1. ACMV/ECS dari Wilianto
Requires4parts of engineering.
Mechanical twoparts
1. AirSide (Ong/ Arun)
1.1 Ductingsubcon
1.2 Install MV Fans
2. Water side (Ong/Arun)
2.1 PipingSubcon
2.1.1 ECS PlantRoom
2.1.2 Transmission
2.2 Install ACfieldequipment.
Electrical twoparts
3. SecondaryElectrical (Wilianto)
3.1 From MCC to fielddevices.
4. Control (DNR)
Authorityshouldbe involvedinInterface meetingtogive advisesandinputs.
Ducting
1. Internal Insulation.
2. External Insulation.
3. Fire RatedBoard.
4. AcousticBoard.
5. Dampersrequires partitionseitherhorizontalorvertical.
Piping
1. Valve Sets.
2. Flangesforjoining.
3. End Caps.
4. Flexible hose.
5. Y strainer@ supplierside forclearingchokes.
6. Vertical/Horizontal/Diagonal.
