Thinking restfully

REST
Thinking RESTfully
Stelios Gkorilas

JHUG 17 Dec 2011

Contents
1.  Types of services
2.  What is REST?
3.  Web services and the REST way
4.  Example: S3
5.  Security
6.  Jersey/JAX-RS
7.  CTR

JHUG 17 Dec 2011

Distributed services
•  The everlasting need to (re-)use logic as black box
•  Even across different machines and platforms
•  Gave birth to distributed objects and several protocols for

remoting (e.g. CORBA, DCOM, RMI)
•  Web services prevailed because the web is ubiquitous and
scalable
•  Web services provide the means to integrate disparate systems
and expose reusable business functions over HTTP
•  Mostly SOAP services up to now in RPC style
•  Some serve HTML, JSON, plain text, or binary documents, but most

use XML
•  WSDL and the WS-* specs
•  HTTP is used as the transport service not the application protocol
JHUG 17 Dec 2011

Service styles
•  RPC services
•  Message oriented services
•  Resource oriented services

JHUG 17 Dec 2011

RPC style
•  The request message identifies the procedure to be

executed, and the fixed set of parameters that map
directly to the parameters of the remote procedure

•  XML-RPC and later the WS-* stack
•  Procedure arguments are tightly coupled messages
•  Usually flat APIs
•  Communication through proxies that have to be

regenerated in case of change
•  e.g. JAX-WS

JHUG 17 Dec 2011

Message oriented
•  Services that have Message APIs (a.k.a. Document APIs)

receive one or more self-descriptive message types at a
given URI
•  They are not coupled to procedure names hence they can
easier change
•  They can constitute commands, events or just documents
•  They contain values that identify their type and/or
handling

JHUG 17 Dec 2011

making a Google search the SOAP way
POST search/beta2
HTTP/1.1 Host: api.google.com
Content-Type: application/soap+xml
SOAPAction: urn:GoogleSearchAction
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">
<soap:Body>

<gs:doGoogleSearch xmlns:gs="urn:GoogleSearch">

<key>00000000000000000000000000000000</key>

<q>jhug user group</q>

<start>0</start>

<maxResults>10</maxResults>

<filter>true</filter>

<restrict />

<safeSearch>false</safeSearch>

<lr />

<ie>latin1</ie>

<oe>latin1</oe>

</gs:doGoogleSearch>
</soap:Body>
</soap:Envelope>
JHUG 17 Dec 2011

Resource oriented
•  It’s like object oriented – Resources are objects
•  Resource is the design of data; what we perceive data to

be; it is what we think others might find interesting about
our data
•  Everything can be a resource
•  Resources are accessed through a Uniform Interface
•  Resources are interconnected
•  Resources have multiple representations
•  Communication is stateless

JHUG 17 Dec 2011

Resources
•  Everything can be a resource (like everything can be an object)
•  A procedure, instances of domain data, files
•  Examples:
•  A list of search results about ‘Mullus barbatus’
•  An article
•  The jhug meeting on Dec 17
•  The latest jhug meeting
•  The software version release 1.1.2.3
•  The latest release
•  The list of unresolved issues of type ‘bug’ and component ‘Launcher’
•  Every resource should have a unique identifier, a URI
•  http://www.jhug.gr/meetings/meet-up/17-dec-2011
JHUG 17 Dec 2011

What is REST?
•  Architectural style
•  Architectural constraints
•  A way to evaluate architectures
•  Design principles
•  Key properties of a simple (not simplistic) application
•  The null style: Start with system needs as a whole,

without constraints, and then incrementally identifies and
applies constraints to elements of the system in order to
differentiate the design space
•  Representational State Transfer
•  You request a resource and a representation of its state is

returned

JHUG 17 Dec 2011

HTTP Example
Request
GET /meetups/latest HTTP/1.1
Host: www.jhug.gr
Accept: application/xml
Response
HTTP/1.1. 200 OK
Date: Sat, 17 Dec 2011 13:45:34 GMT
Server: Apache/1.3.6
Content-Type: application/xml; charset=UTF-8
<meetup xmlns="...">
<occurred date=".."/>
<presentations>
...
</presentations>
<next uri=".."/>
</meetup>
JHUG 17 Dec 2011

HTTP, URIs & XML define the web
•  Operations: GET, PUT, DELETE, POST
•  And the less known HEAD, OPTIONS
•  Headers
•  content-type
•  Accept-Language
•  Media types
•  text/plain
•  text/xml
•  application/atom+xml
•  Response codes
•  2xx Success
•  3xx Redirect
•  4xx Client Error
•  5xx Server Error
•  URIs and URLs define the web
•  XML: content attributes and structure

An Application protocol for service logic
JHUG 17 Dec 2011

REST constraints (Fielding dissertation)
•  Client/server
•  Uniform Interface
•  Layered System
•  Stateless
•  Cache
•  Code on Demand

JHUG 17 Dec 2011

Resources and the uniform interface
•  HTTP standard methods: GET, PUT, POST, DELETE
•  HEAD and GET should not modify anything
•  Idempotent: PUT DELETE GET HEAD
•  HTTP is the application protocol defining service

behaviors
•  GET /meetups/latest instead of getLatestMeetup()
•  RPC verbs become REST nouns
•  GET the more recent state of the resource
•  PUT/POST a representation that alters the state of the

resource

JHUG 17 Dec 2011

Representations
•  Representations have media types
•  Multiple formats for different needs
•  Content negotiation
•  Accept: application/json (request)
•  Content-Type: application/json (response)

•  URI
•  /meetups/latest.json

JHUG 17 Dec 2011

Addressability
•  Representations should be addressable
•  Increase the surface of the service
•  Client can enter the application where convenient
•  A URI can never point to more than one resource

JHUG 17 Dec 2011

Interconnected Resources
• 
• 
• 
• 
• 
• 

Resources are not just data but hypermedia
Hypermedia as the engine of state
Representations contain links to other resources
A representation may contain links ot other states of the resource
Paths a client can follow
Makes clients more resilient to changes

<meetup xmlns="...">
<occurred date="17-12-2011"/>
<presentations>
<presentation ref="/presentations/title/disruptor"/>
<presentation ref="/presentations/title/rest"/>
<presentation ref="/presentations/title/sw-dev-practices"/>
</presentations>
<next ref="/meetings/date/17-01-2011"/>
</meetup>

JHUG 17 Dec 2011

Stateless
•  HTTP is stateless
•  All information needed for processing part of the request
•  No session on the server
•  No session ids exchanged (jsessionId, phpSessionId, etc. )
•  Application state belongs to the client
•  Resource state alone belongs to the server
•  Simplifies server and client logic, allows scalability

e.g. http://www.google.gr/search?q=jhug&start=20
JHUG 17 Dec 2011

Cacheability
•  Conditional queries
•  Cacheable when last-modified and etag are used (response
headers)
•  If- Modified-Since and If-None-Match (request headers)
•  304 Response Code when not modified with no entity body
•  Cache proxies and other commodity caching technologies

JHUG 17 Dec 2011

REST Patterns
•  Paths for hierarchy
•  jhug/discussions/april
•  Post for not owned URIs
•  Container items
•  Jhug/discussions/1342
•  PUT for URIs defined by the client
•  Jhug/presentations/rest
•  Semicolon (;) or comma (,) for name/value or matrix

values
•  jhug/presentations/author,gkorilas/rest

•  Query string for algorithmic resources
•  Jhug/search?q=“rest”
JHUG 17 Dec 2011

Think Resource Oriented
•  Define the data set
•  Expose data as resources
•  Assign URIs to resources
•  Decide the UI commands accepted
•  Decide the representations accepted
•  Decide the representations served
•  Add hypermedia links between them

JHUG 17 Dec 2011

REST +
•  Serve representations suitable for many clients
•  The uniform interface allows all http clients to easily consume a
suitable representation
•  Content negotiation can allow a single URL to serve content to a
browser, a JS client that is interested in JSON or a mobile phone client
interested in an XML representation
•  Cacheable by commodity technologies
•  Scalable
•  Fail over
•  Clients:
•  Browser friendly
•  Easy support by many languages
•  Bookmarkable
•  Data formats
•  It is the natural way of the web!
JHUG 17 Dec 2011

REST Security standards

JHUG 17 Dec 2011

The Amazon S3 Service
•  S3 “buckets” and S3 “objects”
•  Bucket can only contain objects
•  Bucket names are unique in S3
•  Object has a name (key) and content (value)
•  Object has a reference to the parent bucket
•  Object has metadata key-value pairs; can also be http headers like
content-type or content-disposition
•  Three types of resources
•  List of your buckets (https://s3.amazonaws.com/)
•  A particular bucket (https://s3.amazonaws.com/{name-of-bucket}/). There
can be up to 100 resources of this type.
•  A particular S3 object inside a bucket (https://s3.amazonaws.com/
{name-of- bucket}/{name-of-object}
JHUG 17 Dec 2011

S3 resources and methods
GET

HEAD

PUT

DELETE

(/)

List your
buckets

-

-

-

/{bucket}

List objects of
bucket

-

Create the
bucket

Delete the
bucket

/{bucket}/
{object}

Object’s value Object’s
and metadata metadata

Set the
object’s value
and metadata

Delete the
object

JHUG 17 Dec 2011

S3 Security
•  Message digest of the canonical string of the request with a

secret key (amazon knows it too)
•  {http method}{content-type}{date}{amazon headers}{path}

•  Add it to http Authorization: header
•  Add it to query string together with expires date to make

bookmarkable (https://s3.amazonaws.com/stelinio/rest.pdf# ?
Signature=J%2Qu6krT3j0zaaFXjsLbowdfzExQ%3D #
&Expires=1162156788&AWSAccessKeyId=0F9RBCLB5274NK
TJ4DA3")
•  Access policies
•  Private, public-read, public-write, authenticated read
JHUG 17 Dec 2011

HTTP security, OAuth
•  http basic
•  http digest
•  http client certificate
•  OAuth
•  Delegated user authentication solution - Valet key principle
•  Client, server, resource owner (OAuth love triangle)
•  client credentials, temporary credentials, and token credentials

JHUG 17 Dec 2011

Java REST Services
•  Java EE 6 specification: JAX-RS
•  Jersey: Reference implementation of JSR 311
•  Available as standalone and enterprise

JHUG 17 Dec 2011

Standalone example setup
<servlet>
<servlet-name>jersey</servlet-name>
<servlet-class>com.sun.jersey.spi.container.servlet.ServletContainer</servlet-class>
<init-param>
<param-name>com.sun.jersey.config.property.packages</param-name>
<param-value>eu.ema.eudract.rest</param-value>
</init-param>
<load-on-startup>1</load-on-startup>
</servlet>
<dependency>
<groupId>com.sun.jersey</groupId>
<artifactId>jersey-server</artifactId>
</dependency>
<dependency>
<artifactId>jersey-json</artifactId>
</dependency>
<dependency>
<artifactId>jersey-atom</artifactId>
</dependency>
JHUG 17 Dec 2011

JAX-RS Resources
Annotate POJOs
@Path("/meetups")
@Singleton()
public class MeetUpsResource {

@GET()
@Path("/latest")
@Produces("text/plain")
public String getLatestMeetUp() {

return getDataService().getLatestMeetUp().toString();
}

@GET()
@Path("/next")
public String getNextMeetUp() {

return getDataService().getNextMeetUp().toString();
}

@GET()
@Produces(MediaType.APPLICATION_JSON)
public MeetUps getAllMeetUps() {

return getDataService().getAllMeetUps();
}
}

JHUG 17 Dec 2011

Methods & Paths
•  @javax.ws.rs.GET
•  @javax.ws.rs.PUT
•  @javax.ws.rs.POST
•  @javax.ws.rs.DELETE
•  @javax.ws.rs.HEAD
•  Paths: Most specific match wins

JHUG 17 Dec 2011

JAX-RS Injection
•  @javax.ws.rs.PathParam
•  values from URI template parameters
•  @javax.ws.rs.MatrixParam
•  URI’s matrix parameters.
•  @javax.ws.rs.QueryParam
•  Query String parameters
•  @javax.ws.rs.FormParam
•  form-encoded key-value pairs
•  @javax.ws.rs.HeaderParam
•  HTTP request headers
•  @javax.ws.rs.CookieParam
•  HTTP cookies set by the client
•  @javax.ws.rs.core.Context
•  All-purpose injection annotation. It allows you to inject various helper and
informational objects that are provided by the JAX-RS API e.g.
•  @Context final HttpServletRequest request
•  @Context final SecurityContext secCtx
JHUG 17 Dec 2011

JAX-RS Content Handling
•  MIME types
•  Automatic content negotiation
•  Automatic content serialization
•  Jaxb representation → XML, JSON
•  Byte[] → Binary or */*
•  String → text/*
•  MultiValuedMap<String, String> → application/x-www-formurlencoded
•  StreamingOutput
•  @Providers

JHUG 17 Dec 2011

JAX-RS Error Handling
•  HTTP Error Codes
•  WebApplicationException
•  ExceptionMapper

throw new WebApplicationException(new RuntimeException (“Timeframe
not an Integer"),
Response.Status.NOT_ACCEPTABLE);

@Provider
public class EntityNotFoundMapper implements
ExceptionMapper<EntityNotFoundException>
{
public Response toResponse(EntityNotFoundException e){
return Response.status(Response.Status.NOT_FOUND).build();
}
}
JHUG 17 Dec 2011

Enforcing security
•  @RolesAllowed({“admin”,”client-admin”})
•  @PermitAll
•  Any authenticated user
•  @SecurityContext
public interface SecurityContext
{
public static final String BASIC_AUTH = "BASIC";

public static final String CLIENT_CERT_AUTH = "CLIENT_CERT";

public static final String DIGEST_AUTH = "DIGEST";

public static final String FORM_AUTH = "FORM";

public Principal getUserPrincipal();

public boolean isUserInRole(String role);

public boolean isSecure();

public String getAuthenticationScheme();
}

JHUG 17 Dec 2011

Example
@Path(”/presentations")
@Singleton()
public class PresentationsResource {

@PUT()
@Path(”/presentation/{name}”)
@RolesAllowed(”admin”)
public void addPresentation(@PathParam name, InputStream is){

return getDataService().addPresentation(is);
}

@GET()
@Path(”/presentation/{name}")
public StreamingOutput getPresentation(@PathParam name) {

return new StreamingOutput() {

@Override

public void write(OutputStream output) throws

IOException {

stream(

getDataService().getPresentation(name)

, output

);

}

}

}
}

JHUG 17 Dec 2011

CTR
•  Clinical Trials Register
•  (https://www.clinicaltrialsregister.eu/)
•  Rest services
•  Data to other agency html pages
•  Content to the World Health Organization
•  Data to the web application users
•  Rest clients
•  JS code as the client
•  Controller servlet
•  JSP <c:import url=“/trial/2010-022009-16/GB”/>
•  A guy at World Health Organization every Tuesday at 19:00
JHUG 17 Dec 2011

Data consumed by html pages (1/3)
@Path("/trials")
@Singleton()
public class TrialsMetaDataResource {

@GET()
@Path("/count/public")
public String countPublicTrials() {

return getDataService().countPublicClinicalTrials().toString();
}

@GET()
@Path("/count/public/under18")
public String countUnder18PublicTrials() {

return getDataService().countPublicClinicalTrialsWithSubjectsUnder18().toString();
}

@GET()
@Path("/landing")
@Produces(MediaType.APPLICATION_JSON)
public LandingPageMetadata landingPageMetadata() {

Integer total = getDataService().countPublicClinicalTrials();

Integer under18 = getDataService().countPublicClinicalTrialsWithSubjectsUnder18();

}
…
}

LandingPageMetadata metadata = new LandingPageMetadata(total, under18);
return metadata;

JHUG 17 Dec 2011


@XmlRootElement()
@XmlAccessorType(value = XmlAccessType.PROPERTY)
public class LandingPageMetadata implements Serializable {

private static final long serialVersionUID = -8784258618018188874L;

private Integer numberOfPublicClinicalTrials;
private Integer numberOfPublicClinicalTrialsWithSubjectsUnder18;

public LandingPageMetadata() {…}

public LandingPageMetadata(Integer numberOfPublicClinicalTrials,

Integer numberOfPublicClinicalTrialsWithSubjectsUnder18) {…}
@XmlElement(name="total")
public Integer getNumberOfPublicClinicalTrials() {…}
public void setNumberOfPublicClinicalTrials(Integer numberOfPublicClinicalTrials) {…}

@XmlElement(name="under18")
public Integer getNumberOfPublicClinicalTrialsWithSubjectsUnder18() {…}

public void setNumberOfPublicClinicalTrialsWithSubjectsUnder18(Integer
numberOfPublicClinicalTrialsWithSubjectsUnder18) {…}

@Override
public String toString() {…}

}

JHUG 17 Dec 2011

function showNumbers() {
$.getJSON('api/trials/landing', function(data) {

var total = data['total'];

var under18 = data['under18'];

$("#total").text(total);

$("#under18").text(under18);
});
}

JHUG 17 Dec 2011

Streaming Content (1/2)
@Path("/download")
public class DownloadResource {

@GET
@Path("/summary")
public Response downloadSummaryTrials(@Context final HttpServletRequest request, @QueryParam

("mode") final String mode) {

return Response.ok(new SummaryStreamingOutput(request, mode),MediaType.APPLICATION_OCTET_STREAM)

.header("content-disposition","attachment; filename = trials-summary.txt").build();
}

@GET
@Path("/full")
public Response downloadFullTrials(@Context final HttpServletRequest request, @QueryParam

("mode") final String mode) {

return Response.ok(new FullStreamingOutput(request, mode),MediaType.APPLICATION_OCTET_STREAM)

.header("content-disposition","attachment; filename = trials-full.txt").build();
}

@GET
@Path("/trial/{eudractnumber}/{nca}")
public Response downloadFullCta(@Context final HttpServletRequest req, @PathParam

("eudractnumber") String eudractnumber, @PathParam("nca") String nca) {

return Response.ok(new CtaStreamingOutput(req, eudractnumber, nca),MediaType.APPLICATION_OCTET_STREAM)

.header("content-disposition","attachment; filename = trial.txt").build();
}
}

JHUG 17 Dec 2011

Streaming Content (2/2)
public class CtaStreamingOutput implements StreamingOutput
{
public CtaStreamingOutput(HttpServletRequest

request, String euNumber, String nca) {…}

}

public void write(OutputStream output) throws

IOException {

TextSerializer ser = new TextSerializer();

ser.setOutputStream(output);

CtaIdentification pubCta = mapper.map

(eudractNumber, nca);

ser.serializeCtaFull(pubCta);
}

JHUG 17 Dec 2011

RSS 2.0 instead of built in Atom (1/2)

@GET
@Path("/bydates”)
@Produces("application/rss+xml")
public SyndFeed getFeed(@Context final HttpServletRequest request) {
String feedType = "rss_2.0”;
SyndFeed feed = new SyndFeedImpl();
feed.setFeedType(feedType);
String url = request.getRequestURL().toString().replaceFirst("/rest/

feed/bydates", ”/search") + "?" + request.getQueryString();
feed.setLink(url);
feed.setTitle("EU Clinical Trials Register RSS Feed");
feed.setDescription("This provides a regular feed of new or updated

clinical trial information published on the EU

Clinical Trial Register and matching the search

subscribed to.");

List<CtrDocument> docs = search(request);

for(CtrDocument doc: docs){

SyndEntry entry = buildEntry(doc, entryBasicUrl, countryUrl);

feed.getEntries().add(entry);
}
LOG.info("Generated RSS feed {}", feed.getLink());
return feed;
}
JHUG 17 Dec 2011

RSS 2.0 instead of built in Atom (2/2)
@Provider
@Produces("application/rss+xml")
@Consumes("application/rss+xml")
public class RomeRssSupport implements MessageBodyWriter<Object>{

public boolean isWriteable(Class<?> type, Type genericType,

Annotation[] annotations, MediaType mediaType) {
return (SyndFeed.class.isAssignableFrom(type));
}
public long getSize(Object t, Class<?> type, Type genericType,

Annotation[] annotations, MediaType mediaType) {
return -1;
}

}

public void writeTo(Object feedOrEntry, Class<?> type, Type genericType,

Annotation[] annotations, MediaType mediaType,

MultivaluedMap<String, Object> httpHeaders, OutputStream outputStream)

throws IOException {
if (feedOrEntry instanceof SyndFeed) {

SyndFeed feed = (SyndFeed)feedOrEntry;

SyndFeedOutput output = new SyndFeedOutput();

doc = output.outputW3CDom(feed);

Source source = new DOMSource(doc);

Result result = new StreamResult(outputStream);

TransformerFactory factory = TransformerFactory.newInstance();

Transformer transformer = factory.newTransformer();

transformer.transform(source, result);

}
}

JHUG 17 Dec 2011

Resources
•  Restful Web Services - Leonard Richardson and Sam
Ruby
•  Service Design Patterns - Robert Daigneau
•  Restful Java - Bill Burke
•  www.amazon.com
•  http://icondrawer.com
•  http://www.iconeden.com
•  http://www.iconshock.com

JHUG 17 Dec 2011

Thinking restfully

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Similar to Thinking restfully

Similar to Thinking restfully (20)

Recently uploaded

Recently uploaded (20)

Thinking restfully
