The document discusses exploiting multi-core architectures to speed up processing of satellite data. It describes developing a multithreaded application using a master-slave model to parallelize preprocessing steps like extracting auxiliary data, Reed-Solomon decoding, and decompression. Performance analysis shows the application scales dynamically based on system resources and achieves maximum speedup when assigning 7 threads per core. While theoretical speedup is limited by Amdahl's law, accounting for parallelization overhead provides a more realistic performance measure.
