Weather barrier paper is applied to sheathing to serve as an air barrier and waterproof backing underneath sidings. Attic ventilation allows water vapor and heat to escape through soffit vents, gable vents, and ridge vents, helping to keep houses cooler. A bulldozer is a tracked tractor equipped with a metal blade used to move large amounts of soil and rubble during construction projects.

1. BSCI
4 -21-2009

2. Weather barrier paper is applied to sheathing and serves as an air barrier

to reduce leaking air through joints and as a waterproofing backing
underneath sidings.

3. Attic ventilation is used not only to allow water vapor to escape, but to prevent solar
heat buildup conducted through the roof and roof sheathing by drawing air through
the spaces keeping the house cooler.
Soffit Vent- also known as Frieze vent.
Gable Vent
Covered with slot covered insect
screening allows airflow in rafters while
keeping out insects

4. Ridge Vent - located at highest point of
Roof Turbine roof, prevent snow and rain from
entering by blown wind

7. Roman Arch
Key Stone

8. Gothic Arch

9. Running Bond- consist of all stretchers
Flemish Bond- row of headers and stretchers

10. Sailors Rowlock Stretchers

11. Soldiers

12. Rowlocks

13. Headers

14. Modular Brick
3 5/8 x 7 5/8 x 2 1/4
7 5/8 “
3 5/8 “

15. Standard Brick
3 5/8 x 8 x 2 1/4
8”
3 5/8 “

16. A bulldozer is a tracked tractor equipped with a metal blade used to push large
amounts of soil rubble and gravel during construction. Typically known as an
engineering vehicle.

17. Wood Boards
Brick exterior

18. EIFS- exterior Insulation Finish System- synthetic stucco

19. Stone exterior - Random Rubble

20. Emergency and escape openings must meet a maximum height of 44” and opening
Size of 5.7 square feet . Any number of combinations are required for an opening to be
Effective with height no less than 24” and opening no less than 20”. This window meets
Code due to a height above finished floor of 26” and an opening of 35 ½”.
Window requirements
35 ½”
26 “ AFF

21. Wood Framed Stairs
Tread 10”
Riser 5 ½”
Meets code because it stays within dimensions
Tread min. 4”- 7”
Riser Min 11”

22. Control Joints - ¼” depth slab weaken by a recess joint in hopes to relieve stress
that the concrete will crack to that joint.
Control Joint
Control Joint
Crack to Control Joint

23. Isolation Joint
Isolation joint is a padding of concrete underneath
a point of pressure so that the slab will not crack.
Column is isolated from the slab

24. Concrete Masonry units (CMU) primarily serve as foundations, retaining walls,
and fireplaces. They are larger solid units than brick and are less expensive.
Actual dimensions 7 5/8” x 7 5/8” x 15 5/8” : Nominal 8” x 8” x 16”
1 CMU = 3 Modular Bricks

25. 10” CMU- both ends plain

26. 4” CMU- both ends plain

27. -6 panel wood Stile and Rail door
Top Rail
Panels
stile
Lock Rail
Bottom Rail

28. Transom- glass glazing Sidelight- Glass Glazing
 
above door on sides of door
Transom
Sidelights Sidelights

29. Flush Door- usually interior but can be exterior hollow

or solid core door

30. Power pole w/ transformer- local transmission Service Head- two hot wires and one
lines carry direct current voltage converted w/ Neutral wire carrying current enter
A transformer to alternating current. House through a service head.

31. Service Panel- also called
panel board holds and
Meter- after leaving service head current
controls circuits throughout
Travels down to the meter base which holds
the house with a disconnect
and measures power usage.
switch and a man breaker.

32. Duplex receptacle- the circuits( branches of electrical service)

travel to GFI also known as Duplex receptacle which are normally
located in kitchens which hold most of appliance electricity.

33. Anchor Bolt Sill Plate

34. Floor Joist


35. Stringer Subflooring
 

36. Sole plate Stud
 
Stud Wall

37. Top Plate Ceiling Joist
 
Ceiling Joist
Ceiling Joist

38. Rafters

39. Sheathing

40. Engineering vehicle used to load and move around dirt, gravel and other materials
another machine and/or to a location.

41. Gypsum Board is a building material known as drywall
that is made of gypsum plaster placed between two sheets
of paper that is then kiln dried.

42. A component of the forced air system used to move heat and air through ducts to all
Rooms through a process called convection.
Advantage: allows the ability to filter air and control humidity
while heating and cooling.
Disadvantage: Relatively noisy and controls bulky ducts
Air Handling Unit- absorbs direct Compressor- condenses air and rejects heat
Expansion and supplies air to ducts.

43. Any material that is added to the perimeter of a building to slow down the conduction
of heat flow referred to as thermal insulation. Most critical spaces are the walls and
Ceiling.
Batt/ Blanket- wedge in between
Framing

44. Lintels are steel or concrete angles placed above window and door openings to
Support opening span. Typically reinforced brick or block lintel or precast concrete.
Concrete Lintel

45. Concave Mortar Joint- 3/8”thick, tooled, public education building,
Type M Mortar- High Strength Exterior

46. Flush Joint- trowled, 3/8 ” thick, exterior,Type M Morta

47. OSB- a softwood made of long strand-like wood particle that are compresses and glued
into three to five layers. OSB is generally stronger because of the length and compression
of the strands and is stiffer than veneered panels. Used as Sheathing.

48. Lavatory
Washing area that flushes waste out to the building drain and
down to building sewer
1 ½” -2” pipe

49. Water closet
Any room that has a toilet ; toilets are the only fixture that uses cold water

50. Manufactured Tub during rough in
Plumbing vent
Plumbing vent is apart of the Drain Waste Vent
System(DWV) that allows the escape of sewer
gases contained by p-traps.

51. Drop In sink

52. Veneer-thin slices of wood glued onto
Five core panels to produce plywood.
Manufactured wood.
4’ x 8’ sheet Plywood

53. Found only in attics and reflect up to 97% of
heat stored in attics. Since most of the heat in
Homes escapes and enters through the attic,
the radiant barrier acts much like a form of
Insulation.

54. The deformation on the surface help it
To bond tightly to concrete.
This rebar is ½ in diameter. It
Is referred to as a #4 rebar.

55. Gutter- allows for rain

and melted snow to
be collected to from
roofing to prevent
moisture and water
damage.

56. Downspout- collects

water from gutter to
drain away from the
house.

57. Splashblock- usually

made of precast
concrete that allow
control of water
drainage flowing
from downspout and
away from the
building.

58. Underlayment- 15-30

pound building felt
protects building from
precipitation before
the roofing is applied.
Easily installed and is
“dried in”

59. Clay tiles


60. Wood shingles
Shingles- small units applied in overlaying layers
with staggered vertical joints.

61. Preformed Metal roofing –common thin sheets of aluminum or galvanized steel
( usually common in commercial work, green or blue) is long-lasting and can be
recycled after it is replaced. All metal panel roofing is preformed and requires no
equipment for installation.

62. Gable roof Gambrel roof


63. Hip roof

64. Mansard roof


65. Ridge- level of roof intersection at its

highest point.

66. Valley- the sloping intersection of two roof

planes where water runs toward it

67. Eave- lowest horizontal edge of the low side

of a sloping roof

68. Rake- usually on

gable roofs; sloping
corner of a roof
(upward fascia)

69. Fascia- board that run around the eave of a

building along the edge

70. Soffit-undersurface of

a horizontal rafter that
Forms at triangular shape
in connection with the
eave

71. Random Ashlar


72. Random Rubble

73. Coursed Rubble

74. Vapor Retarder-placed on the warm in winter side;
determines and helps block the amount of
dew or condensation that seeps through insulation.

75. Weep hole-allows water that seeps behind building through mortar to drain out
so that the wood framing of building will not rot. Efflorescence is salt found around
Weep holes from hard water evaporation.

76. Form of reinforcing laid in a grid pattern
that supports concrete.
It is supported by high chairs
And is also known as wire mesh.

77. Sliding- single hung window on its side;

tracks in the frame hold the sash on two
opposite sides

78. Double hung window- has two
moving sashes that slide up and down
its tracks in the frame of the window
