The document provides details on calculating earthwork volumes and costs for a road construction project based on a mass haul diagram (MHD). Key information from the MHD includes: - Freehaul distance of 600m and balance line at 400 cubic meters - Freehaul volume of 1500 cubic meters over 600m for a cost of RM9000 - Haul volume of 3075 cubic meters over 610m (average haul distance) for a cost of RM18,757.50 - Overhaul volume of 1575 cubic meters over 750m (average overhaul distance) for a cost of RM2362.50 Total estimated cost of earthwork is RM176,375.
More Related Content
What's hot
What's hot (20)
Viewers also liked
Viewers also liked (20)
Similar to Tutorial MHD
Similar to Tutorial MHD (20)
More from kmasz kamal
More from kmasz kamal (11)
Recently uploaded
Recently uploaded (20)
Tutorial MHD
- 1. MASS HAUL DIAGRAM tutorial 3 PREPARED BY : KMASZ
- 5. Cumulative volume m 3 Chainage ,m Draw a MHD using the scale below: X axis : 1 cm = 100 m Y axis: 1 cm = 250 m 3 X axis : 1 cm = 100 m Y axis: 1 cm = 250 m 3 STEP 1
- 7. Freehaul volume = 6cm x 250 m 3 = 1500 m 3 Freehaul distance = 600m (given) Axis y; Measurement line = 6 cm Freehaul = Freehaul volume x freehaul distance stn.m 100 Freehaul = 1500 x 600 = 9000 stn.m 100 Axis x; Measurement line = 6 cm Freehaul distance = 6cm x 100 m = 600 m Cumulative volume m 3 Chainage ,m E F 480 m – max point STEP 3 – determine free haul
- 8. Axis y; Measurement line AB = 12.3 cm Haul volume = 12.3cm x 250 m 3 = 3075 m 3 Axis x; Measurement line EF = 6.1 cm How to determine average haul distance??? Average haul distance = Line AB /2 = 12.3 / 2 = 6.15 A B At the point line parallel with axis-x = Line EF Average haul distance = 6.1 cm x 100 m = 610 m Haul = Haul volume x average haul distance stn.m 100 Haul = 3075 x 610 = 18757.5 stn.m 100 Chainage ,m Cumulative volume m 3 E F 480 m – max point STEP 4 – determine haul
- 9. Axis y; Measurement line AB = 6.3 cm Overhaul volume = 6.3cm x 250 m 3 = 1575 m 3 How to determine average over haul distance??? Average overhaul distance = Line AB /2 = 6.3 / 2 = 3.15 At the point line parallel with axis-x = Line EF A B Axis x; Measurement line EF = 7.5 cm Average overhaul distance = 7.5 cm x 100 m = 750 m Overhaul = Overhaul volume (average overhaul distance – freehaul distance) stn.m 100 Overhaul = 1575 (750 – 600) = 2362.5 stn.m 100 STEP 5 – determine overhaul Chainage ,m Cumulative volume m 3 E F 480 m – max point
- 12. TOTAL COST OF EARTHWORK Freehaul prices in freehaul distance = freehaul volume x freehaul distance x freehaul prices = (22 000 + 10 000) x 200 x RM1.25/200 = RM 40 000 Overhaul prices in freehaul distance = overhaul volume x freehaul distance x freehaul prices = (18 000 + 21 500) x 200 x RM1.25/200 = RM 49 375 Overhaul prices in overhaul distance = overhaul volume x ( average overhaul distance – freehaul distance ) x overhaul prices = [(18 000 x (245 – 200) x (RM1.25 + RM0.40)/100) + (21 500x (360 – 200) x (RM1.25 + RM0.40)/100)] =RM 70 125 Borrow prices = borrow volume x borrow prices = 22500 x RM 0.75 = RM 16 875 TOTAL COST OF EARTHWORK = RM 176 375
