OpenGL ES is a 3D graphics API targeted at embedded and mobile devices. It was created by removing redundancy from OpenGL and focusing on the most useful techniques, like using only vertex arrays instead of immediate mode and display lists. OpenGL ES is designed to be compatible with OpenGL to allow porting between desktop and embedded. New features were also introduced, like precision qualifiers, to improve performance on constrained devices. Major versions include OpenGL ES 1.0-1.1 and OpenGL ES 2.0, which uses a fully programmable pipeline instead of fixed-function rendering. It is widely used on Android, iOS, Blackberry, web platforms and more. Samples are provided to help learn the API.

1. OpenGL ES
ERIC CHENG CGGT
CIS 565 GPU PROGRAMMING
UNIVERSITY OF PENNSYLVANIA

2. OpenGL ES

3. What is OpenGL ES?
 OpenGL ES is an application programming interface
(API) for advanced 3D graphics targeted at handheld
and embedded devices such as cell phones, personal
digital assistants (PDAs), consoles, appliances,
vehicles, and avionics. OpenGL ES is one of a set of
APIs created by the Khronos Group. The Khronos
Group, founded in January 2000, is a member-
funded industry consortium that is focused on the
creation of open standard and royalty- free APIs for
handheld and embedded devices.

4. Features:
 The OpenGL API is very large and complex and the goal
of the OpenGL ES working group was to create an API
suitable for constrained devices. To achieve this goal, the
working group removed any redundancy from the
OpenGL API. In any case where there was more than one
way of performing the same operation, the most useful
method was taken and the redundant techniques were
removed. A good example of this is specifying geometry,
where in OpenGL an application can use immediate
mode, display lists, or vertex arrays. In OpenGL ES, only
vertex arrays exist and immediate mode and display lists
were removed.

5. Features
 Removing redundancy was an important goal, but
maintaining compatibility with OpenGL was also
important. As much as possible, OpenGL ES was
designed such that applications that were written to
the embedded subset of functionality in OpenGL
would also run on OpenGL ES. The reason this was
an important goal is it allows developers to leverage
both APIs and develop applications and tools that
use the common subset of functionality. Although
this was an important goal, there are cases where it
has deviated, especially with OpenGL ES 2.0.

6. Features
 New features were introduced to address specific
constraints of hand- held and embedded devices. For
example, to reduce the power consumption and
increase the performance of shaders, precision
qualifiers were introduced to the shading language.

7. OpenGL ES Versions
 Several versions of the OpenGL ES specification now
exist. OpenGL ES 1.0 is drawn up against the OpenGL 1.3
specification, OpenGL ES 1.1 is defined relative to the
OpenGL 1.5 specification and OpenGL ES 2.0 is defined
relative to the OpenGL 2.0 specification. This means
that, for example, an application written for OpenGL ES
1.0 should be easily portable to the desktop OpenGL 1.3;
as the OpenGL ES is a stripped-down version of the API
the reverse may or may not be true, depending on the
particular features used.
 Version 1.0 and 1.1 both have common and common lite
profiles, the difference being that the common lite profile
only supports fixed-point instead of floating point data
type support, whereas common supports both.

8. OpenGL ES 2.0
 OpenGL ES 2.0 was publicly released in March
2007.[2] It eliminates most of the fixed-function
rendering pipeline in favor of a programmable one.
Almost all rendering features of the transform and
lighting pipelines, such as the specification of
materials and light parameters formerly specified by
the fixed-function API, are replaced by shaders
written by the graphics programmer. As a result,
OpenGL ES 2.0 is not backward compatible with
OpenGL ES 1.1.

9. Usage
 OpenGL ES 1.0
 Official 3D graphics API of the operating systems Android[3] and
Symbian[4]
 Supported by the PlayStation 3 as one of official graphics APIs[5] (the other
one being low level libgcm library), the PlayStation 3 also includes several
features of OpenGL ES 2.0
 Supported by QNX[6]
 OpenGL ES 1.1
 Supported by Android 1.6
 Supported by iOS for iPad, iPhone, and iPod Touch
 Supported by the BlackBerry 5.0 operating system series,[7] however, only
BlackBerry Storm 2, BlackBerry Curve 8530 and later models have the
needed hardware[8]
 Supported for Palm webOS, using the Plug-in Development Kit[9]
 Supported by the Nintendo 3DS

10. Usage
 OpenGL ES 2.0
 Supported by the iPad, iPhone 3GS or later, and iPod Touch 3rd generation and
later
 Supported by the Android platform since Android 2.2[10]
 Supported by the Android platform NDK since Android 2.0[11]
 Support by BlackBerry devices with BlackBerry OS 7.0
 Supported by the BlackBerry PlayBook
 3D Library of the Pandora console
 Chosen for WebGL: OpenGL for web browsers[12]
 Supported by some new Nokia mobile phones, such as the Maemo based Nokia
N900[13] and the Symbian^3 based Nokia N8.
 Supported by various Samsung mobile phones, including the Galaxy S and Wave
 Supported for Palm webOS, using the Plug-in Development Kit[9]
 Supported by the Archos Internet tablets: Archos 70 IT, Archos 101 IT, Archos 80
G9, Archos 101 G9

11. Learn though Samples!
 Sample 1: Rotating Cubes
 Written by me based on Xcode template

12. Learn through Samples!
 Sample 2: Bump Mapping
 From iPhone 3D Programming

13. Learn through Samples!

14. Learn through Samples!

15. Q&A
THANK YOU!
