Exploring .NET
memory management
A trip down memory lane
Maarten Balliauw
@maartenballiauw
—
.NET runtime
Manages execution of programs
Just-in-time compilation: Intermediate Language (IL) ->machine code
Type safety
Exception handling
Security
Thread management
Memory management
Garbage collection (GC)
Garbage Collector
Memory management and GC
“Virtually unlimited memory for our applications”
Big chunk of memory pre-allocated
Runtime manages allocation in that chunk
Garbage Collector (GC) reclaims unused memory, making it available again
.NET memory management 101
Memory allocation
Objects allocated in “managed heap” (big chunk of memory)
Allocating memory is fast, it’s just adding a pointer
Some unmanaged memory is also consumed (not GC-ed)
.NET CLR, Dynamic libraries, Graphics buffer, …
Memory release or “Garbage Collection” (GC)
Generations
Large Object Heap
.NET memory management 101
Memory allocation
Memory release or “Garbage Collection” (GC)
GC releases objects no longer in use by examining application roots
GC builds a graph of all the objects that are reachable from these roots
Object unreachable? Remove object, release memory, compact heap
Takes time to scan all objects!
Generations
Large Object Heap
.NET memory management 101
Memory allocation
Memory release or “Garbage Collection” (GC)
Generations
Large Object Heap
Generation 0 Generation 1 Generation 2
Short-lived objects (e.g. Local
variables)
In-between objects Long-lived objects (e.g. App’s
main form)
.NET memory management 101
Memory allocation
Memory release or “Garbage Collection” (GC)
Generations
Large Object Heap (LOH)
Special segment for large objects (>85KB)
Collected only during full garbage collection
Not compacted (by default) -> fragmentation!
Fragmentation can cause OutOfMemoryException
The .NET garbage collector
Runs very often for gen0
Short-lived objects, few references, fast to clean
Local variable, web request/response
Higher generation
Usually more references, slower to clean
GC pauses the running application to do its thing
Usually short, except when not…
Background GC (enabled by default)
Concurrent with application threads
May still introduce short locks/pauses, usually just for one thread
The .NET garbage collector
When does it run? Vague… But usually:
Out of memory condition – when the system fails to allocate or re-allocate memory
After some significant allocation – if X memory is allocated since previous GC
Failure of allocating some native resources – internal to .NET
Profiler – when triggered from profiler API
Forced – when calling methods on System.GC
Application moves to background
GC is not guaranteed to run
http://blogs.msdn.com/b/oldnewthing/archive/2010/08/09/10047586.aspx
http://blogs.msdn.com/b/abhinaba/archive/2008/04/29/when-does-the-net-compact-framework-garbage-collector-run.aspx
Helping the GC, avoid pauses
Optimize allocations (use struct when it makes sense, Span<T>, object pooling)
Don’t allocate when not needed
Make use of IDisposable / using statement
Clean up references, giving the GC an easy job
Weak references
Allow the GC to collect these objects, no need for checks
Finalizers
Beware! Moved to finalizer queue -> always gen++
Helping the GC
DEMO
https://github.com/maartenba/memory-demos
Allocations
When is memory allocated?
Not for value types (int, bool, struct, decimal, enum, float, byte, long, …)
Allocated on stack, not on heap
Not managed by garbage collector
For reference types
When you new
When you load data into a variable, object, property, ...
Hidden allocations!
Boxing!
Put an int in a box
Take an int out of a box
Lambda’s/closures
Allocate compiler-generated
DisplayClass to capture state
Params arrays
And more!
int i = 42;
// boxing - wraps the value type in an "object box"
// (allocating a System.Object)
object o = i;
// unboxing - unpacking the "object box" into an int again
// (CPU effort to unwrap)
int j = (int)o;
How to find them?
Past experience
Intermediate Language (IL)
Profiler
“Heap allocations viewer”
ReSharper Heap Allocations Viewer plugin
Roslyn’s Heap Allocation Analyzer
Hidden allocations
DEMO
https://github.com/maartenba/memory-demos
ReSharper Heap Allocations Viewer plugin
Roslyn’s Heap Allocation Analyzer
Measure!
Don’t do premature optimization – measure!
Allocations don’t always matter (that much)
Measure!
How frequently are we allocating?
How frequently are we collecting?
What generation do we end up on?
Are our allocations introducing pauses?
www.jetbrains.com/dotmemory (and www.jetbrains.com/dottrace)
Always Be Measuring
DEMO
https://github.com/maartenba/memory-demos
[
{ ... },
{
"name": "Westmalle Tripel",
"brewery": "Brouwerij der Trappisten van Westmalle",
"votes": 17658,
"rating": 4.7
},
{ ... }
]
Object pools / object re-use
Re-use objects / collections (when it makes sense)
Fewer allocations, fewer objects for the GC to scan
Less memory traffic that can trigger a full GC
Object pooling - object pool pattern
Create a pool of objects that can be re-used
https://www.codeproject.com/articles/20848/c-object-pooling
“Optimize ASP.NET Core” - https://github.com/aspnet/AspLabs/issues/3
System.Buffers.ArrayPool
Garbage Collector summary
GC is optimized for high memory traffic in short-lived objects
Use that knowledge! Don’t fear allocations!
Don’t optimize what should not be optimized…
GC is the concept that makes .NET / C# tick – use it!
Know when allocations happen
GC is awesome
Gen2 collection that stop the world not so much…
Measure!
Strings
Strings are objects
.NET tries to make them look like a value type, but they are a reference type
Read-only collection of char
Length property
A bunch of operator overloading
Allocated on the managed heap
var a = new string('-', 25);
var b = a.Substring(5);
var c = httpClient.GetStringAsync("http://blog.maartenballiauw.be");
String literals
Are all strings on the heap? Are all strings duplicated?
var a = "Hello, World!";
var b = "Hello, World!";
Console.WriteLine(a == b);
Console.WriteLine(Object.ReferenceEquals(a, b));
Prints true twice. So “Hello World” only in memory once?
Portable Executable (PE)
#UserStrings
DEMO
https://github.com/maartenba/memory-demos
String literals in #US
Compile-time optimization
Store literals only once in PE header metadata stream ECMA-335 standard, section II.24.2.4
Reference literals (IL: ldstr)
var a = Console.ReadLine();
var b = Console.ReadLine();
Console.WriteLine(a == b);
Console.WriteLine(Object.ReferenceEquals(a, b));
String duplicates
Any .NET application has them (System.Globalization duplicates quite a few)
Are they bad?
.NET GC is fast for short-lived objects, so meh.
Don’t waste memory with string duplicates on gen2
(but: it’s okay to have strings there)
String interning
Store (and read) strings from the intern pool
Simply call String.Intern when “allocating” or reading the string
Scans intern pool and returns reference
var url = "http://blog.maartenballiauw.be";
var stringList = new List<string>();
for (int i = 0; i < 1000000; i++)
{
stringList.Add(string.Intern(url + "/"));
}
String interning caveats
Why are not all strings interned by default?
CPU vs. memory
Not on the heap but on intern pool
No GC on intern pool – all strings in memory for AppDomain lifetime!
Rule of thumb
Lot of long-lived, few unique -> interning good
Lot of long-lived, many unique -> no benefit, memory growth
Lot of short-lived -> trust the GC
Measure!
Exploring the heap
for fun and profit
How would you...
…build a managed type system, store in memory, CPU/memory friendly
Probably:
Store type info (what’s in there, what’s the offset of fieldN, …)
Store field data (just data)
Store method pointers
Inheritance information
Stuff on the Stack
Stuff on the Managed Heap
(scroll down for more...)
Theory is nice...
Microsoft.Diagnostics.Runtime (ClrMD)
“ClrMD is a set of advanced APIs for programmatically inspecting a crash dump of
a .NET program much in the same way that the SOS Debugging Extensions (SOS)
do. This allows you to write automated crash analysis for your applications as well
as automate many common debugger tasks. In addition to reading crash dumps
ClrMD also allows supports attaching to live processes.”
“LINQ-to-heap”
Maarten’s definition
ClrMD
DEMO
https://github.com/maartenba/memory-demos
But... Why?
Programmatic insight into memory space of a running project
Unit test critical paths and assert behavior (did we clean up what we expected?)
Capture memory issues in running applications
Other (easier) options in this space
dotMemory Unit (JetBrains)
Benchmark.NET
dotMemory Unit
DEMO
https://github.com/maartenba/memory-demos
Conclusion
Conclusion
Garbage Collector (GC) optimized for high memory traffic + short-lived objects
Don’t fear allocations! But beware of gen2 “stop the world”
Don’t optimize what should not be optimized…
Measure!
Using a profiler/memory analysis tool
ClrMD to automate inspections
dotMemory Unit, Benchmark.NET, … to profile unit tests
Blog series: https://blog.maartenballiauw.be
Thank you!
Maarten Balliauw
@maartenballiauw
—

More Related Content

What's hot

Building a Scalable Distributed Stats Infrastructure with Storm and KairosDB
Building a Scalable Distributed Stats Infrastructure with Storm and KairosDBBuilding a Scalable Distributed Stats Infrastructure with Storm and KairosDB
Building a Scalable Distributed Stats Infrastructure with Storm and KairosDB
Cody Ray

TensorFrames: Google Tensorflow on Apache Spark
TensorFrames: Google Tensorflow on Apache SparkTensorFrames: Google Tensorflow on Apache Spark
TensorFrames: Google Tensorflow on Apache Spark
Databricks

Understanding Java Garbage Collection - And What You Can Do About It
Understanding Java Garbage Collection - And What You Can Do About ItUnderstanding Java Garbage Collection - And What You Can Do About It
Understanding Java Garbage Collection - And What You Can Do About It
Azul Systems Inc.

Quantifying the Performance of Garbage Collection vs. Explicit Memory Management
Quantifying the Performance of Garbage Collection vs. Explicit Memory ManagementQuantifying the Performance of Garbage Collection vs. Explicit Memory Management
Quantifying the Performance of Garbage Collection vs. Explicit Memory Management
Emery Berger

Accelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDS
Accelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDSAccelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDS
Accelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDS
Databricks

High Performance Machine Learning in R with H2O
High Performance Machine Learning in R with H2OHigh Performance Machine Learning in R with H2O
High Performance Machine Learning in R with H2O
Sri Ambati

Deep learning with kafka
Deep learning with kafkaDeep learning with kafka
Deep learning with kafka
Nitin Kumar

Scale up and Scale Out Anaconda and PyData
Scale up and Scale Out Anaconda and PyDataScale up and Scale Out Anaconda and PyData
Scale up and Scale Out Anaconda and PyData
Travis Oliphant

Understanding Java Garbage Collection
Understanding Java Garbage CollectionUnderstanding Java Garbage Collection
Understanding Java Garbage Collection
Azul Systems Inc.

Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...
Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...
Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...
Databricks

Machine learning at scale with Google Cloud Platform
Machine learning at scale with Google Cloud PlatformMachine learning at scale with Google Cloud Platform
Machine learning at scale with Google Cloud Platform
Matthias Feys

Need for Time series Database
Need for Time series DatabaseNeed for Time series Database
Need for Time series Database
Pramit Choudhary

First steps with Keras 2: A tutorial with Examples
First steps with Keras 2: A tutorial with ExamplesFirst steps with Keras 2: A tutorial with Examples
First steps with Keras 2: A tutorial with Examples
Felipe

View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...
View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...
View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...
Srinath Perera

Using Spark ML on Spark Errors - What do the clusters tell us?
Using Spark ML on Spark Errors - What do the clusters tell us?Using Spark ML on Spark Errors - What do the clusters tell us?
Using Spark ML on Spark Errors - What do the clusters tell us?
Holden Karau

Chronix Time Series Database - The New Time Series Kid on the Block
Chronix Time Series Database - The New Time Series Kid on the BlockChronix Time Series Database - The New Time Series Kid on the Block
Chronix Time Series Database - The New Time Series Kid on the Block
QAware GmbH

Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...
Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...
Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...
Big Data Spain

How to use Apache TVM to optimize your ML models
How to use Apache TVM to optimize your ML modelsHow to use Apache TVM to optimize your ML models
How to use Apache TVM to optimize your ML models
Databricks

ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...
ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...
ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...
Srinath Perera

Real time and reliable processing with Apache Storm
Real time and reliable processing with Apache StormReal time and reliable processing with Apache Storm
Real time and reliable processing with Apache Storm
Andrea Iacono


What's hot (20)

Building a Scalable Distributed Stats Infrastructure with Storm and KairosDB
Building a Scalable Distributed Stats Infrastructure with Storm and KairosDBBuilding a Scalable Distributed Stats Infrastructure with Storm and KairosDB
Building a Scalable Distributed Stats Infrastructure with Storm and KairosDB

TensorFrames: Google Tensorflow on Apache Spark
TensorFrames: Google Tensorflow on Apache SparkTensorFrames: Google Tensorflow on Apache Spark
TensorFrames: Google Tensorflow on Apache Spark

Understanding Java Garbage Collection - And What You Can Do About It
Understanding Java Garbage Collection - And What You Can Do About ItUnderstanding Java Garbage Collection - And What You Can Do About It
Understanding Java Garbage Collection - And What You Can Do About It

Quantifying the Performance of Garbage Collection vs. Explicit Memory Management
Quantifying the Performance of Garbage Collection vs. Explicit Memory ManagementQuantifying the Performance of Garbage Collection vs. Explicit Memory Management
Quantifying the Performance of Garbage Collection vs. Explicit Memory Management

Accelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDS
Accelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDSAccelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDS
Accelerated Machine Learning with RAPIDS and MLflow, Nvidia/RAPIDS

High Performance Machine Learning in R with H2O
High Performance Machine Learning in R with H2OHigh Performance Machine Learning in R with H2O
High Performance Machine Learning in R with H2O

Deep learning with kafka
Deep learning with kafkaDeep learning with kafka
Deep learning with kafka

Scale up and Scale Out Anaconda and PyData
Scale up and Scale Out Anaconda and PyDataScale up and Scale Out Anaconda and PyData
Scale up and Scale Out Anaconda and PyData

Understanding Java Garbage Collection
Understanding Java Garbage CollectionUnderstanding Java Garbage Collection
Understanding Java Garbage Collection

Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...
Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...
Strata NYC 2015: Sketching Big Data with Spark: randomized algorithms for lar...

Machine learning at scale with Google Cloud Platform
Machine learning at scale with Google Cloud PlatformMachine learning at scale with Google Cloud Platform
Machine learning at scale with Google Cloud Platform

Need for Time series Database
Need for Time series DatabaseNeed for Time series Database
Need for Time series Database

First steps with Keras 2: A tutorial with Examples
First steps with Keras 2: A tutorial with ExamplesFirst steps with Keras 2: A tutorial with Examples
First steps with Keras 2: A tutorial with Examples

View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...
View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...
View, Act, and React: Shaping Business Activity with Analytics, BigData Queri...

Using Spark ML on Spark Errors - What do the clusters tell us?
Using Spark ML on Spark Errors - What do the clusters tell us?Using Spark ML on Spark Errors - What do the clusters tell us?
Using Spark ML on Spark Errors - What do the clusters tell us?

Chronix Time Series Database - The New Time Series Kid on the Block
Chronix Time Series Database - The New Time Series Kid on the BlockChronix Time Series Database - The New Time Series Kid on the Block
Chronix Time Series Database - The New Time Series Kid on the Block

Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...
Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...
Training Deep Learning Models on Multiple GPUs in the Cloud by Enrique Otero ...

How to use Apache TVM to optimize your ML models
How to use Apache TVM to optimize your ML modelsHow to use Apache TVM to optimize your ML models
How to use Apache TVM to optimize your ML models

ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...
ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...
ICTER 2014 Invited Talk: Large Scale Data Processing in the Real World: from ...

Real time and reliable processing with Apache Storm
Real time and reliable processing with Apache StormReal time and reliable processing with Apache Storm
Real time and reliable processing with Apache Storm


Similar to CodeStock - Exploring .NET memory management - a trip down memory lane

ConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory laneConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory lane
Maarten Balliauw

Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...
Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...
Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...
Maarten Balliauw

Exploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinarExploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinar
Maarten Balliauw

Java Garbage Collection, Monitoring, and Tuning
Java Garbage Collection, Monitoring, and TuningJava Garbage Collection, Monitoring, and Tuning
Java Garbage Collection, Monitoring, and Tuning
Carol McDonald

Intro to SnappyData Webinar
Intro to SnappyData WebinarIntro to SnappyData Webinar
Intro to SnappyData Webinar
SnappyData

Profiler Guided Java Performance Tuning
Profiler Guided Java Performance TuningProfiler Guided Java Performance Tuning
Profiler Guided Java Performance Tuning
osa_ora

High Performance With Java
High Performance With JavaHigh Performance With Java
High Performance With Java
malduarte

Scope Stack Allocation
Scope Stack AllocationScope Stack Allocation
Scope Stack Allocation
Electronic Arts / DICE

Advanced Hibernate Notes
Advanced Hibernate NotesAdvanced Hibernate Notes
Advanced Hibernate Notes
Kaniska Mandal

Improving app performance using .Net Core 3.0
Improving app performance using .Net Core 3.0Improving app performance using .Net Core 3.0
Improving app performance using .Net Core 3.0
Richard Banks

dotMemory 4 - What's inside?
dotMemory 4 - What's inside?dotMemory 4 - What's inside?
dotMemory 4 - What's inside?
Maarten Balliauw

performance optimization: Memory
performance optimization: Memoryperformance optimization: Memory
performance optimization: Memory
晓东 杜

Optimizing training on Apache MXNet
Optimizing training on Apache MXNetOptimizing training on Apache MXNet
Optimizing training on Apache MXNet
Amazon Web Services

Optimizing training on Apache MXNet (January 2018)
Optimizing training on Apache MXNet (January 2018)Optimizing training on Apache MXNet (January 2018)
Optimizing training on Apache MXNet (January 2018)
Julien SIMON

Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)
Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)
Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)
Yonik Seeley

jvm goes to big data
jvm goes to big datajvm goes to big data
jvm goes to big data
srisatish ambati

Centralized log-management-with-elastic-stack
Centralized log-management-with-elastic-stackCentralized log-management-with-elastic-stack
Centralized log-management-with-elastic-stack
Rich Lee

Performance Tuning - Memory leaks, Thread deadlocks, JDK tools
Performance Tuning -  Memory leaks, Thread deadlocks, JDK toolsPerformance Tuning -  Memory leaks, Thread deadlocks, JDK tools
Performance Tuning - Memory leaks, Thread deadlocks, JDK tools
Haribabu Nandyal Padmanaban

ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)
ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)
ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)
srisatish ambati

Java programing considering performance
Java programing considering performanceJava programing considering performance
Java programing considering performance
Roger Xia


Similar to CodeStock - Exploring .NET memory management - a trip down memory lane (20)

ConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory laneConFoo - Exploring .NET’s memory management – a trip down memory lane
ConFoo - Exploring .NET’s memory management – a trip down memory lane

Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...
Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...
Exploring .NET memory management - A trip down memory lane - Copenhagen .NET ...

Exploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinarExploring .NET memory management - JetBrains webinar
Exploring .NET memory management - JetBrains webinar

Java Garbage Collection, Monitoring, and Tuning
Java Garbage Collection, Monitoring, and TuningJava Garbage Collection, Monitoring, and Tuning
Java Garbage Collection, Monitoring, and Tuning

Intro to SnappyData Webinar
Intro to SnappyData WebinarIntro to SnappyData Webinar
Intro to SnappyData Webinar

Profiler Guided Java Performance Tuning
Profiler Guided Java Performance TuningProfiler Guided Java Performance Tuning
Profiler Guided Java Performance Tuning

High Performance With Java
High Performance With JavaHigh Performance With Java
High Performance With Java

Scope Stack Allocation
Scope Stack AllocationScope Stack Allocation
Scope Stack Allocation

Advanced Hibernate Notes
Advanced Hibernate NotesAdvanced Hibernate Notes
Advanced Hibernate Notes

Improving app performance using .Net Core 3.0
Improving app performance using .Net Core 3.0Improving app performance using .Net Core 3.0
Improving app performance using .Net Core 3.0

dotMemory 4 - What's inside?
dotMemory 4 - What's inside?dotMemory 4 - What's inside?
dotMemory 4 - What's inside?

performance optimization: Memory
performance optimization: Memoryperformance optimization: Memory
performance optimization: Memory

Optimizing training on Apache MXNet
Optimizing training on Apache MXNetOptimizing training on Apache MXNet
Optimizing training on Apache MXNet

Optimizing training on Apache MXNet (January 2018)
Optimizing training on Apache MXNet (January 2018)Optimizing training on Apache MXNet (January 2018)
Optimizing training on Apache MXNet (January 2018)

Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)
Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)
Native Code, Off-Heap Data & JSON Facet API for Solr (Heliosearch)

jvm goes to big data
jvm goes to big datajvm goes to big data
jvm goes to big data

Centralized log-management-with-elastic-stack
Centralized log-management-with-elastic-stackCentralized log-management-with-elastic-stack
Centralized log-management-with-elastic-stack

Performance Tuning - Memory leaks, Thread deadlocks, JDK tools
Performance Tuning -  Memory leaks, Thread deadlocks, JDK toolsPerformance Tuning -  Memory leaks, Thread deadlocks, JDK tools
Performance Tuning - Memory leaks, Thread deadlocks, JDK tools

ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)
ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)
ApacheCon2010: Cache & Concurrency Considerations in Cassandra (& limits of JVM)

Java programing considering performance
Java programing considering performanceJava programing considering performance
Java programing considering performance


More from Maarten Balliauw

Bringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptxBringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptx
Maarten Balliauw

Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Maarten Balliauw

Building a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to SpaceBuilding a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to Space
Maarten Balliauw

Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Maarten Balliauw

Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Maarten Balliauw

NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
Maarten Balliauw

.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se....NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
Maarten Balliauw

CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
Maarten Balliauw

NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and SearchNDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
Maarten Balliauw

Approaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days PolandApproaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days Poland
Maarten Balliauw

Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Maarten Balliauw

Approaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologneApproaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologne
Maarten Balliauw

ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
Maarten Balliauw

ConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttlingConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttling
Maarten Balliauw

Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Maarten Balliauw

VISUG - Approaches for application request throttling
VISUG - Approaches for application request throttlingVISUG - Approaches for application request throttling
VISUG - Approaches for application request throttling
Maarten Balliauw

What is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays FinlandWhat is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays Finland
Maarten Balliauw

ConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello WorldConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello World
Maarten Balliauw

Approaches to application request throttling
Approaches to application request throttlingApproaches to application request throttling
Approaches to application request throttling
Maarten Balliauw

NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017
Maarten Balliauw


More from Maarten Balliauw (20)

Bringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptxBringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptx

Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...

Building a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to SpaceBuilding a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to Space

Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...

Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...

NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...

.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se....NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...

CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...

NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and SearchNDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search

Approaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days PolandApproaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days Poland

Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...

Approaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologneApproaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologne

ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...

ConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttlingConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttling

Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...

VISUG - Approaches for application request throttling
VISUG - Approaches for application request throttlingVISUG - Approaches for application request throttling
VISUG - Approaches for application request throttling

What is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays FinlandWhat is going on - Application diagnostics on Azure - TechDays Finland
What is going on - Application diagnostics on Azure - TechDays Finland

ConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello WorldConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello World

Approaches to application request throttling
Approaches to application request throttlingApproaches to application request throttling
Approaches to application request throttling

NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017NuGet beyond Hello World - DotNext Piter 2017
NuGet beyond Hello World - DotNext Piter 2017


Recently uploaded

“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
Edge AI and Vision Alliance

Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...
Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...
Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...
saastr

GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge GraphGraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
Neo4j

Leveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and StandardsLeveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and Standards
Neo4j

Fueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte WebinarFueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte Webinar
Zilliz

Driving Business Innovation: Latest Generative AI Advancements & Success Story
Driving Business Innovation: Latest Generative AI Advancements & Success StoryDriving Business Innovation: Latest Generative AI Advancements & Success Story
Driving Business Innovation: Latest Generative AI Advancements & Success Story
Safe Software

WeTestAthens: Postman's AI & Automation Techniques
WeTestAthens: Postman's AI & Automation TechniquesWeTestAthens: Postman's AI & Automation Techniques
WeTestAthens: Postman's AI & Automation Techniques
Postman

Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024
Jason Packer

What is an RPA CoE? Session 1 – CoE Vision
What is an RPA CoE?  Session 1 – CoE VisionWhat is an RPA CoE?  Session 1 – CoE Vision
What is an RPA CoE? Session 1 – CoE Vision
DianaGray10

Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-EfficiencyFreshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
ScyllaDB

The Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptxThe Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptx
operationspcvita

HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAUHCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
panagenda

Biomedical Knowledge Graphs for Data Scientists and Bioinformaticians
Biomedical Knowledge Graphs for Data Scientists and BioinformaticiansBiomedical Knowledge Graphs for Data Scientists and Bioinformaticians
Biomedical Knowledge Graphs for Data Scientists and Bioinformaticians
Neo4j

Presentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of GermanyPresentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of Germany
innovationoecd

Digital Marketing Trends in 2024 | Guide for Staying Ahead
Digital Marketing Trends in 2024 | Guide for Staying AheadDigital Marketing Trends in 2024 | Guide for Staying Ahead
Digital Marketing Trends in 2024 | Guide for Staying Ahead
Wask

Main news related to the CCS TSI 2023 (2023/1695)
Main news related to the CCS TSI 2023 (2023/1695)Main news related to the CCS TSI 2023 (2023/1695)
Main news related to the CCS TSI 2023 (2023/1695)
Jakub Marek

Nordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptxNordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptx
MichaelKnudsen27

FREE A4 Cyber Security Awareness Posters-Social Engineering part 3
FREE A4 Cyber Security Awareness  Posters-Social Engineering part 3FREE A4 Cyber Security Awareness  Posters-Social Engineering part 3
FREE A4 Cyber Security Awareness Posters-Social Engineering part 3
Data Hops

Serial Arm Control in Real Time Presentation
Serial Arm Control in Real Time PresentationSerial Arm Control in Real Time Presentation
Serial Arm Control in Real Time Presentation
tolgahangng

Introduction of Cybersecurity with OSS at Code Europe 2024
Introduction of Cybersecurity with OSS  at Code Europe 2024Introduction of Cybersecurity with OSS  at Code Europe 2024
Introduction of Cybersecurity with OSS at Code Europe 2024
Hiroshi SHIBATA


Recently uploaded (20)

“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...
“Temporal Event Neural Networks: A More Efficient Alternative to the Transfor...

Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...
Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...
Deep Dive: AI-Powered Marketing to Get More Leads and Customers with HyperGro...

GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge GraphGraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph

Leveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and StandardsLeveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and Standards

Fueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte WebinarFueling AI with Great Data with Airbyte Webinar
Fueling AI with Great Data with Airbyte Webinar

Driving Business Innovation: Latest Generative AI Advancements & Success Story
Driving Business Innovation: Latest Generative AI Advancements & Success StoryDriving Business Innovation: Latest Generative AI Advancements & Success Story
Driving Business Innovation: Latest Generative AI Advancements & Success Story

WeTestAthens: Postman's AI & Automation Techniques
WeTestAthens: Postman's AI & Automation TechniquesWeTestAthens: Postman's AI & Automation Techniques
WeTestAthens: Postman's AI & Automation Techniques

Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024Columbus Data & Analytics Wednesdays - June 2024
Columbus Data & Analytics Wednesdays - June 2024

What is an RPA CoE? Session 1 – CoE Vision
What is an RPA CoE?  Session 1 – CoE VisionWhat is an RPA CoE?  Session 1 – CoE Vision
What is an RPA CoE? Session 1 – CoE Vision

Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-EfficiencyFreshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency

The Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptxThe Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptx

HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAUHCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU
HCL Notes und Domino Lizenzkostenreduzierung in der Welt von DLAU

Biomedical Knowledge Graphs for Data Scientists and Bioinformaticians
Biomedical Knowledge Graphs for Data Scientists and BioinformaticiansBiomedical Knowledge Graphs for Data Scientists and Bioinformaticians
Biomedical Knowledge Graphs for Data Scientists and Bioinformaticians

Presentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of GermanyPresentation of the OECD Artificial Intelligence Review of Germany
Presentation of the OECD Artificial Intelligence Review of Germany

Digital Marketing Trends in 2024 | Guide for Staying Ahead
Digital Marketing Trends in 2024 | Guide for Staying AheadDigital Marketing Trends in 2024 | Guide for Staying Ahead
Digital Marketing Trends in 2024 | Guide for Staying Ahead

Main news related to the CCS TSI 2023 (2023/1695)
Main news related to the CCS TSI 2023 (2023/1695)Main news related to the CCS TSI 2023 (2023/1695)
Main news related to the CCS TSI 2023 (2023/1695)

Nordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptxNordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptx

FREE A4 Cyber Security Awareness Posters-Social Engineering part 3
FREE A4 Cyber Security Awareness  Posters-Social Engineering part 3FREE A4 Cyber Security Awareness  Posters-Social Engineering part 3
FREE A4 Cyber Security Awareness Posters-Social Engineering part 3

Serial Arm Control in Real Time Presentation
Serial Arm Control in Real Time PresentationSerial Arm Control in Real Time Presentation
Serial Arm Control in Real Time Presentation

Introduction of Cybersecurity with OSS at Code Europe 2024
Introduction of Cybersecurity with OSS  at Code Europe 2024Introduction of Cybersecurity with OSS  at Code Europe 2024
Introduction of Cybersecurity with OSS at Code Europe 2024


CodeStock - Exploring .NET memory management - a trip down memory lane

  • 1. Exploring .NET memory management A trip down memory lane Maarten Balliauw @maartenballiauw —
  • 2.
  • 3. .NET runtime Manages execution of programs Just-in-time compilation: Intermediate Language (IL) ->machine code Type safety Exception handling Security Thread management Memory management Garbage collection (GC)
  • 5. Memory management and GC “Virtually unlimited memory for our applications” Big chunk of memory pre-allocated Runtime manages allocation in that chunk Garbage Collector (GC) reclaims unused memory, making it available again
  • 6. .NET memory management 101 Memory allocation Objects allocated in “managed heap” (big chunk of memory) Allocating memory is fast, it’s just adding a pointer Some unmanaged memory is also consumed (not GC-ed) .NET CLR, Dynamic libraries, Graphics buffer, … Memory release or “Garbage Collection” (GC) Generations Large Object Heap
  • 7. .NET memory management 101 Memory allocation Memory release or “Garbage Collection” (GC) GC releases objects no longer in use by examining application roots GC builds a graph of all the objects that are reachable from these roots Object unreachable? Remove object, release memory, compact heap Takes time to scan all objects! Generations Large Object Heap
  • 8. .NET memory management 101 Memory allocation Memory release or “Garbage Collection” (GC) Generations Large Object Heap Generation 0 Generation 1 Generation 2 Short-lived objects (e.g. Local variables) In-between objects Long-lived objects (e.g. App’s main form)
  • 9. .NET memory management 101 Memory allocation Memory release or “Garbage Collection” (GC) Generations Large Object Heap (LOH) Special segment for large objects (>85KB) Collected only during full garbage collection Not compacted (by default) -> fragmentation! Fragmentation can cause OutOfMemoryException
  • 10. The .NET garbage collector Runs very often for gen0 Short-lived objects, few references, fast to clean Local variable, web request/response Higher generation Usually more references, slower to clean GC pauses the running application to do its thing Usually short, except when not… Background GC (enabled by default) Concurrent with application threads May still introduce short locks/pauses, usually just for one thread
  • 11. The .NET garbage collector When does it run? Vague… But usually: Out of memory condition – when the system fails to allocate or re-allocate memory After some significant allocation – if X memory is allocated since previous GC Failure of allocating some native resources – internal to .NET Profiler – when triggered from profiler API Forced – when calling methods on System.GC Application moves to background GC is not guaranteed to run http://blogs.msdn.com/b/oldnewthing/archive/2010/08/09/10047586.aspx http://blogs.msdn.com/b/abhinaba/archive/2008/04/29/when-does-the-net-compact-framework-garbage-collector-run.aspx
  • 12. Helping the GC, avoid pauses Optimize allocations (use struct when it makes sense, Span<T>, object pooling) Don’t allocate when not needed Make use of IDisposable / using statement Clean up references, giving the GC an easy job Weak references Allow the GC to collect these objects, no need for checks Finalizers Beware! Moved to finalizer queue -> always gen++
  • 15. When is memory allocated? Not for value types (int, bool, struct, decimal, enum, float, byte, long, …) Allocated on stack, not on heap Not managed by garbage collector For reference types When you new When you load data into a variable, object, property, ...
  • 16. Hidden allocations! Boxing! Put an int in a box Take an int out of a box Lambda’s/closures Allocate compiler-generated DisplayClass to capture state Params arrays And more! int i = 42; // boxing - wraps the value type in an "object box" // (allocating a System.Object) object o = i; // unboxing - unpacking the "object box" into an int again // (CPU effort to unwrap) int j = (int)o;
  • 17. How to find them? Past experience Intermediate Language (IL) Profiler “Heap allocations viewer” ReSharper Heap Allocations Viewer plugin Roslyn’s Heap Allocation Analyzer
  • 18. Hidden allocations DEMO https://github.com/maartenba/memory-demos ReSharper Heap Allocations Viewer plugin Roslyn’s Heap Allocation Analyzer
  • 19. Measure! Don’t do premature optimization – measure! Allocations don’t always matter (that much) Measure! How frequently are we allocating? How frequently are we collecting? What generation do we end up on? Are our allocations introducing pauses? www.jetbrains.com/dotmemory (and www.jetbrains.com/dottrace)
  • 21.
  • 22. [ { ... }, { "name": "Westmalle Tripel", "brewery": "Brouwerij der Trappisten van Westmalle", "votes": 17658, "rating": 4.7 }, { ... } ]
  • 23. Object pools / object re-use Re-use objects / collections (when it makes sense) Fewer allocations, fewer objects for the GC to scan Less memory traffic that can trigger a full GC Object pooling - object pool pattern Create a pool of objects that can be re-used https://www.codeproject.com/articles/20848/c-object-pooling “Optimize ASP.NET Core” - https://github.com/aspnet/AspLabs/issues/3 System.Buffers.ArrayPool
  • 24. Garbage Collector summary GC is optimized for high memory traffic in short-lived objects Use that knowledge! Don’t fear allocations! Don’t optimize what should not be optimized… GC is the concept that makes .NET / C# tick – use it! Know when allocations happen GC is awesome Gen2 collection that stop the world not so much… Measure!
  • 26. Strings are objects .NET tries to make them look like a value type, but they are a reference type Read-only collection of char Length property A bunch of operator overloading Allocated on the managed heap var a = new string('-', 25); var b = a.Substring(5); var c = httpClient.GetStringAsync("http://blog.maartenballiauw.be");
  • 27. String literals Are all strings on the heap? Are all strings duplicated? var a = "Hello, World!"; var b = "Hello, World!"; Console.WriteLine(a == b); Console.WriteLine(Object.ReferenceEquals(a, b)); Prints true twice. So “Hello World” only in memory once?
  • 29. String literals in #US Compile-time optimization Store literals only once in PE header metadata stream ECMA-335 standard, section II.24.2.4 Reference literals (IL: ldstr) var a = Console.ReadLine(); var b = Console.ReadLine(); Console.WriteLine(a == b); Console.WriteLine(Object.ReferenceEquals(a, b));
  • 30. String duplicates Any .NET application has them (System.Globalization duplicates quite a few) Are they bad? .NET GC is fast for short-lived objects, so meh. Don’t waste memory with string duplicates on gen2 (but: it’s okay to have strings there)
  • 31. String interning Store (and read) strings from the intern pool Simply call String.Intern when “allocating” or reading the string Scans intern pool and returns reference var url = "http://blog.maartenballiauw.be"; var stringList = new List<string>(); for (int i = 0; i < 1000000; i++) { stringList.Add(string.Intern(url + "/")); }
  • 32. String interning caveats Why are not all strings interned by default? CPU vs. memory Not on the heap but on intern pool No GC on intern pool – all strings in memory for AppDomain lifetime! Rule of thumb Lot of long-lived, few unique -> interning good Lot of long-lived, many unique -> no benefit, memory growth Lot of short-lived -> trust the GC Measure!
  • 33. Exploring the heap for fun and profit
  • 34. How would you... …build a managed type system, store in memory, CPU/memory friendly Probably: Store type info (what’s in there, what’s the offset of fieldN, …) Store field data (just data) Store method pointers Inheritance information
  • 35. Stuff on the Stack
  • 36. Stuff on the Managed Heap (scroll down for more...)
  • 37. Theory is nice... Microsoft.Diagnostics.Runtime (ClrMD) “ClrMD is a set of advanced APIs for programmatically inspecting a crash dump of a .NET program much in the same way that the SOS Debugging Extensions (SOS) do. This allows you to write automated crash analysis for your applications as well as automate many common debugger tasks. In addition to reading crash dumps ClrMD also allows supports attaching to live processes.” “LINQ-to-heap” Maarten’s definition
  • 39. But... Why? Programmatic insight into memory space of a running project Unit test critical paths and assert behavior (did we clean up what we expected?) Capture memory issues in running applications Other (easier) options in this space dotMemory Unit (JetBrains) Benchmark.NET
  • 42. Conclusion Garbage Collector (GC) optimized for high memory traffic + short-lived objects Don’t fear allocations! But beware of gen2 “stop the world” Don’t optimize what should not be optimized… Measure! Using a profiler/memory analysis tool ClrMD to automate inspections dotMemory Unit, Benchmark.NET, … to profile unit tests Blog series: https://blog.maartenballiauw.be

Editor's Notes

  1. https://pixabay.com/en/memory-computer-component-pcb-1761599/
  2. https://pixabay.com/en/tires-used-tires-pfu-garbage-1846674/
  3. Application roots: Typically, these are global and static object pointers, local variables, and CPU registers.
  4. Application roots: Typically, these are global and static object pointers, local variables, and CPU registers.
  5. Application roots: Typically, these are global and static object pointers, local variables, and CPU registers.
  6. Open TripDownMemoryLane.sln Show WeakReferenceDemo (demo “1-1”) Explain weak reference allows GC to collect reference Show Cache object – has weak references to data, we expect these to probably be cleaned up by GC Attach profiler, run demo “1-1”, snapshot, see 20 instances of WeakReference<Data> Snapshot again, compare – see WeakReference<Data> has been regenerated a couple of times Show DisposeObjectsDemo (demo “1-2”) Explain first demo does not dispose and relies on GC + finalizers. This will mean our object remains in memory for two GC cycles! Explain dispose does clean them up and requires only one cycle In SampleDisposable, explain GC.SuppressFinalize -> tell the GC no finalizer queue work is needed here!
  7. Open TripDownMemoryLane.sln Show Demo02_Random Open IL viewer tool window, show what happens in IL for each code sample Explain IL viewer + hovering statements to see what they do BoxingRing() – show boxing and unboxing statements in IL, explain they consume CPU and allocate an object ParamsArray() – the call to ParamsArrayImpl() actually allocates a new string array! CPU + memory AverageWithinBounds() – temporary class is created to capture state of all variables, then passed around IL_0000: newobj instance void TripDownMemoryLane.Demo02.Demo02_Random/'<>c__DisplayClass3_0'::.ctor() Lambdas() – same thing, temporary class to capture state in the loop IL_001f: newobj instance void Allocatey.Talk.Demo02_Random/'<>c__DisplayClass4_0'::.ctor() Show Demo02_ValidateArgumentsDemo – this one is fun! Explain what we want to do: build a guard function – check a condition, show error First one is the easy one, but it allocates a string and runs string.Format Second one is better – does not allocate the string! But does allocate a function and a state capture... Third one – allocates an array (params) Fourth one – no allocations, yay! Using overloads... Show heap allocations viewer!
  8. Open TripDownMemoryLane.sln Show BeersDemoUnoptimized (demo “3-1” and “3-2”) Explain we’re building an application that shows all beers in the world and their ratings Stored in beers.json (show document) with beer name, brewery, number of votes For a view in our application, read this file into a multi-dimensional dictionary that contains breweries, beers, and their rating Show BeerLoader and note the dictionary format Show LoadBeersInsane and explain this is BAD BAD BAD because of the high memory usage Show LoadBeersUnoptimized, explain what it does, optimized against the insane version as we’re streaming over our file Load beers a number of times Inspect snapshots GC is very visible Most memory in gen2 (we keep our beers around) Compare two snapshots: high traffic on dictionary items (Lots of string allocations - JSON.NET) Show LoadBeersOptimized, explain what it does, re-using dictionary and updating items as we read the JSON Load beers a number of times Inspect snapshots GC is almost invisible Less allocations happening Compare two snapshots: almost no traffic Less work for GC, less pauses! Measure and make it look good!
  9. There is an old adage in IT that says “don’t do premature optimization”. In other words: maybe some allocations are okay to have, as the GC will take care of cleaning them up anyway. While some do not agree with this, I believe in the middle ground. The garbage collector is optimized for high memory traffic in short-lived objects, and I think it’s okay to make use of what the .NET runtime has to offer us here. If it’s in a critical path of a production application, fewer allocations are better, but we can’t write software with zero allocations - it’s what our high-level programming language uses to make our developer life easier. It’s not okay to have objects go to gen2 and stay there when in fact they should be gone from memory. Learn where allocations happen, using any of the above methods, and profile your production applications frequently to see if there are large objects in higher generations of the heap that don’t belong there.
  10. Will print “true” twice.
  11. Open our demo application in dotPeek Explain PE headers Show #US table Open StringAllocationDemo class. Jump to IL code, show ldstr statement for strings that are in #US table
  12. Code = trick question, what if we enter same value twice? String equals, reference not equals!
  13. How many strings are stored
  14. How many strings are stored
  15. Open ClrMD.sln Explain: two projects, one target application, one running ClrMD to analyze what we have Open ClrMD.Explorer.Program, show attaching ClrMD Get CLR version – gets info about the current CLR version Get runtime – gets info about the actual runtime hosting our app Show DumpClrInfo – get info, stress DAC data access components location – defines the runtime structures, used by ClrMD and VS Debugger etc to explore runtime while debugging/profiling/... Explore DumpHeapObjects, stress the heap structure Loop object addresses - foreach (var objectAddress in generation) Get type of object at address - var type = heap.GetObjectType(objectAddress.Ptr); Use type info to get value - type.GetValue(objectAddress.Ptr) Explore type autocomplete – structure to get enum, method addresses, ...
  16. Open TestsWithDMU.sln Explain: similar Clock leak as in previous demo Two unit tests that create the clock, and timer. Then run GC.Collect, then use dMU to check whether instances are left in memory. Easy way to test, after investigation, when a memory leak comes back (or not)
  17. https://pixabay.com/en/memory-computer-component-pcb-1761599/
