Description Data Science and ML development bring many new complexities beyond the traditional software development lifecycle. Unlike in traditional software development, ML developers want to try multiple algorithms, tools, and parameters to get the best results, and they need to track this information to reproduce work. MLflow addresses some of these challenges during an ML model development cycle. Abstract ML development brings many new complexities beyond the traditional software development lifecycle. Unlike in traditional software development, ML developers want to try multiple algorithms, tools, and parameters to get the best results, and they need to track this information to reproduce work. In addition, developers need to use many distinct systems to productionize models. To address these problems, many companies are building custom “ML platforms” that automate this lifecycle, but even these platforms are limited to a few supported algorithms and to each company’s internal infrastructure. In this session, we introduce MLflow, a new open source project from Databricks that aims to design an open ML platform where organizations can use any ML library and development tool of their choice to reliably build and share ML applications. MLflow introduces simple abstractions to package reproducible projects, track results, and encapsulate models that can be used with many existing tools, accelerating the ML lifecycle for organizations of any size. With a short demo, you see a complete ML model life-cycle example, you will walk away with: MLflow concepts and abstractions for models, experiments, and projects How to get started with MLFlow Using tracking Python APIs during model training Using MLflow UI to visually compare and contrast experimental runs with different tuning parameters and evaluate metrics

1. : Platform for Complete
Machine Learning Lifecycle
Jules S. Damji
PyData Miami, FL
Jan 10, 2019
@2twitme

2. Apache Spark Developer & CommunityAdvocate @ Databricks
DeveloperAdvocate@ Hortonworks
Software engineering @Sun Microsystems, Netscape, @Home,
Excite@Home, VeriSign, Scalix, Centrify, LoudCloud/Opsware, ProQuest
Program Chair Spark + AI Summit
https://www.linkedin.com/in/dmatrix
@2twitme

3. Outline
Overview of ML development challenges
How MLflow tackles these
MLflow Components
Developer Experience & Demo
Ongoing Roadmap
Q & A

4. Machine Learning
Development is Complex

5. ML Lifecycle
5
Delta
Data Prep
Training
Deploy
Raw Data
μ
λ θ Tuning
Scale
μ
λ θ Tuning
Scale
Scale
Scale
Model
Exchange
Governance

6. “I build 100s of models/day to lift revenue, using any library:
MLlib, PyTorch, R, etc. There’s no easy way to see what data
went in a model from a week ago, tune it and rebuild it.”
-- Chief scientist at ad tech firm
Example

7. Custom ML Platforms
Facebook FBLearner, Uber Michelangelo, Google TFX
+Standardize the data prep / training / deploy loop:
if you work with the platform, you get these!
–Limited to a few algorithms or frameworks
–Tied to one company’s infrastructure
–Out of luck if you left the company….
Can we provide similar benefits in an open manner?

8. Introducing
Open machine learningplatform
• Works with any ML library& language
• Runs the same wayanywhere (e.g., anycloud)
• Designed to be useful for 1 or 1000+ person orgs
• Simple, Easy-to-use, Developer Experience, and get started!

9. MLflow Design Philosophy
1. “API-first”, open platform
• Allow submittingruns,models,etc from anylibrary & language
• Example: a “model” can justbe a lambdafunction thatMLflow
can thendeploy in many places (Docker, AzureML, Spark UDF, …)
Key enabler: built aroundREST APIs and CLI

10. MLflow Design Philosophy
2. Modular design
• Let people use different components individually(e.g.,use
MLflow’s project format but not its deployment tools)
• Not monolithic, Distinctiveand Selective
Key enabler: distinct components (Tracking/Projects/Models)

11. MLflow Components
11
Tracking
Record and query
experiments: code,
configs, results,
…etc
Projects
Packaging format
for reproducible
runs
on any platform
Models
General model format
that supports diverse
deployment tools

12. Model Development without MLflow
data = load_text(file)
ngrams = extract_ngrams(data, N=n)
model = train_model(ngrams,
learning_rate=lr)
score = compute_accuracy(model)
print(“For n=%d, lr=%f: accuracy=%f”
% (n, lr, score))
pickle.dump(model, open(“model.pkl”))
For n=2, lr=0.1: accuracy=0.71
For n=2, lr=0.2: accuracy=0.79
For n=2, lr=0.5: accuracy=0.83
For n=2, lr=0.9: accuracy=0.79
For n=3, lr=0.1: accuracy=0.83
For n=3, lr=0.2: accuracy=0.82
For n=4, lr=0.5: accuracy=0.75
...
What if I expand
the input data?
What if I tune this
other parameter?
What if I upgrade
my ML library?
What version of
my code was this
result from?

13. Key Concepts in Tracking
Parameters: key-value inputs to your code
Metrics: numeric values (can update over time)
Tags and Notes: information about a run
Artifacts: files, data and models
Source: what code ran?
Version: what of the code?

14. MLflow Tracking API: Simple!
14
Tracking
Record and query
experiments: code,
configs, results,
…etc
import mlflow
# log model’s tuning parameters
with mlflow.start_run():
mlflow.log_param("layers", layers)
mlflow.log_param("alpha", alpha)
# log model’s metrics
mlflow.log_metric("mse", model.mse())
mlflow.log_artifact("plot", model.plot(test_df))
mlflow.tensorflow.log_model(model)

15. $ mlflow ui
Model Development with MLflow is Simple!
data = load_text(file)
ngrams = extract_ngrams(data, N=n)
model = train_model(ngrams,
learning_rate=lr)
score = compute_accuracy(model)
mlflow.log_param(“data_file”, file)
mlflow.log_param(“n”, n)
mlflow.log_param(“learning_rate”, lr)
mlflow.log_metric(“score”, score)
mlflow.sklearn.log_model(model)
Track parameters, metrics,
output files & code version
Search using UI or API

16. Notebooks
LocalApps
CloudJobs
Tracking Server
UI
API
MLflow Tracking
Python,
Java, R or
REST API
$ export MLFLOW_TRACKING_URI <URI>
(http://mlflow.tracking.com/mlflow)
mlflow.set_tracking_uri(URI)

17. MLflow Projects Motivation
Diverse set of tools
Diverse set of environments
Result: It is difficult to productionize and share.
Projects
Packaging format
for reproducible
runs
on any platform

18. Project Spec
Code DataConfig
LocalExecution
Remote Execution
MLflow Projects

19. Example MLflow Project
my_project/
├── MLproject
│
│
│
│
│
├── conda.yaml
├── main.py
└── model.py
...
conda_env: conda.yaml
entry_points:
main:
parameters:
training_data: path
lambda: {type: float, default: 0.1}
command: python main.py {training_data} {lambda}
$ mlflow run git://<my_project> -P lambda=0.2
mlflow.run(“git://<my_project>”, ...)

20. ML Frameworks
InferenceCode
Batch & Stream Scoring
Serving Tools
MLflow Models
Standard for ML models
Model Format
ONNX Flavor
Python Flavor
. . .

21. Example MLflow Model
my_model/
├── MLmodel
│
│
│
│
│
└── estimator/
├── saved_model.pb
└── variables/
...
Usable by tools that understand
TensorFlowmodel format
Usable by any tool that can run
Python (Docker,Spark,etc!)
run_id: 769915006efd4c4bbd662461
time_created: 2018-06-28T12:34
flavors:
tensorflow:
saved_model_dir: estimator
signature_def_key: predict
python_function:
loader_module: mlflow.tensorflow
>>> mlflow.tensorflow.log_model(...)

22. Developer Experience &
Demo
Binary Classification of
IMDB Movie Reviews Using
Keras Neural Network Model
https://dbricks.co/keras_imdb
https://github.com/dmatrix/jsd-mlflow-examples/
+

23. 23
Model Units Epochs Loss Function Hidden
Layers
Base 16 20 binary_crosstropy 1
Experiment-1 32 30 binary_crosstropy 3
Experiment-2 32 20 mse 3
MLflow Baseline & Experiment Models

24. 24
MLflow Baseline & Experiment Models
.0.1
.1.0

25. Ongoing MLflow Roadmap
• TensorFlow, Keras, PyTorch, H2O, MLleap, MLlib integrations ✔
• Java and R MLflow Client language APIs ✔
• Multi-step workflows ✔
• Hyperparameter tuning ✔
• Integration with Databricks Tracking Server ✔
• Support for Data Store (e.g., MySQL) ✔
• Stabilize Mlflow APIs 1.0
• Model metadata & management & registry
• Hosted MLflow
Just released v8.0.1
• Faster & Improved UI
• Extended Python Model
as Spark UDF
• Persist model
dependencies as Conda
Environment

26. Learning More About MLflow
• pip install mlflow to get started
• Find docs & examples at mlflow.org
• https://github.com/mlflow/mlflow
• tinyurl.com/mlflow-slack
• https://dbricks.co/mlflow-survey2019
26

27. What Did We Talk About?
Workflow tools can greatly simplifythe ML lifecycle
• Simplify lifecycle development
• Lightweight, open platform that integrates easily
• Available APIs: Python, Java & R
• Easy to install and use
• Develop locally and track locally or remotely
• Deploy locally, cloud, on premise…
• Visualize experiments

28. 15% Discount Code: PyDataMiami

29. Thank You J
jules@databricks.com
@2twitme
https://www.linkedin.com/in/dmatrix/
