Logistic Regression

What Will You Learn Today?
What is Regression?
The 5 Questions
asked in Data Science
Logistic Regression – What
and Why?
How does Logistic
Regression work?
Demo In R: Diabetes
Use Case
1 2 3
4 65
Logistic Regression –
Use Cases

The 5 Questions Asked In Data
Science

The 5 Questions Asked In Data Science
In data science, basically we have 5 kind of problems.
Classification Algorithm
Anomaly Detection Algorithm
Regression Algorithms
Clustering Algorithms
Reinforcement Learning
Q1.
Q2.
Q4.
Q3.
Q5.
Is this A or B?
Is this weird?
How much or how many?
How is this organized?
What should I do next?

The 5 Questions Asked In Data Science
In data science, basically we have 5 kind of problems.
Q1.
Q2.
Q4.
Q3.
Q5.
Is this A or B?
Is this weird?
How is this organized?
What should I do next?
Classification Algorithm
Anomaly Detection Algorithm
Regression Algorithms
Clustering Algorithms
Reinforcement Learning
How much or how many?
Is this A or B?

What Is Regression?

What Is Regression?
➢ Regression analysis is a predictive
modelling technique.
➢ It estimates the relationship between
a dependent (target) and an
independent variable (predictor).
Input value = 7.00
Predicted outcome = 123.9
X-axis
Y-axis

Types Of Regression

Types Of Regression
Linear Regression
• When there is a linear
relationship between
independent and dependent
variables.
• When the dependent variable is
categorical (0/ 1, True/ False, Yes/
No, A/B/C) in nature.
Logistic Regression Polynomial Regression
• When the power of independent
variable is more than 1.
X
Y
X
Y

Why Logistic Regression?

Whenever the outcome of the dependent variable (Y) is discrete, like 0 or 1, Yes or No, A, B or C, we use
logistic regression.

Why can’t we use Linear Regression?
Why Not Linear Regression?
Whenever the outcome of the dependent variable (Y) is discrete, like 0 or 1, Yes or No, A, B or C, we use
logistic regression.

Y-axis
X-axis
0
1
Now since our value of Y will be between 0 and 1, the linear line has to be clipped at 0 and 1.

Y-axis
X-axis
0
1
With this, our resulting curve cannot be formulated into a single formula. We needed a new way to solve this kind of problem.
Hence, we came up with Logistic Regression!

0
0.2
0.4
0.6
0.8
1
1.2
0 1 2 3 4 5 6 7 8 9 10
LOGISTIC REGRESSION
The S Curve
Logistic Regression Curve

Equation for a straight line
Y = C + B1X1 + B2X2 + …. Range of Y is from – (infinity) to infinity

Let’s try to reduce the Logistic Regression Equation from this equation
Y = C + B1X1 + B2X2 + …. In Logistic Regression Y can only be between 0 and 1.

Y = C + B1X1 + B2X2 + …. In Logistic Equation Y can only be between 0 and 1.
Now, to get the range of Y between 0 and infinity, let’s transform Y
Y
1 − Y
Y=0 | 0
Y=1 | infinity
Now, we have the range between 0 and infinity

Y = C + B1X1 + B2X2 + …. In Logistic Equation Y can only be between 0 and 1.
Now, to get the range of Y between 0 and infinity, let’s transform Y
Y
1 − Y
Y=0 | 0
Y=1 | infinity
Now, we have the range between 0 and infinity
Let us transform it further, to get the range between –( infinity ) and infinity
Y
1 − Y
log
𝐘
𝟏 − 𝐘
log = C + B1X1 + B2X2 + ….

What Is Logistic Regression?

Logistic regression, or logit regression, or logit model is a regression model where the dependent variable (DV) is categorical.
DependentCategorical
Variables that can have only fixed values
such as A, B or C, Yes or No
Y = f(X)
i.e Y is dependent on X.

Therefore, whenever the outcome of the dependent variable (Y) is categorical, like 0 or 1, Yes or No, A, B or
C, we use logistic regression.
0.0
1.0

How Does Logistic Regression Work?

Let us take an example to understand this:
MODEL
Selected
147, 120, 121, 128, 110,
119, 133
Not Selected
107, 89, 92, 106, 104,
114
How does Logistic Regression Work?

Let’s take a sample dataset in R, which is called mtcars.
Our aim is to predict whether a car will have a V-engine or
a Straight engine based on our inputs.
Mpg - Miles/US Gallon
Cyl – Number of cylinders
Disp – Number of cylinders
Hp – Gross horsepower
Drat – Rear axle ratio
Wt – Weight (lb/1000)
Qsec – 1/4 mile time
Vs – V Engine
Am – Transmission Type
Gear – Number of forward gears
Carb - Number of carburetors
Key

For now, let’s take disp and wt as our primary
independent variables. Why? We’ll be discussing it in
our next section.
Vs – V Engine
Key

Since our aim is to know which engine will fit, the engine will
either be V – type or not, i.e either 1 or 0. Therefore, our
dependent variable is Y.
Vs – V Engine
Key

Before creating the model, we divide our dataset
into training and testing.
80 %
20%
Training Dataset
Testing Dataset

Training to create our model and testing to validate it.
80 %
Create model from this Training Dataset

Once the model is created we get the following
outputs, which are calculated using MLE*.
𝛽°
𝛽1
𝛽2
*Maximum Likelihood Estimation is a method of estimating the parameters.

Estimated Regression Equation
Estimated Regression Equation:
Here,
β° = Constant Coefficient
𝛽1 = Coefficient of x1
𝛽2 = Coefficient of x2
𝑥1 = Independent variable
𝑥2 = Independent variable
e = Euler’s Number
P(Y) = Probability that Y equals 1
𝑒
𝛽
°
+ 𝛽1 𝑥 1+ 𝛽2 𝑥 2
1 + 𝑒
𝛽
°
+ 𝛽1 𝑥 1+ 𝛽2 𝑥 2
Logit (Y) =
Y
1 − Y
log =

Substituting Values
Let’s take a value from the test dataset
0.9849
1.9849
= = 0.4962
β° = 1.83010
β1 = 1.09428
β2 = - 0.02529
e = 2.7183
X1 = 120.3
X2 = 2.140
= 0.4962Probability of ‘vs’ being ‘1’ We will assume the
threshold to be 0.5
Hence our car will not have a VS engine and hence have a straight engine.
Logit (Y)

Logistic Regression Demo In R

Key
Npreg – number of pregnancies
Glu – plasma glucose concentration
Bp – diastolic blood pressure
Skin – triceps skin fold thickness
Bmi – body mass index
Ped – diabetes pedigree function
Age – age in years
Type – 1 for yes and 0 for No for diabetic
Our aim is to predict whether a patient is diabetic or not based on the following values.

First, we will read the data from our CSV file, by entering this command:

Then, we will split our dataset into training and testing, with the ratio 8:2

Then, we will split our dataset into training and testing, with the ratio 8:2
After that we’ll create our model using the training dataset

The summary of the model will give this.

The summary of the model will give this.
*** - 99.9% confident
** - 99% confident
* - 95% confident
. - 90% confident

• This is the summary model that we get
after improving our model.
• So the insignificant fields is skin
Null deviance shows how
well the response variable
is predicted by a model
that includes only the
intercept (grand mean)
Residual deviance shows
how well the response
variable is predicted with
inclusion of independent
variables.

We will the predict the values for the test dataset and
then categorize them according to threshold which is 0.5

Create Confusion Matrix for the training dataset

And then finding the accuracy
Create Confusion Matrix for the training dataset

How To Find The Threshold?

Let us take a sample for our significant fields and see whether our patient is diabetic or not based on the model that we
created.
Store the predicted values for training
dataset in ‘res’ variable

created.
Import the library for the ROCR package

created.
Define the ‘ROCRPred’ and and ‘ROCRPerf’
variables

created.
Define the ‘ROCRPred’ and and ‘ROCRPerf’
variables
Plot the graph!

Confusion Matrix for Test Dataset with 0.5
threshold
threshold
Accuracy = 73.8%
TrueNegatives = 9
Accuracy = 67.8%
TrueNegatives = 5

threshold
threshold
Accuracy = 73.8%
TrueNegatives = 9
Accuracy = 67.8%
TrueNegatives = 5
Confusion Matrix for Training Dataset with
0.3 threshold
Accuracy = 79.4%

Logistic Regression: Use Cases

Logistic Regression – Use Case
• Logistic Regression was used in
conjugation with Geographic Information
system in 2005, to predict the malaria
breeding grounds in Africa.
• Logistic regression was used to
approximate areas where malaria patients
would exist based on geographical inputs.

Logistic Regression – Use Case
• Logit analysis is a statistical technique used
by marketers to assess the scope of customer
acceptance of a product, particularly a new product.
• It attempts to determine the intensity or magnitude of
customers' purchase intentions and translates that
into a measure of actual buying behavior.
• Many e-commerce websites assess this behavior using
this model.
