The document describes the use of active power filters to improve power quality by compensating for harmonics and reactive power required by nonlinear loads. It discusses shunt active power filters, which compensate for harmonic currents, and series active power filters, which compensate for voltage harmonics. The key points are:
1) Shunt active power filters inject harmonic currents to cancel out load current harmonics and maintain the DC link voltage. Series active power filters inject a compensating voltage to cancel out supply voltage harmonics.
2) Reference compensation currents/voltages are estimated using techniques like Fast Fourier Transform and p-q theory.
3) Unified Power Quality Conditioners (UPQC) consist of back-to-
