A complete carburetor
•Download as PPT, PDF•
35 likes•23,915 views
A simple carburetor can only supply the correct air-fuel ratio at one throttle position. To address this, modern carburetors include additional systems like an idling system, auxiliary port system, power enrichment system, and accelerating pump system. These systems allow the carburetor to meet the engine's demands under different operating conditions like idling, cruising, acceleration, and high power.
