1. SSD/Flash for Modern Databases
Peter Zaitsev,
CEO, Percona
November 1, 2014
Highload++ 2014
Moscow,Russia

2. Percona
• Percona Server
• Percona Xtrabackup
• Percona XtraDB Cluster
• Percona Toolkit
We love Open
Source
Software
• Consulting
• Support
• Managed Services
We want to
help you to
succeed with
MySQL and
Beyond
2 www.percona.com

3. In this Presentation
Flash technology overview
Review some of the available technology
What does this mean for databases ?
Specific opportunities for MySQL
3 www.percona.com

4. Before SSDs
4 www.percona.com

5. There were HDDs
Good at Sequential Read/Writes
RT=Seek Time + Rotation Latency
Reads/Write – Similar Latency
No Specific Write Limits
Retain data for a long time
One IO Request in Parallel
Low cost per GB
5 www.percona.com

6. RAID and SAN
6 www.percona.com

7. Using Many HDDs together
Caching Reads
Buffering Writes (Writeback Cache)
Better Sequential Read/Write speed
Better throughput at high concurrency
Higher IO latencies for uncached IO
7 www.percona.com

8. Flash Revolution
Use Flash
chips instead
of platters
No moving
parts
No seeks
8 www.percona.com

9. NAND Flash
Cell
Page/Read Block
Erase Block
Write but no overwrite
Wears with writes (erases)
9 www.percona.com

10. Writing to the Flash
• Set all bits to
“1111111…” Erase
• Set some of the bits to
0: “0100111..” Write
• Impossible. Do Erase,
when Write
Change
Zero to one
10 www.percona.com

11. Types of NAND Flash
From AnandTech:
11 www.percona.com

12. Flash Storage Design
Cache
Battery/Super Capacitor
Controller + Complex Firmware
Built-in Parallelism
12 www.percona.com

13. Flash Controller Tasks
Write wear leveling
Garbage collection
Error correction
Bad block mapping
Read scrubbing
Read disturb management
Encryption
13 www.percona.com

14. Flash Properties
Lots of IOs per device! (100K+)
Less random IO penalty
Writes more expensive than reads (but can be faster)
Limited by amount of writes
Limited retention
Concurrent execution on single device
Fast write acknowledgement (safe or not)
Can burst writes
14 www.percona.com

15. Flash Interface Designs
DIMM
PCI-E
SFF-8639
SATA/SAS
FC and Network
15 www.percona.com

16. Transitioning
AHCI NVMe
16 www.percona.com

17. AHCI vs NVMe
• Source: AnandTech.com
17 www.percona.com

18. Sandisk ULLtraDIMM
18 www.percona.com

19. HGST Virident
19 www.percona.com

20. Sandisk FusionIO
20 www.percona.com

21. Intel P3700
21 www.percona.com

22. Intel 730 (SATA)
22 www.percona.com

23. mSATA
23 www.percona.com

24. M.2 Interface
24 www.percona.com

25. Violin Memory
25 www.percona.com

26. “Consumer” vs “Enterprise”
Performance
Endurance
Durability
Retention
Encryption
26 www.percona.com

27. Not your HDD
All HDDs are the
same; All SSDs are
different
27 www.percona.com

28. Evaluation
Performance changes over time
Empty Space Matters
Complex internals
Watch stability carefully
28 www.percona.com

29. How Flash Fails
Clear write amount defined EOL
(but often can handle a lot more)
One day… it’s gone
“Power Loss Protection”
Internal ECC and redundancy
29 www.percona.com

30. To RAID or not to RAID ?
More valuable for consumer grade
Watch for good Flash support
RAID controller logic may slow things down
Use a redundant array of inexpensive servers
instead?
30 www.percona.com

31. Redundancy
Device internal redundancy
Hardware RAID
Software RAID
Filesystem “RAID”
31 www.percona.com

32. OS Support
Flash support is actively being
improved
TRIM
Sparse Files
32 www.percona.com

33. Flash And Databases
33 wwwww.wpe.prceorncao.cnoam.com

34. Database History
Most have been designed in HDD time
Optimize for sequential IO
Count on cheap sequential writes
RAID, BBU to improve performance
34 www.percona.com

35. It’s time for Flash
Your OLTP
Database should
live on Flash
35 www.percona.com

36. But What Flash ?
Pick a flash type
that is right for your
application
36 www.percona.com

37. IO vs Memory
37 www.percona.com

38. Warmup
Much faster warmup times
Even if the database fits in
memory, SSD might be justified
38 www.percona.com

39. Tolerate more IO bound load
• 5ms
• Can do 20 IO/s for 100ms
response time (non parallel) HDD
• 0.1ms
• Can do 1000 IO/s for 100ms
response time (non parallel) Flash
39 www.percona.com

40. Endurance
Might be a top
consideration
40 www.percona.com

41. Endurance Math
• 4400GB/day over 5 Years
• 1400MB/sec peak writes
• 66 days at peak write
throughput
HGST
FlashMax
III 2200GB
• 72TB total life time writes
• 400MB/sec write
• 52 hours at peak write
throughput
Crucial
M500
960GB
41 www.percona.com

42. Databases and Flash
How do we optimize
databases to us
Flash best?
42 www.percona.com

43. “Torn Page” problem
Flash can avoid this with little cost due to internal design
FusionIO NVMFS (Atomic Writes)
Copy-on-Write File Systems
• ZFS
• BTRFS
Filesystem level data journaling less preferred
• data=journal for EXT4
Skip-Innodb-double-write
43 www.percona.com

44. Fast IO Path
Bypass Caching O_DIRECT
Native Asynchronous IO
Efficient Checksuming
Innodb_checksum_algorithm=crc32
Innodb_flush_method=O_DIRECT
44 www.percona.com

45. IO Cost Accounting
Sequential vs Random IO balance
IO vs CPU Balance
Smaller page sizes might make sense
• innodb_page_size=4K
45 www.percona.com

46. Less Pre-fetching
Most pre-fetched data
must be used
Often best to try It out
46 www.percona.com

47. Less merging on flushing
Do not assume flushing multiple
sequential dirty pages has same
cost
Innodb_flush_neighbors=0
47 www.percona.com

48. Less Space on Disk
Innodb Compression (2x typical)
TokuDB Compression (5-10x typical)
Archiving data off OLTP System
48 www.percona.com

49. Less Writes on Flash
Hybrid Flash/SSD System
Transactional Logs, Other logs on the HDD with
RAID and BBU
Small Temporary objects on tmpfs
Innodb_log_file_size=<LARGE>
49 www.percona.com

50. Logs on RAID can be fast
50 www.percona.com

51. Single Intel 730 Sysbench
51 www.percona.com

52. IOPS
52 www.percona.com

53. Consistency
• Graph by http://cloud.percona.com
53 www.percona.com

54. Is Flash Too Fast ?
• Multiple instances might scale better
54 www.percona.com

55. Other Thoughts
Host hardware and OS matter,
especially with high end flash
Virtualization has higher relative
overhead
Network higher relative overhead
55 www.percona.com

56. Thank You!
Peter Zaitsev
pz@percona.com
@PeterZaitsev
https://www.linkedin.com/in/peterzaitsev
56 wwwww.wpe.prceorncao.cnoam.com
