Net-X was originally established in 1992 as InterwebNetz serving small businesses on the East Coast, and has since grown into a national company through acquisitions. It provides networking design, installation, and support services to CASPAIN across five sites in Virginia and Norfolk. The proposed solution includes routers, switches, firewalls, access points, servers, workstations, phones, and management software. Net-X recommends a 3-year renewable warranty contract for $53,706 to cover all hardware. The total cost of the project is $669,250.

2.  Established in 1992 as InterwebNetz
◦ SOHO only
◦ Grew to handle most of the East Coast and
Northeast
 Took over Sync in summer 2009
◦ Took a focus on all types of network from SOHO to
Enterprise
 Renamed NetX in 2010
◦ Grew a to a national company after acquiring
networking leaders in the Midwest and West coast

3.  Nick Ford – President
 Christian Van Alstyne – IP Scheme &
LAN Design
 Andrew Duke – Senior Network
Engineer
 Christian Pangilinan – Voice Technician
 Laron Goffigan – Wireless/Voice
Specialist
 Tyler Jaundoo – Lead Virtual Designer
 Mike Bishop – Security Administrator

15. Site VLAN Host
172. X. X. X
SITE
VIRGINIA BEACH
VB1 172.17.1.1 /24
VB2 172.17.1.2 /24
GAMERS - VLAN 10 172.17.10.0 /24
MANGER - VLAN 20 172.17.20.0 /24
ADMINS - VLAN 30 172.17.30.0 /24
PHONES- VLAN 40 172.17.40.0 /24
SERVERS - VLAN 50 172.17.50.0 /24
NORFOLK
NOR1 172.18.1.1 /24
NOR2 172.18.1.2 /24
GAMERS - VLAN 10 172.18.10.0 /24
MANGER - VLAN 20 172.18.20.0 /24

17.  Cisco 2851
 Cisco 2951
 Cisco 3845

18.  Wire-speed performance for concurrent services
such as security and voice, an advanced services to
multiple T1/E1/xDSL WAN rates
 Enhanced investment protection through increased
performance and modularity
 Intrusion Prevention as well as Cisco IOS Firewall
support and many more essential security features

19.  Delivers highly secure data, voice, video, and
application services for small offices.
 Fully integrated power distribution to modules
supporting Power over Ethernet (PoE)
 Integrated threat control using Cisco IOS Firewall,
Cisco IOS Zone-Based Firewall, Cisco IOS IPS, and
Cisco IOS Content Filtering
 High-density packet voice DSP module, optimized
for voice and video support

20.  Wire-speed performance for concurrent services
such as security and voice , and advanced services
at full T3/E3 rates
 Enhanced investment protection through increased
performance and modularity
 Antivirus defense support through Network
Admission Control (NAC)
 Optional Layer 2 switching support with Power over
Ethernet (POE)

21.  Cisco 3750v2

22.  Cisco 3750 is the next-generation energy-efficient
Layer 3 Fast Ethernet stackable switches
 Allowed to manage power consumption of network
infrastructure and network-attached devices,
thereby reducing their energy costs
 Preconfigurable with a Cisco IOS® Software release
at the time of ordering
 Compatible with Cisco Redundant Power System
(RPS) 2300

23.  Offers enhanced functionality for businesses that
require advanced communications capabilities.
 7941G is a full-featured handset that provides two
programmable line and feature buttons along with
four interactive softkeys
 A high-resolution, graphical 4-bit grayscale display
(320 x 222)

24.  Alienware 51
 Dell M2400
 Dell Power Edge R905 Server

25.  Alienware Area 51 provide the ultimate gaming
experience
 Provided with the most powerful graphics in the
world. ATI CrossFireXTM and
NVIDIA® SLI® graphics deliver higher frame rates at
HD resolutions

26.  Graphics solution and 256MB dedicated graphics
memory for demanding tasks
 At only 4.77 pounds making it the lightest
workstation to date
 Multi-tasking with the latest generation
Intel® Core™2 Duo processors
 Wireless capabilities include Wi-Fi, Mobile
Broadband7, Bluetooth® and Omni directional
Antenna

27.  R905 was designed for architected performance
and streamlined virtualization deployment.
 Dell’s server and storage platforms are engineered
for virtual environments to help provide an optimal
balance between performance and cost.
 Dell’s strategy is to help you manage your
infrastructure with the tools you already
have, which is why we work with industry leaders to
deliver an integrated solution for managing
physical and virtual infrastructures.

28.  Cisco Aironet 1250
 These enterprise-class access points offer
combined data rates of up to 600 Mbps to provide
users with mobile access to high-bandwidth data,
voice, and video applications.
 ClientLink Technology to improve the end-user
experience for 802.11a/g and 802.11n clients

29.  Cisco IOS Firewall
• IOS Firewall segments the network for compliance requirements
in transparent or routed environments, wireless to wired
segments
 Cisco ASA 5510
• The Cisco ASA 5510 Security Appliance provides High-
Performance firewall and VPN services with five Integrated
10/100 Fast Ethernet Interfaces.

31.  We will be using Cisco ASA5510-CSC20 bundle to
prevent virtually all known malicious code from
entering and propagating across the network.
 We will be using the Symantec Endpoint Protection
software to protect the business resources from a
variety of known and unknown threats. This
software monitors the network in real-time, so
threats can be detected and deleted before they
cause harm.

33.  Our network will provide coverage over
a/b/g/n frequencies
 WPA2 Encryption and EAP-TLS will be used to
provide maximum security from potential
threats
 We will implement the 802.11 architecture for
maximized security

34. Network
Management

35.  Each site will be equipped with one server
running NetCrunch6 network management
software.

36.  This software will collect SNMP, Syslog,
Windows Event Logs, and more to notify
managers of events within the network.
 NetCrunch6 is also able to analyze and
display network data in graphical format for
easy interpretation by managers.

38.  Net-X will provide CASPAIN with Smart Net
warranty services
 Warranty services will provides maximum
coverage in all fields
 Net-X recommends a 3 year renewable
contract warranty agreement
 Included is 8x5xNBD hardware replacement
 Cisco Technical Assistance Center support
 24/7 Access to cisco.com
 Ongoing updates as well bugs and software
updates and patches

39.  24/7 Direct hardware support
 Remote Access - Provides service and
support for your Dell laptop while you are
traveling.
 Accidental Damage Protection repairs or
replaces accidentally damaged systems
 Keep Your Hard Drive helps you retain
control of sensitive data
 Online Support Fast Responses to certified
technicians in 2 minutes or less guaranteed

40. Cost Per Site:
Virginia Beach $193,781.10
Norfolk $166,928.30
Chesapeake $98,618.40
Portsmouth $82,265.40
Suffolk $64,579.30
Labor $9,371.50
Warranty (3 years) $53,706.00
Total Cost: $669,250.00

41.  If you have any questions please do not
hesitate to ask at this time
