1. Circles
Mathematics 4
August 10, 2011
Mathematics 4 () Circles August 10, 2011 1 / 17

2. Review of Completing the Square
Completing the Square
Express the following quadratic expressions as (y − k) = a(x − h)2 .
Mathematics 4 () Circles August 10, 2011 2 / 17

3. Review of Completing the Square
Completing the Square
Express the following quadratic expressions as (y − k) = a(x − h)2 .
1 x2 − y − 12x + 7 = 0
Mathematics 4 () Circles August 10, 2011 2 / 17

4. Review of Completing the Square
Completing the Square
Express the following quadratic expressions as (y − k) = a(x − h)2 .
1 x2 − y − 12x + 7 = 0
→ (y + 29) = (x − 6)2
Mathematics 4 () Circles August 10, 2011 2 / 17

5. Review of Completing the Square
Completing the Square
Express the following quadratic expressions as (y − k) = a(x − h)2 .
1 x2 − y − 12x + 7 = 0
→ (y + 29) = (x − 6)2
2 2x2 − 5x − y − 3 = 0
Mathematics 4 () Circles August 10, 2011 2 / 17

6. Review of Completing the Square
Completing the Square
Express the following quadratic expressions as (y − k) = a(x − h)2 .
1 x2 − y − 12x + 7 = 0
→ (y + 29) = (x − 6)2
2 2x2 − 5x − y − 3 = 0
49
→y+ 8 = 2(x − 5 )2
4
Mathematics 4 () Circles August 10, 2011 2 / 17

7. Review of Completing the Square
Completing the Square
Express the following expressions as (x − h)2 + (y − k)2 = r, where h, k,
and r are constants.
Mathematics 4 () Circles August 10, 2011 3 / 17

8. Review of Completing the Square
Completing the Square
Express the following expressions as (x − h)2 + (y − k)2 = r, where h, k,
and r are constants.
1 x2 + y 2 + 2x − 8y + 4 = 0
Mathematics 4 () Circles August 10, 2011 3 / 17

9. Review of Completing the Square
Completing the Square
Express the following expressions as (x − h)2 + (y − k)2 = r, where h, k,
and r are constants.
1 x2 + y 2 + 2x − 8y + 4 = 0
→ (x + 1)2 + (y − 4)2 = 13
Mathematics 4 () Circles August 10, 2011 3 / 17

10. Review of Completing the Square
Completing the Square
Express the following expressions as (x − h)2 + (y − k)2 = r, where h, k,
and r are constants.
1 x2 + y 2 + 2x − 8y + 4 = 0
→ (x + 1)2 + (y − 4)2 = 13
2 9x2 + 9y 2 + 6x − 12y + 5 = 63
Mathematics 4 () Circles August 10, 2011 3 / 17

11. Review of Completing the Square
Completing the Square
Express the following expressions as (x − h)2 + (y − k)2 = r, where h, k,
and r are constants.
1 x2 + y 2 + 2x − 8y + 4 = 0
→ (x + 1)2 + (y − 4)2 = 13
2 9x2 + 9y 2 + 6x − 12y + 5 = 63
→ (x + 3 )2 + (y − 2 )2 = 7
1
3
Mathematics 4 () Circles August 10, 2011 3 / 17

12. Circles
What is a circle?
Mathematics 4 () Circles August 10, 2011 4 / 17

13. Circles
Definition of Circles
A circle is a set of all points (locus) that are the same distance from a
given point.
Mathematics 4 () Circles August 10, 2011 5 / 17

14. Circles
Definition of Circles
A circle is a set of all points (locus) that are the same distance from a
given point.
Terminology
Mathematics 4 () Circles August 10, 2011 5 / 17

15. Circles
Definition of Circles
A circle is a set of all points (locus) that are the same distance from a
given point.
Terminology
same distance → radius
Mathematics 4 () Circles August 10, 2011 5 / 17

16. Circles
Definition of Circles
A circle is a set of all points (locus) that are the same distance from a
given point.
Terminology
same distance → radius
given point → center
Mathematics 4 () Circles August 10, 2011 5 / 17

17. The Standard Form of the Circle Equation
The Distance Formula
The distance between two points (x1 , y1 ) and (x2 , y2 ) in the Cartesian
plane is given by:
d= (x2 − x1 )2 + (y2 − y1 )2
Mathematics 4 () Circles August 10, 2011 6 / 17

18. The Standard Form of the Circle Equation
The Distance Formula
Use the distance formula to relate the radius with the center of the circle.
r= (x − h)2 + (y − k)2 (1)
Mathematics 4 () Circles August 10, 2011 7 / 17

19. The Standard Form of the Circle Equation
Standard Form/Center-Radius Form
Given a circle with center at (h, k) and having a radius r, the center radius
form of the circle equation is given by:
(x − h)2 + (y − k)2 = r2
Mathematics 4 () Circles August 10, 2011 8 / 17

20. Graphing Examples
Graph x2 + y 2 = 10. Label center, radius, and any intercepts.
Mathematics 4 () Circles August 10, 2011 9 / 17

21. Graphing Examples
Graph x2 + y 2 = 10. Label center, radius, and any intercepts.
√ √
x-intercepts → 10, − 10
Mathematics 4 () Circles August 10, 2011 9 / 17

22. Graphing Examples
Graph x2 + y 2 = 10. Label center, radius, and any intercepts.
√√
x-intercepts → 10, − 10
√ √
y-intercepts → 10, − 10
Mathematics 4 () Circles August 10, 2011 9 / 17

23. Graphing Examples
Graph (x + 3)2 + (y − 2)2 = 9. Label center, radius, and any intercepts.
Mathematics 4 () Circles August 10, 2011 10 / 17

24. Graphing Examples
Graph (x + 3)2 + (y − 2)2 = 9. Label center, radius, and any intercepts.
√ √
x-intercepts → −3 + 5, −3 − 5
Mathematics 4 () Circles August 10, 2011 10 / 17

25. Graphing Examples
Graph (x + 3)2 + (y − 2)2 = 9. Label center, radius, and any intercepts.
√ √
x-intercepts → −3 + 5, −3 − 5
y-intercepts → 2
Mathematics 4 () Circles August 10, 2011 10 / 17

26. Problems on Circles
Example 1
What is the equation of a circle with radius 5, centered on the origin?
Graph this circle.
Mathematics 4 () Circles August 10, 2011 11 / 17

27. Problems on Circles
Example 1
What is the equation of a circle with radius 5, centered on the origin?
Graph this circle.
Mathematics 4 () Circles August 10, 2011 11 / 17

28. Problems on Circles
Example 1
What is the equation of a circle with radius 5, centered on the origin?
Graph this circle.
x2 + y 2 = 25
Mathematics 4 () Circles August 10, 2011 11 / 17

29. Problems on Circles
Example 1
What is the equation of a circle with radius 5, centered on the origin?
Graph this circle.
x2 + y 2 = 25
Mathematics 4 () Circles August 10, 2011 11 / 17

30. Problems on Circles
Example 2
Move the circle in the previous problem 3 units to the left and 2 units up.
What is its equation? Graph this circle and note the intercepts.
Mathematics 4 () Circles August 10, 2011 12 / 17

31. Problems on Circles
Example 2
Move the circle in the previous problem 3 units to the left and 2 units up.
What is its equation? Graph this circle and note the intercepts.
Mathematics 4 () Circles August 10, 2011 12 / 17

32. Problems on Circles
Example 2
Move the circle in the previous problem 3 units to the left and 2 units up.
What is its equation? Graph this circle and note the intercepts.
(x + 3)2 + (y − 2)2 = 25
Mathematics 4 () Circles August 10, 2011 12 / 17

33. Problems on Circles
Example 2
Move the circle in the previous problem 3 units to the left and 2 units up.
What is its equation? Graph this circle and note the intercepts.
(x + 3)2 + (y − 2)2 = 25
√
x-intercepts : −3 ± 21, y-intercepts: 6, −2
Mathematics 4 () Circles August 10, 2011 12 / 17

34. Problems on Circles
Example 3
Find an equation of a circle with a diameter whose endpoints are at
P1 (7, −3) and P2 (1, 7).
Mathematics 4 () Circles August 10, 2011 13 / 17

35. Problems on Circles
Example 3
Find an equation of a circle with a diameter whose endpoints are at
P1 (7, −3) and P2 (1, 7).
Mathematics 4 () Circles August 10, 2011 13 / 17

36. Problems on Circles
Example 3
Find an equation of a circle with a diameter whose endpoints are at
P1 (7, −3) and P2 (1, 7).
center: Use the midpoint formula
x1 + x2 y1 + y2
→ (h, k) = , = (4, 2)
2 2
Mathematics 4 () Circles August 10, 2011 13 / 17

37. Problems on Circles
Example 3
Find an equation of a circle with a diameter whose endpoints are at
P1 (7, −3) and P2 (1, 7).
center: Use the midpoint formula
x1 + x2 y1 + y2
→ (h, k) = , = (4, 2)
2 2
radius: Distance from one endpoint to the center
√
→ r = (x1 − h)2 + (y1 − k)2 = 34
Mathematics 4 () Circles August 10, 2011 13 / 17

38. Problems on Circles
Example 3
Find an equation of a circle with a diameter whose endpoints are at
P1 (7, −3) and P2 (1, 7).
center: Use the midpoint formula
x1 + x2 y1 + y2
→ (h, k) = , = (4, 2)
2 2
radius: Distance from one endpoint to the center
√
→ r = (x1 − h)2 + (y1 − k)2 = 34
(x − 4)2 + (y − 2)2 = 34
Mathematics 4 () Circles August 10, 2011 13 / 17

39. The General Form of the Circle Equation
Rewriting the answer to the previous problem:
(x − 4)2 + (y − 2)2 = 34
Mathematics 4 () Circles August 10, 2011 14 / 17

40. The General Form of the Circle Equation
Rewriting the answer to the previous problem:
(x − 4)2 + (y − 2)2 = 34 → x2 + y 2 − 8x − 4y − 14 = 0
This is called the General Form of the Circle Equation.
Mathematics 4 () Circles August 10, 2011 14 / 17

41. The General Form of the Circle Equation
The General Form of the Circle Equation
Ax2 + Ay 2 + Cx + Dy + E = 0
The x2 and y 2 terms should have identical coefficients.
Mathematics 4 () Circles August 10, 2011 15 / 17

42. Problems on Circles
Example 4
Find the center and radius of the circle with the equation
x2 + y 2 + 4x − 6y + 5 = 0.
Mathematics 4 () Circles August 10, 2011 16 / 17

43. Problems on Circles
Example 4
Find the center and radius of the circle with the equation
x2 + y 2 + 4x − 6y + 5 = 0.
(x2 + 4x) + (y 2 − 6y) = −5
Mathematics 4 () Circles August 10, 2011 16 / 17

44. Problems on Circles
Example 4
Find the center and radius of the circle with the equation
x2 + y 2 + 4x − 6y + 5 = 0.
(x2 + 4x) + (y 2 − 6y) = −5
(x2 + 4x+4) + (y 2 − 6y+9) = −5+4 + 9
Mathematics 4 () Circles August 10, 2011 16 / 17

45. Problems on Circles
Example 4
Find the center and radius of the circle with the equation
x2 + y 2 + 4x − 6y + 5 = 0.
(x2 + 4x) + (y 2 − 6y) = −5
(x2 + 4x+4) + (y 2 − 6y+9) = −5+4 + 9
(x + 2)2 + (y − 3)2 = 8
Mathematics 4 () Circles August 10, 2011 16 / 17

46. Problems on Circles
Example 4
Find the center and radius of the circle with the equation
x2 + y 2 + 4x − 6y + 5 = 0.
(x2 + 4x) + (y 2 − 6y) = −5
(x2 + 4x+4) + (y 2 − 6y+9) = −5+4 + 9
(x + 2)2 + (y − 3)2 = 8
Mathematics 4 () Circles August 10, 2011 16 / 17

47. Problems on Circles
Example 4
Find the center and radius of the circle with the equation
x2 + y 2 + 4x − 6y + 5 = 0.
(x2 + 4x) + (y 2 − 6y) = −5
(x2 + 4x+4) + (y 2 − 6y+9) = −5+4 + 9
(x + 2)2 + (y − 3)2 = 8
C(−2, 3)√
√
r= 8=2 2
Mathematics 4 () Circles August 10, 2011 16 / 17

48. Problems on Circles
More examples
Mathematics 4 () Circles August 10, 2011 17 / 17

49. Problems on Circles
More examples
1 Find the standard equation of a circle with center at (1, 5) and passes
through (7, 2).
Mathematics 4 () Circles August 10, 2011 17 / 17

50. Problems on Circles
More examples
1 Find the standard equation of a circle with center at (1, 5) and passes
through (7, 2).
2 Find the area of the circle with equation x2 + y 2 + 8x − 12y − 14.
Mathematics 4 () Circles August 10, 2011 17 / 17

51. Problems on Circles
More examples
1 Find the standard equation of a circle with center at (1, 5) and passes
through (7, 2).
2 Find the area of the circle with equation x2 + y 2 + 8x − 12y − 14.
3 Find the general equation of the circle tangent to both axes, whose
center is in QII, and whose radius is 4.
Mathematics 4 () Circles August 10, 2011 17 / 17
