This document presents a study on using a fuzzy logic controlled D-STATCOM (distributed static compensator) to improve power quality in a power distribution system. A D-STATCOM equipped with an LCL passive filter is modeled and connected in parallel to an 11kV distribution system. Fuzzy logic control is implemented to regulate the D-STATCOM's reactive power injection and compensate for voltage sags and total harmonic distortion. Simulation results show the D-STATCOM improves the voltage profile under different fault conditions and reduces current THD from 43.43% to 0.73% when the LCL filter is used. The paper concludes the D-STATCOM effectively mitigates voltage sags and enhances power quality in the distribution
