This research aims to monitor the traffic condition and to control the traffic light. This system can reduce not only traffic congestion but also waiting time. This system is designed to be implemented in places nearing the junctions. This research is based on the effective use of Internet of Things IoT . This system will display the traffic conditions in the website and the traffic light can be controlled from this website. This system has been implemented by using esp8266, ultrasonic sensor and arduino. Esp8266 nodemcu which is IoT device is used to transmit the traffic information to the website which is connected with this device. Ultrasonic sensors are placed on each road to sense the presence and absence of vehicles. Traffic information is received from these sensors. Traffic light prototype is built by using an arduino UNO. This traffic light can be controlled from the website. The system will display the traffic states in the website that can guide the drivers to select the right way and avoid traffic congestions. Ei Swe Zin | Kyaw Zin Latt ""Traffic Monitoring and Control System Using IoT"" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-3 | Issue-4 , June 2019, URL: https://www.ijtsrd.com/papers/ijtsrd25138.pdf
Paper URL: https://www.ijtsrd.com/engineering/electronics-and-communication-engineering/25138/traffic-monitoring-and-control-system-using-iot/ei-swe-zin
A smart traffic management is a wide topic of research. Many modifications can be made to make the urban traffic flow smoothly on the roads. The increasing utilization of private vehicles and public transportation due to advancement of technology causes hectic traffic complexities for the civilians across the globe. The problem of traffic congestion is an everyday problem for human resource and therefore hinders the growth of the country by affecting its productivity as well as economy. Moreover, the traffic signaling systems have predetermined fixed operational time which fails to manage the traffic density changing with time and thus, long traffic queues are formed at the road crossings resulting in increased pollution and waiting time. In this paper, we tried to provide solution to reduce the waiting time at road crossings while keeping in mind the importance of time of the citizens as well as the emergency service providers (such as EMS i.e. Emergency Medical Services, Fire and Rescue Services, etc.). The presented system in this paper is based on smart traffic congestion control system that will automatically set the signal time based on the measured values of vehicle density on road lanes. However, the manual changes can also be made to traffic signals for efficient traffic management in case of emergencies. This paper presents an idea of traffic management using internet of things (IOT). The Internet of Things (IoT) refers to a system of internet-connected objects that are able to collect and transfer data over a wireless network without human intervention. This technology provides an effective communication between different signals and helps in collection of data thereby providing an IoT based smart traffic management system in terms of its automated tracking, monitoring and controlling of vehicles and its data processing.
In this presentation, Swetha presents an innovative solution that aims to solve traffic problems in the country. Her solution uses sensors to collect information and relay the information to users over a mobile app.
The project is designed to develop a density based dynamic traffic signal system having remote override facilities. During normal time the signal timing changes automatically on sensing the traffic density at the junction but in the event of any emergency vehicle like ambulance, fire brigade etc. requiring priority are built in with RF remote control to override the set timing by providing instantaneous green signal in the desired direction while blocking the other lanes by red signal for some time. Traffic congestion is a severe problem in many major cities across the world thus it is felt imperative to provide such facilities to important vehicles.
Conventional traffic light system is based on fixed time concept allotted to each side of the junction which cannot be varied as per varying traffic density. Junction timings allotted are fixed. Sometimes higher traffic density at one side of the junction demands longer green time as compared to standard allotted time. The proposed system using a PIC microcontroller duly interfaced with sensors, changes the junction timing automatically to accommodate movement of vehicles smoothly avoiding unnecessary waiting time at the junction. The sensors used in this project are IR, are in line of sight configuration across the loads to detect the density at the traffic signal. The override feature is activated by an on board RF transmitter operated from the emergency vehicle.
Intelligent traffic information and control systemSADEED AMEEN
As the problem of urban traffic congestion spreads, there is a pressing need for the introduction of advanced technology and equipment to improve the state of the art of traffic control. In current situation, the signal remains green until the present cars have passed. To avoid those problems we propose a system for controlling the traffic light by image processing. The system will detect vehicles through images instead of using electronic sensors embedded in the pavement. A camera will be installed alongside the traffic light. It will capture image sequences. For this purpose, edge detection has been carried out and according to percentage of matching traffic light-durations can be controlled. In addition, when an emergency vehicle is approaching the junction, it will communicate to the traffic controller in the junction to turn ON the green light. This module uses ZigBee modules for wireless communications between the ambulance and traffic controller. Intelligent traffic control system helps to pass emergency vehicles smoothly. Traffic signal management system is developed for the traffic police, to control the traffic lights manually. Additionally an information system is added using a chat bot module to avail traffic information to user.
A smart traffic management is a wide topic of research. Many modifications can be made to make the urban traffic flow smoothly on the roads. The increasing utilization of private vehicles and public transportation due to advancement of technology causes hectic traffic complexities for the civilians across the globe. The problem of traffic congestion is an everyday problem for human resource and therefore hinders the growth of the country by affecting its productivity as well as economy. Moreover, the traffic signaling systems have predetermined fixed operational time which fails to manage the traffic density changing with time and thus, long traffic queues are formed at the road crossings resulting in increased pollution and waiting time. In this paper, we tried to provide solution to reduce the waiting time at road crossings while keeping in mind the importance of time of the citizens as well as the emergency service providers (such as EMS i.e. Emergency Medical Services, Fire and Rescue Services, etc.). The presented system in this paper is based on smart traffic congestion control system that will automatically set the signal time based on the measured values of vehicle density on road lanes. However, the manual changes can also be made to traffic signals for efficient traffic management in case of emergencies. This paper presents an idea of traffic management using internet of things (IOT). The Internet of Things (IoT) refers to a system of internet-connected objects that are able to collect and transfer data over a wireless network without human intervention. This technology provides an effective communication between different signals and helps in collection of data thereby providing an IoT based smart traffic management system in terms of its automated tracking, monitoring and controlling of vehicles and its data processing.
In this presentation, Swetha presents an innovative solution that aims to solve traffic problems in the country. Her solution uses sensors to collect information and relay the information to users over a mobile app.
The project is designed to develop a density based dynamic traffic signal system having remote override facilities. During normal time the signal timing changes automatically on sensing the traffic density at the junction but in the event of any emergency vehicle like ambulance, fire brigade etc. requiring priority are built in with RF remote control to override the set timing by providing instantaneous green signal in the desired direction while blocking the other lanes by red signal for some time. Traffic congestion is a severe problem in many major cities across the world thus it is felt imperative to provide such facilities to important vehicles.
Conventional traffic light system is based on fixed time concept allotted to each side of the junction which cannot be varied as per varying traffic density. Junction timings allotted are fixed. Sometimes higher traffic density at one side of the junction demands longer green time as compared to standard allotted time. The proposed system using a PIC microcontroller duly interfaced with sensors, changes the junction timing automatically to accommodate movement of vehicles smoothly avoiding unnecessary waiting time at the junction. The sensors used in this project are IR, are in line of sight configuration across the loads to detect the density at the traffic signal. The override feature is activated by an on board RF transmitter operated from the emergency vehicle.
Intelligent traffic information and control systemSADEED AMEEN
As the problem of urban traffic congestion spreads, there is a pressing need for the introduction of advanced technology and equipment to improve the state of the art of traffic control. In current situation, the signal remains green until the present cars have passed. To avoid those problems we propose a system for controlling the traffic light by image processing. The system will detect vehicles through images instead of using electronic sensors embedded in the pavement. A camera will be installed alongside the traffic light. It will capture image sequences. For this purpose, edge detection has been carried out and according to percentage of matching traffic light-durations can be controlled. In addition, when an emergency vehicle is approaching the junction, it will communicate to the traffic controller in the junction to turn ON the green light. This module uses ZigBee modules for wireless communications between the ambulance and traffic controller. Intelligent traffic control system helps to pass emergency vehicles smoothly. Traffic signal management system is developed for the traffic police, to control the traffic lights manually. Additionally an information system is added using a chat bot module to avail traffic information to user.
This Presentation describes about the concept of self driving car with uses of different technology. This presentation will be helpful for those who want to know about new technology and will also be helpful for those who want to give seminar in technical college.
Recently more & more hearing impaired people started using sign language. There are about 70 million people in the whole World that are not able to speak (dumb). A dumb person makes communication with other people using their motion of the hand or expressions. . Sign language helps the dumb people to make communication like normal people. The sign language translator which has been already developed uses a glove fitted with sensors that can interpret the 16 English letters in American Sign Language (ASL). Accelerometers and flex sensors are used in this system which increases its overall cost. We proposed a solution as a prototype called as “smart glove-for speech impaired people” which will translate sign language into text. It will help dump and deaf people to express their thoughts in more convenient way. As a sign language we have used traditional finger movements with contact switch wrapped around the user’s fingers. An IR transmitter receiver pair, HT12E and HT12D IC and, Arduino (Micro Controller) board helps transmitting data to PC. Moreover, use of contact switches reduces the system’s overall cost.
Keywords: - Arduino, HT12E IC & HT12D IC, IR transmitter receiver, contact switch.
Automatic toll collection system (presentation)Rohan Kale
ATCS is an Automated Toll Collection System used for collecting tax automatically. A vehicle will hold an RFID tag. This tag is nothing but unique identification number assigned. This will be assigned by RTO or traffic governing authority. In accordance with this number we will store, all basic information as well as the amount he has paid in advance for the TOLL collection. Reader will be strategically placed at toll collection center. Whenever the vehicle passes the toll Plaza, the tax amount will be deducted from his prepaid balance. New balance will be updated. Incase if one has insufficient balance, his updated balance will be negative one. To tackle this problem, we are alarming a sound, which will alert the authority that this vehicle doesn’t have sufficient balance and that particular vehicle can be trapped. As vehicles don’t have to stop in a queue, it assures time saving, fuel conservation and also contributing in saving of money.
Due to the heavy traffic in the road many people are suffering. Even though there is traffic signal available at various places it is not easy to control the crowd. In order to avoid traffic problem heavily on the road, we designed and developed a system so called as traffic controller with wireless control for ambulance and VIP vehicles. In this paper, we proposed an Implementing Intelligent Traffic Control for Congestion, Ambulance clearance, and Stolen Vehicle Detection. This system was implemented based on present criteria that tracking three conditions in those one is heavy traffic control and another one is making a root of emergency vehicle like ambulance and VIP vehicle. In this paper we are going to implement a sensor network work which is used to detect the traffic density and also use RFID reader and tags. We use AVR system-on-chip to read the RFID tags attached to the vehicles. It counts number of vehicles that passes on a particular path during a specified duration using infrared sensor. If the RFID tag read belongs to the stolen vehicles. GSM SIM900 used for message sending towards the police control room. In addition, when an ambulance or some VIP vehicle if approach the junction, it will communicate the traffic controller in the junction to turn on the green light in the path.
ppt on accident detection system based on Iotrahul ranjan
The Internet if Things(IoT) is regarded as atechnology and economic wave in the global information industry after the Internet. The IoT is an intelligent network which connects all things to the Internet for the purpose of exchanging information and communicating through the information sensing devices in accordance with agreed protocols. It achieves the goal of intelligent identifying, locating, tracking, monitoring, and managingthings . It is an extension and expansion of Internet-based network, which expands the communication from human and human to human andthings or things and things. In the IoT paradigm, many objectssurrounding us will be connected into networks in one form oranother. TheIOT concept, hence, aims at making the Internet even more immersive and pervasive.
IOT will foster the development of a number of applications that make useof the potentially enormous amount and variety of data generated by suchObjects to provide new services to citizens, companies, and public administrations.
Here we are designing “INTELLIGENT HIGHWAY” by deploying wireless sensor network. Wireless sensor networks are adhoc networks which consistof large number of tiny sensor nodes with limited resource and one or more base stations, sensor nodes consist of processing unit with limited computational power and limited capacity. We are integrating this wireless sensor networks into the internet as a part of IOT so that anyone can access the Situations about the highway anywhere in the world.
Nowadays the vehicle accident rate has been increasing as compared to the previous decade. This system proposes a solution to minimize the action time after an accident. It has the capability of ensuring the drivers safety along with the co-passengers and can easily be integrated with the car. The vehicle is connected to a hardware device that detects the collision with the help of a vibration sensor. The hardware device also consists of a fire sensor that senses fire breakouts. It communicates with an application in the Smartphone through Zigbee Bluetooth whenever collision or fire is sensed. If the driver doesnt want to communicate any information, he can cancel using the reset switch. Once the Bluetooth connection is established, the application would track and communicate the victims GPS location along with the patients entire medical report to their companions as well as the nearest hospital through an SMS. The application also checks the availability of the blood in the nearest blood bank and sends a notification back as soon as the availability of blood is ensured. A. Geetha | Shahanaz Khan N | Sneha Rajagopal | Soundariya B"An IOT based solution for Road Accidents" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-2 | Issue-3 , April 2018, URL: http://www.ijtsrd.com/papers/ijtsrd11158.pdf http://www.ijtsrd.com/computer-science/other/11158/an-iot-based-solution-for-road-accidents/a-geetha
This Presentation describes about the concept of self driving car with uses of different technology. This presentation will be helpful for those who want to know about new technology and will also be helpful for those who want to give seminar in technical college.
Recently more & more hearing impaired people started using sign language. There are about 70 million people in the whole World that are not able to speak (dumb). A dumb person makes communication with other people using their motion of the hand or expressions. . Sign language helps the dumb people to make communication like normal people. The sign language translator which has been already developed uses a glove fitted with sensors that can interpret the 16 English letters in American Sign Language (ASL). Accelerometers and flex sensors are used in this system which increases its overall cost. We proposed a solution as a prototype called as “smart glove-for speech impaired people” which will translate sign language into text. It will help dump and deaf people to express their thoughts in more convenient way. As a sign language we have used traditional finger movements with contact switch wrapped around the user’s fingers. An IR transmitter receiver pair, HT12E and HT12D IC and, Arduino (Micro Controller) board helps transmitting data to PC. Moreover, use of contact switches reduces the system’s overall cost.
Keywords: - Arduino, HT12E IC & HT12D IC, IR transmitter receiver, contact switch.
Automatic toll collection system (presentation)Rohan Kale
ATCS is an Automated Toll Collection System used for collecting tax automatically. A vehicle will hold an RFID tag. This tag is nothing but unique identification number assigned. This will be assigned by RTO or traffic governing authority. In accordance with this number we will store, all basic information as well as the amount he has paid in advance for the TOLL collection. Reader will be strategically placed at toll collection center. Whenever the vehicle passes the toll Plaza, the tax amount will be deducted from his prepaid balance. New balance will be updated. Incase if one has insufficient balance, his updated balance will be negative one. To tackle this problem, we are alarming a sound, which will alert the authority that this vehicle doesn’t have sufficient balance and that particular vehicle can be trapped. As vehicles don’t have to stop in a queue, it assures time saving, fuel conservation and also contributing in saving of money.
Due to the heavy traffic in the road many people are suffering. Even though there is traffic signal available at various places it is not easy to control the crowd. In order to avoid traffic problem heavily on the road, we designed and developed a system so called as traffic controller with wireless control for ambulance and VIP vehicles. In this paper, we proposed an Implementing Intelligent Traffic Control for Congestion, Ambulance clearance, and Stolen Vehicle Detection. This system was implemented based on present criteria that tracking three conditions in those one is heavy traffic control and another one is making a root of emergency vehicle like ambulance and VIP vehicle. In this paper we are going to implement a sensor network work which is used to detect the traffic density and also use RFID reader and tags. We use AVR system-on-chip to read the RFID tags attached to the vehicles. It counts number of vehicles that passes on a particular path during a specified duration using infrared sensor. If the RFID tag read belongs to the stolen vehicles. GSM SIM900 used for message sending towards the police control room. In addition, when an ambulance or some VIP vehicle if approach the junction, it will communicate the traffic controller in the junction to turn on the green light in the path.
ppt on accident detection system based on Iotrahul ranjan
The Internet if Things(IoT) is regarded as atechnology and economic wave in the global information industry after the Internet. The IoT is an intelligent network which connects all things to the Internet for the purpose of exchanging information and communicating through the information sensing devices in accordance with agreed protocols. It achieves the goal of intelligent identifying, locating, tracking, monitoring, and managingthings . It is an extension and expansion of Internet-based network, which expands the communication from human and human to human andthings or things and things. In the IoT paradigm, many objectssurrounding us will be connected into networks in one form oranother. TheIOT concept, hence, aims at making the Internet even more immersive and pervasive.
IOT will foster the development of a number of applications that make useof the potentially enormous amount and variety of data generated by suchObjects to provide new services to citizens, companies, and public administrations.
Here we are designing “INTELLIGENT HIGHWAY” by deploying wireless sensor network. Wireless sensor networks are adhoc networks which consistof large number of tiny sensor nodes with limited resource and one or more base stations, sensor nodes consist of processing unit with limited computational power and limited capacity. We are integrating this wireless sensor networks into the internet as a part of IOT so that anyone can access the Situations about the highway anywhere in the world.
Nowadays the vehicle accident rate has been increasing as compared to the previous decade. This system proposes a solution to minimize the action time after an accident. It has the capability of ensuring the drivers safety along with the co-passengers and can easily be integrated with the car. The vehicle is connected to a hardware device that detects the collision with the help of a vibration sensor. The hardware device also consists of a fire sensor that senses fire breakouts. It communicates with an application in the Smartphone through Zigbee Bluetooth whenever collision or fire is sensed. If the driver doesnt want to communicate any information, he can cancel using the reset switch. Once the Bluetooth connection is established, the application would track and communicate the victims GPS location along with the patients entire medical report to their companions as well as the nearest hospital through an SMS. The application also checks the availability of the blood in the nearest blood bank and sends a notification back as soon as the availability of blood is ensured. A. Geetha | Shahanaz Khan N | Sneha Rajagopal | Soundariya B"An IOT based solution for Road Accidents" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-2 | Issue-3 , April 2018, URL: http://www.ijtsrd.com/papers/ijtsrd11158.pdf http://www.ijtsrd.com/computer-science/other/11158/an-iot-based-solution-for-road-accidents/a-geetha
In recent years usage of private vehicles create urban traffic more and more crowded. As result traffic becomes one of the important problems in big cities in all over the world. Some of the traffic concerns are traffic jam and accidents which have caused a huge waste of time, more fuel consumption and more pollution. Time is very important parameter in routine life. The main problem faced by the people is real time routing. Our solution Virtual Eye will provide the current updates as in the real time scenario of the specific route. This research paper presents smart traffic navigation system, based on Internet of Things, which is featured by low cost, high compatibility, easy to upgrade, to replace traditional traffic management system and the proposed system can improve road traffic tremendously.
The world is moving forward at a fast hop, and the credit goes to ever growing technology. One such idea is IOT Internet of things with which automation is no longer a virtual reality. The Internet of Things will seamlessly incorporate a large number of different and heterogeneous end systems, while providing open access to selected subsets of data for the development of an overabundance of digital services. Building a wide ranging architecture for IoT is required because of the extremely large variety of devices but it is a very complex task, link layer technologies, and services that may be involved in such a system. In this paper we emphasis specifically to an urban IoT systems that, while still being quite a broad category, are characterized by their specific application domain. Urban IoTs, in fact, are designed to support the Smart City vision, which aims at take advantage of the most advanced communication technologies to support added value services for the administration of the city and for the citizens. Sunitha C | Asha Priya B | Lavanya S ""Need of Internet of Things for Smart Cities"" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-3 | Issue-4 , June 2019, URL: https://www.ijtsrd.com/papers/ijtsrd23597.pdf
Paper URL: https://www.ijtsrd.com/computer-science/world-wide-web/23597/need-of-internet-of-things-for-smart-cities/sunitha-c
VANET based Intelligent TransportationSystem using Li-Fi technologyIOSRJECE
VANET (Vehicular Ad-hoc Network) is a wireless network in vehicle for Intelligent Transportation System (ITS).In thispaper, we propose a mechanism toprevent accidents due to sleepiness and alcohol consumption of the driver. Vehicle to Vehicle (V2V) communication is the most effective solutionwe have used in order to prevent accidents using the Li-Fi technology.
Since the development of advanced metering and digital technology, Smart City has been equipped based on things IOT in different electronic devices, and therefore smarter than before. The purpose of this paper is to carry out the concept of smart cities and their motivation and application of a comprehensive review. In addition, the survey describes the intelligent networking technology and smart cities and major components of urban functions. This also explains the major challenges and experiences around the world. Mukesh Kumawat | Mr. Durgesh Kumar | Dr. Garima Mathur ""IOT Based Smart Cities"" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-3 | Issue-3 , April 2019, URL: https://www.ijtsrd.com/papers/ijtsrd23246.pdf
Paper URL: https://www.ijtsrd.com/engineering/electronics-and-communication-engineering/23246/iot-based-smart-cities/mukesh-kumawat
A SHORT SURVEY ON CONSTRUCTING AN IOTBASED INTELLIGENT ROAD SYSTEMijcsit
Road construction is a crucial component of modern infrastructure since it greatly facilitates travel between various areas.Sustainability, Progress, and Transformation refer to the upgrading of roads employing communication, lighting, and control transmission mechanisms that may promote sustainability, road progress, and a better driving experience for users.Smart roads that are connected to the Internet of Things (IoT) devices make it possible to drive more efficiently, sustainably, and safely.For this reason, the range of smart road technology like actuators, sensors, and solar power along with software infrastructures like Artificial Intelligence and big data are now made standard in all new roads. This article provides a framework for patients to employ speech-to-text chatbots to conduct treatment. Using chat-box technology, we have implemented cognitive therapy as a solution.
Road construction is a crucial component of modern infrastructure since it greatly facilitates travel
between various areas.Sustainability, Progress, and Transformation refer to the upgrading of roads
employing communication, lighting, and control transmission mechanisms that may promote sustainability,
road progress, and a better driving experience for users.Smart roads that are connected to the Internet of
Things (IoT) devices make it possible to drive more efficiently, sustainably, and safely.For this reason, the
range of smart road technology like actuators, sensors, and solar power along with software
infrastructures like Artificial Intelligence and big data are now made standard in all new roads. This
article provides a framework for patients to employ speech-to-text chatbots to conduct treatment. Using
chat-box technology, we have implemented cognitive therapy as a solution.
Road construction is a crucial component of modern infrastructure since it greatly facilitates travel
between various areas.Sustainability, Progress, and Transformation refer to the upgrading of roads
employing communication, lighting, and control transmission mechanisms that may promote sustainability,
road progress, and a better driving experience for users.Smart roads that are connected to the Internet of
Things (IoT) devices make it possible to drive more efficiently, sustainably, and safely.For this reason, the
range of smart road technology like actuators, sensors, and solar power along with software
infrastructures like Artificial Intelligence and big data are now made standard in all new roads. This
article provides a framework for patients to employ speech-to-text chatbots to conduct treatment. Using
chat-box technology, we have implemented cognitive therapy as a solution
‘Six Sigma Technique’ A Journey Through its Implementationijtsrd
The manufacturing industries all over the world are facing tough challenges for growth, development and sustainability in today’s competitive environment. They have to achieve apex position by adapting with the global competitive environment by delivering goods and services at low cost, prime quality and better price to increase wealth and consumer satisfaction. Cost Management ensures profit, growth and sustainability of the business with implementation of Continuous Improvement Technique like Six Sigma. This leads to optimize Business performance. The method drives for customer satisfaction, low variation, reduction in waste and cycle time resulting into a competitive advantage over other industries which did not implement it. The main objective of this paper ‘Six Sigma Technique A Journey Through Its Implementation’ is to conceptualize the effectiveness of Six Sigma Technique through the journey of its implementation. Aditi Sunilkumar Ghosalkar "‘Six Sigma Technique’: A Journey Through its Implementation" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64546.pdf Paper Url: https://www.ijtsrd.com/other-scientific-research-area/other/64546/‘six-sigma-technique’-a-journey-through-its-implementation/aditi-sunilkumar-ghosalkar
Edge Computing in Space Enhancing Data Processing and Communication for Space...ijtsrd
Edge computing, a paradigm that involves processing data closer to its source, has gained significant attention for its potential to revolutionize data processing and communication in space missions. With the increasing complexity and data volume generated by modern space missions, traditional centralized computing approaches face challenges related to latency, bandwidth, and security. Edge computing in space, involving on board processing and analysis of data, offers promising solutions to these challenges. This paper explores the concept of edge computing in space, its benefits, applications, and future prospects in enhancing space missions. Manish Verma "Edge Computing in Space: Enhancing Data Processing and Communication for Space Missions" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64541.pdf Paper Url: https://www.ijtsrd.com/computer-science/artificial-intelligence/64541/edge-computing-in-space-enhancing-data-processing-and-communication-for-space-missions/manish-verma
Dynamics of Communal Politics in 21st Century India Challenges and Prospectsijtsrd
Communal politics in India has evolved through centuries, weaving a complex tapestry shaped by historical legacies, colonial influences, and contemporary socio political transformations. This research comprehensively examines the dynamics of communal politics in 21st century India, emphasizing its historical roots, socio political dynamics, economic implications, challenges, and prospects for mitigation. The historical perspective unravels the intricate interplay of religious identities and power dynamics from ancient civilizations to the impact of colonial rule, providing insights into the evolution of communalism. The socio political dynamics section delves into the contemporary manifestations, exploring the roles of identity politics, socio economic disparities, and globalization. The economic implications section highlights how communal politics intersects with economic issues, perpetuating disparities and influencing resource allocation. Challenges posed by communal politics are scrutinized, revealing multifaceted issues ranging from social fragmentation to threats against democratic values. The prospects for mitigation present a multifaceted approach, incorporating policy interventions, community engagement, and educational initiatives. The paper conducts a comparative analysis with international examples, identifying common patterns such as identity politics and economic disparities. It also examines unique challenges, emphasizing Indias diverse religious landscape, historical legacy, and secular framework. Lessons for effective strategies are drawn from international experiences, offering insights into inclusive policies, interfaith dialogue, media regulation, and global cooperation. By scrutinizing historical epochs, contemporary dynamics, economic implications, and international comparisons, this research provides a comprehensive understanding of communal politics in India. The proposed strategies for mitigation underscore the importance of a holistic approach to foster social harmony, inclusivity, and democratic values. Rose Hossain "Dynamics of Communal Politics in 21st Century India: Challenges and Prospects" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64528.pdf Paper Url: https://www.ijtsrd.com/humanities-and-the-arts/history/64528/dynamics-of-communal-politics-in-21st-century-india-challenges-and-prospects/rose-hossain
Assess Perspective and Knowledge of Healthcare Providers Towards Elehealth in...ijtsrd
Background and Objective Telehealth has become a well known tool for the delivery of health care in Saudi Arabia, and the perspective and knowledge of healthcare providers are influential in the implementation, adoption and advancement of the method. This systematic review was conducted to examine the current literature base regarding telehealth and the related healthcare professional perspective and knowledge in the Kingdom of Saudi Arabia. Materials and Methods This systematic review was conducted by searching 7 databases including, MEDLINE, CINHAL, Web of Science, Scopus, PubMed, PsycINFO, and ProQuest Central. Studies on healthcare practitioners telehealth knowledge and perspectives published in English in Saudi Arabia from 2000 to 2023 were included. Boland directed this comprehensive review. The researchers examined each connected study using the AXIS tool, which evaluates cross sectional systematic reviews. Narrative synthesis was used to summarise and convey the data. Results Out of 1840 search results, 10 studies were included. Positive outlook and limited knowledge among providers were seen across trials. Healthcare professionals like telehealth for its ability to improve quality, access, and delivery, save time and money, and be successful. Age, gender, occupation, and work experience also affect health workers knowledge. In Saudi Arabia, healthcare professionals face inadequate expert assistance, patient privacy, internet connection concerns, lack of training courses, lack of telehealth understanding, and high costs while performing telemedicine. Conclusions Healthcare practitioners telehealth perceptions and knowledge were examined in this systematic study. Its collection of concerned experts different personal attitudes and expertise would help enhance telehealths implementation in Saudi Arabia, develop its healthcare delivery alternative, and eliminate frequent problems. Badriah Mousa I Mulayhi | Dr. Jomin George | Judy Jenkins "Assess Perspective and Knowledge of Healthcare Providers Towards Elehealth in Saudi Arabia: A Systematic Review" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64535.pdf Paper Url: https://www.ijtsrd.com/medicine/other/64535/assess-perspective-and-knowledge-of-healthcare-providers-towards-elehealth-in-saudi-arabia-a-systematic-review/badriah-mousa-i-mulayhi
The Impact of Digital Media on the Decentralization of Power and the Erosion ...ijtsrd
The impact of digital media on the distribution of power and the weakening of traditional gatekeepers has gained considerable attention in recent years. The adoption of digital technologies and the internet has resulted in declining influence and power for traditional gatekeepers such as publishing houses and news organizations. Simultaneously, digital media has facilitated the emergence of new voices and players in the media industry. Digital medias impact on power decentralization and gatekeeper erosion is visible in several ways. One significant aspect is the democratization of information, which enables anyone with an internet connection to publish and share content globally, leading to citizen journalism and bypassing traditional gatekeepers. Another aspect is the disruption of conventional media industry business models, as traditional organizations struggle to adjust to the decrease in advertising revenue and the rise of digital platforms. Alternative business models, such as subscription models and crowdfunding, have become more prevalent, leading to the emergence of new players. Overall, the impact of digital media on the distribution of power and the weakening of traditional gatekeepers has brought about significant changes in the media landscape and the way information is shared. Further research is required to fully comprehend the implications of these changes and their impact on society. Dr. Kusum Lata "The Impact of Digital Media on the Decentralization of Power and the Erosion of Traditional Gatekeepers" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64544.pdf Paper Url: https://www.ijtsrd.com/humanities-and-the-arts/political-science/64544/the-impact-of-digital-media-on-the-decentralization-of-power-and-the-erosion-of-traditional-gatekeepers/dr-kusum-lata
Online Voices, Offline Impact Ambedkars Ideals and Socio Political Inclusion ...ijtsrd
This research investigates the nexus between online discussions on Dr. B.R. Ambedkars ideals and their impact on social inclusion among college students in Gurugram, Haryana. Surveying 240 students from 12 government colleges, findings indicate that 65 actively engage in online discussions, with 80 demonstrating moderate to high awareness of Ambedkars ideals. Statistically significant correlations reveal that higher online engagement correlates with increased awareness p 0.05 and perceived social inclusion. Variations across colleges and a notable effect of college type on perceived social inclusion highlight the influence of contextual factors. Furthermore, the intersectional analysis underscores nuanced differences based on gender, caste, and socio economic status. Dr. Kusum Lata "Online Voices, Offline Impact: Ambedkar's Ideals and Socio-Political Inclusion - A Study of Gurugram District" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64543.pdf Paper Url: https://www.ijtsrd.com/humanities-and-the-arts/political-science/64543/online-voices-offline-impact-ambedkars-ideals-and-sociopolitical-inclusion--a-study-of-gurugram-district/dr-kusum-lata
Problems and Challenges of Agro Entreprenurship A Studyijtsrd
Noting calls for contextualizing Agro entrepreneurs problems and challenges of the agro entrepreneurs and for greater attention to the Role of entrepreneurs in agro entrepreneurship research, we conduct a systematic literature review of extent research in agriculture entrepreneurship to overcome the study objectives of complications of agro entrepreneurs through various factors, Development of agriculture products is a key factor for the overall economic growth of agro entrepreneurs Agro Entrepreneurs produces firsthand large scale employment, utilizes the labor and natural resources, This research outlines the problems of Weather and Soil Erosions, Market price fluctuation, stimulates labor cost problems, reduces concentration of Price volatility, Dependency on Intermediaries, induces Limited Bargaining Power, and Storage and Transportation Costs. This paper mainly devoted to highlight Problems and challenges faced for the sustainable of Agro Entrepreneurs in India. Vinay Prasad B "Problems and Challenges of Agro Entreprenurship - A Study" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64540.pdf Paper Url: https://www.ijtsrd.com/other-scientific-research-area/other/64540/problems-and-challenges-of-agro-entreprenurship--a-study/vinay-prasad-b
Comparative Analysis of Total Corporate Disclosure of Selected IT Companies o...ijtsrd
Disclosure is a process through which a business enterprise communicates with external parties. A corporate disclosure is communication of financial and non financial information of the activities of a business enterprise to the interested entities. Corporate disclosure is done through publishing annual reports. So corporate disclosure through annual reports plays a vital role in the life of all the companies and provides valuable information to investors. The basic objectives of corporate disclosure is to give a true and fair view of companies to the parties related either directly or indirectly like owner, government, creditors, shareholders etc. in the companies act, provisions have been made about mandatory and voluntary disclosure. The IT sector in India is rapidly growing, the trend to invest in the IT sector is rising and employment opportunities in IT sectors are also increasing. Therefore the IT sector is expected to have fair, full and adequate disclosure of all information. Unfair and incomplete disclosure may adversely affect the entire economy. A research study on disclosure practices of IT companies could play an important role in this regard. Hence, the present research study has been done to study and review comparative analysis of total corporate disclosure of selected IT companies of India and to put forward overall findings and suggestions with a view to increase disclosure score of these companies. The researcher hopes that the present research study will be helpful to all selected Companies for improving level of corporate disclosure through annual reports as well as the government, creditors, investors, all business organizations and upcoming researcher for comparative analyses of level of corporate disclosure with special reference to selected IT companies. Dr. Vaibhavi D. Thaker "Comparative Analysis of Total Corporate Disclosure of Selected IT Companies of India" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64539.pdf Paper Url: https://www.ijtsrd.com/other-scientific-research-area/other/64539/comparative-analysis-of-total-corporate-disclosure-of-selected-it-companies-of-india/dr-vaibhavi-d-thaker
The Impact of Educational Background and Professional Training on Human Right...ijtsrd
This study investigated the impact of educational background and professional training on human rights awareness among secondary school teachers in the Marathwada region of Maharashtra, India. The key findings reveal that higher levels of education, particularly a master’s degree, and fields of study related to education, humanities, or social sciences are associated with greater human rights awareness among teachers. Additionally, both pre service teacher training and in service professional development programs focused on human rights education significantly enhance teacher’s knowledge, skills, and competencies in promoting human rights principles in their classrooms. Baig Ameer Bee Mirza Abdul Aziz | Dr. Syed Azaz Ali Amjad Ali "The Impact of Educational Background and Professional Training on Human Rights Awareness among Secondary School Teachers" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64529.pdf Paper Url: https://www.ijtsrd.com/humanities-and-the-arts/education/64529/the-impact-of-educational-background-and-professional-training-on-human-rights-awareness-among-secondary-school-teachers/baig-ameer-bee-mirza-abdul-aziz
A Study on the Effective Teaching Learning Process in English Curriculum at t...ijtsrd
“One Language sets you in a corridor for life. Two languages open every door along the way” Frank Smith English as a foreign language or as a second language has been ruling in India since the period of Lord Macaulay. But the question is how much we teach or learn English properly in our culture. Is there any scope to use English as a language rather than a subject How much we learn or teach English without any interference of mother language specially in the classroom teaching learning scenario in West Bengal By considering all these issues the researcher has attempted in this article to focus on the effective teaching learning process comparing to other traditional strategies in the field of English curriculum at the secondary level to investigate whether they fulfill the present teaching learning requirements or not by examining the validity of the present curriculum of English. The purpose of this study is to focus on the effectiveness of the systematic, scientific, sequential and logical transaction of the course between the teachers and the learners in the perspective of the 5Es programme that is engage, explore, explain, extend and evaluate. Sanchali Mondal | Santinath Sarkar "A Study on the Effective Teaching Learning Process in English Curriculum at the Secondary Level of West Bengal" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd62412.pdf Paper Url: https://www.ijtsrd.com/humanities-and-the-arts/education/62412/a-study-on-the-effective-teaching-learning-process-in-english-curriculum-at-the-secondary-level-of-west-bengal/sanchali-mondal
The Role of Mentoring and Its Influence on the Effectiveness of the Teaching ...ijtsrd
This paper reports on a study which was conducted to investigate the role of mentoring and its influence on the effectiveness of the teaching of Physics in secondary schools in the South West Region of Cameroon. The study adopted the convergent parallel mixed methods design, focusing on respondents in secondary schools in the South West Region of Cameroon. Both quantitative and qualitative data were collected, analysed separately, and the results were compared to see if the findings confirm or disconfirm each other. The quantitative analysis found that majority of the respondents 72 of Physics teachers affirmed that they had more experienced colleagues as mentors to help build their confidence, improve their teaching, and help them improve their effectiveness and efficiency in guiding learners’ achievements. Only 28 of the respondents disagreed with these statements. With majority respondents 72 agreeing with the statements, it implies that in most secondary schools, experienced Physics teachers act as mentors to build teachers’ confidence in teaching and improving students’ learning. The interview qualitative data analysis summarized how secondary school Principals use meetings with mentors and mentees to promote mentorship in the school milieu. This has helped strengthen teachers’ classroom practices in secondary schools in the South West Region of Cameroon. With the results confirming each other, the study recommends that mentoring should focus on helping teachers employ social interactions and instructional practices feedback and clarity in teaching that have direct measurable impact on students’ learning achievements. Andrew Ngeim Sumba | Frederick Ebot Ashu | Peter Agborbechem Tambi "The Role of Mentoring and Its Influence on the Effectiveness of the Teaching of Physics in Secondary Schools in the South West Region of Cameroon" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64524.pdf Paper Url: https://www.ijtsrd.com/management/management-development/64524/the-role-of-mentoring-and-its-influence-on-the-effectiveness-of-the-teaching-of-physics-in-secondary-schools-in-the-south-west-region-of-cameroon/andrew-ngeim-sumba
Design Simulation and Hardware Construction of an Arduino Microcontroller Bas...ijtsrd
This study primarily focuses on the design of a high side buck converter using an Arduino microcontroller. The converter is specifically intended for use in DC DC applications, particularly in standalone solar PV systems where the PV output voltage exceeds the load or battery voltage. To evaluate the performance of the converter, simulation experiments are conducted using Proteus Software. These simulations provide insights into the input and output voltages, currents, powers, and efficiency under different state of charge SoC conditions of a 12V,70Ah rechargeable lead acid battery. Additionally, the hardware design of the converter is implemented, and practical data is collected through operation, monitoring, and recording. By comparing the simulation results with the practical results, the efficiency and performance of the designed converter are assessed. The findings indicate that while the buck converter is suitable for practical use in standalone PV systems, its efficiency is compromised due to a lower output current. Chan Myae Aung | Dr. Ei Mon "Design Simulation and Hardware Construction of an Arduino-Microcontroller Based DC-DC High-Side Buck Converter for Standalone PV System" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64518.pdf Paper Url: https://www.ijtsrd.com/engineering/mechanical-engineering/64518/design-simulation-and-hardware-construction-of-an-arduinomicrocontroller-based-dcdc-highside-buck-converter-for-standalone-pv-system/chan-myae-aung
Sustainable Energy by Paul A. Adekunte | Matthew N. O. Sadiku | Janet O. Sadikuijtsrd
Energy becomes sustainable if it meets the needs of the present without compromising the ability of future generations to meet their own needs. Some of the definitions of sustainable energy include the considerations of environmental aspects such as greenhouse gas emissions, social, and economic aspects such as energy poverty. Generally far more sustainable than fossil fuel are renewable energy sources such as wind, hydroelectric power, solar, and geothermal energy sources. Worthy of note is that some renewable energy projects, like the clearing of forests to produce biofuels, can cause severe environmental damage. The sustainability of nuclear power which is a low carbon source is highly debated because of concerns about radioactive waste, nuclear proliferation, and accidents. The switching from coal to natural gas has environmental benefits, including a lower climate impact, but could lead to delay in switching to more sustainable options. “Carbon capture and storage” can be built into power plants to remove the carbon dioxide CO2 emissions, but this technology is expensive and has rarely been implemented. Leading non renewable energy sources around the world is fossil fuels, coal, petroleum, and natural gas. Nuclear energy is usually considered another non renewable energy source, although nuclear energy itself is a renewable energy source, but the material used in nuclear power plants is not. The paper addresses the issue of sustainable energy, its attendant benefits to the future generation, and humanity in general. Paul A. Adekunte | Matthew N. O. Sadiku | Janet O. Sadiku "Sustainable Energy" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64534.pdf Paper Url: https://www.ijtsrd.com/engineering/electrical-engineering/64534/sustainable-energy/paul-a-adekunte
Concepts for Sudan Survey Act Implementations Executive Regulations and Stand...ijtsrd
This paper aims to outline the executive regulations, survey standards, and specifications required for the implementation of the Sudan Survey Act, and for regulating and organizing all surveying work activities in Sudan. The act has been discussed for more than 5 years. The Land Survey Act was initiated by the Sudan Survey Authority and all official legislations were headed by the Sudan Ministry of Justice till it was issued in 2022. The paper presents conceptual guidelines to be used for the Survey Act implementation and to regulate the survey work practice, standardizing the field surveys, processing, quality control, procedures, and the processes related to survey work carried out by the stakeholders and relevant authorities in Sudan. The conceptual guidelines are meant to improve the quality and harmonization of geospatial data and to aid decision making processes as well as geospatial information systems. The established comprehensive executive regulations will govern and regulate the implementation of the Sudan Survey Geomatics Act in all surveying and mapping practices undertaken by the Sudan Survey Authority SSA and state local survey departments for public or private sector organizations. The targeted standards and specifications include the reference frame, projection, coordinate systems, and the guidelines and specifications that must be followed in the field of survey work, processes, and mapping products. In the last few decades, there has been a growing awareness of the importance of geomatics activities and measurements on the Earths surface in space and time, together with observing and mapping the changes. In such cases, data must be captured promptly, standardized, and obtained with more accuracy and specified in much detail. The paper will also highlight the current situation in Sudan, the degree to which survey standards are used, the problems encountered, and the errors that arise from not using the standards and survey specifications. Kamal A. A. Sami "Concepts for Sudan Survey Act Implementations - Executive Regulations and Standards" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd63484.pdf Paper Url: https://www.ijtsrd.com/engineering/civil-engineering/63484/concepts-for-sudan-survey-act-implementations--executive-regulations-and-standards/kamal-a-a-sami
Towards the Implementation of the Sudan Interpolated Geoid Model Khartoum Sta...ijtsrd
The discussions between ellipsoid and geoid have invoked many researchers during the recent decades, especially during the GNSS technology era, which had witnessed a great deal of development but still geoid undulation requires more investigations. To figure out a solution for Sudans local geoid, this research has tried to intake the possibility of determining the geoid model by following two approaches, gravimetric and geometrical geoid model determination, by making use of GNSS leveling benchmarks at Khartoum state. The Benchmarks are well distributed in the study area, in which, the horizontal coordinates and the height above the ellipsoid have been observed by GNSS while orthometric heights were carried out using precise leveling. The Global Geopotential Model GGM represented in EGM2008 has been exploited to figure out the geoid undulation at the benchmarks in the study area. This is followed by a fitting process, that has been done to suit the geoid undulation data which has been computed using GNSS leveling data and geoid undulation inspired by the EGM2008. Two geoid surfaces were created after the fitting process to ensure that they are identical and both of them could be counted for getting the same geoid undulation with an acceptable accuracy. In this respect, statistical operation played an important role in ensuring the consistency and integrity of the model by applying cross validation techniques splitting the data into training and testing datasets for building the geoid model and testing its eligibility. The geometrical solution for geoid undulation computation has been utilized by applying straightforward equations that facilitate the calculation of the geoid undulation directly through applying statistical techniques for the GNSS leveling data of the study area to get the common equation parameters values that could be utilized to calculate geoid undulation of any position in the study area within the claimed accuracy. Both systems were checked and proved eligible to be used within the study area with acceptable accuracy which may contribute to solving the geoid undulation problem in the Khartoum area, and be further generalized to determine the geoid model over the entire country, and this could be considered in the future, for regional and continental geoid model. Ahmed M. A. Mohammed. | Kamal A. A. Sami "Towards the Implementation of the Sudan Interpolated Geoid Model (Khartoum State Case Study)" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd63483.pdf Paper Url: https://www.ijtsrd.com/engineering/civil-engineering/63483/towards-the-implementation-of-the-sudan-interpolated-geoid-model-khartoum-state-case-study/ahmed-m-a-mohammed
Activating Geospatial Information for Sudans Sustainable Investment Mapijtsrd
Sudan is witnessing an acceleration in the processes of development and transformation in the performance of government institutions to raise the productivity and investment efficiency of the government sector. The development plans and investment opportunities have focused on achieving national goals in various sectors. This paper aims to illuminate the path to the future and provide geospatial data and information to develop the investment climate and environment for all sized businesses, and to bridge the development gap between the Sudan states. The Sudan Survey Authority SSA is the main advisor to the Sudan Government in conducting surveying, mappings, designing, and developing systems related to geospatial data and information. In recent years, SSA made a strategic partnership with the Ministry of Investment to activate Geospatial Information for Sudans Sustainable Investment and in particular, for the preparation and implementation of the Sudan investment map, based on the directives and objectives of the Ministry of Investment MI in Sudan. This paper comes within the framework of activating the efforts of the Ministry of Investment to develop technical investment services by applying techniques adopted by the Ministry and its strategic partners for advancing investment processes in the country. Kamal A. A. Sami "Activating Geospatial Information for Sudan's Sustainable Investment Map" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd63482.pdf Paper Url: https://www.ijtsrd.com/engineering/information-technology/63482/activating-geospatial-information-for-sudans-sustainable-investment-map/kamal-a-a-sami
Educational Unity Embracing Diversity for a Stronger Societyijtsrd
In a rapidly changing global landscape, the importance of education as a unifying force cannot be overstated. This paper explores the crucial role of educational unity in fostering a stronger and more inclusive society through the embrace of diversity. By examining the benefits of diverse learning environments, the paper aims to highlight the positive impact on societal strength. The discussion encompasses various dimensions, from curriculum design to classroom dynamics, and emphasizes the need for educational institutions to become catalysts for unity in diversity. It highlights the need for a paradigm shift in educational policies, curricula, and pedagogical approaches to ensure that they are reflective of the diverse fabric of society. This paper also addresses the challenges associated with implementing inclusive educational practices and offers practical strategies for overcoming barriers. It advocates for collaborative efforts between educational institutions, policymakers, and communities to create a supportive ecosystem that promotes diversity and unity. Mr. Amit Adhikari | Madhumita Teli | Gopal Adhikari "Educational Unity: Embracing Diversity for a Stronger Society" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64525.pdf Paper Url: https://www.ijtsrd.com/humanities-and-the-arts/education/64525/educational-unity-embracing-diversity-for-a-stronger-society/mr-amit-adhikari
Integration of Indian Indigenous Knowledge System in Management Prospects and...ijtsrd
The diversity of indigenous knowledge systems in India is vast and can vary significantly between different communities and regions. Preserving and respecting these knowledge systems is crucial for maintaining cultural heritage, promoting sustainable practices, and fostering cross cultural understanding. In this paper, an overview of the prospects and challenges associated with incorporating Indian indigenous knowledge into management is explored. It is found that IIKS helps in management in many areas like sustainable development, tourism, food security, natural resource management, cultural preservation and innovation, etc. However, IIKS integration with management faces some challenges in the form of a lack of documentation, cultural sensitivity, language barriers legal framework, etc. Savita Lathwal "Integration of Indian Indigenous Knowledge System in Management: Prospects and Challenges" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd63500.pdf Paper Url: https://www.ijtsrd.com/management/accounting-and-finance/63500/integration-of-indian-indigenous-knowledge-system-in-management-prospects-and-challenges/savita-lathwal
DeepMask Transforming Face Mask Identification for Better Pandemic Control in...ijtsrd
The COVID 19 pandemic has highlighted the crucial need of preventive measures, with widespread use of face masks being a key method for slowing the viruss spread. This research investigates face mask identification using deep learning as a technological solution to be reducing the risk of coronavirus transmission. The proposed method uses state of the art convolutional neural networks CNNs and transfer learning to automatically recognize persons who are not wearing masks in a variety of circumstances. We discuss how this strategy improves public health and safety by providing an efficient manner of enforcing mask wearing standards. The report also discusses the obstacles, ethical concerns, and prospective applications of face mask detection systems in the ongoing fight against the pandemic. Dilip Kumar Sharma | Aaditya Yadav "DeepMask: Transforming Face Mask Identification for Better Pandemic Control in the COVID-19 Era" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd64522.pdf Paper Url: https://www.ijtsrd.com/engineering/electronics-and-communication-engineering/64522/deepmask-transforming-face-mask-identification-for-better-pandemic-control-in-the-covid19-era/dilip-kumar-sharma
Streamlining Data Collection eCRF Design and Machine Learningijtsrd
Efficient and accurate data collection is paramount in clinical trials, and the design of Electronic Case Report Forms eCRFs plays a pivotal role in streamlining this process. This paper explores the integration of machine learning techniques in the design and implementation of eCRFs to enhance data collection efficiency. We delve into the synergies between eCRF design principles and machine learning algorithms, aiming to optimize data quality, reduce errors, and expedite the overall data collection process. The application of machine learning in eCRF design brings forth innovative approaches to data validation, anomaly detection, and real time adaptability. This paper discusses the benefits, challenges, and future prospects of leveraging machine learning in eCRF design for streamlined and advanced data collection in clinical trials. Dhanalakshmi D | Vijaya Lakshmi Kannareddy "Streamlining Data Collection: eCRF Design and Machine Learning" Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-8 | Issue-1 , February 2024, URL: https://www.ijtsrd.com/papers/ijtsrd63515.pdf Paper Url: https://www.ijtsrd.com/biological-science/biotechnology/63515/streamlining-data-collection-ecrf-design-and-machine-learning/dhanalakshmi-d
Instructions for Submissions thorugh G- Classroom.pptxJheel Barad
This presentation provides a briefing on how to upload submissions and documents in Google Classroom. It was prepared as part of an orientation for new Sainik School in-service teacher trainees. As a training officer, my goal is to ensure that you are comfortable and proficient with this essential tool for managing assignments and fostering student engagement.
Macroeconomics- Movie Location
This will be used as part of your Personal Professional Portfolio once graded.
Objective:
Prepare a presentation or a paper using research, basic comparative analysis, data organization and application of economic information. You will make an informed assessment of an economic climate outside of the United States to accomplish an entertainment industry objective.
Welcome to TechSoup New Member Orientation and Q&A (May 2024).pdfTechSoup
In this webinar you will learn how your organization can access TechSoup's wide variety of product discount and donation programs. From hardware to software, we'll give you a tour of the tools available to help your nonprofit with productivity, collaboration, financial management, donor tracking, security, and more.
Model Attribute Check Company Auto PropertyCeline George
In Odoo, the multi-company feature allows you to manage multiple companies within a single Odoo database instance. Each company can have its own configurations while still sharing common resources such as products, customers, and suppliers.
The French Revolution, which began in 1789, was a period of radical social and political upheaval in France. It marked the decline of absolute monarchies, the rise of secular and democratic republics, and the eventual rise of Napoleon Bonaparte. This revolutionary period is crucial in understanding the transition from feudalism to modernity in Europe.
For more information, visit-www.vavaclasses.com
Palestine last event orientationfvgnh .pptxRaedMohamed3
An EFL lesson about the current events in Palestine. It is intended to be for intermediate students who wish to increase their listening skills through a short lesson in power point.
Acetabularia Information For Class 9 .docxvaibhavrinwa19
Acetabularia acetabulum is a single-celled green alga that in its vegetative state is morphologically differentiated into a basal rhizoid and an axially elongated stalk, which bears whorls of branching hairs. The single diploid nucleus resides in the rhizoid.
June 3, 2024 Anti-Semitism Letter Sent to MIT President Kornbluth and MIT Cor...Levi Shapiro
Letter from the Congress of the United States regarding Anti-Semitism sent June 3rd to MIT President Sally Kornbluth, MIT Corp Chair, Mark Gorenberg
Dear Dr. Kornbluth and Mr. Gorenberg,
The US House of Representatives is deeply concerned by ongoing and pervasive acts of antisemitic
harassment and intimidation at the Massachusetts Institute of Technology (MIT). Failing to act decisively to ensure a safe learning environment for all students would be a grave dereliction of your responsibilities as President of MIT and Chair of the MIT Corporation.
This Congress will not stand idly by and allow an environment hostile to Jewish students to persist. The House believes that your institution is in violation of Title VI of the Civil Rights Act, and the inability or
unwillingness to rectify this violation through action requires accountability.
Postsecondary education is a unique opportunity for students to learn and have their ideas and beliefs challenged. However, universities receiving hundreds of millions of federal funds annually have denied
students that opportunity and have been hijacked to become venues for the promotion of terrorism, antisemitic harassment and intimidation, unlawful encampments, and in some cases, assaults and riots.
The House of Representatives will not countenance the use of federal funds to indoctrinate students into hateful, antisemitic, anti-American supporters of terrorism. Investigations into campus antisemitism by the Committee on Education and the Workforce and the Committee on Ways and Means have been expanded into a Congress-wide probe across all relevant jurisdictions to address this national crisis. The undersigned Committees will conduct oversight into the use of federal funds at MIT and its learning environment under authorities granted to each Committee.
• The Committee on Education and the Workforce has been investigating your institution since December 7, 2023. The Committee has broad jurisdiction over postsecondary education, including its compliance with Title VI of the Civil Rights Act, campus safety concerns over disruptions to the learning environment, and the awarding of federal student aid under the Higher Education Act.
• The Committee on Oversight and Accountability is investigating the sources of funding and other support flowing to groups espousing pro-Hamas propaganda and engaged in antisemitic harassment and intimidation of students. The Committee on Oversight and Accountability is the principal oversight committee of the US House of Representatives and has broad authority to investigate “any matter” at “any time” under House Rule X.
• The Committee on Ways and Means has been investigating several universities since November 15, 2023, when the Committee held a hearing entitled From Ivory Towers to Dark Corners: Investigating the Nexus Between Antisemitism, Tax-Exempt Universities, and Terror Financing. The Committee followed the hearing with letters to those institutions on January 10, 202
Francesca Gottschalk - How can education support child empowerment.pptxEduSkills OECD
Francesca Gottschalk from the OECD’s Centre for Educational Research and Innovation presents at the Ask an Expert Webinar: How can education support child empowerment?
Honest Reviews of Tim Han LMA Course Program.pptxtimhan337
Personal development courses are widely available today, with each one promising life-changing outcomes. Tim Han’s Life Mastery Achievers (LMA) Course has drawn a lot of interest. In addition to offering my frank assessment of Success Insider’s LMA Course, this piece examines the course’s effects via a variety of Tim Han LMA course reviews and Success Insider comments.
Biological screening of herbal drugs: Introduction and Need for
Phyto-Pharmacological Screening, New Strategies for evaluating
Natural Products, In vitro evaluation techniques for Antioxidants, Antimicrobial and Anticancer drugs. In vivo evaluation techniques
for Anti-inflammatory, Antiulcer, Anticancer, Wound healing, Antidiabetic, Hepatoprotective, Cardio protective, Diuretics and
Antifertility, Toxicity studies as per OECD guidelines
2. International Journal of Trend in Scientific Research and Development (IJTSRD) @ www.ijtsrd.com eISSN: 2456-6470
@ IJTSRD | Unique Paper ID – IJTSRD25138 | Volume – 3 | Issue – 4 | May-Jun 2019 Page: 1329
Internet of things can be compared to the communication
among humans, with respect to the equation above. For
instance, humans have biological sensors such as ears, eyes,
skin, taste buds, etc. to perceive what is happening in their
surroundings [2]. This research focuses on the
communication between traffic lights, sensors and users. In
this case, each sensors which sense and transmit traffic data
act as eye.
III. LITERATURE REVIEW
N. Choosri, in March 2015, proposed IoT-RFID testbed for
supporting traffic light control. In this paper, RFID
technology is used to figure out congestion level of road.
RFID tags are equipped in every vehicle and RFID reader is
installed at the intersection to read the tag when thetags are
within the operating distance of the reader. With this
configuration, the reader can count the number of identified
tags to figure out congestion level.[2]
Dr. Sanjeev Uppal, in April 2016, proposed smart traffic
control system using GSM. This system allows traffic
management and traffic reporting advice to road users. It
provides the users who wish to obtain the latest traffic
information on congested roads by using GSM phone with
SMS facility. The presence of vehicles is sensed by sensor
mounted on each road. The timing sequence of traffic lights
is decided by the total traffic on all the adjacent roads. [10]
Aadish Agrawal, Shreyash Saurabh, in2017, proposedtraffic
control system using zigbee module. Thissystemcanchange
all the traffic light signals to green in order to provide a clear
way for the emergency vehicles. In this system, the
emergency vehicle is equipped with the zigbee transmitter
and zigbee receiver is implemented at the traffic pole. If
zigbee transmitter is switched on by the driver, the
transmitter will communicate with nearby traffic signal and
it will convert the traffic light to green. [11]
IV. SOFTWARE REQUIREMENT
A. Thinger.io IoT platform
Thinger.io is an open source IoT platform. IoT devices are
connected with this platform andmanagethesedevicesfrom
this platform. An account is registered to their cloud
infrastructure and the open source libraries can be used for
connecting devices. This platform can connect with any
devices such as Arduino, ESP8266, Raspberry Pi and so on.
Turning on a light from the internet and reading a sensor
value are made by writing a single line of code on the MCU.
B. Wireshark software
Wireshark is the open-source packet or network protocol
analyser. It is a network analysis tool formerly known as
Ethereal. It can capture packets in realtime anddisplaythem
in human-readable format. Using wireshark, user can
troubleshoot network problems, examine security issues,
debug protocols and learn network process. It can also save
packet data to file for offline analysis. It is a GUI based
network capture tool.
V. PROPOSED SYSTEM
The functional block diagram of overall system is shown in
Figure 1. The system is divided into two parts: monitoring
section and control section.
In monitoring section, it includes IoT devices. Each IoT
devices consists of esp8266 nodemcu, ultrasonic sensors,
arduino, TM1637 LED display and LEDs. Arduino , LEDs and
TM1637 are used to build the traffic light. Ultrasonic sensor
and nodemcu are used to monitor the traffic condition.
Ultrasonic sensor senses the traffic condition and the result
is send to the website by using nodemcu esp8266 wifi
module. So user can see the traffic information from this
website.
In control section, arduino and nodemcu are connected to
change the timing sequence of traffic light. Arduino that is
used to build the traffic lightisinterrupted with nodemcu via
the website from control room when the traffic jams at the
road.
Fig.1. Overall block diagram of proposed system
Fig. 2. Ultrasonic sensor
Hcsr04 ultrasonic sensor is composed of ultrasonic
transmitter, ultrasonic receiver and a control circuit.
Ultrasonic transmitter transmits ultrasound waves at
40kHz.Transmitted waves bounce back if they hit any flat
surface or object in their path. Bounced back waves reach
the ultrasonic receiver. Ultrasonic receiver receives the
bounced back waves and notifies the control circuit about it.
Control circuit calculates the time taken by waves to reach
back after transmission. It can measure distancebetween an
active range of 2cm to 4m.It has four pins-Vcc ,Gnd, Trigger
and Echo.
D =1/2×T×C ,
Where D = distance,
C = the sonic speed(340m/s),
T= time between the emission and reception
The value is multiplied by ½ because T is the time for go-
and-return distance.
3. International Journal of Trend in Scientific Research and Development (IJTSRD) @ www.ijtsrd.com eISSN: 2456-6470
@ IJTSRD | Unique Paper ID – IJTSRD25138 | Volume – 3 | Issue – 4 | May-Jun 2019 Page: 1330
Fig.3. NodeMCU ESP8266
The ESP8266 is the name of a micro controller designed by
Espressif systems.TheESP8266 itself isaself-containedWiFi
networking solution offering as a bridge from existingmicro
controller to WiFi and is also capable of running self-
contained applications. This module comes with a built in
USB connecter and a rich assortment of pin-outs. NodeMCU
is a firmware that allows user to program the ESP8266
module.
NodeMCU microcontroller consists of nine digital I/O pins
and one analog I/O pin. It requires 600mA of current for its
full load opertaion. It operates at 3.3V power supply. The
microcontroller is equipped with an esp8266 WiFi module
[1]. The esp8266 WiFi module has 4MB of flash memory.
Nodemcu has 80MHz CPU frequency and upload speed is
115200 baud rate. This device can be directly programmed
from the arduino IDE.
Fig.4. Flow Chart of the System
Firstly, start block is represented as initialization of the
system. Then, parameters that used in the system are
declared and check the internet connection of the devices. If
device is not connected with the internet, go back to the
second step. If the device is connected with the internet, go
to the next step. In this step, ultrasonic sensor senses the
traffic condition and then this result is sent to the thinger.io.
Then the result is checked. If the result is “free”, go to the 4th
step. If the result is “traffic jam”, traffic light is interrupted
from thinger.io IoT platform.
VI. EXPERIMENTAL TEST AND RESULT
A. Monitoring Section
Fig.5. Testing ultrasonic sensor and sending to the
thinger.io
Figure 5 shows the monitoring of the traffic condition and
display the result in the thinger.io IoT platform. Ultrasonic
sensor is connected with nodemcu and senses thecondition.
And then, the result is sent to the thinger.io via nodemcu. To
use the thinger.io IoT platform, an account is signed up to
this platform. And, device must be added in device list and
dashboard is added in dashboard list to monitor and control
the traffic condition. In dashboard, condition is displayed
with many ways by adding widget. The figure in the left
shows testing the ultrasonic sensor with object in front of it.
The figure in the right shows that the traffic condition of the
road can be seen from dashboard list in thinger.io.
Fig. 6. Testing ultrasonic sensor and this result is sent to
the thinger.io
Figure 6 also shows the monitoring of the traffic condition
and the result is shown in the thinger.io IoT platform. The
figure in the left shows testing the ultrasonic sensor with no
object in front of it. The figure in the right shows that the
condition which is no vehicle in front of ultrasonic sensor
can be seen from thinger.io IoT platform.
B. Control Section
Fig.7. Traffic light with regular timing sequence
4. International Journal of Trend in Scientific Research and Development (IJTSRD) @ www.ijtsrd.com eISSN: 2456-6470
@ IJTSRD | Unique Paper ID – IJTSRD25138 | Volume – 3 | Issue – 4 | May-Jun 2019 Page: 1331
Fig.8. Controlling timing sequence of traffic light from
thinger.io
Figure 8 show the timing sequenceafterinterruption.Traffic
light and timing sequence are built by using arduino.
Interruption can be made from thinger.ioIoTplatformwhen
it needs to change the timing sequence of traffic light. When
there is traffic in first lane and there is no traffic in other
lane, the timing sequence of the first lane is interrupted at
green time duration. This can madelonggreen timeduration
for first lane and long red time duration for other lane.
Fig.9. Throughput graph between computer and
thinger.io
Figure 9 shows thethroughputgraphbetween computer and
thinger.io. Throughput is defined as the quantity of data
being sent or received by unit of time. This graph is resulted
from wireshark software. Wireshark software is usedtotest
the response speed of the system. All the packets which are
passing through system network interfacefrom computerto
thinger.io IoT platform can be seen by using this software.
From these packets, response speed such as round trip time
and throughput graph can be produced inthissoftware. This
throughput graph can be produced from these packets. In
this figure, Y axis at the right represents the average
throughput in bit per second, Y axis at the left represent the
segment length and X axis represents the time. At thisgraph,
average throughput 4500 bits/s are sent from computer to
thinger.io at every 1 second.
VII. CONCLUSION
As the volume of vehicles inside city is increasing
significantly, citizens using public transportation are more
troubles for traffic jam. In this paper, a traffic management
system that is capable of monitoring and controlling the
traffic condition have been developed and implemented by
using internet of things (IoT). By usingthissystem,userscan
know the traffic information from anywhere and sothey can
decide the right way to reach their destination in time. Thus,
the system developed in this paper proves to be reliable and
cost-effective.
ACKNOWLEDGMENT
The author would like to express special thanks to Dr.Kyaw
Zin Latt, Associate Professor, Department of Electronic
Engineering for kind permission to prepare for this paper,
for his close supervision, helpful advice, encouragementand
invaluable guidance. The author would also thank to all
teachers and friends who willingly helped the author
throughout the preparation of the paper.
REFERENCES
[1] Bharath Kumar Perumalla, M. Sunil Babu, PG student,
Department of Electronics and Communication
Engineering, Vasireddy Venkatadri Institute of
Technology, Namburu, Guntur(dt.), A.P.(India), “An
Intelligent Traffic and VehicleMonitoringSystemusing
Internet of Things Architecture”, IJSR-
ISSN(Online):2319-7064.
[2] N.Choosri, Y.Park, S.Grudpan, P.Chuarjedton, and A.
Ongvisesphaiboon, “IoT- RFID Testbed for Supporting
Traffic Light Control”, International Journal of
Information and Electronics Engineering, volume 5,
no.2, March 2015.
[3] Nyoman Putra Sastra, Electricalc Engineering
Department, Engineering Faculty,Udayana University
,Bukit Jimbaran Campus, Badung, Bali, Indonesia,
“Internet of Things for Intelligent Traffic Monitoring
System: A Case Study in Denpasar”, IJCTT-volume 30,
number 3, December 2015.
[4] Shiu Kumar, Yong Ok Jo,Eun Sik Ham,Jun Woo Shinand
SeongRo Lee, Mokpo National University,NIPA,“Traffic
Monitoring Using M2M Communication”.
[5] Mahesh Lakshminarasimhan,DepartmentofComputer
Science and Engineering, Sri Krishna College of
Engineering and Technology, Coimbatore, TamilNadu,
India, “Advanced Traffic Management System Using
Internet of Things”,
[6] Dinesh Kulkarni, Sohail Shaikh, Amol Shirsath,
Tejaswini Kadam, Department of Computer Engg,
PVG’S COET, Pune,India, “Traffic and Weather
Monitoring System Using Wireless Sensor Networks”,
IJARCCE- Volume 4, Issue 3, March 2015.
[7] P.Dayaker, Department of CSE, MLR Institute of
Technology, Hyderabad, India, “Smart Traffic Control
System Using Zigbee/RFID Networks”, IJCIET-volume
8, Issue 6, June 2017.
[8] Chandana K K, Student, Department of Computer
Science and Engineering, GSSS Institute of Engineering
and Technology for Women, Mysuru, India,”A Smart
Traffic ManagementSystemfor Congestion Controland
Warnings Using Internet of Things(IoT)”, Saudijournal
of Engineering and Technology.
[9] Nikita Tendulkar, Komal Sonawane, Darshana vakte,
Deepti pujari, Ghanshyam Dhomase, “A Review of
Traffic Management System Using IoT”, International
Journal of ModernTrendsinEngineeringand Research,
April, 2016.
[10] Aadish Agrawal, Shreyash Saurabh, Department of
School of Electronics Engineering, VIT University,
Vellore, India, “Traffic Control System using Zigbee
Module”,IJESC , volume 7, issue no.4, April 2017.
[11] Lakshya Chaudhary, Abhishek Badoni, Mohammad
Aqdas Khan, Department of Electrical and Electronics
Engineering SRM University Delhi NCR Campus,
Ghaziabad,”Smart Traffic Control System Using GSM”,
ijarets, April 2016 volume 3, issue 4.
![International Journal of Trend in Scientific Research and Development (IJTSRD)
Volume: 3 | Issue: 4 | May-Jun 2019 Available Online: www.ijtsrd.com e-ISSN: 2456 - 6470
@ IJTSRD | Unique Paper ID – IJTSRD25138 | Volume – 3 | Issue – 4 | May-Jun 2019 Page: 1328
Traffic Monitoring and Control System Using IoT
Ei Swe Zin, Kyaw Zin Latt
Department of Electronic Engineering, Mandalay Technological University, Mandalay, Myanmar
How to cite this paper: Ei Swe Zin |
Kyaw Zin Latt "Traffic Monitoring and
Control System Using IoT" Published in
International Journal of Trend in
Scientific Research and Development
(ijtsrd), ISSN: 2456-
6470, Volume-3 |
Issue-4, June 2019,
pp.1328-1331, URL:
https://www.ijtsrd.c
om/papers/ijtsrd25
138.pdf
Copyright © 2019 by author(s) and
International Journal of Trend in
Scientific Research and Development
Journal. This is an Open Access article
distributed under
the terms of the
Creative Commons
Attribution License (CC BY 4.0)
(http://creativecommons.org/licenses/
by/4.0)
ABSTRACT
This research aims to monitor the traffic condition and tocontrolthetrafficlight.
This system can reduce not only traffic congestion but also waiting time. This
system is designed to be implemented in places nearing the junctions. This
research is based on the effective use of Internetof Things(IoT).Thissystemwill
display the traffic conditions in the website and the trafficlight can becontrolled
from this website. This system has been implemented by using esp8266,
ultrasonic sensor and arduino. Esp8266 nodemcu which is IoT device is used to
transmit the traffic information to the website which is connected with this
device. Ultrasonic sensors are placed on each road to sense the presence and
absence of vehicles. Traffic information is received from these sensors. Traffic
light prototype is built by using an arduino UNO. This traffic light can be
controlled from the website. The system will display the traffic states in the
website that can guide the drivers to select the right way and avoid traffic
congestions.
Keywords: Internet of Things (IoT), ultrasonic sensor, Wi-Fi module (ESP8266),
wireshark software
I. INTRODUCTION
Nowadays, world’s population is increasing. So many vehicles are used in
transportation system. As the use of vehiclesisincreasing,theproblemof trafficis
arising. Traffic congestion is a common problem in large cities.
Thus the traffic management system involves in vital role in
every country. If the transportation is poor, that means the
image of this country will not develop. Because of the traffic
jams and lack of proper trafficmanagementsystem, timeand
money of the public is being wasted. Traffic congestion
results in direct economic loss, and also exacerbates the air
pollution of the urban cities because vehicles emit more
carbon dioxide and other toxic materials when they are at a
lower speed [4]. There are a lot of technologies to build the
traffic management system such as RFID, Bluetooth, zigbee,
GSM-GPS based system [1]. Among them, the traffic
efficiency can be improved with the helpof internetof things
(IoT). This research intends to determine the design of the
implementation of the internet of things (IoT) for traffic
management system. Traffic management system using IoT
is built to help people to get latest information of traffic
condition in different area [6]. The traffic signals can be
managed by monitoring the traffic density to avoid traffic
congestion on road using network communication between
website and hardware module [9]. Trafficlightsaretypically
used to control the flow of vehicles at intersections. The
problem with the traffic system is thateven thoughthereare
no vehicles on one side and there are many vehicles on
another side, the traffic signals will flow for given fixed time
[7]. Due to that, there is time wasteprocess.Thus,thesystem
must be implemented to controls the traffic based on the
heavy flow of vehicles at any particular side. In this system,
the number of vehicles on each side at the junction will be
counted by using ultrasonic sensors. Ultrasonic sensors are
used to sense the number of vehicles on the road. Therefore
this system will make transportation to be developed.
II. INTERNET OF THINGS
Internet of things (IoT) can be expressed as a world-wide
network of interconnected objects uniquely addressable,
based on standard communication protocols [3].By using
IoT, any device that is connected to the internet can be
controlled and monitored from any place. This device is
considered as IoT device. IoT is simply connecting all the
surrounding smart devices (things) to internet. So, IoT is a
giant network of physical object devices, vehicles, buildings
and other items which are embedded with electronics,
software, sensors and network connectivity. IoT connect
between the physical world and virtual world [8].
IoT is considered as a part of the internet of the future and
will comprise billions of intelligent communicating ‘things’.
The future of the internet will consist of heterogeneously
connected devices that will further extend thebordersof the
world with physical entities and virtual components. IoT is
an emerging research paradigm and apparently the
discovery of its body of knowledge is still in an infancystage.
Most scholars agree on the idea of expanding and
interpreting the pioneering conceptual definition of Kevin
Ashton who defined IoT as “a standardized way for
computer to understand the real world”. IoT-based systems
have been proposed in several applications such as
supporting disabilities, managing diabetes therapy, building
smart home, improving safety in mining operations [2][5].
The following equation describes IoTinasimplified manner,
IoT = Physical Entity+Controller,Sensor,Actuators+
Internet
IJTSRD25138](https://image.slidesharecdn.com/282trafficmonitoringandcontrolsystemusing-190710100232/85/Traffic-Monitoring-and-Control-System-Using-IoT-1-320.jpg)
![International Journal of Trend in Scientific Research and Development (IJTSRD) @ www.ijtsrd.com eISSN: 2456-6470
@ IJTSRD | Unique Paper ID – IJTSRD25138 | Volume – 3 | Issue – 4 | May-Jun 2019 Page: 1329
Internet of things can be compared to the communication
among humans, with respect to the equation above. For
instance, humans have biological sensors such as ears, eyes,
skin, taste buds, etc. to perceive what is happening in their
surroundings [2]. This research focuses on the
communication between traffic lights, sensors and users. In
this case, each sensors which sense and transmit traffic data
act as eye.
III. LITERATURE REVIEW
N. Choosri, in March 2015, proposed IoT-RFID testbed for
supporting traffic light control. In this paper, RFID
technology is used to figure out congestion level of road.
RFID tags are equipped in every vehicle and RFID reader is
installed at the intersection to read the tag when thetags are
within the operating distance of the reader. With this
configuration, the reader can count the number of identified
tags to figure out congestion level.[2]
Dr. Sanjeev Uppal, in April 2016, proposed smart traffic
control system using GSM. This system allows traffic
management and traffic reporting advice to road users. It
provides the users who wish to obtain the latest traffic
information on congested roads by using GSM phone with
SMS facility. The presence of vehicles is sensed by sensor
mounted on each road. The timing sequence of traffic lights
is decided by the total traffic on all the adjacent roads. [10]
Aadish Agrawal, Shreyash Saurabh, in2017, proposedtraffic
control system using zigbee module. Thissystemcanchange
all the traffic light signals to green in order to provide a clear
way for the emergency vehicles. In this system, the
emergency vehicle is equipped with the zigbee transmitter
and zigbee receiver is implemented at the traffic pole. If
zigbee transmitter is switched on by the driver, the
transmitter will communicate with nearby traffic signal and
it will convert the traffic light to green. [11]
IV. SOFTWARE REQUIREMENT
A. Thinger.io IoT platform
Thinger.io is an open source IoT platform. IoT devices are
connected with this platform andmanagethesedevicesfrom
this platform. An account is registered to their cloud
infrastructure and the open source libraries can be used for
connecting devices. This platform can connect with any
devices such as Arduino, ESP8266, Raspberry Pi and so on.
Turning on a light from the internet and reading a sensor
value are made by writing a single line of code on the MCU.
B. Wireshark software
Wireshark is the open-source packet or network protocol
analyser. It is a network analysis tool formerly known as
Ethereal. It can capture packets in realtime anddisplaythem
in human-readable format. Using wireshark, user can
troubleshoot network problems, examine security issues,
debug protocols and learn network process. It can also save
packet data to file for offline analysis. It is a GUI based
network capture tool.
V. PROPOSED SYSTEM
The functional block diagram of overall system is shown in
Figure 1. The system is divided into two parts: monitoring
section and control section.
In monitoring section, it includes IoT devices. Each IoT
devices consists of esp8266 nodemcu, ultrasonic sensors,
arduino, TM1637 LED display and LEDs. Arduino , LEDs and
TM1637 are used to build the traffic light. Ultrasonic sensor
and nodemcu are used to monitor the traffic condition.
Ultrasonic sensor senses the traffic condition and the result
is send to the website by using nodemcu esp8266 wifi
module. So user can see the traffic information from this
website.
In control section, arduino and nodemcu are connected to
change the timing sequence of traffic light. Arduino that is
used to build the traffic lightisinterrupted with nodemcu via
the website from control room when the traffic jams at the
road.
Fig.1. Overall block diagram of proposed system
Fig. 2. Ultrasonic sensor
Hcsr04 ultrasonic sensor is composed of ultrasonic
transmitter, ultrasonic receiver and a control circuit.
Ultrasonic transmitter transmits ultrasound waves at
40kHz.Transmitted waves bounce back if they hit any flat
surface or object in their path. Bounced back waves reach
the ultrasonic receiver. Ultrasonic receiver receives the
bounced back waves and notifies the control circuit about it.
Control circuit calculates the time taken by waves to reach
back after transmission. It can measure distancebetween an
active range of 2cm to 4m.It has four pins-Vcc ,Gnd, Trigger
and Echo.
D =1/2×T×C ,
Where D = distance,
C = the sonic speed(340m/s),
T= time between the emission and reception
The value is multiplied by ½ because T is the time for go-
