Indexing and searching NuGet.org
with Azure Functions and Search
Maarten Balliauw
@maartenballiauw
STRATEGICSPONSORS
GOLDSPONSORS
Agenda
“Find this type on NuGet.org”
NuGet server-side API
Building a new version using Azure Functions
“Find this type on NuGet.org”
“Find this type on NuGet.org”
In ReSharper and Rider
Search for namespaces
& types that are not yet referenced
“Find this type on NuGet.org”
Idea in 2013, introduced in ReSharper 9
(2015 - https://www.jetbrains.com/resharper/whatsnew/whatsnew_9.html)
Consists of
ReSharper functionality
A service that indexes packages and powers search
Azure Cloud Service (Web and Worker role)
Indexer uses NuGet OData feed
https://www.nuget.org/api/v2/Packages?$select=Id,Version,NormalizedVersion,LastEdited,Published&$
orderby=LastEdited%20desc&$filter=LastEdited%20gt%20datetime%272012-01-01%27
NuGet over time...
https://twitter.com/controlflow/status/1067724815958777856
NuGet over time...
Repo-signing announced August 10, 2018
Big chunk of packages signed
over holidays 2018/2019
Re-download all metadata & binaries
Very slow over Odata
Is there a better way?
https://blog.nuget.org/20180810/Introducing-Repository-Signatures.html
NuGet server-side API
NuGet talks to a repository
Can be on disk/network share or remote over HTTP(S)
HTTP(S) API’s
V2 – OData based (used by pretty much all NuGet servers out there)
V3 – JSON based (available on NuGet.org, TeamCity, MyGet.org, Azure DevOps)
V2 Protocol
Started as “OData-to-LINQ-to-Entities” (V1 protocol)
Optimizations added to reduce # of random DB queries (VS2013+ & NuGet 2.x)
Search – Package manager list/search
FindPackagesById – Package restore (Does it exist? Where to download?)
GetUpdates – Package manager updates
https://www.nuget.org/api/v2 (code in https://github.com/NuGet/NuGetGallery)
V3 Protocol
JSON based
A “resource provider” of various endpoints per purpose
Catalog (NuGet.org only) – append-only event log
Registrations – materialization of newest state of a package
Flat container – .NET Core package restore (and VS autocompletion)
Report abuse URL template
Statistics
…
https://api.nuget.org/v3/index.json (code in https://github.com/NuGet/NuGet.Services.Metadata)
How does NuGet.org work?
User uploads to NuGet.org
Data added to database
Data added to catalog (append-only data stream)
Various jobs run over catalog using a cursor
Registrations (last state of a package/version), reference catalog entry
Flatcontainer (fast restores)
Search index (search, autocomplete, NuGet Gallery search)
…
Catalog seems interesting!
Append-only stream of mutations on NuGet.org
Updates (add/update) and Deletes
Chronological
Can continue where left off (uses a timestamp cursor)
Can restore NuGet.org to a given point in time
Structure
Root https://api.nuget.org/v3/catalog0/index.json
+ Page https://api.nuget.org/v3/catalog0/page0.json
+ Leaf https://api.nuget.org/v3/catalog0/data/2015.02.01.06.22.45/adam.jsgenerator.1.1.0.json
NuGet.org catalog
demo
“Find this type on NuGet.org”
Refactor from using OData to using V3?
Mostly done, one thing missing: download counts (using search now)
https://github.com/NuGet/NuGetGallery/issues/3532
Build a new version?
Welcome to this talk 
Building a new version
What do we need?
Watch the NuGet.org catalog for package changes
For every package change
Scan all assemblies
Store relation between package id+version and namespace+type
API that is compatible with all ReSharper and Rider version
Bonus points!
Easy way to re-index later (copy .nupkg binaries + dump index to JSON blobs)
What do we need?
Watch the NuGet.org catalog for package changes periodic check
For every package change based on a queue
Scan all assemblies
Store relation between package id+version and namespace+type
API that is compatible with all ReSharper and Rider version always up, flexible scale
Bonus points!
Easy way to re-index later (copy .nupkg binaries + dump index to JSON blobs)
Sounds like functions?
Sounds like functions!
NuGet.org catalog Watch catalog
Index command
Find type API
Find namespace API
Search index
Index package
Raw .nupkg
Index as JSON
Download packageDownload command
Collecting from catalog
demo
Functions best practices
https://medium.com/@PaulDJohnston/serverless-best-practices-b3c97d551535
Each function should do only one thing (“it depends”)
Easier error handling & scaling
Functions don’t call other functions
Avoid coupling
Use as few libraries in your functions as possible (preferably zero)
Slower cold starts with more dependencies
Learn to use messages and queues
Asynchronous means of communicating, helps scale
...
Collecting from catalog
(better version)
demo
Bindings
Help a function do only one thing
Trigger, provide input/output
Function code bridges those
Build your own!*
SQL Server binding
Dropbox binding
...
NuGet Catalog
*Custom triggers not officially supported (yet?)
Trigger Input Output
Timer ✔
HTTP ✔ ✔
Blob ✔ ✔ ✔
Queue ✔ ✔
Table ✔ ✔
Service Bus ✔ ✔
EventHub ✔ ✔
EventGrid ✔
CosmosDB ✔ ✔ ✔
IoT Hub ✔
SendGrid, Twilio ✔
... ✔
Creating a trigger
binding
demo
We’re making progress!
NuGet.org catalog Watch catalog
Index command
Find type API
Find namespace API
Search index
Index package
Raw .nupkg
Index as JSON
Download packageDownload command
Downloading packages
demo
Next up: indexing
NuGet.org catalog Watch catalog
Index command
Find type API
Find namespace API
Search index
Index package
Raw .nupkg
Index as JSON
Download packageDownload command
Indexing
Opening up the .nupkg and reflecting on assemblies
System.Reflection.Metadata
Does not load the assembly being reflected into application process
Provides access to Portable Executable (PE) metadata in assembly
Store relation between package id+version and namespace+type
Azure Search? A database? Redis? Other?
System.Reflection.Metadata Free decompiler
www.jetbrains.com/dotpeek
System.Reflection.Metadata
using (var portableExecutableReader = new PEReader(assemblySeekableStream))
{
var metadataReader = portableExecutableReader.GetMetadataReader();
foreach (var typeDefinition in metadataReader.TypeDefinitions.Select(metadataReader
.GetTypeDefinition))
{
if (!typeDefinition.Attributes.HasFlag(TypeAttributes.Public)) continue;
var typeNamespace = metadataReader.GetString(typeDefinition.Namespace);
var typeName = metadataReader.GetString(typeDefinition.Name);
if (typeName.StartsWith("<") || typeName.StartsWith("__Static") ||
typeName.Contains("c__DisplayClass")) continue;
typeNames.Add($"{typeNamespace}.{typeName}");
}
}
Azure Search
“Search-as-a-Service”
Scales across partitions and replicas
Define an index that will hold documents consisting of fields
Fields can be searchable, facetable, filterable, sortable, retrievable
Can’t be changed easily, think upfront!
Have to define what we want to search, and what we want to display
My function will also write documents to a JSON blob
Can re-index using Azure Search importer in case needed
Indexing packages
demo
“Do one thing well”
Our function shouldn’t care about creating a search index.
Better: return index operations, have something else handle those
Custom output binding?
Indexing packages
(better version)
demo
Almost there…
NuGet.org catalog Watch catalog
Index command
Find type API
Find namespace API
Search index
Index package
Raw .nupkg
Index as JSON
Download packageDownload command
HTTP trigger binding
[HttpTrigger(AuthorizationLevel.Anonymous,
"get", Route = "v1/find-type")] HttpRequest request
Options for trigger
Authentication (anonymous, a function/host key, a user token)
HTTP method
What the route looks like
Making search work
with ReSharper and Rider
demo
One issue left...
Download counts - used for sorting and scoring search results
Change continuously on NuGet
Not part of V3 catalog
Could use search but that’s N(packages) queries
https://github.com/NuGet/NuGetGallery/issues/3532
If that data existed, how to update search?
Merge data! new PackageDocumentDownloads(key, downloadcount)
We’re done!
NuGet.org catalog Watch catalog
Index command
Find type API
Find namespace API
Search index
Index package
Raw .nupkg
Index as JSON
Download packageDownload command
We’re done!
Functions
Collect changes from NuGet catalog
Download binaries
Index binaries using PE Header
Make search index available in API
Trigger, input and output bindings
Each function should do only one thing
NuGet.org catalog Watch catalog
Index command
Find type API
Find namespace API
Search index
Index package
Raw .nupkg
Index as JSON
Download packageDownload command
We’re done!
All our functions can scale (and fail)
independently
Full index in May 2019 took ~12h on 2 B1 instances
Can be faster on more CPU’s
~ 1.7mio packages (NuGet.org homepage says)
~ 2.1mio packages (the catalog says )
~ 8 400 catalog pages
with ~ 4 200 000 catalog leaves
(hint: repo signing)
NuGet.org catalog Watch catalog
Index command
Find type API
Find namespace API
Search index
Index package
Raw .nupkg
Index as JSON
Download packageDownload command
Closing thoughts…
Would deploy in separate function apps for cost
Trigger binding collects all the time so needs dedicated capacity (and thus, cost)
Others can scale within bounds (think of $$$)
Would deploy in separate function apps for failure boundaries
Trigger, indexing, downloading should not affect health of API
Are bindings portable...?
Avoid them if lock-in matters to you
Please rate this session using
Event Master
Mobile App
at the booth
in Lobby
login.developerdays.pl
STRATEGIC SPONSORS
GOLD SPONSORS
Thank you!
https://blog.maartenballiauw.be
@maartenballiauw

More Related Content

What's hot

Introduction to ELK
Introduction to ELKIntroduction to ELK
Introduction to ELK
Harshakumar Ummerpillai

Elk stack
Elk stackElk stack
Elk stack
Jilles van Gurp

Logstash + Elasticsearch + Kibana Presentation on Startit Tech Meetup
Logstash + Elasticsearch + Kibana Presentation on Startit Tech MeetupLogstash + Elasticsearch + Kibana Presentation on Startit Tech Meetup
Logstash + Elasticsearch + Kibana Presentation on Startit Tech Meetup
Startit

Machine Learning in a Twitter ETL using ELK
Machine Learning in a Twitter ETL using ELK Machine Learning in a Twitter ETL using ELK
Machine Learning in a Twitter ETL using ELK
hypto

Logstash-Elasticsearch-Kibana
Logstash-Elasticsearch-KibanaLogstash-Elasticsearch-Kibana
Logstash-Elasticsearch-Kibana
dknx01

Elk
Elk Elk
Distributed Eventing in OSGi - Carsten Ziegeler
Distributed Eventing in OSGi - Carsten ZiegelerDistributed Eventing in OSGi - Carsten Ziegeler
Distributed Eventing in OSGi - Carsten Ziegeler
mfrancis

Spark with Elasticsearch
Spark with ElasticsearchSpark with Elasticsearch
Spark with Elasticsearch
Holden Karau

Logstash
LogstashLogstash
Logstash
琛琳 饶

Reactive Functional Programming with Java 8 on Android N
Reactive Functional Programming with Java 8 on Android NReactive Functional Programming with Java 8 on Android N
Reactive Functional Programming with Java 8 on Android N
Shipeng Xu

Monitoring with Graylog - a modern approach to monitoring?
Monitoring with Graylog - a modern approach to monitoring?Monitoring with Graylog - a modern approach to monitoring?
Monitoring with Graylog - a modern approach to monitoring?
inovex GmbH

Large Scale Log Analytics with Solr (from Lucene Revolution 2015)
Large Scale Log Analytics with Solr (from Lucene Revolution 2015)Large Scale Log Analytics with Solr (from Lucene Revolution 2015)
Large Scale Log Analytics with Solr (from Lucene Revolution 2015)
Sematext Group, Inc.

Elastic - ELK, Logstash & Kibana
Elastic - ELK, Logstash & KibanaElastic - ELK, Logstash & Kibana
Elastic - ELK, Logstash & Kibana
SpringPeople

Building Your First App with Shawn Mcarthy
Building Your First App with Shawn Mcarthy Building Your First App with Shawn Mcarthy
Building Your First App with Shawn Mcarthy
MongoDB

LogStash in action
LogStash in actionLogStash in action
LogStash in action
Manuj Aggarwal

Experiences in ELK with D3.js for Large Log Analysis and Visualization
Experiences in ELK with D3.js  for Large Log Analysis  and VisualizationExperiences in ELK with D3.js  for Large Log Analysis  and Visualization
Experiences in ELK with D3.js for Large Log Analysis and Visualization
Surasak Sanguanpong

Rest application
Rest applicationRest application
Rest application
Illia Seleznov

Hacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech Talk
Hacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech TalkHacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech Talk
Hacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech Talk
Red Hat Developers

Side by Side with Elasticsearch and Solr
Side by Side with Elasticsearch and SolrSide by Side with Elasticsearch and Solr
Side by Side with Elasticsearch and Solr
Sematext Group, Inc.

Spark with Elasticsearch - umd version 2014
Spark with Elasticsearch - umd version 2014Spark with Elasticsearch - umd version 2014
Spark with Elasticsearch - umd version 2014
Holden Karau


What's hot (20)

Introduction to ELK
Introduction to ELKIntroduction to ELK
Introduction to ELK

Elk stack
Elk stackElk stack
Elk stack

Logstash + Elasticsearch + Kibana Presentation on Startit Tech Meetup
Logstash + Elasticsearch + Kibana Presentation on Startit Tech MeetupLogstash + Elasticsearch + Kibana Presentation on Startit Tech Meetup
Logstash + Elasticsearch + Kibana Presentation on Startit Tech Meetup

Machine Learning in a Twitter ETL using ELK
Machine Learning in a Twitter ETL using ELK Machine Learning in a Twitter ETL using ELK
Machine Learning in a Twitter ETL using ELK

Logstash-Elasticsearch-Kibana
Logstash-Elasticsearch-KibanaLogstash-Elasticsearch-Kibana
Logstash-Elasticsearch-Kibana

Elk
Elk Elk
Elk

Distributed Eventing in OSGi - Carsten Ziegeler
Distributed Eventing in OSGi - Carsten ZiegelerDistributed Eventing in OSGi - Carsten Ziegeler
Distributed Eventing in OSGi - Carsten Ziegeler

Spark with Elasticsearch
Spark with ElasticsearchSpark with Elasticsearch
Spark with Elasticsearch

Logstash
LogstashLogstash
Logstash

Reactive Functional Programming with Java 8 on Android N
Reactive Functional Programming with Java 8 on Android NReactive Functional Programming with Java 8 on Android N
Reactive Functional Programming with Java 8 on Android N

Monitoring with Graylog - a modern approach to monitoring?
Monitoring with Graylog - a modern approach to monitoring?Monitoring with Graylog - a modern approach to monitoring?
Monitoring with Graylog - a modern approach to monitoring?

Large Scale Log Analytics with Solr (from Lucene Revolution 2015)
Large Scale Log Analytics with Solr (from Lucene Revolution 2015)Large Scale Log Analytics with Solr (from Lucene Revolution 2015)
Large Scale Log Analytics with Solr (from Lucene Revolution 2015)

Elastic - ELK, Logstash & Kibana
Elastic - ELK, Logstash & KibanaElastic - ELK, Logstash & Kibana
Elastic - ELK, Logstash & Kibana

Building Your First App with Shawn Mcarthy
Building Your First App with Shawn Mcarthy Building Your First App with Shawn Mcarthy
Building Your First App with Shawn Mcarthy

LogStash in action
LogStash in actionLogStash in action
LogStash in action

Experiences in ELK with D3.js for Large Log Analysis and Visualization
Experiences in ELK with D3.js  for Large Log Analysis  and VisualizationExperiences in ELK with D3.js  for Large Log Analysis  and Visualization
Experiences in ELK with D3.js for Large Log Analysis and Visualization

Rest application
Rest applicationRest application
Rest application

Hacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech Talk
Hacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech TalkHacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech Talk
Hacking the Mesh: Extending Istio with WebAssembly Modules | DevNation Tech Talk

Side by Side with Elasticsearch and Solr
Side by Side with Elasticsearch and SolrSide by Side with Elasticsearch and Solr
Side by Side with Elasticsearch and Solr

Spark with Elasticsearch - umd version 2014
Spark with Elasticsearch - umd version 2014Spark with Elasticsearch - umd version 2014
Spark with Elasticsearch - umd version 2014


Similar to Indexing and searching NuGet.org with Azure Functions and Search - Cloud Developer Days Poland

Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Maarten Balliauw

Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...
Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...
Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...
Fwdays

.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se....NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
Maarten Balliauw

ConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello WorldConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello World
Maarten Balliauw

NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017
Maarten Balliauw

Let's build Developer Portal with Backstage
Let's build Developer Portal with BackstageLet's build Developer Portal with Backstage
Let's build Developer Portal with Backstage
Opsta

Release 8.1 - Breakfast Paris
Release 8.1 - Breakfast ParisRelease 8.1 - Breakfast Paris
Release 8.1 - Breakfast Paris
Nuxeo

Examiness hints and tips from the trenches
Examiness hints and tips from the trenchesExaminess hints and tips from the trenches
Examiness hints and tips from the trenches
Ismail Mayat

Django deployment with PaaS
Django deployment with PaaSDjango deployment with PaaS
Django deployment with PaaS
Appsembler

Building a Better BaaS
Building a Better BaaSBuilding a Better BaaS
Building a Better BaaS
Apigee | Google Cloud

Apache Calcite (a tutorial given at BOSS '21)
Apache Calcite (a tutorial given at BOSS '21)Apache Calcite (a tutorial given at BOSS '21)
Apache Calcite (a tutorial given at BOSS '21)
Julian Hyde

Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]
Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]
Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]
Udit Gangwani

China Science Challenge
China Science ChallengeChina Science Challenge
China Science Challenge
remko caprio

SgCodeJam24 Workshop
SgCodeJam24 WorkshopSgCodeJam24 Workshop
SgCodeJam24 Workshop
remko caprio

Harnessing the power of Nutch with Scala
Harnessing the power of Nutch with ScalaHarnessing the power of Nutch with Scala
Harnessing the power of Nutch with Scala
Knoldus Inc.

Akash rajguru project report sem v
Akash rajguru project report sem vAkash rajguru project report sem v
Akash rajguru project report sem v
Akash Rajguru

OGCE Project Overview
OGCE Project OverviewOGCE Project Overview
OGCE Project Overview
marpierc

Plugin-based software design with Ruby and RubyGems
Plugin-based software design with Ruby and RubyGemsPlugin-based software design with Ruby and RubyGems
Plugin-based software design with Ruby and RubyGems
Sadayuki Furuhashi

Beyond Wordcount with spark datasets (and scalaing) - Nide PDX Jan 2018
Beyond Wordcount  with spark datasets (and scalaing) - Nide PDX Jan 2018Beyond Wordcount  with spark datasets (and scalaing) - Nide PDX Jan 2018
Beyond Wordcount with spark datasets (and scalaing) - Nide PDX Jan 2018
Holden Karau

RESTful OSGi middleware for NoSQL databases with Docker
RESTful OSGi middleware for NoSQL databases with DockerRESTful OSGi middleware for NoSQL databases with Docker
RESTful OSGi middleware for NoSQL databases with Docker
Bertrand Delacretaz


Similar to Indexing and searching NuGet.org with Azure Functions and Search - Cloud Developer Days Poland (20)

Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...

Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...
Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...
Maarten Balliauw "Indexing and searching NuGet.org with Azure Functions and S...

.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se....NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...

ConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello WorldConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello World

NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017

Let's build Developer Portal with Backstage
Let's build Developer Portal with BackstageLet's build Developer Portal with Backstage
Let's build Developer Portal with Backstage

Release 8.1 - Breakfast Paris
Release 8.1 - Breakfast ParisRelease 8.1 - Breakfast Paris
Release 8.1 - Breakfast Paris

Examiness hints and tips from the trenches
Examiness hints and tips from the trenchesExaminess hints and tips from the trenches
Examiness hints and tips from the trenches

Django deployment with PaaS
Django deployment with PaaSDjango deployment with PaaS
Django deployment with PaaS

Building a Better BaaS
Building a Better BaaSBuilding a Better BaaS
Building a Better BaaS

Apache Calcite (a tutorial given at BOSS '21)
Apache Calcite (a tutorial given at BOSS '21)Apache Calcite (a tutorial given at BOSS '21)
Apache Calcite (a tutorial given at BOSS '21)

Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]
Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]
Django apps and ORM Beyond the basics [Meetup hosted by Prodeers.com]

China Science Challenge
China Science ChallengeChina Science Challenge
China Science Challenge

SgCodeJam24 Workshop
SgCodeJam24 WorkshopSgCodeJam24 Workshop
SgCodeJam24 Workshop

Harnessing the power of Nutch with Scala
Harnessing the power of Nutch with ScalaHarnessing the power of Nutch with Scala
Harnessing the power of Nutch with Scala

Akash rajguru project report sem v
Akash rajguru project report sem vAkash rajguru project report sem v
Akash rajguru project report sem v

OGCE Project Overview
OGCE Project OverviewOGCE Project Overview
OGCE Project Overview

Plugin-based software design with Ruby and RubyGems
Plugin-based software design with Ruby and RubyGemsPlugin-based software design with Ruby and RubyGems
Plugin-based software design with Ruby and RubyGems

Beyond Wordcount with spark datasets (and scalaing) - Nide PDX Jan 2018
Beyond Wordcount  with spark datasets (and scalaing) - Nide PDX Jan 2018Beyond Wordcount  with spark datasets (and scalaing) - Nide PDX Jan 2018
Beyond Wordcount with spark datasets (and scalaing) - Nide PDX Jan 2018

RESTful OSGi middleware for NoSQL databases with Docker
RESTful OSGi middleware for NoSQL databases with DockerRESTful OSGi middleware for NoSQL databases with Docker
RESTful OSGi middleware for NoSQL databases with Docker


More from Maarten Balliauw

Bringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptxBringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptx
Maarten Balliauw

Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Maarten Balliauw

Building a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to SpaceBuilding a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to Space
Maarten Balliauw

Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Maarten Balliauw

NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
Maarten Balliauw

JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
Maarten Balliauw

Approaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days PolandApproaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days Poland
Maarten Balliauw

Approaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologneApproaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologne
Maarten Balliauw

CodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory laneCodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory lane
Maarten Balliauw

ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
Maarten Balliauw

ConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttlingConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttling
Maarten Balliauw

Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Maarten Balliauw

JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
Maarten Balliauw

DotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NETDotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NET
Maarten Balliauw

VISUG - Approaches for application request throttling
VISUG - Approaches for application request throttlingVISUG - Approaches for application request throttling
VISUG - Approaches for application request throttling
Maarten Balliauw

What is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays FinlandWhat is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays Finland
Maarten Balliauw

ConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory laneConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory lane
Maarten Balliauw

Approaches to application request throttling
Approaches to application request throttlingApproaches to application request throttling
Approaches to application request throttling
Maarten Balliauw

Exploring .NET memory management (iSense)
Exploring .NET memory management (iSense)Exploring .NET memory management (iSense)
Exploring .NET memory management (iSense)
Maarten Balliauw

Exploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinarExploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinar
Maarten Balliauw


More from Maarten Balliauw (20)

Bringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptxBringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptx

Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...

Building a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to SpaceBuilding a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to Space

Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...

NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...

JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...

Approaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days PolandApproaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days Poland

Approaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologneApproaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologne

CodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory laneCodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory lane

ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...

ConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttlingConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttling

Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...

JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...

DotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NETDotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NET

VISUG - Approaches for application request throttling
VISUG - Approaches for application request throttlingVISUG - Approaches for application request throttling
VISUG - Approaches for application request throttling

What is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays FinlandWhat is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays Finland

ConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory laneConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory lane

Approaches to application request throttling
Approaches to application request throttlingApproaches to application request throttling
Approaches to application request throttling

Exploring .NET memory management (iSense)
Exploring .NET memory management (iSense)Exploring .NET memory management (iSense)
Exploring .NET memory management (iSense)

Exploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinarExploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinar


Recently uploaded

HCL Notes and Domino License Cost Reduction in the World of DLAU
HCL Notes and Domino License Cost Reduction in the World of DLAUHCL Notes and Domino License Cost Reduction in the World of DLAU
HCL Notes and Domino License Cost Reduction in the World of DLAU
panagenda

20240607 QFM018 Elixir Reading List May 2024
20240607 QFM018 Elixir Reading List May 202420240607 QFM018 Elixir Reading List May 2024
20240607 QFM018 Elixir Reading List May 2024
Matthew Sinclair

Infrastructure Challenges in Scaling RAG with Custom AI models
Infrastructure Challenges in Scaling RAG with Custom AI modelsInfrastructure Challenges in Scaling RAG with Custom AI models
Infrastructure Challenges in Scaling RAG with Custom AI models
Zilliz

How to use Firebase Data Connect For Flutter
How to use Firebase Data Connect For FlutterHow to use Firebase Data Connect For Flutter
How to use Firebase Data Connect For Flutter
Daiki Mogmet Ito

Building Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and MilvusBuilding Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and Milvus
Zilliz

TrustArc Webinar - 2024 Global Privacy Survey
TrustArc Webinar - 2024 Global Privacy SurveyTrustArc Webinar - 2024 Global Privacy Survey
TrustArc Webinar - 2024 Global Privacy Survey
TrustArc

GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
Neo4j

RESUME BUILDER APPLICATION Project for students
RESUME BUILDER APPLICATION Project for studentsRESUME BUILDER APPLICATION Project for students
RESUME BUILDER APPLICATION Project for students
KAMESHS29

Presentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of GermanyPresentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of Germany
innovationoecd

Artificial Intelligence for XMLDevelopment
Artificial Intelligence for XMLDevelopmentArtificial Intelligence for XMLDevelopment
Artificial Intelligence for XMLDevelopment
Octavian Nadolu

GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024
Neo4j

Uni Systems Copilot event_05062024_C.Vlachos.pdf
Uni Systems Copilot event_05062024_C.Vlachos.pdfUni Systems Copilot event_05062024_C.Vlachos.pdf
Uni Systems Copilot event_05062024_C.Vlachos.pdf
Uni Systems S.M.S.A.

How to Get CNIC Information System with Paksim Ga.pptx
How to Get CNIC Information System with Paksim Ga.pptxHow to Get CNIC Information System with Paksim Ga.pptx
How to Get CNIC Information System with Paksim Ga.pptx
danishmna97

Best 20 SEO Techniques To Improve Website Visibility In SERP
Best 20 SEO Techniques To Improve Website Visibility In SERPBest 20 SEO Techniques To Improve Website Visibility In SERP
Best 20 SEO Techniques To Improve Website Visibility In SERP
Pixlogix Infotech

GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024
GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024
GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024
Neo4j

HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAUHCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
panagenda

“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...
“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...
“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...
Edge AI and Vision Alliance

Serial Arm Control in Real Time Presentation
Serial Arm Control in Real Time PresentationSerial Arm Control in Real Time Presentation
Serial Arm Control in Real Time Presentation
tolgahangng

“I’m still / I’m still / Chaining from the Block”
“I’m still / I’m still / Chaining from the Block”“I’m still / I’m still / Chaining from the Block”
“I’m still / I’m still / Chaining from the Block”
Claudio Di Ciccio

AI 101: An Introduction to the Basics and Impact of Artificial Intelligence
AI 101: An Introduction to the Basics and Impact of Artificial IntelligenceAI 101: An Introduction to the Basics and Impact of Artificial Intelligence
AI 101: An Introduction to the Basics and Impact of Artificial Intelligence
IndexBug


Recently uploaded (20)

HCL Notes and Domino License Cost Reduction in the World of DLAU
HCL Notes and Domino License Cost Reduction in the World of DLAUHCL Notes and Domino License Cost Reduction in the World of DLAU
HCL Notes and Domino License Cost Reduction in the World of DLAU

20240607 QFM018 Elixir Reading List May 2024
20240607 QFM018 Elixir Reading List May 202420240607 QFM018 Elixir Reading List May 2024
20240607 QFM018 Elixir Reading List May 2024

Infrastructure Challenges in Scaling RAG with Custom AI models
Infrastructure Challenges in Scaling RAG with Custom AI modelsInfrastructure Challenges in Scaling RAG with Custom AI models
Infrastructure Challenges in Scaling RAG with Custom AI models

How to use Firebase Data Connect For Flutter
How to use Firebase Data Connect For FlutterHow to use Firebase Data Connect For Flutter
How to use Firebase Data Connect For Flutter

Building Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and MilvusBuilding Production Ready Search Pipelines with Spark and Milvus
Building Production Ready Search Pipelines with Spark and Milvus

TrustArc Webinar - 2024 Global Privacy Survey
TrustArc Webinar - 2024 Global Privacy SurveyTrustArc Webinar - 2024 Global Privacy Survey
TrustArc Webinar - 2024 Global Privacy Survey

GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...

RESUME BUILDER APPLICATION Project for students
RESUME BUILDER APPLICATION Project for studentsRESUME BUILDER APPLICATION Project for students
RESUME BUILDER APPLICATION Project for students

Presentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of GermanyPresentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of Germany

Artificial Intelligence for XMLDevelopment
Artificial Intelligence for XMLDevelopmentArtificial Intelligence for XMLDevelopment
Artificial Intelligence for XMLDevelopment

GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024

Uni Systems Copilot event_05062024_C.Vlachos.pdf
Uni Systems Copilot event_05062024_C.Vlachos.pdfUni Systems Copilot event_05062024_C.Vlachos.pdf
Uni Systems Copilot event_05062024_C.Vlachos.pdf

How to Get CNIC Information System with Paksim Ga.pptx
How to Get CNIC Information System with Paksim Ga.pptxHow to Get CNIC Information System with Paksim Ga.pptx
How to Get CNIC Information System with Paksim Ga.pptx

Best 20 SEO Techniques To Improve Website Visibility In SERP
Best 20 SEO Techniques To Improve Website Visibility In SERPBest 20 SEO Techniques To Improve Website Visibility In SERP
Best 20 SEO Techniques To Improve Website Visibility In SERP

GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024
GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024
GraphSummit Singapore | Neo4j Product Vision & Roadmap - Q2 2024

HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAUHCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU

“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...
“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...
“Building and Scaling AI Applications with the Nx AI Manager,” a Presentation...

Serial Arm Control in Real Time Presentation
Serial Arm Control in Real Time PresentationSerial Arm Control in Real Time Presentation
Serial Arm Control in Real Time Presentation

“I’m still / I’m still / Chaining from the Block”
“I’m still / I’m still / Chaining from the Block”“I’m still / I’m still / Chaining from the Block”
“I’m still / I’m still / Chaining from the Block”

AI 101: An Introduction to the Basics and Impact of Artificial Intelligence
AI 101: An Introduction to the Basics and Impact of Artificial IntelligenceAI 101: An Introduction to the Basics and Impact of Artificial Intelligence
AI 101: An Introduction to the Basics and Impact of Artificial Intelligence


Indexing and searching NuGet.org with Azure Functions and Search - Cloud Developer Days Poland

  • 1. Indexing and searching NuGet.org with Azure Functions and Search Maarten Balliauw @maartenballiauw
  • 3. Agenda “Find this type on NuGet.org” NuGet server-side API Building a new version using Azure Functions
  • 4. “Find this type on NuGet.org”
  • 5. “Find this type on NuGet.org” In ReSharper and Rider Search for namespaces & types that are not yet referenced
  • 6. “Find this type on NuGet.org” Idea in 2013, introduced in ReSharper 9 (2015 - https://www.jetbrains.com/resharper/whatsnew/whatsnew_9.html) Consists of ReSharper functionality A service that indexes packages and powers search Azure Cloud Service (Web and Worker role) Indexer uses NuGet OData feed https://www.nuget.org/api/v2/Packages?$select=Id,Version,NormalizedVersion,LastEdited,Published&$ orderby=LastEdited%20desc&$filter=LastEdited%20gt%20datetime%272012-01-01%27
  • 8. NuGet over time... Repo-signing announced August 10, 2018 Big chunk of packages signed over holidays 2018/2019 Re-download all metadata & binaries Very slow over Odata Is there a better way? https://blog.nuget.org/20180810/Introducing-Repository-Signatures.html
  • 10. NuGet talks to a repository Can be on disk/network share or remote over HTTP(S) HTTP(S) API’s V2 – OData based (used by pretty much all NuGet servers out there) V3 – JSON based (available on NuGet.org, TeamCity, MyGet.org, Azure DevOps)
  • 11. V2 Protocol Started as “OData-to-LINQ-to-Entities” (V1 protocol) Optimizations added to reduce # of random DB queries (VS2013+ & NuGet 2.x) Search – Package manager list/search FindPackagesById – Package restore (Does it exist? Where to download?) GetUpdates – Package manager updates https://www.nuget.org/api/v2 (code in https://github.com/NuGet/NuGetGallery)
  • 12. V3 Protocol JSON based A “resource provider” of various endpoints per purpose Catalog (NuGet.org only) – append-only event log Registrations – materialization of newest state of a package Flat container – .NET Core package restore (and VS autocompletion) Report abuse URL template Statistics … https://api.nuget.org/v3/index.json (code in https://github.com/NuGet/NuGet.Services.Metadata)
  • 13. How does NuGet.org work? User uploads to NuGet.org Data added to database Data added to catalog (append-only data stream) Various jobs run over catalog using a cursor Registrations (last state of a package/version), reference catalog entry Flatcontainer (fast restores) Search index (search, autocomplete, NuGet Gallery search) …
  • 14. Catalog seems interesting! Append-only stream of mutations on NuGet.org Updates (add/update) and Deletes Chronological Can continue where left off (uses a timestamp cursor) Can restore NuGet.org to a given point in time Structure Root https://api.nuget.org/v3/catalog0/index.json + Page https://api.nuget.org/v3/catalog0/page0.json + Leaf https://api.nuget.org/v3/catalog0/data/2015.02.01.06.22.45/adam.jsgenerator.1.1.0.json
  • 16. “Find this type on NuGet.org” Refactor from using OData to using V3? Mostly done, one thing missing: download counts (using search now) https://github.com/NuGet/NuGetGallery/issues/3532 Build a new version? Welcome to this talk 
  • 17. Building a new version
  • 18. What do we need? Watch the NuGet.org catalog for package changes For every package change Scan all assemblies Store relation between package id+version and namespace+type API that is compatible with all ReSharper and Rider version Bonus points! Easy way to re-index later (copy .nupkg binaries + dump index to JSON blobs)
  • 19. What do we need? Watch the NuGet.org catalog for package changes periodic check For every package change based on a queue Scan all assemblies Store relation between package id+version and namespace+type API that is compatible with all ReSharper and Rider version always up, flexible scale Bonus points! Easy way to re-index later (copy .nupkg binaries + dump index to JSON blobs)
  • 21. Sounds like functions! NuGet.org catalog Watch catalog Index command Find type API Find namespace API Search index Index package Raw .nupkg Index as JSON Download packageDownload command
  • 23. Functions best practices https://medium.com/@PaulDJohnston/serverless-best-practices-b3c97d551535 Each function should do only one thing (“it depends”) Easier error handling & scaling Functions don’t call other functions Avoid coupling Use as few libraries in your functions as possible (preferably zero) Slower cold starts with more dependencies Learn to use messages and queues Asynchronous means of communicating, helps scale ...
  • 25. Bindings Help a function do only one thing Trigger, provide input/output Function code bridges those Build your own!* SQL Server binding Dropbox binding ... NuGet Catalog *Custom triggers not officially supported (yet?) Trigger Input Output Timer ✔ HTTP ✔ ✔ Blob ✔ ✔ ✔ Queue ✔ ✔ Table ✔ ✔ Service Bus ✔ ✔ EventHub ✔ ✔ EventGrid ✔ CosmosDB ✔ ✔ ✔ IoT Hub ✔ SendGrid, Twilio ✔ ... ✔
  • 27. We’re making progress! NuGet.org catalog Watch catalog Index command Find type API Find namespace API Search index Index package Raw .nupkg Index as JSON Download packageDownload command
  • 29. Next up: indexing NuGet.org catalog Watch catalog Index command Find type API Find namespace API Search index Index package Raw .nupkg Index as JSON Download packageDownload command
  • 30. Indexing Opening up the .nupkg and reflecting on assemblies System.Reflection.Metadata Does not load the assembly being reflected into application process Provides access to Portable Executable (PE) metadata in assembly Store relation between package id+version and namespace+type Azure Search? A database? Redis? Other?
  • 32. System.Reflection.Metadata using (var portableExecutableReader = new PEReader(assemblySeekableStream)) { var metadataReader = portableExecutableReader.GetMetadataReader(); foreach (var typeDefinition in metadataReader.TypeDefinitions.Select(metadataReader .GetTypeDefinition)) { if (!typeDefinition.Attributes.HasFlag(TypeAttributes.Public)) continue; var typeNamespace = metadataReader.GetString(typeDefinition.Namespace); var typeName = metadataReader.GetString(typeDefinition.Name); if (typeName.StartsWith("<") || typeName.StartsWith("__Static") || typeName.Contains("c__DisplayClass")) continue; typeNames.Add($"{typeNamespace}.{typeName}"); } }
  • 33. Azure Search “Search-as-a-Service” Scales across partitions and replicas Define an index that will hold documents consisting of fields Fields can be searchable, facetable, filterable, sortable, retrievable Can’t be changed easily, think upfront! Have to define what we want to search, and what we want to display My function will also write documents to a JSON blob Can re-index using Azure Search importer in case needed
  • 35. “Do one thing well” Our function shouldn’t care about creating a search index. Better: return index operations, have something else handle those Custom output binding?
  • 37. Almost there… NuGet.org catalog Watch catalog Index command Find type API Find namespace API Search index Index package Raw .nupkg Index as JSON Download packageDownload command
  • 38. HTTP trigger binding [HttpTrigger(AuthorizationLevel.Anonymous, "get", Route = "v1/find-type")] HttpRequest request Options for trigger Authentication (anonymous, a function/host key, a user token) HTTP method What the route looks like
  • 39. Making search work with ReSharper and Rider demo
  • 40. One issue left... Download counts - used for sorting and scoring search results Change continuously on NuGet Not part of V3 catalog Could use search but that’s N(packages) queries https://github.com/NuGet/NuGetGallery/issues/3532 If that data existed, how to update search? Merge data! new PackageDocumentDownloads(key, downloadcount)
  • 41. We’re done! NuGet.org catalog Watch catalog Index command Find type API Find namespace API Search index Index package Raw .nupkg Index as JSON Download packageDownload command
  • 42. We’re done! Functions Collect changes from NuGet catalog Download binaries Index binaries using PE Header Make search index available in API Trigger, input and output bindings Each function should do only one thing NuGet.org catalog Watch catalog Index command Find type API Find namespace API Search index Index package Raw .nupkg Index as JSON Download packageDownload command
  • 43. We’re done! All our functions can scale (and fail) independently Full index in May 2019 took ~12h on 2 B1 instances Can be faster on more CPU’s ~ 1.7mio packages (NuGet.org homepage says) ~ 2.1mio packages (the catalog says ) ~ 8 400 catalog pages with ~ 4 200 000 catalog leaves (hint: repo signing) NuGet.org catalog Watch catalog Index command Find type API Find namespace API Search index Index package Raw .nupkg Index as JSON Download packageDownload command
  • 44. Closing thoughts… Would deploy in separate function apps for cost Trigger binding collects all the time so needs dedicated capacity (and thus, cost) Others can scale within bounds (think of $$$) Would deploy in separate function apps for failure boundaries Trigger, indexing, downloading should not affect health of API Are bindings portable...? Avoid them if lock-in matters to you
  • 45. Please rate this session using Event Master Mobile App at the booth in Lobby login.developerdays.pl

Editor's Notes

  1. Show feature in action in Visual Studio (and show you can see basic metadata etc.)
  2. Copied in 2017 in VS - https://www.hanselman.com/blog/VisualStudio2017CanAutomaticallyRecommendNuGetPackagesForUnknownTypes.aspx Demo the feed quickly?
  3. Around 3 TB in May 2019
  4. Demo ODataDump quickly
  5. Demo: click around in the API to show some base things
  6. Raw API - click around in the API to show some base things, explain how a cursor could go over it Root https://api.nuget.org/v3/catalog0/index.json Page https://api.nuget.org/v3/catalog0/page0.json Leaf https://api.nuget.org/v3/catalog0/data/2015.02.01.06.22.45/adam.jsgenerator.1.1.0.json Explain CatalogDump NuGet.Protocol.Catalog comes from GitHub CatalogProcessor feches all pages between min and max timestamp My implementation BatchCatalogProcessor fetches multiple pages at the same time and build a “latest state” – much faster! Fetches leaves, for every leaf calls into a simple method Much faster, easy to pause (keep track of min/max timestamp)
  7. LOL input, process, output More serious: events trigger code Periodic check for packages Queue message to index things API request runs a search No server management or capacity planning
  8. Will use storage queues n demo’s to be able to run things locally. Ideally use SB topics or event grid (transactional)
  9. Create a new TimerTrigger function We will need a function to index things from NuGet Timer will trigger every X amount of time Timer provides last timestamp and next timestamp, so we can run our collector for that period Snippet: demo-timertrigger Mention HttpClient not used correctly: not disposed, so will starve TCP connections at some point Go over code example and run it var httpClient = new HttpClient(); var cursor = new InMemoryCursor(timer.ScheduleStatus?.Last ?? DateTimeOffset.UtcNow); var processor = new CatalogProcessor( cursor, new CatalogClient(httpClient, new NullLogger<CatalogClient>()), new DelegatingCatalogLeafProcessor( added => { log.LogInformation("[ADDED] " + added.PackageId + "@" + added.PackageVersion); return Task.FromResult(true); }, deleted => { log.LogInformation("[DELETED] " + deleted.PackageId + "@" + deleted.PackageVersion); return Task.FromResult(true); }), new CatalogProcessorSettings { MinCommitTimestamp = timer.ScheduleStatus?.Last ?? DateTimeOffset.UtcNow, MaxCommitTimestamp = timer.ScheduleStatus?.Next ?? DateTimeOffset.UtcNow, ServiceIndexUrl = "https://api.nuget.org/v3/index.json" }, new NullLogger<CatalogProcessor>()); await processor.ProcessAsync(CancellationToken.None);
  10. Each function should only do one thing! We are violating this.
  11. Go over Approach1 code – Enqueuer class Mention we are using roughly the same code as before Differences are that our function is now no longer doing things itself, instead it’s adding messages to a queue for processing later on That Queue binding is interesting. This is where the input/output comes from. Instead of managing our own queue connection, we let the framework handle all plumbing so we can focus on adding messages. In Indexer, we use the Queue as an input binding, and read messages. We can now scale enqueuing and scaling separately! But are we there yet?
  12. https://github.com/thinktecture/azure-functions-extensibility
  13. Go over Approach2 code Show this is MUCH simpler – trigger binding that provides input, queue output bindign to write that input to a queue Let’s go over what it takes to build a trigger binding NuGetCatalogTriggerAttribute – the data needed for the trigger to work – go over properties and attributes Hooking it up requires a binding configuration – NuGetCatalogTriggerExtensionConfigProvider It says: if you see this specific binding, register it as a trigger that maps to some provider So we need that provider – NuGetCatalogTriggerAttributeBindingProvider Provider is there to create an object that provides data. In our case we need to store the NuGet catalog timestamp cursor, so we do that on storage, and then return the actual binding – NuGetCatalogTriggerBinding In NuGetCatalogTriggerBinding, we have to specify how data can be bound. What if I use a differnt type of object than PackageOperation? What if someone used a node.js or Python function instead of .NET. Need to define the shape of the data our trigger provides. PackageOperationValueProvider is also interesting, this provides data shown in the portal diagnostics CreateListenerAsync is where the actual triger code will be created – NuGetCatalogListener NuGetCatalogListener uses the BatchCatalogProcessor we had previously, and when a package is added or deleted it will call into the injected ITriggeredFunctionExecutor ITriggeredFunctionExecutor is Azure Functions framework specific, but it’s the glue that will clal into our function with the data we provide Note StartAsync/StopAsync where you can add startup/shutdown code ONE THING LEFT THAT IS NOT DOCUMENTED – Startup.cs to register the binding. And since we are in a different class library, also need Microsoft.Azure.WebJobs.Extensions referenced to generate \bin\Debug\netcoreapp2.1\bin\extensions.json As a result our code is now MUCH cleaner, show it again and maybe also show it in action Mention [Singleton(Mode = SingletonMode.Listener)] – we need to ensure this binding only runs single-instance (cursor clashes otherwise). This is due to ho the catalog works, parallel processing is harder to do. But we can fix that by scaling the Indexer later on. Show Approach3 PopulateQueueAndTable Same code, but a bit more production worthy Sending data to two queues (indexing and downloading) Storing data in a table (and yes, violating “do one thing” again but I call it architectural freedom)
  14. Next up will be downloading and indexing. Let’s start with downloading. Grab a copy of the .nupkg from NuGet and store it in a blob Redundancy - no need to re-download/stress NuGet on a re-index
  15. Go over Approach3 code DownloadToStorage uses a QueueTrigger to run whenever a message appears in queue Note no singleton: we can scale this across multiple instances/multiple servers Uses a Blob input binding that provides access to a blob Note the parameters, name of the blob is resolved based on data from other inputs which is prety nifty Our code checks whether it’s an add or a delete, and either downloads+uploads to the blob reference, or delets the blob reference
  16. Next up will be indexing itself. There are a couple of things here…
  17. Go over Approach3 code PackageIndexer uses a QueueTrigger to run whenever a message appears in queue Uses a Blob input binding that provides access to a blob where we can write our indexed entity – will show this later Based on package operation, we will add or delete from the index RunAddPackageAsync has some plumbing, probably too much, to dowload the .nupkg file and store it on disk Note: we store it on disk as we need a seekable stream. So why no memoy stream? Some NuGet packages are HUGE. Find PEReader usage and show how it will index a given package’s public types and namespaces All goes into a typeNames collection. Now: how do we add this info to the index? Show PackageDocument class, has MANY properties First important: the Identifier property has [Key] applied. Azure Search needs a key for teh document so we can retrieve by key, which could be useful when updating existing content or to find a specific document and delete it from the index. Second important: TypeNames is searchable. Also mention “simpleanalyzer”: “Divides text at non-letters and converts them to lower case.” Other analyzers remove stopwords and do other things, this one should be as searchable as possible. Other fields are sometimes searchable, sometimes facetable – a bit of leftover from me thinking about search use cases. The R# API ony searches on typename so could make everything else just retrievable as well. Of course, index is not there by default, so need to create it. We do this when our function is instantiated (static constructor, so only once per launch of our functions) Is this good? Yes, because only once per server instance our function runs on. No because we do it at one point, what if the index is deleted in between and needs to be recreated? Edge case, but a retry strategy could be a good idea... Next, we create our package document, and at one point we add it to a list of index actions, and to blob storage indexActions.Add(IndexAction.MergeOrUpload(packageToIndex)); JsonSerializer.Serialize(jsonWriter, packagesToIndex); Writing to index using batch - var indexBatch = IndexBatch.New(actions); Leftover code from earlier, batch makes no sense for one document, but in case you want to do multiple in one go this is the way. Do beware a batch can only be several MB in size, for this NuGet indexing I can only do ~25 in a batch before payload is too large. That’s… it! Run approach 3 (for last hour) and see functions being hit / packages added to index Go to Azure Search portal as well, show how importer would work in case of fire
  18. Go over Approach3 code PackageIndexerWithCustomBinding is mostly the same code One difference: it uses the [AzureSearchIndex] binding to write add/delete operations to the index instead Go over how it works. Again, an attribute with settings – AzureSearchIndexAttribute Also a configuration that registers the binding as an output binding using BindToCollector – AzureSearchExtensionConfigProvider Now, what’s this OpenType? It’s some sort of dynamic type. If we want to create an AzureSearch output binding, we better support more than just our PackageDocument use case! So we need a collector builder that can create the actual binding implementation based on the real type requested by our function parameter – AzureSearchAsyncCollectorBuilder In AzureSearchAsyncCollectorBuilder, we do that. Very simple bootstrap code in this case, but could be more complex depending on the type of binding you are creating. Our AzureSearchAsyncCollector uses the attribute to check for Azure Search connection details, as well as the type of operation we expect it to handle. Why not all? Well, IAsyncCollector only has Add and Flush. Note: add called manually, flush at function complete – could use flush to send things in a batch... Code itself pretty straightforward. On Add, we add an action to search. With a retry in case the index does not exist – we then create it. Creation code kind of interesting as we use some reflection in case we specify a given type of coument to index. Why? Cause when we do Upserts, we may want to update just one or two properties, and can use a different Dto in that case (but still have the index shaped to the full document shape) Run when time left, but nothing fancy here...
  19. Now we need to make ReSharper talk to our search. We have the index, so that should be a breeze, right?
  20. Go over Web code RunFindTypeApiAsync and RunFindNamespaceAsync Both use “name” as their query parameter to search for RunInternalAsync does the heavy lifting Grabs other parameters Runs search, and collects several pages of results Why is this ForEachAsync there? Search index has multiple versions for every package id, yet ReSharper expects only the latest matching all parameters Azure Search has no group by / distinct by, so need to do this in memory. Doing it here by fetching a maximum number of results and doing the grouping manually. Use the collected data to build result. Add matching type names etc. Example requests: http://localhost:7071/api/v1/find-type?name=JsonConvert http://localhost:7071/api/v1/find-type?name=CamoServer&allowPrerelease=true&latestVersion=false https://nugettypesearch.azurewebsites.net/api/v1/find-type?name=JsonConvert In ReSharper (devenv /ReSharper.Internal, go to NuGet tool window, set base URL to https://nugettypesearch.azurewebsites.net/api/v1/) Write some code that uses JsonConvert / JObject and try it out.
