![Unit IV Practice Questions
Q1. A 50 MVA, 11KV unloaded generator has the following data:
Xg0 = 0.04pu, X1 = 0.3pu, X2= 0.25pu, Xn = 0.1pu, Xf = 0.3pu. Find the fault current and the
voltage of the healthy line if there is a DLG type of fault on the terminals of the generator which is
maintained at 80% of the rated voltage. [2.067KA]
Q2. The given figure shows a power network with two generators connected in parallel to a transformer
feeding a transmission line. The far end of the line is connected to an infinite bus through another
transformer. Star point of each transformer. Generator 1 and infinite bus are solidly grounded. The
positive, negative and zero sequence reactance of various components in per unit on a common
base are :
Positive Negative Zero
Generator 1 0.15 0.15 0.08
Generator 2 0.25 0.25 0.06(neutral
isolated)
Each 0.15 0.15 0.15
Transformer
Infinite Bus 0.15 0.15 0.05
Line 0.20 0.20 0.40
With both generators and infinite bus operating at 1.0 pu voltage on no load, a line-to-ground fault occurs
at one of the terminals of the star-connected winding of the transformer A.
Calculate the currents flowing in the fault.
[-j6.74pu]
Q3. For a power system shown in figure below, find the fault current at point F for a SLG type of fault,
assuming that the pre- fault current in the circuit is zero :
The rating of the components are:
machines(generator as well as motor) : 1200KVA, 600V, X1 = X2 = 10% and X0 = 5%
Transformers : 1200 KVA, 600/3300V and leakage reactance is 5%](https://image.slidesharecdn.com/questionsunit4-130406084039-phpapp01/85/Questions-unit4-1-320.jpg)
![Transmission lines : Reactance is 20% on a base of 1200KVA and 3300V
Q4. Determine the fault current, the bus voltages and the line currents during the fault when a 3φ fault
occurs with a fault impedance of Z f = j0.16 pu. The negative sequence reactance is same as positive
sequence reactance mentioned in the diagram, the zero sequence reactance is 5% and neutral
reactance is 4% for both the machines.
Q5. For the power system shown in the figure, there is a DLG fault at the point F. Calculate the fault
current by taking a base of 100MVA and 11KV in the generator circuit. Rating of generator is
100MVA, 11KV, X1=20%, X2=15% and X0=10%.the voltage at the load point is 60KV prior to the fault.
The neutral reactance of the generator is 5% on its rating.
.
