This document discusses integrating wind and solar power into a smart grid system using islanding operation. It presents a method for reducing voltage and frequency fluctuations in an AC smart grid during islanding by controlling photovoltaic power output and wind turbine pitch angle. The smart grid system consists of photovoltaics, a wind turbine generator, controllable loads, and an inverter. Simulation results show that by applying power control of the photovoltaics and varying the wind turbine's pitch angle, voltage and frequency deviations caused by renewable energy fluctuations can be suppressed, allowing stable power supply even during islanding operation.
