Using PTC Creo Parametric and Flexible Modeling, an engineering company was able to reduce new project design time by 75% by more efficiently reusing existing design data. The document discusses how a leading LCD display manufacturer in Taiwan, AmTRAN Technology, purchased licenses for PTC Creo 3.0 and additional extensions after facing product development challenges. They aimed to achieve shorter mechanical design time, improved large assembly design processes, and a flexible design methodology. It also provides details on the sales win, including that AmTRAN had not allocated budget for CAD software in recent years but was shown how PTC Creo 3.0 could greatly improve design productivity. The $650K order included an upgrade to

1. 11
Using PTC Creo Parametric and Flexible Modeling we were able to more efficiently reuse our existing
design data to reduce new project design time by 75%.”
- Matthew Moore, Mechanical Engineer, VULKAN
Industry: Power Transmission Equipment Manufacturing
Region: USA
Products: PTC Creo
Company Description: Established in 1971, American
VULKAN Corporation (AVC) manufactures COUPLINGS, DRIVE TECH
and LOKRING products of the highest industrial quality standards.
Company Showcase − American Vulkan

2. 2
Business Challenges & Initiatives Sales Win Overview PTC Product Use
Located in Taiwan, AmTRAN Technology is a
leading company in the LCD display manufacture
industry.
• AmTRAN needed to address product
development Concept and Design
challenges.
• AmTRAN only had a small number of
licenses for PTC Creo Engineer I
package. They needed PTC Creo
Advanced Assembly Extension (AAX)
for copy geometry and engineering
change functionality.
• The positive business outcomes they
were looking to achieve included
shorter mechanical design time,
improved large assembly design
process, and flexible design
methodology.
Congratulations to the team that contributed to this win:
Sales: Daniel Hsiao
Technical Sales: Charlie Cho
Compliance: Judy Chen
• AmTRAN had not allocated budget for
CAD software in last two years, but we
were able to show AmTRAN that their
engineers would greatly improve their
design productivity by using PTC Creo
3.0.
• The $650K order included an upgrade
from PTC Creo 2.0 to PTC Creo 3.0.
They also purchased licenses of PTC
Creo Advanced Assembly Extension
(AAX) and PTC Creo Flexible Modeling
Extension (FMX).
• Key stakeholders at AmTRAN in the
buying process included the RD
Director (Technical Buyer) and IT
Manager (Coach).
PTC Creo 3.0 Win at AmTRAN Technology
• AmTRAN plans to use PTC Creo to
accommodate late stage design
changes, improve large assembly
design processes, and improve the
creation of highly engineered geometry.
• 80 individuals will use PTC Creo 3.0.

3. 3
3
Bandai uses direct modeling in a parametric environment to
solve design challenges
Bandai established its business in 1950 as a wholesaler of metal toys and other products. With
its major success in marketing “Kamen Rider Henshin Belt (Masked Rider Series
transformation belt)”, Bandai entered into full-scale character business, and now designs,
manufactures and markets toys as well as many other products, including plastic models, toy
snacks and sweets, toys in capsule, character cards, apparel, and household goods.
“The Boys Toy Department has never been afraid of
change and aggressively pursued 3D CAD systems
initiatives.” “PTC Creo has enabled us to make last-
minute changes quickly through the integration of
parametric and direct modeling approaches, leading
to reduced time to production and improved efficiency.
As a result, we are now able to spend more time on
engineering and improve the quality of our products.”
Takahiro Mizuno
General Manager, Boys Toy Department, Bandai
Reference: http://finance.yahoo.com/news/ptc-creo-brings-super-sentai-131500621.html
TOKUMEI SENTAI GO-BUSTERS
DX GO-BUSTER ACE
(C) 2012 TV ASAHI・TOEI AG・TOEI
*Reprint of this image is strictly prohibited.

4. 4
4
Bandai uses direct modeling in a parametric environment to
solve design challenges
S o l u t i o n
• PTC Creo upgrade from previous
Pro/ENGINEER implementation
• PTC Creo Flexible Modeling Extension
(FMX) for enabling late stage changes
• FMX for enabling a MultiCAD
environment with legacy and imported
designs
• Freestyle modeling for rapid concepting
of advanced 3D shapes
I n i t i a t i v e s
• Take advantage of both direct and
parametric design approaches
• Create 3D concepts directly in CAD tool
• Improve collaboration with overseas
factories and within group companies
.
R e s u l t s
• Increased design agility in development
process enabling last minute changes to
be recorded in parametric model
• Improved efficiency in product
development
• Reduced time to production
• More time available for engineering the
product
• Higher product quality
Bandai established its business in 1950 as a wholesaler of metal toys and other products. With
its major success in marketing “Kamen Rider Henshin Belt (Masked Rider Series
transformation belt)”, Bandai entered into full-scale character business, and now designs,
manufactures and markets toys as well as many other products, including plastic models, toy
snacks and sweets, toys in capsule, character cards, apparel, and household goods

5. 5
5
“PTC Creo allows me to quickly and easily make
variations on a part. When I have used other CAD
systems, similar design tasks have taken 2 1/2 times
as long. The ability to reuse that initial data is
priceless. It's a huge advantage.”
Nate Rollins
Owner
BearsFeat increased development of design options 2 ½
faster using PTC Creo
BearsFeat, Inc. is a independent mechanical engineering and design firm
utilizing the latest in product development and mechanical design technologies.
With over 20 years, their experience base spans many facets of the
mechanical design industry including machine design, tooling design, injection
molded plastics, product development, industrial design and analysis.

6. 6
6
BearsFeat increased development of design options 2 ½
faster using PTC Creo
I n i t i a t i v e s
• Create robust models for more
economical production
• Reduce revision cycles
• Accommodate customer needs
• Explore more design options
S o l u t i o n s
• Upgraded from Pro/ENGINEER
Wildfire 5.0 to PTC Creo
• PTC Creo offers tools that ensure
design quality and optimization
• Engineers that use PTC Creo tools can
make practical changes to native files
which speeds up development
• PTC Creo provides options for
modifying and reusing data
R e s u l t s
• Using PTC Creo reduced rework by
25% as more robust models move
downstream
• PTC Creo provides visibility within the
tool to identify missing references and
fix them
• Working with clients’ native files design
is easier and faster
• Created design options 2 ½ times
faster compared to similar work in other
CAD systems
BearsFeat, Inc. is a independent mechanical engineering and design firm
utilizing the latest in product development and mechanical design
technologies. With over 20 years, their experience base spans many facets of
the mechanical design industry including machine design, tooling design,
injection molded plastics, product development, industrial design and
analysis.

7. 7
7
Bowles Fluidics tests component designs years before first
physical prototypes using PTC Solutions
At Bowles Fluidics Corporation, the primary mission is to be a world-class
developer and manufacturer of fluid distribution products. For more than 50
years, the company has offered innovative products at low cost in both
automotive and non-automotive markets.
“Our automotive customers have development
cycles that last 4-5 years. But we can run digital
simulations with PTC Creo to evaluate our
windshield sprayers years before the first physical
prototype of a vehicle is available.”
Praveen Pai,
Lead designer
“Using PTC Creo Flexible Modeling Extension, we
anticipate a 35% drop in design iterations as we
work with customers.”
Austin Baird
Engineering Systems Administrator

8. 8
8
Bowles Fluidics tests component designs years before first
physical prototypes using PTC Solutions
S o l u t i o n s
• With PTC Creo Flexible Modeling
Extension, teams share new designs
and ideas in 3D, cutting
misunderstandings
• PTC Creo simulation tools support
digital “spray studies,” reducing the
number of late changes needed
• PTC Windchill manages &
synchronizes data for all locations,
connecting processes and geographies
• PTC Creo modules added as needed,
keeping costs down while scaling as
company grows
I n i t i a t i v e s
• Reduce design iterations when working
with customers
• Create accurate, testable digital
prototypes
• Streamline engineering change
notification process
• Accommodate growing business
R e s u l t s
• Using PTC Creo Flexible Modeling
Extension, Bowles anticipates 35% fewer
design iterations, both saving time and
inspiring customer confidence
• Engineers evaluate performance of
windshield sprayers, even at speeds of 60
mph, years before OEMs build physical
automobiles
• Plans to base Engineer Change Notice
process on PTC Windchill
• Bowles buys just the software it needs,
spending only ¼ the price of competing
vendors’ products for the same capabilities
At Bowles Fluidics Corporation, the primary mission is to be a world-class
developer and manufacturer of fluid distribution products. For more than 50
years, the company has offered innovative products at low cost in both
automotive and non-automotive markets.

9. 9
9
BRITAX has been a leader in mobile safety for more than 70 years, with a legacy
of leadership in developing innovations that enhance the safety of child car seats
and improve their ease of installation and use. BRITAX’s uncompromising focus
has made it the best-selling child car seat in Europe and one of the brands most
trusted by American parents and caregivers since entering the U.S. market in
1996.
“BRITAX recently made a strategic decision to
standardize on PTC Creo.
Our stroller line was previously designed using
SolidWorks, but after evaluating PTC Creo, it was a
‘no brainer’ to make the switch.
We are now leveraging PTC Creo for double-digit
performance gains in some areas of design.”
BRITAX Product Development Group
PTC Creo lets BRITAX speed concept development by
15%

10. 10
10
“Bringing a new medical device to market requires a great
deal of adjustments. Feedback from focus groups help us to
make the right design choices for the people that will use our
device. By using PTC Creo and PTC Creo Flexible Modeling
Extension, we can quickly and easily make changes that
save us days of design work as we develop new prototypes
that we then can test with the intended user or our product.
It’s rewarding when you’re designing devices that make a
difference in people’s lives. ”
Patrick McDermott,
Senior Product Design Engineer
CeQur quickly responds to user feedback and saves days of design work
using PTC Creo
CeQur® is dedicated to helping people with type 2 diabetes manage their
disease by developing and commercializing simple drug delivery devices that can
be easily integrated into daily life. The company’s lead product, PaQ ®, is a
wearable insulin delivery device that delivers both basal and bolus insulin for 3
days at a time.
PaQ - Simple, 3 day insulin delivery device

11. 11
11
CeQur quickly responds to user feedback and saves days of design work
using PTC Creo
I n i t i a t i v e s
• Ensure robust surfacing on designs for
reliable manufacturing
• Speed up prototyping
• Respond quickly to tester feedback to
create highly usable product
• Maximize performance of teams
working on PaQ product
• Spend less time preparing for design
reviews
S o l u t i o n s
• Migrated from Pro/ENGINEER Wildfire
4.0 to PTC Creo
• PTC Creo’s surfacing features prevent
errors downstream
• PTC Creo Flexible Modeling Extension
supports quick changes of last-minute
design work
• Lightweight graphic versions of parts
and assemblies can be selected for
faster download
• Cross-sectioning features eliminate
need for preparing 2D slides of key
areas
R e s u l t s
• Productivity improved 40% in surfacing
activities
• Exploring new designs by modifying
existing models and “pulling and
stretching” concepts into new geometry
save days of work
• Downloading and working with models
is 25% faster
• 40% of time saved preparing for design
reviews
CeQur® is dedicated to helping people with type 2 diabetes manage their
disease by developing and commercializing simple drug delivery devices that can
be easily integrated into daily life. The company’s lead product, PaQ ®, is a
wearable insulin delivery device that delivers both basal and bolus insulin for 3
days at a time.

12. 12
“Time is of the essence when putting
together a design: by using PTC Creo
software we have achieved a time-gain of
25% already in cutting back lost time.”
Nico Marini,
Managing Director, Certum Engineering
Certum Engineering replaces Inventor and standardizes
fully on PTC products for automotive design.
Certum Engineering has its field of expertise
within the automotive industry. Designing
and engineering engine rooms, chassis,
integral structures, axle fixation structures,
steering systems, fuel systems, exhaust
systems,…’complete’ vehicles.

13. 13
I n i t i a t i v e s R e s u l t s
• Improved working with large
assemblies and its performance
by 25%
• Improved working with Steel and
Aluminum frames by 50%
• Data can flow seamlessly within
the company
• Less failures and errors within
the design process through data
management
S o l u t i o n
A fully integrated package of PTC
Creo and PTC Windchill products:
• PTC Creo Essentials Package
which contains PTC Creo
Parametric and the Flexible
Modeling Extension
• Extensions: Advanced
Assembly Design, Advanced
Framework Design,
Mechanism Dynamics Option.
• Data Management:
PDMEssentials
• While working with PTC
Creo Parametric, Certum got
convinced of the PTC Creo
solution
• Reduce product
development cost,
production cost and improve
product quality
When working with a lot of different suppliers
CAD data is not always native. There are no
struggles with PTC software when dealing
with large assemblies. Even with imported
CAD data.
Certum Engineering replaces Inventor and standardizes
fully on PTC products for automotive design.

14. 1414
We get a lot of IGES and STEP files from our customers. With the PTC Creo Flexible Modeling
Extension, we are now able to make design changes even faster.”
- Daniel Wang, R&D Vice General Manager, CHIH KANG
Industry: Manufacturing
Region: Taiwan
Products: PTC Creo Flexible Modeling Extension
Company Description: Chih Kang Material
Company is an OEM sheet metal fabricator based in Taiwan.
Established in 1995, Chih Kang specializes in sheet metal
fabrication. A strong competitor in the international market,
Chih Kang focuses on advanced sheet metal work.
Company Showcase − CHIH KANG

15. 1515
Implementing PTC Creo Flexible Modeling Extension reduced late stage design changes by 15%.”
- Bart Aerens, Managing Director, IMA
Industry: Machinery Design
Region: Belgium
Products: PTC Creo Flexible Modeling Extension
Company Description: IMA is a partner in machinery
design & engineering, construction, automation and maintenance,
where safety, sustainability and cost saving are the main goals for the
customers.
Company Showcase − IMA

16. 16
16
INFOPIA reduces manufacturing time by 30% using PTC
Creo
Infopia was founded in Korea in 1996 developing biosensor technology products including auto
chemical analyzers, blood glucose monitoring systems and HBA1C measuring systems. Infopia
has grown into a publically traded corporation exporting to over 60 countries worldwide. Infopia
continues to expand its technology and product line to include heart disease diagnostic kits,
cancer diagnosing, liver analyzers, and remote treatment systems.
“Using PTC Creo Flexible Modeling Extension we
reduced design times by 30% when working with
IGES and STEP files from other companies.”
Kim Min su
Senior researcher engineer

17. 17
17
S o l u t i o n
 Infopia adopted the PTC Creo
Essentials Package, which supports
the design process from the beginning
I n i t i a t i v e s
 Increase collaboration with other
companies using 2D CAD to reduce
problems with changing designs
R e s u l t s
 Reduced the development time due to
collaborative design
 Reduced time-to-design by 30%
 Reduced errors resulting from
changing of designs
 Increased customer’s satisfaction by
using 3D models
INFOPIA reduces manufacturing time by 30% using PTC
Creo
Infopia was initially founded in Korea in 1996 developing biosensor technology products
including auto chemical analyzers, blood glucose monitoring systems and HBA1C measuring
systems. Infopia has grown into a publically traded corporation exporting to over 60 countries
worldwide. Infopia continues to expand its technology and product line to include heart disease
diagnostic kits, cancer diagnosing, liver analyzers, and remote treatment systems.

18. 18
18
“PTC Creo helps us to deliver high quality, complex
products in a shorter time frame. Thanks to PTC
Creo we increased revenue by 50.000 € in 2013.
In the past, we used CATIA V5 but later have
moved to PTC Creo. We now have the capability
to easily collaborate with more customers and
deliver work 20% faster than ever before.”
Dirk Seibertz
Business Owner
Ingenieurdienste Seibertz
Ingenieurdienste Seibertz is an independent partner in the automotive
environment and engineers barrel heads and tooling equipment. Main customers
can be found amongst the suppliers of VW and other OEMs.
Ingenieurdienste Seibertz increased revenue by 50.000 €
using
PTC Creo
Ingenieurdienste Seibertz

19. 19
19
S o l u t i o nI n i t i a t i v e s R e s u l t s
Ingenieurdienste Seibertz increased revenue by 50.000 €
using
PTC Creo
• Expand the company‘s footprint in the
automotive industry
• Eliminate difficulty in recognizing and
changing patterns automatically
• Engineer complex products for the target
market
• Address collaboration needs with
customers
• PTC Creo helps Ingenieurdienste
Seibertz to meet customer expectations
regarding quality
• PTC Creo Flexible Modeling Extension
helps to solve the challenge of changes
of patterns
• PTC Creo is efficiently used for concept
design and development of products
using parametric models
• High customer satisfaction through
increased quality
• Using PTC Creo Flexible Modeling
Extension, Seibertz can now make
faster changes to geometry and avoid
reverse engineering the model resulting
in 20% time savings
• Increased revenue by 50.000 € in 2013
compared to 2012
Ingenieurdienste Seibertz
Ingenieurdienste Seibertz is an independent partner in the automotive
environment and engineers barrel heads and tooling equipment. Main customers
can be found amongst the suppliers of VW and other OEMs.

20. 20
20
“As we work with multiple groups, we have to
incorporate CAD data from multiple CAD systems.
With PTC Creo, we can read and modify those files
directly in our system, and it’s definitely a quicker
approach.
Many of the features that come with PTC Creo save
Intel time and money.
For example, use of lightweight graphics reduce the
time it takes to work with large assemblies from
minutes to seconds.”
Glen Hanna,
System Platform Architect, Intel
Intel Cuts Task Time Up To 17x With PTC Creo
Intel is a world leader in computing innovation. The company designs and builds
the essential technologies that serve as the foundation for the world’s computing
devices.

21. 21
21
Jandia Engineering Reduced New Product Lead Time by
30% Using PTC Creo
Jandia Engineering is a subsidiary of Fein Power tool. They are an offshore CAD
drawing, drafting, designing and conversion BPO service provider from India. They
specialize in providing Mechanical Engineering CAD outsourcing services.
“Jandia is able to support new product
development with increased quality and
reduced cost by 30% using PTC Creo.”
B.T. Vijayakumar,
Managing Director

22. 22
22
Solution
• Jandia Engineering upgraded from
Pro/ENGINEER Wildfire 4.0 to PTC
Creo
• PTC Creo Flexible Modeling
Extension is used to manage late
stage design changes and reduce
errors
Initiatives
• Jandia needed a design software to help
the team develop and deliver new
products with less lead time and higher
quality
• Reduce manufacturing cost by digital
prototyping
• Standardize CAD platform across global
design groups
Results
• New product development lead time
has been reduced by 30%
• Manufacturing cost have been
reduced by 30% through use of digital
mock ups
• Improved communication across the
global design groups
• Large assembly management time
reduced by 15%
Jandia Engineering is a subsidiary of Fein Power tool. They are an offshore CAD
drawing, drafting, designing and conversion BPO service provider from India. They
specialize in providing Mechanical Engineering CAD outsourcing services.
Jandia Engineering Reduced New Product Lead Time by
30% Using PTC Creo

23. 23
JB-Konstruktion supports customers in all stages throughout the
entire development chain in tool making. With years of experience
and industry knowledge, use of modern development tools and
innovative solution concepts the design specialist is a partner of
choice for the plastics processing industry. JB-Konstruktion
specializes in plastic-compatible (re)design of injection molded parts
to developing and optimizing complete mold assemblies.
“Using PTC Creo Flexible Modeling Extension (FMX)
allows us to easily relocate a dome, remove radii or
add drafts. The ability of directly modeling 3rd party or
parametric parts has really improved our work.
Sometimes we're up to 90% faster; just a few parts
and FMX has paid off.“
“We are still exploring the full potential of parametric
design within an associative development chain from
part to tool assembly with PTC Creo: replace or
modify the reference part, regenerate and done!“
Jürgen Brichta
CEO, JB-Konstruktion
JB-Konstruktion benefits from a 90% time savings in tool and mold
design using PTC Creo

24. 24
S o l u t i o n
• Upgraded from Pro/ENGINEER
Wildfire 5.0 to PTC Creo
• PTC Creo Flexible Modeling
Extension is used for direct
modeling of parametric geometry
and easily opens 3rd party data
• PTC Creo Complete Mold Design
Extension is used for specialized
mold assemblies
• Easy to use interface
I n i t i a t i v e s
• Include direct modeling for
redesigning, quick geometry
modification for tool design, change
management, and variant design
• Need bidirectional data interchange
with customer CAD systems without
rework
• Take advantage of a parametric
development environment with
integrated, fully associative mold
features especially for multiple usage
of tools/molds and variants
• Increase CAD user productivity
through faster handling via the new
interface
R e s u l t s
• Up to 90% time savings when
redesigning products through direct
modeling using PTC Creo Flexible
Modeling Extension
• 50% faster at modification and
variant design in mold construction
with PTC Creo Complete Mold
Design Extension
• Tools and molds designed with PTC
Creo are 100% accurate
• Significantly less mouse interaction
and faster access via the new user
interface
JB-Konstruktion benefits from a 90% time savings in tool and mold
design using PTC Creo
JB-Konstruktion supports customers in all stages throughout the entire
development chain in tool making. With years of experience and
industry knowledge, use of modern development tools and innovative
solution concepts the design specialist is a partner of choice for the
plastics processing industry. JB-Konstruktion specializes in plastic-
compatible (re)design of injection molded parts to developing and
optimizing complete mold assemblies.

25. 25
25
K’NEX reduces concept development time by 50% with PTC
Creo
K'NEX Brands, L.P. headquarters and manufacturing facility is located in Hatfield,
Pennsylvania. K'NEX Brands, the world’s most innovative construction toy
company, was established to make and sell what has become one of the world’s
leading integrated construction systems for children, and is America’s STEM
building solution.
“With PTC Creo we can rapidly model and prototype
pieces that were critical to constructing the Atomic
Coaster. Functions that took 6 hours now take 3
hours. PTC Creo Flexible Modeling Extension (FMX)
allows engineers to easily select and edit a range of
geometry and features.
PTC Creo features made creating instructions for the
1000+ piece K’NEX Atomic Coaster a snap, and the
new user interface is great.”
Michael Klitsch,
Senior Designer
Lincoln Logs®*
*Licensed by Hasbro
K’NEX Atomic Coaster

26. 26
26
K’NEX reduces concept development time by 50% with PTC
Creo
S o l u t i o n
• PTC Creo enables engineers to create
multiple design iterations before
prototyping
• The Freestyle capability allows us to
freeform shapes and surfaces quickly
• PTC Creo Flexible Modeling Extension
(FMX) allows engineers to easily select
and edit a range of geometry and
features
• Functionality in PTC Creo allows us to
create instructions for toys
I n i t i a t i v e s
• Reduce product design time and
increase productivity to improve time to
market
• Maintain development of high quality
toys and reduce errors
• Select and standardize on a single
product solution across the company for
designing and managing projects
R e s u l t s
• Eliminated two design iterations and
reduced concept development time by
50%
• PTC Creo helps to develop 1,000 parts
in the Atomic Coaster accurately to
maintain surface quality and product
safety
• Evaluated SolidWorks and determined
PTC was the best solution and easy for
new engineers to learn. All Design
Engineers are using PTC Creo
K'NEX Brands, L.P. headquarters and manufacturing facility is located in Hatfield,
Pennsylvania. K'NEX Brands, the world’s most innovative construction toy
company, was established to make and sell what has become one of the world’s
leading integrated construction systems for children, and is America’s STEM
building solution.

27. 27
“PTC Creo helped us speed up the
product development process with its
variant design functions.
The Creo Flexible Modeling Extension
helps us to handle IGES and STEP file
that we receive from our customers
models.
We’ve been able to cut our development
time by 20%.”
Chadwick Lai, Section Manager, Optic
Technology Department
PixArt Accelerates Product Development by 20%
with PTC Creo
Founded in 1998, PixArt Technologies is a
leading global provider of CMOS image
sensors. PixArt has extensive experience in
analog IC, image sensor IC designing, and
image-processing algorithm IC design.

28. 28
S o l u t i o n
• PTC Creo enables concurrent
engineering which speed up the
product development process
• Engineers can easily modify
IGES/STEP files with PTC Creo
Flexible Modeling Extension (FMX)
I n i t i a t i v e s
• Integrated optical design with
mechanical engineering
• Improve editing of IGES/STEP files
R e s u l t s
• Accelerated the entire product
development process by 20%
• PixArt is able to quickly respond to
customer requests
• Mechanical Engineers get involved
in the product development process
earlier, saving time and rework
Founded in 1998, PixArt Technologies is a leading
global provider of CMOS image sensors. PixArt
has extensive experience in analog IC, image
sensor IC designing, and image-processing
algorithm IC design.
PixArt Accelerates Product Development by 20%
with PTC Creo

29. 29
29
Playmobil Creates Assembly Instructions 50% Faster
with PTC Creo
geobra Brandstätter GmbH & Co.KG is the producer of PLAYMOBIL® and
Germany´s largest toy manufacturer. Since its inception in 1974,
PLAYMOBIL® has produced over 2.7 billion PLAYMOBIL® figures for children
worldwide.
“With PTC Creo we have a streamlined solution for
the product development process, from concept
design to manufacturing.
Plus, PTC Creo enables us to create assembly
instructions for the online catalogue 50% faster.”
Christian Winter
Playmobil – R&D

30. 30
30
S o l u t i o n
• Use PTC Creo for the entire product
development process
• Use PTC Creo’s concept design tools
such as PTC Creo Freestyle for concept
design
• Easily share concept design details
with manufacturing for prototypes using
PTC Creo
• Use PTC Creo Flexible modeling for
late state direct and parametric
modeling changes
• Use PTC Creo for assembly
instructions
I n i t i a t i v e s
• Use one solution for the product
development process instead of
disparate systems
• Design product concepts in 3D CAD
software instead of by hand
• Integrate prototype and manufacturing
details in concept designs for 3rd party
manufacturers
• Integrate technical documentations and
illustrations
R e s u l t s
• Streamlined the overall product
development process from concept
design to manufacturing with PTC Creo
• Reduced the overall process time 25%
by integrating manufacturing details in
the product concept designs
• Created assembly instructions for the
online catalogue 50% faster
Playmobil Creates Assembly Instructions 50% Faster
with PTC Creo
geobra Brandstätter GmbH & Co.KG is the producer of PLAYMOBIL® and
Germany´s largest toy manufacturer. Since its inception in 1974,
PLAYMOBIL® has produced over 2.7 billion PLAYMOBIL® figures for children
worldwide.

31. 3131
PTC Creo Parametric has enabled us to reduce our design time by approximately 20 – 30 %. We can make
radical design changes much faster.”
- Mr. Girish Kathuria , Chief Operating Officer & Head Engg.
Company Showcase − Sanrok
Industry: Railway Component Manufacturer
Region: India
Products: PTC Creo Parametric, PTC Creo Flexible Modeling
Extension, PTC Creo Intelligent Fastener Extension
Company Description: Sanrok, an ISO 9001-2000 certified
firm, is a leader in providing rail freight operators and car builders
with innovative engineering products, services and solutions.
Trackwork products include long life rail pads and rail fastening
systems, rail anchors, air brake hose couplings, brake cylinders and
other track accessories.

32. 3232
PTC Creo improved our design process. Not only is PTC Creo Flexible Modeling invaluable for working
with late stage changes, but it ultimately reduced our design time by almost 30%. Plus, it has helped us
to design more efficiently and share data faster between different processes and departments.”
- Michael Lee, CIO, SANYO
Industry: Consumer Electronics
Region: Taiwan
Products: PTC Creo Flexible Modeling
Company Description: Sanyo Electric (Taiwan)
Co., Ltd. primarily manufactures and distributes household
electrical appliances in addition to wireless products and
small household electrical appliances.
Company Showcase − SANYO

33. 33
33
“PTC Creo gives me the ability to create libraries
and, as they grow, the tools within PTC Creo
scalesand make creating new assemblies easier
I model my customers files and increase their
libraries. The best feature of PTC Creo is the ability
to upload and streamline models from other CAD
systems without errors. This saves me a
tremendous amount of time.”
Robert Antonelli
CEO and Founder
SEPCON Solutions
SEPCON saves over 10 hours a week using PTC Creo
SEPCON provides engineering solutions and strategies which deliver long term benefits, based
upon our clients key business requirements. The strategies involved are economical, efficient,
durable, flexible and allow the organization to respond rapidly to both market and customer needs.

34. 34
34
S o l u t i o n
• PTC Creo Flexible Modeling Extension
is used to manage changes and
reduce errors
• Multi-CAD functionality and PTC Creo’s
ease of use make it simple to upload
CAD files and STEP files with no re-
work or errors, including 2D files
• PTC Creo provides the ability to view a
part in 3D and easily confirm design
intent
I n i t i a t i v e s
• Supply a high quality on-call systems
engineering process solution to
develop highly technical products
• Easily import data and modify imported
files from other CAD systems including
STEP files
• Increase the part libraries of our
customers files and create new
assembly configurations
R e s u l t s
• PTC Creo delivers a time savings of a
minimum of 10 hours per week
• SEPCON has more time to service
customers quickly and accurately resulting
from the 40% savings in overall time
• PTC Creo provides the ability to upload
and streamline models from other CAD
systems without errors
• SEPCON eliminated the need to remodel
parts/files from 2D into 3D saving the team
80 hours in total per project
SEPCON provides engineering solutions and strategies which deliver long term
benefits, based upon our clients key business requirements. The strategies
involved are economical, efficient, durable, flexible and allow the organization to
respond rapidly to both market and customer needs.
SEPCON saves over 10 hours a week using PTC Creo

35. 35
35
Specialized Bicycle Components is the global leader in the designing and
manufacturing of high performing technologically advanced bicycles, components
and cycling apparel for world champion riders and cycling enthusiasts. Founded
in 1974 and headquartered in Morgan Hill, CA. Specialized is a global company
with offices throughout the world.
“We leverage a team of engineers and industrial
designers to bring a much more complex bike to
market.
PTC Creo has allowed us to boost productivity by
about 20 - 30% and foster more creativity.
Late stage design changes allow model changes in
2-3 hours, compared to a process that previously
took 2-3 days.”
Ross Galson
CAD Administrator
Specialized Boosts Productivity by 20-30% with PTC
Creo

36. 36
36
“PTC Creo Parametric is our main CAD tool for
designing and engineering from concept to end
product. Not only does it have excellent modelling and
visualization performance, it also has a good interface
to other CAD products.
Its fast and accurate performance allows us to turn our
customers’ dreams into a reality.”
Dirk Van de Weyer,
Managing Director, SpinCED
SpinCED Cuts Time Spent on Design Changes by 30% with
PTC Creo Parametric
SpinCED is a product and engineering design company that
specializes in vehicle and equipment design. Their services include
industrial design, detailed engineering, prototyping and
manufacturing as well as engineering services.

37. 37
37
I n i t i a t i v e s R e s u l t s
• With PTC Flexible Modeling Extension,
changes that used to take hours took a
fraction of the time
- Design changes were completed
30% faster using Flexible Modeling
Extension
• Faster design changes enabled greater
collaboration with customers
• Engineers spent more time on optimizing
concepts and less time on detailed design
work
S o l u t i o n
• Upgrade to PTC Creo
• Implement PTC Flexible Modeling
Extension (FMX) to:
- Make fast, easy changes to
parametric geometry regardless of
design intent
- Eliminate wasted time spent
rebuilding geometry to implement
change
• Reduce product development cost
• Reduce production cost
• Improve product quality
SpinCED Cuts Time Spent on Design Changes by 30% with PTC Creo
Parametric
SpinCED provides engineering design services including industrial
design, detailed engineering and prototyping as well as special CAD
services. They have a strong focus on vehicle and equipment
design.

38. 3838
We needed to integrate the ideas from multiple disciplines into one digital design. PTC Creo’s
Unite Technology allowed us to seamlessly incorporate CAD files from numerous sources, which
made it possible for us to accept changes from suppliers or re-purpose the data ourselves.”
- John Margicin, Associate Member Technical Staff, SRI International
Industry: High Technology
Region: Princeton, NJ
Products: PTC Creo 3.0 Unite and Flexible Modeling
Company Description: SRI International is a nonprofit, independent
research center serving government and industry. SRI moves R&D from the
laboratory to the marketplace to create high value and real innovation. Our
research and innovations have led to new industries and products that impact
people’s lives every day—from the computer mouse and interactive
computing to medical ultrasound, cancer drugs, and much more.
Company Showcase − SRI International
IOM RapID-Cam™ II
Handheld Biometric System
IOM PassPort™ SL
Walk-Through Biometric System

39. 39
39
Stettler Improves Design Collaboration with PTC Creo
Stettler Kunststofftechnik specializes in the manufacturing of complex high-tolerance, high-
quality polymer components. Stettler has 90 employees and has world-class clients including
Bosch, Delphi, ZF, and Cherry
“Our customers send us CATIA or Unigraphics models. With
the flexible modeling capabilities, we can modify those models
for our needs when creating the molds. There’s lots of
changes we make. PTC Creo is very good in working on
models from other CAD tools and formats.”
Karsten Dempert
Product development
Stettler Kunststofftechnik

40. 40
40
“PTC Creo is a powerful and stable design platform, it
can meet all requirements of our product design
process. After PTC Creo adopted by Shanghai Yuan
Zhao company, We changed the existing design
method. It doesn’t bring us the pain due to design tool
change, but to speed up the efficiency of our design
and shorten the design cycle. We can reuse the
legacy data effectively in PTC Creo environment.”
Wei Guo Wang,
Supervisor of R&D
Tengen selects PTC Creo as a unified design platform
Tengen Group Co., Ltd. is one of the largest scale enterprises of industrial
equipment. Its general headquarters lies in "China Electric Appliance Capital",
Liushi, Wenzhou. It has successively won honorary titles such as national large-
scale enterprise, national level enterprise, China's electric top 100 enterprise,
China mechanical top 100 enterprise, and China's top 100 manufacturer. The
product quality of Tengen Group has been strictly controlled in each working
procedure, and many kinds of internationalization standard quality guaranteed
systems can be highly effective under the company's strict monitoring.

41. 41
41
S o l u t i o n
• PTC Creo was adopted as unified design
platform. The successful realization of 3D
design association with 2D drawing in a
single design platform.
• The successful application of PTC Creo
Flexible Modeling Extension method,
realize the fast design change in late stage.
And reuse and edit the different format
legacy date efficiently.
• Leverage PTC e-Learning system to
consolidate and strengthen the Creo
adoption.
I n i t i a t i v e s
• To share 3D design data in all
departments. There were several 3D
design software tools to be used. It is
difficult to share design data between
different departments.
• To select a unified 3D design platform,
in order to associate 3D design and 2D
drawing. Reduce to regenerate 2D
drawing after 3D design change.
• Fast design change in late stage.
• Reuse the legacy data efficiently.
R e s u l t s
• PTC Creo is unified design platform of
Tengen. Eliminate data exchange in whole
process of product development. Shorten
the design cycle.
• The successful realization of 3D design
association with 2D drawing in PTC Creo.
reduced the previous design changes
brought by the 2D to figure out the waste of
time, reducing the error rate, improve the
efficiency of design.
• Modify the design of fast and efficient
response to customer needs in the late
stage, improve customer satisfaction.
Tengen selects PTC Creo as a unified design platform
Tengen Group Co., Ltd. is one of the largest scale enterprises of industrial
equipment. Its general headquarters lies in "China Electric Appliance Capital",
Liushi, Wenzhou. It has successively won honorary titles such as national large-
scale enterprise, national level enterprise, China's electric top 100 enterprise,
China mechanical top 100 enterprise, and China's top 100 manufacturer. The
product quality of Tengen Group has been strictly controlled in each working
procedure, and many kinds of internationalization standard quality guaranteed
systems can be highly effective under the company's strict monitoring.

42. 42
42
“The most recent version of PTC Creo includes enhanced
capabilities that have helped us improve our mold design
efficiency.
Using a PTC University consultant, we delivered informative
training to the team, which resulted in faster adoption.”
Shen yang Liao
Manager of Mold Design department
PTC Creo Improves TONTEC’s Mold Design Efficiency Up to 15%
Tontec International, Ltd. offers mold design, tooling, and molding services and is
equipped with sophisticated manufacturing and assembly facilities. It has one of the most
advanced factories of its kind in mainland China. Tontec's expertise spans plastic
injection molding, metal stamping, mold and die making, silk-screen and pad printing,
spray painting, and assembly.

43. 43
43
S o l u t i o n
• Upgraded from Pro/ENGINEER Wildfire 4.0 to
PTC Creo for improved mold design features
• Move from PTC Windchill PDMLink 9.1 to PTC
Windchill PDMLink 10.1 to optimize the PDM
system for client applications
• Use PTC Creo View Lite for collaboration with
casual users
• Work easily with client and vendor data using
PTC Creo Flexible Modeling Extension
• Enlist PTC e-Learning to ensure reinstallation
and reconfiguration run smoothly
I n i t i a t i v e s
• Improve efficiency and retain
compatibility with PDM and client
software environments
• Establish a stable PDM system to
manage enormous volume of design
data
• Improve mold quality and
performance
• Reduce mold development cost
R e s u l t s
• Mold design efficiency improved up to 15%
• Design rework reduced by up to 30%
• Existing design and third party data is easy
to edit
• Collaboration between all departments
and partners is improved by 25%
• PTC University consultant delivered
informative training to the team, which
resulted in faster adoption
PTC Creo Improves TONTEC’s Mold Design Efficiency Up to 15%
Tontec International, Ltd. offers mold design, tooling, and molding services and is
equipped with sophisticated manufacturing and assembly facilities. It has one of the most
advanced factories of its kind in mainland China. Tontec's expertise spans plastic
injection molding, metal stamping, mold and die making, silk-screen and pad printing,
spray painting, and assembly.
