The document discusses a hybrid microgrid solution from Schneider Electric that can optimize efficiency, improve sustainability, and ensure reliability for customers. The solution utilizes both renewable energy sources like solar and non-renewable sources like gas turbines. It includes energy storage, a distribution network, and SCADA software for monitoring and control. Schneider Electric can provide the full turnkey solution including power generation, conversion, distribution and engineering services.

1. End 2 End Conventional and Non Conventional Power Generation
Confidential Property of Schneider Electric
Hybrid Micro Grid Solution

2. Hybrid Micro Grid – “Path to Energy Autonomy”
Optimize Efficiency
• Minimize energy cost through load
shifting, peak saving or demand
response
• Harness combine heat & power,
maximize incentives
• Reduce dependence on grid pricing
and availability
Improve Sustainability
• Take full advantage of distributed energy resources (e.g. gas, solar,
wind, and biomass)
• Store and harness energy to use when needed
• Reduce greenhouse gas emissions and carbon footprint
Ensure Reliability
• Business continuity 24/7 with
localised energy generation
• Proactive islanding from unstable
utility supply and reconnect
• Meet your dynamic energy needs
• Determine the root cause of outages
and restore power quickly
• Cyber secure design protects from
potential threats
• Prioritizes load preservation keeps
power flowing to the most critical
loads

3. Financing & Contractual scheme;
Profile: Financial IPP, Mastering Financing
(equity + debt), Focused on West Africa
Partner providing PPA
• Turn key Solution: Project Management, Power Generation, Electrical Power
Conversion, Electrical Distribution, Software Solution & Engineering Services
Schneider Electric’s Value Proposition

4. Hybride System Architecture
Renewable: Solar Solution
Non-Renewable: CHP Turbines
Energy Storage: Li-Ion Solution
Distribution Network: Substations
SCADA Solution: PowerSCADA

5. Utility Scale Storage SolutionSolar Conversion Substation
• Energy Storage System: Core XC ESS
– Energy Storage Box including LV/MV transformers, full
insulations and protections.
– AC/DC/AC Conversion between battery and grid network
• Li-Ion Battery Package: Ecoblade
– Ecoblade Substation Storage up to 3.2MWh bank
Page 5Confidential Property of Schneider Electric |
Non-Conventional Power Generation
Schneider Electric Solar Conversion System
Centralized and Decentralized Solar Power Plants
• Centralized Solar Solution: Core XC
– DC power Collection upto 3MW;
– Power Conversion to MV AC;
– AC Medium Voltage power collection and delivery
– Monitoring and Control
• Decentralized System: Conext CL
– Conext CL three phase inverter with DC integration up
to 160kW

6. Conventional Power Generation
Modular Capstone Turbine system (C30, C65, C200, C1000)
• High 98%+ reliability
• Lower Total Cost of Ownership
• Short Commissioning Period
• Easy Interconnects to Local Grid or Bus
• Low Maintenance
• Ease of Operations
• No Lubricants or Coolants
• Small Footprint, Light Weight
• < 65dBA Acoustic Emissions
– Multiple fuel powered
– Advanced combustion (low emissions)
– Micro turbines are ideal for remote
locations; requires no fuel delivery
pipelines
– One fuel connection; One electrical
connection
– Perform maintenance on 1 while 4
continues to operate
– Fuel Options – Natural Gas, Propane,
Diesel, Kerosene, CNG, Field Gas
Value Proposition
Plug and Play Turbine Units
up to 10 MW

7. Page 7Confidential Property of Schneider Electric |
Main LV Switch BoardIn-built transformers in Conversion
Substations
• Customizable solution
• E-House with Medium
Voltage Switchgear, Motor
Control Centres,
Transformers, HVAC, UPS,
and Building Management
and Control Systems.
Sub Distribution Board
Consumer Units
MV/LV Prefabricated Substation
Distribution Network
Modular Power Distribution Units
Schneider Electric is the undisputed global leader in LV/MV Distribution

8. Grid Monitoring and Control
Page 8Confidential Property of Schneider Electric |
• StruxureWare Software forms an important part of your overall
energy efficiency and reliability solutions.
• A PowerLogic System can grow with your business, giving you
the level of energy intelligence and control you need to reduce
energy consumption and costs, minimise environmental
impacts, and assure power availability, uptime and safety.
• Collects Energy-related Data from a variety of sources,
including PowerLogic or third-party meters and sensors.
• Integration with Schneider Electric or 3rd systems and feeds.

9. Micro Grid References
• FAROE Islands
• 50 MW for 50,000 inhabitants
• 35 kW Heat Pump used for Salmon
Farming
• 50 kW Cooling Compressor in a cold
store
• Individual customers (~1000 kW and
~600 kW)
• Wind / Diesel / Hydro Generation
• 3 MW Thermal Storage
aDMS
Scada
OASyS
PCS/AGC
Regional RCC
-OASyS
Power Hub
Flexible Load
Embedded Generation
StorageDistributed Generation
System Operator Network Operator
Demand Side
Operation
Supply Side
Operation
Distributed
Energy Operation
DERMS
PCS = Power Control System AGC = Automatic Generation Control -control diesel
FLS = Fast Load Shedding 125-250ms FFDR : Fast Frequency Demand Response
RCC = Renewable Control Centre UC : Unit commitment
WFMS = Wind Farm Management system ED : Economic Dispatching
LF : Load forecast PP : Power plant
SE : State Estimation SOM : Switch Order management

10. Africa
………Make the most of your Energy
