The document discusses Hyperloop, a proposed method of transportation involving capsules that travel through low pressure tubes at both low and high speeds. Key points include: - Hyperloop was proposed by Elon Musk as a fast and inexpensive way to transport people and goods between cities. It uses magnetic levitation and linear induction motors to propel capsules through tubes. - Capsules would float on cushions of air and be accelerated using magnetic linear accelerators powered by solar energy. Simulations show the concept is technically feasible. - A proposed Hyperloop between Los Angeles and San Francisco would cost $6-7.5 billion and transport passengers at 598 mph, taking 35 minutes and costing $

1. Hyperloop
Transportation
System
A Viable Option for the Future of Transportation…..
1

2. 2

3. 3

4. 4

5. 5

6. 6

7. 7

8. What is HYPERLOOP?
• Hyperloop is a new mode of transport
• -Both fast and inexpensive for people and goods.
• -Open design concept
• -Consists of a low pressure tube with capsules that
are transported at both low and high speeds
throughout the length of the tube.
• Elevated system of transportation through a tube
between cities
• Idea proposed by Elon Musk, founder of Tesla and
SpaceX
• Simulations and model-building in progress 8

9. 9

10. Technology
• Pods float on cushion of air through low-pressure
tube
• Magnetic linear accelerators to accelerate pods
• Solar power to propel pods
• Simulation technology shows feasibility (Ansys
software)
10

11. 11

12. •Hyperloop Passenger Capsule
•Hyperloop Passenger Plus Vehicle Capsule
12

13. 13

14. 14

15. •Allows the capsule to traverse the relatively narrow tube
without choking flow that travels between the capsule and the
tube walls (resulting in a build-up of air mass in front of the
capsule and increasing the drag) by compressing air that is
bypassed through the capsule. Thus overcoming Kantrovitz
limit.
•Supplies air to air bearings that support the weight of the
capsule throughout the journey.
15

16. •Air bearing suspension.
•Offers stability and extremely low drag at a feasible cost by
exploiting the ambient atmosphere in the tube.
16

17. •5,500 lb (2,500 kg) of batteries to power the onboard
compressor and capsule systems in addition to the compressor
motor and coolant.
•Advanced linear motor system is being developed to accelerate
the capsule above1,220 kph)at a maximum of 1g for comfort.
•The moving motor element will be located on the vehicle for
weight savings and power requirements
while
•The tube will incorporate the stationary motor element
(stator) which powers the vehicle.
17

18. TUBE
18

19. HYPERLOOP consists of a partially evacuated cylindrical tube
that connects the Los Angeles and San Francisco stations in a
closed loop System .
The tube is specifically sized for optimal air flow around the
capsule improving performance and energy consumption at
the expected travel speed.
The expected pressure inside the tube will be maintained
around 0.015psi (100 Pa, 0.75 torr), which is about 1/6 the
pressure on Mars.
19

20. Hyperloop was initially designed to travel between
Los Angeles and San Francisco in approximately 35 minutes
To avoid bend radii that would lead to uncomfortable
passenger inertial accelerations and hence limit velocity.
Optimized by
•Deviating from the current highway system,
• Earth removal,
•Constructing pylons to achieve elevation change
or
• Tunneling. 20

21. Cost
• Estimated cost of the Hyperloop vs. the California rail
project
Estimated
Cost
Average
Speed
Cost of
One-way
Ticket (LA
to SF)
Type of
Cargo
Hyperloop $6-$7.5
billion
598 mph $20 Passenger
s and
vehicles
California
rail
project
$68.4
billion
164 mph $105 Passenger
s 21

22. Future plans
• Marco Villa and Patricia Galloway guide the progress of
the project
• Marco Villa- former director of mission operations at
SpaceX
• Patricia Galloway- former president of the American
Society of Civil Engineers
• JumpStartFund plans to help finance the Hyperloop
through crowdsourcing
22

23. Benefits and Implications
• Drastically reduced commuting time
• Transition from living in major cities to suburbs
• Increased speed of business transactions
• Reduced need for telecommuting
23

24. Benefits and Implications
• Green technologies involved in Hyperloop powering
• Less cars on the road
• Less energy requirements
• Less air pollution
• Reduced emissions
of greenhouse gases
24

25. 25
PICTURE COURTSSY : SpaceX. Hyperloop Alpha Design Proposal, 2015

26. Issueswith Hyperloop
• Costs are underestimated
• Technology not ready
• Lack of political support
*See Elon Musk’s argument for Hyperloop here.
26

27. Costs Underestimated
• Only cost of materials
• No account for unforeseen
engineering/technological
problems
• Not calculated from downtown to
downtown
• More expensive/person
27

28. Lack of Political Support
• Musk not willing to lead
• No politicians
• Knowledge not wide-spread
• Lack of public support
28

29. Technology not ready
• No prototypes
• Engineering/physics
• Not tested
29

30. 30

31. References
• . [1]. Musk, Elon (August 12, 2013). "Hyperloop Alpha“
.SpaceX
• [2]. Generic proposal for evacuated tube transport Technology
(et3) high speed ground transportation System (hsgts) using
high temperature Superconductuve maglev (htsm) by et3
global alliance inc.
• [3]. Open-Source Conceptual Sizing Models for the Hyperloop
Passenger Pod Je↵rey C. Chin, Justin S. Gray, Scott M. Jones,
Je↵rey J. BertonNASA Glenn Research Center, Cleveland, OH
• [4]. "Beyond the hype of Hyperloop: An analysis of Elon
Musk's proposed transit system".Gizmag.com. August 22,
2013.
• [5]. HYPERLOOP DESIGN REPORT Makers UPV Team Universitat
Polit`ecnica de Val`encia , Valencia - January 2016
31

32. References
•[6]. Wilbrink, Joost. "SVT 137 153 Ff. Leipzig.“
Dbtrains.com. N.p., n.d. Web. 13 Nov. 2013.
•[7]. "Hyperloop in OpenMDAO". OpenMDAO. October 9,
2013. Retrieved October 9, 2013.
•[8]. "HYPERLOOP:FIFTH MODE OF TRANSPORTATION".
Kayela, editor of scientific and technical department
•[9]. "Hyperloop". SpaceX. Space Exploration Technologies.
Retrieved June 15, 2015.
32

33. Questions?
33
