENDCONN,9CR-1MO/410/17-
4PH/INCOLOY 925/ INCONEL 718 BODY,API14A/ISO 10432,API CLASS 1,3S API-
14A,NACE MR-01-75/ ISO 1515,APIMONOGRAMMED,MAXIMUM OD: 5.965 IN,
MINIMUM ID: 3.813 IN, SEALBORE MIN ID: 3.813 IN, LENGTH: 63.10 IN, LOCK
PROFILE: X,PRESSURE: 5000 PSI, TEMPERATURE: 20-300 DEG F, MAX. FULL
OPENPRESS.: 2000 PSI, MIN. CLOSING PRESS.: 600 PSI, PISTONDISPLACEMENT
VOL.: 1.09 CU. IN.,
1000806020

Material Number
9COM/9CAT
379
Drilling Equipment
(Downhole
Equipment)
ICD,4-1/2",NVAM,11.6#,6-
1/8"OH,CARBO
EQUALIZER; NT TI TASKING VALVE (MTV), CF TYPE,HYDRO MECHANICALICD
(SPIRAL MODULE). ICD TYPE: HELICAL CHANNELS WITH MTV SYSTEM.ICD FLOW
RESISTANCE RATE: 1.9 FRR. RESTRICTOR MODULE: 90 PSI AT300 STB/DAY. MAX
OD: 5.630 IN. MIN ID: 3.510 IN. OPENINGMECHANISM: SHEAR WIRES. SETTING
TOOL REQUIRED: NONE. OPEN HOLESIZE: 6-1/8 IN. CONNECTIONS: 4-1/2 IN, 11.6
PPF, NEW VAM BOX XPIN. DEBRIS BARRIER MATERIAL: 316L STAINLESS STEEL.
HELIXMATERIAL: 13 CR. WORKING TEMPERATURE: 200 DEG F. SHEAR
VALUE:2,400 PSI.
1000839814
380
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,14X18-
5/8,TB,114#,T95,MEC
HANGER LINER; 14 IN END 1,18-5/8 IN END 2,136 PPF END 2,TENARISBLUE
DOPELESS,14 IN, 114 PPF X 18-5/8 IN, 136 PPF CSG LINERHANGER AND
ACCESSORIESKIT COMPONENTS
1000830809
381
Drilling Equipment
(Downhole
Equipment)
LATERAL,9-5/8X7,LEVEL
4,3DEG,MILLRITE
LATERAL; 'MILLRITE' SYSTEM TYPE,9-5/8 IN NPS,3° DEG,LEVEL 4MULTILATERAL
EQUIPMENT. ALL ITEMS SHOULD BE ASSEMBLED TOGETHERPRIOR TO
TESTING.KITS COMPONENTSITEM QTY DESCRIPTION01 01 EA WHIPFACE:
#LATCHRITE# DRILLING;FOR 9-5/8 IN 47 PPF, 8.500 IN DRILLOUT,TOTAL LENGTH:
389.46 IN,DEBRIS BARRIER OD: 8.988 IN,MAX OD (CENTRALIZER PAD): 8.480
IN,WHIP BODY OD: 7.250 IN,WHIP BORE ID: 4.000 IN,MIN. ID (FLAPPER VALVE):
2.060 IN,WHIPFACE TAPER ANGLE: 3.00OPART NUMBER: 31491702 01 MILL:
WINDOW AND GAUGE, #LATCHRITE#;9-5/8 IN 40-47 PPF,TOTAL LENGTH: 73.83
IN,MAX OD: 8.500 IN,MIN. ID: 2.500 IN,TOP CONNECTION: API 4.5 in IF
PIN,TENSILE STRENGTH (4-1/2 THREAD): 1,017,426 LBS,TORSIONAL LOAD: 18,000
LBS,TORSIONAL YIELD: 20,000 LBS,FLOW AREA (THRU MILL): 0.59 IN2ASSEMBLY
WEIGHT: 543 LBS,PART NUMBER: 10149711/10156026403 01 JOINT:
TRANSITION, 7 IN 29 PPF, NVAM;TOTAL LENGTH: 316.53 IN, (8.04 M),MAX OD
(CENTRALIZER): 8.500 IN,BODY OD: 7.250 IN,MIN ID (SETTING SLEEVE): 6.130
IN,CASING WEIGHT: 23.200 PPF,CASING GRADE: L-80,TENSILE STRENGTH: 145,000
LBS,RUNNING TOOL:MAX OD: 8.450 IN,MIN ID (CONNECTOR): 2.625
IN,MATERIAL: 4145H MOD,TENSILE STRENGTH: 143,500 LBS,04 01 SHOE: FLOAT;
7 IN 26 PPF, NVAM,SUPER SEAL II,OD: 7.656 IN,ID: 6.276 IN,DRIFT: 6.125
IN,LENGTH: 2 FT.05 01 COLLAR: FLOAT; 7 IN 26 PPF,NVAM LATCHRITE,SUPER SEAL
II,OD: 7.656 IN,ID: 6.276 IN,DRIFT: 6.125 IN,LENGTH: 2 FT,06 01 WASHOVER
SHOE: 9-5/8 IN 47 PPF,TOTAL LENGTH: 301.11 IN,LENGTH OF CROSSOVER: 32.300
IN,LENGTH OF WASHOVER PIPE: 232.310 IN,LENGTH OF SHOE ASSEMBLY: 36.500
IN,THREADS TO BOTTOM: 9.060 IN,MAX OD (SHOE BOTTOM): 8.490 IN,MIN ID
(WASHOVER SUB): 3.000 IN,CONNECTION: API 4.5 in IF BOX,ASSEMBLY WEIGHT:
1400 LBS.PART NUMBER: 286179
1000817064

Material Number
9COM/9CAT
382
Drilling Equipment
(Downhole
Equipment)
KIT,FRAC,4-
1/2X5.875"OH,VTHC,13.5#,PK
PACKER PRODUCTION; STAGE FRAC BLANK STAGE ASSEMBLY TYPE,7.625
INOD,3.50 IN ID,7 IN OD,32-35 LB/FT,4-1/2 IN CONNECTN,13.5LB/FT,VAM TOP HC
BOX X PIN COONECTN,10000 PSI WORKING PRESSURESUPPLY,OPEN HOLE: 5-7/8
IN, MATERIAL: P-110KITS COMPONENTS:
1000835552
383
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,9-
5/8X14,FJL,53.5#,625,HYD
HANGER LINER; HYDRAULIC ACTIVATI,9-5/8 IN END 1,53.5 PPF END 1,14 IN END
2,114 PPF END 2,VAM FJL KIT COMPONENTS 1000835539
384
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,VTHC,10K,HYD,1TRIP
PACKER PRODUCTION; "THT", PERMANENT
TYPE,HYDRAULICACTIVATI,CUSTOMIZED BUNDLE, POLISHED BORE RECEPTACLE
WITH SEALUNIT, THT HYDRAULIC-SET, MULESHOE RE-ENTRY GUIDE.
1000792070
385
Drilling Equipment
(Casing Accessories &
Cementing
Equipment)
DV TOOL,13-3/8",BTC,61-
72#,L80,MEC,3K
COLLAR: PACKER; INFLATABLE ASSY; FOR13-3/8 IN. OD 61.0 - 72.0 LB/FTCASING;
API-5B BUTTRESS BOX AND PIN;COLLAR PACKER; INFLATABLE TYPE,FOR
CEMENTING H2S,MULTISTAGE,L-80 CASING,13-3/8 IN INSIDE O,61.0-72.0
LB/FT,BUTTRESSBOX & PIN THD TERMINAL,16-3/4 IN TOOL OD,12.3590 IN ID
DRILLOU,19-1/2 IN EXPANSIO,BOTTOM PLUG 1ST,FREE FALL PLUG 2ND,API 5B,API
5AC,FREE FALL PLUG SET CONSISTS OF SHUT-OFF BAFFLE & PLUGAND OPENING &
CLOSING PLUG, BOTTOM PLUG SET CONSISTS OF BY-PASSBAFFLE & PLUG,
PACKED TO CUSTOMER SPECS, CONTROLLED HARDNESS API5ACKITS
COMPONENTS
1000022920
386
Drilling Equipment
Cementing
Equipment)
DV TOOL,13-3/8",BTC,48-
68#,L80,MEC,4FT
COLLAR: PACKER; INFLATABLE, MODEL (781 POST), WITH 4 FTELEMENT, FOR 13-
3/8 IN 48-68 LB/FT CASING, WITH BTCTHREAD, BOX x PINCOLLAR PACKER;
INFLATIBLE TYPE,FOR CEMENTING,MULTI STAGE,L-80CASING,13-3/8 IN INSIDE
O,48-68 LB/FT,18-5/8 IN OUTSIDE,115LB/FT OUTSIDE,BTC BOX X BTC PIN THD
TERMINAL,15.500 IN TOOLOD,12.250 IN ID DRILL OU,19 IN
EXPANSIO,DISPLACEMENT PLUG2ND,API 5D,EACH POST TOOL MUST BE BOXED
AS INDIVIDUAL UNITS FORSHIPMENT AND STORAGE.KITS COMPONENTS
1000644503
387
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,VTHC,32#,41XX,HYD
HANGER, LINER: HYDRAULIC-ROTATING ACTIVATION, HT SOUR SERVICE, (BMS A-
142) 41XX-HC110 MYS, 4 IN END 1, 32 0 HANGER LINER; HYDRAULIC-ROTATING
ACTIVATI,FOR HT SOUR,GR (BMS A-142) 41XX-HC110 MYS,4 IN END 1,32.0 LB/FT
END 1,9-5/8 IN END 2,43.5-58.4 LB/FT END 2,7 IN END CONN,7 IN 32 LB/FT VAM
TOP HC PIN X PIN,C-110 EQUIVALENT - NACE TEST TM0177 WAIVED,6.074 IN MIN
ID, GEN-2. HANGER AND ITS COMPONENTS SHOULD BE BOXED TOGETHER. KITS
COMPONENTS
1000644360

Material Number
9COM/9CAT
388
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,4-
1/2",NVAM,CRA,5K,TRMAXX5E
VALVE; SUBSURFACE SAFETY, TRMAXX-5E TYPE,SIZE 4-1/2 IN,5000 PSIWORKING
PRESSURE SUPPLY,4-1/2 IN, 12.6 PPF, NEW VAM BOX X PINEND CONN,9CR-1MO,
410-13CR BODY,9CR-1MO, 410-3CR, 4130/4140TRIM,API-14A/ISO10432,CLASS 2
3S,3C NACE MR-01-75,API-14A NACEMR-01-75/,ISO 1515 API
MONOGRAMMED,MAX. OD: 6.923 IN, MIN. ID:3.812 IN, MAKE-UP LENGTH: 60 IN,
NIPLLE PROFILE: 3.812 X TYPE,THREAD CONFIGURATION: BOX X PIN, THREAD
SIZE: 4-1/2 IN, THREADTYPE: NEW VAM, HYDRAULIC CONNECTION: 1/4 IDFC,
OPENING PRESSURE:1,915 PSI, CLOSING PRESSURE: 815 PSI, TEMPERATURE
RATING: 40-300DEG F, MATERIAL: FLOW WETTED: 9CR-1MO/ 410-13CR, HYD.
CHAMBERHSNG.: 410-13CR, LOWER NIPPLE: 9CR-1MO, SPRING: X-750,
TENSILESTRENGTH- EOEC @ AMBIENT: 413,374 LBS , EOEC @ SPECIFIED TEMP(F)
: 376,100 LBS (300 DEG F), YIELD PRESSURE- EXTERNAL: 5,978PSI, INTERNAL:
8,034 PSI
1000732501
389
Drilling Equipment
(Downhole
Equipment)
KIT,TIEBACK,7",VTHC,32#,625,PK
RSEAL,MDSK
PACKER LINER; JMZXDG TYPE,NICKEL ALLOY 625 PLUS,8.312 IN OD,7 IN LINER
OD,32 PPF LINER,9-5/8 IN OD,47.0 - 53.5 PPF,8.375 IN EXT OD,6.039 IN EXT
ID,VAM TOP HC BOX UP X MULESHOE DOWN COONECTN,7 IN 32 PPF
CONNECTN,7 IN X 9-5/8 IN 58.4 PPF UPPER COMPLETION FOR HASBAH
INCREMENT. KIT COMPONENTS
1000891632
390
Drilling Equipment
Cementing
Equipment)
DV TOOL,18-
5/8",BTC,115#,K55,MEC
COLLAR: PACKER; INFLATABLE ASSY;INFLATABLE: FOR 18-5/8 IN. OD 115.0LB/FT;
CASING W/API 5B BUTTRESS THREADCOLLAR PACKER; INFLATABLE TYPE,FOR
CEMENTING,MULTI STAGE,K-55CASING,18-5/8 IN INSIDE O,115.0 LB/FT,24 IN
OUTSIDE,176.0 LB/FTOUTSIDE,BUTTRESS BOX & PIN THD TERMINAL,20-4/5 IN
TOOLOD,17.3750 IN ID DRILL OU,24 IN EXPANSIO,BOTTOM PLUG 1ST,FREEFALL
PLUG 2ND,API 5B,FREE FALL PLUG SET CONSISTS OF SHUT-OFFBAFFLE & PLUG
AND OPENING & CLOSING PLUG, BOTTOM PLUG SETCONSISTS OF BY-PASS
BAFFLE & PLUG, PACKED TO CUSTOMER SPECSKITS COMPONENTS
1000022922
391
Drilling Equipment
Cementing
Equipment)
DV TOOL,13-3/8",VAM
TOP,72#,C95HCHS,4FT
COLLAR: PACKER; INFLATABLE, MODEL 781POST F/13-3/8 IN OD 72 LB/FT CASING,
W/4 FT ELEMENT, VAM TOP THREAD, BOX X PINCOLLAR PACKER; INFLATABLE
TYPE,FOR CEMENTING,MULTISTAGE,C-95HCCHS CASING,13-3/8 IN INSIDE O,72
LB/FT,18-5/8 INOUTSIDE,115 LB/FT OUTSIDE,VAM TOP BOX & VAM TOP PIN
THDTERMINAL,15.875 IN TOOL OD,12.25 IN ID DRILL OU,18.5 - 20.20
INEXPANSIO,AS PER THREAD MANUFACTURER'S SPECS,EACH POST TOOL MUSTBE
BOXED AS INDIVIDUAL UNITS FOR SHIPMENT AND STORAGE. THIS TOOLDOES
NOT HAVE A PLUG SET WITH IT. PACK TO SAUDI ARAMCOSPECIFICATIONKITS
COMPONENTS
1000024890

Material Number
9COM/9CAT
392
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,9-
5/8,VAM21,53.5#,718,TRSSV
VALVE; SAFETY TYPE,SIZE 9-5/8 IN, 53.5 PPF,NICKEL ALLOY 718, 140 KSI MYS
BODY,API-14A,NACE MR-01-75/ ISO 1515,API MONOGRAMMED,SELF EQUALIZING
TUBING RETRIEVABLE SUB SURFACE SAFETY VALVE, THREAD: VAM 21, TOOL ID:
12.200 IN, UPPER SEAL BORE: 8.375 IN LOWER SEAL BORE: 8.250 IN, WORKING
PRESSURE: 10,000 PSI
1000830504
393
Drilling Equipment
Cementing
Equipment)
DV TOOL,9-5/8",LTC,29.3-
40#,P110,MEC
COLLAR: PACKER; INFLATABLE ASSY;INFLATABLE; F/9-5/8 IN. OD 29.3 TO 40LB/FT
CASING; W/API 5B LTC THREAD;COLLAR PACKER; INFLATABLE TYPE,FOR
CEMENTING,MULTI STAGE,P-110CASING,9-5/8 IN INSIDE O,29.3-40.0 LB/FT,13-
3/8 INOUTSIDE,61.0-72.0 LB/FT OUTSIDE,8RD LTC BOX & LTC PIN
THDTERMINAL,11-3/4 IN TOOL OD,8.9270 IN ID DRILL OU,14
INEXPANSIO,BOTTOM PLUG 1ST,FREE FALL PLUG 2ND,API 5B,FREE FALLPLUG SET
CONSISTS OF SHUT-OFF BAFFLE & PLUG AND OPENING &CLOSING PLUG,
BOTTOM PLUG SET CONSISTS OF BY-PASS BAFFLE & PLUG,PACKED TO CUSTOMER
SPECS, WITH RUPTURE DISC ASSEMBLY HALLIBURTONP/N 100075423 (OLD PART
NO 813.30290)KITS COMPONENTS
1000024738
394
Drilling Equipment
(Downhole
Equipment)
WHIPSTOCK,7",5.375,23-
35#,HYD,PKR,3.0DG
WHIPSTOCK:7 IN OD, HYDRAULIC SET,RETRIEVABLE TRACKMASTER ONE TRIP SIDE-
TRACKING SYSTEM, FOR 7 IN 23-35 LB/FTCASING.WHIPSTOCK; HYDRAULIC SET,
RETRIEVABLE TRACKMASTER ONE TRIPSIDE-TRACKING SYSTEM TYPE,7 IN BODY
STD,ONE TRIP-SIDE TRACKINGSYSTEM TRIP,5-3/8 IN OD, COMPLETE WITH
TRACKMASTER SLIDE WITH 3DEGREES FACE WITH HOOK RETRIEVING SLOT AND
HYDRAULIC RETRIEVABLEPACKER, FOR 7 IN 23-35 LB/FT CASING.------
1000709228
395
Drilling Equipment
(Advanced Well
Completion
Equipment)
PDHMS,4-1/2,NVAM,DUAL
GAUGE
ASSEMBLY; MONITORING TYPE,DOWN HOLE, 4-1/2 IN, DUAL, PERMANENT KIT
COMPONENTS
1000754847
396
Drilling Equipment
(Downhole
Equipment)
KIT,FRAC,4-
1/2X7",VTHC,13.5#,LH-PK-SL
PACKER PRODUCTION; FOR STAGE FRAC SET UP ASSEMBLY,5.625 INOD,3.50 IN
ID,7 IN OD,32-35 LB/FT,4-1/2 IN CONNECTN,13.5LB/FT,VAM TOP HC BOX X PIN
COONECTN,10000 PSI PSI WORKINGPRESSURE SUPPLY,MATERIAL: P-110KITS
COMPONENTS:
1000835550
397
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,4-
1/2",BLADERUNNER,5.625"OD
CENTRALIZER CASING; BLADE RUNNER TYPE,4-1/2 IN X 5-7/8 IN (OD5-5/8 IN)
CASING,TYPE: SOLID BODY, SLIP ON. BLADES: 5 X SPIRALRIGHT HAND. MATERIAL:
ZINC-ALLOY/TEFLON. WEIGHT (KG): 4.40.FLOW-BY (SQ INS): 6.41.
MANUFACTURING PROCESS: DIE CAST.
1000886008

Material Number
9COM/9CAT
398
Drilling Equipment
(Downhole
Equipment)
KIT,VALVE,ISOL,5-
1/2",VTOP,13CR+TOOL+JTS
VALVE BALL; SIZE 5-1/2 IN,5000 PSI SUPPLY,VAM TOP PIN ENDCONN,13CR AISI
420 MOD 80 KSI MYS BODY,ACTUATED OPERATED,VALVEOD (IN): 8.200. VALVE ID
(IN): 4.625. SEAL BORE ID (IN): 6.000.WORKING PRESSURE (PSI): 5,000. TEST
PRESSURE (PSI): 6,250. YIELDPRESSURE RATING (PSI): 6,250 (BURST), 5,000
(COLLAPSE). WORKINGTEMPERATURE (°F): 35-300. BALL DIFFERENTIAL PRESSURE
FROMABOVE/BELOW (PSI): 5,000. DIFFERENTIAL OPENING RATING (PSI):1,000.
VALVE METALLURGY: 13CR AISI 420 MOD 80 KSI MYS. VALVESEALS: NON-
ELASTOMERIC. RUNNING PULLING TOOL (RPT): H826700001.RPT METALLURGY:
LOW ALLOY STEEL, 80KSI MYS. SHEAR VALUE: 60KLBSTO RELEASE. RPT PACKING
UNIT: BONDED NITRILE. PRODUCTIONSHIFTING TOOL (PST): H826710001. PST
METALLURGY: 13CR AISI 420MOD 80 KSI MYS. PST PACKING UNIT: A-RYTE
(AFLAS). TSOJMETALLURGY: LOW ALLOY STEEL, 80KSI MYS. TSOJ ELASTOMERS:
NOSEALS WITHIN TSOJ.KIT COMPONENTS
1000885079
399
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,5-
LG,SS316L,FOR SANDSTONE INSTALLATION, BASE PIPE MATERIAL:L-80, PIPE SIZE:
5-1/2 IN, 20.0 LB/FT, THREAD CONNECTION: NEWVAM, WEIGHT: 26.64 LB/FT,
DISPLACEMENT: 0.50 GAL/FT, AXIAL RODPROFILE: 4.0 X 3.0 MM, NO. OF RODS:
32, WRAP WIRE PROFILE: 4.0 X3.0 MM, SCREEN (WRAPPED) INFLOW AREA:
6.98%, SLOT OPENING: 225MICRONS/0.009 IN, CENTRALIZER PER LOCATION:
ONE/JT @ PIN END,NO. OF STOP COLLARS: TWO/CENTRALIZERS, NOZZLE
DIAMETER: 4 MM,NUMBER OF NOZZLES: 4 PER JOINT.
1000778519
400
Drilling Equipment
(Advanced Well
Completion
Equipment)
CABLE,DOWNHOLE,18AWG,1/4",
INC825,1FT
CABLE; PERMANENT DOWNHOLE TYPE,18 AWG DIA,TIN COATED COPPER,1.16
MM OD,1000 VDC, WITH T-05 DIELECTRIC 2.60 MM OD, TYPE-06FILLER, 4.57 MM
OD, TYPE 825 INCOLOY ALLOY TUBE 0.035 IN WALLTHK, 6.35 MM OD TYPE
POLYAMIDE NYLON JACKET, 11 MM X 11 MM SIZE,ELECTRICAL CHARACTERISTICS:
DC RESISTANCE AT 20 DEG C CENTERCONDUCTOR: 21.06 OHMS/KM,
CAPACITANCE CENTER CONDUCTOR TO TUBE:99 PF/M, INSULATION RESISTANCE
AT 20C CENTER CONDUCTOR TO TUBLE:2900 MEG-OHM/KM.
1000839686

Material Number
9COM/9CAT
401
Drilling Equipment
(Advanced Well
Completion
Equipment)
SCREEN,EXPAND,4",MKI,230MIC,
INC825,SNDST
SCREEN; EXPANDABLE SAND (ESS), CORROSION RESISTANT TYPE,SIZE
4IN,INCOLOY 825,WITH 230 MICRON WEAVE SIZE, JOINT (SCREEN)LENGTH: 38 FT,
BASE PIPE DIA: 4 IN, BASE PIPE MATERIAL: ALLOY28, WITH MK I ESS BOX X PIN
CONNECTIONS. 1- COMPLETE ASSEMBLYMUST BE BOXED AS AN INDIVIDUAL UNIT
FOR SHIPMENT AND STORAGE PERSAUDI ARAMCO PACKAGING SPEC 844418. 2-
MANUFACTURER MUST BARCODE IDENTIFY EACH ISSUE UNIT ON BOTH THE
MATERIAL AND OUTSIDETHE CONTAINER IN WHICH THE ISSUE UNIT IS
CONTAINED CODE TO BE INTHE INTERNATIONAL CODE 39 BAR CODING SYSTEM
FORMAT AND ADHERE TOANSI MH10.8M (LATEST EDITION) SPECIFICATION (LESS
SECTIONS 12 &13). BAR CODE TAG MUST INCLUDE THE SAUDI ARAMCO STOCK
NUMBER ANDPURCHASE ORDER NUMBER. 3- ALL ITEMS SHOULD BE ASSEMBLED
TOGETHERPRIOR TO TESTING.
1000804355
402
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,5-
1/2,NVAM,17#,350MC,SNDST
SCREEN; FLOREG ICD WITH 350 MICRON DIRECT WRAP SCREEN TYPE,SIZE 5-1/2
IN,SS316L,GRADE: L-80, BASE PIPE SIZE: 5-1/2 IN, BASE PIPE MATERIAL: SS316L,
WITH SLOT AT 0.014 IN GAUGE OPENING (SLOT TOLERANCE +0.002 IN, -0.003 IN).
BASE PIPE WEIGHT: 17 PPF, BASE PIPE GRADE: L-80, CONNECTION: NEW VAM PIN
X BOX AT 38 FT (+0, -1 FT). SCREEN LENGTH AT 16 FT WITH IN –FLOW CONTROL
DEVICE. HOUSING RETAINING RING: 316L, HOUSING: 13CR-80KSI, FLOW RING:
316L, THREADED RING: 316L, FLOW PORT MATERIAL: TUNGSTEN CARBIDE, SET
SCREW (5/16 UNF): 316L, O-RING: VITON, DIRECT WRAP TENSILE: 337,000 LBS,
DIRECT WRAP TORQUE: 33,000 FT-LBS, DIRECT WRAP BURST: 3,555 PSI, DIRECT
WRAP COLLAPSE: 4,535 PSI.
1000840975
403
Drilling Equipment
(Downhole
Equipment)
VALVE,ICV,3-
1/2",NVAM,9.2#,13CR,HCM-A
VALVE; HCM-A TYPE,SIZE 3-1/2 IN,7500 PSI SUPPLY,3-1/2 IN. 9.2PPF NEW VAM
BOX X PIN END CONN,13CR/INC 718/925/825 & TUNGSTENCARBIDE BODY,MAX
OD: 5.850 IN, MIN ID: 2.812 IN, LENGTH: 102 IN,MAX WORKING TEMP.: 40-
325OF, CONTROL CHAMBER PRESS. RATING:10000 PSI, RUPTURE DISC PRESSURE:
9,000 PSI, INCREMENTALPISTONDISPLACEMENT: 19 ML MAX, VALVE IS CAPABLE
OF HAVING 8 TO 12CHOKING POSITIONS INCLUDING THE FULLY OPEN AND FULLY
CLOSEDPOSITION. THE DESIGN ALSO PROVIDES THE ABILITY TO MOVE TO
THEFULLY CLOSED POSITION WITH A HYDRAULIC PRESSURE APPLICATION TOTHE
CLOSE PORT. VALVE SHALL BE CAPABLE TO "PROGRESSIVELY OPEN"WITH RAPID
CLOSURE.
1000782380

Material Number
9COM/9CAT
404
Drilling Equipment
(Downhole
Equipment)
PACKER,LINER,7",NK3SB,29#,41X
X,TBR 15FT
PACKER, LINER: ZXP, (BMS A-142)41XX-HC110 MYS, HT SOUR, 15 FT X 7 50 IN 29
LB/FT TIE-BACK, 7 IN LINER PACKER LINER; ZXP TYPE,(BMS A-142)41XX-HC110
MYS,FOR HT SOUR,15 FT X 7.50 IN 29 LB/FT TIE-BACK,7 IN LINER OD,29 LB/FT
LINER,9-5/8 IN OD,47.0-53.5 LB/FT (ALSO 58.4 LB/FT SPECIAL DRIFT),7.5000 IN
EXT OD,NK-3SB BOX DOWN COONECTN,7 IN 29 LB/FT CONNECTN,(C-110
EQUIVALENT-NACE TEST TM0177 WAIVED),WITH HOLD DOWN SLIPS AND HR
PROFILE, XYLAN-1052 COATED, 6.276 IN MIN ID. ELEMENT RATING:10,000 PSI
KITS COMPONENTS
1000644357
405
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,4-
1/2,10K,WRSSSV,FXE
SUBSURFACE SAFETY VALVE, WIRELINE RETRIEVABLE ASSY. FLAPPER TYPE, 3.813
X 2.12, H2S SERVICE VALVE; SUBSURFACE SAFETY TYPE,SIZE 3.813 X 2.12,10,000
PSI WORKING PRESSURE SUPPLY,***** END CONN,API 14A,NACE MR-01-75 API-
14A,NACE MR-01-75/ ISO 1515,API MONOGRAMMED,FLAPPER TYPE "FXE" PART#
120056486 TOP THREAD 3-1/4-12-UN, SPECIAL FEATURE, EQUALIZING, REQUIRES
LOCKING MANDREL PART# 101070268 KITS COMPONENTS
1000026440
406
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,4-
1/2X7",NK3SB,13.5#,CRA
LINER; DEPLOYMENT, KIT TYPE,LINER DEPLOYMENT KIT FOR 4-1/2 INEXCLUDER
SCREENKITS COMPONENTS: CONSIST OF:ITEM QUANTITY DESCRIPTION01 01
Baker Model ZXP-Flexlock #Liner Packerwith 15ft. 5-1/4 IN. Tie-back sleeve(HR
profile)Size: 7 IN. 32 lb/ft.Threads: 5 IN. 18lb/ft NT-3SB PinTool O.D.: 5.875
IN.Tool I.D.: 4.250 IN.Material: S13Cr 95-110 KSIXylan 1052 Co aledHanging
Capacity: 380,000#Pressure Rating: 10,000 psiPART# H29316011002 01 Baker
Casing SubSize: 5 IN. 18lb/ft X 4-1/2 13.5lb/ftThread Connection Up: 5 IN. 18
lb/ftTN-3SB Box TOPThread Connection Down: 4.5 IN. 13.5Lb/ft TN-3SB PinTool
O.D.: 5.000 IN.Tool I.D.: 3.820 IN.Material: S13Cr-95PART# H29989383003 01
Baker#Magnum# Dual Acting DiscSize: 4-1/2 IN. 13.5 lb/ftThread Connection: TN-
3SBTool O.D.: 5.300 IN.Tool I.D.: 3.877 IN.Material: Super 13Cr 95 KSIPressure
Rating: 10,000 psiPART# SAP1016706504 01 Baker Bull PlugSize: 4-1/2 IN.Thread:
4.5 IN. 12.60 lb/ft TN-3SB BOXTool O.D.: 5.000 IN.Material: Super 13Cr-95
KSIPART# H485304566
1000751501
407
Drilling Equipment
(Downhole
Equipment)
PACKER,ISOL,4-
1/2X7"OH,NK3SB,MPAS,13CR
PACKER PRODUCTION; MECHANICAL TYPE,HYDRAULIC SET ACTIVATI,5.000IN
(MAX) OD,2.897 IN (MIN) ID,S13% CR MODEL "MPAS" OPEN HOLEMECHANICAL
PACKER, SIZE: 4-1/2 IN X 5 IN OD, SETTING MECHANICSM:HYDRAULIC SETTING
TOOL REQUIRED: WORKING SHIFTING TOOL, OPENHOLE RANGE: 5-7/8 IN X 7 IN,
CONNECTION: 4-1/2 IN 13.5 LBTENARIS 3SB BOX X PIN, MATERIAL: SUPER 13CR,
95 KSI MYS, ELEMENTELASTOMER: NITRILE, TEMPERATURE RATING: 300 DEG F,
TENSILERATING: 246000 LBS
1000827889

Material Number
9COM/9CAT
408
Drilling Equipment
(Downhole
Equipment)
38#,HYD,2.0DG,TT
WHIPSTOCK; THROUGH TUBING TYPE,3-5/8 IN OD BODY STD,RETRIEVABLETRIP,7
IN CSNG DRE,32-38 LB/FT CSNG DRE,15 FT LONG, 2.00 INSCOOP RADIUS. THE
WHIPSTOCK ANCHOR IS FIRMLY SET BY UTILIZING ASIZE 10 E-4 WIRELINE
PRESSURE SETTING ASSEMBLY OR A SIZE 10 JHYDRAULIC SETTING TOOL. 1- ITEMS
MUST BE BOXED AS PER SAUDIARAMCO PACKAGING SPEC 844418. 2-
MANUFACTURER MUST BAR CODE/IDENTIFY EACH ISSUE UNIT ON BOTH THE
MATERIAL AND OUTSIDE THECONTAINER (IN WHICH THE ISSUE UNIT IS
CONTAINED). CODE TO BE INTHE INTERNATIONAL CODE 39 BAR CODING SYSTEM
FORMAT AND ADHERE TOANSI MH10.8M (LATEST EDITION) SPECIFICATION (LESS
SECTIONS 12 &13). BAR CODE TAG MUST INCLUDE THE SAUDI ARAMCO STOCK
NUMBER ANDPURCHASE ORDER NUMBER. ALL ITEMS SHOULD BE ASSEMBLED
TOGETHERPRIOR TO TESTING.
1000804765
409
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,4-
1/2X7,NK3SB,13.5#,CRA,HYD
HANGER, LINER: HYDRAULIC-ROTATINGACTIVATION, HT SOUR SERVICE, (BMSA-
142) 41XX-HC110 MYS, 4-1/2 IN END 1,HANGER LINER; HYDRAULIC-ROTATING
ACTIVATI,FOR HT SOUR,GR (BMSA-142) 41XX-HC110 MYS,4-1/2 IN END 1,13.5
LB/FT END 1,7 IN END2,29-32 LB/FT END 2,4-1/2 IN END CONN,4-1/2 IN 13.5
LB/FTNK-3SB,T-95 EQUIVALENT-NACE TEST TM0177 WAIVED,FOR KHUFF GEN-
2.AND JOINT COLLAPSE PRESSURE, 10,710 PSI MIN BODY AND JOINT
BURSTPRESSURE: 364,000 LBS. BODY AND JOINT TESNILE STRENGTH. KHUFFLINER
HANGER SYSTEM COMPLETE ASSEMBLY. MUST BE BOXED AS ANINDIVIDUAL UNIT
WITH ITS COMPONENTS AS LISTED BELOWKITS COMPONENTS
1000644367
410
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,5-
1/2,NVAM,17#,FLOREG,SNDST
SCREEN; FLOREG INFLOW CONTROL DEVICE (ICD) TYPE,SIZE 5-1/2 IN XR3,L-
80,FOR SANDSTONE INSTALATION, MAT'L: L-80, FILTER: CSM INSS 316L, PIPE SIZE:
5-1/2 IN 17.0 LB/FT, THREAD CONNECTION: NEWVAM BOX X PIN, JACKET
LENGTH: 16 FT (SINGLE MODULE), MAX OD:6.500 IN, MIN ID: 4.892 IN
1000794602

Material Number
9COM/9CAT
411
Drilling Equipment
(Downhole
Equipment)
PACKER,ECP,6.125x4-
/2,NVAM,12.6#,MECH
PACKER PRODUCTION; OPEN HOLE, MECHANICAL TYPE,FOR STANDARD,5.625IN
(MAX) OD,3.500 IN (MIN) ID,SIZE: 6-1/8 IN, MATERIAL: VAM,AMBIENT), MAX SET
DOWN/PULL UP DURING RIH: L-80, LENGTH: 176.500IN, 100000 LBS, HOLE SIZE
(ID): THREAD UP: 4-1/2 IN OD 12.6 6.00TO 7.00 IN ROUND HOLE LB/FT NEW VAM
BOX THREAD & 6.30 IN X 7.00IN OVAL DOWN: 4-1/2 IN OD 12.6 HOLE, RELEASE
SLEEVE SHEAR LB/FTNEW VAM PIN, BASE MATERIAL : AISI 4140 (18-22 SCREW
RTG: 4250 TO5750 HRC), ELASTOMERS : HNBR CUP LBS, MAX BYPASS FLOW RATE:
5BBL/MIN (WATER), TORQUE SEAL, HNBR O-RINGS, DESIGN RATING THRUTOOL:
3000 FT VERIFICATION : ISO 14310 LBS. V3, QUALITY CONTROLGRADE : Q3,
WEIGHT OF TOOL: 510 LBS (185 KG), DIFFERENTIALPRESSURE RATING : 2000 PSI ,
BURST RATING OF TOOL: 3000 PSI,COLLAPSE RATING OF TOOL: 3000 PSI,
HYDROSTATIC SETTING PRESSURERANGE : 2600 TO 6500 PSI, OPERATING
TEMPERATURE :20 TO 110 DEGC, RUNNING TEMPERATURE :20 TO 110 DEG C,
TENSILE RATING: 193358LBS (MAIN MANDREL), COMPRESSION RATING: 115000
LBS (40% NEW
1000827791
412
Drilling Equipment
Cementing
Equipment)
DV TOOL,9-
5/8",NK3SB,53.5#,T95,MEC,HTHP
CEMENTER; POST HTHP TYPE,9-5/8 IN OD,53.5 LB/FT WT,TENARIS 3SB
(NK3SB),11.75 IN TOOL OD,8.505 IN (ID) DRILL OD,(2-STAGE) MECHANICAL
PACKOFF. CASING GRADE: API GRADE T-95. ELEMENT MATERIAL: HNBR. OD
(MAX): 11.75 IN. PACKER ELEMENT OD: 11.25 IN. DRILLOUT ID: 8.505 IN. DRIFT:
8.500 IN. OVERALL LENGTH: 10.5 FT. PACKER ELEMENT LENGTH: 0.3 FT. OPENING
SEAT ID: 7.250 IN. CLOSING SEAT ID: 7.750 IN. OPENING PRESSURE: 400-600 PSI
(INNER SLEEVE MOVESTO BEGIN PACKER SET). PACKER SETTING PRESSURE
(SHIFTS CONE AND SETS SLIPS): 2140 PSI (12 SCREWS @ 178 PSI PER SCREW).
OPENING OF STAGE TOOL PORTS (EXTERNAL SLEEVE OPENING PRESSURE): 3000
PSI (MAXIMUM) 12 SCREWS @ 250 PSI PER SCREW. CLOSING PRESSURE: 1200 PSI.
STAGE TOOL SEALS: FLOUROCARBON O-RING SEALS. CEMENTING PORTS: SIX 1-
1/8 IN DIA PORTS. MAXIMUM INTERNAL PRESSURE: 7800 PSI. MAXIMUM
EXTERNAL PRESSURE: 7480 PSI. SAFE LOAD BELOW TOOL (FS = 1.5): 909,000 LBS.
MAXIMUM TEMPERATURE RATING: 350 DEG F. MAXIMUM DIFFERENTIAL
PRESSURE (ABOVE ELEMENT): 7000 PSI WITH WATER (WHEN SET INSIDE 13-3/8
IN, 86 PPF P-110 CASING). MAXIMUM DIFFERENTIAL PRESSURE (BELOW
ELEMENT): 4500 PSI WITH WATER AND 3600 PSI WITH GAS (PLUG SET REQUIRED
FOR TOOL OPERATION MUST BE ORDERED SEPARATELY).
1000882666

Material Number
9COM/9CAT
413
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,VTHC,32#,C95,HYD
HANGER: LINER ASSY; 7 IN 32# VAM TOP HCX 9-5/8 IN 53.5-58.4# 'TSP' HYDRO-
HANGER, 6.0" MIN. DRIFT ID, GEN-2,HANGER LINER; HYDRAULIC ACTIVATI,FOR
H2S SOUR SERVICE,GR41XX-95000 MYS (C-95),7 IN END 1,32 LB/FT END 1,9-5/8
IN. END2,53.5 - 58.4 LB/FT END 2,VAM TOP HC END CONN,NACE MR-01-
75,TIWTYPE TSP-RRP FOR 7 IN GENERATION-2 KHUFF LINER HANGER
SYSTEMS.COMPLETE ASSEMBLY MUST BE BOXED AS AN INDIVIDUAL UNIT WITH
ITSCOMPONENTS AS LISTED BELOWKITS COMPONENTS
1000023992
414
Drilling Equipment
Cementing
Equipment)
DV TOOL,9-5/8",NK3SB,43.5-
53.5#,MEC,3FT
COLLAR: PACKER; INFLATABLE ASSY; ESIPC;F/9-5/8 IN NK3-SB 43.5-53.5
LBS/FTCASING; W/RUPTURE DISK; W/3 FT ELEMENT;COLLAR PACKER; INFLATABLE
TYPE,FOR CEMENTING,MULTI STAGE,C-95 OREQUIVALENT CASING,9-5/8 IN.
INSIDE O,43.5-53.5 LBS/FT,13-3/8 IN.OUTSIDE,61-72 LBS/FT OUTSIDE,NK3-SB
TERMINAL,11.38 IN. TOOLOD,8.619 IN. DRILL OU,13.5 IN. EXPANSIO,API 5B,EACH
PACKERCOLLAR MUST BE BOXED AS AN INDIVIDUL UNIT FOR SHIPMENT
ANDSTORAGE, THIS DV PACKER DOES NOT HAVE PLUG SET INCLUDED WITH
IT.AND DOES NOT INCLUDE HANDLING SUB WITH IT. COMPLETE ASSEMBLYMUST
BE BOXED AS AN INDIVIDUL UNIT WITH ITS COMPONENTSKITS COMPONENTS
1000024893
415
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,4-
1/2X6.125"OH,SLIPON
PACKER PRODUCTION; RESPACK TYPE,SWELLABLE ACTIVATI,5.790 INOD,4.607 IN
ID,4.5 IN OD,OPEN,OPEN CONNECTN,OPEN,OPENCOONECTN,OPEN HOLE SIZE:
6.125 IN. PACKER LENGTH: 18 IN.EXTERNAL ELEMENT THICKNESS (SWELLING
RUBBER): 0.913 IN. SUPPORTTUBE THICKNESS (CARBON STEEL): 0.100 IN. INNER
ELEMENT THICKNESS(SWELLING RUBBER): 0.180 IN. END RING LENGTH: 1.750 IN.
END RINGOD: 5.790 IN. END RING ID: 4.560 IN.
1000875948
416
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,NVAM,12.6#,L80,RET
PACKER PRODUCTION; QHSB HYDRAULIC SET RETRIEVABLE TYPE,FOR
H2S,CO2,HYDRAULIC SET ACTIVATI,6.000 IN OD,3.875 IN ID,7 IN OD,26-
29LB/FT,5.250-4TPI LEFT HAND SQUARE THREAD (TOP) X 4-1/2 IN, 12.6LB, L-80
NEW VAM PIN DOWN CONNECTN,12.6 LB/FT (BOTTOM),LEFT-HANDSQUARE
THREAD (TOP) NEW VAM PIN (DOWN) COONECTN,6,000 PSISUPPLY,NACE
MR0175,CARBON STEEL 4140 FLOW WETTED NITRILEELASTOMERKIT
COMPONENTS
1000742277

Material Number
9COM/9CAT
417
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,7",VTHC,10K,718,
TRSSSV
VALVE; SAFETY, TUBING RETRIEVABLE TYPE,SIZE 7 IN 32 LB/FT,10000PSI
SUPPLY,NICKEL ALLOY 718 120 MYS BODY,API-14A,NACE MR-01-75/ISO 15156
MONOGRAMMED,MIN ID: 5.812 IN, ONYX SAFETY VALVE ID:5.860 IN, MAX OD:
9.200 IN, TYPE OF SERVICE: CO2 & H2S & CL,SELF EQUALIZING TYPE
CONNECTION: 7 IN 32 LB/FT VAM TOP HC BOX XPIN, TOP NIPPLE ADAPTOR
PROFILE: 5.812 IN RPT, BOTTOM SEAL BOREID: 5.812 IN, TENSILE: 877.000 LBS,
TEMPERATURE RATING: 20 TO350 DEG F, WORKING PRESSURE ABOVE: 10000 PSI,
EQUALIZINGPRESSURE: 10000 PSI, FLAPPER LOCK OPEN PRODUCT
NUMBER:H822805801, COMMUNICATION TOOL PRODUCT NUMBER:
H822815803,INSERT TOOL PRODUCT NUMBER: H825535810KIT COMPONENTS
1000824001
418
Drilling Equipment
(Advanced Well
Completion
Equipment)
PDHMS,3-1/2,EUE,DUAL
GAUGE,P+T
ASSEMBLY; MONITORING, DOWN HOLE TYPE,3-1/2 IN, DUAL, PERMANENTKIT
COMPONENTS
1000754845
419
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,7",BLADERUNNER,
8.250"OD
CENTRALIZER CASING; SLIP-ON, SOLID BODY, SPIR-O-LIZERBLADERUNNER TYPE,7
IN X 8-1/2 IN CASING,8-1/4 IN BOW OD,STYLE5-BLADE, SPIRAL,INTERNAL DIA.: 7-
1/8 INCH, WALL THICKNESS: 3/16INCH, LENGTH: 10 INCH, WEIGHT: 6.10 KG,
BLADES: 5 X SPIRAL,BLADE ANGLE: 25O, BLADE LEAD IN: 2-1/2 INCH, BLADE LEAD
OUT:1-1/2 INCH, MATERIAL: ZINC ALLOY & TEFLON, USE WITH 2 EACHDUCTILE
IRON SPIR-O-LOK STOP COLLARS, WITH MATERIAL NUMBER1000XXXXX, ITEMS
MUST BE BOXED AS AN INDIVIDUAL UNIT FORSHIPMENT AND STORAGE PER
SAUDI ARAMCO PACKAGING SPEC 844418.MANUFACTURER MUST BAR CODE
IDENTIFY EACH ISSUE UNIT ON BOTH THEMATERIAL AND OUTSIDE THE
CONTAINER IN WHICH THE ISSUE UNIT ISCONTAINED. CODE TO BE IN THE
INTERNATIONAL CODE 39 BAR CODINGSYSTEM FORMAT AND ADHERE TO ANSI
MH10.8 ( LATEST EDITION)SPECIFICATION (LESS SECTIONS 12 & 13). BAR CODE
TAG MUST INCLUDETHE SAUDI ARAMCO STOCK NUMBER ANDBE PURCHASE
ORDER NUMBER.BF
1000803581
420
Drilling Equipment
(Downhole
Equipment)
WHIPSTOCK,9-5/8,8,36-
58.4,HYD,PKR,1.98DG
WHIPSTOCK; HYDRAULIC SET TYPE,8 IN OD BODY STD,ONE TRIP
WITHRETREIVABLE PACKER, 14 FT SLIDE WITH 1.98-DEGREE WHIP FACETRIP,9-5/8
IN OD CSNG DRE,36-58.4 LB/FT CSNG DRE,CONNECTION:TOP: SHEAR BOLT,
BOTTOM: BULL NOSE, PRESSURE RATING: 5,000 PSI,MATERIAL GRADE: MODIFIED
4145 WITH 40 RC, PACKER MATERIAL: 80DURO NITRILE, RETREIVING METHOD:
HOOK OR DIE COLLAR
1000762313

Material Number
9COM/9CAT
421
Drilling Equipment
Cementing
Equipment)
DV TOOL,13-3/8",VAM TOP,61-
72#,C95,3FT
COLLAR, PACKER: INFLATIBLE, CEMENTING, MULTI STAGE, C-95 OR EQUIVALENT
CASING, 13-3/8 IN INSIDE OD, W/ 3 FT ELEMENT. COLLAR PACKER; INFLATIBLE
TYPE,FOR CEMENTING,MULTI STAGE,C-95 OR EQUIVALENT CASING,13-3/8 IN
INSIDE O,61-72 LBS/FT,18-5/8 IN. OUTSIDE,115 LBS/FT OUTSIDE,VAM TOP
TERMINAL,15.25 IN. TOOL OD,12.359 IN. DRILL OU,18.5 IN. EXPANSIO,API
5B,EACH PACKER COLLAR MUST BE BOXED AS AN INDIVIDUL UNIT FOR SHIPMENT
AND STORAGE, THIS DV PACKER DOES NOT HAVE PLUG SET INCLUDED WITH IT.
ALSO, NO HANDLING SUB IS REQUIRED. COMPLETE ASSEMBLY MUST BE ##BOXED
AS AN INDIVIDUL UNIT WITH ITS COMPONENTS. KITS COMPONENTS............ ITM
01, QTY 01, DESCRIPTION COLLAR: PACKER, INFLATABLE, CASING SIZE: 13-3/8" 61-
72 THREADS : VAM TOP TOOL LENGTH : 56.8 IN TOOL OD : 15.25 IN DRILL OUT ID
: 12.359 IN MAX HOLE SIZE: 18.50 IN MATERIAL : C-95 OR EQUIVALENT. P/N
101321539
1000648892
422
Drilling Equipment
Cementing
Equipment)
DV TOOL,18-
5/8",BTC,115#,L80,MEC,4FT
COLLAR: PACKER; INFLATABLE; MODEL (781 POST), F/18-5/8" 115 LBS/FT CSG,
W/BTC THD, BOX X PIN, W/4 FT ELEMENT COLLAR PACKER; INFLATABLE TYPE,FOR
CEMENTING,MULTI STAGE,L-80 CASING,18-5/8 IN INSIDE O,115 LBS/FT,24 IN
OUTSIDE,176 LBS/FT OUTSIDE,BTC BOX & BTC PIN THD TERMINAL,21.625 IN TOOL
OD,17.251 IN DRILL OU,22.25 IN EXPANSIO,FREE FALL PLUG SET PLUG 2ND,API
5B,EACH TOOL MUST BE BOXED AS INDIVIDUAL UNITS FOR SHIPMENT AND
STORAGE. PACKED TO ARAMCO SPECS. PACKING SPEC 844418 APPLIES KITS
COMPONENTS
1000609477
423
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,7",BLADERUNNER,
8.125"OD
CENTRALIZER CASING; BLADE RUNNER TYPE,7 IN X 8-3/8 IN (OD 8-1/8 IN)
CASING,TYPE: SOLID BODY, SLIP ON. BLADES: 5 X SPIRAL RIGHT HAND. MATERIAL:
ZINC-ALLOY/TEFLON. WEIGHT (KG): 5.80. FLOW-BY (SQ INS): 10.72.
1000886162

Material Number
9COM/9CAT
424
Drilling Equipment
(Downhole
Equipment)
VALVE,ICV,3-
1/2",NVAM,9.2#,718,7.5K,HVC
VALVE; INTEGRATED HVC CHOKE AND ACCUPULSE TYPE,SIZE 3-1/2 IN,7,500 PSI
SUPPLY,3-1/2 9.2# NEW VAM BOX X PIN END CONN,CASING SIZE: 7 IN. 20-32#,
MAXIMUM OD: 5.865 IN, MINIMUM ID: 2.750 IN, LENGTH: 130.25 IN, 3-1/2 9.2#
NEW VAM CONNECTION TORQUE (FT-LBS):4,300 MIN, 4,770 OPT., 5,240 MAX,
HVC CONNECTION: 3-1/2 10.2# NS-CT B X P THD, 3-1/2 10.2# NS-CT CONNECTION
TORQUE(FT-LBS): 3,070 MIN, 3,430 OPT., 3,790 MAX, SERVICE: STD/H²S/CO², MAX
WORKING TEMP :275°F, WORKING PRESSURE INTERNAL: 7,500 PSI, WORKING
PRESSURE EXTERNAL: 7,500 PSI, TEST PRESSURE INTERNAL: 8,000 PSI, TEST
PRESSURE EXTERNAL: 8,000 PSI, MAX. HYDRAULIC PRESSURE: 10,000 PSI,
WORKING HYDRAULIC PRESSURE: 7,500 PSI, MAX. DIFF UNLOADING PRESSURE:
5,000 PSI, MAX. DIFF BETWEEN ACCUPULSE CHAMBER AND ANNULUS: 5,000 PSI,
HVC CHOKE: 214HVC350034, ACCUPULSE: 213AP1350003, HVC METALLURGY: INC
718, FITTING KIT METALLURGY: INC 718 / 4140, ACCUPULSE METALLURGY: INC
718, FASTENER METALLURGY: 300 SS / INC 718, CLAMP BOLT SIZE (ON ANCHOR
PROTECTOR) (ON ACCUPULSE): 3/8 - 16, ½ - 13, CLAMP BOLT TORQUE (ON
ANCHOR PROTECTOR) (ON ACCUPULSE): 50 FT-LBS, 20 FT-LBS, ELASTOMERS
F/HYD. CHAMBER: V-RINGS E081 (PTFE), O-RINGS (CHEMRAZ), BACK UP RINGS
E080 (PEEK), ELASTOMERS F/ WELLBORE FLUID: BACK UP RINGS E080 (PEEK), O-
RINGS (CHEMRAZ), PISTON AREA: 2.075 SQ. IN, TOTAL STROKE: 6.00 IN, HYD
CHAMBER DISPLACEMENT: 12.45 CU. IN, TENSILE RATING: 310,000 LBF,
COMPRESSIVE RATING: 200,000 LBF, MIN. INTERNAL FLOW AREA: 5.94 SQ.IN,
FLOW AREA BETWEEN OD OF HVC AND ID OF 7 IN. 32# CASING (6.094 ID): 4.83
SQ IN, TOTAL(2.68 SQ. IN. DUE SLOTS), FLOW TRIM CHOKE SETTINGS BASED ON
TOOL ID OF 2.75: 11 POSITIONS (1 X FULLY OPEN, 1 X FULLY CLOSED, 9 X FIXED)
0%, 3%, 4%,6%, 10%, 14% 19%,24%, 43%, 83%, 116%, COIL TUBING SHIFTING
TOOL: 290HM0275000, SPAECIAL NOTES: 2 BYPASS SLOTS, ASSY PICTORAL/ BOM
DRAWING: 312557-10-01, TECH DOC: 312025-00-01
1000780057

Material Number
9COM/9CAT
425
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X3-
1/2,NVAM,9.2#,41XX,FTHRU
PACKER PRODUCTION; MULTI-PORT, HYDRAULIC SET, RETRIEVABLEMILLABLE
TYPE,HYDRAULIC SET ACTIVATI,5.992 IN OD MAX. OD,2.940IN ID MIN. WITH 0.350
IN. OFFSET ID,7.000 IN OD,26-29LB/FT,3-1/2 IN. 2.9 PPF NEW VAM BOX X PIN
CONNECTN,2.9 PPF (TOP)X 2.9 PPF(BOTTOM),NEW VAM BOX X PIN
COONECTN,5,000 PSI IWPSUPPLY,EXTERNAL WP: 5000 PSI @ 250OF, DRIFT ID:
2.920 IN,MATERIALS: ELASTOMERS: NITRILE, ELEMENTS: CENTER: HNBR
(80DURO), END: HNBR (90 DURO)/316SS WIRE MESH FLOW WETTED:4130/4140
O-RINGS: HNBR (90 DURO) TEMP. RATING: 250OF THISMULTI-PORT PACKER
NEEDS 3,000 TO 3,500 PSI PRESSURE DIFFERENTIALAT THE PACKER AGAINST A
PLUG LOCATED BELOW THE SETTING PORTS OFTHE PACKER. THE HYDRAULIC
PRESSURE ENTERS A PORT IN THE MANDRELRELEASING THE TRIPPING PISTON
AND UNLOCKING THE ANTI-PRESETMECHANISM. A FURTHER INCREASE IN
TUBING PRESSURE SHEARS THESHEAR PINS IN THE LOWER CONE, ALLOWING
PISTON TO STROKE THESEALING ELEMENT WHILE WHILE THE SLIPS REMAIN
RETRACTED. SETTINGIS COMPLETED WHEN SUFFICIENT FORCE IS APPLIED TO
ANCHOR THEUPPER TEETH, THEN THE LOWER TEETH OF THE SLIPS. THE
RACHETRINGRETAINS THE SETTING FORCE. ALL SETTING CHAMBERS ARE
ISOLATEDBELOW THE PACKING ELEMENT SYSTEM- THIS ELIMINATES THE
POTENTIALFOR A LEAK PATH THROUGH THE SETTING MECHANISM. APPLYING
STRAIGHTPULL RETRIEVES THE PACKER. WHEN THE TENSION REACHES THE
PRESETVALUE AT THE PACKER, THE SHEAR RING IS SHEARED ALLOWING
THEMANDREL TO MOVE UPWARD AND THE OUTER PARTS OF THE PACKER
TORELAX FROM THE CASING WALL. SUBSEQUENT PULL WILL STROKE THEOUTER
PARTS, PERMITTING THE RETRIEVAL OF THE PACKER.
1000782736

Material Number
9COM/9CAT
426
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,NVAM,12.6#,S13CR,RET
PACKER, PRODUCTION: "PREMIER",RETRIEVABLE, H2S, HYDRAULIC SET, 5.875IN
OD, 3.875 IN ID, 7 IN CASING OD,PACKER PRODUCTION; "PREMIER", RETRIEVABLE
TYPE,FOR H2S,HYDRAULICSET ACTIVATI,5.875 IN OD,3.875 IN ID,7 IN OD,23-26
LB/FT,4-1/2IN (TOP) X 4-1/2 IN (BOTTOM) CONNECTN,12.6 LB/FT,NEW VAM
BOX(TOP) X PIN (BOTTOM) COONECTN,7,500 PSI SUPPLY,NACE-01-75,L-80PACKER
AND PBR MATERIAL, 9CHROME-1MOLY SEAL ASSEMBLY MATERIAL ASPER NACE-
01-75, 18-22 RC, PACKER NITRILE ELASTOMER.PACKER, PRODUCTION:
"PREMIER",RETRIEVABLE, H2S, HYDRAULIC SET, 5.875IN OD, 3.875 IN ID, 7 IN
CASING OD,PACKER PRODUCTION;"PREMIER", RETRIEVABLE TYPE,FOR
H2S,HYDRAULICSET ACTIVATI,5.875 IN OD,3.875 IN ID,7 IN OD,23-26 LB/FT,4-
1/2IN (TOP) X 4-1/2 IN (BOTTOM) CONNECTN,12.6 LB/FT,NEW VAM BOX(TOP) X
PIN (BOTTOM) COONECTN,7,500 PSI SUPPLY,NACE-01-75,L-80PACKER AND PBR
MATERIAL, 9CHROME-1MOLY SEAL ASSEMBLY MATERIAL ASPER NACE-01-75, 18-
22 RC, PACKER NITRILE ELASTOMER.
1000669724
427
Drilling Equipment
(Downhole
Equipment)
CONNECTOR,HYD,4-1/2,WET
MATE,2PORT,AFLAS
LINE; HYDRAULIC LINE TYPE,SIZE 4-1/2 INCH,AFLAS,4 1/2 INCHHYDRAULIC LINE
WET MATE CONNECT SYSTEMKIT COMPONENTS 1000888235
428
Drilling Equipment
(Advanced Well
Completion
Equipment)
GAUGE
ASSEMBLY; MONITORING TYPE,PERMANENT DOWNHOLE, DUAL, 4-1/2 IN KIT
COMPONENTS
1000757804
429
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,VTHC,15.1#,S13CR
PACKER PRODUCTION; ONE TRIP COMPLETION TYPE,FOR
CO2,HYDRAULICACTIVATI,5.750 IN OD,3.743 IN ID,7 IN OD,32 - 35 PPF,4-1/2
INCONNECTN,15.10 PPF,VAM TOP HC BOX-PIN COONECTN,100 - 300 DEG F,9020
PSI SUPPLYKITS COMPONENTS
1000840278
430
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,NVAM,12.6,#,4140,HYD
PACKER PRODUCTION; 'QHSB' TYPE,FOR H2S, CO2,HYDRAULIC SET ACTIVATI,5.875
IN OD,3.875 IN ID,7 IN OD,26-29 LB/FT,5.250-4TPI LEFT HAND SQUARE THREAD
(TOP) X 4-1/2 IN 12.6# L-80 NEW VAM PIN DOWN CONNECTN,12.6 LB/FT
(BOTTOM),LEFT-HAND SQUARE THREAD (TOP) COONECTN,6,000 PSI
SUPPLY,NACE MR 01-75,CARBON STEEL 4140 FLOW WETTED AFLAS ELASTOMER
KIT COMPONENTS
1000731568

Material Number
9COM/9CAT
431
Drilling Equipment
Cementing
Equipment)
DV TOOL,9-5/8",LTC,36-
40#,L80,MEC
COLLAR: PACKER; INFLATABLE; MODEL (781 POST) F/9-5/8 IN. OD 36 TO 40 LB/FT
CASING; W/API 5B LTC THREAD COLLAR PACKER; INFLATABLE TYPE,FOR
CEMENTING,MULTI STAGE,L-80 CASING,9-5/8 IN INSIDE O,36-40 LB/FT,13-3/8 IN
OUTSIDE,61.0-72.0 LB/FT OUTSIDE,8RD LTC BOX & LTC PIN THD TERMINAL,11-3/4
IN TOOL OD,8.75 IN ID DRILL OU,16 IN EXPANSIO,BOTTOM PLUG 1ST,FREE FALL
PLUG 2ND,API 5B,FREE FALL PLUG SET CONSISTS OF SHUT-OFF BAFFLE & PLUG
AND FREE FALL OPENING CONE & CLOSING PLUG, PACKED TO CUSTOMER SPECS
PACKING SPEC 844418 APPLIES KITS COMPONENTS
1000022888
432
Drilling Equipment
(Downhole
Equipment)
KIT,TIEBACK,9-
5/8",VTOP,53.5#,TBR,MDISK
PACKER PRODUCTION; 9-5/8 IN, 53.5 PPF X 14 IN, 114 PPF, 10K PSI BAKER LINER
TOP PACKER ASSEMBLY. KIT COMPONENTS 1000830500
433
Drilling Equipment
(Downhole
Equipment)
COUPLING,FLOW,4-
1/2,VTHC,9CR1MO,3.731"ID
COUPLING: FLOW, KHUFF, 4-1/2 IN 15.10 LB/FT, 9% CHROMIUM - 1%
MOLYBDENUM, API 5CT, API 5C2, NACE MR-01-75 (LATEST COUPLING; FLOW,
KHUFF TYPE,SIZE 4-1/2 IN 15.10 LB/FT,9% CHROMIUM - 1% MOLYBDENUM,API
5CT,API 5C2 NACE,MR-01-75 (LATEST EDITI,5.041" OD X 3.731" ID X 5' LG, VAM
TOP HC BOX X PIN THD, H2S & CO2 SERVICE, BURST PRESSURE: 10,480 PSI,
(CALCULATED) COLLAPSE PRESSURE: 11,080 PSI, (CALCULATED) PRESSURE
RATING: 9,600 PSI.
1000648887
434
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,9-5/8X3-
1/2,NVAM,9.2#,FTHRU
PACKER PRODUCTION; MULTI-PORT, HYDRAULIC SET, RETRIEVABLE MILLABLE
TYPE,HYDRAULIC SET ACTIVATI,8.445 IN OD MAX. OD,2.940 IN ID ID,9-5/8 IN
OD,43.5-47 LB/FT,3-1/2 IN. 9.2 PPF NEW VAM BOX (TOP) X 3-1/2 IN. 9.2 PPF NEW
VAM PIN (BOTTOM), CONNECTN,9.2 PPF X 9.2 PPF(TOP X BOTTOM),NEW VAM
BOX X PIN COONECTN,5,000 PSI IWP SUPPLY,EXTERNAL WP: 5000 PSI @ 250OF,
DRIFT ID: 2.925 IN, MIN. ID: 2.935 IN, MATERIALS: ELASTOMERS: NITRILE,
ELEMENTS: NITRILE FLOW WETTED: 4130/4140, O-RINGS: NITRILE, TEMP.
RATING: 250OF MAX. HYDROSTATIC PRESS.: 4200 PSI MAX. @ 250OF OA LENGTH:
98 IN. SETTING DIFF. PRESS.: 3800 PSI MIN. THIS MULTI-PORT PACKER NEEDS
3,000 TO 3,500 PSI PRESSURE DIFFERENTIAL AT THE PACKER AGAINST A PLUG
LOCATED BELOW THE SETTING PORTS OF THE PACKER. APPLYING STRAIGHT PULL
RETRIEVES THE PACKER. WHEN THE TENSION REACHES THE PRESET VALUE AT
THE PACKER, THE SHEAR RING IS SHEARED ALLOWING THE MANDREL TO MOVE
UPWARD AND THE OUTER PARTS OF THE PACKER TO RELAX FROM THE CASING
WALL. SUBSEQUENT PULL WILL STROKE THE OUTER PARTS, PERMITTING THE
RETRIEVAL OF THE PACKER.
1000782735

Material Number
9COM/9CAT
435
Drilling Equipment
Cementing
Equipment)
DV TOOL,9-
5/8",NK3SB,53.5#,110,HYD
CEMENTER; HYDRAULIC TYPE,9-5/8 IN OD,53.5 PPF WT,TENARIS HYDRIL
3SB,11.700 IN TOOL OD,8.500 IN DRILL OD,9-5/8 IN X 13-3/8 IN, 86 PPF
HYDRAULIC MID STRING ZX PACKER TWO STAGE CEMENTING SYSTEM WITH PAC
VALVE SYSTEM KIT COMPONENTS
1000885435
436
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,16X18-
5/8,ABF,84#,L80,HYD
HANGER LINER; HYDRAULIC ACTIVATI,GR L-80,16 IN END 1,84 PPF END 1,18-5/8
IN END 2,87.5 PPF END 2,ANTARES BIG FLUSH,TIW IB-TC R HYDRO-HANGER
ASSEMBLY WITH LX LINER PACKER WITH RPOB AND HD CEMENT MANIFOLD FOR
16 IN 84 PPF BY 18-5/8 IN 87.5 PPF LINER. KIT COMPONENTS
1000882677
437
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,VTHC,32#,625,HYD
HANGER LINER; HYDRAULIC ACTIVATI,7 IN END 1,32 PPF END 1,9-5/8 IN END
2,58.4 PPF END 2,7 IN, 32 PPF VAM TOP HC BOX DOWN END CONN,7 IN X 9-5/8
IN 58.4 PPF LOWER COMPLETION FOR HASBAH. MATERIAL: NICKLE ALLOY 625
PLUS. KIT COMPONENTS
1000891392
438
Drilling Equipment
(Downhole
Equipment)
NIPPLE,LANDING,4-
1/2",VTHC,R,3.688"ID
NIPPLE, LANDING: TYPE R, 9% CHROMIUM - 1% MOLYBDENUM, 80K, H2S AND
CO2, API 14L/ISO 16070, API Q1/ISO 9001. NIPPLE LANDING; R TYPE,9%
CHROMIUM - 1% MOLYBDENUM,80K,FOR H2S & CO2,API 14L/ISO 16070, API
Q1/ISO 9001 COONECTN,POLISHED BORE,3.688 IN ID,5.041 OD,18.37 IN LG,4-1/2
IN TUBING OD,15.10 LB/FT,VAM TOP HC BOX X PIN,API 14L/ISO 16070, API
Q1/ISO 9001,MADE TO NACE MR-01-75 (LATEST EDITION), BURST PRESSURE:
10,480 PSI (CALCULATED) COLLAPSE PRESSURE: 11,080 PSI (CALCULATED)
PRESSURE RATING: 9,600 PSI
1000648889
439
Drilling Equipment
Cementing
Equipment)
DV TOOL,9-
5/8",NK3SB,53.5#,T95HCHS,MEC,
4
COLLAR: PACKER; INFLATABLE; MODEL (781 POST) F/9-5/8 IN OD 53.5 LB/FT
CASING, W/4 FT ELEMENT, NK-3SB THD, BOX X PIN COLLAR PACKER; INFLATABLE
TYPE,FOR CEMENTING,MULTI STAGE,T-95HCHS CASING,9-5/8 IN INSIDE O,53.5
LB/FT,13-3/8 IN OUTSIDE,86 LB/FT OUTSIDE,NK-3SB BOX & NK-3SB HC PIN THD
TERMINAL,11.75 IN TOOL OD,8.50 IN ID DRILL OU,15.50 IN EXPANSIO,API
5B,EACH POST TOOL MUST BE BOXED AS INDIVIDUAL UNTS FOR SHIPMENT AND
STORAGE THIS TOOL DOES NOT HAVE A PLUG SET WITH IT. PACKED TO SAUDI
ARAMCO SPECS. PACKING SPEC 844418 APPLIES KITS COMPONENTS
1000609476

Material Number
9COM/9CAT
440
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,4-
1/2X7,VTHC,13.5,41XX,32#
HANGER LINER; 4-1/2 IN END 1,13.5 LBS END 1,7 IN END 2,29-32 LBS END 2,VAM
TOP HC END CONN,VLH BDY ASSY ,5,7,29-32,87 OD,VTN LINER HANGER TYPE :
STANDARD CASING SIZE : 7 CASING WEIGHT : 29.0:32.0 MATERIAL : 41XX LOW
ALLOY STEEL ELEMENT MATERIAL : RUBBER TEMPERATURE RATING SERVICE : 40
TO 275 SERVICE : STD BOTTOM THREAD : 5- 18.00 VAM TOP-HT CONNECTION
TYPE : PIN BOTTOM THREAD MAKE-UP TORQUE : 10500( OPTIMUM) (FT-LBS):
9500( MINIMUM), : 11500(MAXIMUM) FOR 5-18.00 VAMTOP-HC MAKE-UP
TORQUE ,LINER HANGER : 1700 (MINIMUM) 1865(OPTIMUM) BODY #UPPER (FT-
LBS) 2035 (MAXIMUM) FOR 5.607 HST-DS MAKE #UP TORQUE,LINER : 4850 (
MINIMUM) HANGER : 5340 ( OPTIMUM) BODY-LOWER (FT- LBS) : 5820
(MAXIMUM) FOR 5.366 HST-DS MAKE-UP TORQUE, SETTING : 4850 ( MINIMUM)
SLEEVE- UPPER ( FT-LBS) : 5340 (OPTIMUM) FOR 5.366 HST-DS MAKE #UP
TORQUE,SEETING : 5300( MINIMUM) SLEEVE-LOWER (FT- LBS : 5840(OPTIMUM ) :
6360(MAXIMUM) : FOR 5.366 HST-DS MAXIMUM OD : 5.885 INCH 149.479MM
MAXIMUM OD REMARKS : UPPER SETTING SLEEVE MAXIMUM OD (TIE-BACK
RECEPTACLE : 5.880 IN 149.352 MM NOMINAL OD ( ELASTOMERS) : 5.870 INCH
149.098MM ID-MIN (TIE-BACK RECEPTACLE) : 5.246 IN 133.248 MM SEAL BORE
LENGTH-MAX(TIEBACK RECEPTACLE : 94.996 IN 241.29 CM MAXIMUM OD (
SETTING SLEEVE ) : 5.885 INCH 149.479 MM NOMINAL ANNULAR BYPASS :
2.973(7, 29), AROUND : 2.105(7,32) LINER HANGER (SQ.INCHES) : MINIMUM ID :
4.213 INCH 107.01 MM MINIMUM ID REMARKS : LOWER SETTING SLEEVE
NOMINAL LENGTH : 255.31 INCH SETTING PRESSURE : 6829 PSI (7,29), : 5752 PSI
(7,32) BURST PRESSURE ABOVE : 8191 PSI 56475 KPA ELASTOMERS (CALC) BURST
PRESSURE ABOVE ELASTOMERS REMARKS: PBR WALL OF BODY COLLAPSE
PRESSURE ABOVE ELASTOMERS (CALC) : 7821 PSI 53924 KPA COLLAPSE PRESSURE
ABOVE ELASTOMERS REMARKS : PBR WALL OF BODY TENSILE RATING ABOVE
ELASTOMERS (CALC) : 178054 POUND 80764 KPA TENSILE RATING ABOVE
ELASTOMERS REMARKS: BODY UPPER THREADS BURST PRESSURE BELOW
ELASTOMERS CALC : 9377 PSI 64652 KPA BURST PRESSURE BELOW ELASTOMERS
REMARKS : BODY LOWER THREADS COLLAPSE PRESSURE BELOW ELASTOMERS
(CALC) : 10263 PSI 70761 KPA COLLAPSE PRESSURE BELOW ELASTOMERS REMARK
1000828970
441
Drilling Equipment
Cementing
Equipment)
COLLAR,STOP,7",SLIPON,2.000",
DHP
COLLAR CASING STOP; SLIP-ON, SPIR-O-LOK, 7 IN TYPE,FOR POSITIONING
CENTRALIZERS,INTERNAL DIA.: 7.125 INCH, OUTSIDE DIA.: 8.00 INCH, LENGTH: 2
INCH, NO. OF SCREWS: 8 EACH, SIZE OF SCREW: 1/2 INCH DIA., MATERIAL: CAST
DUCTILE IRON, FOR 7" X 8-1/2" SPIR-O-LIZER CENTRALIZER,
1000803586

Material Number
9COM/9CAT
442
Drilling Equipment
(Downhole
Equipment)
PBR/SEAL,4-
1/2",VTOP,15K,41XX,30 FT
SEAL; LOWER PBR TYPE,SIZE 4-1/2 IN,41XX LOW ALLOY STEELKIT COMPONENTS
1000898876
443
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,NVAM,26#,47-53.5#
HANGER LINER; MECHANICAL ACTIVATI,FOR STD,7 IN 26# NEW VAM END
CONN,MAXIMUM OD (ELASTOMERS) 8.325 IN ID-MIN (TIE-BACK
RECEPTACLE)116.50 IN MAXIMUM OD (SETTING SLEEVE)8.325 IN MAXIMUM ID
6.745 IN MINIMUM ID REMARKS,SETTING SLEEVE NOMINAL LENGTH 346.6 IN
SETTING PRESSURE 3902(47 LBS),2792(53.5 LBS) BURST PRESSURE ABOVE
ELASTOMERS(CLAC)6483 BURST PRESSURE ABOVE ELASTOMERS REMARKS PBR
WALL OF BODY COLLAPSE PRESSURE ABOVE ELASTOMERS (CALC)4530 PSI
COLLAPSE PRESSURE ABOVE ELASTOMERS (CALC) PBR TENSILE RATING ABOVE
ELASTOMERS (CALC)30865 LNR HGR BDY ASSY, VLH, POUND 7-5/8,9-5/8,53.5-47.
LINER TENSILE RATING ABOVE ELASTOMERS (CALC) HANGER TYPE,STANDARD
CASING BODY UPPER THREAD SIZE 9-5/8,9-7/8. BURST MATERIAL,41 XX LOW
ALLOY PRESSURE BELOW ELASTOMERS STEEL. ELEMENT (CALC) 8761 PSI
MATERIAL,FLUOROCARBON BURST RUBBER. PRESSURE BELOW ELASTOMERS
TEMPERATURE RATING 40:275. REMARK 7.583 HST-DS BOX SERVICE THRAD
COLLAPSE PRESSURE STD BELOW ELASTOMERS(CALC)8340 BOTTOM THREAD
7.5/8-33.70 NEW VAM. PSI . COLLAPSE PRESSURE CONNECTION TYPE PIN BELOW
ELASTOMERS REMARKS BOTTOM THREAD MARK-UP (CALC). TORQUE (FT-LBS)
12700(MINIMUM),14100. BOTTOM THREADS (OPTIMUM),15500(MAXIMUM)FOR
7"IN 26# NEW VAM PIN 7-5/8-33.7 NEW VAM . TENSILE RATING BELOW ELAS
MAXIMUM OD 8.375 IN MAXIMUM OD REMARKS GAUGE RING OD MAXIMUM
OD (TIE-BACK RECEPTACLE)8.325 IN
1000791668
444
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,4-
1/2X8.50"OH,SLIPON
PACKER PRODUCTION; RESPACK TYPE,SWELLABLE ACTIVATI,8.150 INOD,5.654 IN
ID,5.5 IN OD,OPEN,OPEN CONNECTN,OPEN,OPENCOONECTN,OPEN HOLE SIZE:
8.500 IN. PACKER LENGTH: 18 IN.EXTERNAL ELEMENT THICKNESS (SWELLING
RUBBER): 1.166 IN. SUPPORTTUBE THICKNESS (CARBON STEEL): 0.100 IN. INNER
ELEMENT THICKNESS(SWELLING RUBBER): 0.180 IN. END RING LENGTH: 1.750 IN.
END RINGOD: 8.150 IN. END RING ID: 5.579 IN.
1000875949

Material Number
9COM/9CAT
445
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,NVAM,26#,L80,HYD
HANGER LINER; HYDRAULIC ACTIVATI,GR L-80 & P-110 CASING,7 IN END 1,26
LB/FT END 1,9-5/8 IN END 2,36-43.5 LB/FT END 2,NEW VAM END CONN,SMITH
SERVICE 7 IN HYDRAULIC SET LINER HANGER, SIZE 7 IN. 26# X 9-5/8 IN. 36-43.5#
MODEL "HCDC" HYDRAULIC SET LINER HANGER WITH "SATM" SETTING ADAPTER,
6 FT LONG TIE-BACK RECEPTACLE. CONSIST OF: ITEM NO. QUANTITY DESCRIPTION
01 01 MODEL #HCDC# SOLID BODY, DUAL CONE HYDRAULIC SET LINER HANGER,
7 IN. 26# NEW VAM BOX X PIN.HANGER O.D. 8.250 IN. I.D. 6.276 IN. L-80
MATERIAL. FIELD ADJUSTABLE SHEAR: 1220-3000 PSI PART NUMBER:
HCDC373601044LE 02 01 MODEL #BC# BALL SEAT LANDING COLLAR WITH 7 IN.
26# NEW VAM BOX X PIN CAST IRON BALL SEAT, L-80 MATERIAL. FIELD
ADJUSTABLE SHEAR: 1200-3000 PSI. PART NUMBER: BC44997044LE 03 01 MODEL
#FC# FLOAT COLLAR WITH 7 IN. 26# NEW VAM BOX X PIN, SINGLE FLAPPER VALVE
CAST IRON INSERT, L-80 MATERIAL. PART NUMBER: FC4498949044LE 04 01
MODEL #FS# FLOAT SHOE WITH 7 FT. 26# NEW VAM BOX, DOUBLE FLAPPER
VALVE CAST IRON INSERT, L-80 MATERIAL. PART NUMBER: FS44989590044LE 05
01 MODEL #LWPC# LINER WIPER PLUG WITH ANTI ROTATIONAL LOCK NOSE, PDC
DRILLABLE, MATERIAL NITRILE, ALUMINIUM T-6061. PART NUMBER:
LWPC49004N 06 01 MODEL #PDPC# DRILL PIPE PUMP DOWN PLUG WITH ANTI
ROTATIONAL LOCK NOSE, PDC DRILLABLE SUITABLE FOR 5 IN. 19.5# DRILL PIPE.
MATERIAL NITRILE ALUMINIUM T-6061. PART NUMBER: PDPC50004N
1000771959

Material Number
9COM/9CAT
446
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,4-
1/2X7,TB,15.2#,125,HYD
HANGER LINER; HYDRAULIC ACTIVATI,4 1/2 INCH END 1,15.2 PPF END1,7 INCH
END 2,35 PPF END 2,TENARIS BLUE END CONN,4 1/2 INCH,15.2 PPF, TENARIS
BLUE PIN X PIN.,4 1/2 INCH BAKER LINER HANGEREQUIPMENT FOR DEEP GAS
EXPLORATION WELLS, CONSISTING OFFOLLOWING: 1) LINER HANGER ASSEMBLY :
4 1/2 INCH, 15.2 PPF X 7INCH, 35 PPF, MODEL FLEX-LOCK III, AS FOLLOWS: 1.01
(QTY 1)BAKER HYDRAULIC SET MODEL 'FLEX-LOCK III. SIZE : 4 1/2 INCH,15.2 PPF X
7 INCH, 35 PPF. MAX OD : 5.625 INCH. MIN ID :3.800INCH. MIN DRIFT ID : 3.750
INCH. MAX LOAD CAPACITY :600,000 LBS, INSIDE 7 INCH, 35 PPF. TENSILE LOAD :
414,625 LBS.YIELD PRESSURE : 15,380 PSI. COLLAPSE PRESSURE : 14,430
PSI.LENGHT : 10 FT LONG. THREADS : 4 1/2 INCH, 15.2 PPF, TENARISBLUE PIN X
MYS CR-MO LOW ALLOY PIN. MATERIAL : => 125 KSISTEEL,FOR SERVICE IN H2S
ENVIROMENTAT TEMP _> 225 DEG F.THISWILL BE FOR ALL THE MATERIAL L/I 3.01
TO 3.09. MATERIAL NO :H2941001XX. BRONZE SETTING BALL. MATERIAL NO :
HWX17398XX. 1.02(QTY 1) BAKER MODEL 'ZXP' LINER TOP PACKER C/W HOLD
DOWN SLIPS,HR 20 FT PBR XYLAN-1052 COATED, FOR USE WITH 41/2 INCH
HRRUNNING TOOL, HONNED ID X 15FT LONG. SIZE : 4 1/2 INCH, 15.2PPFX 7 INCH,
35 PPF. EXTENSION SIZE : 5.750 INCH OD X 5.000 INCH.MAX PACKER OD : 5.789
INCH. MIN ID : 3.800 INCH. MIN DRIFT ID :3.750 INCH. INT YIELD PRESSURE :
16,380 PSI. COLLAPSE PRESSURE :15,840 PSI. TENSILE LOAD : PACKER ELEMENT
RATING : 13,000 PSI @400 DEG F, 352,825 LBS W/110MYS. QUALIFIED TO ISO
14310 V-0,ELEMENT SHALL FURTHER EXHIBIT NO (ZERO) SEAL DAMAGE WHEN
EXPOSEDTO HIGH CIRCULATION RATES UPTO 15 BPM WITH CONDITIONS
REFERENCEDIN API RP 10F-CAT IIIC. THREAD : 4 1/2 INCH, 15.2 PPF, TENARISBLUE
BOX DOWN. MATERIAL NO : H2962803XX. 1.03 (QTY 1). BAKERDRILLABLE PACK
OFF BUSHING. SIZE : 4 1/2 INCH, 15.2 PPF, TENARISBLUE PIN UP X#BOX DOWN.
MATERIAL NO : H28205XXXX. 1.04 (QTY 1).BAKER PLUG HOLDER BUSHING. SIZE :
4 1/2 INCH, 15.2 PPF, TENARISBLUE BOX UP X PIN DOWN. 1.05 (QTY 1). BAKER
TYPE II LANDINGCOLLAR BALL SEAT. SIZE : 4 1/2 INCH, 15.2 PPF, TENARIS
W/BAFFLEPLATE AND CERAMIC BLUE BOX UP X PIN DOWN. MATERIAL NO
:H2665512XX. 1.06 (QTY 1). BAKER DOUBLE VALVE FLOATCOLLAR
W/CASTALUMINUM VALVES, MUST MEET API RP 10F. SIZE : 4 1/2 INCH, 15.2PPF,
1000844953

Material Number
9COM/9CAT
447
Drilling Equipment
Cementing
Equipment)
DV TOOL,18-5/8",TN
ER,136#,L80,MEC
COLLAR; STAGE CEMENTER TYPE,SIZE 18-5/8 IN,TENARIS HYDRIL,STAGE TOOL,
COLLAR, TYPE P ES INFLATABLE PACKER, TYPE: ESIPC-P WITH METAL BLADDER
PACKER, CASING SIZE: 18-5/8 IN, CASING THREADER: TENARIS HYDRIL, CASING
THREAD: ER, CASING WEIGHT: 136 PPF, CASING GRADE: L-80, NOMINAL OD:
20.800 IN, MIN CASING ID: 17.219 IN, LENGTH: 75.76 IN, OPENING: 330 PSI, 2ND
OPENING: 1,450 PSI, CLOSING: 490 PSI, BURST: 5,435 PSI, COLLAPSE: 5,435 PSI,
TENSILE: 3,164,352 LBS.WITH COMPLETE SET OF FREE FALL PLUG SET
1000844376
448
Drilling Equipment
Cementing
Equipment)
SHOE,FLOAT,24",JVLW,176#,X52,
ISC
SHOE FLOAT; GR X-52,24 IN OD,176 LB/FT,JVLW BOX CONNECTN,API 5B,22.2450
IN DRILL ID, WITH SS3 VALVE AND ISC PROFILE AND 5.5 IN X 5 IN DRILL PIPE
DISPLACEMENT DART "PDC DRILLABLE" 1000736311
449
Drilling Equipment
(Downhole
Equipment)
29#,HYD,1.98DG
WHIPSTOCK; SHALLOW ANGLE QUICK CUT (SAQC) TYPE,5-1/2 IN OD BODY
STD,ONE TRIP, RETRIEVABLE TRIP,7 IN CSNG DRE,23-29 LB/FT CSNG
DRE,SHALLOW ANGLE QUICK CUT, HYDRAULIC SET, RETRIEVABLE TYPE, WITH
PACKER, FOR 7 IN. 23-29 LB/FT. FACE LG, OVERALL LG OF 20.4 FT.
1000787908
450
Drilling Equipment
(Downhole
Equipment)
PBR/SEAL,2-
7/8",EUE,6.4#,9CR,10FT
RECEPTACLE: POLISHED BORE; 2.330 IN MIN ID, 3.80 IN MAX OD, 10 FT STROKE,
F/2-7/8 IN 6.4 LB/FT TUBING, TO BE USED ON 4-1/2 IN AND 5 IN ‘TWR’ PACKER
WITH MATERIAL NUMBERS 10000025174 AND 1000589638. RECEPTACLE; PBR
TYPE,SIZE 2.33 IN ID X 3.80 IN OD X 17.5 FT LG,ALLOY STEEL,NACE MR-01-75-
97,AA 8 RD EUE PIN, H2S SERVICE KITS COMPONENTS
1000589639
451
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
HANGER: LINER ASSEMBLY; HORIZONTAL; 7 IN. 26 LB/FT VAM X 9-5/8 IN. 36.0 TO
47.0 LB/FT; L-80 MATERIAL; TEXAS IRON HANGER LINER; HYDRAULIC
ACTIVATI,FOR HORIZONTAL & HIGH ANGLE COMPLETIONS,GR L-80,7 IN END
1,26.0 LB/FT END 1,9-5/8 IN END 2,36.0-47.0 LB/FT END 2,STUB ACME BOX UP X
NEW VAM PIN DOWN END CONN,TEXAS IRON WORKS TYPE "RP" & "IB-SC-R",
SINGLE CONE, COMPLETE ASSEMBLY MUST BE BOXED AS AN INDIVIDUAL UNIT
WITH COMPONENTS AS SPECIFIED IN KITS SECTION KITS COMPONENTS
1000024133

Material Number
9COM/9CAT
452
Drilling Equipment
(Advanced Well
Completion
Equipment)
PANEL,CONTROL,HYD-
ELE,1WELL,4VALVE,AUTOM
PANEL; CONTROL, HYDRAULIC TYPE,SS AISI 316,NEMA 4X, POWER
REQUIREMENT: 110 VAC, 4 KW, SCADA COMPATIBLE, REMOTELY OPERATED
ELECTRICALLY DRIVEN FOR IWC, CAPABLE OF OPERATING 4 VALVES, AND
MONITORING PDHMS IN 1 WELL, SCADA COMMUNICATION PROTOCOL: MODBUS-
485 OR ETHERNET, MAX PRESSURE: 10000 PSI, TEMPERATURE RATING: 55 DEG C
(UNDER SHELTER), HYDRAULIC TANK CAPACITY: 30 GAL., FLOW CONTROL VALVE:
SCHLUMBERGER TRFC-HN, PUMP FLOW RATE: 1 L/MIN (MAX), FULLY
COMPATIBLE WITH SAUDI ARAMCO I-FIELD REQUIREMENTS THE SURFACE UNIT
SHALL BE E WITH DRAIN VENT CONNECTIONS ARAMCO SAES-J-902. SURFACE
UNIT SHALL DISPLAY VIA ELECTRONIC VISUAL DISPL CRYSTAL DISPLAY (LDC) TO
DO LOCALLY
1000824566
453
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,4-
1/2,NVAM,11.6#,250MC
SCREEN; SIZE 4-1/2 IN,316L/304SS,MESH-SCREEN TYPE, MAX LENGTH: 41 FT, 11.6
PPF, RANGE 3, THREAD CONNECTION: NEW VAM BOX X PIN, RESTICTOR
MODULE: ADJUSTABLE, TOOL MAX OD: 5.625 IN, TOOL MIN ID: 3.939 IN, BASE
PIPE MATERIAL: L-80, SCREEN LENGTH: 20 FT, SCREEN: 250 MICRON NOMINAL,
ICD AND SCREEN MATERIAL: 316L/304SS.
1000818229
454
Drilling Equipment
Cementing
Equipment)
DV TOOL,18-5/8",BIG
OMEGAIS,136#,L80,MEC
CEMENTER; SET, ESIPC TYPE,18-5/8 IN OD,136 LB/FT WT,BIG OMEGA IS,GRADE: L-
80, TYPE P ES INFLATABLE PACKER COLLAR WITH METAL BLADDER PACKER AND
TWO-STAGE FREE-FALL PLUG SET, WITH 9.81 ID INSERT BAFFLE ADAPTER, WITH
COMPOSITE FREE-FALL OPENING PLUG.THIS DV SHOULD BE WITH 3,000 PSI
(MINIMUM) DIFFERENTIAL PRESSURE & WILL BE DEPLOYED @+/- 5,000-FT.
1000830134
455
Drilling Equipment
(Advanced Well
Completion
Equipment)
SCREEN,4-
1/2,NK3SB,13.5#,250MIC,S13CR
SCREEN; SIZE 4-1/2 IN,S13CR STAND ALONE, SAND CONTROL SCREENS FOR GAS
WELLS SHOULD MEET OR EXCEED FOLLOWING SPECIFICATION, BASE PIPE, SIZE
AND WEIGHT: 4 1/2 IN, 13.5 PPF, RANGE 3, MIN YIELD STRENGTH: 95,000 PSI,
MIN TENSILE STRENGTH: 105,000 PSI, SUPER 13 CHROME, NK3SB CASING
THREADS (BOX AND PIN CONNECTION), SCREEN /FILTER MEDIA/ WEAVE,
NOMINAL 250 MICRON WEAVE, ALLOY 20 OR INCONEL 825, TWO SCREEN
SUPPORTING LAYERS (INNER JACKET/ DARINAGE LAYER), ALLOY 20 OR INCONNEL
825, SHROUD: 304 STAINLESS STEEL. LENGTH: 38-40 FT
1000840500

Material Number
9COM/9CAT
456
Drilling Equipment
(Advanced Well
Completion
Equipment)
ICD-SCREEN,4-
SCREEN; FLOREG ICD WITH 350 MICRON DIRECT WRAP SCREEN TYPE,SIZE 4-1/2
IN,SS316L,GRADE: L-80 BASE PIPE, BASE PIPE SIZE: 4-1/2 IN, BASE PIPE MATERIAL:
SS316L, WITH SLOT AT 0.014" GAUGE OPENING, (SLOT TOLERANCE +0.002 IN, -
0.003 IN). BASE PIPE WEIGHT: 12.6 PPF, BASE PIPE GRADE: L-80, CONNECTION:
NEW VAM PIN X BOX AT 38 FT (+0, -1 FT), SCREEN LENGTH AT 16 FT WITH IN
–FLOW CONTROL DEVICE, HOUSING RETAINING RING: 316L, HOUSING: 13CR-
80KSI, FLOW RING: 316L, THREADED RING: 316L, FLOW PORT MATERIAL:
TUNGSTEN CARBIDE, SET SCREW (5/16 UNF): 316L, O-RING: VITON, DIRECT WRAP
TENSILE: 227,000 LBS, DIRECT WRAP TORQUE: 18,000 FT-LBS, DIRECT WRAP
BURST: 4175 PSI, DIRECT WRAP COLLAPSE: 5,080 PSI.
1000840969
457
Drilling Equipment
(Advanced Well
Completion
Equipment)
CABLE,DOWNHOLE,16AWG,1/4",
INC825,1FT
CABLE; PERMANENT DOWNHOLE TYPE,16 AWG DIA,NICKEL PLATED
COPPER,DOWNHOLE CABLE COMES IN, MINIMUM BEND RADIUS: 1 IN, 1/4 IN, OD
SIZE FOR PDHMS HARDNESS: 250-345 MICRO (HV 500), WEIGHT: 160, SYSTEM
APPLICATION, PHYSICAL LBS/1000 FT, METHOD OF MANUFACTURE: COLD
FORMED, SPECIFICATIONS TUBE: OD: 0.25 IN, WELDED AND ROLL REDUCED,
ELECTRICAL WALL THICKNESS: 0.035 IN, MATERIAL: INC, PROPERTIES:
CONDUCTOR, 825, INSULATOR: RESISTANCE: 4.35 OHMS/1000, SIZE: 2.57 MM
NOMINAL, MATERIAL: TEFZEL (ETFE), OHMS/1000 FT @ 150 DEG C, IP-1300,
FILLER: TUBE RESISTANCE: 15, OHMS/1000 FT @ 20 DEG C, SIZE: 3.86 MM
NOMINAL, 16.8 OHMS/1000 FT @ 150, MATERIAL: DEG C, CAPACITANCE: 27.9, IP-
1030, ENCAPSULATION: DIMENSION: 11 MM X 11 MM, PICO FARDS/FT @ 20 DEG
C, 31.7 PICO FARADS/FT, MATERIAL: NYLON @ 150 DEG C, INSULATION RATING:
6, YIELD RESISTANCE: 15,000 M, STRENGTH: 106,000 PSI, OHMS/1000 FT,
VOLTAGE ULT, TENSILE STRENGTH: 123,000 PSI, COLLAPSE RATING: 1,000 VDC.
MAX, CURRENT: 2.4 A, VELOCITY PRESSURE: >20,000 PSI, BURST PRESSURE:
>29,000 OF PROPAGATION: 69.1, ENCAPSULATION PSI, CRUSH RESISTANCE:
22,300 LBS, SURFACE PROPERTIES: TEMPERATURE, FINISH: 12.9 MICRON,
RATING: 150 DEG C, HARDNESS: 50 (SHORE D), WATER ABSORPTION, (GRAM/1SQ
MM, 0.5 MM THK: 0.45 GRAM (ASTM 96-A,1.61 GRAM (ASTM 96-BW, TENSILE
STRENGTH: 4,003 PSI, ELONGATION: 600%.
1000840502
458
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,4-
1/2",BLADERUNNER,5.750"OD
CENTRALIZER CASING; BLADE RUNNER TYPE,4-1/2 IN X 6-1/8 IN (OD 5-3/4 IN)
CASING,TYPE: SOLID BODY, SLIP ON. BLADES: 5 X SPIRAL RIGHT HAND. MATERIAL:
ZINC-ALLOY/TEFLON. WEIGHT (KG): 4.6. FLOW-BY (SQ INS): 8.12.
1000886160

Material Number
9COM/9CAT
459
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,7",SPIROLIZER,8.25
0"OD
CENTRALIZER CASING; SLIP-ON, SOLID BODY, SPIR-O-LIZER TYPE,7 IN X 8-1/2 IN
CASING,8-1/4 IN BOW OD,STYLE 5-BLADE, SPIRAL,INTERNAL DIA.: 7-1/8 INCH,
WALL THICKNESS: 3/16 INCH, LENGTH: 10 INCH, WEIGHT: 6.10 KG, BLADES: 5 X
SPIRAL, BLADE ANGLE: 25O, BLADE LEAD IN: 2-1/2 INCH, BLADE LEAD OUT: 1-1/2
INCH, MATERIAL: ZINC ALLOY, USE WITH 2 EACH DUCTILE IRON SPIR-O-LOK STOP
COLLARS, WITH MATERIAL NUMBER 1000XXXXX, ITEMS MUST BE BOXED AS AN
INDIVIDUAL UNIT FOR SHIPMENT AND STORAGE PER SAUDI ARAMCO PACKAGING
SPEC 844418. MANUFACTURER MUST BAR CODE IDENTIFY EACH ISSUE UNIT ON
BOTH THE MATERIAL AND OUTSIDE THE CONTAINER IN WHICH THE ISSUE UNIT IS
CONTAINED. CODE TO BE IN THE INTERNATIONAL CODE 39 BAR CODING SYSTEM
FORMAT AND ADHERE TO ANSI MH10.8 ( LATEST EDITION) SPECIFICATION (LESS
SECTIONS 12 & 13). BAR CODE TAG MUST INCLUDE THE SAUDI ARAMCO STOCK
NUMBER AND PURCHASE ORDER NUMBER.
1000803582
460
Drilling Equipment
(Advanced Well
Completion
Equipment)
GAUGE,DUAL PORT
GAUGE; PDHMS-PERMANENT DOWNHOLE MEASUREMENT TYPE,175/150
RANGE,SIZE 3-1/2 IN,INCONEL 718,DAUL AND SINGLE SURE SENS 150 -PDHMS-
PERMANENT DOWNHOLE MEASUREMENT SYSTEM .DUAL TUBING/ANNULUS
GAUGE ASSEMBLY : EUE KIT COMPONENTS
1000908043
461
Drilling Equipment
(Downhole
Equipment)
35#,HYD,1.98DG
WHIPSTOCK; SHALLOW ANGLE QUICK CUT (SAQC) TYPE,5-1/2 IN DIAMETER BODY
STD,HYDRAULIC SET TRIP,7 IN CSNG DRE,23-35 LB/FT CSNG DRE,WEATHERFORD
WHIPSTOCK, QUICK CUT, SHALLOW ANGLE HYDRAULIC RETRIEVABLE TYPE, 5-1/2
IN OD BODY, MULTI-CATCH ANCHOR, 1.98 DEGREE WHIP FACE FOR 7 IN 23-35
LB/FT CASING
1000769303
462
Drilling Equipment
(Downhole
Equipment)
PBR/SEAL,4-
1/2",VTHC,15.1#,41XX-95,24FT
RECEPTACLE: RETRIEVABLE, 5.820 IN X 3.762 IN X 15.1 LB, 4130/4140, 18-22 HRC
EXCEPT LOCATOR, SPACER TOP SEAL RECEPTACLE; RETRIEVABLE TYPE,SIZE 5.820
IN X 3.762 IN X 15.1 LB,4130/4140, 18-22 HRC EXCEPT LOCATOR, SPACER, TOP
SEAL MANDREL, AND PBR B-SUB AD WHICH MUST BE AS FOLLOWS AISI 41XX
W/MODIFIED CHEM F PER API GRADE T-95, 95 KS MIN YIELD, Q & T, 25 HRC MAX
FOR H2S SERVICE PER NACE MR-01-75 (LATEST REV) SSC TEST TM-01777 IS NOT
REQUIRED.,NACE MR-01-75,EACH ASSEMBLY MUST BE BOXED AS AN INDIVIDUAL
UNIT WITH COMPONENTS AS LISTED IN SAMS CATALOG. KITS COMPONENTS
1000025605

Material Number
9COM/9CAT
463
Drilling Equipment
(Downhole
Equipment)
PBR/SEAL,4-
1/2",VTHC,13.5#,41XX-95,25FT
7 IN. X 4 IN. RETRIEVABLE PACKER BORE RECEPTACLE W/INTEGRAL 'KTR' SEAL
ASSY; 4-1/2 IN,13.5 LB/FT VAM TOP HC BOX RECEPTACLE; RETRIEVABLE PACKER
BORE TYPE,SIZE 3.720 IN ID X 5.875 IN OD X 13.5 LB/FT,41XX-95 KSI (25 HRC
MAX), (BMS A-152) HT PLUS Q&T,NACE MR-01-75 (LAST REV.),FOR H2S SVC,FOR
USE W/7 IN. FAB-1 PACKER EACH ASSEMBLY MUST BE BOXED AS AN INDIVIDUAL
UNIT WITH COMPONENTS AS LISTED IN TH SAMS CATALOG, CONSISTING OF
COMPONENTS AS DETAILED IN KITS SECTION. KITS COMPONENTS
1000025604
464
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,4-1/2X9-
5/8,VTHC,13.5#,P110
HANGER LINER; GR P-110,7 IN END 1,32 PPF END 1,9-5/8 IN END 2,53.5 PPF END
2,VAM-SIIJ-II END CONN,VAM-SIIJ-II,X-PAK LINER HANGER EQUIPMENT FOR 7 IN,
32 PPF BY 9-5/8 IN, 53.5 - 58.4 PPF LINER KIT COMPONENTS
1000888136
465
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,4-
1/2X6.125"OH,SLIPON
PACKER PRODUCTION; SLIDE ON PIPE OH SWELL PACKER TYPE,5.625 IN OD,3.958
IN ID,4-1/2 IN OD,NA (SLIDE ON PIPE) CONNECTN KIT COMPONENTS 1000844947
466
Drilling Equipment
(Downhole
Equipment)
PACKER,TIEBACK,7",NK3SB,32#,P
110,TBR12FT
PACKER, LINER: PACKER, LINER TOP, GEN-2 TYPE SN-AT-12 HI-LOAD FOR
DEVIATED & VERTICAL KHUFF GAS WELLS PACKER LINER; PACKER, LINER TOP,
GEN-2 TYPE SN-AT-12 HI-LOAD FOR DEVIATED & VERTICAL KHUFF GAS WELLS
WITH LG-12 TBR KIT COMPONENTS: ITM(1) P/N 621333 PACKER: LINER TOP, TYPE
SN-AT-12 HI-LOAD SLIPS FOR TYPE LG-12 TBR, 7 IN 32# X 9-5/8 IN 53.5 W/NK-3SB
BOX UP, W/6 FT PORTED NIPPLE & FULL MULESHOE BOTTOM, 3 SETS ATR SEALS
FOR 7.375 IN I.D. TBR, W/AFLAS PI-PO PKR (10M PSI DP) AND HOLD DOWN SLIPS,
41XX - 110,000 PSI MIN. YIELD (P-110), 6.094 IN MIN I.D., 6.0 IN DRIFT ID. KITS
COMPONENTS
1000025009
467
Drilling Equipment
(Downhole
Equipment)
SCREEN,WIRE,7",LTC,26#,0.012",I
NJECTION
WELL SCREEN: . . SCREEN; CASING WELL TYPE,304 SS,WIRE WRAPPED, RIBBED,
DRILLED HOLE, 0.012 IN OPENINGS, 24 IN BLANK ON EACH END, TO BE WRAPPED
ON 7 IN OD 26 LB/FT GR J/K-55 8RD LT & C RANGE 2 CASING WITH THD
PROTECTORS INSTALLED ON ON BOTH ENDS BEFORE SHIPMENT
1000032752
468
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,13-
3/8",BOWSPR,HINGED,19.88"
CENTRALIZER: CASING; FOR 13-3/8 IN. OD CASING; TO FIT INSIDE 18-5/8 IN.
CASING. CENTRALIZER CASING; STRAIGHT SPRING TYPE,18-5/8 IN CASING,13-3/8
IN OD,19.8800 IN BOW OD,STYLE NON-WELDED HINGE,48.0-102.0 LB/FT,TYPE "ST-
IV", WITHOUT HINGE PINS
1000022660

Material Number
9COM/9CAT
469
Drilling Equipment
Cementing
Equipment)
SHOE,FLOAT,18-5/8",BTC,87.5-
115#,K55
SHOE, FLOAT: FOR 18-5/8 IN OD CASING 87.5-115 LB/FT API 5B BUTTRESS
THREAD, K-55 SHOE FLOAT; FOR 18-5/8 IN OD CASING, 87.5-115 LB/FT API 5B
BUTTRESS THREAD, K-55 "PDC DRILLABLE" 1000025919
470
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,4-
1/2X7,VTHC,13.5#,C95,HYD
HANGER: LINER ASSEMBLY; 4.5 IN. 13.5# VAM TOP HC X 7 IN 29-35# 'TSP' HYDRO-
HANGER RRP-TSP 3.920" MIN ID, GEN-2, FOR KHUFF HANGER LINER; HYDRAULIC
ACTIVATI,FOR H2S SOUR SERVICE,GR 41XX- 95000 MYS (C-95),4- 1/2 IN END
1,13.5 LB/FT END 1,7 IN END 2,29-35 LB/FT END 2,VAM TOP HC PIN X PIN END
CONN,NACE MR-01-75,TIW TYPE "TSP", FOR 4.5 GENERATION-2 KHUFF LINER
HANGER SYSTEM COMPLETE ASSEMBLY MUST BE BOXED AS AN INDIVIDUAL UNIT
WITH ITS COMPONENTS AS LISTED BELOW KITS COMPONENTS
1000024316
471
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,9-
5/8,VAM21,10K,TRSSSV+CL
EQUALIZER; 9-5/8 IN, 10,000 PSI PRESSURE RATING, TUBING-RETRIEVABLE
SAFETY VALVE ASSY COMPLETE WITH ACCESSORIES 1000831437
472
Drilling Equipment
(Downhole
Equipment)
PBR/SEAL,4-
1/2",NK3SB,13.5#,41XX-95,10FT
SEAL ASSY; SIZE 4-1/2 IN, TO LOCATE AT TOP OF 4-1/2 IN SETTING SLEEVE AND
SEAL 4-1/2 IN PBR. SEAL; PBR SEALS TYPE,SIZE 4-1/2 IN,(BMS A-152) 41XX-HC95
MYS MATERIAL FOR HT SOUR SERVICE (T-95EQUIVALENT-NACE TEST TM0177
WAIVED),TO LOCATE AT TOP OF 4-1/2 IN SETTING SLEEVE. KITS COMPONENTS
1000644370
473
Drilling Equipment
(Advanced Well
Completion
Equipment)
SCREEN,MESH,4-
1/2,NVAM,11.6#,250MIC
SCREEN; STAND ALONE PREMIUM SCREEN TYPE,SIZE 4-
1/2IN,316SS,SCHLUMBERGER PREMIUM SCREEN SYSTEM,L-80, R3, THREAD
250MICRON MESH
1000903439
474
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,9-
5/8X14,FJL,53.5#,718,HYD
HANGER LINER; 9-5/8 IN END 1,9-5/8 IN END 2,53.3 LB END 2,9-5/8 IN, 53.3 PPF X
14 IN, 114 PPF BAKER CSG LINER HANGER AND ACCESSORIES. KIT COMPONENTS 1000830502
475
Drilling Equipment
(Downhole
Equipment)
3/8,NK3SB,53.5#,HY
HANGER LINER; HYDRAULIC ACTIVATI,9-5/8 INCH END 1,53.5 LB/FT END 1,13-3/8
INCH END 2,86.0-92.0 LB/FT END 2,#9-5/8 IN X 13-3/8 IN LINER HANGER SYSTEM
KIT COMPONENTS
1000903460
476
Drilling Equipment
(Advanced Well
Completion
Equipment)
SCREEN,4-
1/2,NVAM,12.6#,0.020",INJECTIO
N
SCREEN; WELDED TYPE,SIZE 4-1/2 IN,STATINLESS STEEL,BASE PIPE SIZE: 4-1/2 IN,
WEITH: 12.6 PPF, L-80, WIRE WRAPPED 0.020 GA, ALONG WITH CENTRALIZER
CONNECTION: NEW VAM -BOX X PIN, LENGTH: R-3 (38 TO 42 FT)
1000827338

Material Number
9COM/9CAT
477
Drilling Equipment
(Advanced Well
Completion
Equipment)
KIT,ICD+DUAL P/T GAUGES,3-
1/2",4140/L80
ASSEMBLY; 3 1/2 IN. COMPACT INTERGRATED COMPLETION SYSTEM
TYPE,CONSISTING OF 3 1/2 IN. INFLOW CONTROL VALVES WITH ABSOLUTE
POSITION SENOR AND DUAL TUBING/ANNULUS P/T GAUGES. MATERIAL: 4140/L-
80
1000888959
478
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,18-
CENTRALIZER: CASING; FOR 18-5/8 IN. OD CASING; TO FIT INSIDE 24- - IN. HOLE. .
CENTRALIZER CASING; STRAIGHT SPRING TYPE,24 IN CASING,18-5/8 IN
OD,23.7000 IN BOW OD,STYLE NON-WELDED HINGE,78.0-122.0 LB/FT,TYPE "ST-
III", WITHOUT HINGE PINS
1000022661
479
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,4-
1/2X7,VTHC,13.5#,95,HYD
HANGER LINER; HYDRAULIC ACTIVATI,4.500 IN END 1,13.50 PPF END 1,7.00 IN
END 2,20.0 - 35.0 PPF END 2,4.500 IN 13.50 PPF VAM TOP HC PIN UP 4.500 IN
13.50 PPF VAM TOP HC PIN DOWN 07.000 IN 20.0-35.0 PPF,4-1/2 IN X 7 IN
CONTROL SET LINER HANGER FOR UDILIYAH GAS. SIZE: 4.5 IN (13.5 PPF) X 7.00 IN
(20-35 PPF) VTHC PXP. MAX OD: 5.819 IN. MIN ID: 3.830 IN. LENGTH: 10 FT.
ROTATING: YES. MATERIAL: 95 KSI MYS. LINER SIZE IN INCHES: 4.500 IN X 7.00 IN.
LINER THREAD: VTHC. LINER WEIGHT, (WEIGHT RANGE IF APPLICABLE), IN PPF:
13.5 PPF. PARENT CASING SIZE IN INCHES: 7.00 IN. PARENT CASING WEIGHT,
(WEIGHT RANGE IF APPLICABLE), IN PPF: 20-35 PPF. STEEL GRADE:95 KSI MYS.
SETTING METHOD (MECHANICAL/HYDRAULIC): HYDRAULIC. ROTATABLE WHILE
CEMENTING, YES/NO: NO. APPLICATION, GAS/OIL/WATER: GAS. KIT
COMPONENTS
1000917506
480
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,9-
5/8",SPIROLIZER,11.875"OD
CENTRALIZER CASING; SLIP-ON, SOLID BODY, SPIR-O-LIZER TYPE,9-5/8 IN X 12-1/4
IN CASING,11-7/8 IN BOW OD,STYLE 5-BLADE, SPIRAL,INTERNAL DIA.: 9.77 INCH,
WALL THICKNESS: 0.30 INCH, LENGTH: 10 INCH, WEIGHT: 13.9 KG, BLADES: 5 X
SPIRAL, BLADE ANGLE: 25O, BLADE LEAD IN: 3-1/2 INCH, BLADE LEAD OUT: 2-1/2
INCH, MATERIAL: ZINC ALLOY, USE WITH 2 EACH DUCTILE IRON SPIR-O-LOK STOP
COLLARS, WITH MATERIAL NUMBER 1000XXXXX, ITEMS MUST BE BOXED AS AN
INDIVIDUAL UNIT FOR SHIPMENT AND STORAGE PER SAUDI ARAMCO PACKAGING
SPEC 844418. MANUFACTURER MUST BAR CODE IDENTIFY EACH ISSUE UNIT ON
BOTH THE MATERIAL AND OUTSIDE THE CONTAINER IN WHICH THE ISSUE UNIT IS
CONTAINED. CODE TO BE IN THE INTERNATIONAL CODE 39 BAR CODING SYSTEM
FORMAT AND ADHERE TO ANSI MH10.8 ( LATEST EDITION) SPECIFICATION (LESS
SECTIONS 12 & 13). BAR CODE TAG MUST INCLUDE THE SAUDI ARAMCO STOCK
NUMBER AND PURCHASE ORDER NUMBER.
1000803584

Material Number
9COM/9CAT
481
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,9-
CENTRALIZER: CASING; FOR 9-5/8 IN. OD CASING; TO FIT INSIDE 13-3/8 IN.
CASING. CENTRALIZER CASING; STRAIGHT SPRING TYPE,13-3/8 IN CASING,9-5/8 IN
OD,14.5830 IN BOW OD,STYLE NON-WELDED HINGE,40.0-71.8 LB/FT,TYPE "ST-III",
WITHOUT HINGE PINS
1000022639
482
Drilling Equipment
(Downhole
Equipment)
SEAL,PRODUCTION,9-
5/8",VAM21,53.5#,718
SEAL; SNAP IN-SNAP OUT TYPE,SIZE 9-5/8 IN,INCONNEL 718, 120 KSI MYS,9 5/8
INCH SNAP IN-SNAP OUT SHEAR. RELEASE ANCHOR PRODUCTION SEAL
ASSEMBLY. SIZE: 9 5/8 INCH, 53.5 PPF, THREADS: VAM 21 BOX UP X 1/2 MULE
SHOE. MATERIAL: INCONNEL 718, 120 KSI MYS. TOOL OD: 12.130 INCH, TOOL ID:
9.398 INCH
1000830501
483
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,4-
1/2X7",NVAM,11.6#,L80,NCE
LINER; NON CEMENTED KIT TYPE,4-1/2 IN OFF BOTTOM NON- CEMENTING KIT.
FOR 7 IN 26# CASING AND 6-1/8 IN OPEN HOLE CONSIST OF: ITEM QUANTITY
DESCRIPTION 01 01 Baker SLZXP Liner Hanger/Packer Size: 5 IN. 18b/ft X 7 IN. 23-
29Lb/ft Thread: 5 IN. 18lb/ft New Vam Box Down Extension I.D.: 5-1/4 IN. Tool
O.D.: 6.060 IN. Tool I.D.: 4.276 IN. Extension Length: 10 feet PART# H296350005
02 01 Baker #PBR# Style Locator Seal Assembly Size: 5.250 IN. X 4-1/2 IN. 11.6
lb/ft Thread Connection: New Vam Box Up X ½ Mulshoe Length: 10 ft effective
Seal Stroke Material: L-80 Seal: Bullet Style Premium Seal Material: L-80 PART#
H297550798 03 01 Baker Bull plug Size: 4-1/2 IN. 11.6lb/ft Thread Connection:
New Vam Box Tool O.D.: 5.000 IN. Material: L-80 PART# H485-30-4512
1000751070
484
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,4-
1/2X8.00",VTHC,13.#,P110
PACKER; SWELLPACKER SP OS H2S TYPE,#SWELLPACKER, OIL SWELLING, 6A,
H2S,#4.5IN, 13.5LBS, API GRADE P-110#LOW ALLOY STEEL, VAMTOP-HC, BOX
X#PIN, 12M BASEPIPE X 8IN ELEMENT OD#X 9M ELEMENT LENGTH
1000917808
485
Drilling Equipment
(Downhole
Equipment)
NIPPLE,LANDING,4-
1/2",VAM,X,SL,3.813"ID
NIPPLE: LANDING; 5.03 IN. OD X 3.813 IN. ID X 18.05 IN. LG; 4-1/2 IN. 12.6 LB/FT
VAM BOX UP X NIPPLE LANDING; X (SELECTIVE) TYPE,9% CHROMIUM - 1%
MOLYBDENUM,L-80,FOR H2S & CO2,API-Q1/ISO 9001 AND API 14L/ISO 16070
COONECTN,POLISHED BORE,3.813 IN ID,5.030 IN OD,18.05 IN LG,4-1/2 IN TUBING
OD,12.60 LB/FT,VAM BOX UP X PIN DOWN,API 5B, API-Q1/ISO 9001, API 14L/ISO
16070, NACE MR-01-75,HES NO 711X38107 MADE TO: NACE MR-01-75 (LATEST
EDITION)
1000024620

Material Number
9COM/9CAT
486
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
HANGER, LINER: HYDRAULIC ACTIVATION, HORIZONTAL & HIGH ANGLE
COMPLETIONS SERVICE, L-80, 7 IN END 1, 26 LB/FT END HANGER LINER;
HYDRAULIC ACTIVATI,FOR HORIZONTAL & HIGH ANGLE COMPLETIONS,GR L-80,7
IN END 1,26 LB/FT END 1,9-5/8 IN END 2,40-47 LB/FT END 2,7 IN 26 L/FT NEW
VAM PIN X PIN END CONN,API 5B,BASE MATERIAL: L-80, TOTAL WEIGHT: 550
KGS, VOLUME: 25 CU. FT. COMPLETE UNIT MUST BE BOXED AS AN INDIVIDUAL
UNIT WITH ITS COMPONENTS AS LISTED BELOW. KITS COMPONENTS
1000645123
487
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X3-
1/2,VTOP,10.2#,718,FTHRU
PACKER PRODUCTION; XMP MULTI PORT, FEED-THROUGH TYPE,6.00 IN OD,2.88
IN ID,7 IN OD,26-29 PPF,3-1/2 IN CONNECTN,10.2 PPF,VAM TOP
COONECTN,MATERIAL INC 718 , ELEMENT AFLAS(90-80-90), WP:7500PSI AND
WT:350 DEGF, 4 X 1/4 IN FEEDTHROUGH
1000888236
488
Drilling Equipment
Cementing
Equipment)
DV TOOL,24",RL4S,176#,X42,MEC
TOOL; SIZE 24 IN,STYLE MECHANICAL STAGE,X-42, RL-4S, 176 PPF, 22.19 IN MIN
DRILLOUT ID, BOTTOM PLUG WITH RUPTURE DISK, SHUT OFF PLUG WITH
LANDING COLLAR, FREE FALL OPEN CONE AND CLOSING PLUG, NOT PDC
DRILLABLE
1000830132
489
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,2-
7/8",SSSV,9CR1MO,10K,FXE
VALVE: 'FXE' FLAPPER SUBSURFACE SAFETY, 2 813 IN X 1 500 IN, 10,000 PSI
WORKING PRESSURE, 9CR-1MO BODY, API VALVE; 'FXE' FLAPPER SUBSURFACE
SAFETY TYPE,SIZE 2.813 IN X 1.500 IN,10,000 PSI WORKING PRESSURE
SUPPLY,9CR-1MO BODY,API 14A,CLASSES 1 3,NACE MR-01-75 (2002 EDITI NACE
MR-01-75,API-14A NACE MR-01-75/,ISO 1515 API MONOGRAMMED,EQUALIZING,
TOP THREAD: 2-1/4"-12 SLB, SERVICE:H2S, MAX OD: 2.813 IN., MIN OD:1.500 IN,
LENGTH:44.80 IN, TEMPERATURE: 20 TO 300 DEG F, RUNNING TOOL PN:41 XO
28100 (13623), RUNNING PRONG PN: 49 P 1789 (101010079), PULLING PRONG
PN: 49 P 1789 (101010079), (ADAPTER REQUIRED) PULLING PRONG ADAPTER PN
49 P 1791 (101010081)
1000645125
490
Drilling Equipment
(Downhole
Equipment)
1/2,NVAM,12.6#,RET
PACKER PRODUCTION; 'QHSB' HYDRAULIC SET RETRIEVABLE TYPE,FOR H2S,
CO2,HYDRAULIC SET ACTIVATI,8.445 IN OD,4.747 IN ID,9-5/8 IN OD,40-47
LB/FT,5.250-4TPI LEFT HAND SQUARE THREAD(TOP) X 4-1/2 IN 12.6 PPF L-80 NEW
VAM PIN DOWN CONNECTN,12.6 LB/FT (BOTTOM),LEFT-HAND SQUARE
THREAD(TOP) NEW VAM PIN (DOWN) COONECTN,6,000 PSI SUPPLY,NACE MR 01-
75,CARBON STEEL 4130/4140 FLOW WETTED NITRILE ELASTOMER, NITRILE O-
RINGS. KIT COMPONENTS
1000810364

Material Number
9COM/9CAT
491
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,4-
1/2X7,NVAM,11.6#,L80,MEC
HANGER LINER; MECHANICAL ACTIVATI,FOR STANDARD,GR L-80,4-1/2 IN END
1,11.6 LB/FT END 1,7 IN END 2,26 LB/FT END 2,NEW VAM BOX UP X MULE SHOE
END CONN,NON-CEMENTED SYSTEM, SCHLUMBERGER LINER HANGER SCREEN,
HANGER SYSTEM FOR 7 IN CASING CONSISTS OF THE FOLLOWING: 1. TIE BACK
STEM SYSTEM WITH BULLET SEAL, FOR 10 FT EXTENSION 2. POLISHED BORE
RECEPTACLE (PBR) 3. R-SETTING SLEEVE WITH XTS LINER TOP PACKER, PACK-OFF
NIPPLE AND MECHANICAL LOCK 4. HYDRAULIC ROTATING DOUBLE CONE LINER
HANGER WITH PTFE/CARBON SEALING ELEMENT IN CYLINDER AND HANGER 5.
SEATING BALL KIT COMPONENTS
1000827948
492
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,4-
1/2X6.125"OH,NVAM,12.6#
PACKER PRODUCTION; OH SWELL PACKER TYPE,5.625 IN OD,3.958 IN ID,6-1/8 IN
HOLE OD,4-1/2 IN CONNECTN,12.6 PPF,NEW VAM BOX X PIN COONECTN,4-1/2 IN
SWELL REPACKER, BASE PIPE MATERIAL: L-80 STEEL, SEAL MATERIAL: OIL SWELL
ELEMENT, SEAL LENGTH: 20 FT, JOINT LENGTH: 30 FT.
1000844948
493
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,NVAM,26#,CRA,HYD
HANGER LINER; HYDRAULIC ACTIVATI,7 IN END 1,26 LB/FT END 1,9-5/8 IN END
2,40-47 LB END 2,NEW VAM END CONN,CONTROL SET LINER HANGER WITH ZXP
LINER TOP PACKER AND FLEX LOCK LINER HANGER ASSEMBLY CONSISTING OF:
ZXP LINER TOP PACKER 7 IN, 26 LB/FT X 9-5/8 IN 40-47 LB, WITH HOLD DOWN
SLIPS SIZE: 7 IN X 9-5/8 IN 40-47 LB, EXTENSION SIZE: 15 FT, MAX TOOL OD: 8.453
IN, MIN TOOL OD: 6.278 IN, MIN. BURST: 8,251 PSI, MIN. COLLAPSE: 5,376 PSI,
TENSILE LOAD: 602,351 LBS, ELEMENT RATING: 10,000 PSI AT 400 DEG F,
ELEMENT RATING: 17 BPM CIRCULATION RATE, MATERIAL: 22 RC, 80 KSY MYS.
KIT COMPONENTS
1000827579
494
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,4-
1/2",CRA,WRSV,XVE
SAFETY VALVE COMPONENTS: SUBSURFACE, FLAPPER; WIRELINE RETRIEVABLE
PORTION; 4.500 IN X 3.810 IN. VALVE; SUBSURFACE SAFETY TYPE,SIZE 4.50 IN X
3.810 IN, PROFILE 2.122 IN,6000 PSI WORKING PRESSURE 1500 PSI OPENING
PRESSURE SUPPLY,9CR. IMO. ON FLOW WETTED PARTS ID TREATED WITH 63RMS
AND BAKERTON V BODY,API 14A,NACE MR-01-75 API-14A,NACE MR-01-75/ ISO
15156 MONOGRAMMED,H2S AND CO2 SERVICE, BAKER MODEL 'XVE' WITH
FLAPPER
1000026444

Material Number
9COM/9CAT
495
Drilling Equipment
(Downhole
Equipment)
VALVE,ICV,2-
7/8",EUE,6.5#,41XX,FCV004
VALVE; TUBING RETRIEVABLE FLOW CONTROL-HYDRAULIC TYPE,SIZE 2-7/8 IN,2-
7/8 IN 6.5 PPF EUE BOX X PIN END CONN,INC718 BODY,INC718, 9CR-1MO,
4140/4130 TRIM,EXTERNAL WORKING PRESSUR: 7500 PSI, INTERNAL DIA.: 2.250
IN MIN, DRIFT ID: 2.245 IN, LENGTH: 194 IN, MAX FLOW RATE: 25000 BBL/DAY,
MAX WORKING TEMP.: 325°F, MIN WORKING TEMP.: 40°F, MINOR OD: 4.530 IN,
OD: 4.530 IN, OD: 5.125 IN MAX, SEAL BORE SIZE: 2.250 IN. THE TUBING
RETRIEVABLE FLOW CONTROLLER SYSTEM PROVIDES REMOTELY ACTUATED
DOWNHOLE CONTROL OF FLOW FROM THE RESERVOIR IN INTELLIGENT
COMPLETIONS. THE SYSTEM MUST BE OPERATED BY A 0.25-IN HYDRAULIC
CONTROL LINE THAT IS ROUTED FROM THE SURFACE CONTROLS TO THE CHOKE
SECTION OF THE TOOL.
1000782149
496
Drilling Equipment
(Downhole
Equipment)
35#,MEC,1.98DG
WHIPSTOCK; SHALLOW ANGLE QUICK CUT TYPE,5-1/2 IN DIA BODY
STD,MECHANICAL TRIP,7 IN CSNG DRE,23-35 LB/FT CSNG DRE,WEATHERFORD
WHIPSTOCK, QUICK CUT, SHALLOW ANGLE MECHANICAL RETRIEVABLE TYPE, 5-
1/2 IN OD BODY, MULTI-CATCH ANCHOR, 1.98 DEGREE WHIP FACE FOR 7 IN 23-
35 PPF CASING
1000769301
497
Drilling Equipment
(Downhole
Equipment)
SEAL,9-
5/8",VAM21,53.5#,725/625,R-
LATCH
NIPPLE LANDING; NIPPLE: RATCH LATCH C/W SEAL ASSEMBLY KIT COMPONENTS,
ITEM 1, QTY. 1EA, SHEAR -TO-LATCH RATCH LATCH SEAL ASSY, 10000 PSI, 9-5/8
IN, 53.5 PPF, VAM 21 BOX X MULE SHOE GUIDE, KTR SEAL STACK, 12.13 IN OD X
8.535 IN ID, MATERIAL: NICKEL ALLOY 725 / 625+ FOR ELEMENTAL SULPHUR,
H2S/CO2 SERVICE. ITEM 2, QTY. 1EA, RATCH LATCH SEAL NIPPLE, 10.375-6 R/L
BOX 9-5/8 IN, 53.5 PPF, VAM 21 PIN, 10000 PSI WORKING PRESSURE, 12.13 IN OD
X 8.535 IN ID, MATERIAL: NICKEL ALLOY 725/625+ FOR ELEMENTAL SULPHUR,
H2S/CO2 SERVICE.
1000831428

Material Number
9COM/9CAT
498
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,5-1/2X9-
5/8",NVAM,17#,NONCEMEN
LINER; NON CEMENTED KIT TYPE,5-1/2 IN OFF BOTTOM NON- CEMENTING KIT.
FOR 9-5/8 IN 43.5 # CASING AND 8-1/2 IN OPEN HOLE, PDC DRILLABLE CONSIST
OF: ITEM QUANTITY DESCRIPTION 01 01 PBR Seal Assembly with Bullet Seals Size:
7.500 IN. X 5-1/2 IN. 15.5 lb/ft For 15 ft extension Thread connection: New Vam
Box Up X ½ Mulshoe Seal O.D.: 7.500 IN. Tool I.D.: 4.892 IN. Length: 10 ft effective
Seal Stroke Material: L-80 PART# H297550652 02 01 Baker #SLZXP# Liner Top
Packer w/ HR Profile and 15ft Tie-Back Sleeve Size: 7 IN. 26 lb/ft Thread
Connection: New Vam Pin Down PBR Extension O.D. 8.250 IN. (8.312 IN. Tool
O.D.) PBR Extension I.D.: 7.500 IN. Tool I.D.: 6.276 IN. as per 26# casing Spec
Material: L-80 PART# H296350015 ITEM QUANTITY DESCRIPTION 03 01 Baker
Casing Sub Size: 7 IN. 26lb/ft X 5-1/2 IN. 17lb/ft Thread Connection: New Vam Box
X Pin Tool O.D.: 7.656 IN. Tool I.D.: 4.892 IN. Material: L-80 PART# H494016798 04
01 Baker O-ring Seal Sub Size: 5-1/2 IN. 17 lb/ft X 2.875 IN. Bore Thread
Connection: New Vam Box X Pin Tool O.D.: 7.390 IN. Tool I.D.: 4.000 IN. Material:
L-80 PART# H485355525 05 01 Baker Pup Joint Size: 5-1/2 IN. 17 lb/ft. 6 feet long
Thread Connection: New Vam Box x Pin Tool O.D.: 6.050 IN. Tool I.D.: 4.892 IN.
Material: L-80 PART# H494032302 06 01 Baker #BPV# Set Shoe Size: 5-1/2 IN. 17
lb/ft Thread Connection: New Vam Box X Pin Tool O.D.: 6.050 IN. Material: L-80
PART# H487365502
1000751071
499
Drilling Equipment
(Downhole
Equipment)
PACKER,LINER,7",NVAM,26#,L80,
TBR 6FT
PACKER; WMPO WEIGHT TYPE,SIZE 7 IN. 26# X 9-5/8 IN, "WMPO" WEIGHT SET
PACKER, 6 FT LONG TIE-BACK RECEPTACLE CONSISTING OF: MODEL "WMPO"
WEIGHT SET PACKER ,OD 8.375 IN X ID 6.276 IN, FITTED WITH 6 FT LONG TIE-
BACK RECEPTACLE, RCB PROFILE OD 8.250 IN, ID 7.375 IN, WITH 7 IN. 26# NEW
VAM PIN, L-80 MATERIAL, NITRILE PACKING ELEMENT.
1000771958
500
Drilling Equipment
Cementing
Equipment)
COLLAR,FLOAT,13-3/8",VAM
TOP,72#,HC95
COLLAR: FLOAT, 13-3/8 IN 72 LB, HC95 GRADE, VAM TOP, W/12.25 IN DRILL OUT
ID . COLLAR FLOAT; CEMENTING TYPE,STYLE PLASTIC SEAT,13-3/8 IN OD,72
LB/FT,VAM TOP,12.25 IN DRILL ID,WITH PLASTIC VALVE "PDC DRILLABLE" 1000624815
501
Drilling Equipment
(Advanced Well
Completion
Equipment)
GAUGE,P+T
ASSEMBLY; MONITORING TYPE,PERMANENT DOWNHOLE, DUAL, 3-1/2 IN KIT
COMPONENTS
1000757802

Material Number
9COM/9CAT
502
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,5-
1/2X8.50"OH,NVAM,17#,L80
PACKER PRODUCTION; SWELL TYPE,FOR OIL,5.5 IN OD,4.892 IN ID,17 PPF,NEW
VAM COONECTN,SWELLPACKER, 5.5 IN X 8 IN X 3 M, BASEPIPE OD: 5.5 IN,
BASEPIPE WEIGHT: 17 PPF, BASE MATERIAL: L80, THREAD TYPE: NEW VAM, END
RING MATERIAL: ST52, PACKER ELEMENT OD: 8 IN, PACKER ELEMENT LENGTH:
118.1 IN, TOTAL PACKER LENGTH: 236.2 IN, PACKER DRIFT ID: 4.767 IN, PACKER
NOMINAL ID: 4.892 IN, MINIMUM HANDLING SPACE BOX END: 47 IN, MINIMUM
HANDLING SPACE PIN END: 47 IN, COUPLING LENGTH: 11.693 IN, COUPLING OD:
6.075 IN, ENDRING LENGTH: 3.1 IN, ENDRING OD: 7.98 IN, MAX H2S LEVEL STD.
POLYMER: 0.5 %, HOLE SIZE: 8.5 IN
1000769400
503
Drilling Equipment
(Downhole
Equipment)
7/8,EUE,6.5#,PER
PACKER: PRODUCTION, FOR 4-1/2 IN, 9.5-12.6 LB/FT CASING 'TWR' WITH BIG
BORE, L-80 MATERIAL. PACKER PRODUCTION; 'TWR' PERMA-SERIES TYPE,FOR
H2S, CO2,HYDRAULIC SETTING TOOL ACTIVATI,3.79 IN MAX OD,2.375 IN ID,4-1/2
IN OD,9.5-12.6 LB/FT,2-7/8 IN CONNECTN,6.5 LB/FT,API EUE PIN
COONECTN,10,570 PSI SUPPLY,NACE MR-0175 KITS COMPONENTS: ITEM QTY
DESCRIPTION 01 01 EA TWR WIRELINE-SET PERMA-SERIES® PRODUCTION
PACKER, RATCH-LATCH HEAD, TUBING THREAD, 4 1/2 IN. 9.5-12.6 AND 5 IN. 23.2-
24.2 LB/FT WEIGHT RANGE, 3.000 IN. SEAL BORE ID-MIN, 9CR-1MO MATL, 80000
PSI MIN YIELD, NITRILE RUBBER ELEMENT MATL, 3.790 IN. MAX OD, 2.375 IN.
MIN ID, 58.50 IN. LENGTH, H2S/CO2 SERVICE, 40-325 DEG. F, 10570 PSI PRESSURE
RATING, 2 7/8-6.50 API-EU PN: 101391704 (OLD PN: 212TWR4502-A) 02 01 EA
RLV RATCH-LATCH® SEAL ASSEMBLY WITH VTR SEAL, 3.000 IN. SEAL BORE ID-MIN,
9CR-1MO MATL, VITON/TEFLON/RYTON SEAL MATL, 2 7/8 API-EU BOX, 3.185-8
RTH LTH LH LATCH TYPE, 3.705 IN. MAX OD, 2.330 IN. MIN ID, 37.50 IN. LENGTH,
100-450 DEG. F, 7600 PSI PRESSURE RATING, H2S/CO2 SERVICE PN: 101391817
(OLD PN: 213RLV82-C)
1000589638
504
Drilling Equipment
(Downhole
Equipment)
PACKER,LINER,7",VTOP,29#,110K
SI,TBR 15FT
PACKER; ZXP LINER TYPE,#ZXP LINER TOP PACKER 7 IN 29 LB/FT X 9-5/8 IN 47-53.5
# , W/HOLD DOWN SLIPS#SIZE : 7 INCH X 9-5/8 INCH 47.0-53.5 # #RUNNING TOOL
: MECHANICAL "RH"#EXTENSION LENGTH : 15 FT #EXTENSION ID : 7.375 IN #MAX
TOOL OD : 8.312 IN #MIN TOOL ID : 6.100 INCH #ELEMENT RATING :10,000 PSI AT
400 F #ELEMENT RATING: 17BPM CIRCULATION RATE #THREAD : 7 INCH 29# VAM
TOP KSY MYS #MATERIAL : 33 RC , 110 KSY MYS .
1000891296

Material Number
9COM/9CAT
505
Drilling Equipment
Cementing
Equipment)
COLLAR,FLOAT,9-
5/8",NK3SB,53.5#,T95
COLLAR: FLOAT; 9-5/8 IN 53.5 LB; T95 GRADE, NK-3SB W/8.5 IN DRILL OUT ID
COLLAR FLOAT; CEMENTING TYPE,STYLE PLASTIC SEAT,9-5/8 IN OD,53.5 LB/FT,NK-
3SB,8.5000 IN DRILL ID,WITH PLASTIC VALVE, T95 GRADE "PDC DRILLABLE" 1000022859
506
Drilling Equipment
(Downhole
Equipment)
PACKER,ACP,24",RL4S,176#,X42,
4FT
PACKER; ANNULUS CASING TYPE,SIZE: 24 IN, 4 FT DRVS, 25.90 IN OD, 176 PPF, X-
42, RL-4S 1000830133

Material Number
9COM/9CAT
507
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,VTHC,32#,41XX,58.4#
HANGER LINER; 7-5/8 IN END 1,9-5/8 IN END 2,58.4 LB END2,RECEPTACLE) : 8.210
IN, NOMINAL OD (ELASTOMERS) : 8.205 IN,SEAL BORE ID-MIN (TIE-BACK
RECEPTACLE) : 7.624 IN, SEAL BORELENGTH -MAX (TIE-BACK RECEPRACLE) :
118.800 IN, MAXIMUM OD(SETTING SLEEVE) : 8.210 IN, NOMINAL ANNULAR BY
PASS AROUNDLINER HANGER (S.Q INCH): 2.993, MINIMUM ID: 6.780 IN,
NOMINALLENGTH : 347.248 IN, SETTING PRESSURE : 2745 PSI, BURST
PRESSUREABOVE ELASTOMERS (CALC) : 7468 PSI, BURST PRESSURE
ABOVEELASTOMERS REMARKS: 7-7/8 HST-DS-BOX, COLLAPSE PRESSURE
ABOVEELASTOMERS (CALC): 5309 PSI, COLLAPSE PRESSURE REMARKS : 7-7/8HST-
DS PIN TENSILE RATING ABOCE ELASTOMERS (CALC) : 385178 LBS,TENSILE
RATING ABOVE ELASTOMERS REMARKS : 7-7/8 HST-DS PIN,BURST PRESSURE
BELOW ELASTOMERS (CALC) : 8313 PSI, BURSTPRESSURE BELOW ELASTOMERS
REMARKS : 7.509 HST-DS BOX COLLAPSEPRESSURE BELOW ELASTOMERS (CALC):
8726 PSI, COLLAPSE PRESSUREBELOW ELASTOMERS REMARKS: BODY -POST
EXPANSION 58.4 LB, TENSILERATING BELOW ELASTOMERS (CALC ) : 747500 LB,
TENSILE RATINGBELOW ELASTOMERS REMARKS : 7.509 HST-DS PIN, TORQUE
RATINGMAXIMUM (FT-LBS) : 71043, TORQUE RATING REMARKS : 7.509 HST-
DSPIN HYDRAULIC SETTING TOOL-OPTION : 10152189(59VRT7096300),CONES
FOR OPTION 1 HYDRAULIC SETTING TOOL: 101625471 59V960049,REMARKS:
ADJUSTING SLEEVE 101637127 (59V960092) IS REQUIRED TORUN LINER HANGER
ID LENGTH MAX (TIE LINER HANGER ASSY VLH, 7-5/8IN 32-35 LB X 9-5/8 BACK
RECEPTACLE : 122.78 IN, 58.4 LB, TYPE:IN, EQUIPMENT NUMBER: 101633851,
PART NUMBER: STANDARD, CASINGSIZE: 59VF70965800-A 9-5/8 IN CASING
WEIGHT: 58.4 LB, MATERIAL:41XX LOW ALLOY STEEL, ELEMENT MATERIAL:
FLUOROCARBON RUBBER,TEMPERATURE RATING: 40 TO 275 DEG F, SERVICE:
STD, BOTTOMTHREAD: 7, CONNECTION TYPE: PIN, MAKE-UP TORQUE, LINER
HANGER :4528 FT-LBS (MINIMUM), BODY -UPPER(FT-LBS):
5032(OPTIMUM),5535(MAXIMUM) FOR 7-7/8 HST-DS, MAKE -UP TORQUE,LINER
HANGER :9043 FT-LBS (MINMUM), BODY -LOWER(FT-LBS) :
10048(OPTIMUM),11053(MAXIMUM) FOR 7.509 DS-HST, MAXIMUM OD: 8.21 IN,
MAXIMUM OD(TIE-BACKKIT COMPONENTS
1000828160
508
Drilling Equipment
(Advanced Well
Completion
Equipment)
LINE,FIBER OPTIC,50/125
SIZE,FOR DTS
LINE; FIBER OPTIC (GRADED INDEX MULTI-MODE) TYPE,SIZE 50/125,CARBON
POLYIMIDE,DISTRIBUTED TEMPERATURE FIBER OPTIC FOR SCHLUMBERGER
DISTRIBUTED TEMPERATURE SYSTEM. GEN II - 50/125 CARBON/POLYAMIDE MM
OPTICAL FIBER. FIBER TYPE: GRADED INDEX MULTI- MIODE, MAXIMUM
OPERATING TEMPERATURE: 175 DEF C, FIBER COATING MATERIAL: CARBON
POLYIMIDE.
1000845762

Material Number
9COM/9CAT
509
Drilling Equipment
Cementing
Equipment)
DV TOOL,13-3/8",VAM TOP,72-
86#,Q125,MEC
TOOL; STAGE TYPE,SIZE 13-3/8 IN,ESIPC-P, 72-86 LBS/FT, VAM TOP - Q-125
COLLAR, TYPE P ES INFLATABLE PACKER, 13- 3/8 IN VAM TOP 72-86 LBS/ FT,
METAL BLADDER PACKER, SUITABLE FOR USE WITH Q-125 HC, CASING SIZE: 13-
3/8 IN, TYPE: P ESIPC, CASING WEIGHT: 72-86 LBS/FT, THREADER: VALLOUREC,
CASING THREAD: VAM TOP, GRADE: Q-125HC, DRILL OUT ID: 12. 279 IN, LENGTH:
82.07 IN, NET WEIGHT: 1031.9, MAX OD: 15.25 IN, PACKER TYPE: METAL, BURST
PRESSURE: 10233 PSI, COLLAPSE PRESSURE: 10233 PSI, PRIMARY OPENING
PRESSURE: 325 PSI, SECONDARY OPENING PRESSURE: 2200 PSI, CLOSING
PRESSURE: 910 PSI, TENSILE STRENGTH: 2601.631 KSI
1000828584
510
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,4-
1/2X7",NVAM,12.6#,NCEMENTE
D
LINER; NON-CEMENTED DEPLOYMENT, KIT TYPE,SIZE 4-1/2 INCH,C-SERIES
HYDRAULIC LINER SYSTEM, COMPLETE ASSMBLY WITH ITEMS AS DESCRIBED IN
KITS SECTION MUST BE BOXED AS AN INDIVIDUAL UNIT FOR SHIPMENT AND
STORAGE PER SAUDI ARAMCO PACKAGING SPEC 844418. MANUFACTURER MUST
BAR CODE IDENTIFY EACH ISSUE UNIT ON BOTH THE MATERIAL AND OUTSIDE
THE CONTAINER IN WHICH THE ISSUE UNIT IS CONTAINED. CODE TO BE IN THE
INTERNATIONAL CODE 39 BAR CODING SYSTEM FORMAT AND ADHERE TO ANSI
MH10.8 ( LATEST EDITION) SPECIFICATION (LESS SECTIONS 12 & 13). BAR CODE
TAG MUST INCLUDE THE SAUDI ARAMCO STOCK NUMBER AND PURCHASE ORDER
NUMBER. ALL ITEMS SHOULD BE ASSEMBLED TOGETHER PRIOR TO TESTING. KIT
COMPONENTS
1000794892
511
Drilling Equipment
(Downhole
Equipment)
3/8,NK3SB,58.4#,HY
HANGER LINER; HYDRAULIC ACTIVATI,9-5/8 IN END 1,53.5 LB/FT END 1,13-3/8 IN
END 2,48-98 LB/FT END 2,NEW VAM PIN X PIN END CONN KIT COMPONENTS 1000825383
512
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,4-
1/2,NVAM,11.6#,L80,CEMENTED
HANGER LINER; 4-1/2 INCH END 1,NA END 2,TIW OFF BOTTOM LINER ASSEMBLY
WITH IB-TC HYDRO HANGERWITH S-10 LINER TOP PACKER AND ECP INFLATABLE
PACKER ASSEMBLY. KIT COMPONENTS
1000904741
513
Drilling Equipment
(Downhole
Equipment)
KIT,FRAC,5-1/2X8.5",VTHC,PK-SL-
PJ-CN
PACKER PRODUCTION; STAGE FRAC SYSTEM, FRAC STAGE ASSEMBLY TYPE,7.750
IN MAX OD,4.700 IN MIN ID,9-5/8 IN OD,43.5 - 58.4 LB/FT,5-1/2 IN CONNECTN,20
LB/FT,VAM TOP HC BOX X PIN, C/W COONECTN,10,000 PSI WORKING PRESSURE
SUPPLY,FOR OPEN HOLE: 8-3/8 IN - 8-1/2 IN, MATERIAL: P-110, PULL STRENGTH
THROUGH TOOL: 514,000 LBS, BURST PRESSURE: 10,750 PSI COLLAPSE PRESSURE:
10,300 PSI, EFFECTIVE SHEAR AREA: 8.500 IN2, SHEAR PRESSURE PER PIN: 341
PSI, MAX SHEAR PRESSURE: 4,092 PSI, MAX NUMBER OF SHEAR PINS: 12 PINS,
OVERALL LENGTH: 69.900 IN, WEIGHT: 322.79 LBS, ELASTOMER MATERIAL: HSN
1000823559

Material Number
9COM/9CAT
514
Drilling Equipment
(Downhole
Equipment)
PACKER,TIEBACK,4-
1/2,NK3SB,13.5#,TBR12
PACKER, LINER: PACKER, LINER TOP, TYPE SN-12-AT HI-LOAD FOR GEN-1 AND GEN-
2, 4-1/2 IN LINERS W/ TYPE LG-12 PACKER LINER; PACKER, LINER TOP, TYPE SN-12-
AT HI-LOAD FOR GEN-1 AND GEN-2, 4-1/2 IN LINERS W/ TYPE LG-12 TBR KIT
COMPONENTS:
1000025007
515
Drilling Equipment
(Downhole
Equipment)
VALVE,ICV,2-
7/8",NVAM,5K,718,HVC+ACCUPU
L
SUPPLY,2-7/8 IN, 6.4# NEW VAM END CONN,INCONEL 718 / 4140 BODY,CASING
SIZE: 7 IN. (17# THRU 38#), MAXIMUM OD: 4.665 IN.(5.02 PROJECTED OD OFF
TUBING CENTER LINE), MINIMUM ID: 2.313 IN, LENGTH: 137.3 IN, 2-7/8 IN. 6.4#
(P-110 GRADE) NEW VAM TORQUE FT-LBF: 2,870 MIN, 3,180 OPT., 3,490 MAX, 2-
7/8 IN. 6.4# (L-80 GRADE) NEW VAM TORQUE FT-LBF: 2,160 MIN, 2,390 OPT.,
2,620 MAX, HVC THREAD: 2-7/8 IN, 6.4# NS-CT BOX X PIN THD, 3-1/2 10.2# NSCT
TORQUE FT-LBF: 2,065 MIN, 2,250 OPT., 2,435 MAX, SERVICE: STD/H²S/CO², MAX
WORKING TEMP: 275°F, WORKING PRESSURE INTERNAL: 7,500 PSI, WORKING
PRESSURE EXTERNAL: 7,500 PSI, TEST PRESSURE INTERNAL: 8,000 PSI, TEST
PRESSURE EXTERNAL: 8,000 PSI, MAX. HYDRAULIC PRESSURE: 10,000 PSI,
WORKING HYDRAULIC PRESSURE: 5,000 PSI, HVC CHOKE: 214HVC280003,
ACCUPULSE: 213APE702801, HVC METALLURGY: 718 INC., FITTING KIT
METALLURGY: 925 INC./4140, ACCUPULSE METALLURGY: 718 INC, FASTENER
METALLURGY: 300 SS, ELASTOMERS F/HYD. CHAMBER: V-RINGS E081 (PTFE), O-
RINGS (CHEMRAZ), BACK UP RINGS E080 (PEEK), ELASTOMERS F/ WELLBORE
FLUID: BACK UP RINGS E080 (PEEK), O-RINGS (VITON), PISTON AREA: 1.783 IN²,
TOTAL STROKE: 6.00 IN, HYD CHAMBER DISPLACEMENT: 10.69 IN³, TENSILE
RATING: 145,000 LBF, COMPRESSIVE RATING: 58,000 LBF, MIN. INTERNAL FLOW
AREA: 4.20 IN², FLOW AREA BETWEEN OD OF HVC AND ID OF CSG. 7 IN. (32#)
(6.094 ID): 14.75 SQ IN TOTAL(.910SQ. IN. OF TOTAL IS DUE TO SLOTS), FLOW
TRIM CHOKE SETTINGS: 11 POSITIONS (1 X FULLY OPEN, 1 X FULLY CLOSED, 9 X
FIXED) 0%, 2.38%, 3.57%, 5.90%, 9.43%, 14.09% 18.75%, 23.41%, 43.63%, 84.06%,
100%, COIL TUBING SHIFTING TOOL: 290HM0231000, ASSY PICTORAL/ BOM
DRAWING: 312499-01-01, TECH DOC: 312025-00-01.
1000780059

Material Number
9COM/9CAT
516
Drilling Equipment
(Downhole
Equipment)
KIT,LINER,7X9-
5/8,TB,26#,HYD,NONCEMENTED
HANGER LINER; HYDRAULIC ACTIVATI,FOR SCREEN HANGING SYSTEM, NON-
CEMENTED KIT,GR L-80,7 IN END 1,26 LB/FT END 1,9-5/8 IN END 2,40-43.5 LB/FT
END 2,NEW VAM PIN DOWN END CONN,7" 26# TENARIS BLUE PIN X NEW VAM
PIN,'QUANTUM' NON-CEMENTED KIT TYPE, 8.465" OD X 6.240" ID, 40.175 INCH
LONG, 1, COMPLETE ASSEMBLY WITH ITEMS AS DESCRIBED IN KITS SECTION
MUST BE BOXED AS AN INDIVIDUAL UNIT FOR SHIPMENT AND STORAGE PER
SAUDI ARAMCO PACKAGING SPEC 844418, 2-MANUFACTURER MUST BAR CODE
IDENTIFY EACH ISSUE UNIT ON BOTH THE MATERIAL AND OUTSIDE THE
CONTAINER IN WHICH THE ISSUE UNIT IS CONTAINED, CODE TO BE IN THE
MH10.8 ( LATEST EDITION) SPECIFICATION (LESS SECTIONS 12 & 13), BAR CODE
NUMBER, ALL ITEMS SHOULD BE ASSEMBLED TOGETHER PRIOR TO TESTING KIT
COMPONENTS
1000807104
517
Drilling Equipment
(Downhole
Equipment)
PACKER,LINER,7",LTC,23-
26#,L80,TBR 6FT
PACKER: LINER; TYPE S-6; WITH 6 FT TIE-BACK EXTENSION; . PACKER LINER;
WEIGHT SET TYPE,L-80,TYPE S-6 6 FT TIE-BACK,8.453 IN OD,7 IN LINER OD,23.0 -
26.0 LB/FT LINER,9-5/8 IN OD,36-40 LB/FT,8-1/4 IN EXT OD,7-3/8 IN EXT ID,LT & C
PIN DOWN COONECTN,API 5B,TO BE RUN ABOVE LINER HANGER, 8.250 IN TOOL
ID, SHEAR PINNED TO 15000 LB SET DOWN WEIGHT TO SET PACKER, TIW PART
NO 516543 EACH S/N MUST BE BOXED AS AN INDIVIDUAL UNIT (SEPARATELY)
1000024961
518
Drilling Equipment
(Advanced Well
Completion
Equipment)
GAUGE
UNIT; 4-1/2 IN, DUAL PERMANENT DOWNHOLE TYPE,BAKER HUGHES, 4-1/2 IN
PERMANENT DOWNHOLE MONITORING SYSTEM PDHMS WITH 4-1/2 IN NEW
VAM 12.6 PPF NEW VAM SINGLE CARRIER ITEM NO. QUANTITY DESCRIPTION 1.00
02 SINGLE 1 IN. WELLGUARD QUART PT GAUGE (2 PER WELL) HASTELLOY
HOUSING WITH INCONEL WETED PARTS RESONANT QUARTZ CRYSTAL
ELECTRONICS HOUSING WITH PRESSURE TESTABLE CABLE HEAD 10,000 PSI
PRESSURE RATING 150 DEG C RATING PRESSURE ACCURACY 0.02% FS AND DRIFT
<(><<)> 2 PSI / YR PRESSURE RESOLUTION = 0.01 PSI (TEMP RES 0.01 DEG C) 1.01
02 SINGLE SOLID GAUGE CARRIER (2 PER WELL) 4-1/2 IN. X 12.6 PPF NEW VAM
CONNECTIONS (PIN X PIN) 4140 L80 METALLURGY (YIED STRENGTH 288.000 LBS)
MAX. OD 5.889 IN DRIFT ID 3.833 IN. AND LENGTH OF 79 IN. DRAWING NUMBER:
GAD-00-8483 PART NUMBER: GA-00-8483 1.02 01 WELLHEAD OUTLET (1 PER
WELL) SAUDI ARAMCO APPROVED MODEL (5,000 PSI MINIMUM RATED) ½ IN.
NPT EEXD MODEL 1.03 02 TUBING HUNGER PENETRATOR (2 PER WELL) 3/8 IN.
NPT TO ¼ IN. SWAGELOCK CONNECTION
1000769328

Material Number
9COM/9CAT
519
Drilling Equipment
Cementing
Equipment)
COLLAR,FLOAT,18-5/8",BTC,87.5-
115#,K55
COLLAR: FLOAT; 18-5/8 IN.; 87.5-115 LB/FT; K-55; BUTTRESS THREAD BOX UP X
PIN DOWN PER COLLAR FLOAT; CEMENTING TYPE,STYLE PLASTIC SEAT,18-5/8 IN
OD,87.5-106 LB/FT,BUTTRESS BOX & PIN THD,17.5000 IN DRILL ID,API 5B,WITH
PLASTIC VALVE "PDC DRILLABLE"
1000022883
520
Drilling Equipment
(Advanced Well
Completion
Equipment)
PANEL,CONTROL,HYD-
PANEL; CONTROL TYPE,SS AISI 316,NEMA-4X, SCADA COMPATIBLE REMOTELY
OPERATED ELECTRICALLY DRIVEN HYDRAULIC CONTROL UNIT FOR IWC. CAPABLE
OF OPERATING 9 VALVES AND MONITORING PDHMS IN 3 WELLS. POWER
REQUIREMENTS: 110 VAC, 4 KW, SCADA COMMUNICATION PROTOCOL: MODBUS-
485 OR ETHERNET, PRESSURE: 10000 PSI (MAX), TEMPERATURE RATING: 55 DEG
C (SHELTERED), HYDRAULIC TANK CAPACITY: 30 GAL, FLOW CONTROL VALVE:
SCHLUMBERGER TRFC-HN, PUMP FLOW RATE: 1 L/MIN (MAX), FULLY
COMPATIBLE WITH SAUDI ARAMCO I-FIELD REQUIREMENTS (SEE ATTACHED). THE
SURFACE UNIT SHALL BE E WITH DRAIN VENT CONNECTIONS ARAMCO SAES-J-
902. SURFACE UNIT SHALL DISPLAY VIA ELECTRONIC VISUAL DISPL CRYSTAL
DISPLAY (LDC) TO DO LOCALLY
1000824872

Material Number
9COM/9CAT
521
Drilling Equipment
(Downhole
Equipment)
PDHMS,4-1/2,VTHC,SINGLE
GAUGE,HPHT
ASSEMBLY; SINGLE HIGH PRESSURE HIGH TEMPERATURE (HPHT) PERMANENT
DOWNHOLE MONITORING (PDHM). TYPE,SIZE: 4-1/2 IN. 1- COMPLETE#ASSEMBLY
WITH ITEMS AS DESCRIBED IN KITS SECTION MUST BE BOXED#AS AN INDIVIDUAL
UNIT FOR SHIPMENT AND STORAGE PER SAUDI ARAMCO#PACKAGING SPEC
844418. 2- MANUFACTURER MUST BAR CODE IDENTIFY#EACH ISSUE UNIT ON
BOTH THE MATERIAL AND OUTSIDE THE CONTAINER#(IN WHICH THE ISSUE UNIT
IS CONTAINED). CODE TO BE IN THE#INTERNATIONAL CODE 39 BAR CODING
SYSTEM FORMAT AND ADHERE TO#ANSI MH10.8M (LATEST EDITION)
SPECIFICATION (LESS SECTIONS 12 &#13). BAR CODE TAG MUST INCLUDE THE
SAUDI ARAMCO STOCK NUMBER AND#PURCHASE ORDER NUMBER. ALL ITEMS
SHOULD BE ASSEMBLED TOGETHER#PRIOR TO TESTING. KIT COMPONENTS: ITEM
QTY DESCRIPTIONS 01 01 SINGLE 4.5#SOLID GAUGE CARRIER PORTED TUBING-
SUPER 13 CR,13.5 LB/FT VAM TOP HC CONNECTION PXP, EXTERNALLY TESTABLE
AEMP TO FIT INSIDE 9-5/8#58.4 LB/FT CASING YIELD STRENGTH 95
KPSI,MAXIMUM OD: 5.55#,DRIFT ID : 3.795# DRAWING NUMBER PAD-P245135-
0049 PART NUMBER : P245135-0049 02 01 SINGLE HIGH PRESSURE/HIGH
TEMPERATURE (175 DEG C,20 KPSI) SURESENS 175 GAUGE READING TUBING
PRESSURE AND TEMPERATURE . QUARTZ SENSOR,CONSTRUCTED ENTIRELY OF
NACE MR0175 COMPLIANT MATERIALS. PHYSICAL PROFILE IS
0.75#DIAMETER/GAUGE. UTILIZES EXISTING HYBRID TECHNOLOGY FOR GAUGE
AND TRANSDUCER ELECTRONIC. PRESSURE RESOLUTION :0.0001 PSI
TEMPERATURE RESOLUTION: 0.0001°C.PRESSURE ACCURACY:±0.02%FULL SCALE.
TEMPERATURE ACCURACY :0.15°C. SAMPLING GATE DURATION(S):<0.1 TO
3.2(CONFIGURABLE) PART NUMBER: P1211-1010 03 01 WELLHEAD OUTLET WITH
# 11 GRAYLOC INTERFACE PRESSURE CONNECTION TO TREE. PRESSURE RATING :
10,000 PSI 04 01 TUBING HANGER PENETRATORS(2 PER WELL) TWO OFF INCOLOY
725 3/8# NPT TO 1/4# SWAGELOCK CONNECTION.
1000837756
522
Drilling Equipment
(Downhole
Equipment)
REAMER,TURBOCASER,7",NVAM,
26#,8.250"OD
REAMER; TURBOCASER TYPE,7 IN 26#, N VAM DIA,7 INCH TURBOCASER EXPRESS
TOOL WITH NEW VAM CONNECTION. MAX BODY OD: 7.67 INCH. TOP
CONNECTION: 7 INCH NEW VAM, 26 PPF. TOOL WEIGHT: 706 LB. REAMER BIT OD:
8.25 INCH. OVERALL LENGTH: 11.1 FT. REAMER PERFORMANCE
CHARACTERISTICS: FLOW RANGE: 0 - 500 GPM. MAX TORQUE ON BIT: 720 LB-FT.
MAX POWER OUTPUT: 80 HP. MAX PRESSURE DROP: 836 PSI.
1000888048

Material Number
9COM/9CAT
523
Drilling Equipment
(Downhole
Equipment)
TUBING,COILED,2-
3/8"TAPERED.156/.204#WT
TUBING; COILED, TAPERED TYPE,2-3/8 IN OD,18000 FT LG,CONTINUOUSLY
MILLED STRING,GR HS-90,THE UNDERBALANCED 2-3/8 IN OD HS90
CONTINUOUSLY MILLED STRING COILED TUBING IS TAPERED AS FOLLOWS: (1)
0.156 IN WALL THICKNESS SECTION (2375-156-9-C): 4,000 FT LONG. (2) 0.175 IN
WALL THICKNESS SECTION (2375-175-9-C): 2,000 FT LONG. (3) 0.190 IN WALL
THICKNESS SECTION (2375-190-9-C): 5,000 FT LONG. (4) 0.204 IN WALL
THICKNESS SECTION (2375-204-9-C): 7,000 FT LONG. THE TOTAL LENGTH IS
18,000 FT. IT WILL BE PROVIDED WITH 7/16 IN OD, 7 CONDUCTORS, ELECTRIC
CABLE (HEPTACABLE). KIT COMPONENTS
1000885164
524
Drilling Equipment
(Advanced Well
Completion
Equipment)
SCREEN,SPIRAL,5-
1/2",VAGT,17#,300MIC,316
SCREEN; LINE SLOT TYPE,SIZE 5.5 INCH,5.50# LINESLOT, 0.012# GAUGE,
300UM/316L, SPIRAL, 17.0LB/FT, VAGT, RANGE 3, L80
1000919001
525
Drilling Equipment
(Downhole
Equipment)
KIT,FRAC,5-
1/2X8.500"2OH,VTHC,20#,PK
PACKER PRODUCTION; STAGE FRAC SYSTEM, BLANK STAGE ASSEMBLY TYPE,7.750
IN MAX OD,4.700 IN MIN ID,9-5/8 IN OD,43.5 - 58.4 LB/FT,5-1/2 IN CONNECTN,20
LB/FT,VAM TOP HC BOX X PIN, C/W COONECTN,10,000 PSI WORKING PRESSURE
SUPPLY,FOR OPEN HOLE: 8-3/8 IN - 8-1/2 IN, MATERIAL: P-110, PULL STRENGTH
THROUGH TOOL: 514,000 LBS, BURST PRESSURE: 10,750 PSI COLLAPSE PRESSURE:
10,300 PSI, EFFECTIVE SHEAR AREA: 8.500 IN2, SHEAR PRESSURE PER PIN: 341
PSI, MAX SHEAR PRESSURE: 4,092 PSI, MAX NUMBER OF SHEAR PINS: 12 PINS,
OVERALL LENGTH: 69.900 IN, WEIGHT: 322.79 LBS, ELASTOMER MATERIAL: HSN
KITS COMPONENTS:
1000823558
526
Drilling Equipment
(Downhole
Equipment)
HANGER,LINER,7X9-
5/8,THS563,26#,125,HYD
HANGER LINER; HYDRAULIC ACTIVATI,7 IN END 1,26 PPF END 1,9-5/8 IN END 2,40 -
47 PPF END 2,HYDRIL 563 END CONN,7 IN 26 PPF HYDRIL 563,7 IN, 26 PPF X 9-5/8
IN 40-47 PPF CONTROL SET LINER HANGER WITH ZXP LINER TOP PACKER AND
SETTING SLEEVE. KIT COMPONENTS
1000847744
527
Drilling Equipment
Cementing
Equipment)
SHOE,FLOAT,13-3/8",VAM
TOP,72#,HC95
SHOE: FLOAT; 13-3/8 IN. 72 LB; HC95 GRADE, VAM TOP, W/12.25 IN. DRILL OUT
ID SHOE FLOAT; CEMENTING TYPE,FOR CEMENTING TOOL,PLASTIC SEAT,GR
HC95,13-3/8 IN CASING OD,72.0 LB/FT,VAM TOP CONNECTN,WITH PLASTIC
VALVE, 12-1/4 IN DRILL OUT ID "PDC DRILLABLE"
1000624831

Material Number
9COM/9CAT
528
Drilling Equipment
(Downhole
Equipment)
VALVE,ICV,3-
1/2",NVAM,5K,718,HVC+ACCUPU
L
SUPPLY,3-1/2 9.3# API E.U.E. B X P THD END CONN,INCONEL 718 / 4140
BODY,CASING SIZE: 7 IN. (17-32 #), MAXIMUM OD: 5.855 IN, MINIMUM ID: 2.75
IN, LENGTH: O.A.L. 136.25 IN, 3-1/2 9.3# API EUE 80K MAT'L CONNECTION
TORQUE (FT-LBS):2,400 MIN, 3,200 OPT., 4,000 MAX, HVC CONNECTION: 3-1/2
10.2# NS-CT B X P THD, 3-1/2 10.2# NS-CT 80K MAT'L CONNECTION TORQUE, (FT-
LBS): 2,530 MIN., 2,890 OPT., 3,250 MAX, SERVICE: STD/H²S/CO², MAX WORKING
TEMP.,275°F, WORKING PRESSURE INTERNAL: 7,500 PSI, WORKING PRESSURE
EXTERNAL: 7,500 PSI, TEST PRESSURE INTERNAL: 8,000 PSI, TEST PRESSURE
EXTERNAL: 8,000 PSI, MAX. HYDRAULIC PRESSURE: 10,000 PSI, WORKING
HYDRAULIC PRESSURE: 7,500 PSI, MAX. DIFF UNLOADING PRESSURE: 5,000 PSI,
HVC CHOKE: 214HVC350022, ACCUPULSE: 213AP1350004, HVC METALLURGY:
718 INC. / 4140, FITTING KIT METALLURGY: 4140 (80K YIELD), ACCUPULSE
METALLURGY: 9CR, FASTENER METALLURGY: 300 SS, TYPE OF SEALS: NON-
ELASTOMERS AND ELASTOMERS, ELASTOMERS F/HYD. CHAMBER: CHEMRAZ,
ELASTOMERS F/ WELLBORE FLUID: VITON, PISTON AREA: 2.075 SQ. IN, TOTAL
STROKE: 6.00 IN, HYD CHAMBER DISPLACEMENT: 12.45 CU. IN, TENSILE RATING:
202,220 LBF, COMPRESSIVE RATING: 200,000 LBF, MIN. INTERNAL FLOW AREA:
5.94 SQ.IN, FLOW AREA BETWEEN OD OF HVC AND ID OF CSG 7 IN. (17#) (6.538
ID): 9.23 SQ IN TOTAL(2.58 SQ. IN. OF TOTAL IS DUE SLOT), FLOW TRIM CHOKE
SETTINGS: 11 POSITIONS (1 X FULLY OPEN, 1 X FULLY CLOSED, 9 X FIXED) 0%,
2.38%, 3.57%, 5.90%, 9.43%, 14.09% 18.75%, 23.41%, 43.63%, 84.06%, 100%,
COIL TUBING SHIFTING TOOL: 290HM0275000, ASSY PICTORAL/ BOM DRAWING:
312557-03-01, TECH DOC: 312025-00-01.
1000780058

Material Number
9COM/9CAT
529
Drilling Equipment
(Advanced Well
Completion
Equipment)
PANEL,CONTROL,HYD-
PANEL; CONTROL, AUTOMATED MULTI-VALVE, 4 VALVE, 1 WELL TYPE,SIZE 56.13
IN HT X 57 IN WD X 40 IN DP,SS AISI 316,ENCLOSURE: NEMA 4X (XPIO) / (IP 56),
POWER REQUIREMENTS: 110/220 V, 60 HZ, WORKING PRESSURE: 6000 PSI WITH
SURFACE DATA LOGGER, NUMBER OF WELLS: 1 (MAX), MAXIMUM NUMBER OF
VALVES: 4 DOWNHOLE CONTROL VALVES, MAXIMUM NUMBER OF DOWNHOLE
GAUGES: 4, WORKING TEMPERATURE: 65 DEG C UNDER SHELTER, AS PER
ARAMCO I - FIELD REQUIREMENTS FOR THE SURFACE DATA LOGGER AND
ATTACHMENT A. SURFACE DATA LOGGER TECHNICAL DESCRIPTION, MAXIMUM
NUMBER OF DOWNHOLE GAUGES: 4, POWER SUPPLY OPTIONS: AC/DC, POWER
CONSUMPTION: 14 W + 1 PER DOWNHOLE GAUGE, MEMORY CAPACITY: 4 MB ON
ONBOARD AND 2 GB COMPACT FLASH, COMMUNICATION PORTS: RS-232, RS-485
AND ETHERNET PORT.
1000827654
530
Drilling Equipment
Cementing
Equipment)
DV TOOL,18-5/8",BTC,87.5-
94.5#,L80,MEC,4
TOOL; CEMENTING TYPE,SIZE 18-5/8 IN,W/FREE-FALL PLUG SET, MODEL 781P4
L80, 87.5-94.50 LB/FT, A5 ELEMENT, INFLATABLE PACKOFF TWO STAGE, CASING
SIZE: 18-5/8 CASING WEIGHT RANGE: 87.5-94.5 LB/FT, CASING GRADE: L-80,
THREADS: BUTTRESS (BTC), ELEMENT MATERIAL: A5, PDC DRILLABLE: YES, O.D
(MAXIMUM): 21.625 IN, PACKER ELEMENT O.D: 20.50 IN, DRILL OUT I.D: 17.659
IN, DRIFT: 17.567 IN, LENGTH OVERALL: 11.8 FT, PACKER ELEMENT LENGTH: 4FT,
OPENING SEAT I.D: 15.500 IN,CLOSING SEAT I.D: 15.125 IN, OPENING PRESSURE
(INNER SLEEVE MOVES TO INFLATE PACKER): 200-500 PSI, PACKER SETTING
PRESSURE (EXTERNAL SLEEVE OPENING), PRESSURE: 400-800 PSI, 8 SCREWS AT
175 PSI SCREW, STAGE TOOL SEALS: FLUOROCARBON O-RING SEALS, CEMENTING
PORTS: SIX 1-1/8 DIA.PORTS, INTERNAL PRESSURE: 2,930 PSI, MAXIMUM
EXTERNAL PRESSURE: 780 PSI, SAFE LOAD BELOW TOOL: 1,312,000 LBS. (S.F. 1.5),
MAXIMUM TEMPERATURE: 250 DEG. F.
1000839640

Material Number
9COM/9CAT
531
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X3-
1/2,NVAM,9.2#,13CR,FTHRU
PACKER PRODUCTION; RETRIEVABLE, PREMIER FEED-THROUGH TYPE,HYDRAULIC
SET ACTIVATI,5.980 IN OD OD,2.945 IN ID NOM. ID,7 IN OD,26-29 LB/FT,3-1/2 IN
CONNECTN,9.2 PPF,NEW VAM BOX X PIN COONECTN,7500 PSI SUPPLY,ISO-
SPEC.14310,WITH 7 EA. X 1/4 IN CONTROL LINE PORTS, MATERIALS: 13%
CHROME, 80 KSI MYS, ELASTOMERS: NITRILE PE, TEMP. RATING: 65-350°F MAX.
THE PACKER SHOULD BE THREADED DIRECTLY PRODUCTION STRING AND SET IN
ONE TRIP BY PRESSING UP AGAINST A PLUGGING DEVICE BELOW THE PACKER.
REMOVAL ON THE PRODUCTION STRING IS ACCOMPLISHED BY USE OF A THRU-
TUBING SHIFT TOOL OR THRU-TUBING CUTTER. THIS MUST BE SUITED FOR
MULTIZONE STACKED PACKER, INTELLIGENT/SMART WELL COMPLETIONS. KIT
COMPONENTS DESCRIPTION ITEM QTY SUB: HYDRAULIC 01 01 SPLICE FOR TOP
AND BOTTOM PF THE PACKER. SIZE: 3-1/2 IN. THREAD: 3-1/2 IN. 9.2 PPF AM NEW
VAM BOX X PIN, TOOL OD: 6.00 IN. TOOL ID: 2.953 IN. LENGTH: 43 IN. MATERIAL:
4140 LOW ALLOY, 80 KSI MYS THIS 3-1/2" SPLICE SUB IS TO ACCOMMODA 5X1/4"
& 1X1/4" ELECTRICAL SPLICE CONNECTIONS PART NO.: H781273508 KIT
COMPPNENTS: ITEM QTY DESCRIPTION 01 01 SUB: HYDRAULIC SPLICE FOR TOP
AND BOTTOM PF THE PACKER.SIZE: 3-1/2 IN. THREAD: 3-1/2 IN. 9.2 PPF AM NEW
VAM BOX X PIN, AM NEW VAM BOX X PIN, TOOL OD: 6.00 IN. LENGTH: 43
IN.MATERIAL: 4140 LOW ALLOY 80 KSI MYS THIS 3-1/2" SPLICE SUB IS TO
ACCOMMODA SPLICE SUB IS TO ACCOMMODA 5X1/4" <(>&<)> 1X1/4"
ELECTRICAL SPLICE CONNECTIONS PART NO.: H781273508
1000781980

Material Number
9COM/9CAT
532
Drilling Equipment
(Downhole
Equipment)
PACKER,ACP,24",BW,176#,4FT
PACKER; 24.00 IN SLIMLINE CLEARANCE ACP W/4 FT ELEMENT, NOMINAL CASING
ID: 22.50, CASING THREADS: ANSI BUTTRESS PIN UP X BLANK PIN DOWN, ACP
OD:25.90 IN, ACP LENGTH :125.0 IN, BURST RATING ON CASING :(API SPEC)3,060
PSI, VALVE BODY MATERIAL 1026 (55,000 PSI YIELD STRENGTH), VALVE BODY
BURST AFTER INFLATION SEQUENCE IS COMPLETED AND THE CLOSING VALVE
HAS CLOSED, ULTIMATE BURST 3,300 PSI, RECOMMENDED MAXIMUM WORKING
PRESSURE 80% OF BURST OF CASING 2,450 PSI, TENSILE YIELD OF THE ACP-
2,450,000 LBF, COLLAPSE RATING OF THE ACP -1,450 PSI, DIFFERENTIAL RATING
OF ACP IN 28.50 IN ID-1500 PSI, MECHANICAL STAGE TOOL, CASING SIZE : 24 IN,
CASING WEIGHT RANGE :176.00 LB/FT (PE), CASING GRADE: X-56, THREADS
:BUTTWELD (PREPPED FOR WELD ON CONNECTION SUCH AS VETCO RL-4S ),
O.D.(MAXIMUM): 25.125 IN, DRILL OUT I.D.: 22.250 IN, LENGTH OVERALL: 44.5 IN
(APPROXIMATE), OPENING SEAT I.D.: 17.250, CLOSING SEAT I.D.: 19.960,
OPENING PRESSURE: 400-600 PSI, CLOSING PRESSURE: 800-PSI, STAGE TOOL
SEALS: STRILE O-RING SEALS, CEMENTING PORTS: SIX 1-1/8 DIA.PORTS,
MAXIMUM INTERNAL PRESSURE : 217 PSI, MAXIMUM EXTERNAL PRESSURE :1083
PSI, SAFE LOAD BELOW TOOL: 1361000 LBS.(S.F1.5), MAXIMUM TEMPERATURE
:275 DEG F, ALL ITEMS SHOULD BE ASSEMBLED TOGETHER PRIOR TO TESTING KIT
COMPONENTS
1000820392
533
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,5-
1/2X8.50"OH,NVAM,17#,L80
PACKER PRODUCTION; OH SWELL PACKER TYPE,8.000 IN OD,4.892 IN ID,8-1/2 IN
OPEN HOLE OD,5-1/2 IN CONNECTN,17.0 PPF,NEW VAM BOX X PIN COONECTN,5-
1/2 IN SWELL REPACKER, BASE PIPE MATERIAL: L-80 STEEL, SEAL MATERIAL: OIL
SWELL ELEMENT, SEAL LENGTH: 20 FT, JOINT LENGTH: 30 FT.
1000845069
534
Drilling Equipment
(Downhole
Equipment)
TUBING,COILED,2-
3/8",TAPERED.134/.204"WT
TUBING; COILED, STRING, TAPERED HS-90 TYPE,2-3/8 IN OD,18,000 FT LG,GR HS-
90,CONTINUOUSLY MILLED STRINGS OD ARE TAPERED ASFOLLOW: 0.134 IN WALL
THICKNESS SECTION -3,500FT(2375-134-9-C) 0.145 IN WALL THICKNESS SECTION -
2,000FT(2375-145-9-C), 0.156 IN WALL THICKNESS SECTION -2,000FT(2375-156-9-
C), 0.175 IN WALL THICKNESS SECTION -2,000FT(2375-175-9-C), 0.190 IN WALL
THICKNESS SECTION -5,000FT(2375-190-9-C), 0.204 IN WALL THICKNESS SECTION -
3,500FT(2375-204-9-C), WITH 7/16 IN OD 7-CONDUCTORS ELECTRIC CABLE
(HEPTACABLE) INSTALLED EXTRA LENGTH FOR SLACK
1000823039
535
Drilling Equipment
(Downhole
Equipment)
LAUNCHER,5-
1/2X7,XPC,18.24#,COMPACT,SES
LAUNCHER; COMPACT TYPE,SIZE 5-1/2 IN 18.24 IB/FT X 7 IN 26 LB/FT,SOLID
EXPANDABLE TUBULAR (SET), COUPLED WITH CONNECTION SLEEVE, MATERIAL:
EX-80, CONNECTION: ENVENTURE PROPRIETARY XPC PIN UP LENGTH: 6 FT
1000819335

Material Number
9COM/9CAT
536
Drilling Equipment
(Downhole
Equipment)
PACKER,TIEBACK,5",NVAM,18#
PACKER, LINER: LINER, TOP ISOLATION PACKER, TYPE JMZX 5 IN 18 LB/FT NEW
VAM PIN,TOOL OD 5.819 IN X TOOL ID 4.276 X PACKER LINER; LINER, TOP
ISOLATION PACKER, TYPE JMZX 5 IN 18 LB/FT NEW VAM PIN,TOOL OD 5.819 IN X
TOOL ID 4.276 X SEAL OD 5.250 IN
1000024966
537
Drilling Equipment
(Downhole
Equipment)
VALVE,ISOL,7",NVAM,174PH,4.9
90"ID
VALVE; LARGE BORE FLAPPER TYPE,SIZE 9-5/8 IN,ID: 4.990 IN, OD: 8.237 IN,
OVERALL LENGTH: 23 IN, LOWER THREAD: 7 IN NEW VAM PIN, UPPER THREAD: 7
IN NEW VAM BOX, ACTIVE FLOW WETTED MATERIAL: 17-4 PH, ALL ITEMS
SHOULD BE ASSEMBLED TOGETHER PRIOR TO TESTING
1000815456
538
Drilling Equipment
(Downhole
Equipment)
VALVE,SAFETY,3-
1/2",NVAM,CRA,TRSSSV
VALVE; TUBING-RETRIEVABLE SUBSURFACE SAFETY (FLAPPER) TYPE,SIZE 3-1/2
IN,3 1/2-9.20 NEW VAM BOX X3 1/2-9.20 NEW VAM PIN END CONN,9CR-
1MO/410/17-4PH BODY,NACE MR0175/ISO 15156,API-1 NACE MR-01-75/,ISO
1515 API MONOGRAMMED,API-14A,CLOSURE TYPE FLAPPER. SIZE 3 ½. LOCK
PROFILE: X. MIN ID WITHOUT PACKING BORE: 2.840 INCH. TOP SEAL BORE ID-
MIN: 2.813 INCH. BOTTOM SEAL BORE ID MIN: 2.813 INCH. MAX OD: 5.20 INCH.
LENGTH: 56.08 INCH. MATERIAL: 9CR-1MO/410/17-4PH. SERVICE: H2S. SERVICE
REMARKS: H2S SERVICE BASED ON CUSTOMER DEFINED, WELL SPECIFIC
CONDITIONS. APPLICATIONS MUST BE REVIEWED FOR SPECIFIC ENVIRONMENTAL
COMPATIBILITY. MEETS MATERIAL SERVICE REQUIREMENTS OF: NACE
MR0175/ISO 15156. TOP THREAD: 3 ½ IN, 9.20 PPF VAM-NEW. BOTTOM THREAD:
3 ½ IN, 9.20 PPF VAM-NEW. CONNECTION TYPE: BOX-PIN. TUBING THREAD
TORQUE: 3250 FOOT POUND. PRESSURE RATING 5000 PSI. BURST PRESSURE:
9436 PSI. API COLLAPSE PRESSURE AT AMBIENT: 7195 PSI. TENSILE WITH WORK
PRESS, WITHOUT TBG THD, AT AMBIENT, CALC/1000: 216 POUND. TENSILE
WITHOUT WORK PRESS, WITHOUT TBG THD, AT AMBIENT, CALC/1000: 296
POUND. TEMPERATURE RATING: 20:300 DEG. F. MAXIMUM FULL OPEN
PRESSURE: 1900 PSI. MINIMUM CLOSING PRESSURE: 600 PSI. PISTON
DISPLACEMENT VOLUME: 0.75 CU. INCH. EQUALIZING FEATURE: YES. MAXIMUM
PRESSURE DIFFERENTIAL AT VALVE OPENING: 5000 PSI. CONTROL LINE PRESSURE
TO EQUALIZE AT PRESSURE RATING: 4000 PSI. CONTROL LINE CONNECTION: 7/16-
20 HIF. COMMUNICATION TYPE: NE. LOCKOUT TYPE: NE. ISOLATION ASSEMBLY
LOCK MANDREL TYPE: 2.813 X. ISOLATION ASSEMBLY EQUALIZING VALVE TYPE:
2.813 XO. SEAT INSERT TORQUE-MIN: 2000 FOOT POUND.
1000845391

Material Number
9COM/9CAT
539
Drilling Equipment
(Downhole
Equipment)
COLLAR,SETTING,7",NK3SB,29#,4
1XX,TBR12FT
COLLAR: SETTING; W/TYPE LG-12 TBR AND RPOB PROFILE F/7 IN GEN-2 LINER
HANGER; IN VERTICAL KHUFF GAS WELLS COLLAR TIE BACK; 7 IN OD,6.184 IN
MIN. I.D. ID,NK-3SB PIN DOWN END CONN,NACE MR-01-75,FOR 7 IN
GENERATION-2 KHUFF LINER HANGER SYSTEMS IN VERTICAL WELLS. KITS
COMPONENTS
1000024083
540
Drilling Equipment
(Downhole
Equipment)
KIT,PACKER,LINER,7X3-
1/2",EUE,F/SCREEN
PACKER LINER; 'QUANTUM' NON-CEMENTED KIT TYPE,4140 L-80,FOR SCREEN
HANGING SYSTEM,6.083 IN OD,7.00 IN OD,23-26 LB/FT,4.937 - 6 IN-8 STUB ACME
PIN DOWN CONNECTN,MR0175/ISO 15156,6,000 PSI RATING ELEMENT, USED ON
7 INCH CASING, 1. COMPLETE ASSEMBLY WITH ITEMS AS DESCRIBED IN KITS
SECTION MUST BE BOXED AS AN INDIVIDUAL UNIT FOR SHIPMENT AND STORAGE
PER SAUDI ARAMCO PACKAGING SPEC 844418. 2. MANUFACTURER MUST BAR
CODE IDENTIFY EACH ISSUE UNIT ON BOTH THE MATERIAL AND OUTSIDE THE
CONTAINER IN WHICH THE ISSUE UNIT IS CONTAINED. CODE TO BE IN THE
MH10.8 ( LATEST EDITION) SPECIFICATION (LESS SECTIONS 12 & 13). BAR CODE
NUMBER. ALL ITEMS SHOULD BE ASSEMBLED TOGETHER PRIOR TO TESTING. KITS
COMPONENTS
1000807103
541
Drilling Equipment
(Downhole
Equipment)
TUBING,HYDRAULIC,1/4",0.049",
MONEL,300FT
SAFETY VALVE COMPONENTS: TUBING: MONEL, ASTM B165; ANNEALED; 1/4 IN.
OD; HYDROTESTED; OR NON-DESTRUCTIVE EXAMINATION (NDE) 300 FT TUBING
METALLIC STOCK; 1/4 IN OD,91.44 M (300 FT) LG,MONEL,ANNEALED,ASTM
B165,CONTINUOUS LENGTH COIL ON SPOOL, HYDROTESTED OR NON-
DESTRUCTIVE EXAMINATION (NDE) FOR SUBSURFACE SAFETY VALVE ASSEMBLIES
1000026406
542
Drilling Equipment
(Downhole
Equipment)
PACKER,SWELL,4-
1/2X5.60"',NVAM,12.6#,L80
PACKER PRODUCTION; SWELL TYPE,FOR OIL,4.5 IN OD,3.958 IN ID,12.6 PPF,NEW
VAM COONECTN,SWELLPACKER, 4.5 IN X 5.6 IN X 3 M, BASEPIPE OD: 4.5 IN,
BASEPIPE WEIGHT: 12.6 PPF, BASE MATERIAL: L80, THREAD TYPE: NEW VAM, END
RING MATERIAL: ST52, PACKER ELEMENT OD: 5.6 IN, PACKER ELEMENT LENGTH:
118.1 IN, TOTAL PACKER LENGTH: 236.2 IN, PACKER DRIFT ID: 3.833 IN, PACKER
NOMINAL ID: 3.958 IN, MINIMUM HANDLING SPACE BOX END: 50 IN, MINIMUM
HANDLING SPACE PIN END: 50 IN, COUPLING LENGTH: 9.921 IN, COUPLING OD:
4.892 IN, ENDRING LENGTH: 2.2 IN, ENDRING OD: 5.58 IN, MAX H2S LEVEL STD.
POLYMER: 0.5 %, HOLE SIZE: 6.125 IN
1000769329

Material Number
9COM/9CAT
543
Drilling Equipment
(Downhole
Equipment)
PIPE,5-
1/2,VETW,17#,VM50,30FT,EXPA
ND,SES
HANGER LINER; MECHANICAL ACTIVATI,FOR STD,5-1/2 IN X 7 IN METALSKIN
CASING STRING : OUTSIDE DIAMETER: 7.00 IN, WEIGHT ¿OPEN -HOLE LINER,
(LB/FT): SEE CHART BELOW, EXPANDABLE BASE PIPE : GRADE: ANY, CONNECTION
OUTSIDE DIAMETER: 5.500 IN, SEALABILITY : METAL TO WALL THICKNESS: 0.304
IN INSIDE DIAMETER: 4.892 IN, METAL, PREVIOUS CASING DRIFT DIAMETER:
4.767 IN, STRING OTSIDE DIAMETER: 7.00 IN, WEIGHT (LB/FT): WEIGHT : 17.0
LB/FT, GRADE: SEE CHART, GRADE: ANY VM50, SEAMLESS TUBING : YES,
CONNECTION TYPE: VAM ET WISE, CONNECTION PROTECTIVE SLEEVE: YES,
PROTECTIVE SLEEVE OD: 5.703 IN, CONE HOUSING RUNNING DIA (IN): 23 LB-29
LB/6.00, CONE HOUSING RUNNING DIA (IN): 32LB/5.850, WELL PARAMTERS :
MINIMUM OPEN HOLE SIZE: 7.00 IN, MAXIMUM HOLE ANGLE(DEG): ANY
INCLINATION, MAXIMUM DOGLEG SEVERITY EXPANDED SECTION: 12 DEG/100 FT,
SOUR SERVICE : WELL-SPECIFIC, CONNECTION SEALABILITY :METAL-TO-METAL,
PREVIOUS
1000831473
544
Drilling Equipment
(Downhole
Equipment)
COLLAR,SETTING,4-
1/2,NK3SB,13.5#,TBR12FT
COLLAR: SETTING, TYPE LG-12, & TBR, RP- RRP-RPOB PROFILE F/4-1/2 IN GEN-2
KHUFF LINER HANGER IN HORIZONTAL GAS WELLS COLLAR TIE BACK; 4-1/2 IN
OD,NK-3SB END CONN,NACE MR-01-75,FOR 4.5 IN. GENERATION-2, KHUFF LINER
HANGER SYSTEMS IN HORIZONTAL KHUFF GAS WELLS KITS COMPONENTS
1000024132
545
Drilling Equipment
(Downhole
Equipment)
LAUNCHER,16X18-
5/8",XPC,EX80,COMPACT,SES
LAUNCHER; COMPACT TYPE,SIZE 16 IN,16 IN X 18-5/8 IN, 115 PPF, 17 IN OD,
COMPLETE WITH CONNECTION SLEEVE, EX-80 MATERIAL, XPC PIN UP
CONNECTION
1000886902
546
Drilling Equipment
(Downhole
Equipment)
PBR/SEAL,4-
1/2",NK3SB,13.5#,41XX110,24FT
RECEPTACLE: POLISHED BORE, TO RUN WITH 4-1/2" GEN-2 'SN-AT-12' PACKER
RECEPTACLE; PBR TYPE,SIZE 5.813" OD X 5.250" ID X 24',41XX-SOUR SERVICE-
110,000 PSI MIN YIELD (P-110),NACE MR-01-75-97,TO BE RUN WITH 4-1/2" "GEN-
2 'SN-AT-12' PACKER KITS COMPONENTS
1000609482
547
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,7",SPIRAGLIDER,8.
125"OD,SC
CENTRALIZER: CASING; 7 IN. OD; SLIP-ON, SEMI-RIGID, SPIRAGLIDER .
CENTRALIZER CASING; SLIP-ON, SEMI-RIGID, SPIRAGLIDER TYPE,9-5/8 IN 36-53.5
LB/FT OR 8-3/8 IN MIN ID. OPEN HOLE CASING,7 IN NON-UPSET OD,8-1/4 IN MAX
BOW OD,STYLE 6-BLADE, SPIRAL,36-53.5 LB/FT,NRA,USE WITH STOP COLLARS
1000022719
548
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,9-
5/8",SPIRAGLIDER,11.75"SC
CENTRALIZER: CASING; 9-5/8 IN. OD; SLIP-ON, SEMI-RIGID, SPIRAGLIDER .
CENTRALIZER CASING; SLIP-ON, SEMI-RIGID, SPIRAGLIDER TYPE,13-3/8 IN, 54.5-86
LB/FT OR 12 IN MIN ID OPEN HOLE CASING,9-5/8 IN NON-UPSET OD,11-3/4 IN
MAX BOW OD,STYLE 8-BLADE, SPIRAL,54.5-86 LB/FT,USE WITH STOP COLLARS,
8444-18
1000022752

Material Number
9COM/9CAT
549
Drilling Equipment
Cementing
Equipment)
CENTRALIZER,9-
5/8",RIGID,HINGED,12.125"
CENTRALIZER: CASING; FOR 9-5/8 IN. OD CASING TO FIT INSIDE 13-3/8 IN., 61 TO
72 LB/FT CASING; CENTRALIZER CASING; POSITIVE TYPE,13-3/8 IN CASING,9-5/8
IN OD,12.1250 IN BOW OD,STYLE NON-WELDED HINGE WITH PREFORMED RIGID
BOWS,61.0-72.0 LB/FT,TYPE "PO-V", WITHOUT HINGE PINS
1000022710
550
Drilling Equipment
(Downhole
Equipment)
1/2,NVAM,12.6#,RET
PACKER PRODUCTION; PREMIER RETRIEVABLE TYPE,FOR H2S,WIRELINE OR
HYDRAULIC SER ACTIVATI,8.540 IN OD,3.875 IN ID,9-5/8 IN OD,40-47 LB/FT,4-1/2
IN CONNECTN,12.6 LB/FT,4-1/2 IN, 12.6 PPF NEW VAM PIN X PIN
COONECTN,5,000 PSI SUPPLY,BMS A099 LOW ALLOY CARBON STEEL, 8C 18-22RC
MATERIAL, WITH HNBR PACKING ELEMENT, NITRILE O-RINGS WITH TEFLON BACK-
UPS, SET WORKING PRESSURE: 4000 & 7500 PSI, TEMPERATURE RATING: 100-350
DEG F. KITS COMPONENTS
1000764263
551
Drilling Equipment
(Downhole
Equipment)
MILL,PATHMAKER,8.375",WINDO
W/FORMATION
MANDREL; SIZE 8.375 IN,PATHMAKER WINDOW FORMATION MILL
1000839813
552
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,NVAM,12.6#,ALLOY
PACKER PRODUCTION; VHR SINGLE TRIP TYPE,FOR H2S,8.460 IN OD,3.880 IN ID,9-
5/8 IN OD,40-47 LB/FT,5-1/2-6ACLH X 4-1/2 IN, 12.6 PPF NVAM CONNECTN,12.6
LB/FT (BOTTOM),BOX-PIN COONECTN,PLUGGED: 5,000 PSI ABOVE, 5,000 PSI
BELOW, UNPLUGGED WITH 4-1/2 IN TUBING :6,000 PSI ABOVE, 5,000 PSI BELOW
SUPPLY,NACE MR0175,ALLOY, 80,000 PSI YIELD STRENGTH 5.250-6 RTH LTH LH,
BURST PRESSURE: 8,430 PSI, COLLAPSE PRESSURE: 7,500 PSI, TENSILE STRENGTH:
288,000 LBS, SETTING PRESSURE: MINIMUM:2,000 PSI, MAXIMUM: 5,000 PSI,
TEST PRESSURE: 300 PSI KIT COMPONENTS
1000765770
553
Drilling Equipment
(Advanced Well
Completion
Equipment)
VALVE,ICV,3-
1/2",EUE,9.3#,CRA,ODIN
VALVE; ODIN FLOW CONTROL VALVE TYPE,SIZE 3-1/2 INCH,9.3 PPF EUE BOX X PIN
END CONN, TUNGSTEN CARBIDE TRIM,3-1/2 INCH ODIN FLOW CONTROL VALVE
9.3 PPF EUE BOX X PIN END CONN 9CR-1MO/4140,INC718, TUNGSTEN CARBIDE
TRIM, EXTERNAL WORKING PRESSURE 6500 PSI, INTERNAL DIA.:2.812 IN MIN
LENGTH: 136 IN, MAX FLOW RATE: 40000 BBL/DAY, MAX WORKING TEMP.:
325DEGF MIN WORKING TEMP.: 40DEGF, MAJOR OD: 5.850 IN, SEAL BORE SIZE:
2.812 IN, NO.#OF BYPASS CONTROL LINES:4. THE TUBING RETRIEVABLE FLOW
CONTROLLER PROVIDE REMOTELY ACTUATED DOWNHOLE CONTROL OF FLOW
FROM THE RESERVOIR. THE SYSTEM IS OPERATED BY TWO 0.25-IN HYDRAULIC
CONTROL LINE THAT IS ROUTED FROM THE SURFACE CONTROLS TO THE CHOKE
SECTION OF THE TOOL. MAX DIFFERENTIAL OPENING PRESSURE:3000 PSI AND
INTEGRAL#SHIFTING PROFILE FOR MECHANICAL OVERRIDE CONTINGENCY.
1000904428

Material Number
9COM/9CAT
554
Drilling Equipment
Cementing
Equipment)
COLLAR,FLOAT,24",JVLW,176#,IS
C
COLLAR FLOAT; CEMENTING TYPE,STYLE SS3 VALVE, ALUM. RECEPTACLE,24 IN
OD,176.0 LB/FT,JV-LW BOX UP X PIN DOWN,22.2450 IN DRILL ID,API 5B,WITH SS3
VALVE AND ISC PROFILE AND 5.5 IN X 5 IN DRILL PIPE DISPLACEMENT DART, "PDC
DRILLABLE"
1000736660
555
Drilling Equipment
(Downhole
Equipment)
PACKER,PROD,7X4-
1/2,VAM,12.6#,ALLOY
PACKER, PRODUCTION: RETRIEVABLE, H2S, HYDRAULIC SET, 6.000 IN OD, 3.880 IN
ID, 7.00 IN CASING OD, 26-29 LB/FT, PACKER PRODUCTION; RETRIEVABLE
TYPE,FOR H2S,HYDRAULIC SET ACTIVATI,6.000 IN OD,3.880 IN ID,7.00 IN OD,26-
29 LB/FT,4-1/2 IN (BOTTOM THREAD) CONNECTN,12.6 LB/FT,VAM - NEW PIN
COONECTN,6000 PSI SUPPLY,MATERIAL: ALLOY, LENGTH: 83.68 IN,
TEMPERATURE: 325 DEG F, UPPER SEAL BORE ID: 5.00 IN MIN., TYPE LATCH:
5.250-6 RTH LTH, WITH A HYDRAULIC SETTING TOOL PART NO. 12VRR38812-E
KITS COMPONENTS: ITEM 01,QTY 01, DESCRIPTION PACKER: PRODUCTION, 'VSR',
CASING SIZE:7" 26-29 LB/FT, 6.00" MAX OD, 3.88" MIN ID, 83.68" LG, 5.00" MIN
SEAL SEAL BORE ID, H2S SERVICE, ALLOY MATERIAL, 4-½"-12.6 VAM-NEW PIN
BOTTOM THREAD, 5.250-6RTH LTH LATCH TYPE, W/ AFLAS ELEMENTS WITH
BRASS BACK-UP SHOES. RATINGS: PRESSURE (UNPLUGGED): 6,0000 PSI TENSILE
STRENGTH (CALC):170,400 LBS MATERIAL NO.: 145034 ITEM 02,
QTY01,DESCRIPTION RECEPTACLE: POLISHED BORE (PBR), W/ SEAL ASSEMBLY, 7 X
5.00", 4-1/2" VAM-NEW, 15 FT, VTR, 3.85" MIN ID, 5.875" MAX OD,5.00" SEAL
BORE ID,279.5" LENGTH, PBR-ALLOY/PSA 9CR-1MO, 5-1/2-6 ACME BOX PBR TOP
THREAD, 4-1/2"-12.6 VAM-NEW BOX TOP THREAD, 4-1/2-13.5 VAM-NEW PIN
BOTTOM THREAD, SEAL MATERIAL: VTR, TEMPERTURE: 40-350 DEG F, PRESSURE
RATING: 7,500 PSI, CALCULATED TENSILE STRENGTH: 288,000 LBS, STROKE: 180"
UP. PBR RETRIEVING TOOL: NO. 212L7276 SEAL ASSEMBLY: NO. 144866 PB
RECEPTACLE: NO. 145284 MATERIAL NO. 144679 ITEM 03, QTY01,DESCRIPTION
RATCH LATCH ASSEMBLY: 5.250-6 LH TYPE, 5.29" MAX OD, 3.938" MIN ID, 5.076"
SEAL OD, 5.00" MATING SEAL BORE ID, 40.25" LG, , 4-1/2"-12.6 VAM-NEW BOX,
MATERIAL: ALLOY 80MY-22RC MAX, SEAL MATERIAL: VTR, TEMPERATURE: 40-350
DEG F, SERVICE: H2S, PRESSURE RATING: 7,500 PSI, CALCULATED TENSILE
STRENGTH: 207,400 LBS, DEBRIS SHROUD: TEFLON. MATING PACKER: NO. 812
VSR 71138-V (145034) MATERIAL NO. 144678.
1000669725

Material Number
9COM/9CAT
556
Drilling Equipment
Cementing
Equipment)
COLLAR,STOP,4-
1/2",SLIPON,2.00",DHP
COLLAR CASING STOP; SLIP-ON, SPIR-O-LOK, 4-1/2 IN TYPE,FOR POSITIONING
CENTRALIZERS,INTERNAL DIA.: 4.625 INCH, OUTSIDE DIA.: 5.25 INCH, LENGTH: 2
INCH, NO. OF SCREWS: 8 EACH, SIZE OF SCREW: 1/2 INCH DIA., MATERIAL: CAST
DUCTILE IRON, FOR 4-1/2" X 6" SPIR-O-LIZER CENTRALIZER,
1000803585
557
Drilling Equipment
(Gas Wellhead
Equipment)
SPOOL ASSY: TUBING; PSL 3-4
SPOOL TUBING WELLHEAD; CARBON,FOR H2S, CO2, AMINE,API RING
JOINTFLANGE TOP CONN,API RING JOINT FLANGE BTM,API RING JOINT
STUDDEDOUTLET,API 6A,NACE MR0175,PSL 3 AND 4,MR EE,PR 2 (APPENDIX
F),TRU (SUITABLE FOR 300 DEG F MAX),API MONOGRAMMED
6000003757
558
Drilling Equipment
(Wellhead Production
Trees)
TREE: PRODUCTION; KHF; 10M-
15M
TREE PRODUCTION; KHUFF TREE TYPE,HH,FOR H2S, CO2, AMINE,10M-15MPSI
BODY,10M-15M PSI FLG,45-SAMSS-005,API-6A NACE MR0175,PSL 3(PSL 4 GAS
TEST),MR HH,PR 2 (APPENDIX F),TR U (SUITABLE FOR 300DEG F MAX),API 6A
MONOGRAMMED
6000003773
559
Drilling Equipment
(Gas Wellhead
Equipment)
BONNET: TUBING; KHF;
W/LMMV; 10-15M
BONNET TUBING WELLHEAD KHUFF; CARBON (WITH CLAD WETTED
SURFACES),FOR H2S, CO2, AMINE,10-15M PSI TOP,API RING JOINT FLANGE TOP
CONN,10-15M PSI BOTTOM,API RING JOINT STUDDED BTM,45-SAMSS-005,API-6A
NACE MR0175,PSL 4,MR HH,PR 2 (APPENDIX F),TR U (SUITABLE FOR 300 DEG F
MAX), HAS BUILT IN SPLIT GATE LMMV API 6A MONOGRAMMED
6000003641
560
Drilling Equipment
(Gas Wellhead
Equipment)
BONNET: TUBING; KHF; 10-15M
BONNET TUBING WELLHEAD KHUFF; FOR H2S, CO2, AMINE,10-15M PSI TOP,API
RING JOINT STUDDED TOP CONN,10-15M PSI BOTTOM,API RING JOINT STUDDED
BTM,API-6A,NACE MR0175 45-SAMSS-005,PSL 4,PR 2 (APPENDIX F),TR U
(SUITABLE FOR 300 DEG F MAX), BONNET ONLY, NO BUILT IN LMMV API
MONOGRAMMED
6000003637
561
Drilling Equipment
(Oil Wellhead
Equipment)
COMPLETION ASSY: TUBING;
WLHD; 2-5M
COMPLETION ASSEMBLY TUBING; WELLHEAD, OIL TYPE,PR API 2 - 5MPSI,FOR
H2S, CO2 AND AMINE,PSL 2,MR DD,PR 2 (APPENDIX F),TRU,API-6A,NACE MR0175
45-SAMSS-005,TO BE API MONOGRAMMED
6000003659
562
Drilling Equipment
(Oil Wellhead
Equipment)
SPOOL ASSY: TUBING; 2-5M
SPOOL TUBING WELLHEAD; CARBON,FOR H2S, CO2, AMINE,2-5M PSITOP,API
RING JOINT FLANGE TOP CONN,2-5M PSI BOTTOM,API RINGJOINT FLANGE
BTM,45-SAMSS-005,API-6A NACE MR0175,PSL 2,MR DD,PR2 (APPENDIX F),TR
U,API 6A MONOGRAMMED
6000003755
563
Drilling Equipment
(Oil Wellhead
Equipment)
FLANGE: DSPO & ADPT; 2-5M
PACK-OFF DOUBLE STUDDED; CARBON,FOR H2S, C02, AMINE,2-5M PSITOP,API
RING JOINT STUDDED TOP CONN,2-5M PSI BTM,API RING JOINTSTUDDED BTM,45-
SAMSS-005,API-6A NACE MR0175,PSL 2,MR DD,PR 2(APPENDIX F),TR U,API 6A
MONOGRAMMED
6000003687
564
Drilling Equipment
(Gas Wellhead
Equipment)
HANGER; ASSY: TUBING; 10M-
15M
HANGER TUBING WELLHEAD; UNS 7718,FOR H2S, CO2, AMINE,PR 10M-15M
PSI,API-6A,NACE MR0175 45-SAMSS-005,PSL 4,MR HH,PR 2 (APPENDIX F),TR U
(SUITABLE FOR 300 DEG F MAX),API MONOGRAMMED
6000003709

Material Number
9COM/9CAT
565
Drilling Equipment
(Gas Wellhead
Equipment)
SPOOL ASSY: CASING HEAD
SPOOL CASING HEAD; CARBON,FOR H2S, CO2, AMINE,API RING JOINTFLANGE
TOP CONN,45-SAMSS-005,API-6A NACE MR0175,PSL 2,MR DD,PR 2(APPENDIX
F),TR U,API 6A MONOGRAMMED
6000003745
566
Drilling Equipment
(Gas Wellhead
Equipment)
VALVE: GATE; HYD; SSV; WHLD;
10M-15M
VALVE GATE WELLHEAD; HYD ACTUATED FAIL-SAFE OPERATED,FOR H2S, CO2,
AMINE,PR 10M-15M PSI,API RING JOINT FLANGE END CONN,API 6A,NACE MR-01-
75,PSL 3 (PSL 4 GAS TEST),MR HH,PR 2 9APPENDIX F),TR U (SUITABLE FOR 300
DEG F MAX),API MONOGRAMMED
6000003799
567
Drilling Equipment
Trees)
TREE: PRODUCTION; OFFSHORE;
2-5M
TREE PRODUCTION; OFFSHORE TREE TYPE,CARBON,FOR H2S, CO2, AMINE,2-5M
PSI BODY,2-5M PSI FLG,API RING JOINT FLG,API-6A,NACE MR0175 45-SAMSS-
005,PSL 2,MR EE,PR 2 (APPENDIX F),TR U,API MONOGRAMMED
6000003775
568
Drilling Equipment
(Wellhead Equipment
Spares)
VALVE: GATE; MAN; WLHD; 10M-
15M
VALVE GATE WELLHEAD; MANUAL OPERATED,FOR H2S, CO2, AMINE,PR 10M-
15M PSI,API RING JOINT FLANGE END CONN,API 6A,NACE MR-01-75,PSL 3 (PSL 4
GAS TEST),MR HH,PR 2 (APPENDIX F),TR U (SUITABLE FOR 300 DEG F MAX),API
MONOGRAMMED
6000003787
569
Drilling Equipment
(Gas Wellhead
Equipment)
VALVE: BACKPRESSURE; & TWCV;
WLHD
VALVE BACKPRESSURE WELLHEAD; FOR HS2, CO2, AMINE,UNS 7718BODY,45-
SAMSS-005,NACE MR0175 6000003789
570
Drilling Equipment
Trees)
TREE: PRODUCTION; ONSHORE; 2-
5M
TREE PRODUCTION; ONSHORE TREE TYPE,CARBON,FOR H2S,CO2,AMINE,2-5M PSI
BODY,2-5M PSI FLG,API RING JOINTFLG,45-SAMSS-005,API-6A NACE MR0175,PSL
2,MR EE,PR 2 (APPENDIXF),TR U,API 6A MONOGRAMMED
6000003777
571
Drilling Equipment
(Oil Wellhead
Equipment)
HANGER ASSY: TUBING; 2-5M
HANGER TUBING WELLHEAD NON-KHUFF; CARBON,FOR H2S, CO2, AMINE,PR2-
5M PSI,API-6A,NACE MR0175,PSL 2,MR DD,PR 2 (APPENDIX F),TRU,API
MONOGRAMMED
6000003707
572
Drilling Equipment
(Gas Wellhead
Equipment)
SUB-SEA WELLHEAD SYSTEM, 2M-
15M
UNIT; SUB-SEA WELLHEAD SYSTEM, 2M-15M TYPE,API SPECIFICATION 17 D,PSL 2,
3, 3G AND 4 6000014703
573
Drilling Equipment
(Drilling Items, Other)
PUMP, CENTRIFUGAL, VERTICAL -
LINESHAFT
PUMP CENTRIFUGAL; VERTICAL - LINESHAFT TYPE,SIZE 8 IN X 3 IN X 1-11/16
IN,1000 GPM AT 600 FT TDH, 1780 RPM,11 STAGE(S),DIESEL ENGINE
DRIVER,CASING, IMPELLERS AND SHAFT WET PART,STEEL CASING,17-4PH SS
SHAFT,BRONZE IMPELLER,VIL, ENCLOSED LINESHAFT MTG,14 IN SHAFT STICK UP,
DYNAMICALLY-BALANCED IMPELLER, BOWL SHAFT DIA.: 1.6875 IN, BOWL
MATERIAL: CAST IRON W GLASS ENAMEL STD., SUCTION BELL BEARING: BRONZE,
BOWL BEARING MATERIAL: BRONZE, STRAINER MATERIAL: GALVANIZED STEEL
(CONE), SERVICE: NON-TOXIC WATER, 70 DEG F, SP. GR.: 1.0
1000751965

Material Number
9COM/9CAT
574
Drilling Equipment
COUPLING: TUBE, 3 IN, STEEL,
COUPLING; TUBE TYPE,SIZE 3 IN,STEEL,SEAMLESS,WITH OIL IMPREGNATED
REDWOOD INNER LINING, FOR WESTERN TYPE C LEFT HAND THD WATERWELL
TUBES, MARLEY CO LAYNE & BOWLER INC DWG #1727 A
1000240014
575
Drilling Equipment
HOOK: BLOCK OR COMBINATION
HOOK; HOOK OR BLOCK OR HOOK/ BLOCK COMBINATION, API COMPLIANT
6000004095
576
Drilling Equipment
BLOCK: CROWN
BLOCK; CROWN TYPE,API COMPLIANT
6000004101
577
Drilling Equipment
RIG AND/OR DERRICK: DRILLING
DERRICK; DRILLING TYPE,DRILLING,API COMPLIANT
6000004103
578
Drilling Equipment
PANEL: CONTROL; DRILLING; &
COMPONENTS
PANEL CONTROL; DRILLING CONTROL PANEL AND COMPONENTS TYPE,AB. AND
COMPONENTS,API COMPLIANT 6000004109
579
Drilling Equipment
DRAWWORKS: DRLG RIG; &
ASSOC EQUIP
CATHEAD DRAWWORKS; AIR CONTROL TYPE,AIR CONTROL,AUTOMATIC, API
COMPLIANT 6000004111
580
Drilling Equipment
BOARD: MONKEY; DRLG RIG
BOARD; MONKEY TYPE,MONKEY,MONKEY BOARD
6000004151
581
Drilling Equipment
PUMP: MUD; DRILLING
PUMP; MUD TYPE,DRILLING, API COMPLIANT
6000004153
582
Drilling Equipment
TABLE: ROTARY; DRLG
TABLE; ROTARY TYPE,API COMPLIANT, RIG FLOOR ROTARY TABLE
6000004175
583
Drilling Equipment
SWIVEL: ROTARY; DRLG
SWIVEL; ROTATING EQUIPMENT TYPE,ROTATING EQUIPMENT,API COMPLIANT
6000004193
584
Drilling Equipment
UNIT: TESTING, SKID MOUNTED
UNIT; SKID MOUNTED TYPE,PULSE VARIABLE SPEED DRIVE, SUPPLIED WITH
GENERATOR SET, MOTOR CONTROLLER, JUNCTION BOXES, CABLE, CIRCUIT
BREAKERS AND OTHER EQUIPMENT & ACCESSORIES, USED FOR TESTING
SUBMERSIBLE PUMP MPTORS
6000013381
585
Drilling Equipment
SPARES: OILWELL; TRAVELING
BLOCK
SPARE PART 9COM; OILWELL DIV, UNITED STATES STEEL,BLOCK TRAVELLING
TABLE ROTARY 6000004539

Material Number
9COM/9CAT
586
Drilling Equipment
VALVE; MUD; GATE OR PLUG;
DRLG
VALVE GATE MUD; API COMPLIANT,API COMPLIANT
6000004157

Aramco approved vendor list 2015

More Related Content

What's hot

Similar to Aramco approved vendor list 2015

Recently uploaded

Aramco approved vendor list 2015
