…  Extend Your Business  Mobilize Your Network …  Colubris Networks Product Overview
Wilfredo López Escobar DATEN  System Engineer   Caribbean and Latin America [email_address]
What is Wi-Fi? Wireless Ethernet – WLAN IEEE 802.11 Broadband wireless data service that connects mobile devices to an Ethernet network Data rates: 11 to 54 Mbps Distance:  300 ft, depending on antenna and environment Ethernet Wi-Fi Access Point Network
Colubris Overview Mission: Industry-leading developer of unified  multiservice  WLAN/LAN systems Highly  scalable  business mobility solutions for enterprises and service providers Market  Leadership: Over 1,000 customers worldwide 60,000 WLAN devices installed, worldwide #2 global market share in hospitality and service provider; #1 in transportation Founded in 2000; HQ in Waltham, MA Profile: Strategic Partners – Alcatel, Juniper, Avaya #1 privately held WLAN company
Distributed Intelligence  VPN Termination/Aggregation Distributed Intelligence –  VPN termination on AP eliminates separate WLAN infrastructure Secure VPN perimeter from client-to-corporate LAN On-board encryption accelerator   optimizes performance Local termination enables simplicity, greater scale Back-end aggregation to fewer VPN tunnels  Secure VPN management interface SSID=Employee Security=VPN CN1250 Employees Corporate HQ AAA NMS DHCP VPN Server Wide Area Network
Next Generation WLAN Architecture Smart Access Management & Control (incl. 1 st  Gen WLAN Switch) Scalability & Services Breadth
Localized Services Policy Control Services   applied at AP Distributed  architecture with  Centralized  management and control NOT in Data Path Adds centralized WLAN  QoS ,  security  and  roaming  to existing LAN 10x higher scalability than WLAN switch solutions Leverages commercial AP chips for reduced costs Smooth migration to unified switch and 802.11n standards WLAN RF & system mgt. QoS and security enforcement, packet forwarding AP AP NMS Central QoS and security control, roaming MultiService Controller LAN Policy Data Base
Colubris WLAN Solution InMotion VoIP-PBX InCharge  CNMS InCharge RF Security Server  L2/L3 Switch Internet Gateway Internet InReach VLAN Switch VLAN Switch .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
Product Application- Mobility Voice Over WLAN Service Highest R-values and voice session capacity More than 28% lower jitter than competitors Fast, Secure Intra/Inter Subnet Roaming Service   Mobility Enabled for real-time applications Secure WPA2 hand-offs  < 50 milliseconds RF Security and Management Embedded Wireless IDS/IPS Sensor Active load balancing and congestion management VSC 2 VSC 1 Voice Telephony Segment Traffic  P1 QoS Priority  PBX Destination Filter Data Applications Segment Traffic  WPA Security P3 QoS Priority Server VoIP PBX VLAN Switch Intelligent MultiService System
Free or Fee-based Hotspot Services Cafes and restaurants Hotels and marinas Train stations Increase foot traffic Customer stays longer Generate revenue FEE-BASED SERVICE OPPORTUNITIES Retailers, Malls Municipalities Increase foot traffic Attract techno-savvy clients FREE SERVICE OPPORTUNITIES NOC CN3200 Access Network Kiosk Hotspot
Public Interface
Internal Web Page
Original URL and Session Page
Customized Local (MSC) Pages
Rich Content Remote WEB server Page
Interactive Captive Portal
Payment options
Credit Card Payment
Public Internet Access Industry Structure Wireless service provider Owns and operates WLAN infrastructure Carrier Owns and operates Internet network service Back-office service provider Performs back-end authentication, billing, phone support Venue owner (hotel, restaurant, etc.) Aggregator Markets services to end-users Aggregates service operated by 3 rd  party WSPs End User Venue Owner Wireless Service Provider Back Office Service Provider Carrier
Global Hospitality Customers and Partners Hotspot Service Partners Global Customer Base
Public Access Service Business Models Service branding Private label for venue Wireless service provider brand Aggregator brand Revenue models Service paid by venue owner Service paid by end user and split with venue owner Service paid by aggregator and split with service provider and venue owner Various back office and carrier outsourcing models Aggregator Wireless Service Provider Back Office Service Provider Carrier
Public Access Solution Partners Speed Entry Back-office service partners lower barriers to entry CIMS supports billing and customer service outsourcing Aggregator (roaming) partners make hotspots part of a larger network CIMS interoperability enables WSP to join large aggregator networks Back-office Service Partners Aggregator Partners
Public Access Service Network Components Back Office Firewall/ Router WLAN  Access Point (s) Service  Provider NOC Service Provider NMS Broadband client connectivity Client authentication, service presentation, billing support Routing services, security Access Gateway NMS manages and controls public access infrastructure, Portal delivers web content to clients Back Office Subscriber authentication, Credit card processing Public Internet Access Venue Portal Carrier Internet Service Cable/DSL Modem
CIMS Fully Integrated Public Access Solution Back Office InMotion  MSC InReach  MAP(s) InCharge  Colubris  NMS (CNMS) Service Provider MultiService client connectivity Turnkey public access CPE solution Integrated access gateway, router, firewall, access point CNMS manages and controls geographically distributed public access infrastructure Back Office Comprehensive support for AAA and back-office billing systems Public Access Venue Portal Carrier Internet Service Cable/DSL Modem CNMS MultiService Controller MultiService Access Point
CIMS Meets Public Access Business Needs Easy for Customers to Use Colubris “Zero Configuration” service interface  Per user bandwidth management Range of Billing Models Rich AAA interface supports range of billing models Location-aware billing support Minimizes Operating Costs Highly reliable integrated system Central WLAN management system for ease of operation Low Deployment Costs Low cost, purpose-built solutions are easy to install Public Access Venue NOC CNMS WLAN  Mgmt AAA, Billing, Portal Internet VSC 1 Public Internet Access Segment Traffic  Access Control Bandwidth Management Intelligent MultiService System
Fixed Network Infrastructure Wireless Network Infrastructure Defining  W ireless LANS Components of a Generic 802.11  Nework AP AP STA STA Router Switch Internet Protocol: CSMA-CA w/ ACK
Wi-Fi Primer Interoperability:  Wi-Fi Alliance  Governing standard:  IEEE 802.11 Specification Ratified Data Rate Distance (dipole) Frequency Band 802.11 a 1999 54 Mbps 100 ft. 5 GHz 802.11 b 1999 11 Mbps 300 ft. 2.4 GHz 802.11 g 2003 54 Mbps 300 ft. 2.4 GHz
SSID and Windows XP
VAPs – Access Contol lists and Backend Services LAN/WAN SSID=Admin Security=VPN QoS=P2 RADIUS Profile 2 ACL 3 SSID=Voice Security=WEP QoS=P1 RADIUS Profile 2 ACL - 4 SSID= POS Security=MAC QoS=P2 RADIUS Profile 2 ACL - 2 SSID=Guest Security=Open QoS=P3 RADIUS Profile 3 ACL - 5 POS Server VoIP  Gateway SSID=Hotspot Security=Open QoS=P4 RADIUS Profile 3 ACL - 6 Services Controller Access Devices Radius Profile 1 – Walled Garden ACL’a Back-end  RADIUS 4 & WEB AAA NMS Billing Portal Back-end  RADIUS 3 & WEB AAA NMS Billing Portal Back-end  RADIUS 2 & WEB AAA NMS Billing Portal Back-end  RADIUS 1 & WEB AAA NMS Billing Portal
Multi-Service WLANs for Higher Education LAN/MAN/WAN SSID=Faculty Security=VPN QoS=P2 SSID=Voice Security=WEP QoS=P1 Staff SSID=Student Security=Open QoS=P4 Admin  Services Student Services VoIP  Gateway Faculty Data Center SSID=Assets Security=WPA QoS=P2 Students CNMS WLAN  Mgmt AAA/ VPN Server Services Controller Access Devices Internet
GSM / Wi-Fi phones are here
Toll-Quality Voice Service Broad QoS support for VoWLAN handsets SpectraLink, 802.11e, Vocera, SIP and H.323 softphones Transparent client subnet roaming support Traffic segregation and IP filters reinforce security Open support for 3 rd  party power-save modes Employee Server VoIP Gateway CN1250 SSID=VOICE Security= WEP IP Filter=VoIP G/W QoS=P1 Router Data Center Subnet “A” Subnet “B” Seamless Subnet Roaming
Multimedia Service WMM/802.11e EDCA QoS protocol support Four classes of service enable rich multimedia applications Service-Aware QoS for non-protocol client devices Enables legacy devices to access QoS Mapping to wired network QoS policies 802.1p and TOS/DiffServ integration CN320 Switch/Router Video Server SSID=VIDEO Security=Open Filter=Video server QoS=P2 SSID=Multimedia Security=WPA QoS=802.11e Surveillance Video Conference Internet
Colubris: QoS Enforced at the AP Edge Policies applied at WLAN/wired network boundary Mapping between WLAN and LAN/WAN policies Embedded processors provide scalability to large networks Each AP adds processing power for 16 services to network  CNMS centrally configures QoS policies for ease of operation Applications Corporate HQ Suppliers IP  Backbone LAN Backbone 802.1p TOS/DiffServ QoS Policy Enforcement SSID 802.1p WME 802.1p TOS/DiffServ
Interoperability with QoS-Capable Clients Protocol-based policy enables client device to request priority 802.11e WME provides open voice, video, data interoperability SVP support provides interoperability with SpectraLink phones Part of end-to-end QoS scheme Client-AP-Ethernet  SVP QoS WME QoS No QoS Ethernet Wi-Fi 1 2 3 4 Protocol-based Forwarding SSID=Multimedia Security=Open QoS=Protocol
WMM for Voice over Wi-Fi Support Corporate Server VoIP Gateway SSID=Voice Security=WEP SSID=Employee Security=WPA SSID=Voice Security=WEP Normal Priority Corporate Data Traffic WMM-Tagged VoIP Traffic 802.1p-Tagged VoIP Traffic
Problems with next generation Solutions Phone IP NEW  IP Inter AP Roam – re associate & KEY  .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. VoIP-PBX Management VLAN Switch Subnet A Master VLAN Switch IP Router Internet RADIUS Server DNS Server VLAN Switch Subnet B
Large Site / Campus deployment VLAN Switch In Motion MSC VoIP-PBX Control /  mgmt Call Setup Legend: Call CNMS Management VLAN Switch Master VLAN Switch IP Router Internet Secure Control  IP Tunnel In Motion MSC .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
InMotion ™  Delivers New Services New  Industry-leading Voice Over WLAN Service Highest R-values and voice session capacity More than 28% lower jitter than competitors New  Fast, Secure Intra/Inter Subnet Roaming Service   Mobility for real-time applications MOBILE IP Protocol Secure WPA2 hand-offs < 50 milliseconds New  Plug-and-Play Deployment Service Automatic MAP discovery and configuration Mutual authentication and encryption for security Industry-Leading Public/guest Network Access Service “ Zero configuration” for easy client access Rich service management policies MultiService Controllers
Retail Multi-Service WLAN LAN/WAN Retailer Headquarters Supplier Headquarters Back-end  Hotspot Services AAA NMS Billing Portal Supplier SSID=Admin Security=VPN QoS=P2 Scanner SSID=Voice Security=WEP QoS=P1 Voice SSID= POS Security=MAC QoS=P2 SSID=Guest Security=Open QoS=P3 POS Server VoIP  Gateway Manager SSID=Hotspot Security=Open QoS=P4 Customer DHCP, AAA VPN Server Firewall Services Controller Access Devices CNMS Central Mgt Retail Store Location
Healthcare Multi-service WLAN LAN/MAN/WAN SSID=Admin Security=VPN QoS=P2 SSID=Voice Security=WEP QoS=P1 Staff SSID=Guest Security=Open QoS=P4 Admin  Services EMR System SSID=Patient Info Security=WPA QoS=P2 Doctors Nurses VoIP  Gateway Admin SSID=Badges Security=WEP QoS=P1 Affiliated Clinics Doctor/Clinician Office, Home Supplier  Headquarters Data Center Asset Tracking SSID=Assets Security=WPA QoS=P2 Suppliers CNMS WLAN  Mgmt AAA/ VPN Server Services Controller Access Devices
Data Network Security 3 Requirements Access Control – Bi directional, verifiable, centrally Managed  Confidentiality – Encryption Data Integrity – Frame Check and Sequencing Cipher Text Encryption KEY Encryption KEY RC4 DES/3DES CCMP AES RC4 DES/3DES CCMP AES Static – PSK Certificate PMK  TKIP DATA DATA Encryption Engine Encryption Engine
Wi-Fi Security WEP – Wired Equivalent Privacy Original 802.11 encryption scheme RC4 - Static Weak Key VPN – Virtual Private Network (DES, 3DES) cryptography – VPN client and Gateway IEEE 802.1x – Access Control  EAP protocol using Radius Authentication WPA – Wireless Protected Access Strong encryption TKIP RC4 Requires access to authentication server IEEE 802.11i – WPA2 Strongest encryption (AES) Government approved  HTML Access Control Public Access via Captive Portal authentication
Managed Services Network Components Firewall/ Router WLAN  Access Point (s) Service Provider NOC Service Provider NMS QoS for real-time services Segments services Broadband client connectivity Routing services Security VoIP switch provides telephony service Application server delivers business services  NMS Manages and controls CPE Customer Premises VoIP Switch Cable/DSL Modem Carrier Internet Service App. Server Business Applications Telephony
CIMS Managed WLAN Services Solution Easy WLAN access to multiple voice, video, data network services VSCs tailor QoS and security policy for each service VSC traffic mapped to separate NOC or customer premise destinations Comprehensive remote WLAN management minimizes operations costs VSC 2 Voice Telephony Segment Traffic  P1 QoS Enterprise Premise Internet NOC VSC 3 Credit Card Processing Segment Traffic P3 QoS  VPN Security Intelligent MultiService System VSC 1 Public Internet Access Segment Traffic  Access Control P4 QoS
Colubris Unique Selling Proposition Centralized management and control minimizes OpEx Distributed network intelligence for service flexibility Highly scalable architecture minimizes CapEx Comprehensive Public/Guest Internet Access Service XYZ Networks ABC Co. Acme Co.
WLAN System Components
Colubris Products Product Type 1 Radio 2 ports total 2 Radios 3 ports total Appliance  No Radio, 4 Ethernet Ports only In Reach MAP –  MultiService Access Point MAP-320 MAP-320R CN320 WAP-200   2 VAP no QOS MAP-330 MAP-330R CN330 In Motion MSC –  MultiService  Access Contoller MSC-3200 MSC-3200R CN3200 100 concurrent Users MSC-3300 MSC-3300R CN3300 100 concurrent Users MSC-5200 CN3400 500 concurrent Users MSC-5500 2000 concurrent Users 2-1000BASE-T4 MGW –  MultiService Gateway MGW-1250 CN1250 MGW-3500 CN3500  1000 concurrent Users
Access Controller
Product Positioning Performance- User Capacity, Future Proofing Features- Connectivity, Security, Mobility MSC-3200 MSC-3300 100 Users 500 Users/25 AP 2000 Users/200 AP MSC-5500 MSC-5200 MGW-3500 1000 Users
InMotion ™  MultiService Controllers Specifications MSC-5200 MSC-5500 Software Configuration COS Access Service COS Service Pack COS Access Service COS Service Pack Services VoWLAN Fast Roaming Plug & Play Deployment Public/Guest Access           Maximum MAPs N.A. 25 N.A. 200 Max. Public/Guest Access Users 500 500 2,000 2,000
Firewall
NAT
VPN Client To protect the VPN, add the following definitions to the access list: access-list=vpn,DENY,all,192.168.30.0/24,all use-access-list=vpn
Centralized Mode
Dual Radio Access Device Features Industry first dual a/b/g radios Two channels on single band increases performance, coverage Configurable AP, WDS Bridge and Monitor operating modes Flexibility and investment protection Enables continuous full-spectrum rogue scanning for increased security Robust monitor and diagnostic capability Eliminates cost of redundant probes/monitors Configurability Radio 1 Radio 2 Transceiver Mode a/b/g a/b/g Operating Mode AP, Bridge, Monitor AP, Bridge, Monitor
Single Radio vs Dual Radio
Extended Access Control Network
Network Topology - WDS MAP-330 MAP-330 MAP-330 MAP-330 MAP-330 Access line Client Client client Client Client Client Client MAP-330 MAP-3300 MAP-330 MAP-330 MAP-330 MAP-330 MAP-330 Internet MAP-330 Client Client Client Client Client Client .11g or 11a (WDS) .11b ch 1 area (AP) .11b ch 6 area (AP) .11b ch 11 area (AP) MAP-3300/MAP-330 – one radio in AP mode and the other radio in WDS mode Potential hidden node issue, for shared WDS/AP radios
Rogue AP Detection and Reporting Wireless RF Scanning Use of existing, authorized APs for wireless scans  Differentiates between true “rogues” and “ignored” 3 rd  party APs Multi-vendor support enables most comprehensive Rogue AP detection Wireline Rogue Discovery Scans network via multiple protocols Automatically IDs the “fingerprints” of rogue APs Integrated Rogue AP Reporting Correlates all information to rapidly locate and disable rogues
Outdoor Rated Enclosure: MSC-3200R, MAP-320R Die-Cast Aluminum, NEMA 67 rating 2 waterproof N-type Antennas option Waterproof, quick disconnect RJ-45 connector 3 point silicone-rubber gasket Pole-top and wall-mount mounting options Colubris Logo Applied This slide for planning purposes only, content and dates subject to change
Locking Mounting Bracket Die-Cast Aluminum Wall or Ceiling Mountable Compatible with standard product enclosure (slides in and out) Padlock not included List Price $50 (USD) This slide for planning purposes only, content and dates subject to change
CNMS - WiFi Network Management
WiFi Network Management
CNMS Overview NMS Authentication RADIUS SNMP NOC WAN/LAN Campus A Campus B CN3200 CN320 CN3200 CN1250 SNMP/HTTP/TFTP CNMS Monitor AP discovery User monitoring Rogue AP detection NMS & AAA integration Analyze Alerts & diagnostics Performance reports RF event correlation Act Multi-vendor   config mgt Firmware distribution Grouping & scheduling
Colubris Networks Offers a Comprehensive RF Security and Management Solution InCharge RF Server InReach 330P InCharge RF Planner Automatically prevent Wi-Fi security attacks Perform real-time network audits Assist performance troubleshooting Monitor wireless LAN health
InCharge RF Server Two appliance models support up to 50 sensors or up to 200 sensors Correlates sensor data Analyzes and classifies Wi-Fi devices Enforces security policy Web interface Within CNMS, launch InCharge RF Server screens in Phase 1 Tight integration with CNMS in Phase 2 InCharge RF Server, InReach 330P, InCharge RF Planner InReach 330P Scans 2.4 and 5 GHz bands Centrally managed and configured by Server Dedicated sensor function in Phase 1 Concurrent AP and Sensor function at Phase 2; Phase 1 InReach 330P devices can be upgraded to Phase 2 capability Power over Ethernet InCharge RF Planner Stand-alone Windows-based application  Models wireless LAN coverage without a physical site survey Evaluates security risk from wireless LAN spillage outside building  Assesses changes with simple drag and drop techniques Generates equipment lists for installation team Provides powerful predictive planning  Input floor plan Add building material type Specify 802.11b, g or a Input minimum bandwidth requirements Drag and drop APs Supports dynamic floor plan models  RF coverage Channels Signal strength Spillage InReach 330P Web Interface InCharge RF Server InCharge Security Server
The Threat!!!; Eight Major Classes of  Wi-Fi Threats Firewalls, VPNs, and 802.11 Security Standards Do Not Prevent These Wi-Fi Threats on Either Wired or Wireless Networks Enterprise Network Neighboring Network ? Ad Hoc Denial of Service Attack AP MAC Spoofing Rogue AP Mis-configured AP Unauthorized Association Mis-association Honeypot Common  Rogue Access Points Mis-configured Access Points Ad hoc connections Client mis-associations Unauthorized client associations Malicious  Honeypot APs MAC Spoofing APs Client > Malicious AP Denial of Service De-authentication flood Packet storm
Monitor/Detect Scan all bands 2.4 GHz and 5 GHz Detect all Wi-Fi activity Access points, soft APs, NATing APs, clients Correlate information from multiple sensors Eliminate confusing  duplicate reports of the  same device
Visualize Make your airwaves visible View RF coverage in real    time Handhelds only provide a    snapshot in time Plan for security and Wi-Fi    coverage Only integrated solution that    ensures proper sensor placement Model detection and prevention    levels   Self-calibrating  Site-specific RF    characteristics Deployment orientation Good Coverage No RF Coverage Poor RF Coverage
Auto-Classify Comprehensive Access points Authorized, Rogue, External Clients Authorized and Unauthorized Accurate and Reliable No false positives/no false negatives Instantaneous No manual user intervention required InCharge RF Server dashboard automatically classifies Access Points and Clients into appropriate categories.
Prevent Over-the-air Ensures non-stop protection Instantaneous Based on quarantine policy and accurate auto-classification Doesn’t require manual administrator intervention No harm policy Won’t disrupt your own or neighbor’s networks Most comprehensive solution All major classes of threats Rogue access points, Evil Twin/Honey Pot APs, MAC spoofing APs, mis-configured APs, rogue clients, client mis-associations, ad hoc networks and DoS attacks InCharge RF Server dashboard shows  rogue access points that has been quarantined; I.e. automatically blocked to prevent  any and all  client connections.  3 5
Locate Precise Locates rogues and other Wi-Fi security threats for physical remediation Pinpoints all AP and client device locations Authorized, unauthorized and neighbor Immediate One click operation Site calibrated Displays location on a  floor plan One click operation provides graphical probability analysis of location Not just a red ‘X’ InCharge RF Server integrates a floor plan to show a range of probable locations of rogue APs or clients.
Prevent Wi-Fi Threats in a Non Wi-Fi Network Even if you have no 802.11 AP’s, most laptops have 802.11 cards A laptop radio is default configured to ‘automatically associate’ with the  strongest signal from a list of SSID’s  Hackers simple sit outside the building with an AP configured to a common SSID and wait for a number of laptops to connect SSID:  linksys Corporate Firewall Internet X X X X Honeypot attack lures in multiple laptops to miss-associate.
Rogue AP Blocking Rogue AP is Detected Over-the-air detection Network connect tested Auto-classified No False Positives  Does not rely on switch Blocked over-the-air De-auth all Clients 100% accurate Any network / switch Better than port blocking Port blocking is not reliable Port blocking may cause DoS  Rogue AP Wi-Fi Ready Laptop X Corporate Firewall Internet
Prevent Client Mis-Association Enterprise Network Neighboring Network SSID:  a1b2c3 SSID:  a1b2c3 SSID:  a1b2c3 X X X X Clients associate to strongest signal  Blocks clients that  mis-associate Prevents  SSID spoofing Client roaming
Prevent MAC & Air-Jack Attack Enterprise Network SSID:  a1b2c3 MAC:  00.20.A6.4C.1A.46 SSID:  a1b2c3 MAC: 00.20.A6.4C.1A.46 X X Detects MAC Spoofing  Blocks unauthorized spoofed AP’s Prevent malicious threats Evil Twin  Man-in-the-middle
Denial of Service Attack Prevention Wi-Fi Denial of Service can shut down your network Blocks DoS attacks Exclusive vendor DoS prevention Patented ‘ Virtual Selective Jamming’ technique Corporate Firewall Internet Enterprise Network X X X DoS attack
Complete Protection Requires Simultaneous Threat Prevention Enterprise Network X X X X X Rogue AP  Single Sensor must block multiple Clients and multiple Rogue AP’s on multiple channels simultaneously Corporate Firewall Internet SSID:  linksys
Knowledge-Based Troubleshooting Step-by-step flowchart Connectivity and performance problems Client and access point issues Not just problem    identification Suggests remedies Easy to use Helpdesks Remote administrators Live over-the-air packet    capture Ethereal
Knowledge-based Troubleshooting (cont’d)  Administrator logs into the InCharge RF Server &  chooses the device to troubleshoot  Administrator selects the appropriate sensor to troubleshoot the device Step 1 Step 2 Live Packet stream
Customizable Reports This custom report captures uncategorized & unauthorized clients that are not quarantined!
Security & Performance Monitoring Monitor & alert for security and performance issues Total of 140 events! Complete protection Sensors scan ALL channels  Independent of regulatory domain Details provided for each event Suggested remedies
Availability Phase 1: GA End of October InReach 300P (dedicated sensor) InCharge RF Server appliance InCharge RF Planning Tool Phase 2: target GA of 1Q06 Multi-function MAP-330 will support AP and sensor function or act as a dedicated sensor  Software migration path from Phase 1 to Phase 2 capability  Tight integration of InCharge CNMS and RF server
A New Paradigm Determine AP and security    sensor  placement without    physical  walk around Much more efficient method than    physical site survey   What-if analysis Predictive planning enables    simply, easily Building floor plan with predicted RF coverage
How it Works Predictive planning Input floor plan Add building material type Specify 802.11b, g or a Input minimum   bandwidth requirements Drag and drop APs Dynamic floor plan models  RF coverage Channels Signal strength Spillage
InCharge RF Planner  Wi-Fi Site Planning InCharge RF Planner Site Planner for Wireless LAN Access Point Coverage  Site Planner for Performance Optimization Planning for WLAN Security Sensors Coverage Advantages Software solution does not require manual site surveys Automatic RF Mapping with ‘True Map’  Automatic report generation Planning for Coverage, Performance and Security
Wi-Fi Site Planning Software Planning Tool Import or create floor plans State-of-the-art RF propagation modeling for wireless LAN and security sensor coverage Models site specific parameters Ensure optimum performance Capacity and coverage Allows for redundancy planning Ensures no blind spots Provides visual confirmation Determine security level needed Detection vs. prevention coverage areas Security sensitivity modeling Good security coverage blind spots
Wireless LAN Coverage Model building RF    reflection, refraction, and    absorption Import floor map from    virtually any electronic    format Plan for complete and    optimum coverage
Redundancy Planning Eliminate blind spots Model 802.11 a/b/g Minimize AP    requirements
Link Speed Performance    optimization modeling  Model 802.11a/b/g  Building specific
Channel Allocation Visualize Channel    Overlap to minimize    interference Model various scenarios Vendor APs Antennae Antennae direction Power a/b/g
Channel Interference Minimize Interference Model multiple    scenarios Optimize performance
Security Exposure Know where you are    vulnerable Model various scenarios    to minimize risk
Comprehensive Security Coverage Planning Accurately determines    number of sensors based on    customer specific risk profile Five specific variables used to    model coverage level  Site specific    characteristics Detection vs. prevention    range Detection range vs.    transmit power of rogue    or attacker Redundancy Other solutions blindly quote    coverage ranges with no real    method to determine actual    security level SpectraGuard Enterprise shows precisely the detection (blue) versus protection (purple) range of each sensor.
Work Order Automatic work order    generation Detailed management    reporting Ease deployment and    maintain performance of    your WLAN project
Global Customer Deployments Wireline  Wireless  Cable  ISP  Hospitality  Retail  Education  Transportation  Sporting Venues  Service Providers  Verticals  Partners New Zealand Argentina
Customer Success: McDonald’s Restaurants McDonald's is the leading global foodservice retailer with more than 30,000 restaurants serving nearly 47 million people in more than 120 countries each day.   Trigger Events: 500+ “Store of the Future” WLAN Program Initiative Why Colubris: Open systems, multiservice platform provided a simple, cost-effective means to evaluate and launch new business applications to improve quality and speed of service Scale and manageability to potentially thousands of locations Simple integration with existing Juniper infrastructure Goals: Enhanced customer satisfaction and revenue throughput Consistent quality monitoring Real-time inventory management Timely corporate communications Vision Point: Use wireless mobility to improve customer service, quality and cost across business systems  Solution: CN3200 AP/SC platform, CNMS Management Competition: Cisco & Symbol
McDonald’s “Store of the Future” VSC 1 VSC 2 Roaming Quality Audits Segment Traffic  WPA Security VSC 3 Public Internet Access Segment Traffic  Access Control Best Effort Priority Quality & Inventory POS Line Busting Hotspot Quality Control Mobile Order Taking Segment Traffic  WEP Security Intelligent Access & Service Control 3 VSCs deliver separate service through single WLAN system VSC security and QoS policies tailored to each application Open support for wide range of devices, users and apps. Applications under evaluation: Wireless telemetry, Inventory management, VoIP (drivethru), Signage WLAN Management Internet
Customer Success:  Wendy's Wendy’s is one of the world's largest restaurant operating and franchising companies with more than 9,500 restaurants under the Wendy's Old Fashioned Hamburgers®, Tim Horton's and Baja Fresh® Mexican Grill brands. Trigger Events: Interoperable, low cost WLAN equipment widely available Why Colubris: Delivers multiple private and public WLAN services in one device Integrated IP routing and VPN security services Centralized management of 1000s of remote sites Easy to deploy solution for autonomous franchises Goals: Wireless mobility for all headquarters and regional employees Real-time network automation of restaurant equipment Single WLAN architecture for campus, regional offices and stores Eliminate cabling expenses Offer customers public Internet access services Vision Point: Common wireless infrastructure for restaurant automation, enhanced customer service and human resource productivity initiatives Solution: CN1250 (HQ), CN3200 (Restaurant), CNMS management Competition: Cisco, Sonic Wall, ReefEdge
Wendy’s Common WLAN Infrastructure Restaurant Automation Segment Traffic  P2 Priority Public Internet Access Segment Traffic  Access Control Best Effort Priority Equipment Controller POS HotSpot (Future) Equipment Automation & Telemetry Regional Mgr Network Segment Traffic  VPN Security Wireless connectivity to HQ VPN network VSC security and QoS policies segment traffic tailored to each application CNMS centralizes management for HQ, regional offices and restaurants WLAN Management Intelligent Access & Service Control VPN access to HQ applications Headquarters Intelligent Access & Service Control Point of Sale/ Line Busting (Future) POS Segment Traffic VPN Security VSC 3 VSC 4 VSC 2 VSC 1 VPN Server Internet
Gander Mountain “Store of the Future” VSC 1: Associate Communication Segment Traffic WEP Security Voice Priority VSC 2: Inventory Control Segment Traffic WPA Security Quality & Inventory Management POS WLAN Management Intelligent Access & Service Control VSCs deliver 3 separate services through single WLAN system VSC security and QoS policies segment traffic tailored to each application VSCs provide open support for wide range of devices, users and applications VoWLAN Wire Replacement Wire Replacement VSC 3: Corporate Employee Segment Traffic WPA Security Best Effort Priority Internet
Customer Success:  Emory University Trigger Events: Availability of unified WLAN voice and data network technology Emory University is recognized as one of the U.S.’s top 25 national universities.  It is known for its demanding academics, outstanding undergraduate college of arts and sciences, highly ranked professional schools and state-of-the-art research facilities.   Why Colubris: VSC capabilities Leadership VoFi and QoS solution Central management for scalability and ease of operation Goals: Easy access to network services from any campus location Instant voice communications for all staff members Wireless student Net access Guest Internet access in hospitals Vision Point: Improved staff, faculty, student productivity through ubiquitous broadband network services Solution: CN1250 Secure Gateway, CNMS Management Competition: Cisco
Emory University Ubiquitous WLAN VSC 1 VSC 2 VPN Data Service Segment Traffic  VPN Security VSC 4 Public Internet Access Segment Traffic  Access Control Best Effort Priority Data Services VoIP Gateway VoFi Hotspot (hospital) Student, Staff, Faculty Voice Service Segment Traffic  High Priority Intelligent Access & Service Control SpectraLink VoWLAN phone support Smooth migration from VPN to WPA capable devices Student, Staff and Faculty security privileges set by RADIUS authentication WLAN Management VSC 3 WPA Data Service Segment Traffic  WPA Security Student, Staff, Faculty Internet
Customer Success:  SJ Trigger Events: “ Internet On Track” -- The first full fleet roll out by a train operator of an onboard wireless Internet service and the world's first implementation of 3G/Satellite -enabled Wi-Fi service  SJ is Sweden’s leading rail traffic company and operator of the X2000, Sweden’s high-speed train, and its new X40 fleet – servicing 85 trains beginning in summer 2005. Why Colubris: VSC capabilities Security policies ensure internal applications are protected from public Internet traffic Corporate responsiveness and networking expertise Goals: Integrate an Internet access service into business class ticket Optional fee service for coach class ticket holders Separate internal WLAN service for train monitoring Vision Point: Continuous broadband Internet service improves passenger experience Solution: CN320 Intelligent MultiService Access Point Competition: Cisco, Proxim
SJ “Internet On Track” Service Data Collection Train Data Monitor Hotspot Intelligent Access & Service Control Segment traffic per VSC for security Strong security for  internal train applications Selective Layer 2 isolation prevents snooping on passenger hotspot service while enabling peer-peer monitoring connections VSC 2 Public Internet Access Segment Traffic  Access Control Best Effort Priority VSC 1 Data Collection Segment Traffic WPA Security  High Priority Internet
Wi-Fi on the Train Head Car Rear Car Middle Cars (7) Mobility Router GPRS, EDGE, CDMA, UMTS, WCDMA, 3G and satellite technologies. Provide wireless multi-service applications in a single footprint Provide Access Control CN330 CN320 CN330 CN3300 Public Access –  internet for passengers  Personnel Access –  ticket sales, inter cart communication Video surveillance SSID 1 SSID 2 SSID 3 Internet
Customer Success:  Sprint Sprint is a Fortune 100 company with more than $27 billion in annual revenues in 2004, Sprint is widely recognized for developing, engineering and deploying state-of-the-art network technologies.  Trigger Events: Previous vendors unable to reach vision point Why Colubris: VSC capabilities:  traffic segmentation, security & QoS policies per VSC Ease of management with CNMS Interoperability with 3 rd  party hotspot back-end services Goals: Upsell existing WAN service customers to managed Wi-Fi Offer revenue-generating hotspot service to retailers and public venue operators Flexibility to add new software-defined Wi-Fi service offerings (training, video surveillance, point-of-sale system, credit card service) Vision Point: Managed Wi-Fi service for installed base of 8,000 enterprises Solution: CN3200 AP/SC platform, CNMS Management Competition: Cisco, Nomadix, AireSpace
Sprint “Enterprise Wi-Fi Access” Service Hotspot Intelligent Access & Service Control Segment traffic per VSN for security Authenticate hotspot users via Airpath back-end service CNMS in NOC centralizes management for all customer sites Additional VSCs available for future services Security Surveillance Service (Future) VSC 2 Video Surveillance Segment Traffic High Priority Back-end Hotspot Service Point of Sale Credit Verification (Future) POS Segment Traffic VPN Security VSC 3 Enterprise Customer Premise WLAN Management Sprint NOC Internet VSC 1 Public Internet Access Segment Traffic  Access Control Best Effort Priority
Customer Success:  Best Western Europa The Europa is a 180-room business hotel located in downtown Montreal and a franchise of the Best Western hotel chain. Trigger Events: Best Western mandate to offer Wi-Fi Internet access in all properties Why Colubris: VSC capabilities Strong security policy enforcement VoWLAN and QoS support Goals: Differentiate by offering wireless keycard and wireless guest authentication services Upgrade path to VoWLAN service for guests Reduce operating costs while expanding guest services Vision Point: Leverage Wi-Fi to provide multiple wireless customer conveniences Solution: CN3200 AP/SC platform, CN320 AP, CNMS Management Competition: Cisco
Best Western MultiService WLAN Guest Internet Access Service Intelligent Access & Service Control Segment traffic per VSC for security Authenticate hotspot users via Airpath back-end service Additional VSCs available for future services VSC 1 Public Internet Access Segment Traffic  Access Control Best Effort Priority Wireless Guest Authentication and Direct Billing VSC 2 Guest Authentication Segment Traffic WPA Security Guest Wireless Voice Service (Future) Telephony Segment Traffic High priority VSC 3 VoIP Gateway Property Management System Internet
Veteran Leadership Team Barry Fougere - President & CEO A.T. Kearney, EDS, Cambridge Strategic Mgt Group  Pierre Trudeau - Co-founder & CTO Eicon Technology, Touch Tones Digital Jukebox  Larry Whitman - CFO WaveSmith Networks, Shiva  John O’Hara – VP, Engineering WaveSmith Networks, New Oak Communications  Marty Falaro – VP, Sales & Business Development Altiga Networks, Cisco, PictureTel  Roger Sands – VP, Enterprise Development Accton Technoloogies, US Robotics  Ken MacLure – VP, Operations Narad Networks, Cascade  Michael Welts – VP, Marketing Unisphere, Castle Networks, Bay Networks
Demonstration Setup MSC-3300 MAP-330 5.8GHz WDS Secure Link In Charge CNMS 192.168.2.20 RADIUS/Apache 192.168.2.99 WIN2K Server 192.168.2.100 Gateway Router Internet
