2. OBJECTIVES
Describe the differences between septal ablation & atrial
ablation
Be able to explain the general procedure for each type of
ablation
Understand the specific uses for each type of ablation
By the end of this presentation you should be able to:
4. WHAT IS “ALCOHOL SEPTALABLATION”?
Procedure involving injection of pure alcohol into the target septal
branch of the LAD to induce a controlled infarction
HISTORY:
Minimally invasive procedure introduced in 1994
Targeted poor surgical candidates
Treatment for HOCM patients
5. HYPERTROPHIC CARDIOMYOPATHY
(HCM)
Non-obstructed vs. Obstructed
1/3 patients have non-obstructed HCM
Obstruction to LVOT is typically found
Symptoms: SOB, CP, Heart Murmur, Palpitations
Causes: Genetically inherited
Relative screening
6. HYPERTROPHIC OBSTRUCTIVE
CARDIOMYOPATHY (HOCM)
Septum becomes asymmetrically thickened & mitral valve moves in
an anterior motion, obstructing aortic outflow in systole
Obstructive vs. Provocable
Obstructive: ASH + SAM
Provocable: SAM of MV leaflets, mid-systolic closure of AoV,
& mitral regurgitation with exercise
7. PROCEDURE
1. Sedative administered
2. TEE monitors cardiac activity
3. Tubes are inserted into groin + temporary pacemaker passed to RV
4. Guide wire & balloon catheter
5. Position of sepal artery is identified (contrast + balloon catheter)
8. PROCEDURE CONTINUED…
6. Alcohol (2-5 cc) is injected
7. Balloon is deflated and removed
Refined over the years:
Utilization of myocardial contrast
Alcohol reduction
12. WHAT IS “CATHETER ABLATION”?
A procedure that uses an energy source to destroy a small
area of the heart tissue that is causing rapid & irregular heart
beats
History:
Originated in 1980s
1990s: Atrial fibrillation
13. WHY HAVE A CATHETER ABLATION?
Unsuccessful medications
Serious side effects
Arrhythmias that respond extremely well to procedure
(Wolff-Parkinson-White Syndrome)
High risk of complications
16. PROCEDURE
1. Catheter inserted & threaded to heart
2. Catheter’s tip threaded through incision in atrial septum
3. Positioned to ablate tissue related to source of erratic electrical signal
(typically PV)
4. Catheter uses an energy source to create a lesion of scar tissue)
Cryothermy (intense cold)
Radiofrequency energy (radio)
Laser energy (light waves)
18. RISKS
Catheter site infection
Damage to vessels
Puncture of heart
Damage to heart valves
Venous thromboembolism
Stroke or heart attack
Damage to heart’s electrical system
Very low risk (90% success)
19. - Use of pure alcohol
- Treat HOCM patients
- Use of TEE
-Catheter balloon
-Contrast used
-Temporary pacemaker
- Energy source based
(cold, radio, light)
- Treats Afib, Atrial
flutter, SVT
- 3D mapping
Septal Ablation Atrial Ablation
-Catheter
based
-SOB, CP,
arrhythmias
-low risk
20. QUIZ
1. Septal ablation is typically a treatment option for patients with
what type of cardiomyopathy?
2. (True/False) Septal & Atrial ablations are considered low risk
procedures.
3. What are the three types of catheter energy sources associated with
atrial ablations?
Cryothermy (cold), Radiofrequency (radio), laser energy (light)
HOCM
True
Induce a controlled infarction of the hypertrophied septum & get rid of the dynamic outflow obstruction
1994: less invasive treatment instead of surgical myomectomy for HOCM patients
Disease in which the myocardium becomes abnormally thick
Sudden death in young athletes
Causes: 50% chance of passing mutation to child
Obstructive: Asymmetric Septal Hypertrophy + Septal Anterior Motion
--- Resting gradient > or equal to 30 mmHg
Provocable: “Dynamic Obstruction”
----Resting gradient is < 30 mmHg but obstruction occurs with exercise
For pain & relaxation
Before & after procedure
Tubes inserted into groin via artery & vein /// Pacemaker passed through venous system to RV of heart
Moved towards heart
via contrast injection, & a balloon catheter is inflated to temporarily block the septal artery
“Septal Artery” = Coronary Art
6. causing the muscles cells in that area to shrink or die
7. From septal artery
Refined:
--for localization area at risk of infarction
--
--10% of patients eventually need a permanent pacemaker
Top Left: To show where ablation should be performed.
Bottom Right: septal ablation procedure for symptomatic HOCM patient
A) Angio sequence: first major septal perforator (connector of deep + superficial vessel) artery with 2 sub-branches (black arrows) as the target vessels for procedure. The long white arrow indicated the temporary pacemaker, while the shorter white arrow indicated the pigtail catheter in LV, with the balloon at the proximal part of the septal perforator
B) distal vessel of the 2 sub-branches with angioplasty
C) Balloon is advanced super-selective into left/basal sub branch
Corresponding Echo sequence:
D) dotted area circling target region of septum with SAM & subaortic obstruction
E) Test injection of echo contrast agent in balloon position of angio B picture (White arrows: highlighting the basal half of septum plus a RV papillary muscle)
F) After the super-selective balloon position of angio C picture, correct opacification of target region achieved
Super-selective angiography: smaller catheter passed through a larger one into a branch artery supplying a small area of tissue
--1980s: treating cardiac arrhythmias
--Variations of procedure have evolved over time
--No success with medications used to treat arrhythmias
--Had a serious side effect from arrhythmia medications
--- WCW: extra electrical pathway between Atria and Ventricles which causes a rapid heart beat (tachycardia)
--Affects people of all ages (11-50 years), including infants
--typically not life threatening but serious heart problems can occur
--from arrhythmias (cardiac arrest)
SVT:
---Due to an abnormal section of heart muscle that allows electricity to “loop”
---1 in 1,000 people
Small punctures are made in the groin, arm, or neck and a thin
4. such as radiofrequency energy (radio waves), cryothermy (intense cold), or laser energy (light waves) to create a lesion of scar tissue (conduction block), that stops the electrical signals from traveling through the heart
Catheter ablation procedure may be necessary to stop heart tissue from causing the arrhythmia.
Numbing small area of groin with a needle
Short, hollow tube in inserted in femoral vein called a catheter sheath
Long, flexible tube is inserted through the sheath
Catheter is guided to the heart through the IVC
5-6.Once catheter reaches heart, it is guided via 3D mapping to correction location of the arrhythmia area
7. Tip of the catheter will admit either hot or cold energy to ablate the tissue
8-9. If affected area is small: focal ablation used
Area is large + complex: ablation remodeling used
--Damage to vessels due to catheter scrapping it as it traveled to heart
--Damage to electrical system…worsening patient’s and require a pacemaker to correct
