With tens of thousands of Java servers running in production in enterprise, Java has become a language of choice for building production systems. If our machines are to exhibit acceptable performance, they require regular tuning.This talk takes a detailed look at techniques for tuning a Java Server.

1. Tuning Java Servers
Srinath Perera

2. Outline
 With size of systems growing, Performance
become increasingly critical for both R&D as
well as support
o Less performance => more machines => lot of
Devops costs and potential for failures
 We will do
o Bit of Theory
o Then to Profiling
 Will discuss different profiling views, and most
importantly when to use them.

3. Based on article
http://www.infoq.com/articles/Tuning-Java-Servers

4. Big Pic

5. What is Performance Tuning?
 Get maximum out of the machine
o Max Throughput
o Min Latency
 Often this become a tradeoff, so you need a
balance
o General case is to get max throughput within given
latency limits. (E.g. max throughput with latency
less than 100ms.)

6. Lets understand what they are
 What is throughput?
o Number of messages server can process per second
o Measured as
the number of messages processed/ time to process messages
 What is latency?
o End to end time for a server to process an message
 We discuss performance as relationship
between three variables: latency,
concurrency, throughput

7. What Limits Performance?
 Lack of resources
 Bottleneck – most scarce resource decides the
performance
o CPU bound
o Disk bound
o Bandwidth bound
o Latency bound
o Memory bound

8. Performance and Bottlenecks
 Think of performance as a water pipe system
 Bottle neck decides overall throughput
 Latency problems often caused at the same
bottlenecks due to contention
 Potential Bottlenecks (Resources)
o CPU
o Disk
o Network
o Memory
- Available Memory
- Heap Size
- GC (Java) – will eat in CPU

9. Performance of a Server

10. Little’s Law
 Bound your queue’s (reject too much requests
to give better response time)

11. Amdhal’s Law

13. Performance Numbers (based on Jeff
Dean’s numbers )
Latency / time
for 1 memory
Op
If Memory
access is a
Second
L1 cache reference 0.05 1/20th sec
Main memory reference 1 1 sec
Send 2K bytes over 1 Gbps network 200 3 min
Read 1 MB sequentially from memory 2500 41 min
Disk seek 1*10^5 27 hours
Read 1 MB sequentially from disk 2*10^5 2 days
Send packet CA->Netherlands->CA 1.5*10^6 17 days
See http://tapestryjava.blogspot.com/2012/06/latency-numbers-every-
programmer-should.html

14. Performance Numbers (based on Jeff
Dean’s numbers )
Latency / time
for 1 memory
Op
If Memory
access is a
Second
L1 cache reference 0.05 1/20th sec
Main memory reference 1 1 sec
Send 2K bytes over 1 Gbps network 200 3 min
Read 1 MB sequentially from memory 2500 41 min
Disk seek 1*10^5 27 hours
Read 1 MB sequentially from disk 2*10^5 2 days
Send packet CA->Netherlands->CA 1.5*10^6 17 days
See http://tapestryjava.blogspot.com/2012/06/latency-numbers-every-
programmer-should.html

15. Latency Lags Bandwidth
 Observation in prof.
Patterson’s Keynote at 2004
 Bandwidth improves, but
not latency
 Same holds now, and the
gap is widening with new
systems

16. Handling Speed Differences in
Memory Hierarchy
1. Caching
o E.g. Processor caches, file
cache, disk cache, permission
cache
2. Replication
o E.g. RAID, Content Distribution
Networks (CDN), Web Cache
3. Prediction – Predict what data
will be needed and prefect
o Tradeoff bandwidth
o E.g. disk caches, Google Earth

17. Potential Performance Problems
 Low performance
o Low Throughput
o High latency
 Memory leaks
 File, Thread, Connection Leaks

18. Warning
 Many think performance is due to CPU
 People forget network and Disk (most our
workloads are network bound)
o That’s why CPU 10% but machine is loaded (load
average 40)
 Need to look at all
 First step is find the bottleneck

19. Where to start? Load Average
 Most start by looking at CPU usage
 That does not reflect non-CPU load
 Load average is much better
o Represent the size of the process queue
o Can found via top (1m, 5m, 15m)
o Goes high when CPU, network, disk, memory etc.,
are limited
o Normal value = number of cores, 4X number of
cores means high
o 10X core size means machine is unusable
Read
• http://prutser.wordpress.com/2012/04/23/understanding-linux-load-average-
part-1/ also part2 and part 3

20. Profiling Tools
 First step is connect through JConsole, and get
basic idea.
 Also monitor the load average, CPU usage, and
IO operations (via top or Sar)
 Then you can switch to tools like JProfiler,
Yourkit, Java Flight Recorder
 Important views
o CPU views (bottlenecks)
o Thread views and monitor views
o Memory views (GC, allocations, and memory leaks)
o IO and JDBC tracing

21. Top

22. JConsole

23. Java Flight Recorder
 Former Oracle Jrocket Mission control
 Now included with JDK 7 update 44+
 Nice tool, very fast, you could run it in
production
 Can start via $JAVA_HOME/bin/jmc
 Profiling JVM need to have following java
option at start
o -XX:+UnlockCommercialFeatures -XX:+FlightRecorder

25. Hands On
 Code and scripts from
https://github.com/srinathperera/JavaProfilingTalk
 Run ant to build the service
 Download and unzip WSO2 AS. Run wso2server.sh to
start
 Go to http:// 127.0.0.1:9443/carbon and login via
admin/ admin
 Deploy the aar by going to Services->Add->AAR
Service
 Download jmeter, unzip, and run bin/jmeter
 Run Jmeter scripts to recreate performance problems

26. Get started with JProfiler
 Download install – work with linux, windows,
and Mac
 New Session, then configure
o Same Machine connect
o Remote connect
- Java -
agentpath:/Applications/jprofiler7/bin/macos/libjprofil
erti.jnilib=port=8849
o Offline profile
 Adjust filters to org.wos2, org.apache,
java.util. and remove excludes (can change
this)
 Connect

27. JProfiler
 Instrumentation vs. Sampling
 Jpenable let you connect to an running server
remotely

28. Problem 1: Tuning for Throughput
 Is machine loaded (checked via load average)?
o If you are putting small load, throughout will be
less
 Try increasing concurrency (load)

29. Problem 1: Tuning for.. (Contd)
 If load average low
o Check lock profile
o Try tuning threads
- If server set to small number of threads, that will limit
performance
o Ensure network not saturated
- Try transfer a large file

30. Problem 1: Tuning for.. (Contd)
 If high load average
o Is machine loaded by something else?
o Check CPU (top)
- If high check CPU profile
- If GC percentage > 10% tune GC
o Check network
o Check Disk
o Check is Machine paging

31. CPU Profile

32. CPU Profile
 First check hotspots
 Then call tree
o show inherent time as oppose to cumulative time
(Call graph)
 Make sure what takes CPU is where real work is
done
 CPU1 and CPU2 samples

33. Network/ Disk Profile
 Enable Socket or Servlet (or Files) via Probes
 Hotspots
 Read/Write via telematics
 Samples tooManyIOPSCall.jmx
tooManyNetowrkCalls.jmx

34. Lock Profile
 Threads view (History and telemetric view)
 Monitor view
 bockedThreadsCall.jmx sample

35. Problem 2: Tuning for Latency
 Look for bottlenecks – same causes add latency
due to queuing
o Try to find any queue are growing
 Check thread views and lock views
o As discussed in Lock profile
 All IO (both disk and network) are expensive
o Network and Disk Profiles
 How to find?
o Call Graph
o Put system outs and check

36. Problem 3: Finding Memory Leaks
 Use Eclipse Memory Analyzer
 Go to JProfiler if it is hard to pin down
 Support mark and monitoring memory in
running system
 Can also analyze a memory dump
o Select the objects
o Checking incoming references (cumulative)
o Reference Graph can also help

37. Eclipse Memory Analyzer
 When OOM, WSO2 servers create a dump
 Open with eclipse memory analyzer

38. Memory leaks with Jprofiler

39. Allocation view
 Use to find where objects are created

40. GC Tuning
 If time spent on GC > 10%, then should tune GC
 “gc overhead limit exceeded” – means > 90%
time spent on GC

41. GC Tuning
 If time spent on GC > 10%, then should tune GC
 “gc overhead limit exceeded” – means > 90%
time spent on GC
 Consider using allocation views to reduce
objects created

42. Problem 4: Finding Thread Leaks
 Check the number of threads in thread graph
 Check which thread are created
 Thread dumps
o jstack <pid> >> threaddumps.log
o Jprofiler can get thread dumps as well
 Take thread dumps at different times

43. Thread Views

44. Problem 3: Connection Leaks
 Exhausted pools, file descriptor limits
 Check at finally points and in catch clauses

45. Tuning without an GUI
 Create a JProfile session and configure the triggers.
o Need Periodic triggers Copy local .jprofiler7/config.xml and
JProfiler binaries or agent code to the remote machine
 Add following before the java command.
o -
agentpath:JPROF_LOCATION/bin/macos/libjprofilerti.jnilib=offline,id=S
ESSION_ID,config=/Users/srinath/.jprofiler7/config.xml
 Here replace the configuration file and JProfiler location with
your machine's values.
o SESSION_ID is the session ID of the session you created with JProfiler UI.
Here ~./jprofiler7/config.xml file has settings for all sessions creates by
jprofiler, and it will pick up the right value. If you are profiling in a
remote machine copy your local configs to the remote host.
 Start and run the program, and it will print the following
 JProfiler> Using JVMTI
 ..
 Open the snapshot file and analyze using JProfiler UI.

46. Tuning
 OS Level Tuning
o For example,
http://www.lognormal.com/blog/2012/09/27/linu
x-tcpip-tuning/
o Generally available with the product
o It depends on OS etc.
 Product Tuning
o Thread pools sizes mainly, there may be others
 Application Tuning
o This is your application, you need to profile

47. Conclusion
 Know the goals
 Find where the bottleneck using Load average and
other OS tools
 Zoom in using profiler
 Know profile views and when to use them
 Details are important, so is the big picture
 Think .. Think ..

48. References
 Responding in a Timely Manner,
https://www.youtube.com/watch?v=q_DCipkM
sy0
 Tuning Java Servers -
http://www.infoq.com/articles/Tuning-Java-
Servers
 Thinking Clearly about Performance,
http://queue.acm.org/detail.cfm?id=1854041#
content-comments

49. Questions?
