This document discusses robots and robotics. It covers several key topics:
- The definition and original meaning of the word "robot"
- The multi-disciplinary field of robotics, encompassing mechanical design, electronics, and artificial intelligence
- Common types of actuators used in robots including motors, pneumatics, and hydraulics
- Methods of locomotion for robots including wheels, legs, climbing, flying, and others
- Systems for controlling robot motion including differential drives, skid-steer drives, and synchronous drives
- The use of sensors to provide feedback to robots about their environment
