A singly linked list is a data structure consisting of nodes where each node stores an element and a link to the next node. The document describes algorithms for inserting nodes at the head, tail, and between two nodes of a singly linked list. It also describes doubly linked lists which allow traversing the list in both directions by including a link to the previous node as well as the next node in each node. Linked lists are useful when the number of elements is unknown or varies, and for operations like inserting or removing elements in the middle of the list without shifting other elements.

3. data next
A singly linked list is a concrete data
structure consisting of a sequence of
nodes.
Each node stores:-
element
link to the next node
struct Node
{ int item
Node *next;
};

4. Inserting at the Head
1. Allocate a new
node
2. Insert new
element
3. Make new node
point to old
head
4. Update head to
point to new
node
void insertLL(Struct Node
*newNode)
{
if (newNode == NULL)
return;
else {
if (head == NULL) {
newNode->next = NULL;
head = newNode;
tail = newNode;
}
else {
newNode->next = head;
head = newNode;
}
}
}

5. Inserting at the Head

6. Update the next link of a new node, to
point to the current head node.

7. Update head link to point to the new
node.

8. Removing at the Head
void removeFirst()
{
if (head == NULL)
return;
else {
Struct Node *removedNode;
removedNode = head;
if (head == tail) {
head = NULL;
tail = NULL;
} else {
head = head->next;
}
delete removedNode;
}
}
1. Update head to
point to next node
in the list
2. Allow garbage
collector to reclaim
the former first
node

9. Update head link to point to the node,
next to the head.

10. Dispose removed node.

12. void insert(Struct Node*newNode)
{
if (newNode == NULL)
return;
else {
newNode->next = NULL;
if (head == NULL) {
head = newNode;
tail = newNode;
} else {
tail->next = newNode;
tail = newNode;
}
}
}
1. Allocate a new
node
2. Insert new element
3. Have new node
point to null
4. Have old last node
point to new node
5. Update tail to point
to new node
Inserting at the Tail

13. Update the next link of the current tail
node, to point to the new node.

14. Update tail link to point to the new
node

15. Insertion between two nodes
New node is always inserted between two nodes, which
are already in the list. Head and tail links are not updated
in this case.

16. Update link of the "previous" node,
to point to the new node.

17. Update link of the new node, to
point to the "next" node.

18.  It is a way of going both directions in a
linked list, forward and reverse.
 Many applications require a quick access
to the predecessor node of some node in
list.
Doubly-Linked Lists
prevnext

19. Algorithm addFirst(v):
w = header.getNext() // the
current first node
v.setNext(w)
w.setPrev(v)
header.setNext(v)
v.setPrev(header)
size++

20. Algorithm removeLast():
v = trailer.getPrev() // the
current last node
if (v = = header) then
Indicate an error: the list
is empty
prev = v.getPrev()
prev.setNext(trailer)
trailer.setPrev(prev)
v.setPrev(null)
v.setNext(null)
size--

21. •If programming in C, there are no “grow able-arrays”, so
typically linked lists used when# elements in a collection
varies, isn’t known, can’t be fixed at compile time
Could grow array, potentially expensive/wasteful especially if #
elements is small.
Also need# elements in array, requires extra parameter
With linked list, one pointer used to access all the elements in a
collection
•Simulation/modelling of DNA gene-splicing
Given list of millions of CGTA... for DNA strand, find locations where
new DNA/gene can be spliced

22. •Remove element from middle of a collection,
maintain order, no shifting. Add an element in the
middle, no shifting
What’s the problem with a vector (array)?
Emacs visits several files, internally keeps a linked-list of
buffers
Naively keep characters in a linked list, but in practice too much storage,
 need more esoteric data structures
•What’s (3x5+ 2x3+ x + 5) + (2x4+ 5x3+ x2+4x) ?
As a vector (3, 0, 2, 0, 1, 5)and (0, 2, 5, 1, 4, 0)
As a list ((3,5), (2,3), (1,1), (5,0))and ________?
Most polynomial operations sequentially visit terms, don’t need random
access, do need “splicing”
