The document discusses penetration testing (pentesting) for mobile applications, covering both Android and iOS architectures, data storage, traffic capturing, and application reversal techniques. It highlights critical vulnerabilities and risks in mobile applications, including malware threats and insecure data handling practices. Best practices for securing mobile applications are also provided, such as encrypting data and avoiding hardcoding sensitive information.

1. Pentesting Mobile Applications
Prashant Verma
Security Consultant & Competency Lead

2. Target Mobile

3. Types of Mobile Applications
• Browser based Mobile Applications (WAP)
• Installed Applications

4. Android architecture
• DVM
• ~JVM
• dex files
• Sandboxing
• Apps run
with its user,
group
• Apps may
share data, if
run with same
user

5. iOS Architecture
 Core OS & Core Services –
Low level file handling, network
Sockets etc. Include Technologies
like Core Foundation, CFNetwork,
SQLite etc
Written in C
 Media Layer – Supports audio and
2D and 3D video
 Cocoa Touch Layer – Provides
infrastructure used by applications.
Contains the UIKit Framework
Written in Objective-C

6. Pentesting Mobile Applications
• Reading Stored Data
• Capturing Requests
• Reversing the Application Package
• Platform Specific Issues

7. Reading Stored Data

8. Reading Stored Data
• Mobile applications store data in local
memory of handset
• This data is stored by developers in files
locally and is used by the application
• Look out for the persistent stored
information in the mobiles for sensitive
data (pwd, keys, account details etc.)
• This may involve hacking / jailbreaking the
phone

9. Reading Stored Data: Android
• Android Applications store the data in
directory /data/data/[PACKAGE_NAME]
• sharedpreferences
• Context.MODE_PRIVATE
• Context.MODE_WORLD_READABLE
• Context.MODE_WORLD_WRITEABLE
• Files may be stored using the filesystem at
/data/data/[PACKAGE_NAME]/files/filenam
• Storage in the SQLite databases
• Can be read using SQLite browser

10. Reading Stored Data: Android
• Demo 1
• Let us see how the stored data can be
accessed in an Android phone
• <Connect the phone via USB debugging
mode, show the storage directory in Android,
browser to show the different storage formats,
read the files, read the databases using
SQLite browser>

11. Reading Stored Data: iOS
• iPhone too stores the data in the
application directory
• /private/var/mobile/Applications/ApplicationID/
• Plist files ..can be read using
• Property List Editor
• plutil
• Sqlite databases
• Same procedure to read as Android

12. Capturing the Traffic

13. Capturing The Traffic
• Capture HTTP requests & responses
• Carry out Parameter Manipulation and
other attacks
• Set up a proxy in between the server & the
client to intercept.
• This can be achieved by
• Proxying the real devices
• Proxying the emulators

14. Capturing The Traffic : Android
• Proxying Android Device
• Root your phone 
• Install Superuser
• Install a proxy tool like ProxyDroid or Auto Proxy
• Set the proxy IP address & port no.
• Emulators can also be proxied

15. Capturing The Traffic

16. Capturing The Traffic : iPhones
• Proxying Apple iPhone / iPAD
• Setup a proxy ipaddress and port for the wifi
connection
• Entire traffic is routed through this proxy
• Proxying Simulators
• Open the Simulator within the xcode IDE
• GUI option to set proxy ipaddress and port

17. Capturing The Traffic: iPhones
• Demo 2
• Let us now see how to proxy an iPhone
device to capture the traffic
• <connect the phone & laptop to the wifi, setup
laptop as proxy for the phone, show the
captured traffic in the laptop, demonstrate the
parameter manipulation attack>

18. Capturing The Traffic: iPhones

19. Reversing the Application Package

20. Reversing the Application Package
• Reverse Engineer the application logic and
source code
• Identify the flaws in the code base to
exploit them
• Look for sensitive data like passwords,
encryption algorithms and keys
• Nokia jar files & Android apk packages are
easy to reverse

21. Reversing the Android Package
• Two step process
• apk to dex conversion
• dex to java conversion

22. Reversing the Android Package
• Demo 3
• Let us now see how to reverse engineer an
Android application package
• <Take a .apk Android Package, demonstrate
the reversing process to convert it to readable
java files, show the sample vulnerability in the
java file>

23. Platform Specific Issues

24. Platform Specific Issues
• Android the prime target of malwares
• ZITMO
• Android Market had malicious apps
• Apple iOS
• iOS URL Schemes
• Screenshot Caching issue

25. Malware: ZITMO
• User logs in to his banking application
• ZITMO, in background, listens to the incoming
SMS
• ZITMO obtains the SMS
• ZITMO forwards the SMS to the attacker’s web
address
• SMS contains the one time password (the
second factor of the two factor authentication)
• Attacker can use it to bypass the two factor
authentication

26. Android Market
• Recently, Google Android Market was in
news for distributing Malicious Applications
• Google had to remove these infected
applications from the Market
• Lack of Proper Vetting Process by Google,
as opposed to Apple App Store
• Experts have advised Google for
establishing the same

27. iOS URL Schemes
• iOS URL schemes
• URL schemes are used for web server
connections, without additional parameters
• This involves sending the required parameters
in the URL, which makes it a vulnerable
implementation
• Sometimes username-password is also send
this way
• Prefer other implementations, if easily
possible without URL schemes

28. iOS Screenshot Caching
• Whenever users press the Home button
while using an Application
• iOS takes screenshot of application
• This is required for the zoom-out animation while
leaving the app
• This same screenshot used to simulate zoom-in
animation while returning to app
• This is store in the device memory and can be
used by anyone having access to rooted device
• Black out the View whenever Home button
is pressed while using the application.

29. Securing Mobile Applications

30. Security Best Practices
• Do not hardcode sensitive information
• Do not store sensitive information locally
• If required to be stored, do not store at
easily readable location like memory card.
• Encrypt the stored data
• Implement SSL
• Protect the webserver against application
layer attacks

31. Security Best Practices
• Sanitize inputs, use prepared statements
(protection against client side injection)
• Implement Proper Authentication. Do not
use UDID or other hardware IDs for auth.
• Prefer encryption over encoding or
obfuscation

32. OWASP Mobile Top 10 Risks

33. References
• Android official documentation
• Apple iOS code guide
• OWASP Mobile Top 10 Project
• Palisade – The application security
magazine
• GoatDroid Project
• iGoat Project

34. Thank you
Prashant Verma
Security Consultant & Competency Lead
verma.prashantkumar@gmail.com
