The four principal types of bones are long, short, flat and irregular. Bones that are longer than they are wide are called long bones. They consist of a long shaft with two bulky ends or extremities.

1. Bones
&
Classification
27-07-2023 1

2. Objectives
• Skeleton
• Bone
• Microscopic structure
• Characteristics
• Classifications of bone
• Gross structure
• Epiphyses
• Blood supply
• MCQ
• Clinical Vignettes
• References
27-07-2023 2

3. Skeleton
Form a rigid frame work of body
Composed of :-
Bones
Cartilages
27-07-2023 3
Made up of specialised supporting
connective tissue called Sclerous
(skeletal) tissue

4. Types of Skeleton
27-07-2023 4

5. Axial skeleton
• Skull
• Ear ossicles
• Hyoid bone
• Sternum
• Vertebral
column
• Rib cage
27-07-2023 5

6. Appendicular
skeleton
• Bilaterally symmetrical
Comprises bone
• Upper limb and
• Lower limb
with bony girdles
27-07-2023 6

7. Bone
• Os (Latin)
• Osteon ( Greek)
Hard structure , form rigid framework of body
27-07-2023 7

8. Structurally
Highly vascular mineral connective tissue
• Specialized form of connective tissue
Distinguish feature from other connective tissues is
Mineralization of its matrix
Mineral is calcium phosphate hydroxyapatite crystals
[Ca10(PO4)6(OH)2].
27-07-2023 8

9. 27-07-2023 9

10. Microscopic Structure
• Cells
• Ground substance + fibre , form the extracellular
substance or matrix
27-07-2023 10

11. Bone Matrix
Organic (no calcified )
• Type 1 collagen
• Non mineralized ground
substance
1. Chondroitin sulfate
2. Keratin sulfate
• Provide resilience
Inorganic (calcified)
• Contain crystalline
mineral salt (calcium ,
phosphorus)
• Osteoid undergo
mineralization process
• Provide hardness and
rigidity
27-07-2023 11

12. Ground substance or Matrix
1. Mainly type I collagen and types III,XI,XIII collagens in
trace amount
Other matrix, (Noncollagenous)proteins that constitute
ground substance of bone.
• Proteoglycan macromolecules
• Multiadhesive glycoprotein's
• Bone-specific, vitamin K–dependent proteins
27-07-2023 12
Both collagen and ground substance become mineralized to form
bone tissue

13. Cells
Osteoproginator
cells
• Osteoblast
• Osteocytes
• Osteoclast
27-07-2023 13
Bone matrix contains lacunae connected by a
network of canaliculi

14. 27-07-2023 14

15. 27-07-2023 15

16. Characteristics
• Living tissue
• Highly vascular
• Serves as a storage site for calcium and
phosphate
• Supply by nerve and blood vessel
• Show pattern of growth
• Subjected to disease & heal after fracture
• Regenerative power
27-07-2023 16

17. Classification of bone
• According to shape
• According to structure
• According to development
27-07-2023 17

18. • Acc to shape of bone
27-07-2023 18

19. 1. Long bone
• Typical long bones
humerus, radius, ulna, femur, tibia, fibula;
• Miniature long bones have only one epiphysis
e.g. metacarpals, metatarsals and phalanges;
27-07-2023 19

20. 2. Short bones:
Shape is usually cuboid, cuneiform,
Trapezoid or scaphoid.
Examples: tarsal and carpal bones
27-07-2023 20

21. 3. Flat bones
Shallow plates
Form boundaries of body cavities.
Examples:
Vault of skull, ribs,
sternum & scapula
27-07-2023 21

22. 4. Sesamoid bone
Bony nodules found embedded in tendons or joint
capsules.
No periosteum and ossify after birth
Functions are:
(a) To resist pressure & friction
(c) To alter direction of pull of muscle
(d) To maintain local circulation.
27-07-2023 22

23. 5. Irregular bone
• Vertebrae
• Sacrum , coccyx
• Temporal , sphenoid, ethmoid, zygomatic,
maxilla, mandible, palatine, inferior nasal
concha,
• Hyoid
27-07-2023 23

24. 6. Pneumatic bone
Irregular bones contain large air spaces lined by epithelium
examples: maxilla, sphenoid, ethmoid.
Function:-
Make skull light in weight,
Help in resonance of voice,
Act as air conditioning chambers for inspired air
27-07-2023 24

25. 7. Accessory bone (supernumerary bone)
Not always present .
Developed from extra-centres of ossification.
Examples: Sutural bones, os trigonum
(lateral tubercle of talus),os vesalianum
(tuberosity of 5th metatarsal)
27-07-2023 25

26. Structural classification
Macroscopically,
• Compact bone
• Cancellous bone
27-07-2023 26

27. Compact bone consist of
• Lamella of collagenous sheet
• Haversian system or osteon
27-07-2023 27

28. Cancellous bone/ spongy bone
• Meshwork of bony spicules.
• Do not form haversian system
• Architecture of cancellous bone is depend upon
trajectory theory (Wolf’s law)
Pressure lamellae Tension lamellae
27-07-2023 28

29. 27-07-2023 29

30. 27-07-2023 30

31. Microscopically
Classification is based on arrangement of different
component in matrix are arranged
• Woven bone – Collagen fasiscle and bony crystal
arranged in mesh network, like woven fabric e.g, callus
bone , young fetal bone
• Lamellar bone- Mineralized matrix arranged in layer of
thin sheet e.g. All adult bone
27-07-2023 31

32. Woven bone lamellar bone
• Lamellar appearance - arrangement of collagen fibres
• Woven bone is weak- repair of fracture

33. 27-07-2023 33

34. Gross structure
27-07-2023 34

35. Epiphyses
• Type of epiphyses
27-07-2023 35

36. Blood Supply
Supplied by following 4 set of
Arteries
• Nutrient arteries
• Metaphyseal arteries
• Epiphyseal
• Periosteal arteries
27-07-2023 36

37. Developmental classification
• Membranous bones
• Cartilaginous bones
• Membrano- Cartilaginous bones
27-07-2023 37
Types of bones Examples
Membranous Bones of cranial vault
Facial bones
Cartilaginous Bone of limbs
Bones of base of skull
Bones of vertebral column
Bones of thoracic cage
Membrano-cartilagnous Mandible
Clavicle

38. Intramembranous Ossification
Develop from mesenchymal model
27-07-2023 38

39. 27-07-2023 39

40. Intra-cartilaginous Ossification
• Develop from cartilaginous ossification
27-07-2023 40

41. Intra-cartilaginous Ossification
27-07-2023 41

42. Clinical
• Paget’s disease
27-07-2023 42

43. MCQ
Mainly all bone in the body is made up of both
compact and spongy bone, except
a) Clavicle
b) Inferior nasal choncha
c) Patella
d) fabella
27-07-2023 43
a) Inferior nasal choncha

44. Name muscle in which fabella bone usually develop?
a) Lateral head of Gastrocnemius
b) Long head of biceps femoris
c) Popliteus
d) Adductor longus
27-07-2023 44
a) Lateral head of Gastrocnemius

45. Clinical Vignettes
A 7 year old boy come to an orthopaedics clinic, having a fever,
swelling and redness over knee, complain of fatigue and having a
history trauma few weeks ago. An X-ray reveal a lesion over tibia,
Doctor diagnose a osteomyelitic lesion.
Q Name the part of growing long bone commonly effected by
osteomyelitis?
27-07-2023 45
Ans Metaphysis

46. A 12 year old child born with a condition called
Cleidocranial dysostosis, as shown in image.
Q what type of development is shown by clavicle?
a) Cartilaginous development
b) Membranous development
c) Membrano – cartilaginous
27-07-2023 46
Membranous development

47. References
• Vishram Singh general anatomy e.2014
• Histology_ A Text and Atlas_ With Correlated
Cell and Molecular Biology, 6th Edition
• Keith L. Moore Clinically Oriented Anatomy,
Sixth Edition .
27-07-2023 47
