This document outlines requirements for testing main and auxiliary steering gear before departure, including operating all components and controls. It also requires emergency steering drills every 3 months to practice procedures. Officers must be trained in steering gear operation and maintenance, and records must be kept of tests and drills conducted. Ships on short voyages may have reduced testing requirements of at least once a week.
