The document introduces the concept of moment of a force. It defines moment as a measure of the tendency of a force to cause rotation about a point or axis. It provides methods to calculate the moment of a force in 2D and 3D, including using the cross product and right hand rule. Examples are given to find the moment of individual forces and the resultant moment of a system of forces about a point.
