DATA ANALYSIS SOFTWARE: METAPY
- 3. Method Tool DNA extraction/ PCR DNAseq QC, Trim, Chimera detection Assemble reads Error correction ???: Bayes Hammer Nested PCR Illumina overlapping read Fastqc, Trimmomatic, Vsearch Flash / PEAR Convert FQ, FA Trim primers off seq Cluster Biopython Python Swarm CD-HIT Vsearch Bowtie Blastclust Python: sklearn Compare clustering Graphics Summarise species Python
- 4. Clustering Swarm – Not biased to input order. Works on a d difference method CD-HIT – Biased to input order. Works on % identity Vsearch - Biased to input order. Works on % identity BLASTCLUST – Unknown bias to input order. Works on % identity Bowtie - PERFECT matches only! Read database
- 5. New approach to Metabarcoding analysis – Exact sequence variants Jamie Orr OTU – Operational Taxonomic Unit
- 6. OTUs vs ZOTUs (Exact sequence variants) • OTUs define sequence-similar groups; variation could be biological, or technical (PCR/sequencing). • ZOTUs explicitly try to correct PCR and sequencing errors.
- 7. Correcting - ZOTUs • Two sequences (A and B) • Skew = abundanceA/abundanceB • B(d)=1/2ad+1 Where “d” is the number of positional differences between two sequences “a” is set by the user • If skew is less than B(d) then A is assigned to B
- 8. Method Tool DNA extraction/ PCR DNAseq QC, Trim, Chimera detection Assemble reads Nested PCR Illumina overlapping read Fastqc, Trimmomatic, Vsearch Flash / PEAR Convert FQ, FA Trim primers off seq Cluster Biopython Python Swarm CD-HIT Vsearch Bowtie Blastclust Python: sklearn Compare clustering Graphics Summarise species Python DADA2 (ZOTU)
- 9. Metapy checks database is OK : INFO: QC passed on sequences: assembled_skew: normal skewtest assemb_lens = 0.718 pvalue = 0.4731 database_skew: normal skewtest db_lens = -2.703 pvalue = 0.0069 Mann_whitney U test: 0.000104940190514 INFO: db_mean= 196.958 db_stdev= 18.808 assem_mean = 189.681 , assem_stdev = 21.155
- 10. Metapy checks database is OK to use: FAILED – Used in previous publication The assembled size of your reads is significantly different to your database. You need to adjust your DB sequences to that of the region you sequenced. assembled_skew: normal skewtest assemb_lens = 0.718 pvalue = 0.4731 database_skew: normal skewtest db_lens = - 8.199 pvalue = 0.0000 Mann_whitney U test: 1.3189757498e-85 db_mean= 711.194 db_stdev= 218.250 assem_mean = 189.681 , assem_stdev = 21.155INFO
- 11. Database matters!!! • If you are going to pick species based on a database. These entries matter! • Reference database quality critically determines classification accuracy! • Compare 5 Phytophthora database. • 2 used for publications
- 12. Database matters!!! Phytophthora_db_v0.001 • Tracked on Github • Can be automatically updated and generated by scripts. • If you are going to pick species based on a database. These entries matter! • Reference database quality critically determines classification accuracy! • Compare 5 Phytophthora database. • 2 used for publications
- 13. Compare databases Out of a known 10 species "spiked" sample - DNAmix Database: TOOL: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 Result found in all tools true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 Blastclust true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 Bowtie true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 cdhit true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 Swarm true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 Vsearch fastclust true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 Vsearch true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 DADA2 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0
- 14. Out of a known 10 species "spiked" sample - DNAmix Database: TOOL: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 Result found in all tools true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 Blastclust true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 Bowtie true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 cdhit true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 Swarm true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 Vsearch fastclust true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 Vsearch true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 DADA2 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0 Compare databases Message 1: • Database length matters. • Including non-ITS1 region has negative impact (obvious, but used in publications!) Out of a known 10 species "spiked" sample - DNAmix Database: tergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 true ositives 0 4 5 2 4 mis - luster 0 3 1 3 1 true ositives 3 7 9 8 9 mis - luster 23 34 37 29 21 true ositives 4 4 5 3 4 mis - luster 5 3 1 3 1 true ositives 7 7 8 7 8 mis - luster 39 23 17 26 19 true ositives 0 7 8 7 8 mis - luster 0 11 8 20 19 true ositives 4 7 8 4 7 mis - luster 26 15 12 11 8 true ositives 6 6 8 4 7 mis - luster 7 7 7 8 5 true ositives 0 3 3 2 3 mis - luster 0 2 1 2 0
- 15. Compare databases Message 2: • Bowtie and DADA2 reduced mis-cluster rate (and true positive rate) Out of a known 10 species "spiked" sample - DNAmix Database: TOOL: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 Result found in all tools true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 Blastclust true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 Bowtie true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 cdhit true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 Swarm true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 Vsearch fastclust true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 Vsearch true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 DADA2 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0 Out of a known 10 species "spiked" sample - DNAmix Database: ry 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 es 0 4 5 2 4 r 0 3 1 3 1 es 3 7 9 8 9 r 23 34 37 29 21 es 4 4 5 3 4 r 5 3 1 3 1 es 7 7 8 7 8 r 39 23 17 26 19 es 0 7 8 7 8 r 0 11 8 20 19 es 4 7 8 4 7 r 26 15 12 11 8 es 6 6 8 4 7 r 7 7 7 8 5 es 0 3 3 2 3 r 0 2 1 2 0 Out of a known 10 species "spiked" sample - DNAmix Database: TOOL: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 Result und in ll tools true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 astclust true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 Bowtie true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 cdhit true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 Swarm true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 search astclust true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 search true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 DADA2 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0
- 16. Compare databases Message 2: • Bowtie and DADA2 reduced false positive rate Message 3: • Blastclust is the worst. We knew that already!! • Blastclust does not produce reliable identifications with these ITS1 databases. • Blastclust also deprecated – do not use! Out of a known 10 species "spiked" sample - DNAmix Database: TOOL: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 Result found in all tools true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 Blastclust true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 Bowtie true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 cdhit true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 Swarm true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 Vsearch fastclust true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 Vsearch true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 DADA2 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0 Out of a known 10 species "spiked" sample - DNAmix Database: ory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 es 0 4 5 2 4 r 0 3 1 3 1 es 3 7 9 8 9 r 23 34 37 29 21 es 4 4 5 3 4 r 5 3 1 3 1 es 7 7 8 7 8 r 39 23 17 26 19 es 0 7 8 7 8 r 0 11 8 20 19 es 4 7 8 4 7 r 26 15 12 11 8 es 6 6 8 4 7 r 7 7 7 8 5 es 0 3 3 2 3 r 0 2 1 2 0 Out of a known 10 species "spiked" sample - DNAmix Database: OOL: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 esult nd in tools true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 tclust true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 wtie true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 dhit true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 warm true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 earch tclust true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 earch true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 ADA2 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0
- 17. Out of a known 10 species "spiked" sample - DNAmix Database: ry 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 es 0 4 5 2 4 r 0 3 1 3 1 es 3 7 9 8 9 r 23 34 37 29 21 es 4 4 5 3 4 r 5 3 1 3 1 es 7 7 8 7 8 r 39 23 17 26 19 es 0 7 8 7 8 r 0 11 8 20 19 es 4 7 8 4 7 r 26 15 12 11 8 es 6 6 8 4 7 r 7 7 7 8 5 es 0 3 3 2 3 r 0 2 1 2 0 Compare databases Message 2: • Bowtie and DADA2 reduced false positive rate Message 3: • Blastclust is the worst. Message 4: • These results are helping us refine the DB. Mis-cluster rate is now reducing Out of a known 10 species "spiked" sample - DNAmix Database: TOOL: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 Result found in all tools true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 Blastclust true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 Bowtie true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 cdhit true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 Swarm true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 Vsearch fastclust true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 Vsearch true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 DADA2 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0 Out of a known 10 species "spiked" sample - DNAmix Database: Catergory 235_FULL length_error _removed 235_trimm ed_to_ITS1 Santi_ modified David’s pre - database trimmed to ITS1 Phytophthora DB version 0.01 true positives 0 4 5 2 4 mis - cluster 0 3 1 3 1 true positives 3 7 9 8 9 mis - cluster 23 34 37 29 21 true positives 4 4 5 3 4 mis - cluster 5 3 1 3 1 true positives 7 7 8 7 8 mis - cluster 39 23 17 26 19 true positives 0 7 8 7 8 mis - cluster 0 11 8 20 19 true positives 4 7 8 4 7 mis - cluster 26 15 12 11 8 true positives 6 6 8 4 7 mis - cluster 7 7 7 8 5 true positives 0 3 3 2 3 mis - cluster 0 2 1 2 0
- 18. Other software made for this project • Software estimates copy number of a given gene of interest. • ITS(theoretical) = ∑ITS_hits ⋅ (x̅ ITS_coverage(assembled) / x̅ gene_coverage) https://github.com/widdowquinn/THAPBI/tree/master/Phyt_ITS_identifying_pipeline Quantify gene copy number: Sanger sequencing identification: • No need for “pointy and clicky” sequencing editor, then web BLAST • Does it all for you! Sanger read ----> Species https://github.com/peterthorpe5/public_scripts/tree/master/Sanger_read_metagenetics
- 19. Future directions “Pipeline” needs to be verified with controls. Sequencing controls: known spikes, “fake” sequences to obtain error rates, identification limitations TODO: Write Bayesian based clustering/ probabilistic model
- 20. Thanks! Plant health testing and natural ecosystem surveillance via In situ water sampling and metabarcoding of Phytophthora diversity THE TEAM! David Cooke Leighton Pritchard Eva Randall & Beatrix Clark
Editor's Notes
- First why whither and what does it mean? “What is the likely future of” To remind us that language also changes and evolves as do species concepts Terminology – metabarcoding better term
