Today, Wind Turbine OEMS utilize design load cases for the design and certification of wind turbines. These load cases are applied to ensure that turbines operate in a stochastic environment for at least 20 years.
However, reliability analysis should not stop at the design stage. Once a turbine is commissioned, consequent reliability analysis should also be conducted in order to understand how long a turbine will truly last at an installed location with the exposed environmental conditions.
