The document discusses electrochemical energy storage and its importance for alternative energy applications. It outlines some key challenges with energy storage, including the need for devices with high power and energy capabilities, long life, fast charging, and portability. The author proposes using hybrid energy storage systems that integrate multiple device types to optimize performance for different applications and timescales. The remainder of the document focuses on lithium-ion battery limitations and using mechanical models to understand capacity fade through stresses induced during operation.
