1. AMD DESKTOP PLATFORMS
2012 AMD A-Series

2. AGENDA
•Platform Overview
•2012 AMD A-Series Accelerated Processors
•Summary
2 | 2012 AMD A-Series Presentation

3. AMD DELIVERS WHAT CUSTOMERS WANT
Unlocked1
Unlocked Performance Latest Tech and World’s Highest Frequencies2
with Maximum Cores
Up to 8 CPU Cores
More Speed and Cores
Ideal Platform with
Better Video and Gaming with AMD Radeon™
up to $100 Graphics
Easy Upgrades
Cool & Quiet
Inexpensive
Every Day PC E-SERIES Best Online Entertainment Experiences
Amazing Price / Performance
AMD Internal Research
3 | 2012 AMD A-Series Presentation

4. 2012 AMD A-SERIES OVERVIEW
CPU Discrete Class Graphics
(“Piledriver” Cores) AMD Radeon™ HD 7000
“Trinity” Details
Core 1 Core 2 Core 3 Core 4 • 32nm
• ~1.3B transistors
• 246mm2
L2 Cache L2 Cache • Up to 4 x86 Cores
FM2 Socket
4 | 2012 AMD A-Series Presentation

5. A-SERIES EVOLUTION
2011 A-Series “Llano” 2012 A-Series “Trinity”
Socket FM1 Socket FM2
1150 3DMark 11 1570
3230 PCMark 7 4040
Numbers rounded to nearest tens digit
5 | 2012 AMD A-Series Presentation See endnotes for more information

6. BUILD A BETTER PC WITH AMD
More Speed
& Better Video & Gaming Easy Upgrade Path
More Cores
Featuring AMD Featuring AMD Featuring A85X, A75,
Turbo Core 3.0 Radeon™ Graphics and A55 Platforms
6 | 2012 AMD A-Series Presentation

7. MORE CORES & MORE SPEED
Intel Core i3
2120/3220
X86 Cores 4 2
Max Frequency (GHz) 4.2 3.3
Powered by AMD Turbo Core 3.0
7 | 2012 AMD A-Series Presentation

8. MORE SPEED WITH AMD ACCELERATED PROCESSORS
WINZIP 16.5
Winzip 16.5 Compression of 1015 Wave Files
9 FASTER
Measured in SECONDS (Lower Is Better)
8
7
6
5
4
• OpenCL Accelerated
3 Encode and Decode
• Additional AES
2 Acceleration
1 AMD A10 AMD A8 AMD A6 AMD A4 Pentium Pentium
5800K 5600K 5400K 5300 Core i3 G860 G630
0
8 | 2012 AMD A-Series Presentation See endnotes for more information

9. MORE SPEED WITH AMD ACCELERATED PROCESSORS
GIMP
GIMP Bilateral Filter Completion Time on a 1732x2592.bmp
OpenCL™ Enabled
9
Measured in SECONDS (Lower Is Better)
8
7
6
5 FASTER • OpenCL™ accelerated
4 rendering, color
conversion, and image
3 computation
• 19 filters accelerated
2 with OpenCL™
1 AMD A10 AMD A8 AMD A6 AMD A4 Pentium Pentium
5800K 5600K 5400K 5300 Core i3 G8x0 G6x0
0
9 | 2012 AMD A-Series Presentation See endnotes for more information

10. OVERCLOCKING1 CAPABILITIES
BUILD A BETTER PC WITH AMD
Overclock the CPU and GPU
GPU @ 1 GHz
CPU* @ 6.5 GHz GPU @ 1.05 GHz Memory @ 2133
+68% +11% +22.4%
Cinebench 3DMark 3DMark
11.5 11(P) 11(P)
*Performed with LN2 (liquid nitrogen)
10 | 2012 AMD A-Series Presentation See endnotes for more information

11. YOUR FAVORITE TITLES ACCELERATED
DOMINATING 1080P GAMING COMPARED TO AN INTEL HD 4000
+102% +79% +77% +107% +101% +93% +82% +82%
2xAA 8xAF Medium Medium Max with
Low Low
High Low Low Shadows Very Low
11 | 2012 AMD A-Series Presentation See endnotes for more information

12. ACCELERATED PROCESSORS DELIVER THE BEST GAMING EXPERIENCE
WHY BUY THEIR MAINSTREAM GRAPHICS
90
Intel Core i5 3450 + NV GT 630 2GB DDR3 +$65
80
AMD A10 5800K
70
60 Get a Better
Value with AMD
50
40
30
20
10
0
AvP Benchmark Call of Duty: Crysis 2 Deus Ex: DirtShowdown Just Cause 2 Left 4 Dead 2 Metro2033 Shogun 2 Skyrim: StarCraft II
Black Ops
Pricing based off of AMD SEPP and Pricewatch.com on 8/28/12
12 | 2012 AMD A-Series Presentation See endnotes for more information

13. AMD THE BETTER PLATFORM
MAKE AMD RADEON <$100 GRAPHICS SHINE
70
Diablo III: 1920x1080 Max Settings
60 AMD
A-Series
50 Discrete
Advantage
40
FPS
30 AMD
A-Series
APU
20 Advantage
• Additive Performance3
• Supports DirectX® 9, 10, 11 10
• Over 100 titles accelerated! 0
AMD A10 5800K Intel Core i3 Core i3 + GT 630 AMD A10 5800K + AMD A10 5800K + Core i3 + GT 640
Graphics AMD Radeon™ HD AMD Radeon™ HD
6570 (Dual 6670 (Dual
Graphics) Graphics)
Graphics Card Pricing: +$65 +$63 +$92 +$102
13 | 2012 AMD A-Series Presentation Pricing based off of Pricewatch.com on 8/28/12 See endnotes for more information

14. EASY UPGRADES
AMD EYEFINITY3 TECHNOLOGY IN THE APU
32 fps
Torchlight II: Max Settings
AMD 10 5800K with AMD Radeon™ HD 7660D Discrete Class Graphics
Native Widescreen Entertainment
on an Accelerated Processor
14 | 2012 AMD A-Series Presentation See endnotes for more information

15. 2012 A-SERIES APUS FOR DESKTOP
MULTI MONITOR TECHNOLOGY @1080P X3
Native Windows 8 Widescreen Enhancements
15 | 2012 AMD A-Series Presentation

16. EASY UPGRADE PATH
INTRODUCING OUR NEW FM2 PLATFORM
2011 2012 Future
“Llano” “Trinity” “…”
FM1 Socket FM2 Socket
AMD A55 Chipset AMD A75 Chipset AMD A85X Chipset
FM2 Socket FM2 Socket FM2 Socket
FM2 Entry Ideal Entertainment Targeted for
Platform Platform Performance
16 | 2012 AMD A-Series Presentation

17. EASY UPGRADE PATH
AMD MEMORY PROFILES
Accelerated Processors Scale with
Memory Frequency
FPS
35
30
25
20 Easily Set
1866 MHz
15 Bios Default Bios Default Bios Default
Performance
1600MHz 1600MHz 1600MHz
10
Dirt Showdown @1080P StarCraft II @1080P High Elder Scrolls: Skyrim
2AA 8AF Medium @1080P Medium
17 | 2012 AMD A-Series Presentation See endnotes for more information

18. INTRODUCING AMD RADEON™ RAMDISK
AMD A10 APU + AMD Memory = Up to 64 GB RAMDisk
Features and Benefits Loading Times
160 (lower is faster)
 Faster web page and application loading 140
 Auto load and save 120
Normal RAM Disk
100
 Maximum Security 80
 No disk fragmentation
60
 Extends the life of SSDs
40
 Extreme Performance 20
 Experience up to 525% faster loading of PC games 0
Crysis Shogun 2 Arma 2 Dirt
Showdown
Less waiting and more doing with PC-compatible RAMDisk
18 | 2012 AMD A-Series Presentation

19. EASY UPGRADE PATH
BUILD A BETTER SYSTEM WHEN CHOOSING <$100 GRAPHICS SOLUTIONS
fps
60 Sleeping Dogs
(1080P Medium Preset) +$92
50
40 +$63
+$105
30
+$65
20
10
0
HD 4000 GeForce GT 630 AMD A10-5800K APU GeForce GT 640 A10-5800K + HD6570 A10-5800K + HD 6670
Pricing based off of AMD SEPP and Pricewatch.com on 8/28/12
19 | 2012 AMD A-Series Presentation See endnotes for more information

20. INTRODUCING THE FM2 PLATFORM
Build a Better PC with AMD
More Speed &
Best Video & Gaming Easy Upgrades
More Cores
Featuring Featuring Featuring A85X, A75,
AMD Turbo Core 3.0 AMD Radeon™ Graphics and A55 Platforms
20 | 2012 AMD A-Series Presentation

21. FM2 SOCKET ACCELERATED PROCESSORS AND PROCESSORS SKU INFORMATION
APU Model A10-5800K A10-5700 A8-5600K A8-5500 A6-5400K A4-5300
AMD Radeon™ Graphics Brand HD 7660D HD 7660D HD 7560D HD 7560D HD 7540D HD 7480D
TDP 100W 65W 100W 65W 65W 65W
AMD Radeon™ Cores 384 384 256 256 192 128
GPU Clock Speed 800 MHz 800 MHz 760 MHz 760 MHz 760 MHz 723 MHz
CPU Cores 4 4 4 4 2 2
3.9/ 3.7/ 3.8/ 3.6/
CPU Clock (Max Turbo/Base) 4.2/3.8 GHz 4.0/3.4 GHz
3.6 GHz 3.2 GHz 3.6 GHz 3.4 GHz
Total Cache 4MB 4MB 4MB 4MB 1MB 1MB
Max DDR3 1866 1866 1866 1866 1866 1600
AMD Turbo CORE 3.0 Yes Yes Yes Yes Yes Yes
Unlocked1 Yes No Yes No Yes No
21 | 2012 AMD A-Series Presentation

22. BACK UP SLIDES
22 | 2012 AMD A-Series Presentation

23. FOOTNOTES
Additional hardware (e.g. Blu-ray drive, HD or 10-bit monitor, TV tuner, wirelessly enabled HDTV) and/or software (e.g. multimedia applications) are
required for the full enablement of some features. HD Video display requires an HD video source. Not all features may be supported on all components
or systems - check with your component or system manufacturer for specific model capabilities and supported technologies.
1. AMD’s product warranty does not cover damages caused by overclocking, even when overclocking is enabled with AMD hardware or software
2. Based on a shipping frequency of 4GHz – the highest shipping frequency of a consumer desktop processor as of September 5th, 2012
3. AMD Eyefinity technology works with games that support non-standard aspect ratios, which is required for panning across multiple displays. To
enable more than two displays, additional panels with native DisplayPort™ connectors, and/or DisplayPort™ compliant active adapters to convert
your monitor’s native input to your cards DisplayPort™ or Mini-DisplayPort™ connector(s), are required. Support for six simultaneous displays may
require complementary products compatible with DisplayPort 1.2 Multi-Stream Transport. Maximum number of configured displays may vary - check
with your component or system manufacturer for specific model capabilities and supported technologies. SLS (“Single Large Surface”) functionality
requires an identical display resolution on all configured displays
4. AMD Radeon™ Dual Graphics requires an AMD “A” series APU plus an AMD Radeon™ discrete graphics configuration and is available on
Windows® 7 Professional, Windows 7 Ultimate, Windows® 7 Home Premium, and/or Windows® 7 Home Basic OS. Linux OS supports manual
switching which requires restart of X-Server to engage and/or disengage the discrete graphics processor for dual graphics capabilities. With AMD
Radeon™ Dual Graphics, full enablement of all discrete graphics video and display features may not be supported on all systems and may depend
on the master device to which the display is connected. Check with your component or system manufacturer for specific mode capabilities and
supported technologies. For All-In-One systems AMD Radeon™ “D” series and AMD Radeon™ “D2” Dual Graphics series do not support AMD
Eyefinity technology. Always check with your system manufacturer for specific model capabilities and supported technologies.
23 | 2012 AMD A-Series Presentation

24. ENDNOTES
Slide 5: A-Series Evolution
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7
 AMD A8-3850 with AMD Radeon™ HD 6550D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7
Slide 8 & 9: More Cores and Faster Speeds with AMD Accelerated Processors
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.3
 AMD A8-5600K with AMD Radeon™ HD 7560D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.4
 AMD A6-5400K with AMD Radeon™ HD 7540D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.4
 AMD A4-5300 with AMD Radeon™ HD 7480D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.4
 Intel Core i3-2120 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712
 Intel Pentium G850 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712
 Intel Pentium G620 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712
Slide 10: Overclocking Capabilities
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7
Slide 11: Your favorite Titles Accelerated
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8
 Intel Core i3-2120 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712
Slide 12: Accelerated Processors Deliver The Best Gaming Experience
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8
 Intel Core i5-3450 with NV GT630 2GB DDR3, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. Driver 304.48
24 | 2012 AMD A-Series Presentation

25. ENDNOTES
Slide 13: Better Platform
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7
 AMD A10-5800K with AMD Radeon™ HD 6570 or AMD Radeon™ HD 6670 Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7
64bit. Catalyst 12.7 and AMD Dual graphics enabled
 Intel Core i3-2120 with HD 2000, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 8.15.10.2712
 Intel Core i3-2120 with NV GT 630 2GB DDR3 or NV GT 640 2GB DDR3, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD, Windows 7 64bit. 304.48
Driver
Slide 14: Easy Upgrades: Eyefinity technology in the APU
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8
Slide 16: Easy Upgrade Path: AMD Memory Profiles
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866 (AMP enabled), A85X, 1TB 7200 rpm HD, Windows 7 64bit.
Catalyst 12.8
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x4 GB DDR3-1866 (Bios default left at 1600), A85X, 1TB 7200 rpm HD, Windows 7
64bit. Catalyst 12.8
Slide 18: AMD RAMDisk
 AMD A10-5800K with AMD Radeon™ HD 7660D Graphics, 2x8 GB DDR3-1600, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.8
25 | 2012 AMD A-Series Presentation

26. ENDNOTES
Slide 19: Easy Upgrade Path: Build a better system with AMD and <$105 graphics
 AMD A10-5800K with AMD Radeon™ HD 7660D or AMD Radeon™ HD 6570 or AMD Radeon™ HD 6670 or AMD Radeon™ HD 7770
Graphics, 2x4 GB DDR3-1866, A85X, 1TB 7200 rpm HD, Windows 7 64bit. Catalyst 12.7 and AMD Dual graphics enabled for AMD Radeon™
HD 6570 and AMD Radeon™ HD 6670.
 Intel Core i5-3570K with HD 4000 on driver 8.15.10.2712 or Intel Core i5-3450 with GeForce GT 630 2GB DDR3 or GeForce GT 640 2GB
DDR3 with Driver 304.48 or AMD Radeon™ HD 7770 Graphics with Catalyst 12.8, 2x4 GB DDR3-1600, P67, 1TB 7200 rpm HD,
Windows® 7 64bit.
