16. Current ZigBee IoT Standards
ZigBee Home Automation (ZHA)
ZigBee Light Link (ZLL)
ZigBee Smart Energy (ZSE)
ZigBee Building Automation (CBA)
ZigBee Telecom Services (ZTS)
ZigBee Health Care (ZHC)
ZigBee Remote Control (ZRC)
ZigBee Input Device (ZID)
ZigBee Retail Services (ZRS)
17. ZigBee 優點
省電 :
RX: 27 mA, TX: 27mA
Wide supply voltage range (2.0V - 3.6V)
8051 compatible microcontroller running at 32 MHz
Device 端適合使用電池長時間工作
適合遠距離無線感測網路(WSN)、物聯網(The internet
of Thing)
使用 TI CC2430 ZigBee SoC, 8051 Microcontroller 容
易與Sensors, 及外接控制線路結合使用
18. ZigBee / Wi-Fi / BT 比較
Feature(s) IEE 802.11g Bluetooth 2.0 ZigBee
電源持續力 Hours Days Years
複雜度 Very comples Comlex Simple
節點數 Many 7 Up to 65535
建立連線速度 Upto 3 S Upto 10 S 30 ms
傳輸距離 100M 10m 70m ~
300m
擴充性 Yes No Yes
資料傳輸率 54Mbps 3Mbps 250Kbps
(2.4Ghz) (2.4Ghz) (2.4Ghz)
安全性 SSID 64bit,128bit 128bit AES
26. Smart Home 系統 (燈光調控器)
Zero Crossing
PIR Sensor
電路板
電路板
Parallax PIR
感應器
TI CC2430 ZigBee
Device Module
PIC & TRIAC
燈光控制電路板
調光器電燈電
源插座
27. Smart Light Control 燈光調控器PCB
TI CC2430
ZigBee SoC IC Zero Crossing
TI CC2430 ZigBee
w/ 溫度Sensor PIC & TRIAC 電路板
Device Module
燈光控制電路板
燈座盒
Parallax PIR Sensor 紅 PIR Sensor
外線體溫感測器 電路板
35. Home Gateway System
Air Home
Light Media
Web Condi. Camera Automat
Control Play
Server Control Service ion
Service Service
Service Service
Light Network
Media Play
JVM Control Protocol
API
API Stack
Linux
Embedded Hardware Platform
RFID Ether
Reader Wi-Fi USB ZigBee UART Sensor Video Audio LCD IR
net
