Now a day’s highly integrated multi layer board with IC’s is virtually impossible to be accessed
physically for testing. The major problem detected during testing a circuit includes test generation and gate to
I/O pin problems. In design of any circuit, consuming low power and less hardware utilization is an important
design parameter. Therefore reliable testing methods are introduced which reduces the cost of the hardware
required and also power consumed by the device. In this project a new fault coverage test pattern generator is
generated using a linear feedback shift register called FC-LFSR which can perform fault analysis and reduces
the total power of the circuit. In this test, it generates three intermediate patterns between the random patterns
which reduces the transitional activities of primary inputs so that the switching activities inside the circuit under
test will be reduced. The test patterns generated are applied to c17 benchmark circuit, whose results with fault
coverage of the circuit being tested. The simulation for this design is performed using Xilinx ISE software using
Verilog hardware description language
In our project, we propose a novel architecture which generates the test patterns with reduced switching activities. LP-TPG (Test pattern Generator) structure consists of modified low power linear feedback shift register (LP-LFSR), m-bit counter; gray counter, NOR-gate structure and XOR-array. The m-bit counter is initialized with Zeros and which generates 2m test patterns in sequence. The m-bit counter and gray code generator are controlled by common clock signal [CLK]. The output of m-bit counter is applied as input to gray code generator and NOR-gate structure. When all the bits of counter output are Zero, the NOR-gate output is one. Only when the NOR-gate output is one, the clock signal is applied to activate the LP-LFSR which generates the next seed. The seed generated from LP-LFSR is Exclusive–OR ed with the data generated from gray code generator. The patterns generated from the Exclusive–OR array are the final output patterns. The proposed architecture is simulated using Modelsim and synthesized using Xilinx ISE 13.2 and it will be implemented on XC3S500e Spartan 3E FPGA board for hardware implementation and testing. The Xilinx Chip scope tool will be used to test the FPGA inside results while the logic running on FPGA.
A Modified Design of Test Pattern Generator for Built-In-Self- Test ApplicationsIJERA Editor
Test Pattern Generators (TPG) are very important logic part of the Circuits that have self-test features.
Nowadays, the self-test feature is an in-built part of the modern application hardware designs. This feature
enables the user to test and verify the specific hardware failure with the help of the hardware itself. To enable
self-test an extra operational and control circuit is required by the application based operational and control
circuit. The size of the self-test block is generally small as compared to the actual hardware. Most of the self-test
hardware includes Linear Feedback Shift Register (LFSR) to generate the test signal pattern in the self-test mode
of circuit operation. In the present work a simple 3-FF based modified design of TPG is designed and simulated
to generate a 4-bit test signal sequence. The present work also shows FPGA based simulation and synthesis of a
16-bit TPG design using the 4-bit TPG. The present TPG design concept can be replicated to generate a test
sequence of higher bit length for advanced applications. The present design is simulated on Xilinx tool for
functional verification.
