NuGet beyond Hello World
Maarten Balliauw
@maartenballiauw
3
Who am I?
Maarten Balliauw
Antwerp, Belgium
Developer Advocate, JetBrains
Founder, MyGet
AZUG
Focus on web
ASP.NET MVC, Azure, SignalR, ...
Former MVP Azure & ASPInsider
Big passion: Azure
http://blog.maartenballiauw.be
@maartenballiauw
4
Agenda
Introduction
Maturing NuGet (conventions)
Beyond package dependencies
Extending tools
Using client SDK
Server API
5
Introduction
6
NuGet?
Project started in 2011 to make dependency management easier & better
Several things
Repositories
Public repository at www.nuget.org
Private repositories everywhere (www.myget.org )
Clients & tools
NuGet.exe, Visual Studio, Rider, Xamarin Studio, Paket, …
dotnet CLI tools
Conventions
7
NuGet evolution
Others have been doing package management for decades
Perl (CPAN.org)
Linux (RPM/YUM/APT-GET/...)
PHP (PEAR, Composer)
Node (npm)
Ruby (Gems)
We can learn a great deal from these! (and we did, with .NET Core / new .csproj)
8
Learnings
Every project is a package
Clearly identifyable
Proper Semantic Versioning
Tooling makes it easy to package
Every project becomes discoverable
Nice description, release notes, ...
Add it to a (private) feed so developers can find it
Dependencies stay out of source control
Dependencies are versioned
9
Maturing NuGet
10
Package producers are
responsible for consumers.
- Maarten Balliauw
11
It’s easy to break the world…
NPM and left-pad http://www.haneycodes.net/npm-left-pad-have-we-forgotten-how-to-program/
Package removed…
Switch to .NET 4.6.1, suddenly can’t start application https://github.com/dotnet/announcements/issues/6
Caused by System.Net.Http changes
Change in behaviour (new Exception type thrown)
Some public method signatures changed
Need for conventions!
12
Don’t break the world!
Never delete a package (unless it’s absolutely unused)
https://docs.microsoft.com/en-us/nuget/policies/deleting-packages
Versioning = specify intent
Detect public API changes
Use semantic versioning
Targeting = specify what is supported
Metadata and symbols = troubleshooting help
13
Versioning
14
Use semantic versioning to state intent
<major>.<minor>.<patch>-<prerelease>+<metadata>
Increment major on breaking change
Increment minor on new feature
Increment patch for bugfixes
Prerelease means it’s not stable yet
Metadata can annotate build info (not supported on NuGet.org yet)
http://semver.org/
15
State intent & acceptable changes
Semantic versioning states intent
Did we break something?
Do you need this update? (feature/bugfix)
Are we on scary territory? (prerelease)
Helps consumers specify dependency ranges
1.0 = 1.0 ≤ x
(,1.0] = x ≤ 1.0
(,1.0) = x < 1.0
[1.0] = x == 1.0
(1.0,) = 1.0 < x
(1.0,2.0) = 1.0 < x < 2.0
[1.0,2.0] = 1.0 ≤ x ≤ 2.0
1.0-* = give me all prereleases in 1.0 ≤ x ≤ 1.1
16
Use the tools
API Comparer
Compare public API surface and detect breaking API’s
https://github.com/ParticularLabs/APIComparer
Example: http://apicomparer.particular.net/compare/rabbitmq.client/3.4.3...3.5.0
GitVersion
Auto-generate package version number based on Git info
https://github.com/GitTools/GitVersion
17
Targeting
18
Frameworks and versions
.NET has so many frameworks!
.NET framework, .NET Core, Xamarin, Tizen, Micro Framework
Windows Phone
Nice list in NuGet repo: FrameworkConstants.cs
Our NuGet package may not (want to) support them all
Be specific about targeting – state platform support
Target one or multiple
19
Multi-targeting
demo
20
.NET Standard
Multi-targeting can be exhausting (add and test all TFM configurations)
Just select one TFM: .NET Standard https://github.com/dotnet/standard
Defines API’s a platform should implement as a minimum
Specification describing supported features (not platforms)
Higher version: more fx features exposed to your library
Lower version: less features but more platforms supported
https://docs.microsoft.com/en-us/dotnet/articles/standard/library
21
Metadata & symbols
22
Metadata
Make it easy for people to find:
Description
Release notes
Project site
License info
...
(also shown in IDE)
23
Symbols
Help people troubleshoot!
Their own code by understanding yours
Your code (better issues logged / PR)
Publish package symbols
Symbols packages – IncludeSource & IncludeSymbols
Needs symbol server like SymbolSource.org / MyGet.org / …
Portable PDB (symbols + sources embedded) – tools like GitLink / SourceLink
Just works™ - but some effort needed as a package author
24
Metadata and symbols
demo
25
Beyond project
dependencies
26
NuGet
More than just a package manager
Extensibility (dotnet CLI)
NuGet is… a protocol!
API for transferring metadata and binaries
Server API
Client-side libraries
Versioning system built-in
27
Extending dotnet CLI
28
Extending dotnet CLI
Why?
Examples
dotnet nuget – the NuGet command line, integrated
dotnet ef – Entity Framework command line tools
Create tools your team/customers can use
dotnet protobuf – Companion tool for creating protobuf models
After this talk, go and build for me 
dotnet outdated – Scan and show outdated package references
dotnet mirror – Mirror referenced packages to a local folder
dotnet nuke – Clear all NuGet cache locations
29
Extending dotnet CLI
How?
Create a console application
Name it dotnet-<something>
Package it with <PackageType>DotnetCliTool</PackageType>
Install as a CLI tool (or in %PATH%)
https://github.com/dotnet/docs/blob/master/docs/core/tools/extensibility.md
30
Extending dotnet CLI
demo
https://github.com/maartenba/dotnetcli-init
31
Client SDK
32
Consuming NuGet programatically
Why?
Find package metadata
Download and extract package
Custom build task, custom tool used in CI, …
Distribute applications / plugins as NuGet packages
Transport and versioning come free!
NuGet Package Explorer, R# extension manager, Chocolatey, Octopus Deploy, Seq, CMS like
EPIserver, SiteCore, Orchard, …
33
Consuming NuGet programatically
How?
Old world: NuGet.Core
New world: NuGet v3 client
Series of packages, NuGet.PackageManagement being the main package
Open-source on GitHub
Dave Glick has a good series (part 1, part 2, part 3)
34
Packages to install
NuGet.PackageManagement
Overall management of packages, sources, …
NuGet.Protocol.Core.v2
V2 protocol client (OData)
NuGet.Protocol.Core.v3
V3 protocol client (JSON and randomness)
NuGet.ProjectManagement
Project system (inside IDE and inside file system)
NuGet.Packaging
Read and write .nuspec and .nupkg
NuGet.Versioning
Implements working with versions and ranges
NuGet.Commands (optional)
Command-line commens (spec, pack, publish, ...) implemented as static classes mostly
35
NuGet, via C#
demo
36
A few things to know…
All operations performed via resources (e.g. PackageSearchResource,
ListCommandResource, …)
All operations performed against a project
Folder (note: only supports installing as there is no tracking)
PackagesConfig
MSBuild
Your own implementation
Package manager orchestrates all operations
Package repository holds packages (can be remote or local)
37
SearchPortal
demo
38
Server API
39
NuGet talks to a repository
Can be on disk/network share
Or remote over HTTP(S)
2* API’s
V2 – OData based (used by pretty much all NuGet servers out there)
V3 – JSON based (available on NuGet.org and MyGet.org)
* This is a lie…
40
V2 Protocol
OData, started as “OData-to-LINQ-to-Entities” (V1 protocol)
Optimizations added to reduce # of random DB queries (VS2013+ & NuGet 2.x)
Search – Package manager list/search
FindPackagesById – Package restore (Does it exist? Where to download?)
GetUpdates – Package manager updates
https://www.nuget.org/api/v2 (code in https://github.com/NuGet/NuGetGallery)
41
V3 Protocol
JSON based
More of a “resource provider” (see client SDK) of various endpoints per purpose
Catalog (NuGet.org only) – append-only event log
Registrations – latest incarnation of a package
Flat container - .NET Core package restore (and VS autocompletion)
Report abuse URL template
Statistics
…
https://api.nuget.org/v3/index.json (code in https://github.com/NuGet/NuGet.Services.Metadata)
42
V3 Protocol is… interesting
Service index points to resources
@id, @type (versioned), comment
Client should load-balance on @type occurrences
NuGet.org does this to perform search etc.: RetryingHttpClientWrapper
(also has a request queue)
Many views on the same data
Specific to a scenario in the client
Some compute based, some storage based
Search, autocomplete -> compute
Registrations, flatcontainer -> storage
Catalog -> NuGet.org internal use
43
Server API
demo
44
How does it fit together?
User uploads to NuGet.org
Data added to database
Data added to catalog (append-only data stream)
Various jobs run over catalog using a cursor
Registrations (last state of a package/version), reference catalog entry
Flatcontainer (fast restores)
Search index (search, autocomplete, NuGet Gallery search)
45
How does it fit together?
User uploads to NuGet.org
Data added to database
Data added to catalog (append-only data stream)
Various jobs run over catalog using a cursor
Registrations (last state of a package/version), reference catalog entry
Flatcontainer (fast restores)
Search index (search, autocomplete, NuGet Gallery search)
46
NuGet.org catalog
demo
47
Catalog data
Updates (add/update)
Deletes
Chronological
Can continue where left off
Can restore NuGet.org to a given point in time
Why use it?
Mirror locally
Send notifications when certain packages changed
Build own index, build own datastore based on data
E.g. https://packagesearch.azurewebsites.net/
…
48
Other extensibility
points
49
Other extensibility points
NuGet Credential Provider
https://docs.microsoft.com/en-us/nuget/api/nuget-exe-credential-providers
NuGet package download
https://github.com/NuGet/Home/wiki/NuGet-Package-Download-Plugin
50
Conclusion
51
Conclusion
Go out and create packages!
Follow conventions, help your consumers, help mature NuGet
Versioning
Targeting
Symbols
Consider NuGet not only as package dependencies but as a protocol
Tooling extensibility
Protocol for metadata and versioning
52
Thank you!
http://blog.maartenballiauw.be
@maartenballiauw

More Related Content

What's hot

Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome
Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome
Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome
Massimiliano Dessì

ABCs of docker
ABCs of dockerABCs of docker
ABCs of docker
Sabyrzhan Tynybayev

C++ for the Web
C++ for the WebC++ for the Web
C++ for the Web
Patrick Charrier

Treinamento Qt básico - aula I
Treinamento Qt básico - aula ITreinamento Qt básico - aula I
Treinamento Qt básico - aula I
Marcelo Barros de Almeida

03 - Qt UI Development
03 - Qt UI Development03 - Qt UI Development
03 - Qt UI Development
Andreas Jakl

An Introduction to CMake
An Introduction to CMakeAn Introduction to CMake
An Introduction to CMake
ICS

A Brief Introduction to the Qt Application Framework
A Brief Introduction to the Qt Application FrameworkA Brief Introduction to the Qt Application Framework
A Brief Introduction to the Qt Application Framework
Zachary Blair

Gradle in 45min
Gradle in 45minGradle in 45min
Gradle in 45min
Schalk Cronjé

Kubernetes
KubernetesKubernetes
Kubernetes
Lhouceine OUHAMZA

Qt for beginners
Qt for beginnersQt for beginners
Qt for beginners
Sergio Shevchenko

The Ring programming language version 1.8 book - Part 77 of 202
The Ring programming language version 1.8 book - Part 77 of 202The Ring programming language version 1.8 book - Part 77 of 202
The Ring programming language version 1.8 book - Part 77 of 202
Mahmoud Samir Fayed

Docker workshop 0507 Taichung
Docker workshop 0507 Taichung Docker workshop 0507 Taichung
Docker workshop 0507 Taichung
Paul Chao

Build and run embedded apps faster from qt creator with docker
Build and run embedded apps faster from qt creator with dockerBuild and run embedded apps faster from qt creator with docker
Build and run embedded apps faster from qt creator with docker
Qt

Gradle build tool that rocks with DSL JavaOne India 4th May 2012
Gradle build tool that rocks with DSL JavaOne India 4th May 2012Gradle build tool that rocks with DSL JavaOne India 4th May 2012
Gradle build tool that rocks with DSL JavaOne India 4th May 2012
Rajmahendra Hegde

Some wonderful Linux softwares for daily use
Some wonderful Linux softwares for daily useSome wonderful Linux softwares for daily use
Some wonderful Linux softwares for daily use
arun.arwachin

The Ring programming language version 1.7 book - Part 75 of 196
The Ring programming language version 1.7 book - Part 75 of 196The Ring programming language version 1.7 book - Part 75 of 196
The Ring programming language version 1.7 book - Part 75 of 196
Mahmoud Samir Fayed

manual
manualmanual
Using the android ndk - DroidCon Paris 2014
Using the android ndk - DroidCon Paris 2014Using the android ndk - DroidCon Paris 2014
Using the android ndk - DroidCon Paris 2014
Paris Android User Group

Exploring Google (Cloud) APIs with Python & JavaScript
Exploring Google (Cloud) APIs with Python & JavaScriptExploring Google (Cloud) APIs with Python & JavaScript
Exploring Google (Cloud) APIs with Python & JavaScript
wesley chun

Docker - Der Wal in der Kiste
Docker - Der Wal in der KisteDocker - Der Wal in der Kiste
Docker - Der Wal in der Kiste
Ulrich Krause


What's hot (20)

Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome
Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome
Microservices in Go_Dessi_Massimiliano_Codemotion_2017_Rome

ABCs of docker
ABCs of dockerABCs of docker
ABCs of docker

C++ for the Web
C++ for the WebC++ for the Web
C++ for the Web

Treinamento Qt básico - aula I
Treinamento Qt básico - aula ITreinamento Qt básico - aula I
Treinamento Qt básico - aula I

03 - Qt UI Development
03 - Qt UI Development03 - Qt UI Development
03 - Qt UI Development

An Introduction to CMake
An Introduction to CMakeAn Introduction to CMake
An Introduction to CMake

A Brief Introduction to the Qt Application Framework
A Brief Introduction to the Qt Application FrameworkA Brief Introduction to the Qt Application Framework
A Brief Introduction to the Qt Application Framework

Gradle in 45min
Gradle in 45minGradle in 45min
Gradle in 45min

Kubernetes
KubernetesKubernetes
Kubernetes

Qt for beginners
Qt for beginnersQt for beginners
Qt for beginners

The Ring programming language version 1.8 book - Part 77 of 202
The Ring programming language version 1.8 book - Part 77 of 202The Ring programming language version 1.8 book - Part 77 of 202
The Ring programming language version 1.8 book - Part 77 of 202

Docker workshop 0507 Taichung
Docker workshop 0507 Taichung Docker workshop 0507 Taichung
Docker workshop 0507 Taichung

Build and run embedded apps faster from qt creator with docker
Build and run embedded apps faster from qt creator with dockerBuild and run embedded apps faster from qt creator with docker
Build and run embedded apps faster from qt creator with docker

Gradle build tool that rocks with DSL JavaOne India 4th May 2012
Gradle build tool that rocks with DSL JavaOne India 4th May 2012Gradle build tool that rocks with DSL JavaOne India 4th May 2012
Gradle build tool that rocks with DSL JavaOne India 4th May 2012

Some wonderful Linux softwares for daily use
Some wonderful Linux softwares for daily useSome wonderful Linux softwares for daily use
Some wonderful Linux softwares for daily use

The Ring programming language version 1.7 book - Part 75 of 196
The Ring programming language version 1.7 book - Part 75 of 196The Ring programming language version 1.7 book - Part 75 of 196
The Ring programming language version 1.7 book - Part 75 of 196

manual
manualmanual
manual

Using the android ndk - DroidCon Paris 2014
Using the android ndk - DroidCon Paris 2014Using the android ndk - DroidCon Paris 2014
Using the android ndk - DroidCon Paris 2014

Exploring Google (Cloud) APIs with Python & JavaScript
Exploring Google (Cloud) APIs with Python & JavaScriptExploring Google (Cloud) APIs with Python & JavaScript
Exploring Google (Cloud) APIs with Python & JavaScript

Docker - Der Wal in der Kiste
Docker - Der Wal in der KisteDocker - Der Wal in der Kiste
Docker - Der Wal in der Kiste


Similar to NuGet beyond Hello World - DotNext Piter 2017

ConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello WorldConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello World
Maarten Balliauw

Kubernetes for the PHP developer
Kubernetes for the PHP developerKubernetes for the PHP developer
Kubernetes for the PHP developer
Paul Czarkowski

A DevOps guide to Kubernetes
A DevOps guide to KubernetesA DevOps guide to Kubernetes
A DevOps guide to Kubernetes
Paul Czarkowski

Operator SDK for K8s using Go
Operator SDK for K8s using GoOperator SDK for K8s using Go
Operator SDK for K8s using Go
CloudOps2005

Organize your chickens: NuGet for the enterprise
Organize your chickens: NuGet for the enterpriseOrganize your chickens: NuGet for the enterprise
Organize your chickens: NuGet for the enterprise
Maarten Balliauw

Let's build Developer Portal with Backstage
Let's build Developer Portal with BackstageLet's build Developer Portal with Backstage
Let's build Developer Portal with Backstage
Opsta

The App Developer's Kubernetes Toolbox
The App Developer's Kubernetes ToolboxThe App Developer's Kubernetes Toolbox
The App Developer's Kubernetes Toolbox
Nebulaworks

Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)
Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)
Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)
QAware GmbH

Monitoring Cloud Native Applications with Prometheus
Monitoring Cloud Native Applications with PrometheusMonitoring Cloud Native Applications with Prometheus
Monitoring Cloud Native Applications with Prometheus
Jacopo Nardiello

Understanding NuGet implementation for Enterprises
Understanding NuGet implementation for EnterprisesUnderstanding NuGet implementation for Enterprises
Understanding NuGet implementation for Enterprises
J S Jodha

Fullstack workshop
Fullstack workshopFullstack workshop
Fullstack workshop
Assaf Gannon

Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)
Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)
Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)
Fabrice Bernhard

Weave User Group Talk - DockerCon 2017 Recap
Weave User Group Talk - DockerCon 2017 RecapWeave User Group Talk - DockerCon 2017 Recap
Weave User Group Talk - DockerCon 2017 Recap
Patrick Chanezon

Kubernetes for Java Developers
Kubernetes for Java DevelopersKubernetes for Java Developers
Kubernetes for Java Developers
Anthony Dahanne

給 RD 的 Kubernetes 初體驗
給 RD 的 Kubernetes 初體驗給 RD 的 Kubernetes 初體驗
給 RD 的 Kubernetes 初體驗
William Yeh

Making your app soar without a container manifest
Making your app soar without a container manifestMaking your app soar without a container manifest
Making your app soar without a container manifest
LibbySchulze

Red Hat Forum Benelux 2015
Red Hat Forum Benelux 2015Red Hat Forum Benelux 2015
Red Hat Forum Benelux 2015
Microsoft

The DevOps paradigm - the evolution of IT professionals and opensource toolkit
The DevOps paradigm - the evolution of IT professionals and opensource toolkitThe DevOps paradigm - the evolution of IT professionals and opensource toolkit
The DevOps paradigm - the evolution of IT professionals and opensource toolkit
Marco Ferrigno

The DevOps Paradigm
The DevOps ParadigmThe DevOps Paradigm
The DevOps Paradigm
NaLUG

Kubernetes - how to orchestrate containers
Kubernetes - how to orchestrate containersKubernetes - how to orchestrate containers
Kubernetes - how to orchestrate containers
inovex GmbH


Similar to NuGet beyond Hello World - DotNext Piter 2017 (20)

ConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello WorldConFoo - NuGet beyond Hello World
ConFoo - NuGet beyond Hello World

Kubernetes for the PHP developer
Kubernetes for the PHP developerKubernetes for the PHP developer
Kubernetes for the PHP developer

A DevOps guide to Kubernetes
A DevOps guide to KubernetesA DevOps guide to Kubernetes
A DevOps guide to Kubernetes

Operator SDK for K8s using Go
Operator SDK for K8s using GoOperator SDK for K8s using Go
Operator SDK for K8s using Go

Organize your chickens: NuGet for the enterprise
Organize your chickens: NuGet for the enterpriseOrganize your chickens: NuGet for the enterprise
Organize your chickens: NuGet for the enterprise

Let's build Developer Portal with Backstage
Let's build Developer Portal with BackstageLet's build Developer Portal with Backstage
Let's build Developer Portal with Backstage

The App Developer's Kubernetes Toolbox
The App Developer's Kubernetes ToolboxThe App Developer's Kubernetes Toolbox
The App Developer's Kubernetes Toolbox

Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)
Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)
Kubernetes One-Click Deployment: Hands-on Workshop (Mainz)

Monitoring Cloud Native Applications with Prometheus
Monitoring Cloud Native Applications with PrometheusMonitoring Cloud Native Applications with Prometheus
Monitoring Cloud Native Applications with Prometheus

Understanding NuGet implementation for Enterprises
Understanding NuGet implementation for EnterprisesUnderstanding NuGet implementation for Enterprises
Understanding NuGet implementation for Enterprises

Fullstack workshop
Fullstack workshopFullstack workshop
Fullstack workshop

Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)
Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)
Adopt DevOps philosophy on your Symfony projects (Symfony Live 2011)

Weave User Group Talk - DockerCon 2017 Recap
Weave User Group Talk - DockerCon 2017 RecapWeave User Group Talk - DockerCon 2017 Recap
Weave User Group Talk - DockerCon 2017 Recap

Kubernetes for Java Developers
Kubernetes for Java DevelopersKubernetes for Java Developers
Kubernetes for Java Developers

給 RD 的 Kubernetes 初體驗
給 RD 的 Kubernetes 初體驗給 RD 的 Kubernetes 初體驗
給 RD 的 Kubernetes 初體驗

Making your app soar without a container manifest
Making your app soar without a container manifestMaking your app soar without a container manifest
Making your app soar without a container manifest

Red Hat Forum Benelux 2015
Red Hat Forum Benelux 2015Red Hat Forum Benelux 2015
Red Hat Forum Benelux 2015

The DevOps paradigm - the evolution of IT professionals and opensource toolkit
The DevOps paradigm - the evolution of IT professionals and opensource toolkitThe DevOps paradigm - the evolution of IT professionals and opensource toolkit
The DevOps paradigm - the evolution of IT professionals and opensource toolkit

The DevOps Paradigm
The DevOps ParadigmThe DevOps Paradigm
The DevOps Paradigm

Kubernetes - how to orchestrate containers
Kubernetes - how to orchestrate containersKubernetes - how to orchestrate containers
Kubernetes - how to orchestrate containers


More from Maarten Balliauw

Bringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptxBringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptx
Maarten Balliauw

Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Maarten Balliauw

Building a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to SpaceBuilding a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to Space
Maarten Balliauw

Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Maarten Balliauw

Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Maarten Balliauw

NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
Maarten Balliauw

JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
Maarten Balliauw

.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se....NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
Maarten Balliauw

CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
Maarten Balliauw

NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and SearchNDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
Maarten Balliauw

Approaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days PolandApproaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days Poland
Maarten Balliauw

Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Maarten Balliauw

Approaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologneApproaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologne
Maarten Balliauw

CodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory laneCodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory lane
Maarten Balliauw

ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
Maarten Balliauw

ConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttlingConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttling
Maarten Balliauw

Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Maarten Balliauw

JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
Maarten Balliauw

DotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NETDotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NET
Maarten Balliauw

VISUG - Approaches for application request throttling
VISUG - Approaches for application request throttlingVISUG - Approaches for application request throttling
VISUG - Approaches for application request throttling
Maarten Balliauw


More from Maarten Balliauw (20)

Bringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptxBringing nullability into existing code - dammit is not the answer.pptx
Bringing nullability into existing code - dammit is not the answer.pptx

Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...
Nerd sniping myself into a rabbit hole... Streaming online audio to a Sonos s...

Building a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to SpaceBuilding a friendly .NET SDK to connect to Space
Building a friendly .NET SDK to connect to Space

Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...
Microservices for building an IDE - The innards of JetBrains Rider - NDC Oslo...

Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...
Indexing and searching NuGet.org with Azure Functions and Search - .NET fwday...

NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...
NDC Sydney 2019 - Microservices for building an IDE – The innards of JetBrain...

JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...
JetBrains Australia 2019 - Exploring .NET’s memory management – a trip down m...

.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se....NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...
.NET Conf 2019 - Indexing and searching NuGet.org with Azure Functions and Se...

CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...
CloudBurst 2019 - Indexing and searching NuGet.org with Azure Functions and S...

NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and SearchNDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search
NDC Oslo 2019 - Indexing and searching NuGet.org with Azure Functions and Search

Approaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days PolandApproaches for application request throttling - Cloud Developer Days Poland
Approaches for application request throttling - Cloud Developer Days Poland

Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...
Indexing and searching NuGet.org with Azure Functions and Search - Cloud Deve...

Approaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologneApproaches for application request throttling - dotNetCologne
Approaches for application request throttling - dotNetCologne

CodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory laneCodeStock - Exploring .NET memory management - a trip down memory lane
CodeStock - Exploring .NET memory management - a trip down memory lane

ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...
ConFoo Montreal - Microservices for building an IDE - The innards of JetBrain...

ConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttlingConFoo Montreal - Approaches for application request throttling
ConFoo Montreal - Approaches for application request throttling

Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...Microservices for building an IDE – The innards of JetBrains Rider - TechDays...
Microservices for building an IDE – The innards of JetBrains Rider - TechDays...

JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...
JetBrains Day Seoul - Exploring .NET’s memory management – a trip down memory...

DotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NETDotNetFest - Let’s refresh our memory! Memory management in .NET
DotNetFest - Let’s refresh our memory! Memory management in .NET

VISUG - Approaches for application request throttling
VISUG - Approaches for application request throttlingVISUG - Approaches for application request throttling
VISUG - Approaches for application request throttling


Recently uploaded

Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...
Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...
Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...
APNIC

Discover the benefits of outsourcing SEO to India
Discover the benefits of outsourcing SEO to IndiaDiscover the benefits of outsourcing SEO to India
Discover the benefits of outsourcing SEO to India
davidjhones387

Securing BGP: Operational Strategies and Best Practices for Network Defenders...
Securing BGP: Operational Strategies and Best Practices for Network Defenders...Securing BGP: Operational Strategies and Best Practices for Network Defenders...
Securing BGP: Operational Strategies and Best Practices for Network Defenders...
APNIC

一比一原版(USYD毕业证)悉尼大学毕业证如何办理
一比一原版(USYD毕业证)悉尼大学毕业证如何办理一比一原版(USYD毕业证)悉尼大学毕业证如何办理
一比一原版(USYD毕业证)悉尼大学毕业证如何办理
k4ncd0z

快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样
快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样
快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样
3a0sd7z3

一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理
一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理
一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理
thezot

怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样
怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样
怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样
rtunex8r

Bengaluru Dreamin' 24 - Personal Branding
Bengaluru Dreamin' 24 - Personal BrandingBengaluru Dreamin' 24 - Personal Branding
Bengaluru Dreamin' 24 - Personal Branding
Tarandeep Singh

Should Repositories Participate in the Fediverse?
Should Repositories Participate in the Fediverse?Should Repositories Participate in the Fediverse?
Should Repositories Participate in the Fediverse?
Paul Walk

办理新西兰奥克兰大学毕业证学位证书范本原版一模一样
办理新西兰奥克兰大学毕业证学位证书范本原版一模一样办理新西兰奥克兰大学毕业证学位证书范本原版一模一样
办理新西兰奥克兰大学毕业证学位证书范本原版一模一样
xjq03c34

HijackLoader Evolution: Interactive Process Hollowing
HijackLoader Evolution: Interactive Process HollowingHijackLoader Evolution: Interactive Process Hollowing
HijackLoader Evolution: Interactive Process Hollowing
Donato Onofri

快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样
快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样
快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样
3a0sd7z3


Recently uploaded (12)

Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...
Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...
Honeypots Unveiled: Proactive Defense Tactics for Cyber Security, Phoenix Sum...

Discover the benefits of outsourcing SEO to India
Discover the benefits of outsourcing SEO to IndiaDiscover the benefits of outsourcing SEO to India
Discover the benefits of outsourcing SEO to India

Securing BGP: Operational Strategies and Best Practices for Network Defenders...
Securing BGP: Operational Strategies and Best Practices for Network Defenders...Securing BGP: Operational Strategies and Best Practices for Network Defenders...
Securing BGP: Operational Strategies and Best Practices for Network Defenders...

一比一原版(USYD毕业证)悉尼大学毕业证如何办理
一比一原版(USYD毕业证)悉尼大学毕业证如何办理一比一原版(USYD毕业证)悉尼大学毕业证如何办理
一比一原版(USYD毕业证)悉尼大学毕业证如何办理

快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样
快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样
快速办理(新加坡SMU毕业证书)新加坡管理大学毕业证文凭证书一模一样

一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理
一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理
一比一原版新西兰林肯大学毕业证(Lincoln毕业证书)学历如何办理

怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样
怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样
怎么办理(umiami毕业证书)美国迈阿密大学毕业证文凭证书实拍图原版一模一样

Bengaluru Dreamin' 24 - Personal Branding
Bengaluru Dreamin' 24 - Personal BrandingBengaluru Dreamin' 24 - Personal Branding
Bengaluru Dreamin' 24 - Personal Branding

Should Repositories Participate in the Fediverse?
Should Repositories Participate in the Fediverse?Should Repositories Participate in the Fediverse?
Should Repositories Participate in the Fediverse?

办理新西兰奥克兰大学毕业证学位证书范本原版一模一样
办理新西兰奥克兰大学毕业证学位证书范本原版一模一样办理新西兰奥克兰大学毕业证学位证书范本原版一模一样
办理新西兰奥克兰大学毕业证学位证书范本原版一模一样

HijackLoader Evolution: Interactive Process Hollowing
HijackLoader Evolution: Interactive Process HollowingHijackLoader Evolution: Interactive Process Hollowing
HijackLoader Evolution: Interactive Process Hollowing

快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样
快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样
快速办理(Vic毕业证书)惠灵顿维多利亚大学毕业证完成信一模一样


NuGet beyond Hello World - DotNext Piter 2017

  • 1. 1 NuGet beyond Hello World Maarten Balliauw @maartenballiauw
  • 2. 3 Who am I? Maarten Balliauw Antwerp, Belgium Developer Advocate, JetBrains Founder, MyGet AZUG Focus on web ASP.NET MVC, Azure, SignalR, ... Former MVP Azure & ASPInsider Big passion: Azure http://blog.maartenballiauw.be @maartenballiauw
  • 3. 4 Agenda Introduction Maturing NuGet (conventions) Beyond package dependencies Extending tools Using client SDK Server API
  • 5. 6 NuGet? Project started in 2011 to make dependency management easier & better Several things Repositories Public repository at www.nuget.org Private repositories everywhere (www.myget.org ) Clients & tools NuGet.exe, Visual Studio, Rider, Xamarin Studio, Paket, … dotnet CLI tools Conventions
  • 6. 7 NuGet evolution Others have been doing package management for decades Perl (CPAN.org) Linux (RPM/YUM/APT-GET/...) PHP (PEAR, Composer) Node (npm) Ruby (Gems) We can learn a great deal from these! (and we did, with .NET Core / new .csproj)
  • 7. 8 Learnings Every project is a package Clearly identifyable Proper Semantic Versioning Tooling makes it easy to package Every project becomes discoverable Nice description, release notes, ... Add it to a (private) feed so developers can find it Dependencies stay out of source control Dependencies are versioned
  • 9. 10 Package producers are responsible for consumers. - Maarten Balliauw
  • 10. 11 It’s easy to break the world… NPM and left-pad http://www.haneycodes.net/npm-left-pad-have-we-forgotten-how-to-program/ Package removed… Switch to .NET 4.6.1, suddenly can’t start application https://github.com/dotnet/announcements/issues/6 Caused by System.Net.Http changes Change in behaviour (new Exception type thrown) Some public method signatures changed Need for conventions!
  • 11. 12 Don’t break the world! Never delete a package (unless it’s absolutely unused) https://docs.microsoft.com/en-us/nuget/policies/deleting-packages Versioning = specify intent Detect public API changes Use semantic versioning Targeting = specify what is supported Metadata and symbols = troubleshooting help
  • 13. 14 Use semantic versioning to state intent <major>.<minor>.<patch>-<prerelease>+<metadata> Increment major on breaking change Increment minor on new feature Increment patch for bugfixes Prerelease means it’s not stable yet Metadata can annotate build info (not supported on NuGet.org yet) http://semver.org/
  • 14. 15 State intent & acceptable changes Semantic versioning states intent Did we break something? Do you need this update? (feature/bugfix) Are we on scary territory? (prerelease) Helps consumers specify dependency ranges 1.0 = 1.0 ≤ x (,1.0] = x ≤ 1.0 (,1.0) = x < 1.0 [1.0] = x == 1.0 (1.0,) = 1.0 < x (1.0,2.0) = 1.0 < x < 2.0 [1.0,2.0] = 1.0 ≤ x ≤ 2.0 1.0-* = give me all prereleases in 1.0 ≤ x ≤ 1.1
  • 15. 16 Use the tools API Comparer Compare public API surface and detect breaking API’s https://github.com/ParticularLabs/APIComparer Example: http://apicomparer.particular.net/compare/rabbitmq.client/3.4.3...3.5.0 GitVersion Auto-generate package version number based on Git info https://github.com/GitTools/GitVersion
  • 17. 18 Frameworks and versions .NET has so many frameworks! .NET framework, .NET Core, Xamarin, Tizen, Micro Framework Windows Phone Nice list in NuGet repo: FrameworkConstants.cs Our NuGet package may not (want to) support them all Be specific about targeting – state platform support Target one or multiple
  • 19. 20 .NET Standard Multi-targeting can be exhausting (add and test all TFM configurations) Just select one TFM: .NET Standard https://github.com/dotnet/standard Defines API’s a platform should implement as a minimum Specification describing supported features (not platforms) Higher version: more fx features exposed to your library Lower version: less features but more platforms supported https://docs.microsoft.com/en-us/dotnet/articles/standard/library
  • 21. 22 Metadata Make it easy for people to find: Description Release notes Project site License info ... (also shown in IDE)
  • 22. 23 Symbols Help people troubleshoot! Their own code by understanding yours Your code (better issues logged / PR) Publish package symbols Symbols packages – IncludeSource & IncludeSymbols Needs symbol server like SymbolSource.org / MyGet.org / … Portable PDB (symbols + sources embedded) – tools like GitLink / SourceLink Just works™ - but some effort needed as a package author
  • 25. 26 NuGet More than just a package manager Extensibility (dotnet CLI) NuGet is… a protocol! API for transferring metadata and binaries Server API Client-side libraries Versioning system built-in
  • 27. 28 Extending dotnet CLI Why? Examples dotnet nuget – the NuGet command line, integrated dotnet ef – Entity Framework command line tools Create tools your team/customers can use dotnet protobuf – Companion tool for creating protobuf models After this talk, go and build for me  dotnet outdated – Scan and show outdated package references dotnet mirror – Mirror referenced packages to a local folder dotnet nuke – Clear all NuGet cache locations
  • 28. 29 Extending dotnet CLI How? Create a console application Name it dotnet-<something> Package it with <PackageType>DotnetCliTool</PackageType> Install as a CLI tool (or in %PATH%) https://github.com/dotnet/docs/blob/master/docs/core/tools/extensibility.md
  • 31. 32 Consuming NuGet programatically Why? Find package metadata Download and extract package Custom build task, custom tool used in CI, … Distribute applications / plugins as NuGet packages Transport and versioning come free! NuGet Package Explorer, R# extension manager, Chocolatey, Octopus Deploy, Seq, CMS like EPIserver, SiteCore, Orchard, …
  • 32. 33 Consuming NuGet programatically How? Old world: NuGet.Core New world: NuGet v3 client Series of packages, NuGet.PackageManagement being the main package Open-source on GitHub Dave Glick has a good series (part 1, part 2, part 3)
  • 33. 34 Packages to install NuGet.PackageManagement Overall management of packages, sources, … NuGet.Protocol.Core.v2 V2 protocol client (OData) NuGet.Protocol.Core.v3 V3 protocol client (JSON and randomness) NuGet.ProjectManagement Project system (inside IDE and inside file system) NuGet.Packaging Read and write .nuspec and .nupkg NuGet.Versioning Implements working with versions and ranges NuGet.Commands (optional) Command-line commens (spec, pack, publish, ...) implemented as static classes mostly
  • 35. 36 A few things to know… All operations performed via resources (e.g. PackageSearchResource, ListCommandResource, …) All operations performed against a project Folder (note: only supports installing as there is no tracking) PackagesConfig MSBuild Your own implementation Package manager orchestrates all operations Package repository holds packages (can be remote or local)
  • 38. 39 NuGet talks to a repository Can be on disk/network share Or remote over HTTP(S) 2* API’s V2 – OData based (used by pretty much all NuGet servers out there) V3 – JSON based (available on NuGet.org and MyGet.org) * This is a lie…
  • 39. 40 V2 Protocol OData, started as “OData-to-LINQ-to-Entities” (V1 protocol) Optimizations added to reduce # of random DB queries (VS2013+ & NuGet 2.x) Search – Package manager list/search FindPackagesById – Package restore (Does it exist? Where to download?) GetUpdates – Package manager updates https://www.nuget.org/api/v2 (code in https://github.com/NuGet/NuGetGallery)
  • 40. 41 V3 Protocol JSON based More of a “resource provider” (see client SDK) of various endpoints per purpose Catalog (NuGet.org only) – append-only event log Registrations – latest incarnation of a package Flat container - .NET Core package restore (and VS autocompletion) Report abuse URL template Statistics … https://api.nuget.org/v3/index.json (code in https://github.com/NuGet/NuGet.Services.Metadata)
  • 41. 42 V3 Protocol is… interesting Service index points to resources @id, @type (versioned), comment Client should load-balance on @type occurrences NuGet.org does this to perform search etc.: RetryingHttpClientWrapper (also has a request queue) Many views on the same data Specific to a scenario in the client Some compute based, some storage based Search, autocomplete -> compute Registrations, flatcontainer -> storage Catalog -> NuGet.org internal use
  • 43. 44 How does it fit together? User uploads to NuGet.org Data added to database Data added to catalog (append-only data stream) Various jobs run over catalog using a cursor Registrations (last state of a package/version), reference catalog entry Flatcontainer (fast restores) Search index (search, autocomplete, NuGet Gallery search)
  • 44. 45 How does it fit together? User uploads to NuGet.org Data added to database Data added to catalog (append-only data stream) Various jobs run over catalog using a cursor Registrations (last state of a package/version), reference catalog entry Flatcontainer (fast restores) Search index (search, autocomplete, NuGet Gallery search)
  • 46. 47 Catalog data Updates (add/update) Deletes Chronological Can continue where left off Can restore NuGet.org to a given point in time Why use it? Mirror locally Send notifications when certain packages changed Build own index, build own datastore based on data E.g. https://packagesearch.azurewebsites.net/ …
  • 48. 49 Other extensibility points NuGet Credential Provider https://docs.microsoft.com/en-us/nuget/api/nuget-exe-credential-providers NuGet package download https://github.com/NuGet/Home/wiki/NuGet-Package-Download-Plugin
  • 50. 51 Conclusion Go out and create packages! Follow conventions, help your consumers, help mature NuGet Versioning Targeting Symbols Consider NuGet not only as package dependencies but as a protocol Tooling extensibility Protocol for metadata and versioning

Editor's Notes

  1. https://pixabay.com
  2. https://pixabay.com/en/tires-used-tires-pfu-garbage-1846674/
  3. Talk about how we learned from the others to consider everythign we make a package. In .NET Core this is made easier by having tooling to quickly set metadata and publish the package.
  4. https://pixabay.com/en/tires-used-tires-pfu-garbage-1846674/
  5. Multi-targeting used to be a pain, different compilation steps, manually compose NuGet package Now: easy! Open VS and create new project View project properties, Packaging, tick the box, provide some metadata Open the .csproj file to show this data is in the .csproj Build, see package is created Increment major version as we are changing TFM’s which is probably breaking, be good citizen! Edit project file and add more TFM’s <TargetFrameworks>netstandard16;net45;net462</TargetFrameworks> (NOTE THE PLURAL S) Explain we can use directives now, too, e.g. #if NET462 Compile and build, open package in package explorer See we now have a package that supports multiple, and NuGet client will use correct on in consumer projects
  6. Open VS project from previous demo Show metadata options that can be provided (license, release notes, ...) How to enable symbols publishing? Symbols package – add <IncludeSource>True</IncludeSource> and add <IncludeSymbols>True</IncludeSymbols> Show resulting packages and what is in them Explain both need to be uploaded in order to provide debugger step through etc Good to keep code private / only share symbols with known users Portable/embedded PDB where symbols and sources are embedded using GitLink/SourceLink Check website on how to set it up Result: it just works Create console app
  7. https://pixabay.com/en/tires-used-tires-pfu-garbage-1846674/
  8. Show the tool in action! Open Rider, create new class library Edit project file, add <ItemGroup><DotNetCliToolReference Include="DotNetInit" Version="*" /></ItemGroup> Run dotnet restore & dotnet init (in correct folder) Profit How to create such tool? Not going to go through code completely as it’s on GitHub, but in simple terms: Open https://github.com/maartenba/dotnetcli-init See it’s just Program.cs that takes args Can be run standalone Edit project file, show: To be part of dotnet-cli -> name it dotnet-<something> Package type (case sensitive)
  9. Create new Console Application in Rider Explain we will build 2 scenarios: a search which displays package metadata, and an install/extract Add NuGet package: NuGet.PackageManagement (should bring down all dependencies we need) AND NuGet.Protocol.Core.v2 Let’s start with search first. Program.cs -> SearchPackageAndDumpDetails("json"); Code – make sure to explain: ILogger Everything is based around resource providers (like protocol support, search, …) private static async Task SearchPackageAndDumpDetails(string searchTerm) { var logger = new NullLogger(); var providers = new List<Lazy<INuGetResourceProvider>>(); providers.AddRange(Repository.Provider.GetCoreV2()); providers.AddRange(Repository.Provider.GetCoreV3()); var packageSource = new PackageSource("https://api.nuget.org/v3/index.json"); var repository = new SourceRepository(packageSource, providers); var searchResource = await repository.GetResourceAsync<PackageSearchResource>(); var searchResults = await searchResource.SearchAsync(searchTerm, new SearchFilter(includePrerelease: true), 0, 10, logger, CancellationToken.None); foreach (var searchResult in searchResults) { Console.WriteLine(searchResult.Identity.Id + " " + searchResult.Identity.Version); } Console.ReadLine(); } Now let’s also install a package. For this, we need a project context. Mention context provider for logging or use EmptyNuGetProjectContext Code: private static async Task InstallPackage(string packageId, string packageVersion, bool includeDependencies) { // Package we ant to install var packageIdentity = new PackageIdentity(packageId, NuGetVersion.Parse(packageVersion)); // Remote var providers = new List<Lazy<INuGetResourceProvider>>(); providers.AddRange(Repository.Provider.GetCoreV2()); providers.AddRange(Repository.Provider.GetCoreV3()); var packageSource = new PackageSource("https://api.nuget.org/v3/index.json"); var repository = new SourceRepository(packageSource, providers); // Local var projectPath = "c:\\users\\maart\\desktop\\temp"; var packagesPath = "c:\\users\\maart\\desktop\\temp\\packages"; var project = new FolderNuGetProject(projectPath); var settings = Settings.LoadDefaultSettings(projectPath, null, new XPlatMachineWideSetting()); // Create package manager var repositoryProvider = new SourceRepositoryProvider(settings, providers); var packageManager = new NuGetPackageManager(repositoryProvider, settings, packagesPath) { PackagesFolderNuGetProject = project }; // Create dependency resolution context (no prerelease/unlisted) var dependencyBehaviour = includeDependencies ? DependencyBehavior.Lowest : DependencyBehavior.Ignore; var resolutionContext = new ResolutionContext(dependencyBehaviour, false, false, VersionConstraints.None); // Install the package already var projectContext = new LoggingNuGetProjectContext(); await packageManager.InstallPackageAsync(packageManager.PackagesFolderNuGetProject, packageIdentity, resolutionContext, projectContext, repository, new SourceRepository[] {}, CancellationToken.None); }
  10. Open SearchPortal application, demo things (install plugin, see it shows up in portal) In code, walk through PluginManager class Plugins stored in plugins folder ListPlugins -> searches remote and combines with local which is an issue with FolderNuGetProject! (no tracking) SearchPortalNuGetProject -> wraps a packages config project as well to keep track of what is actually installed Install -> just like in previous demo Uninstall -> again using override as FolderNuGetProject has no tracking (will not always work as appdomain needs to be unloaded to remove binaries, could do shadow copy to overcome this but meh, demo purposes)
  11. Open Fiddler files Go through V2 one Go through V3 one and look at various resources, mention @id, @type, comment Mention versions as well (e.g. registrations with/without semver2 support) Open a few resources and try some requests Autocomplete: https://api-v2v3search-0.nuget.org/autocomplete?q=json&supportedFramework=any&prerelease=true Autocomplete versions: https://api-v2v3search-0.nuget.org/autocomplete?id=newtonsoft.json Search: https://api-v2v3search-0.nuget.org/query?q=json&supportedFramework=any&prerelease=true Note only latest version + list of version numbers Note link to catalog and registrations Registration: https://api.nuget.org/v3/registration0/newtonsoft.json/index.json Note metadata Note paging, ranges, ... Registration version: https://api.nuget.org/v3/registration0/newtonsoft.json/10.0.1.json Flat container (templated): https://api.nuget.org/v3/flatcontainer/newtonsoft.json/index.json Flat container download (templated): https://api.nuget.org/v3/flatcontainer/newtonsoft.json/10.0.1/newtonsoft.json.10.0.1.nupkg Catalog: list of commits https://api.nuget.org/v3/catalog0/index.json Catalog: specific page https://api.nuget.org/v3/catalog0/page2318.json
  12. Open collector demo project Show packges installed, most important: NuGet.Services.Metadata.Catalog Contains “collectors” that traverse over the catalog and to which we can subscribe Quite an internal implementation, but created a SimpleCommitCollector Handles OnProcessBatch and does some data transformation Fires either ProcessPackageUpdateAsync or ProcessPackageDeleteAsync View hierarchy (Ctrl+E, Ctrl+H) Mention NuGet implementations galore in NuGet.Services.Metadata, even unused ones (but also the ones that create search index, flatcontainer, ...) Example: EchoCollector Run it Breakpoint, show properties available Example: MirrorCollector Run it See it mirrors packages Dirty way of building download URL, should use service index to get template, but it works anyway
