The Docker network overlay driver relies on several technologies: network namespaces, VXLAN, Netlink and a distributed key-value store. This talk will present each of these mechanisms one by one along with their userland tools and show hands-on how they interact together when setting up an overlay to connect containers.
The talk will continue with a demo showing how to build your own simple overlay using these technologies.
The Docker network overlay driver relies on several technologies: network namespaces, VXLAN, Netlink and a distributed key-value store. This talk will present each of these mechanisms one by one along with their userland tools and show hands-on how they interact together when setting up an overlay to connect containers.
The talk will continue with a demo showing how to build your own simple overlay using these technologies.
Linux offers an extensive selection of programmable and configurable networking components from traditional bridges, encryption, to container optimized layer 2/3 devices, link aggregation, tunneling, several classification and filtering languages all the way up to full SDN components. This talk will provide an overview of many Linux networking components covering the Linux bridge, IPVLAN, MACVLAN, MACVTAP, Bonding/Team, OVS, classification & queueing, tunnel types, hidden routing tricks, IPSec, VTI, VRF and many others.
Docker Networking with New Ipvlan and Macvlan DriversBrent Salisbury
Docker Networking presentation at ONS2016.
Docker Macvlan and Ipvlan Networking Drivers Experimental Readme:
github.com/docker/docker/blob/master/experimental/vlan-networks.md
Kernel requirements for Ipvlan mode is v4.2+, Macvlan mode is v3.19.
If using Virtualbox to test with, use NAT mode interfaces unless you have multiple MAC addresses working in your setup. Use the 172.x.x.x subnet and gateway used by the VBox NAT network. Vmware Fusion works out of the box.
Here is a screenshot of a VirtualBox NAT interface:
https://www.dropbox.com/s/w1rf61n18y7q4f1/Screenshot%202016-03-20%2001.55.13.png?dl=0
